NEC MobilePro 900
Release Notes
Congratulations on purchasing an NEC MobilePro 900™ Handheld PC. Before
using your MobilePro 900, please read the following important information. This
information includes:
! Installing the NEC USB Synchronization (Sync) drivers from the NEC
MobilePro 900 Application and Driver CD
! Connecting a device to the USB port on the MobilePro 900
! Connecting an optional headphone to the MobilePro 900
! Opening WESTTEK™ JETCET™ PRINT Help
! Installing BSQUARE
®
bUSEFUL™ Backup and bFAX™ applications
! Installing wireless LAN (WLAN) Co mpactFlash™ (CF) drivers.
Installing the NEC USB Sync Drivers
NEC USB Sync drivers are required to recognize the NEC MobilePro 900 when
the MobilePro is connected to the host PC via a USB cable. The NEC USB Sync
drivers come on the NEC MobilePro 900 Application and Driver CD.
Use the following procedure to install the drivers on the ho st/companion PC.
Note The following procedure replaces the section “Loading USB Files” in
Chapter 1 of the NEC MobilePro 900 User’s Guide.
1. Insert the NEC MobilePro 900 Application and Driver CD in the
CD-ROM drive of your host PC.
! If auto-insert is enabled on your host PC, the CE Setup menu
appears.
! If auto-insert is not enabled, go to Start, Run, and browse for the
CD-ROM drive.
2. Select “P900 Drivers” from the displayed menu.
3. Follow the on-screen instructions to complete the driver installation.
2 NEC MobilePro 900 Release Notes
4. Connect the USB PC Link cable from the MobilePro 900 to the host
PC. Microsoft Windows now det ects the new hardware (U SB device).
5. Click Next to install the USB drivers. The installation prompts you for
the
wceusbsh.sys file.
6. Browse to the appropriate directory on the Application and Driver CD
for your operating system (Win2K USB Driver or WinXP USB Driver).
7. Select the wceusbsh.sys file and click “Open” to complete the driver
installation.
Connecting a Device to the USB Port
Before connecting a USB device to the MobilePro 900, install a ferrite core on
the USB cable. Installation of the ferrite core on the USB cable red uces rad io
interference when you use a USB device connected to the MobilePro 900. Ferrite
cores ship with the MobilePro 900.
Note The USB PC Connect cable that ships with the MobilePro 900
comes with a ferrite core installed. You do not need to install a ferrite core on
this cable.
Install a ferrite core on any other USB cable you connect to the MobilePro,
including the cable attached to a USB mouse or USB keyboard.
To reduce radio interference when using a USB
device, be sure the USB cable has a ferrite core installed.
Use the following procedure to install the ferrite core.
1. Locate one of the ferrite cores that ships with the MobilePro 900.
Ferrite Core
NEC MobilePro 900 Release Notes 3
2. Place the USB cable in the center of the core. Close the core and press
tightly to secure the core tabs in the fasteners.
Installing the Cable in the Core
Note
Connect the cable end with the ferrite core to the M obilePro USB port.
4 NEC MobilePro 900 Release Notes
Connecting an Optional Headphone
Before connecting an optional headphone to the MobilePro 900, install a ferrite
core on the connector end of the headphone cable. Installation of the ferrite core
on the headphone cable reduces radio interference when you connect the
headphone to the MobilePro 900 earphone/microphone jack. Ferrite cores ship
with the MobilePro 900.
To install the ferrite core, follow the procedure for installing the core on the USB
cable (see the previous section, “Connecting a Device to the USB Port”). The
procedure for installing the ferrite core is the same for both cables.
Opening JETCET PRINT Help
If you cannot open JETCET PRINT Help in the MobilePro 900 Help, open the
Help program directly within the JETCET PRINT program.
Installing bUSEFUL Backup and bFAX Files
When you install BSQUARE bUSEFUL Backup and bFAX applications from
the MobilePro 900 Application and Driver CD, the installation program prompts
you to overwrite some files that already exist on the MobilePro 900. Click “Yes”
to overwrite the files.
Installing WLAN CF Drivers
During the installation of the WLAN CF drivers from the MobilePro 900
Application and Driver CD, the installation program displays an “Unsupported
Device Type” message. When prompted, choose “Yes” to install drivers that
support the MobilePro 900.
