NEC LCD2070WNX User Manual

MultiSync LCD2070WNX

User’s Manual

Index

Warning, Caution ........................................................................................................................ English-1

Declaration .................................................................................................................................. English-1

Canadian Department of Communications Compliance Statement ........................................... English-2

Declaration of Conformity ........................................................................................................... English-2

Contents ...................................................................................................................................... English-3

Quick Start .................................................................................................................................. English-4

Controls ....................................................................................................................................... English-8

Recommended use ..................................................................................................................... English-11

Specifications .............................................................................................................................. English-13

Features ...................................................................................................................................... English-14

Troubleshooting........................................................................................................................... English-15

Appendix ..................................................................................................................................... English-15

TCO’03 ........................................................................................................................................ English-16

Manufacturer’s Recycling and Energy Information...................................................................... English-17

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT
USE THIS UNIT'S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS
THE PRONGS CAN BE FULLY INSERTED.

REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM

WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE
POWER CORD FROM THE AC OUTLET.DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause
electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.

This symbol alerts the user that important literature concerning the operation and maintenance of this unit
has been included. Therefore, it should be read carefully in order to avoid any problems.

Caution:

When operating the MultiSync LCD2070WNX with a 220-240V AC power source in Europe, use the power cord provided with
the monitor.

In the UK, a BS approved power cord with a moulded plug has a Black (five Amps) fuse installed for use with this equipment.
If a power cord is not supplied with this equipment please contact your supplier.

When operating the MultiSync LCD2070WNX with a 220-240V AC power source in Australia, use the power cord provided
with the monitor. If a power cord is not supplied with this equipment please contact your supplier.

For all other cases, use a power cord that matches the AC voltage of the power outlet and has been approved by and
complies with the safety standard of your particular country.

English

Declaration

Declaration of the Manufacturer

We hereby certify that the colour monitor
MultiSync LCD2070WNX (L205GX) is in
compliance with

Council Directive 73/23/EEC:

– EN 60950-1

Council Directive 89/336/EEC:

– EN 55022
– EN 61000-3-2
– EN 61000-3-3
– EN 55024

Windows is a registered trademark of Microsoft Corporation. NEC is a registered trademark of NEC Corporation. ENERGY STAR is a
U.S. registered trademark.
OmniColor is a registered trademark of NEC Display Solutions Europe GmbH in the countries of EU and Switzerland.
ErgoDesign is a registered trademark of NEC Display Solutions, Ltd. in Austria, Benelux, Denmark, France, Germany, Italy, Norway,
Spain, Sweden, U.K.
NaViSet is a trademark of NEC Display Solutions Europe GmbH in the countries of EU and Switzerland.
MultiSync is a registered trademark of NEC Display Solutions, Ltd. in the countries of U.K., Italy, Austria, Netherlands, Switzerland,
Sweden, Spain, Denmark, Germany, Norway and Finland.
All other brands and product names are trademarks or registered trademarks of their respective owners.
As an ENERGY STAR® Partner, NEC Display Solutions of America, Inc. has determined that this product meets the ENERGY STAR guidelines
for energy efficiency. The ENERGY STAR emblem does not represent EPA endorsement of any product or service.

and marked with

NEC Display Solutions, Ltd.

4-13-23, Shibaura,

Minato-Ku

Tokyo 108-0023, Japan

English-1

Canadian Department of Communications Compliance Statement

DOC: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.

C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to CAN/CSA C22.2 No. 60950-1.

FCC Information

1. Use the attached specified cables with the MultiSync LCD2070WNX (L205GX) colour monitor so as not to interfere
with radio and television reception.

(1) The power supply cord you use must have been approved by and comply with the safety standards of U.S.A.,

and meet the following condition.

Power supply cord Non shield type, 3-conductor
Length 2.0 m
Plug shape

U.S.A

(2) Please use the supplied shielded video signal cable and USB cable with ferrite cores. Use of other cables and

adapters may cause interference with radio and television reception.

2. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult your dealer or an experienced radio/TV technician for help.

If necessary, the user should contact the dealer or an experienced radio/television technician for additional
suggestions. The user may find the following booklet, prepared by the Federal Communications Commission, helpful:
“How to Identify and Resolve Radio-TV Interference Problems.” This booklet is available from the U.S. Government
Printing Office, Washington, D.C., 20402, Stock No. 004-000-00345-4.

Declaration of Conformity

This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.

U.S. Responsible Party: NEC Display Solutions of America, Inc.
Address: 500 Park Blvd, Suite 1100

Itasca, Illinois 60143

Tel. No.: [phone]

Type of Product: Display Monitor

Equipment Classification: Class B Peripheral

Model: MultiSync LCD2070WNX (L205GX)

We hereby declare that the equipment specified above conforms

to the technical standards as specified in the FCC Rules.

English-2

Contents

Your new NEC MultiSync LCD monitor box* should contain the following:

• MultiSync LCD2070WNX monitor with tilt/swivel adjust stand

• Power Cord

• Video Signal Cable (15-pin mini D-SUB male to 15-pin mini D-SUB male)

• Video Signal Cable (DVI-D to DVI-D)

• USB Cable

• User’s Manual

• Cable Cover

• CD ROM (includes complete User’s Manual in PDF format).

To see the User’s Manual, Acrobat Reader 4.0 must be installed on your PC.

USB Cable

English

Power Cord

User’s Manual 15-pin mini D-SUB male to

15-pin mini D-SUB male

NOTE: This monitor can be equipped

with optional loudspeakers:
“MultiSync Sound bar”. Please ask
your dealer or check our website
http://www.nec-display-solutions.com

Cable Cover

CD-ROM

DVI-D to DVI-D

*

Remember to save your original box and packing material to transport or ship the monitor.

English-3

Quick Start

To attach the MultiSync LCD monitor to your system, follow these instructions:

1. Turn off the power to your computer.

2. For the PC or MAC with DVI digital output: Connect the DVI signal cable to the connector of the display card in your

system (Figure A.1). Tighten all screws.

For the PC with Analog output: Connect the 15-pin mini D-SUB signal cable to the connector of the display card in your
system (Figure A.2). Tighten all screws.

For the MAC: Connect the Macintosh cable adapter to the computer, then attach the 15-pin mini D-SUB signal cable to
the Macintosh cable adapter (Figure B.1). Tighten all screws.

DVI signal cable

Figure A.1 Figure B.1

NOTE: Some Macintosh systems do not require a Macintosh cable adapter.

3. Remove the connector cover (Figure C.1).

4. Place hands on each side of the monitor to tilt the LCD panel 30 degrees angles and lift up to the highest position

(Figure C.2).

5. Connect all cables to the appropriate connectors (Figure C.2).

NOTE: If connecting both DVI and D-Sub cables, the DVI cable must be connected along side the rib on the power cord

side (Figure C.2).

6. Place the connector cover onto the back cabinet (Figure C.3).

Figure A.2

Macintosh
Cable Adapter
(not included)

Figure C.1

DVI Cable

Figure C.3

Figure C.2

7. For successful cable management, place the cables in this order into the cable management: Power cord and DVI cable

(Figure C.4).

8. Place DVI cable and power cord into the specific hooks indicated in Figure C.4.

9. Place the D-Sub and the USB cable into the specific hooks indicated in Figure C.4.

10. Make sure all cables are resting flat against the stand (Figure C.4).
