NEC LCD1530V User Manual

MultiSync LCD1530V

User’s Manual

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN
OR MOISTURE. ALSO, DO NOT USE THIS UNIT’S POLARIZED PLUG WITH AN
EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS
CAN BE FULLY INSERTED.
REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE
COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK • DO NOT OPEN

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER

CAUTION

Caution:

When operating the MultiSync LCD1530V with a 126-240V AC power source in
Europe except UK, use the power cord provided with the monitor.

In the UK, a BS approved power cord with a moulded plug has a Black (five Amps)
fuse installed for use with this equipment. If a power cord is not supplied with this
equipment please contact your supplier.

When operating the MultiSync LCD1530V with a 126-240V AC power source in
Australia, use the power cord provided with the monitor.

For all other cases, use a power cord that matches the AC voltage of the power
outlet and has been approved by and complies with the safety standard of your
particular country.

(OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.

This symbol warns user that uninsulated voltage within the unit may have
sufficient magnitude to cause electric shock. Therefore, it is dangerous to make
any kind of contact with any part inside this unit.

This symbol alerts the user that important literature concerning the operation
and maintenance of this unit has been included. Therefore, it should be read
carefully in order to avoid any problems.

English

ENERGYSTAR is a U.S. trademark.

As an ENERGYSTAR® Partner, NEC-Mitsubishi Electronics Display of America, Inc. has
determined that this product meets the ENERGYSTAR guidelines for energy efficiency. The
ENERGYSTA R emblem does not represent EPA endorsement of any product or service.

IBM PC/XT/AT, PS/2, MCGA, VGA, 8514/A and XGA are registered trademarks of
International Business Machines Corporation.
Apple and Macintosh are registered trademarks of Apple Computer Inc.
Microsoft and Windows are registered trademarks of the Microsoft Corporation.
NEC is a registered trademark of NEC Corporation.
All other trademarks or registered trademarks are property of their respective owners.

English-1

Declaration

Declaration of the Manufacturer

We hereby certify that the colour monitor
MultiSync LCD1530V (LA-15R01)

are in compliance with

Council Directive 73/23/EEC:

Council Directive 89/336/EEC:

and marked with

- EN 60950

- EN 55022

- EN 61000-3-2

- EN 61000-3-3

- EN 55024

NEC-Mitsubishi Electric Visual Systems, Corp.

686-1, NISHIOI OI-MACHI

ASHIGARAKAMI-GUN

KANAGAWA 258-8533, JAPAN

Power consumption of
the monitor is less than
3 W when in power­saving mode.

English-2

For the Customer to use in U.S.A. or Canada

Canadian Department of Communications
Compliance Statement

DOC: This Class B digital apparatus meets all requirements of the

Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du
Règlement sur le matériel brouiller du Canada.

C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety
Regulations according to C.S.A. C22.2 #950.
Ce produit porte la marque ‘C-UL’ et se conforme aux règlements de
sûrele Canadiens selon CAN/CSA C22.2 No. 950.

FCC Information

1. Use the attached specified cables with the MultiSync LCD1530V
colour monitor so as not to interfere with radio and television
reception.

(1)The power supply cord you use must have been approved by and

comply with the safety standards of U.S.A., and meet the following
condition.

Power supply cord Non shield type, 3-conductor
Length 1.8 m
Plug shape

English

(2)Shielded video signal cable.

Use of other cables and adapters may cause interference with
radio and television reception.

English-3

2. This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy, and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

- Consult your dealer or an experienced radio/TV technician for help.
If necessary, the user should contact the dealer or an experienced

radio/television technician for additional suggestions. The user may
find the following booklet, prepared by the Federal Communications
Commission, helpful: “How to Identify and Resolve Radio-TV
Interference Problems.” This booklet is available from the U.S.
Government Printing Office, Washington, D.C., 20402,
Stock No. 004-000-00345-4.

Declaration of Conformity

This device complies with Part 15 of FCC Rules. Operation is subject to the following two
conditions. (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.

U.S. Responsible party: NEC-Mitsubishi Electronics

Display of America, Inc.

Address: 1250 N. Arlington Heights Road

Itasca, Illinois 60143-1248

Tel. No.: [phone]

Type of Product: Computer Monitor

Equipment Classification: Class B Peripheral

Models: MultiSync LCD1530V

We hereby declare that the equipment specified above conforms to the technical

standards as specified in the FCC Rules.

English-4

Contents

Your new NEC-Mitsubishi MultiSync LCD monitor box* should contain
the following:

• MultiSync LCD1530V

• Power Cord

• Video Signal Cable

• User’s Manual

• CD-ROM includes complete User‘s Manual in PDF format and

Windows related files (Inf file and color profile). To see the complete
User‘s Manual, Acrobat Reader 4.0 must be installed on your PC.

monitor with tilt base

English

* Remember to save your original box and packing material to transport
or ship the monitor.

English-5

Quick Start

To attach the MultiSync LCD monitor to your system, follow these
instructions:

1. Turn off the power to your computer.

2. For the PC: Connect the 15-pin mini D-SUB of the appropriate
signal cable to the connector of the display card in your system
(Figure A.1). Tighten all screws.
For the Mac: Connect the MultiSync LCD1530V Macintosh cable
adapter to the computer (Figure B.1). Attach the 15-pin mini D-SUB
end of the appropriate signal cable to the MultiSync LCD1530V
Macintosh cable adapter (Figure B.1). Tighten all screws.

Remove connector cover and cable cover on back of monitor
(Figure E.1).

3. Connect the 15-pin mini D-SUB of the video signal cable to the
appropriate connector on the back of the monitor (Figure C.1).

NOTE: Incorrect cable connections may result in irregular

operation, damage display quality/components of LCD
module and/or shorten the module’s life.

4. Connect one end of the power cord to the MultiSync LCD Series
monitor and the other end to the power outlet. Place the video signal
cable and AC power cord under the clips. (Figure C.1).
Replace connector cover and cable cover. (Figure E.1)

NOTE: Adjust the position of the cable under the clips to avoid

damage for cable or monitor.

5. Turn on the monitor (Figure D.1) and the computer.

6. To complete the setup of your MultiSync LCD monitor, use the
following OSM controls:

• Auto Adjust Contrast

• Auto Adjust

Refer to the Controls section of this User’s Manual for a full description
of these OSM controls.

NOTE: If you have any problems,please refer to the

Troubleshooting section of this User’s Manual.

NOTE: For easy removal of the cable cover or signal cable, place

the monitor face down. (Figure R.2)

English-6

15-pin
mini D-SUB

Mac Adapter
(not included)

English

15-pin
mini D-SUB

Figure A.1

Power Switch

Signal
Cable

AC Power Cord

1. Cables pass through in this hole.

2. Connect each connector

Power Outlet

Figure B.1

Clip

Figure C.1

To Computer

Figure D.1

English-7

Marking area

B

C

A

D

Push

I. Cable Cover

How to remove this cover.
A. Push marking area
B. Slide to up side
C. Remove

Figure E.1

Marking area

II. Connector Cover

How to remove this cover.
D. Push under side
E. Remove

English-8

Tilt

Grasp both sides of the monitor screen
with your hands and adjust the tilt as
desired (Figure TS.1).

Remove Monitor Stand
for Mounting

To prepare the monitor
for alternate mounting
purposes:

1. Remove the connector
cover, hinge cover and
cable cover.
(Figure R.1)

2. Disconnect all cables.

3. Place monitor face
down on a non­abrasive surface.
(Place the screen on a
32 mm platform so that
hole of stand match to
screw location) (Figure R.2).

4. Remove the 4 screws
connecting the monitor to the
stand and lift off the stand
assembly (Figure R.2) the
monitor is now ready for
mounting in an alternate
manner.

5. Connect the AC cord and
signal cable to the back of the
monitor.

6. Reverse this process to
reattach stand.

32mm

Figure TS.1

Push

Figure R.1

Figure R.2

Screws

English

Push

English-9

Controls

OSM (On-Screen-Manager) Controls

The OSM controls on the front of the monitor function as follows:
To access OSM press any of the control buttons ( , , , ) or the
PROCEED button

Control

Main Menu

Sub-Menu

EXIT

CONTROL /

CONTROL /

PROCEED

RESET

The currently
highlighted
control to
factory setting.

NOTE: When RESET is pressed, a warning window will appear

Exits the OSM controls.

Moves the highlighted
area up/down to select
one of the controls.

Moves the highlighted
area left/right to select
control menus.

Has no function.

Resets all the controls
within the highlighted
menu.

allowing you to cancel the reset function.

Exits to the OSM controls
main menu.

Moves the highlighted area
up/down to select one of the
controls.

Moves the bar left/right to
increase or decrease the
adjustment.

Activates Auto Adjust and all
RESET functions.

Resets the highlighted control.

Brightness/Contrast Controls

BRIGHTNESS

Adjusts the overall image and background screen
brightness.

CONTRAST

Adjusts the image brightness in relation to the
background.

AUTO ADJUST CONTRAST

Adjusts the image displayed for non-standard video
inputs.

English-10

OSM LOCK OUT

The OSM LOCK OUT control completely locks out
access to all OSM control functions. When attempting
to activate OSM controls while in the LOCK OUT mode,
a screen will appear indicating that OSM controls are
locked out.

• To enter the LOCK OUT mode, simultaneously press
the PROCEED and
will appear.

• To activate the LOCK OUT function, simultaneously
press and hold down the PROCEED and
The OSM window will disappear within seconds and
the LOCK OUT function will be activated.

• To deactivate the LOCK OUT mode, simultaneously
press the PROCEED and

Auto Adjust

Automatically adjusts the Image Position, the H. Size
and Fine setting.

Position Controls

H. POSITION

Controls Horizontal Image Position within the display
area of the LCD.

English

button. The LOCK OUT window

button.

button.

V. POSITION

Controls Vertical Image Position within the display area
of the LCD.

AUTO

Automatically sets the Horizontal and Vertical Image
Position within the display area of the LCD.

Image Adjust Controls

H. SIZE

Adjusts the horizontal size by increasing or decreasing
this setting.

English-11

FINE

Improves focus, clarity and image stability by increasing
or decreasing this setting.

Automatically adjusts the H. Size and Fine setting.

Color Control System

Five color presets select the desired color setting. Each
color setting is adjusted at the factory.

R,G,B: Increases or decreases Red, Green or Blue
color depending upon which is selected. The change in
color will appear on screen and the direction (increase
or decrease) will be shown by the bars.

Tools

OSM H POS.

OSM V POS.

You can choose where you would like the OSM control
window to appear on your screen. Selecting OSM
Location allows you to manually adjust the position of
the OSM control menu left, right, up or down.

ALL RESET

Selecting ALL RESET allows you to reset all OSM
control settings back to the factory settings. Individual
settings can be reset by highlighting the control to be
used and pressing the RESET button.

Information 1

Indicates the current display resolution and frequency
setting of the monitor.

Information 2

Indicates the Model Name, Serial Number and URL.

Resolution Notifier: While the display is capable of other resolutions
(as with all flat panel displays), it is a fixed matrix of pixels and best
used at its native resolution – 1024 x 768. For further information,
please refer to your display card or system manual.

English-12

Recommended Use

Safety Precautions and Maintenance

FOR OPTIMUM PERFORMANCE, PLEASE NOTE

THE FOLLOWING WHEN SETTING UP AND

USING THE MULTISYNC LCD COLOR MONITOR:

• DO NOT OPEN THE MONITOR. There are no user serviceable parts

inside and opening or removing covers may expose you to dangerous
shock hazards or other risks. Refer all servicing to qualified service
personnel.

• Do not spill any liquids into the cabinet or use your monitor near water.

• Do not insert objects of any kind into the cabinet slots, as they may

touch dangerous voltage points, which can be harmful or fatal or may
cause electric shock, fire or equipment failure.

• Do not place any heavy objects on the power cord. Damage to the cord
may cause shock or fire.

• Do not place this product on a sloping or unstable cart, stand or table, as
the monitor may fall, causing serious damage to the monitor.

• When operating the MultiSync LCD monitor with its AC 126-240V power
supply, use a power supply cord that matches the power supply voltage
of the AC power outlet being used. The power supply cord you use must
have been approved by and comply with the safety standards of your
country. (Type H05VV-F should be used in UK.)

• Do not place any objects onto the monitor and do not use the monitor
outdoors.

• The inside of the flourescent tube located within the LCD monitor
contains mercury.
Please follow the bylaws or rules of your municipality to dispose of the
tube properly.

• In UK, use a BS-approved power cord with molded plug having a black
(5A)fuse installed for use with this monitor. If a power cord is not
supplied with this monitor, please contact your supplier.

English

Immediately unplug your monitor from the wall outlet and refer servicing to
qualified service personnel under the following conditions:

• When the power supply cord or plug is damaged.

• If liquid has been spilled, or objects have fallen into the monitor.

• If the monitor has been exposed to rain or water.

• If the monitor has been dropped or the cabinet damaged.

English-13

• If the monitor does not operate normally by following operating
instructions.

• Do not bend power cord.

• Do not use monitor in high temperatured, humid, dusty, or oily areas.

• Do not cover vent on monitor.

• If monitor is broken, do not come in contact with the liquid crystal.

• If glass is broken. Handle with care.

• Allow adequate ventilation around the monitor so that

heat can properly dissipate. Do not block ventilated
openings or place the monitor near a radiator or other
heat sources. Do not put anything on top of monitor.

Caution

• The power cable connector is the primary means of
detaching the system from the power supply. The
monitor should be installed close to a power outlet which
is easily accessible.

• Handle with care when transporting. Save packaging for
transporting.

CORRECT PLACEMENT AND ADJUSTMENT OF
THE MONITOR CAN REDUCE EYE, SHOULDER
AND NECK FATIGUE. CHECK THE FOLLOWING

WHEN YOU POSITION THE MONITOR:

• For optimum performance, allow
20 minutes for warm-up.

• Adjust the monitor height so that the top of
the screen is at or slightly below eye level.
Your eyes should look slightly downward
when viewing the middle of the screen.

• Position your monitor no closer than
16 inches and no further away than
28 inches from your eyes. The optimal
distance is 21 inches.

• Rest your eyes periodically by focusing on
an object at least 20 feet away. Blink often.

• Position the monitor at a 90° angle to windows and other light sources to
minimize glare and reflections. Adjust the monitor tilt so that ceiling lights
do not reflect on your screen.

• If reflected light makes it hard for you to see your screen, use an anti­glare filter.

English-14

• Clean the LCD monitor surface with a lint-free, non-abrasive cloth. Avoid
using any cleaning solution or glass cleaner!

• Adjust the monitor’s brightness and contrast controls to enhance
readability.

• Use a document holder placed close to the screen.

• Position whatever you are looking at most of the time (the screen or

reference material) directly in front of you to minimize turning your head
while you are typing.

• Avoid displaying fixed patterns on the monitor for long periods of time to
avoid image persistence (after-image effects).

• Get regular eye checkups.

Ergonomics

To realize the maximum ergonomics benefits, we recommend the following:

• Do not position the Contrast control to its maximum setting

• Use the preset Size and Position controls with standard signals

• Use the preset Color Setting

• Use non-interlaced signals with a vertical refresh rate between 60-75 Hz

• Do not use primary color blue on a dark background, as it is difficult to

see and may produce eye fatigue to insufficient contrast

English

English-15

Specifications

Monitor Specifications

LCD Module Diagonal:

Viewable Image Size:

Native Resolution (Pixel Count):

Input Signal Video:

Sync:

Display Colours Analog input:

Synchronization Range Horizontal:

Vertical:

Resolutions Supported
Resolution based on horizontal and
vertical frequencies only

Active Display Horizontal:
Area** Vertical:

Power Supply

MultiSync LCD1530V

15.1 inch

15.1 inch
1024 x 768

ANALOG 0.7 Vp-p/75 Ohms
Separate sync.TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative

16,194,277 colors with
dithering

31.0 kHz to 60.0 kHz

56.2 Hz to 75.0 Hz

720 x 400*VGA text
640 x 480*at 60 Hz to 75 Hz
800 x 600*at 56 Hz to 75 Hz
832 x 624* at 75 Hz
1024 x 768 at 60 Hz to 75 Hz

307 mm/12.1 inches
230 mm/9.1 inches

AC 100-240 V @50/60 Hz

Notes

Active matrix; thin film
transistor (TFT) liquid
crystal display (LCD);

0.30 mm dot pitch; 200cd/m
white luminence; 200:1
contrast ratio, typical

Depends on display card
used.

Automatically
Automatically

Some systems may not
support all modes listed.

NEC-Mitsubishi Electronics
Display cites recommended
resolution at 75 Hz for
optimal display performance.

Dependent upon signal
timing used, and does not
include border area.

2

Current Rating

Dimensions

Weight

Environmental Considerations

Operating Temperature:

Humidity:

Altitude:

Storage Temperature:

Humidity:

Altitude:

* Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD
module, text may appear different. This is normal and necessary for all current flat panel technologies
when displaying non-native resolutions full screen. In flat panel technologies, each dot on the screen is
actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.

0.46 A @ 100-120 V / 0.27 A @ 220-240 V

370 (W) x 370 (H) x 160 (D) mm

4.7 kg (10.4 lbs)

5 °C to 35 °C
30% to 80%
3,000 m

-10 °C to +60 °C
10% to 85%
12,000 m

NOTE: Technical specifications are subject to change without

notice.

English-16

Features

Wider Compatibility: Because the MultiSync LCD monitor is analog

through and through, it does not require special analog to digital display
or interface cards but can accept RGB input directly.

Reduced Footprint: Provides the ideal solution for environments
requiring superior image quality but with size and weight limitations.
The monitor’s small footprint and low weight allow it to be moved or
transported easily from one location to another.

Color Control System: Allows you to adjust the colors on your screen
and customize the color accuracy of your monitor to a variety of
standards.

OSM (On-Screen Manager) Controls: Allow you to quickly and easily
adjust all elements of your screen image via simple to use on-screen
menus.

ErgoDesign Features: Enhance human ergonomics to improve the
working environment, protect the health of the user and save money.
Examples include OSM controls for quick and easy image adjustments,
tilt base for preferred angle of vision, small footprint and compliance with
MPRII guidelines for lower emissions.

English

Plug and Play: The Microsoft solution with the Windows 95/98/2000
operating system facilitates setup and installation by allowing the
monitor to send its capabilities (such as screen size and resolutions
supported) directly to your computer, automatically optimizing display
performance.

IPM (Intelligent Power Manager) System: Provides innovative power­saving methods that allow the monitor to shift to a lower power
consumption level when on but not in use, saving two-thirds of your
monitor energy costs, reducing emissions and lowering the air
conditioning costs of the workplace.

Multiple Frequency Technology: Automatically adjusts monitor to the
display card’s scanning frequency, thus displaying the resolution
required.

FullScan Capability: Allows you to use the entire screen area in most
resolutions, significantly expanding image size.

English-17

Troubleshooting

No picture

• The signal cable should be completely connected to the display card/
computer.

• The display card should be completely seated in its slot.

• Power Switch and computer power switch should be in the ON

position.

• Check to make sure that a supported mode has been selected on the
display card or system being used. (Please consult display card or
system manual to change graphics mode.)

• Check the monitor and your display card with respect to compatibility
and recommended settings.

• Check the signal cable connector for bent or pushed-in pins.

Image persistence

• Image persistence is when a “ghost” of an image remains on the
screen even after the monitor has been turned off. Unlike CRT
monitors, LCD monitors’ image persistence is not permanent. To
alleviate image persistence, turn the monitor off for as long as an
image was displayed. If an image was on the monitor for one hour
and a “ghost” of that image remains, the monitor should be turned off
for one hour to erase the image.

NOTE: As with all personal display devices, NEC-Mitsubishi

Electronic Displays recommends using a screen saver at
regular intervals whenever the screen is idle.

Image is unstable, unfocused or swimming is
apparent

• Signal cable should be completely attached to the computer.

• Use the OSM Image Adjust controls to focus and adjust display by

increasing or decreasing the fine total. When the display mode is
changed, the OSM Image Adjust settings may need to be re­adjusted.

• Check the monitor and your display card with respect to compatibility
and recommended signal timings.

English-18

LED on monitor is not lit (no green or amber color
can be seen)

• Power Switch should be in the ON position and power cord should be
connected.

• Make certain the computer is not in a power-saving mode (touch the
keyboard or mouse).

Display image is not sized properly

• Use the OSM Image Adjust controls to increase or decrease the
Coarse total.

• Check to make sure that a supported mode has been selected on the
display card or system being used. (Please consult display card or
system manual to change graphics mode.)

Selected resolution is not displayed properly

• Use OSM Display Mode to enter Information menu and confirm that
the appropriate resolution has been selected. If not, select
corresponding option.

English

English-19

TCO’99

Congratulations! You have just purchased a TCO’99
approved and labeled product!Your choice has
provided you with a product developed for
professional use. Your purchase has also contributed
to reducing the burden on the environment and also
to the further development of environmentally
adapted electronics products.

Why do we have environmentally labelled computers?

In many countries, environmental labelling has become an established
method for encouraging the adaptation of goods and services to the
environment. The main problem, as far as computers and other
electronics equipment are concerned, is that environmentally harmful
substances are used both in the products and during the manufacturing.
Since it has not been possible for the majority of electronics equipment
to be recycled in a satisfactory way, most of these potentially damaging
substances sooner or later enter Nature.

There are also other characteristics of a computer, such as energy
consumption levels, that are important from the viewpoints of both the
work (Internal) and natural (external) environments. Since all methods of
conventional electricity generation have a negative effect on the
environment (acidic and climate-influencing emissions, radioactive
waste, etc.), it is vital to conserve energy. Electronics equipment in
offices consume an enormous amount of energy since they are often left
running continuously.

What does labelling involve?

This product meets the requirements for the TCO’99 scheme which
provides for international and environmental labelling of personal
computers. The labelling scheme was developed as a joint effort by the
TCO (The Swedish Confederation of Professional Employees), Svenska
Naturskyddsforeningen (The Swedish Society for Nature Conservation)
and Statens Energimyndighet (The Swedish National Energy
Administration).

The requirements cover a wide range of issues: environment,
ergonomics, usability, emission of electrical and magnetic fields, energy
consumption and electrical and fire safety.

English-20

The environmental demands concern restrictions on the presence and
use of heavy metals, brominated and chlorinated flame retardants,
CFCs (freons) and chlorinated solvents, among other things. The
product must be prepared for recycling and the manufacturer is obliged
to have an environmental plan which must be adhered to in each
country where the company implements its operational policy. The
energy requirements include a demand that the computer and/or
display, after a certain period of inactivity, shall reduce its power
consumption to a lower level in one or more stages. The length of time
to reactivate the computer shall be reasonable for the user.

Labelled products must meet strict environmental demands, for
example, in respect of the reduction of electric and magnetic fields,
physical and visual ergonomics and good usability.

Environmental Requirements

Flame retardants
Flame retardants are present in printed circuit boards, cables, wires,

casings and housings. In turn, they delay the spread of fire. Up to thirty
percent of the plastic in a computer casing can consist of flame
retardant substances. Most flame retardants contain bromine or chloride
and these are related to another group of environmental toxins, PCBs,
which are suspected to give rise to severe health effects, including
reproductive damage in fisheating birds and mammals, due to the
bioaccumulative* processes. Flame retardants have been found in
human blood and researchers fear that disturbances in foetus
development may occur.

English

TCO’ 99 demand requires that plastic components weighing more than
25 grams must not contain flame retardants with organically bound
chlorine and bromine. Flame retardants are allowed in the printed circuit
boards since no substitutes are available.

Lead**

Lead can be found in picture tubes, display screens, solders and
capacitors. Lead damages the nervous system and in higher doses,
causes lead poisoning.

TCO’ 99 requirement permits the inclusion of lead since no replacement
has yet been developed.

English-21

Cadmium**

Cadmium is present in rechargeable batteries and in the
colourgenerating layers of certain computer displays. Cadmium
damages the nervous system and is toxic in high doses.

TCO’ 99 requirement states that batteries, the colourgenerating layers of
display screens and the electrical or electronics components must not
contain any cadmium.

Mercury**

Mercury is sometimes found in batteries, relays and switches, Mercury
damages the nervous system and is toxic in high doses.

TCO’ 99 requirement states that batteries may not contain any Mercury.
It also demands that no mercury is present in any of the electrical or
electronics components associated with the display unit.

CFCs (freons)

CFCs (freons)are sometimes used for washing printed circuit boards.
CFCs break down ozone and thereby damage the ozone layer in the
stratosphere, causing increased reception on Earth of ultraviolet light
with consequent increased risks of skin cancer (malignant melanoma).

The relevant TCO’ 99 requirement; Neither CFCs nor HCFCs may be
used during the manufacturing and assembly of the product or its
packaging.

* Bio-accumulative is defined as substances which accumulate within

living organisms.

** Lead, Cadmium and Mercury are heavy metals which are Bio-

accumulative.

To obtain complete information on the environmental criteria document,
order from:

TCO Development Unit

SE-114 94 Stockholm
SWEDEN
FAX Number: [phone]
E-mail (Internet): [e-mail]

You may also obtain current information on TCO’ 99 approved and
labelled products by visiting their website at:
http://www.tco-info.com/

English-22
