NEC MultiSync LCD3735WXM User's Manual
FEDERAL COMMUNICATIONS
COMMISSION (FCC) WARNING
Instruction to Users
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference
to radio and television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures.
- Reorient or relocate the receiving antenna.
- Increase the distance between the equipment
and the receiver.
- Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/
TV technician for help.
Information to Users
The unit is for office equipment use.
Any change or modifications not expressly
approved by the party responsible for compliance
could void the user's authority to operate this
equipment.
DOC NOTICE
This product conforms to Canadian Class B emissions
regulations.
This equipment has been certified to comply with
the limits for a Class B computing device, pursuant
to part 15 of the FCC rules. Only peripherals
(computer input / output devices, terminals, printers
etc.) certified to comply to the Class B limits may
be attached to this computer. Operation with noncertified peripherals is likely to result in interference
to radio and TV reception.
Remarks
To meet FCC requirement, shielded cables are
required to connect the device to a personal
computer or other Class B certified device.
PROPRIETARY NOTICE AND LIABILITY DISCLAIMER
The information disclosed in this document, including all designs and related materials, is the valuable
property of NEC Display Solutions of America, Inc. and/or its licensors, as appropriate, reserve all
patent, copyright and other proprietary rights to this document, including all design, manufacturing,
reproduction, use and sales rights thereto, except to the extent said rights are expressly granted to
others.
The NEC Display Solutions of America, Inc. product(s) discussed in this document are warranted in
accordance with the terms of the Limited Warranty Statement accompanying each product. However,
actual performance of each such product is dependent upon factors such as system configuration,
customer data and operator control. Since implementation by customers of each product may vary,
the suitability of specific product configurations and applications must be determined by the customer
and is not warranted by NEC Display Solutions of America, Inc.
To allow for design and specification improvements, the information in this document is subject to
change at any time without notice. Reproduction of this document or portions thereof without prior
approval of NEC Display Solutions of America, Inc. is prohibited.
DECLARATION OF CONFORMITY
This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions.
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
U.S. Responsible Party: NEC Display Solutions of America, Inc.
Address: 500 Park Blvd, Suite 1100
Tel. No.: (630) 467-3000
Type of Product: Display Monitor
Equipment Classification: Class B Peripheral
Model: MultiSync LCD3735WXM (L375GB)
Itasca, Illinois 60143
We hereby declare that the equipment specified above
conforms to the technical standards as specified in the FCC Rules.
Windows is a registered trademark of Microsoft Corporation. NEC is a registered trademark of NEC
Corporation. All other brands and product names are trademarks or registered trademarks of their
respective owners.
Declaration of the Manufacturer
We hereby certify that the color monitor
MultiSync LCD3735WXM (L375GB)
is in compliance with
Council Directive 73/23/EEC:
Council Directive 89/336/EEC:
and marked with
NEC Display Solutions, Ltd.
Tokyo 108-0023, Japan
Disposing of your old NEC Products
Within the European Union
EU-wide legislation, as implemented in each Member State, requires that waste electrical
and electronic products carrying the mark (left) must be disposed of separately from
normal household waste. This includes monitors and electrical accessories, such as
signal cables or power cords. When you need to dispose of your NEC display products,
please follow the guidance of your local authority, or ask the shop where you purchased
the product, or if applicable, follow any agreements made between yourself and NEC.
The mark on electrical and electronic products only applies to the current European Union
Member States.
– EN 60950-1
– EN 55022
– EN 631000-3-2
– EN 631000-3-3
– EN 55024
4-13-23, Shibaura,
Minato-Ku
Outside the European Union
If you wish to dispose of used electrical and electronic products outside the European
Union, please contact your local authority so as to comply with the correct disposal
method.
IMPORTANT INFORMATION
RISK OF ELECTRIC SHOCK.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert
CAUTION
DO NOT OPEN.
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE BACK COVER.
NO USER - SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment
not expressly approved by the manufacturer could void the user authority to operate this equipment.
CAUTION: TO PREVENT ELECTRIC SHOCK, PLACE THE WIDE BLADE OF THE
PLUG INTO THE WIDE SLOT OF THE POWER OUTLET. FULLY INSERT PLUG INTO OUTLET.
the user to the presence of
uninsulated dangerous voltage
within the product enclosure that
may be of sufficient level to constitute a risk of electric shock to
persons.
The exclamation point within a
triangle is intended to alert the
user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the product.
IMPORTANT:
To aid reporting in case of loss or theft, please
record the monitor model and serial numbers in
the space provided. The numbers are located at
the rear of the monitor.
Model no.:
Serial No.:
IMPORTANT SAFETY PRECAUTIONS
Electricity is used to perform many useful functions, but it can also cause personal injuries and
property damage if improperly handled. This product has been engineered and manufactured with the
highest priority on safety. However, improper use can result in electric shock and / or fire. In order to
prevent potential danger, please observe the following instructions when installing, opening and
cleaning the product. To ensure your safety and prolong the service life of your LCD monitor product,
please read the following precautions carefully before using the product.
· Read instructions - All operating instructions must be read and understood before the product is
operated.
· Keep this manual in a safe place - These safety and operating instructions must be kept in a safe place
for future reference.
· Observe warnings - All warnings on the product and in the instructions must be observed closely
· Follow instructions - All operating instructions must be followed.
· Attachments - Do not use attachments that are not recommended by the manufacturer. Use of
inadequate attachments can result in accidents.
· Entering of objects and liquids - Never insert an object into the product through vents or openings. High
voltage exists in the product, inserting an object can cause electric shock and / or short internal parts.
For the same reason, do not spill water or liquid on the product.
· Servicing - Do not attempt to service the product by yourself. Removing covers can expose you to high
voltage and other dangerous conditions. Request a qualified service person to perform servicing.
· Repair - If any of the following conditions. unplug the power cord from the AC outlet, and request a
qualified service person to perform repairs.
a. When a liquid was spilled on the product or when objects have fallen into the product.
b. When the product has been exposed to rain or water.
IMPORTANT SAFETY PRECAUTIONS (Continued)
· Cleaning - Unplug the power cord from the AC outlet before cleaning the product. Use a damp cloth
to clean the product. Do not use liquid cleaners or aerosol cleaners.
· Water and moisture - Do not use the product near water, such as bathtub, washbasin, kitchen sink
and laundry tub, swimming pool and in a wet basement.
· Stand - Do not place the product on an unstable cart, stand, tripod or table. Placing the product on
an unstable base can cause the product to fall, resulting in serious personal injuries as well as
damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the
manufacturer or sold with the product. When mounting the product on a wall, be sure to follow the
manufacturers instructions. Use only the mounting hardware recommended by themanufacturer.
· When using a cart to transport the product, use utmost care to move the cart. Sudden stops,
excessive force and uneven floor surfaces can cause the product to fall from the cart.
· Ventilation - The vents and other openings in the cabinet are designed for ventilation. Do not cover
or block these vents and openings since insufficient ventilation can cause overheating and / or
shorten the life of the product. Do not place the product on a bed, sofa, rug or other similar surface
since they can block ventilation openings. This product is not designed for built-in installation; do
not place the product in an enclosed place such as a bookcase or rack, unless proper ventilation is
provided or the manufacturers instructions are followed.
· The LCD panel used in this product is made of glass. Therefore, it can break when the product is
dropped or applied with impact. Be careful not to be injured by broken glass pieces in case the LCD
panel breaks.
· Heat sources - Keep the product away from heat sources such as radiators, heaters, stoves and
other heat - generating products (including amplifiers).
· The LCD panel is a very high technology product with many thin-film-transistors, giving you fine
picture details.
Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or
red.
Please note that this does not affect the performance of your product.
· Do not place any heavy object on the power cord. Damage to the cord may cause shock or fire.
· Do not bend, crimp or otherwise damage the power cord.
IMPORTANT SAFETY PRECAUTIONS (Continued)
· If an outside antenna is connected to the LCD equipment, be sure the antenna system is grounded
so as to provide enough protection against voltage surges and built-up static charges. Section
810 of the National Electrical Code provides information with respect to proper grounding of the
mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size
of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
· For added protection to this LCD equipment during a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This
will prevent damage to the equipment due to lightning and power-line surges.
· An outside antenna system should not be located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into such power lines or circuits. When
installing an outside antenna system, extreme care should be taken to keep from touching such
power lines or circuits as contact with them might be fatal.
· Do not place any objects onto the monitor and do not use the monitor outdoors.
· The inside of the fluorescent tube located within the LCD monitor contains mercury. Please follow
the bylaws or rules of your municipality to dispose of the tube properly.
· Do not use monitor in very hot, humid, dusty, or oily areas.
· If monitor or glass is broken, handle with care. Do not come in contact with the liquid crystal.
· Rest your eyes periodically
· Do not move or transport the display with the speaker attached.
English
CONTENTS
Package contents...........................................................E-1
Power cord.....................................................................E-2
Attaching the speakers...................................................E-2
Installing batteries in the remote control....................... E-3
Using the remote control.................................................E-3
Power connection..........................................................E-4
Rear connectors.............................................................E-4
Antenna connection.......................................................E-6
VESA wall mount procedure..........................................E-7
Control options...............................................................E-8
Power management system.........................................E-9
Timing mode..................................................................E-9
OSM function key operation.........................................E-10
Main menu operation....................................................E-10
VIDEO1, VIDEO2, VIDEO3 modes...............................E-10
DVD/HD1 and DVD/HD2 modes...................................E-14
TV modes.....................................................................E-15
DTV modes...................................................................E-15
DVI modes....................................................................E-16
VGA modes..................................................................E-17
Basic operation.............................................................E-19
Specifications...............................................................E-24
Troubleshooting............................................................E-27
Warranty.......................................................................E-28
Package contents
The package contains:
LCD 3735WXM E-1
1. LCD Multi-Function Monitor
3. Setup sheet
Setup sheet
6. 15 Pin D-Sub cable
4. User manual
7.Audio to Audio Cable
with mini jack connector
2. Remote control and AAA Batteries
5. Power cord
8.Speakers and Screws
9. Speaker cables
E-2 LCD 3735WXM
Power cord
· Make sure that the power cord you use is the correct type required for your area.
· This monitor has a universal power supply that allows operation in either 100/120V AC or 220/240V
AC voltage area. No user-adjustment is required.
· First connect the power cord into your monitor power input socket, and then plug the other end into
a 3-pin AC outlet. The power cord may be connected to either a wall socket or the power output
socket on your PC, depending on the type of power cord supplied with your monitor.
· For units to be used at 120V AC:
Use a UL Listed Cord Set consisting of a min. No.18 AWG, Type SVT or SJT three-conductor a
maximum of 10 ft. in length and a parallel blade, grounding type attachment plug rated 10A, 125V.
· For units to be used at 220/240V AC (outside of U.S.):
Use a Cord Set consisting of a min. 0.75mm2, 3G,Type H05VV-F cord and grounding type attachment
plug rated 10-16A, 250V. The cord set should have the appropriate safety approvals for the country
in which the equipment will be installed and marked HAR.
Attaching the speakers
LCD 3735WXM E-3
Installing batteries in the remote control
If the remote control fails to operate the LCD color TV functions, replace the batteries.
1. Open the battery cover.
Slide back and remove the battery cover.
2. Installing the batteries.
Install two size AAA batteries (included).
Align the +, - on the batteries to the +, - on the remote.
3. Close the battery cover.
Replace the battery cover in the dirction of
the arrow and snap it back into place.
Cautions regarding batteries
Improper use of batteries can result in a leakage of chemicals and / or explosion. Be sure to follow the
instructions below.
· Place battery with their terminals corresponding to the (+) and (-) as marked on the remote control. If
inserted in the wrong direction, the batteries could explode or leak, resulting in fires, physical injury, or
stains.
· Different types of batteries have different characteristics. Do not mix batteries of different types.
· Do not mix new and old batteries together. The batteries could explode or leak, resulting in fires,
physical injury, or stains.
· Remove batteries when they become weak.
· The battery supplied with the product may have a shorter life expectancy due to storage conditions.
· If the remote control is not used for an extended period of time, remove the batteries.
In
-
+
Out
Using the remote control
Point the remote control toward the sensor on the front of the monitor when pressing buttons.
Use the remote control within a distance of about 7m/23ft. from the front of the LCD monitor's remote
control sensor and at a horizontal and vertical angle of within 30 degrees within a distance of about 3m/
10ft.
Cautions regarding use of remote control
· Do not expose the remote control to shock.
In addition, do not expose the remote control to liquids, and do not
place in an area with high humidity.
· Do not install or place the remote control under direct sunlight. The
heat may cause deformation of the unit.
· The remote control may not work properly if the remote sensor
window of the LCD unit is under direct sunlight or strong lighting.
In such a case, change the angle of the lighting or LCD, or operate
the remote control closer to the remote sensor window.
E-4 LCD 3735WXM
Power connection
Notes:
· Use provided AC power cord to connect to the wall outlet.
· Always turn the main POWER switch of the LCD off when connecting the AC cord.
· Always unplug the AC cord from the product and power outlet when not using for a long period of time.
Rear connectors
B
C
D
A
LCD 3735WXM E-5
A
B
B1 UP
B2. DOWN
B3. MENU
B4. LEFT
B5. RIGHT
B6. EXIT
B7. INPUT
B8. AUTO ADJUST
B9. POWER
A1
A2
A4 A5
A3
A6
A1*. Speaker out which connected with “RIGHT” speaker output
A2. Power switch
A3. AC inlet
A4. DVI connector
A5. Analog RF input
A6. VGA (D-SUB) connector
A7*. Speaker out which connected with “LEFT” speaker output
* Do not use these connectors unless specified.
C
C4
C1. SPDIF out
C3
C2. AV out (Analog tuner out)
C3. Line out (R/L)
C4 DTV RF input
C5. Audio in-VGA
C6. Audio in-DVI
C7-1.L/R (YPbPr1)
C7-2.L/R (YPbPr2)
C8-1.YPbPr1
C8-2.YPbPr2
B1
B2
B3
B4
B5
B6
B7
B8
B9
C9-1.L/R (Composite video)
C9-2.L/R (S-video)
C10. Video (S-video)
C11. Video (Composite video)
C5
C7-1
C8-1
C9-1
C11
A7
C1
C2
C3
C6
C7-2
C8-2
C9-2
C10
Quick Access (Slide cover to open)
D
D1 HEADPHONES
D2. AUDIO-L
D3. AUDIO-R
D4. S-VIDEO (S-Terminal priority)
D5. VIDEO (Composite video)
D1
D2
D3
D4
D5
E-6 LCD 3735WXM
Antenna connection
ANTENNAS
· Antenna requirements for color television reception are more critical than the antenna requirements
for black and white television reception. For this reason, a good quality outdoor antenna is strongly
recommended.
The following is a brief explanation of the type of connections that are provided with the various
antenna systems.
1. A 75-ohm system is generally a round cable with a F-type
connector that can easily be attached to a terminal without
tools (not supplied).
OUTDOOR ANTENNA CONNECTION
· Connect the outdoor antenna cable lead-in to the analog RF input on the rear of the TV set.
VESA wall mount procedure
LCD 3735WXM E-7
10 Screws (M6)
(Max Depth: 9.5mm)
1.Disconnect all cables.
2.Place monitor face down on a non-abrasive surface
3.Remove the 4 screws connecting the stand to the montor.
4.Lift up the stand to unlatch the upper hooks and remove the stand.
5.Use the 10 screws to attach the arm to the monitor.
Note: The LCD monitor should only be used with an approved arm (e.g. GS mark).
To meet the safety requirements, the monitor must be mounted to an arm which guaranties the
necessary stability under consideration of the weight if the monitor.
E-8 LCD 3735WXM
Control options
Note:
· UP, DOWN, MENU, LEFT, RIGHT, EXIT, INPUT, AUTO ADJUST, and POWER on the main unit have the
same functions as the corresponding buttons on the remote control. Descriptions in this manual are
based on use with the remote control, but will work with the buttons on the monitor.
LCD 3735WXM E-9
Power management system (FOR PC mode only)
The LCD is equipped with a power management function which automatically reduces the power
consumption by using one of three power saving modes when not in use.
LCD STATE
LED
COLOR
POWER Horizontal
SYNC.
ON Green < 170W ON ON
STANDBY Amber < 2W OFF ON
OFF Amber < 2W OFF OFF
Timing mode
Mode Resolution H. Freq. V. Freq.
1 720 x 400 31.469 KHz 70.087 Hz
2 640 x 480 31.469 KHz 59.940 Hz
3 640 x 480 37.860 KHz 72.810 Hz
4 640 x 480 37.500 KHz 75.000 Hz
5 800 x 600 37.880 KHz 60.320 Hz
6 800 x 600 48.080 KHz 72.190 Hz
7 800 x 600 46.875 KHz 75.000 Hz
8 1024 x 768 48.363 KHz 60.004 Hz
9 1024 x 768 56.476 KHz 70.069 Hz
10 1024 x 768 60.023 KHz 75.029 Hz
11 1152 x 864 67.500 KHz 75.000 Hz
12 1280 x 768 47.800 KHz 60.000 Hz
13 1280 x 768 60.289 KHz 74.893 Hz
14 1280 x 1024 63.980 KHz 60.020 Hz
15 1280 x 1024 79.970 KHz 75.020 Hz
16 1360 x 768 47.712 KHz 60.015 Hz
Mode Resolution H. Freq. V. Freq
1 DTV 720 x 576 31.250 KHz 50.000 Hz
2 DTV 720 x 480 31.469 KHz 59.940 Hz
3 DTV 1280 x 720 45.000 KHz 60.000 Hz
4 DTV 1920 x 1080 33.716 KHz 59.940 Hz
PC-VGA / DVI Preset Timing Chart
DVI-HD Preset Timing Chart
Vertical
SYNC.
E-10 LCD 3735WXM
OSM function keys operation:
· Use the "INPUT" function key to change the display mode. There are nine display modes available with
this product: DTV, TV, VIDEO1, VIDEO2, VIDEO3, DVD/HD1, DVD/HD2, VGA, DVI.
Main menu operation:
· Use the menu key to access the menu, and use the "RIGHT" and "LEFT" function keys to select the
desired items (System page for TV & DTV input only. Parent page for TV, VIDEO1,VIDEO2 & VIDEO3
input only. Color page for DVI & VGA input only. Image page, OSM page, Audio page, Setup page, PIP
page for all input types)
· Use the "DOWN" key to enter the sub categories, after the desired item has been selected, use the
"RIGHT" or "LEFT" keys to execute the function or adjust the value.
· When in the OSM menu, press the EXIT key to return one level up of the directory. Pressing the EXIT
key when initial OSM is displayed closes the OSM menu.
VIDEO1, VIDEO2, VIDEO3 modes:
Image Page:
· DV Mode Selects the best setting for Video, Photos, Text, etc. (Standard, Movie, Sport,
Vivid).
· Brightness Adjusts the overall image and background screen brightness.
· Contrast Adjusts the image brightness in relation to the background.
· Sharpness Adjust the image to get as distinct or as soft a picture as is preferred.
· Color Adjusts the intensity.
· Hue Adjusts the hue (tint).
OSM Page:
· Language The OSM menu is available in 3 languages (English, French, Spanish).
· Timeout The OSM control menu will stay on as long as it is use. In the OSM timeout
submenu, the user can select how long the monitor waits after the last touch of a
button to shut off the OSM control menu. Time can be set between 5 to 60 seconds, in 5 second increments.
· H-Position You can choose the horizontal location where the OSM appears on the screen.
· V-Position You can choose the vertical location where the OSM appears on the screen.
· Transparency User could set the transparency level of the OSM.
Audio Page:
· Volume Adjusts the volume level.
· Treble Adjusts the level of the high frequencies.
· Bass Adjusts the level of the low frequencies.
· Balance Adjusts the level of output between right and left speakers.
LCD 3735WXM E-11
Setup Page:
· Closed Caption Select the Closed Caption mode (OFF, CC1, CC2, TT1, TT2)
Closed Captioning
(CCD) Mode
OFF Disable closed caption function.
CC1 1.[Captions] is for the program you are viewing.
CC1, CC2, TT1, TT2 [Captions] is for the program you are viewing.
CC2 2.[Text] is for additional information such as news reports or a TV program guide.This
TT1 3.Text may not be available with every [CC] program.
TT2 4.Closed Captioning and Text modes may vary by region.
· Sleep timer LCD will automatically power down after a user determined length of time. (OFF,
[Text] is for additional information such as news reports or a TV program guide.
information covers the entire screen and viewing the TV program is not possible.
This information covers the entire screen and viewing the TV program is not
possible.
Text may not be available with every [CC] program.
Closed Captioning and Text modes may vary by region.
30, 60, 90, 120 min)
· Noise Reduce Removes the noise in the picture by applying temporal and spatial noise reduction
filters to the video data. There are five levels (OFF, Weak, Medium, Strong, Adaptive)
· AI function Analyzes scenes and automatically adjusts peak brightness according to the
brightness of the images. (When “Standard” or “Movie” is chosen as the DV mode,
the AI function is off.)
· Recall default Allows the user to reset most of the OSM control settings back to the factory
settings.
E-12 LCD 3735WXM
Parent Page:
Parents can block certain types of programming based on the content rating.
· Parent Lock Press "DOWN" key to access parent lock option. Using the number keypads on
your remote control, you must now enter your password. Then the Parent Lock
option can be turned ON or OFF.
Default password is 8888.
· TV rating Select the type of programming to block based on the chart below.
Parents can choose to ALLOW or BLOCK certain types of programming based on
content ratings that may contain the following: Fantasy Violence, Moderate Violence,
Sexual Situations, or Coarse Language, Suggestive Dialog.
TV Parental Guide Ratings Chart
TV-Y All children. The themes and elements in this program are specifically
designed for a very young audience, including children from ages 2 to 6.
TV-Y7 Directed to older children. Themes and elements in this program may include
mild physical or comic violence, or may frighten children under the age of 7.
TV-G General audience. Contains little or no violence, no strong language, and little
or no sexual dialogue or situations.
TV-PG Parental guidance suggested. May contain infrequent coarse language, limited
violence, some suggestive sexual dialogue and situation.
TV-14 Parents strongly cautioned. Contains some material that many parents would
find unsuitable for children under 14 years of age.
May contain intense violence (V), intense sexual situations (S), strong coarse
language (L), or intensely suggestive dialogue (D).
TV-MA Mature audience only. May contain mature themes, indecent language, graphic
violence and explicit sexual content.
LCD 3735WXM E-13
· Movie rating Select the type of programming to block based on the chart below.
Video Parental Guide Ratings Chart
G General audiences. All ages are permitted to watch.
PG Parental guidance suggested. Some material may not be suitable for children.
PG-13 Parents strongly cautioned. Some material may be inappropriate for children under 13.
R Restricted. Under 17 requires an accompanying parent or adult guardian.
NC-17 No one under 17 permitted to watch.
X Adults only.
· Change password This option could allows the user to change the parent lock password
When you are finished making your selection, press "EXIT" on your remote control to
return to normal viewing.
E-14 LCD 3735WXM
PIP Page:
· PIP Mode There are two modes to choose from the PIP window (OFF, PIP, Side by Side ).
· PIP Source
Picture in Picture Source (ü Available / û Unavailable)
DTV TV VIDEO1 VIDEO2 VIDEO3 DVD/HD1 DVD/HD2 VGA DVI
DTV
TV
VIDEO1
VIDEO2
VIDEO3
DVD/HD1
DVD/HD2
VGA
DVI
û û û û û û û û ü
û û û û û û û û ü
û û û û û û û û ü
û û û û û û û û ü
û û û û û û û û ü
û û û û û û û û ü
û û û û û û û û ü
û û û û û û û û ü
ü ü ü ü ü ü ü ü û
· PIP SWAP Swap main picture source and sub picture source.
· Position Select where the PIP window appears on the screen. (PIP only)
There are four locations to choose from "Upper right", "Lower right", "Upper left",
"Lower left"
DVD/HD1 and DVD/HD2 modes:
Setup Page
· Sleep timer LCD will automatically power down after a user determined length of time. (OFF,
30, 60, 90, 120 min)
· Noise Reduce Removes the noise in the picture by applying temporal and spatial noise reduction
filters to the video data. There are five levels. (OFF, Weak, Medium, Strong, Adaptive)
· AI Function Analyzes scenes and automatically adjusts peak brightness according to the
brightness of the images. (When “Standard” or “Movie” is chosen as the DV mode,
the AI function is off.)
· Recall default Allows the user to reset most of the OSM control settings back to the factory
settings.
LCD 3735WXM E-15
Image Page, OSM Page, Audio Page, PIP Page
These functions are the same as they are in video mode.
TV modes:
System Page
· Antenna / CableSelect TV connection type [AIR TV/CATV (FCC)/CATV (IRC)/CATC (HRC)]
(Item selection should be corresponding to country or location)
· Channel SearchAutomatically stores available channels in TV mode.
· Channel Edit Manually add or remove channels from TV mode.
· Favorite Edit Set up to 4 favorite channels for remote control
· Fine Tuning Manually fine tune channels from TV mode.
· Clear Memory Clear TV settings which are stored in the memory.
Image Page , OSM Page , Audio Page , Setup Page , Parent Page , PIP Page
These functions are the same as they are in video mode.
DTV modes:
System Page
DTV Setting
Select YES / NO. When YES is selected the following options appear.
Channel Setup
Using the following item to setup the DTV channels.
· Edit Manually add or remove channels from DTV mode.
· Auto Scan Automatically stores available channels in DTV mode.
· Manual Scan Manually setup available channels in DTV mode.
CC (Close Captioning)
Subtitle setup for DTV
· Font Size There are three font sizes (Default, Small, Large)
· Font Style There are seven styles of fonts (Style 1 to Style 7)
· Font Color There are eight font colors to choose from (Black, White, Red, Green, Blue, Yellow,
Magenta, Cyan) in background or foreground.
· Font Opacity There are four levels of font opacity. (Solid, Transparent, Translucent, Flashing) in
background or foreground.
· Edge Style There are five styles of Edge (None, Raised, Depressed, Uniform, Drop Shadow)
in background or foreground.
· Edge Color There are eight Edge colors to choose from (Black, White,Red, Green, Blue, Yel-
low, Magenta, Cyan) in background or foreground.
E-16 LCD 3735WXM
Setup
· Time zone Select your location time zone.
· EA Emergency Alert, there are two modes (Medium, Low) to turn On / Off.
· About Show the DTV system information.
Password
· Rating Select the type of programming to block.
· Password User could set or change parent lock password and this passwordwill associ-
ate with the password in TV Video setting modes.
Image Page, OSM Page, Audio Page, PIP Page
These functions are the same as they are in video mode.
DVI modes:
Image Page
· Brightness Adjusts the overall image and background screen brightness.
· Contrast Adjusts the image brightness in relation to the background.
Color Page
· Color Temp. There are four modes available: 6500K, 7500K, 9300K, USER
· User R Use the "RIGHT" and "LEFT" keys to increase or decrease the Red level. The
change in color will be shown on the screen and the adjustment level will be
shown by the bars.
· User G Use the "RIGHT" and "LEFT" keys to increase or decrease the Green level. The
change in color will be shown on the screen and the adjustment level will be
shown by the bars.
· User B Use the "RIGHT" and "LEFT" keys to increase or decrease the Blue level. The
change in color will be shown on the screen and the adjustment level will be
shown by the bars.
Setup Page
· DVI Mode There are two DVI modes to choose from. It is recommended to use "DVI-PC" when
connecting to a PC and "DVI-HD" when connecting to a DVD player.
· Back Light Use "RIGHT" and "LEFT" keys to adjust the backlight level
· Sharpness Adjust the image to get as distinct or as soft a picture as is preferred.
· Noise Reduce It could remove the noise in the picture by applying temporal and spatial noise
reduction filters to the video data. There are four level (OFF, Weak, Medium,
Strong ).
· Recall Default Select this function will allow the user to reset the settings back to the factory
settings.
LCD 3735WXM E-17
VGA modes:
Image page
· Brightness Adjusts the overall image and background screen brightness.
· Contrast Adjusts the image brightness in relation to the background.
· H-Size Adjusts the horizontal and vertical position of the picture.
If the "Auto Adjust" function does not give you a satisfactory picture setting,
further tuning can be performed manually using the "H-Size" function.
· Phase Manually adjust the phase if the "Auto Adjust" function does not give you a
satisfactory picture setting.
· H-Position Manually adjust the picture’s horizontal position if the "Auto Adjust" function does
not give you a satisfactory picture setting.
· V-Position Manually adjust the picture’s vertical position if the "Auto Adjust" function does not
give you a satisfactory picture setting.
Setup Page
· Auto Adjust Automatically adjusts the Image Position setting, H-Size settings and fine settings.
(Depending on the type of signal used, Auto Adjust may not fully optimize the
display. Adjust the settings manually to achieve desired level of performance.)
· Back Light Use "LEFT" and "RIGHT" keys to adjust the backlight level
· Sharpness Adjust the image to get as distinct or as soft a picture as is preferred.
· Noise Reduce It could removes the noise in the picture by applying temporal and spatial noise
reduction filters to the video data. There are four level (OFF, Weak, Medium,
Strong).
· Recall Default Allows the user to reset the settings back to the factory settings.
OSM Page, Audio Page, PIP Page
These functions are the same as they are in video mode.
Color Page
This function is the same as it is in DVI mode.
E-18 LCD 3735WXM
Remote control names and functions
LCD 3735WXM E-19
Remote control names and functions
· POWER: Turn the TV LCD ON / OFF
· AI: AI Function
· Red, Green, Yellow, Blue buttons: In TV mode, use these keys to go to one of 4 favorite channels as
determined by the user. In DTV mode, any of these keys will bring up a list of favorite channels as
determined in the DTV channel setup menu.
· EPG: Electronic Program guide
· CCD: Closed Caption Display. For DTV the CCD options are: OFF, CS1, CS2, CS3, CS4, CS5, CS6, CC1,
CC2, CC3, CC4, TT1, TT2, TT3, TT4. For all other inputs the CCD options are OFF/CC1/CC2/TT1/TT2
· DV Mode: Selects brightness settings. There are four choices for TV Mode. Standard / Movie / Sport /
Vivid
· Display: Display the signal information.
Input Select
· VIDEO1: Select composite source
· VIDEO2: Select S-Video source
· VIDEO3: Quick access (Composite or S-Video)
· DVD/HD1: Select YPbPr 1 source
· DVD/HD2: Select YPbPr 2 source
· DTV: Select ATSC / Digital TVsource
· TV: Select NTSC / Analog TV source
· VGA: Select D-SUB source
· DVI: Select DVI source
· Sleep: Turn on the sleep timer (30, 60, 90, 120, OFF)
· CH+: Push to view the next channel
· CH-: Push to view the previous channel
· Vol+: Increase the volume
· Vol-: Decrease the volume
· ASPECT: Select one of four choices for the aspect ratio of the display. (Full Screen / 4:3 / Wide /
Panorama)
PIP Function
· POS: Changes the position of the PIP window
· MODE: Enter and exit PIP mode
· INPUT: Select PIP input source
· SWAP: Swap main picture source and sub picture source
· MENU: Enter the OSM main menu
E-20 LCD 3735WXM
Remote control names and functions (Continued)
· MTS: Select audio program, including "Stereo / Mono" in TV mode. Select different audio language in
DTV mode.
· EXIT: Use "EXIT" key to exit out of the selected component’s menu.
· UP/DOWN/LEFT/RIGHT keys: When not using OSM, use the UP/DOWN keys to change channels(TV,
DTV only), LEFT/RIGHT keys to controls Volume.
When using OSM, use the cursor keys to move the cursor in a program guide or in menu screens.
· Enter: Select or accepts when in OSM or input select menu.
· Number keypads: Press to select a channel.
· CHRTN: Change to the last channel viewed.
Basic operation
Volume (Direct control) or control
1.Press to raise the sound
volume. The control bar of the
indicator increases.
(VOL- / VOL+)
MUTE
2.Press to lower the sound
volume. The control bar of the
indicator decreases.
To mute the sound
1.Press MUTE to temporarily turn
off the sound.
2.Press MUTE to return sound back
to the previous level.
ON / OFF control
LCD 3735WXM E-21
POWER
To turn off the LCD Monitor
Press on the remote control.
To turn the LCD Monitor back on
Press again.
