User's Manual

SpectraView
LCD2180 WideGamut LED

User’s Manual

1-1

Index

Warning, Caution ........................................................................................................................... English-1

Declaration ..................................................................................................................................... English-1

Canadian Department of Communications Compliance Statement .............................................. English-2

Declaration of Conformity .............................................................................................................. English-2

Contents .........................................................................................................................................English-3

Quick Start ..................................................................................................................................... English-4

Controls ..........................................................................................................................................English-6

Recommended use ........................................................................................................................ English-8

Specifications ............................................................................................................................... English-10

Features ....................................................................................................................................... English-11

Troubleshooting............................................................................................................................English-12

Appendix ......................................................................................................................................English-13

Manufacturer’s Recycling and Energy Information.......................................................................English-16

1-2

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT
USE THIS UNIT'S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS
THE PRONGS CAN BE FULLY INSERTED.

REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM

WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE
POWER CORD FROM THE AC OUTLET.DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause
electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.

This symbol alerts the user that important literature concerning the operation and maintenance of this unit
has been included. Therefore, it should be read carefully in order to avoid any problems.

Power Cord Important Information

Caution: Please use the power cord provided with this display in accordance with the table below. If a power cord is not

supplied with this equipment, please contact your supplier. For all other cases, please use a power cord that matches the
AC voltage of the power outlet and has been approved by and complies with the safety standard of your particular country.

Plug Type

Plug Shape Country Voltage

Plug Type

Plug Shape Country Voltage

English

North

America

U.S.A./

Canada

120 230

European

Continental

EU

(except U.K.)

Declaration

Declaration of the Manufacturer

We hereby certify that the colour monitor
SpectraView LCD2180 WideGamut LED (L215GF)
is in compliance with

Council Directive 73/23/EEC:

– EN 60950-1

Council Directive 89/336/EEC:

– EN 55022
– EN 61000-3-2
– EN 61000-3-3
– EN 55024

Windows is a registered trademark of Microsoft Corporation. NEC is a registered trademark of NEC Corporation.
All other brands and product names are trademarks or registered trademarks of their respective owners.
ErgoDesign is a registered trademark of NEC Display Solutions, Ltd. in Austria, Benelux, Denmark, France, Germany, Italy,
Norway, Spain, Sweden, U.K.
NaViSet is a trademark of NEC Display Solutions Europe GmbH in the countries of EU and Switzerland.

and marked with

NEC Display Solutions, Ltd.

4-13-23, Shibaura,

Minato-Ku

Tokyo 108-0023, Japan

English-1

1-3

Canadian Department of Communications Compliance
Statement

DOC: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.

C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to CAN/CSA C22.2 No. 60950-1.

FCC Information

1. Use the attached specified cables with the SpectraView LCD2180 WideGamut LED (L215GF) colour monitor so as not
to interfere with radio and television reception.

(1) Please use the supplied power cord or equivalent to ensure FCC compliance.

(2) Please use the supplied shielded video signal cable, DVI-D to DVI-D cable.

Use of other cables and adapters may cause interference with radio and television reception.

2. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult your dealer or an experienced radio/TV technician for help.

If necessary, the user should contact the dealer or an experienced radio/television technician for additional
suggestions. The user may find the following booklet, prepared by the Federal Communications Commission, helpful:
“How to Identify and Resolve Radio-TV Interference Problems.” This booklet is available from the U.S. Government
Printing Office, Washington, D.C., 20402, Stock No. 004-000-00345-4.

Declaration of Conformity

This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.

U.S. Responsible Party: NEC Display Solutions of America, Inc.
Address: 500 Park Blvd, Suite 1100

Tel. No.: [phone]

Type of Product: Display Monitor

Equipment Classification: Class B Peripheral

Model: SpectraView LCD2180 WideGamut LED (L215GF)

We hereby declare that the equipment specified above conforms

to the technical standards as specified in the FCC Rules.

Itasca, Illinois 60143

English-2

1-4

Contents

Your new NEC LCD monitor box* should contain the following:

• SpectraView LCD2180 WideGamut LED monitor with tilt stand

• Power Cord (North America and European Continental)

• Video Signal Cable (DVI-D to DVI-D cable)

• User’s Manual

• CD-ROM

• Cable Cover

Power Cord

English

Cable Cover

User’s Manual DVI-D to DVI-D cable CD-ROM

Remember to save your original box and packing material to transport or ship the monitor.

*

English-3

1-5

Quick Start

To attach the LCD monitor to your system, follow these instructions:

1. Turn off the power to your computer.

2. Connect the DVI signal cable to the connector of the display card in your

system (Figure A.1). Tighten all screws.

3. Connect the DVI signal cable to the connector on the back of the monitor

(Figure C.1).

NOTE: Incorrect cable connections may cause irregular operation, damage to

4. Connect one end of the power cord to the AC inlet on the back of the monitor

NOTE: Please refer to Caution section (Power Cord Important Information) of this manual for proper selection of AC power

5. The Vacation Switch on the left side of the monitor must be turned on. Turn on the monitor with the front power button

NOTE: The Vacation Switch is a true on/off switch. If this switch is on the OFF position, the monitor cannot be turned on

NOTE: If you have any problems, please refer to the Troubleshooting section of this User’s Manual.

the display and LCD module components and may shorten the lifespan
of the module.

Collect cables and keep them in the stand with attached cable cover. The cable
cover can be attached on the front or back side of Tilt Stand (Figure C.1, C.2).

Please check Tilt when you manage cables.

and the other end to the power outlet (Figure C.1).

cord.

(Figure D.1) and the computer.

using the front button. DO NOT switch on/off repeatedly.

Figure A.1

INPUT1

Figure C.1

INPUT2

Vacation

Switch

Figure C.2

Power Button

Figure D.1

English-4
