NEC MultiSync MD301C4, MultiSync MD212MC, MultiSync MD213MC, MultiSync MD213MG, MultiSync MD304MC Specifications

Medical Desktop

NEC MultiSync® MD Series

High-bright LCD displays ideal for color and grayscale medical imaging applications

Designed exclusively for the demanding needs of radiology, medical imaging,
PACS and mammography, the NEC MultiSync MD Series embodies the
precision, high performance and intelligence you’d expect from a world
leader in display technology. The series includes 2-, 3- and 4-Megapixel (MP)
color displays, and a 3MP grayscale display.

Benefits you’ll realize from these medically certified displays include:

• Outstanding image quality for both color and grayscale images due to
NEC’s UA-SFT and SA-SFT liquid crystal technologies, which offers high

brightness without compromising contrast or viewing

• Color displays that feature brightness and contrast performance rivaling
grayscale displays

• Grayscale displays feature long life, high resolution and high brightness

• Fewer screen uniformity errors and automatic compensation for differences

in color/grayscale and luminance across the entire screen because of digital
uniformity correction on select models

• The MD212MC and MD213MC feature an integrated, tri-stimulus (three-color)
sensor that receives more light information than standard (brightness only)
sensors and, therefore, is extremely accurate and stable

• Each MD Series monitor comes calibrated out of the box to the DICOM
grayscale display function for luminance and every model features an
integrated front sensor or a backlight sensor

• More nely detailed, high-denition rendering of color images and crisper
display of even the most delicate shadings and color differences due to RGB
lookup tables (LUTs) as large as 14-bit

• Every display includes GammaCompMD QA software to ensure consistent
image quality by simple local or network interface for conformance to the
DICOM standard, while providing an easy-to-use QA environment for medical

imaging

Model Size Type

MD212MC 21.3” 2MP Color

MD213MC 21.3” 3MP Color

MD213MG 21.3” 3MP Grayscale

MD304MC 30” 4MP Color
MD301C4 30” 4MP Color

With ColorCompWithout ColorComp

www.necdisplay.com

Achieve complete color and brightness uniformity.

By nature, LCD panels contain uniformity errors,
which are visible as slightly brighter or darker
areas on the screen. To combat this inherent
trait, each MD Series display is individually
characterized during production and digital
uniformity correction is applied. This technology,
called ColorComp, reduces the non-uniformity
to virtually unnoticeable levels and applies a
digital correction to each pixel on the screen
to compensate for differences in color and
luminance.

For consistent image

quality the built in

front sensor constantly
monitors and maintains
brightness for optimal

DICOM GSDF calibration

and for non-assisted
conformance,
calibration and reporting
functions,the sensor is
capable of measuring
monitor brightness,
white-point and contrast
response.

Model

Display
Viewable Size Image
Pixel Pitch
Pixels Per Inch
Brightness (typical)

Contrast Ratio (typical)
Viewing Angle (typical)

Response Time (typical)

Panel Bit Depth

Inputs

Image Stabilization

Native Resolution

Additional Features

Voltage Rating

Power Consumption (typical)
On
Power Savings Mode

Dimensions (WxHxD)
Net (with stand)

Net (without stand)

MultiSync MD212MC

21.3"

0.27mm
94
400 cd/m2 calibrated /
850 cd/m2 max

1050:1
176° Vert., 176° Hor.

(88U/88D/88L/88R)

@ CR>10

Rapid Response™ 20ms

Gray-to-Gray
12-bit internal LUTs,
displays 16.7 million colors
out of 68.5 billion color
palette and 256 shades of
gray out of 4096

DVI-D, DVI-I and VGA 15-

pin D-sub

Tri-stimulus front sensor

1600 x 1200 @ 60 Hz
landscape / 1200 x 1600 @
60 Hz portrait

DICOM GSDF calibrated,

ColorComp image unifor­mity correction, ambi­ent light compensation,
response time overdrive,

GammaComp MD QA

software, pivot, tilt, swivel,

height-adjustable stand (5.9
in./150mm), analog/digital

CableComp™

AC 100-120V /
AC 220-240V

100W

2W

18.4 x 17.1-23 x 12 in. /

467.8 x 434.3-584.3 x
306mm

18.4 x 14.2 x 4.4 in. /

467.8 x 361.6 x 110.7mm

MultiSync MD213MC

21.3”

0.21mm
120

400 cd/m2 calibrated /
800 cd/m2 max

750:1
176° Vert., 176° Hor.

(88U/88D/88L/88R)

@ CR>10
Rapid Response™12ms
Gray-to-Gray
12-bit internal LUTs,
displays 16.7 million colors
out of 68.5 billion color pal­ette and up to 1024 shades
of gray out of 4096

DVI-D and DVI-I

Tri-stimulus front sensor

2048 x 1536 @ 60 Hz
landscape / 1536 x 2048 @
60 Hz portrait

DICOM GSDF calibrated,

ColorComp image unifor­mity correction, ambi­ent light compensation,
response time overdrive,

GammaComp MD QA

software, pivot, tilt, swivel,

height-adjustable stand (5.9
in./150mm), analog/digital

CableComp™

AC 100-120V /
AC 220-240V

105W

2W

18. x 17.1-23 x 12 in. /

467.8 x 434.3-584.3 x
306mm

18.4 x 14.2 x 4.4 in. /

467.8 x 361.6 x 110.7mm

MultiSync MD213MG

21.3”

0.21mm
120

400 cd/m2 calibrated /

1450 cd/m2 max
900:1
176° Vert., 176° Hor.

(88U/88D/88L/88R)

@ CR>10
Rapid Response™ 12ms
Gray-to-Gray
12-bit internal LUTs,
displays up to 1024 shades
of gray out of 4096

DVI-D and DVI-I

Front sensor

2048 x 1536 @ 60 Hz
landscape / 1536 x 2048 @
60 Hz portrait

DICOM GSDF calibrated,

ColorComp image unifor­mity correction, ambi­ent light compensation,
response time overdrive,

GammaComp MD QA

software, pivot, tilt, swivel,

height-adjustable stand (5.9
in./150mm), analog/digital

CableComp™

AC 100-120V /
AC 220-240V

100W

2W

18. x 17.1-23 x 12 in. /

467.8 x 434.3-584.3 x
306mm

18.4 x 14.2 x 4.4 in. /

467.8 x 361.6 x 110.7mm

MultiSync MD304MC

29.8”

0.251mm
101

200 cd/m2 calibrated /
350 cd/m2 max

1000:1
178° Vert., 178° Hor.

(89U/89D/89L/89R)

@ CR>10
Rapid Response™ 6ms
Gray-to-Gray
12-bit internal LUTs,
displays 16.7 million colors
out of 68.5 billion color
palette and 256 shades of
gray out of 4096

DVI-D (HDCP), DVI-I

Backlight sensor

2560 x 1600 @ 60 Hz
landscape / 1600 x 2560 @
60 Hz portrait

DICOM GSDF calibrated,

ColorComp image unifor­mity correction, ambi­ent light compensation,
response time overdrive,

GammaComp MD QA

software, pivot, tilt, swivel,

height-adjustable stand (5.9
in./150mm), analog/digital

CableComp™

AC 100-120V /
AC 220-240V

143W

1.3W

27.1 x 18.8-26.3 x 13.5 in./

687.3 x 478.6-668.6 x

342.8mm

27.1 x 17.6 x 5 in./

687.3 x 446.8 x 126mm

MultiSync MD301C4

29.8”

0.251mm
101

250 cd/m2 calibrated /
350 cd/m2 max

1000:1
178° Vert., 178° Hor.

(89U/89D/89L/89R)

@ CR>10

Rapid Response™ 7ms

Gray-to-Gray
14-bit internal LUTs,
displays 1.07 billion colors
out of 4.3 trillion or 1024
shades of gray out of 4096
(10-bit DisplayPort input);

16.7 million colors out of

1.05 billion color palette or
256 shades of gray out of
4096 (DVI-D input)

DisplayPort (2), DVI-D (2)

Backlight sensor

2560 x 1600 @ 60 Hz
landscape / 1600 x 2560 @
60 Hz portrait

DICOM GSDF calibrated,

Digital Uniformity Correc­tion, ambient light compen­sation, response time over-

drive, GammaCompMD QA

software, pivot, tilt, swivel,

height-adjustable stand (5.9
in./150mm), analog/digital

CableComp™

AC 100-120V /
AC 220-240V

155W (w/o USB active)

1.7W (w/o USB active)

27.1 x 18.4-24.3 x 11.9 in./

687.3 x 467.6-617.2 x

302.3mm

27.1 x 17.6 x 4.9 in./

687.3 x 447 x 124.5mm

Net Weight
(with stand)
(without stand)

VESA Hole Configuration
Specifications

Environmental Conditions
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude

Safety Standards

Limited Warranty*

23.5 lbs. / 10.7 kg

16.5 lbs. / 7.5 kg

100 x 100mm

5-35° C / 41-95° F

30-80%
3000m / 9842 ft.

-10-60° C / 14-140° F
10-85%
12,192m / 40,000 ft.

UL/C-UL, UL60601-1, Gost/

PCT, PSB, CCC, FCC Class

B/Canadian DOC, C-tick,
MPR II / MPR III, VCCI (class

2), JIS C 61000-3-2, static

electricity guideline, low

emission guideline, TUV-

Ergonomie, US Mercury
regulations, WEEE, RoHS,

SASO, Energy Star 4.0 Tier
2, JEITA VOC Guideline.
J-Moss, FDA 510k, CE-MDD
Class 1, AAPM-TG18, CEL
Grade 2

5 years parts and labor,
including Advanced

Overnight Exchange

* Backlight usage limited to 30,000 hours at 400 cd/m2 or less (MD304MC/MD301C4: 20,000 hours at 200 cd/m2 or less)

MultiSync is a registered trademark, and ColorComp is a trademark
of NEC Display Solutions. All other brand or product names are
trademarks or registered trademarks of their respective holders.

Product specications subject to change. 4/11 Ver. 3.

©2011 NEC Display Solutions of America, Inc. All rights reserved.

23.5 lbs. / 10.7 kg

16.5 lbs. / 7.5 kg

100 x 100mm

5-35° C / 41-95° F

30-80%
3000m / 9842 ft.

-10-60° C / 14-140° F
10-85%
12,192m / 40,000 ft.

UL/C-UL, UL60601-1, Gost/

PCT, PSB, CCC, FCC Class

B/Canadian DOC, C-tick,
MPR II / MPR III, VCCI
(class 2), JIS C 61000-3-2,

static electricity guideline,
low emission guideline, US
Mercury regulations, WEEE,

RoHS, SASO, Energy Star, J­Moss, FDA 510k, CE-MDD,
IRAM, TUV GM, EPEAT,
AAPM-TG-18, DIN V 6868­587 (Germany) CATB, CEL
Grade 3

5 years parts and labor,
including Advanced

Overnight Exchange

23.5 lbs. / 10.7 kg

16.5 lbs. / 7.5 kg

100 x 100mm

5-35° C / 41-95° F

30-80%
3000m / 9842 ft.

-10-60° C / 14-140° F
10-85%
12,192m / 40,000 ft.

UL/C-UL, UL60601-1, Gost/

PCT, PSB, CCC, FCC Class

B/Canadian DOC, C-tick,
MPR II / MPR III, VCCI
(class 2), JIS C 61000-3-2,

static electricity guideline,
low emission guideline,

ISO9241-307, US Mercury

regulations, WEEE, RoHS,

SASO, Energy Star, J-Moss,
FDA 510k, CE-MDD, IRAM,
TUV GM, EPEAT, AAPM­TG-18, DIN V 6868-587
(Germany) CATB, CEL
Grade 1

5 years parts and labor,
including Advanced

Overnight Exchange

NEC Display Solutions

500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE

42 lbs. / 19.2 kg

31.7 lbs. / 14.4 kg

100 x 100mm and
200 x 100mm

5-35° C / 41-95° F

30-80%

3048m / 10,000 ft.

-10-60° C / 14-140° F
10-85%
12,192m / 40,000 ft.

UL/C-UL, UL60601-1, CE,
Gost/PCT, PSB, CCC, TUV
GS, FCC Class B/Canadian
DOC, C-tick, MPR II / MPR
III, VCCI (class 2), JIS C
61000-3-2, static electricity

guideline, low emission

guideline, TUV-Ergonomie,
ISO9241-307, US Mercury

regulations, WEEE, RoHS,

SASO, Energy Star 4.0
Tier 2, GEEA, JEITA VOC
Guideline. J-Moss, Windows
XP, DEN-TORI, FDA 510k,
CEL Grade 3

5 years parts and labor,
including Advanced

Overnight Exchange

41.5 lbs. / 18.8 kg

27.6 lbs. / 12.5 kg

100 x 100mm and
200 x 100mm

5-35° C / 41-95° F

30-80%

3048m / 10,000 ft.

-10-60° C / 14-140° F
10-85%
12,192m / 40,000 ft.

UL/C-UL, UL60601-1, CE,
Gost/PCT, PSB, CCC, TUV
GS, FCC Class B/Canadian
DOC, C-tick, MPR II / MPR
III, TUV-GM, VCCI (class

2), JIS C 61000-3-2, static

electricity guideline, low

emission guideline, TUV­Ergonomie, ISO9241-307,

CE-MDD, US Mercury regu­lations, WEEE, RoHS , CEL,

DIN V 6868-57, AAPM­TG18, JESRA-X0093, CEL
Grade 3

5 years parts and labor,
including Advanced

Overnight Exchange
