WARNING
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE
THIS UNIT'S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS
CAN BE FULLY INSERTED.
REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK • DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This
symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause
electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.
This symbol alerts the user that important literature concerning the operation and maintenance of this
unit has been included. Therefore, it should be read carefully in order to avoid any problems.
Canadian Department of Communications Compliance Statement
DOC: This Class B digital apparatus meets all requirements of the Canadian Interference-
Causing Equipment Regulations.
C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations
according to C.S.A. C22.2 No. 950.
FCC Information
1.
Use the attached specified cables with the LCD1525M
radio and television reception.
Please use the supplied power cable or equivalent to ensure FCC compliance.
(1)
(2) Please use the supplied AC Adapter (#A1240T01).
(3) Please use supplied shielded video signal cable.
(4) Please use supplied USB cable.
(5) Please use supplied audio cable.
Use of other cables and adapters may cause interference with radio and television
reception.
2.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult your dealer or an experienced radio/TV technician for help.
If necessary, the user should contact the dealer or an experienced radio/television technician
for additional suggestions. The user may find the following booklet, prepared by the Federal
Communications Commission, helpful: ”How to Identify and Resolve Radio-TV Interference
Problems.“ This booklet is available from the U.S. Government Printing Office, Washington,
D.C., 20402, Stock No. 004-000-00345-4.
color monitor so as not to interfere with
78134672.wpc7/16/99, 2:25 PM3
1
Contents
MultiSync
®
LCD
1
5
2
5
M
U
se
r’s M
a
n
u
a
l
MultiSync
®
LCD
1
5
2
5
M
U
se
r’s M
a
n
u
a
l
N
E
C
L
C
D
S
e
r
i
e
s
You can register your product online at
www.nectech.com/productregistration
Your new NEC Technologies MultiSync® LCD monitor box* should
contain the following:
• MultiSync LCD1525M
monitor with tilt/swivel
base
• Power Cord
(Part # 79PM1764)
• AC Adapter (#A1240T01)
(located in base)
• Video Signal Cable
• Audio Cable
• USB Cable
• User’s Manual
MultiSync LCD1525M
monitor with Video Signal Cable
™
M
u
l
t
i
S
y
n
c
L
C
D
1
5
2
5
M
Audio Cord
Power Cord
USB Cable
User’s Manual
* Remember to save your original box and packing material to transport or ship the monitor.
2
78134672.wpc7/16/99, 2:25 PM4
Quick Start
To attach the MultiSync® LCD monitor to your system, follow these
instructions:
1. Turn off the power to your computer.
2. For the PC: Connect the 15-pin mini D-SUB of the appropriate signal cable
to the connector of the display card in your system (Figure A.1). Tighten all screws.
For the Mac: Connect the MultiSync LCD
(Figure B.1). Attach the 15-pin mini D-SUB end of the appropriate signal cable to the
MultiSync LCD
NOTE: To obtain the MultiSync LCD
call NEC Technologies at (800) 820-1230.
Remove connector cover and cable cover.
3. Connect the 15-pin mini D-SUB of the video signal cable to the appropriate connector on
the back of the monitor. Place the Video Signal Cable under Clip B (Figure C1).
4. Connect the audio cable to “Line-in” on the back of the monitor and the other end to the
“Audio out” terminal of the computer. Place the Audio cable under Clip C (Figure D.1).
Replace connector cover and cable cover.
5. Headphones may be connected to the “Headphones” output on the front of the monitor’s
bezel marked “ ” (Figure E.1). While the headphones are connected, the sound from
the speakers will be disabled. Headphones can be purchased from your local electronics
store.
6. Using the USB cable, connect the B type connector to the USB upstream port on the
back of the monitor and A type connector to the downstream part on the computer
(Figure F.1). If you are using the cord from the USB device, use one of the downstream
port on the side of the monitor (Figure G.1).
NOTE: Incorrect cable connections may result in irregular operation, damage
display quality/components of LCD module and/or shorten the module’s life.
7. Connect one end of the power cord to the AC Adapter (#A1240T01) on the back of
the monitor and the other end to the power outlet (Figure H.1).
8. Turn on the monitor (Figure I.1) and the computer.
To complete the setup of your MultiSync LCD monitor, use the following OSM™ controls:
9.
• Auto Adjust Contrast
• Auto Adjust
Refer to the Controls section of this User’s Manual for a full description of these OSM controls.
NOTE: For download information on the Windows 95/98 INF file for your MultiSync
LCD
NOTE: If you have any problems, please refer to the Troubleshooting section of
this User’s Manual.
1525M Macintosh cable adapter (Figure B.1). Tighten all screws.
1525M Macintosh cable adapter,
1525Mmonitor, refer to the References section of this User’s Manual.
™
1525M
Macintosh cable adapter to the computer
78134672.wpc7/16/99, 2:25 PM5
3
Quick Start cont.
Figure A.1
Clip A
Clip B
Figure B.1
Clip C
Figure C.1
78134672.wpc7/16/99, 2:25 PM6
Figure D.1
4
c
5
Quick Start
A Type
B Type
Figure F.1
MultiSync LCD
1
5
2
5
M
Figure E.1
M
u
ltiS
y
n
c
L
C
D
1
Figure H.1Figure I.1
78134672.wpc7/16/99, 2:25 PM7
Figure G.1
M
u
ltiS
y
n
5
Quick Start cont.
Tilt
Grasp both sides of the monitor screen with your
hands and adjust the tilt as desired (Figure TS.1).
Remove Monitor Stand for Mounting
To prepare the monitor for alternate mounting
purposes:
1. Remove the back cover and the cable cover
(Figure R.1).
2. Disconnect all cables.
3. Place monitor face down on a non-
abrasive surface (Figure R.2).
4. Remove the 4 screws connecting
the monitor to the stand and lift off
the stand assembly (Figure R.2).
The monitor is now ready for
mounting in an alternate manner.
5. Connect the AC Adapter cord to
the back of the monitor marked
“DC in” (Figure R.3).
6. Reverse this process to reattach stand.
NOTE: Use only VESA-compatible alternative mounting method.
When the monitor stand is removed, the USB capabilities
will be disabled.
Please use only the supplied AC Adapter (#A1240T01).
CAUTION
Figure R.1
Figure TS.1
Figure R.2
Non-abrasive surface
78134672.wpc7/16/99, 2:25 PM8
Figure R.3
6
Quick Start cont.
Remove AC Adapter from Monitor Stand
To remove the AC Adapter
1. Remove the back panel and remove cable
cover (Figure AC.1).
2. Disconnect all cables.
3. Place monitor face down on a
non-abrasive surface (Figure AC.2).
4. Remove the 4 screws on the bottom of the
stand and lift bottom panel
(Figure AC.3).
5. Pull out the AC Adapter and cord (Figure AC.4).
6. Reattach the bottom panel to the stand. To connect the AC Adapter
outside of the stand, plug the AC Adapter cord to the back of the monitor
“DC in” (Figure AC.5).
7. Reverse this process to reinstall the AC Adapter inside the monitor stand.
Please use only the supplied AC Adapter (#A1240T01).
CAUTION
Figure AC.1
Figure AC.2
Figure AC.4
78134672.wpc7/16/99, 2:25 PM9
Figure AC.3
Figure AC.5
7
Controls
OSM™ (On-Screen-Manager) Controls
To acess OSM press any of control buttons ( , , , ) or PROCEED button.
To mute volume, press the RESET button.
The OSM controls on the front of the monitor function as follows:
ControlMain MenuSub-Menu
EXITExits the OSM controls.Exits to the OSM controls
main menu.
CONTROL /Moves the highlightedMoves the highlighted area
CONTROL /Proceeds to the selectedMoves the bar in the + or –
PROCEEDHas no functionActivates Auto Adjust feature.
RESET: The currentlyResets all the controls withinResets the highlighted control.
highlighted control tothe highlighted menu.If volume is selected, the
the factory setting.speaker sound will be muted.
Speaker Controls
Volume: Increases or decreases the sound output of speakers.
Treble: Increases or decreases the sound output of treble.
Bass: Increases or decreases the sound output of bass.
Balance: Adjusts the balance between the right and left speakers.
area up/down to selectup/down to select one of the
one of the controls.controls.
menu choice (indicateddirection to increase or
by the highlighted area)decrease the adjustment.
In Display Mode, opens
additional window.
NOTE: When RESET is pressed, a warning window will appear
allowing you to cancel the reset function.
Brightness and Contrast
Brightness: Adjusts the overall image and background screen brightness.
Contrast: Adjusts the image brightness in relation to the background.
Auto Adjust: Corrects the image displayed for non-standard video inputs.
Auto Adjust
Allows adjust the Position and H. Size and Fine settings.
Position
Controls horizontal and vertical image position within the display area
of the LCD.
Auto Adjust: Automatically sets the horizontal and vertical image
position within the display area of the LCD.
8
78134672.wpc7/16/99, 2:25 PM10
Controls
Image Adjust
H.SIZE: Adjusts the horizontal size by increasing or decreasing this setting.
Fine:Improves focus, clarity and image stability by increasing or decreasing
the Fine setting.
Auto Adjust: Automatically adjusts H.Size or Fine settings.
AccuColor® Control System
Color presets 1 through 5. Five color presets select the desired color setting. If a setting
is adjusted, the name of the setting will change to Custom
Color Gain (Red, Green, Blue): Increases or decreases Red, Green or Blue color
depending upon which is selected. The change in color will appear on screen
and the direction (increase or decrease) will be shown by the color bars.
Tools
Language Select: OSM control menus are available in seven languages.
™
OSM
to appear on your screen. Selecting OSM Location allows you to manually adjust
the position of the OSM control menu left, right, up or down.
OSM Turn Off: The OSM control menu will stay on as long as it is in use. In
the OSM Turn Off submenu, you can select how long the monitor waits after the
last touch of a button to shut off the OSM control menu. The preset choices are
10, 20, 30, 60 and 120 seconds.
Position: You can choose where you would like the OSM control image
.
OSM Lock Out: This control completely locks out access to all OSM control
functions. When attempting to activate OSM controls while in the Lock Out
mode, a screen will appear indicating the OSM controls are locked out. To
activate the OSM Lock Out function, press PROCEED, then and hold down
simultaneously. To de-activate the OSM Lock Out, press PROCEED, then
hold down simultaneously.
Factory Preset: Selecting Factory Preset allows you to reset all OSM control
settings back to the factory settings. The RESET button will need to be held down
for several seconds to take effect. Individual settings can be reset by highlighting
the control to be reset and pressing the RESET button.
Resolution Notifier: This optimal resolution is 1024 x 768. If ON is selected,
a message will appear on the screen after 2 minutes, notifying you that the
resolution is not at 1024 x 768.
Information
Display Mode: Provides information about the current resolution display and
technical data including the preset timing being used and the horizontal and
vertical frequencies.
9
78134672.wpc7/16/99, 2:25 PM11
and
Recommended Use
Safety Precautions and Maintenance
FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE
FOLLOWING WHEN SETTING UP AND USING
THE MULTISYNC® LCD COLOR MONITOR:
• DO NOT OPEN THE MONITOR. There are no user serviceable parts inside and
opening or removing covers may expose you to dangerous shock hazards or other
risks. Refer all servicing to qualified service personnel.
• Do not spill any liquids into the cabinet or use your monitor near water.
• Do not insert objects of any kind into the cabinet slots, as they may touch danger-
ous voltage points, which can be harmful or fatal or may cause electric shock, fire
or equipment failure.
• Do not place any heavy objects on the power cord. Damage to the cord may
cause shock or fire.
• Do not place this product on a sloping or unstable cart, stand or table, as the
monitor may fall, causing serious damage to the monitor.
• When operating the MultiSync LCD monitor with its AC 220-240V power supply,
use a power supply cord that matches the power supply voltage of the AC power
outlet being used. The power supply cord you use must have been approved by
and comply with the safety standards of your country (type HOSVV-F should be
used except in U.K.).
• Use supplied AC Adapter. Do not place any objects onto the AC Adapter and do
not use the AC Adapter outdoors.
• The inside of the flourescent tube located within the LCD monitor contains mercury.
Please follow the bylaws or rules of your municipality to dispose of the tube
properly.
• In UK, use a BS-approved power cord with molded plug having a black (5A) fuse
installed for use with this monitor. If a power cord is not supplied with this monitor,
please contact your supplier.
Immediately unplug your monitor from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
• When the power supply cord or plug is damaged.
• If liquid has been spilled, or objects have fallen into the monitor.
• If the monitor has been exposed to rain or water.
• If the monitor has been dropped or the cabinet damaged.
• If the monitor does not operate normally by following operating instructions.
• Allow adequate ventilation around the monitor so that heat can properly
dissipate. Do not block ventilated openings or place the monitor near a
radiator or other heat sources. Do not put anything on top of monitor.
• The power cable connector is the primary means of detaching the system
CAUTION
from the power supply. The monitor should be installed close to a power
outlet which is easily accessible.
• Handle with care when transporting. Save packaging for transporting.
78134672.wpc7/16/99, 2:25 PM12
10
Loading...
+ 28 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
