NEC MD21GS-3MP User Manual

QUICK REFERENCE GUIDE

MD21GS-3MP

Index

Warning .................................................................................................................... 1

Contents.................................................................................................................3

Quick Start............................................................................................................. 4

Controls .................................................................................................................. 6

Recommended Use .................................................................................................7

Specifications ........................................................................................................ 9

References............................................................................................................ 10

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE
THIS UNIT'S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS
CAN BE FULLY INSERTED.
REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM

Power Cord Important Information

CAUTION: Please use the power cord provided with this display in accordance with the table

below. If a power cord is not supplied with this equipment, please contact your supplier. For all
other cases, please use a power cord that matches the AC voltage of the power outlet and has been
approved by and complies with the safety standard of your particular country.

WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE POWER
CORD FROM THE AC OUTLET. DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This

symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause

electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.

This symbol alerts the user that important literature concerning the operation and maintenance of this
unit has been included. Therefore, it should be read carefully in order to avoid any problems.

epyTgulP

epahSgulP

yrtnuoC .A.S.U/ adanaCUEanihCnapaJ

egatloV 021032022001

aciremAhtroN

edarGlatipsoH

latnenitnoCnaeporuEesenihC

esenapaJ

Intended Use

The MD21GS-3MP grayscale display is intended to be used for displaying and viewing of digital
images for diagnosis by trained physicians. To guarantee the display performance as specified, it
must only be used in conjunction with NEC recommended controller boards as specified in the
Installation and Maintenance manual for this model.

European Customers

Unpacking, Installation and calibration of this display should only be done by authorized and
trained personnel. Any installation done by a non-authorized person is done under his own risk
and we accept no responsibility in any device malfunctioning.

Medical Imaging

The NEC MD21GS-3MP is designed for 3-megapixel (1536 x 2048) grayscale medical imaging. This
display comes fully tuned with a setting for gamma correction that complies with the DICOM Part 14
Standard.

1

)ylnotekraMesenapaJrof(

MD21GS3MPquickstart.p65 7/22/04, 9:52 AM1

Canadian Department of Communications Compliance Statement

DOC: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations.
C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to
CAN/CSA C22.2 No. 601.1.

FCC Information

1. Use the attached specified cables with the MD21GS-3MP grayscale display so as not to interfere
with radio and television reception.

(A) Please use the supplied power cord or equivalent to ensure FCC compliance.

(B) Please use the supplied shielded video signal cable, DVI-D to DVI-D cable.

Use of other cables and adapters may cause interference with radio and television reception.

2. This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy, and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

• Consult your dealer or an experienced radio/TV technician for help.

If necessary, the user should contact the dealer or an experienced radio/television technician for
additional suggestions. The user may find the following booklet, prepared by the Federal Communications
Commission, helpful: ”How to Identify and Resolve Radio-TV Interference Problems.“ This booklet is
available from the U.S. Government Printing Office, Washington, D.C., 20402, Stock No. 004-000­00345-4.

Declaration of the Manufacturer

We hereby certify that the grayscale monitor

MD21GS-3MP

is in compliance with Council Directive

93/42/EEC:

– EN 60601-1
– EN 60601-1-2
– EN 61000-3-2

– EN 61000-3-3
and marked with CE.
NEC-Mitsubishi Electric Visual, Systems Corporation, 4-13-23, Shibaura, Minato-Ku, Tokyo 108­0023, Japan
