Nec MOBILEPRO 790 User Guide

NEC MobilePro 790

Release Notes

Congratulations on purchasing the NEC MobilePro Professional PC Companion powered by the Microsoft

This document contains important information and helpful tips for maximizing the use of your MobilePro system. Be sure to read the contents of this document before using your MobilePro.

Windows® CE Handheld PC2000 software.

Contents

Pre-Installed Software................................................................................................................1

Documentation for Pre-Installed Software .........................................................................1

Using WorldTALK on a LAN............................................................................................1

Printing With bPrint Software ............................................................................................2

AC Adapter Cable Storage.........................................................................................................2

Disconnecting During ActiveSync Synchronization..................................................................2

Using the FlashROM Configuration Utility...............................................................................3

Recovering Applications after a Full Reset ........................................................................3

Adding Applications to FlashROM ...........................................................................................3

Removing Applications from FlashROM..................................................................................4

Pre-Installed Software

A variety of software applications are preinstalled your MobilePro. These applications let you take full advantage of your MobilePro capabilities. The software applications shipped on your MobilePro include the following and are subject to change without notice.

bFax by BSQUARE

bBackup Plus by BSQUARE

bPrint by BSQUARE

ConnectForce by Ruksun

HPC NetProfile by Phatware

Primer by Ansyr

WorldTalk by Tenik

RDP Client by Microsoft

Documentation for Pre-Installed Software

Please view the help files of the software as your documentation. More information may also be available on the manufacturers’ web pages, when available.

Using WorldTALK on a LAN

The default setting for WorldTALK is to attempt to autodial your ISP when it is launched. LAN users do not dial out to an ISP, so LAN users must change the settings to prevent autodial on startup. Follow the next steps to disable autodial.

Launch WorldTALK from the Start Menu.

NEC MobilePro 790 Release Notes 1

Select Options from the View pull-down menu.

Click on the “Auto Dial” tab on the Options window.

Uncheck the “Use Autodial” check box.

Click OK.

Close WorldTALK and do a soft reset of the MobilePro.

Printing With bPrint Software

One advantage of the bFax software on your MobilePro 790 is the ability to print faxes through the infrared port at the 115.2Kbps setting, using bFax’s bPrint software. Infrared is the only supported printing device. If you do not have a printer that supports Infrared printing, you can place the file you wish to print on your desktop or notebook computer and print through your default printing device.

Follow these steps to change your Infrared printer port setting:

Tap Start, Settings, Control Panel.

Tap on MobilePro Settings icon.

Use the arrow buttons to access the IrDA tab.

Select 115.2Kbps.

Tap the OK button, then Tap OK again.

Save all your data and soft reset the system.

AC Adapter Cable Storage

In order to ensure the proper operation of your AC adapter cable, and to avoid damaging the adapter, NEC recommends that you not bend the AC cable more than 60 degrees where it connects to the adapter. When storing your AC adapter, use a large enough container that the cable does not bend more than 60 degrees.

Disconnecting During ActiveSync Synchronization

When copying files from your MobilePro to your PC using ActiveSync, do not

turn off your MobilePro or PC.

remove the serial cable from the serial port of either system.

double tap the connection icon in the status area of the task bar and tap the [Disconnect] button.

In the event your serial cable should accidentally disconnect from the MobilePro or the PC during synchronization, you may experience difficulty getting a connection between the two systems. If this happens, if may be necessary to soft reset your MobilePro to restore it to proper operation. Please refer to your user’s guide for instructions on resetting the MobilePro.

2 NEC MobilePro 790 Release Notes
