NEC Express Server

Express5800 Series

Express5800/R120g-2M EXP802

User’s Guide

Chapter 1 General Description

Chapter 2 Preparations

Chapter 3 Setup

Chapter 4 Appendix

10.112.02-101.02 May 2016

Page 2

Manuals

Express5800/R120g-2M User's Guide

Manuals

Manuals for this product are provided as booklets ( ) and electronic manuals ( ) in EXPRESSBUILDER ( ).

Safety Precautions and Regulatory Notices

Describes points of caution to ensure the safe use of this server.

Read these cautions before using this server.

Getting Started

Describes how to use this server, from unpacking to operations. See this guide first and read the outline of this product.

User’s Guide

Chapter 1: General Description Overviews, names, and functions of the server’s parts

Chapter 2: Preparations Installation of additional options, connection of peripheral devices,

and suitable location for this server

Chapter 3: Setup System BIOS configurations and summary of EXPRESSBUILDER

Chapter 4: Appendix Specifications and other information

Installation Guide (Windows)

Chapter 1: Installing Windows Installation of Windows and drivers, and precautions for installation

Chapter 2: Installing Bundled

Software

Installation of NEC ESMPRO, Universal RAID Utility, and other bundled software

Maintenance Guide

Chapter 1: Maintenance Server maintenance and troubleshooting

Chapter 2: Useful Features Useful features and the detail of system BIOS settings, RAID

Configuration Utility, and EXPRESSBUILDER

Chapter 3: Appendix Error messages and Windows Event Logs

Other manuals

The detail of NEC ESMPRO, Universal RAID Utility, and the other features.

PDF

EXPRESSBUILDER

Page 3

Contents

Express5800/R120g-2M User's Guide

Contents

Manuals ................................................................................................................................................................. 2

Contents ................................................................................................................................................................ 3

Conventions Used in This Document .................................................................................................................... 6

Signs and symbols for safety ........................................................................................................................ 6

Notations used in the text .............................................................................................................................. 7

Optical disk drive ........................................................................................................................................... 7

Hard disk drive .............................................................................................................................................. 7

Removable media ......................................................................................................................................... 7

Abbreviations of Operating Systems (Windows) ........................................................................................... 8

POST ........................................................................................................................................................... 8

BMC ........................................................................................................................................................... 8

Trademarks ........................................................................................................................................................... 9

License Agreement Notice ................................................................................................................................... 10

Warnings and Additions to This Document .......................................................................................................... 13

Latest editions ............................................................................................................................................. 13

Safety notes ................................................................................................................................................ 13

Warning label .............................................................................................................................................. 14

Handling precautions (for proper operations) .............................................................................................. 15

Chapter 1 General Description ......................................................................................................................... 17

1. Introduction ................................................................................................................................................. 18

2. Accessories ................................................................................................................................................. 19

3. Features ...................................................................................................................................................... 20

3.1 Firmware and Software Version Management ................................................................................. 23

4. Names and Functions of Parts .................................................................................................................... 24

4.1 Front View (With Front Bezel) .......................................................................................................... 24

4.2 Front View (Without Front Bezel) ..................................................................................................... 25

4.3 Rear View ........................................................................................................................................ 26

4.4 External View ................................................................................................................................... 27

4.5 Internal View .................................................................................................................................... 28

4.6 Motherboard .................................................................................................................................... 29

4.7 Status Indicators .............................................................................................................................. 31

4.7.1 POWER LED ( ) .......................................................................................................... 31

4.7.2 STATUS LED 1,2 ( ) ....................................................................................................... 31

4.7.3 LINK/ACT LED ( 1, 2, 3, 4) ........................................................................... 32

4.7.4 Optical Disk Drive Access LED (option) ............................................................................. 32

4.7.5 UID LED (ID) ...................................................................................................................... 33

4.7.6 Power Capping LED .......................................................................................................... 33

4.7.7 LED on a hard disk drive ................................................................................................... 34

4.7.8 LEDs for LAN connectors .................................................................................................. 35

4.7.9 AC POWER LED on Power Unit ........................................................................................ 37

Chapter 2 Preparations .................................................................................................................................... 38

1. Installing Internal Optional Devices ............................................................................................................. 39

1.1 Safety Precautions ........................................................................................................................... 39

1.2 Overview of Installation and Removal .............................................................................................. 40

1.3 Identifying Servers (UID Switch) ...................................................................................................... 42

Page 4

Contents

Express5800/R120g-2M User's Guide

1.4 Removing Front Bezel ..................................................................................................................... 43

1.5 Removing Top Cover ....................................................................................................................... 44

1.6 Removing PCI Riser Card Unit ........................................................................................................ 45

1.7 Removing Support Bar .................................................................................................................... 46

1.8 Removing Air Duct ........................................................................................................................... 47

1.9 TPM Kit ............................................................................................................................................ 48

Installation ......................................................................................................................... 48

1.9.1

1.10 Processor (CPU) .............................................................................................................................. 49

Maximum number of processor cores supported by this server ......................................... 49

1.10.1

Installation ......................................................................................................................... 50

1.10.2

Replacement / Removal .................................................................................................... 53

1.10.3

1.11 DIMM ............................................................................................................................................... 54

Maximum supported memory size ..................................................................................... 54

1.11.1

Memory Clock .................................................................................................................... 55

1.11.2

Memory RAS Feature ........................................................................................................ 57

1.11.3

DIMM installation order ...................................................................................................... 58

1.11.4

Installation ......................................................................................................................... 59

1.11.5

Removal / Replacement .................................................................................................... 60

1.11.6

Cluster On Die and Early Snoop features .......................................................................... 60

1.11.7

Using Memory RAS Feature .............................................................................................. 62

1.11.8

1.12 Flash Backup Unit for RAID Controller............................................................................................. 70

Handling precautions ......................................................................................................... 70

1.12.1

Installing N8103-181 Flash Backup Unit ............................................................................ 70

1.12.2

Removal ............................................................................................................................ 73

1.12.3

Installing FBU for N8103-179............................................................................................. 73

1.12.4

Removing FBU .................................................................................................................. 74

1.12.5

1.13 LOM Card ........................................................................................................................................ 75

Installation ......................................................................................................................... 75

1.13.1

Removal ............................................................................................................................ 76

1.13.2

1.14 Additional / Redundant Fan Unit ...................................................................................................... 77

Installation ......................................................................................................................... 78

1.14.1

Replacement / Removal .................................................................................................... 79

1.14.2

1.15 Backup Device ................................................................................................................................. 80

Installation ......................................................................................................................... 80

1.15.1

Removal ............................................................................................................................ 82

1.15.2

1.16 PCI Riser Card ................................................................................................................................. 83

Notes ................................................................................................................................. 83

1.16.1

Installation ......................................................................................................................... 83

1.16.2

Removal ............................................................................................................................ 83

1.16.3

1.17 PCI Card .......................................................................................................................................... 84

Notes ................................................................................................................................. 84

1.17.1

Supported PCI cards and available slots ........................................................................... 86

1.17.2

Installation ......................................................................................................................... 93

1.17.3

Removal ............................................................................................................................ 94

1.17.4

Installing RAID Controller .................................................................................................. 95

1.17.5

1.18 Additional 2.5-inch HDD Cage ......................................................................................................... 97

Installation ......................................................................................................................... 97

1.18.1

Removal .......................................................................................................................... 100

1.18.2

1.19 2.5-inch PCle SSD Mounting Kit .................................................................................................... 101

Installation ....................................................................................................................... 101

1.19.1

Removal .......................................................................................................................... 104

1.19.2

1.20 Optical Disk Drive .......................................................................................................................... 105

Installation ....................................................................................................................... 105

1.20.1

Removal .......................................................................................................................... 106

1.20.2

1.21 Use of Internal Hard Disk Drives in the RAID System ................................................................... 107

Connecting cables ........................................................................................................... 108

1.21.1

Notes on Building RAID System ...................................................................................... 110

1.21.2

1.22 Installing Air Duct ........................................................................................................................... 111

1.23 Installing Support Bar .................................................................................................................... 111

1.24 Installing PCI Riser Card Unit ........................................................................................................ 111

1.25 Installing Top Cover ....................................................................................................................... 111

1.26 Hard Disk Drive .............................................................................................................................. 112

Installation ....................................................................................................................... 113

1.26.1

Removal .......................................................................................................................... 114

1.26.2

Replacing a hard disk drive in the RAID System (Auto Rebuild) ..................................... 115

1.26.3

Page 5

Contents

Express5800/R120g-2M User's Guide

1.27 Power Supply Unit ......................................................................................................................... 116

Cold Redundant Feature ................................................................................................. 116

1.27.1

Installation ....................................................................................................................... 117

1.27.2

Replacing a failing power supply unit ............................................................................... 119

1.27.3

1.28 Installing Front Bezel ..................................................................................................................... 120

2. Installation and Connection ....................................................................................................................... 121

2.1 Installation ...................................................................................................................................... 121

Installing Rack ................................................................................................................. 121

2.1.1

Installing the server to the rack or removing it from the rack ........................................... 123

2.1.2

2.2 Connection ..................................................................................................................................... 130

Connecting to Uninterruptible Power Supply (UPS) ......................................................... 132

2.2.1

Chapter 3 Setup ............................................................................................................................................. 133

1. Turning on the Server................................................................................................................................ 134

1.1 POST ............................................................................................................................................. 135

POST sequence .............................................................................................................. 135

1.1.1

POST error messages ..................................................................................................... 137

1.1.2

2. BIOS Setup Utility (SETUP) ...................................................................................................................... 138

2.1 Overview ........................................................................................................................................ 138

2.2 Starting SETUP Utility .................................................................................................................... 138

2.3 Description on On-Screen Items and Key Usage .......................................................................... 139

2.4 Cases that Require Configuration .................................................................................................. 141

3. EXPRESSSCOPE Engine 3 ..................................................................................................................... 143

3.1 Overview ........................................................................................................................................ 143

3.2 EXPRESSSCOPE Engine 3 Network Configuration ...................................................................... 143

4. EXPRESSBUILDER .................................................................................................................................. 145

4.1 Features of EXPRESSBUILDER ................................................................................................... 145

4.2 Usage of EXPRESSBUILDER ....................................................................................................... 145

5. Installing Software Components ............................................................................................................... 146

6. Turning Off the Server ............................................................................................................................... 147

Chapter 4 Appendix ....................................................................................................................................... 148

1. Specifications ............................................................................................................................................ 149

2. Interrupt Lines ........................................................................................................................................... 155

3. Glossary .................................................................................................................................................... 156

4. Revision Record ........................................................................................................................................ 157

Page 6

Conventions Used in This Document

Express5800/R120g-2M User's Guide

Conventions Used in This Document

Signs and symbols for safety

WARNING and CAUTION are used in this guide as following meaning.

WARNING

Indicates there is a risk of death or serious personal injury

CAUTION

Indicates there is a risk of burns, other personal injury, or property damage

Precautions and notices against hazards are presented with one of the following three symbols. The individual symbols are defined as follows:

Attention This symbol indicates the presence of a hazard if

the instruction is ignored. An image in the symbol illustrates the hazard type.

Prohibited Action

This symbol indicates prohibited actions. An image in the symbol illustrates a particular prohibited action.

Mandatory Action

This symbol indicates mandatory actions. An image in the symbol illustrates a mandatory action to avoid a particular hazard.

(Example in this guide)

WARNING

Use only the specified outlet

Use a grounded outlet with the specified voltage. Use of an improper power source

may cause a fire or a power leak.

(Example)

(Disconnect a plug)

Symbol to draw attention

Description of a warning

Term indicating a degree of danger

Page 7

Conventions Used in This Document

Express5800/R120g-2M User's Guide

Notations used in the text

In addition to safety-related symbols urging caution, three other types of notations are used in this manual. These notations have the following meanings.

Important Indicates critical items that must be followed when handling hardware or operating software. If

the procedures described are not followed, server failure, data loss, and other serious

malfunctions could occur.

Note Indicates items that must be confirmed when handling hardware or operating software.

Tips Indicates information that is helpful to keep in mind when using this server.

Optical disk drive

This server is equipped with one of the following drives. These drives are referred to as optical disk drive in this manual.

 DVD-ROM drive

 DVD Super MULTI drive

Hard disk drive



Unless otherwise stated, hard disk drive described in this manual refer to both of the following.

 Hard disk drive (HDD)

 Solid state drive (SSD)

Removable media



Unless otherwise stated, removable media described in this manual refer to both of the following.

 USB flash drive

 Flash FDD

Page 8

Conventions Used in This Document

Express5800/R120g-2M User's Guide

Abbreviations of Operating Systems (Windows)

Windows Operating Systems are referred to as follows.

See Chapter 1 (1.2 Supported Windows OS) in Installation Guide (Windows) for detailed information.

Notations in this manual Official names of Windows

Windows Server 2012 R2

Widnows Server 2012 R2 Standard

Widnows Server 2012 R2 Datacenter

Windows Server 2012

Widnows Server 2012 Standard

Widnows Server 2012 Datacenter

Windows Server 2008 R2

Windows Server 2008 R2 Standard

Windows Server 2008 R2 Enterprise

POST

POST described in this manual refers to the following.

 Power On Self-Test

BMC

BMC described in this manual refers to the following.

 Baseboard Management Controller

Page 9

Trademarks

Express5800/R120g-2M User's Guide

Trademarks

EXPRESSSCOPE and ExpressUpdate are registered trademark of NEC Corporation.

Microsoft, Windows, and Windows Server are registered trademarks or trademarks of Microsoft Corporation in the United States and other countries. Intel, Pentium, and Xeon are registered trademarks of Intel Corporation of the United States. AT is a registered trademark of International Business Machines Corporation of the United States and other countries. Adaptec, its logo, and SCSI Select are registered trademarks or trademarks of Adaptec, Inc. of the United States. Avago, LSI, and the LSI & Design logo are trademarks or registered trademarks of Avago Technologies in the United States and/or other countries. Adobe, the Adobe logo, and Acrobat are trademarks of Adobe Systems Incorporated. DLT and DLTtape are trademarks of Quantum Corporation of the United States. PCI Express is a trademark of Peripheral Component Interconnect Special Interest Group. InfiniBand is a trademark or service mark of InfiniBand Trade Association. Mellanox, and its logo, and Connect-X, Switch-X, MLNX-OS products are trademarks or registered trademarks of Mellanox Technologies in Israel and other countries.

All other product, brand, or trade names used in this publication are the trademarks or registered trademarks of their respective

trademark owners.

Page 10

License Agreement Notice

Express5800/R120g-2M User's Guide

License Agreement Notice

Open source software of following license is included in the part of this product (system BIOS).

 EDK/EDKII

 UEFI Network Stack II and iSCSI

 Crypto package using WPA Supplicant

Open source software of following license is included in the part of this product (Off-line Tools).

 EDK/EDKII

EDK/EDKII

BSD License from Intel

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

・ Redistributions of source code must retain the above copyright notice, this list of conditions and the following

disclaimer.

・ Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the

following disclaimer in the documentation and/or other materials provided with the distribution.

・ Neither the name of the Intel Corporation nor the names of its contributors may be used to endorse or

promote products derived from this software without specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Page 11

License Agreement Notice

Express5800/R120g-2M User's Guide

UEFI NETWORK STACK II and iSCSI

OpenSSL License

-------

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.

2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.

3. All advertising materials mentioning features or use of this software must display the following acknowledgment: "This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (http://www.openssl.org/)"

4. The names "OpenSSL Toolkit" and "OpenSSL Project" must not be used to endorse or promote products derived from this software without prior written permission. For written permission, please contact

openssl-core@openssl.org.

5. Products derived from this software may not be called "OpenSSL" nor may "OpenSSL" appear in their names without prior written permission of the OpenSSL Project.

6. Redistributions of any form whatsoever must retain the following acknowledgment: "This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/)"

THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT ``AS IS'' AND ANY EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL PROJECT OR ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

This product includes cryptographic software written by Eric Young (eay@cryptsoft.com). This product includes software written by Tim Hudson (tjh@cryptsoft.com).

Page 12

License Agreement Notice

Express5800/R120g-2M User's Guide

CRYPTO PACKAGE USING WPA SUPPLICANT

WPA Supplicant

-------

This program is licensed under the BSD license (the one with advertisement clause removed). If you are submitting changes to the project, please see CONTRIBUTIONS file for more instructions.

License

-------

This software may be distributed, used, and modified under the terms of BSD license:

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.

3. Neither the name(s) of the above-listed copyright holder(s) nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOTLIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Page 13

Warnings and Additions to This Document

Express5800/R120g-2M User's Guide

Warnings and Additions to This Document

Unauthorized reproduction of the contents of this manual, in part or in its entirety, is prohibited.

This manual is subject to change at any time without notice.

Do not make copies or alter the manual content without permission from NEC Corporation.

If you have any concerns, or discover errors or omissions in this manual, contact your sales

representative.

Regardless of article 4, NEC Corporation assumes no responsibility for effects resulting from your

operations.

The sample values used in this manual are not actual values.

Keep this manual for future use.

Latest editions

This manual was created based on the information available at the time of its creation. The screen images, messages, and procedures are subject to change without notice. Substitute as appropriate when content has been modified.

The most recent version of the guide, as well as other related manuals, is also available for download from the following website.

http://www.nec.com/

Safety notes

To use this server safely, read thoroughly "Safety Precautions and Regulatory Notices" that comes with your server.

Page 14

Warnings and Additions to This Document

Express5800/R120g-2M User's Guide

Warning label

Warning label are attached on or near the components with potential hazards. This label is either attached or printed on the component.

Do not remove or black out this label and keep it clean. If no label is attached or printed on the server, contact your sales representative.

Page 15

Warnings and Additions to This Document

Express5800/R120g-2M User's Guide

Handling precautions (for proper operations)

Be sure to observe the following precautions for the proper functioning of the server. Ignoring the precautions may cause server malfunction or failure.

 Do not use any cellphones and switch off them near the server. Electric waves from such devices

can cause server to malfunction.

 Install the server in an appropriate place. For details about the installation location, see Chapter 2

Preparations (2. Installation and Connection).

 Before connecting/removing cables to/from peripheral devices, make sure that the server is off and

unplug the power cord, if they are non plug-and-play devices.

 Connect the provided power cord to a 100/200 VAC outlet.  Do not press the POWER switch to turn on the server before the STATUS LED (amber) is unlit.  Make sure that the access LED on the server is off before turning off the power or ejecting an optical

disk.

 Wait for at least 30 seconds before connecting power cord to power outlet after disconnecting it.  If any Uninterruptible Power Supply (UPS) unit is connected, set it to wait for at least 30 seconds

before turning on the server after power off.

 Wait for at least 30 seconds before turning on the server after turning off the server.  Do not power off or reset the server, nor disconnect the power cord before POST completes.  Turn off the server and unplug the power cord before moving it.  Regularly clean the server to prevent various types of failure. See Chapter 1 Maintenance (2. Daily

Maintenance) in "Maintenance Guide" for details about cleaning.

 Momentary voltage drop may occur due to lightning strike. To prevent this, use of UPS is

recommended.

 We do not support that any copy-protected CD that does not conform to standards will play on the

server’s optical disk drive.

 In the following cases, check and adjust the system clock before operation.

 After transportation  After storage  After the server is used following a period of disuse, in which storage conditions did not conform to those

that guarantee server operations (temperature: 5 to 40°C; humidity: 20% to 80%).

 Check the system clock approximately once per month. Use of a time server (NTP server) is

recommended if high accuracy timing is required by the system.

 Observe the storage conditions (Temperature: 10C to 55C, Humidity: 20% to 80%, No condensation of

moisture) to store the server. If this server, internal optional devices, and media set for the backup

devices (tape cartridges) are moved from a cold place to a warm place in a short time, condensation will occur and cause malfunctions and failures when these are used in such state. To protect important stored data and property, make sure to wait for a sufficient period to use the server and components in the operating environment.

Reference: Time effective at avoiding condensation in winter (more than 10C differences between the

room temperature and atmospheric temperature) Disk devices: Approximately 2 to 3 hours Tape media: Approximately 1 day

 This server does not support hibernation/standby function.  For optional devices, we recommend you use our NEC products. Even if they are successfully

installed or connected, installation of unsupported devices can cause the server to malfunction or even failure. You will be charged to repair failure or damage caused by use of such products even within warranty period.

Page 16

Warnings and Additions to This Document

Express5800/R120g-2M User's Guide

Using a computer extensively may affect different parts of your body. Here are tips you should follow while working on

a computer to minimize strain on your body.

Keep proper posture

The basic body position for using a computer is sitting straight with

your hands on the keyboard parallel with the floor, and your eyes

directed slightly downward toward the monitor. With the proper

posture described above, no unnecessary strain is applied on any

part of your body, in other words when your muscles are most

relaxed.

Working on the computer with bad posture such as hunching over or

being too close to the monitor could cause fatigue or deteriorated

eyesight.

Adjust the angle of your display

Most display units are designed for adjustment of the horizontal and

vertical angles. This adjustment is important to prevent the screen

from reflecting bright lights and to make the display contents easy to

see. Working without adjusting the display to a comfortable angle

makes it difficult for you to maintain a proper posture and you will

get tired easily. Adjust the viewing angle before use.

Adjust the brightness and contrast of the display

Display screens have functions to control brightness and contrast.

The most suitable brightness/contrast depends on age, individuals,

and environment, so adjust it to suit your preferences. A too bright

or too dark display is bad for your eyes.

Adjust the angle of keyboard

Some keyboards are ergonomically designed, which allow the angle

to be adjusted. Adjusting the angle of the keyboard is effective to

reduce tension on your shoulders, arms, and fingers.

Clean your equipment

Keeping your equipment clean is important not only for the appearance but also for functional and safety reasons. A

dusty monitor makes it difficult to see the display contents, so clean it regularly.

Take rest breaks

When you feel tired, take a break. Light exercise is also

recommended.

Tips for your health and safety

Page 17

Express5800/R120g-2M User’s Guide

NEC Express5800 Series Express5800/R120g-2M

General Description

This chapter introduces the features of this server and the name of each part.

1. Introduction

2. Accessories

Describes the accessories of the server.

3. Features

Describes the features of the server and the server management.

4. Names and Functions of Parts

Describes the name of each part contained in this server.

Page 18

1. Introduction

Express5800/R120g-2M User's Guide

Chapter 1 General Description

Introduction

Thank you for purchasing this NEC Express5800 Series product.

This high performance server is powered by the latest microprocessor "Intel® Xeon® processor".

NEC’s latest technology and architectures realize high-power and high-speed operation that cannot be matched by existing servers.

The server is designed with consideration of not only reliability but also expandability, which enables you to use it as a network server.

Read this manual before using the server thoroughly to fully understand handling of Express5800 Series Server and appreciate its functions to the maximum extent.

Page 19

2. Accessories

Express5800/R120g-2M User's Guide

Chapter 1 General Description

Accessories

The carton box contains various accessories which are required for setup or maintenance. Make sure you have them all for future use.

 Front Bezel

 Bezel Lock Key (attached to Front Bezel)

 Slide Rails

 Safety Precautions and Regulatory Notices

 SAS/SATA cable

 Getting Started

 6x Screws for internal backup device

Make sure you have all accessories and inspect them. If an accessory is missing or damaged, contact your sales representative.

Important

The chassis serial number plate and maintenance label is located on the

server. If the serial number does not match the number on the warranty, you

may not be guaranteed against failure even within the warranty period.

Contact your sales representative if they do not match.

Page 20

3. Features

Express5800/R120g-2M User's Guide

Chapter 1 General Description

Features

The server has the following features:

High performance

 Intel Xeon processor

-N8101-1029F: E5-2603 v4 (1.70GHz 6Core)

-N8101-1030F: E5-2620 v4 (2.10GHz 8Core)

-N8101-1031F: E5-2623 v4 (2.60GHz 4Core)

-N8101-1032F: E5-2630 v4 (2.20GHz 10Core)

-N8101-1033F: E5-2637 v4 (3.50GHz 4Core)

-N8101-1034F: E5-2640 v4 (2.40GHz 10Core)

-N8101-1035F: E5-2643 v4 (3.40GHz 6Core)

-N8101-1036F: E5-2650 v4 (2.20GHz 12Core)

-N8101-1038F: E5-2667 v4 (3.20GHz 8Core)

-N8101-1039F: E5-2680 v4 (2.40GHz 14Core)

-N8101-1040F: E5-2690 v4 (2.60GHz 14Core)

-N8101-1041F: E5-2697 v4 (2.30GHz 18Core)

-N8101-1042F: E5-2697A v4 (2.60GHz 16Core)

-N8101-1043F: E5-2698 v4 (2.20GHz 20Core)

-N8101-1044F: E5-2699 v4 (2.20GHz 22Core)

 Turbo Boost Technology feature *1  Hyper Threading Technology feature *1  High-speed memory access (DDR4 1600/1866/2400 supported) *2  High-speed disk access (SATA 6Gb/s, SAS 12Gb/s supported)  High-speed 10GBASE-SFP+ / 10GBASE-T / 1000BASE-T/100BASE-TX / 10BASE-T interface

(10Gbps / 1Gbps / 100Mbps / 10Mbps supported) can be selected

High reliability

 Processor throttle-ring feature  Memory monitoring feature (error correction/error detection)  Memory degeneracy feature (logical isolation of a failed device)  Memory x4 SDDC feature  Memory mirroring, memory LockStep (x8 SDDC), memory sparing features  Memory throttle-ring feature

Page 21

3. Features

Express5800/R120g-2M User's Guide

Chapter 1 General Description

 Bus parity error detection  Temperature detection  Error detection  Internal fan monitoring feature  Internal voltage monitoring feature  Power redundant feature (hot swapping supported)  RAID system (Disk Array) (An option card is required.)  Auto rebuild feature (hot swapping supported)  BIOS password feature  The security lock that comes with Front Bezel

 Redundant fan configuration

 Fan (hot swapping supported)

 HDD (hot swapping supported)

Management Utilities

 NEC ESMPRO  ExpressUpdate  Remote controlling feature (EXPRESSSCOPE Engine 3)  RAID system management utility (Universal RAID Utility)  Hard disk drive monitoring  Power supply monitoring

Power saving and noiseless design

 Selection of power unit appropriate to environment, work load, and configuration  Power consumption monitoring feature  Power control feature  80 PLUS

Platinum / Titanium certified high efficiency power supply *5

 Fan control appropriate to environment, work load, and configuration  Silent sound design  Enhanced Intel SpeedStep

Technology supported

 Cold redundant feature

Expandability

 PCI Express 3.0 (x8 lanes): 3 slots (Full height) *6  PCI Express 3.0 (x8 lanes): 3 slots (Low profile) *7  PCI Express 3.0 (x8 lanes): 1 slot (dedicated to RAID controller)  PCI Express 3.0 (x8 lanes): 1 slot (dedicated to LOM card)  Large capacity memory of up to 1.5TB *3  Can upgrade to multi-processor system with up to two processors  Expansion Bay (for hard disk drives): up to 16 slots *4  Optical disk drive bay provided as standard  Expansion Bay (for backup unit) provided as standard  USB3.0 interface (Front: 2 ports, rear: 2 ports, internal: 1 port)  USB2.0 interface (Rear: 2 ports, internal: 1 port)  Management LAN port (1 port)  With optional LOM card, two to four LAN ports can be added.

Page 22

3. Features

Express5800/R120g-2M User's Guide

Chapter 1 General Description

Ready to use

 No cable connection is required to install a hard disk drive, additional power supply unit, and redundant fan

unit (hot swap supported).

 Slide rails for each installation

Many built-in Features

 Redundant power supply system supported (valid when optional power supply unit is installed)  El Torito Bootable CD-ROM (no emulation mode) format supported  Software power-off  Remote power-on feature  AC-Link feature  Remote console feature  Power switch mask  Connector for display unit provided on front panel  Baseboard Management Controller (BMC) conforming to IPMI v2.0

Self-diagnosis

 Power On Self-Test (POST)  Test and Diagnosis (T&D) utility

Easy setup

 EXPRESSBUILDER (setup utility)  BIOS Setup utility (SETUP)

Maintenance features

 Off-line Tools  Memory dump feature using DUMP Switch  Feature to backup and restore BIOS/BMC settings using EXPRESSSCOPE Profile Key

*1: Unsupported on Xeon processor E5-2603 v4 embedded models.

*2: Processor core speed depends on processor type, number and type of DIMMs installed.

*3: In 2-CPU configuration. Up to 768GB in 1-CPU configuration.

*4: When N8154-69 2.5-inch HDD cage is installed. 8 slots in standard configuration.

*5: When N8181-118F power unit is installed. Power supply unit N8181-121F/122F/123F is compliant to 80

Plus Platinum.

*6: Can be changed to PCI Express 3.0: 1 slot (x16 lanes) + PCI Express 3.0: 1 slot (x8 lane) or PCI Express

3.0: 1slot (x16 lanes) + PCI Express 3.0: 2slots (x4 lanes) by using optional PCI riser card.

*7: Can be changed to PCI Express 3.0: 1slot (x16 lanes) + PCI Express 3.0: 2slots (x4 lanes) by using

optional PCI riser card.

Page 23

3. Features

Express5800/R120g-2M User's Guide

Chapter 1 General Description

3.1

Firmware and Software Version Management

Use of NEC ESMPRO Manager, ExpressUpdate Agent, and EXPRESSSCOPE Engine 3 allows you to manage versions of firmware and software as well as update them by applying update packages.

This feature automatically updates modules without stopping the system just by specifying the updating packages from NEC ESMPRO Manager.

Page 24

4. Names and Functions of Parts

Express5800/R120g-2M User's Guide

Chapter 1 General Description

Names and Functions of Parts

This section describes the names of the server parts.

4.1

Front View (With Front Bezel)

(1) Front Bezel

A cover for protecting the front of the server. This cover can

be locked with the provided Bezel Lock Key.

(2) Key Slot

A slot for Bezel Lock Key that is used to lock Front Bezel.

(3) LINK/ACT LED

LEDs for showing the status of accessing to the network.

(See page 32)

(3)-1: LAN1 connector

(3)-2: LAN2 connector

(3)-3: LAN3 connector

(3)-4: LAN4 connector

LEDs for LAN3 and LAN4 are lit when optional LOM card

(N8104-154F/156F) is installed.

(4) Power Capping LED

An LED for showing the power capping of the server.

(5) STATUS LED 1,2

LEDs for showing the server status . (See page 31)

(6) Unit ID (UID) LED

An LED for maintaining the server. This LED turns on when

UID Switch is pressed. Commands from the software also

cause it to turn on or flash.

(See page 33)

(7) POWER LED

An LED for showing the power status of server.

(See page 31)

(1)

(2)

(3)(4) (5) (6)(7)

Page 25

4. Names and Functions of Parts

Express5800/R120g-2M User's Guide

Chapter 1 General Description

4.2

Front View (Without Front Bezel)

(8) DISK LED

LEDs for showing the hard disk status.

The LED provided for each HDD.

(See page 34)

(9) 2.5-inch Hard Disk Drive Bay

Bays for installing HDDs. The sequential numbers indicate

the corresponding slot numbers. All bays include Dummy

Trays.

(10) USB Connectors (front)

Connectors for connecting USB interface devices.

(11) RESET Switch

A switch for resetting the server.

(12) DUMP Switch (NMI)

A switch for collecting the memory dump.

(13) BMC RESET Switch

A switch for resetting BMC of the server. Use this switch

only when there is a problem with EXPRESSSCOPE

Engine 3 (BMC). To use this switch, press it at least five

seconds.

(14) POWER Switch/LED

A switch for turning on/off the server. Press once to turn on

the server. POWER LED lights when it is on. Press it again

to turn off the server. Hold down the switch for four seconds

or more to forcibly turn off the server.

(See page 31)

(15) Unit ID (UID) Switch/LED

A switch for turning on/off UID LED.

Pressing the switch once turns on UID LED and pressing

again turns off the LED.

Commands from the software also cause it to turn on or

flash. (See page 33)

(16) Display Connector *1

A connector for connecting a display. This connector

cannot be used with the display connector on rear panel at

the same time.

(17) Pull-out Tab

A tab for showing the model number and serial number of

the server.

(18) 2.5-inch Additional HDD Cage Bay

A bay for installing N8154-68 2.5-inch HDD cage.

(19) Additional Bay (for file backup unit)

A bay for installing an optional RDX drive.

(20) Optical Disk Drive Bay

A bay for installing an optical disk drive.

Either of the following drive can be installed.

– DVD-ROM drive

– DVD SuperMULTI drive

*1 The tray of optical disk drive cannot open depending on the

connector of display cable. Disconnect the display cable

and then open/close the tray.

(8)-1

(9)-0 (9)-2 (9)-4 (9)-6

(9)-1 (9)-3 (9)-5 (9)-7

(18)

(19) (20)

(17)

(10)

(14)

(15)

(16)

(11) (12) (13)

(8)-2

See (3) to (5) on previous page.

Page 26

4. Names and Functions of Parts

Express5800/R120g-2M User's Guide

Chapter 1 General Description

4.3

Rear View

(1) Power Unit (Power supply slot 1)

A power supply for supplying the DC power to the server.

(2) AC Inlet

A socket for connecting the power cord.

(3) AC POWER LED

An LED for showing the power supply status. (See page 37)

(4) Cap Screw

A screw for fixing the top cover.

(5) Slots for Full-height PCI Card

Slots for installing full-height PCI cards.

"1C", "2C", and "3C" indicate PCI slot number.

(6) Slots for low-profile PCI card

Slots for installing low-profile PCI cards.

"1D" and "2D" indicate PCI slot number.

(7) Blank Cover (for power supply #2)

A cover for protecting the bay of power supply #2.

Remove this cover to install an additional power unit.

(8) USB Connectors

Connectors for connecting USB interface devices.

(9) LINK/ACT LED *1

LEDs for showing the access status of LAN. (See page 36)

(10) LAN connectors *1

Connectors for connecting to a network

(1000BASE-T/100BASE-TX/10BASE-T).

(10)-1: LAN1 connector

(10)-2: LAN2 connector

(10)-3: LAN3 connector

(10)-4: LAN4 connector

If Shared BMC LAN feature is enabled in ROM Utility, LAN1

connector can also be used as the management LAN. Sharing

LAN is not recommended from the point of performance and

security.

(11) SPEED LED *1

LEDs for showing the transfer speed of LAN ports.

(See page 36)

(12) Management LAN Connector

A LAN connector which supports

1000BASE-T/100BASE-TX/10BASE-T.

This port cannot be used as a data transmission port.

This port is used for connecting to EXPRESSSCOPE

Engine 3.

(13) Serial Port A (COM) Connector

A connector for connecting serial interface devices.

This cannot directly connect to a network line.

(14) Display Connector

A connector for connecting a display.

This connector cannot be used with the display

connector on front panel at the same time.

(15) UID Switch/LED

A switch for turning on/off UID LED.

Pressing the switch once turns on UID LED and

pressing again turns off the LED.

Commands from the software also cause it to turn on

or flash. (See page .33)

*1 LOM card is optional. The figure above shows when

N8104-154F is installed.

(1)

(2)

(3)

(4) (5)-1C (5)-2C (5)-3C (6)-1D (6)-2D (6)-3D (7)

(13) (14)

(8)

(9) (11)

(12)

(10)-1 (10)-2 (10)-3 (10)-4

(9) (9) (9) (9)

(11) (11) (11) (11)

(16)

Page 27

4. Names and Functions of Parts

Express5800/R120g-2M User's Guide

Chapter 1 General Description

4.4

External View

(1) Top Cover (front)

(2) Release Button.

(3) Top Cover (rear)

(2)

(1)

(3)

Page 28

4. Names and Functions of Parts

Express5800/R120g-2M User's Guide

Chapter 1 General Description

4.5

Internal View

The duct is not shown in the figure below.

(1) Front Panel Board

(mounted beneath the protective cover)

(2) Protective Cover

(3) Backplane

(4) Cooling Fan

-1 FAN1R

-2 FAN2R

-3 FAN3R

-4 FAN4R

-5 FAN5R (option)

-6 FAN1F (option)

-7 FAN2F (option)

-8 FAN3F (option)

-9 FAN4F (option)

-10 FAN5F (option)

FAN1 to FAN4 are factory installed. FAN 5 is required in

2-CPU configuration. FAN6 to FAN10 are used when

optional redundant fan unit is installed.

(5) Support Bar

Can install battery unit on this bar.

(6) Processor (CPU)

Mounted beneath the heat sink.

(7) DIMM (optional)

(8) Motherboard

(9) Slot for LOM Card

Assigned PCI slot number is "1B".

(10) Riser Card

(11) Power Supply Unit

(12) Slot for RAID Controller

Assigned PCI slot number is "1A".

(13) Expansion Bay

(4)-6

(4)-7

(4)-8

(4)-9

(4)-10

(4)-1

(4)-2

(4)-3

(4)-4

(4)-5

(5)(3) (6) (7) (8) (10)

(13) (12) (11)

(1)

(2)

(9)

Page 29

4. Names and Functions of Parts

Express5800/R120g-2M User's Guide

Chapter 1 General Description

4.6

Motherboard

(23)

(8)-1

(27)

(17)

(16)

(19)

(14)

(10)

(9)

(25)

(8)-2

(7)

(6)

(5)

(4)(3)

(2)

(1)-1

(2)

(1)-2

(2)

(18)

(15)

(22)

(20)

(13)

(23)

(21)

(24)

(26)

(28)

(29)

(11)

(13)

(12)

Page 30

4. Names and Functions of Parts

Express5800/R120g-2M User's Guide

Chapter 1 General Description

(1) Processor (CPU) Socket

-1: Processor #1 (CPU #1)

-2: Processor #2 (CPU #2)

(2) DIMM Socket

(3) Front Panel Connector

(4) Fan Board Connector

(5) Power Connector for Fan Unit

(6) Power Connector for SATA Optical Disk Drive

(7) Power Connector for HDD Cage

(8) Power Connector

-1: Standard power unit (POW #1)

-2: Optional power unit (POW #2)

(9) LAN Mezzanine Card Connector

(10) Lithium Battery

(11) Clear NVRAM Jumper Switch

(12) Clear Password Jumper Switch

(13) Unused Connector

(14) USB Memory Module Connector

(15) HDD BP Connector

(16) Connector for Option COM

Connect an additional RS-232C connector kit N8117-01A

to use this port as a serial port.

(17) SPI Mezzanine Connector

EXPRESSSCOPE Profile Key (SPI memory) has been

installed, where BIOS and BMC configuration data is

stored. Relocate it when replacing motherboard to inherit

configuration data.

(18) Power Connector for Optional HDD Cage

(19) Front Video Connector

(20) TPM Kit Connector

(21) SATA Connector (for optical disk drive)

(22) SATA Connector

(23) PCI Riser Card Connector

For the supported card specifications, see Chapter 2 (1.17

PCI card).

(24) Connectors for External Devices (See page 26)

(25) RAID Controller Connector

(26) USB Connector (front)

(27) USB Connector for File Backup Unit

(28) Power Connector for Expander Board

Page 31

4. Names and Functions of Parts

Express5800/R120g-2M User's Guide

Chapter 1 General Description

4.7

Status Indicators

4.7.1

POWER LED ( )

POWER LED indicates power ON/OFF status of the server.

POWER LED pattern Description

On (green) The server is normally powered on.

Off The server is off-powered.

The server is in halt status.

4.7.2

STATUS LED 1,2 ( )

While hardware is operating normally, STATUS LED 1 lights green. STATUS LED 2 is off. STATUS LED 1 is off or STATUS LED 2 lights/flashes amber if there is a hardware failure.

Tips

If NEC ESMPRO is installed, you can view error logs to check the causes of

failures.

If the LED indication does not change even if the action below is performed, contact your sales representative.

STATUS LED pattern

Description Action

STATUS LED 1 STATUS LED 2

On (green) Off The server is operating normally. 

On (green) On (amber) Initialization of BMC is in progress. Wait until initialization of BMC completes. If

the status remains the same after several

minutes pass, contact your sales

representative.

Blinking (green) Off Memory is in a degraded state. Check the electrical system such as power

cords. If there is no problem with the system,

contact your sales representative.

Operating while CPU error is detected.

In redundant power configuration, power is

not supplied to either of power unit.

Off Off The power is off. If the power is not on, Turn on the server. If

POST is in progress, wait until POST

completes. If DUMP switch is pressed, wait

until the memory dump is completed.

If a problem persists after taking these actions,

contact your sales representative.

POST is in progress.

Memory dump is being requested.

Note: It remains green if the dump is caused

by software.

CPU was not recognized.

Watchdog timer expired.

Page 32

4. Names and Functions of Parts

Express5800/R120g-2M User's Guide

Chapter 1 General Description

STATUS LED pattern

Description Action

STATUS LED 1 STATUS LED 2

An uncorrectable memory error was

detected.

A PCI system error occurred

A PCI parity error occurred

A PCI bus error occurred.

Off Blinking(amber) Power Supply Unit is failing (in power

redundant configuration).

Check the internal fan or air inlets for dust.

When dust clings to them, remove it. If the

status remains the same after several minutes

pass, contact your sales representative.

A fan alarm was detected.

A temperature alarm was detected.

A voltage alarm was detected

One or more hard disk drives are failing

(excluding RAID0 or non-RAID

configuration).

Log collection stopped: A correctable

memory error has often occurred.

Off On (amber) Power anomaly was detected

An abnormal temperature was detected.

An abnormal voltage was detected.

A CPU error was detected.

A chipset error was detected.

An uncorrectable memory error was

detected.

SMI Timeout was detected

Sensor error was detected.

An error occurred on Intel Node Manager

(one of the features of EXPRESSSCOPE

Engine 3).

4.7.3

LINK/ACT LED ( 1, 2, 3, 4)

LINK/ACT LED on front panel indicates the status of LAN port.

LEDs 3 and 4 turns on, off, or flashes when an optional LAN riser card is installed.

LINK/ACT LED pattern Description

On (green) The server is connected with network normally.

Blinking (green) The server is accessing network.

Off The server is disconnected from network.

4.7.4

Optical Disk Drive Access LED (option)

The LED for optical disk drive at the front of the server flashes when a CD or DVD is being accessed.

Page 33

4. Names and Functions of Parts

Express5800/R120g-2M User's Guide

Chapter 1 General Description

4.7.5

UID LED (ID)

UID LED is provided one each at the front and rear of the server. If you press UID Switch provided at the front or rear of the server, the light turns on. If you press it again, the light turns off. It flashes when commands from software are received.

This LED is used to identify the target server among multiple servers installed in a rack. Especially when performing maintenance from behind the server, lighting the LED will help you to identify which server to work with.

UID LED pattern Description

On (blue) The UID switch is pressed.

Off The UID switch is not pressed.

4.7.6

Power Capping LED

Power Capping LED indicates enabled/disabled status of Power Capping feature as shown below.

Power Capping LED pattern Description

On (green) Power Capping feature is enabled.

Blinking (green) Power Capping is enabled and power control (capping) is working.

Off Power Capping feature is disabled.

Note

The Power Capping LED seems to be lit or blinking amber when STATUS LED is lit or

blinking amber. The amber STATUS LED indicates a hardware failure. Contact your

service representative.

Page 34

4. Names and Functions of Parts

Express5800/R120g-2M User's Guide

Chapter 1 General Description

4.7.7

LED on a hard disk drive

Each HDD is equipped with DISK LED.

DISK LED pattern

Description Action

DISK LED 1 DISK LED 2

Blinking (green) Off Hard disk drive is being accessed. –

Off On (amber)

(RAID system only)

Hard disk drive is failing. Contact your sales representative.

Blinking (green) Blinking (amber )

(RAID system only)

Rebuilding is in progress.

When the failed hard disk drive is replaced,

rebuilding process starts automatically (auto

rebuilding feature).

–

Off Off Hard disk drive is halted. –

Important

Observe the following precautions whenever you use the auto rebuilding

feature.

 Do not turn off or reboot the server while a HDD is being rebuilt.  Wait for at least 90 seconds before installing a HDD after removing one.  Do not replace a HDD while another HDD is being rebuilt.

DISK LED 1 (green)

DISK LED 2 (amber)

Page 35

4. Names and Functions of Parts

Express5800/R120g-2M User's Guide

Chapter 1 General Description

4.7.8

LEDs for LAN connectors

The LAN connectors on rear panel have LINK/ACT LED and SPEED LED.

When an optional LOM card N8104-154F is installed:

When an optional LOM card N8104-155F is installed:

Management LAN

connector

LAN connectors

LINK/ACT LED

SPEED LED

LINK/ACT LED

SPEED LED

1 2

Management LAN

connector

LAN connectors

LINK/ACT LED

SPEED LED

LINK/ACT LED

SPEED LED

Page 36

4. Names and Functions of Parts

Express5800/R120g-2M User's Guide

Chapter 1 General Description

When an optional LOM card N8104-156F is installed:

 LINK/ACT LED ( 1, 2, 3, 4, M)

This LED indicates the state of the LAN port.

LINK/ACT LED pattern Description

On (green) The server is connected with network normally.

Blinking (green) The server is accessing network.

Off The server is disconnected from network.

 SPEED LED ( 1, 2, 3, 4, M)

This LED indicates which network interface is used.

N8100-154F 1000BASE-T LOM Card (4ch)

SPEED LED pattern Description

On (amber) The port is operating with 1000BASE-T interface.

On (green) The port is operating with 100BASE-TX interface.

Off The port is operating with 10BASE-T interface.

N8104-155F 10GBASE-T LOM Card (2ch)

SPEED LED pattern Description

On (green) The port is operating with 10BASE-T interface.

On (amber) The port is operating with 1000BASE-T interface.

Off The port is operating with 10BASE-TX interface.

LNK ACT

Management LAN

connector

LAN connectors

LINK/ACT LED

SPEED LED

LINK/ACT LED

SPEED LED

Page 37

4. Names and Functions of Parts

Express5800/R120g-2M User's Guide

Chapter 1 General Description

N8104-156F 10GBASE-SFP+(2ch)+1000BASE-T(2ch) LOM Card

・When operating in 10GBASE-SFP+

SPEED LED pattern Description

On (green) The port is operating with 10GBASE-SFP+.

On (amber) The port is operating with 1000BASE-SFP+ interface.

Off The port is not operating

・When operating in 1000BASE-T

SPEED LED pattern Description

On (amber) The port is operating with 1000BASE-T interface.

On (green) The port is operating with 100BASE-TX

Off The port is operating with 10BASE-T interface.

4.7.9

AC POWER LED on Power Unit

The power unit is equipped with AC POWER LED.

AC POWER LED pattern Description Action

On (green) The server is powered on. –

Blinking (green) The power cable is connected and AC power is

supplied.

–

Cold Redundant feature is enabled (see page

112).

–

On (amber) The power cable is not connected in redundant

power configuration.

Connect the power cable.

Power unit is failing. Contact your sales representative.

Blinking (amber) Power unit is failing. Contact your sales representative.

Off The power is not supplied to the server. Connect the power cable. If it is already

connected, contact your sales representative.

AC POWER LED

Page 38

Express5800/R120g-2M User’s Guide

NEC Express5800 Series Express5800/R120g-2M

Preparations

This chapter describes preparations for using this server.

1. Installing Internal Optional Devices

You can skip this section if you did not purchase any optional devices.

2. Installation and Connection

Place the server in a suitable location and connect cables following this section.

Page 39

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Installing Internal Optional Devices

This section describes the instructions for installing supported optional devices and precautions.

Important

Use only the devices and cables specified by NEC. You will be charged to

repair damages, malfunctions, and failures caused by the use of any devices

or cables not specified for use with this server even within the warranty

period.

1.1

Safety Precautions

Be sure to observe the following precautions to install and remove optional devices properly and safely.

WARNING

Be sure to observe the following precautions to use the server safety. Failure to

observe the precautions may cause death or serious injury. For details, see

Safety Precautions and Regulatory Notices.

 Do not disassemble, repair, or modify the server.  Do not remove the lithium battery, NiMH battery, or Li-ion battery.  Disconnect the power plug when installing and removing devices.

CAUTION

Be sure to observe the following precautions to use the server safely. Failure to

observe the precautions may cause burns, injury, and property damage. For

details, see Safety Precautions and Regulatory Notices.

 Do not drop  Do not leave the server being pulled out.  Make sure to complete installation.  Do not install with the cover removed.  Do not get your fingers caught.  High temperature  Electrical shock

Page 40

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.2

Overview of Installation and Removal

Install/remove components by using the following procedure.

CAUTION

Be sure to observe the following precautions to use the server safely. Failure to

observe the precautions may cause burns, injury, and property damage. For

details, see Safety Precautions and Regulatory Notices.

 Do not drop the server  Do not leave the server pulled out of the rack  Replace the cover after installing components  Beware of high temperatures  Do not get your fingers caught when installing components

1. If the server is mounted on a rack, use the UID switch to identify the target server. See Chapter 2 (1.3 Identifying Servers (UID Switch)).

2. Remove Front Bezel. See Chapter 2 (1.4 Removing Front Bezel).

3. Turn off the server. See Chapter 3 (6. Turning Off the Server).

4. Disconnect the power cord from the outlet and the server.

Important

 After disconnecting the power cord from the server, wait for at least 30

seconds before installing/removing optional devices.

 Make sure AC POWER LED on power supply unit is unlit.

5. If you install a hard disk drive only, go to step 14, and if you install a power suppply unit only, go to step

15. If not, pull out the server from rack and put it on a flat rigid desk. See Chapter 2 (2.1 Installation).

Important

Do not leave the server being pulled out from the rack.

6. Remove Top Cover. See Chapter 2 (1.5 Removing Top Cover).

7. Remove PCI riser card. See Chapter 2 (1.6 Removing PCI Riser Card).

8. Remove the support bar. See Chapter 2 (1.7 Removing Support Bar).

9. Depending on the components to be installed or removed, follow the procedure in order. See Chapter 2 (1.9 TPM Kit) to (1.21 Use of Internal Hard Disk Drives in the RAID System).

10. Mount the support bar. See Chapter 2 (1.23 Installing Support Bar).

Page 41

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

11. Mount PCI riser card. See (1.24 Installing PCI Riser Card).

12. Attach Top Cover. See Chapter 2 (1.25 Installing Top Cover).

13. Mount the server onto the rack. See Chapter 2 (2.1.2 (1) Installation).

14. Install hard disk drives. See Chapter 2 (1.26 Hard Disk Drive).

15. Install power supply units See Chapter 2 (1.27 Power Supply Unit).

16. Attach Front Bezel. See Chapter 2 (1.28 Installing Front Bezel).

Installation and removal for internal optional devices are now complete.

Continue the setup with reference to Chapter 2 (2.2 Connection).

Page 42

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.3

Identifying Servers (UID Switch)

Using UID (Unit ID) Switch helps you to identify the target server.

When the server is working, be sure to identify the target server by using UID Switch first before you turn off the server or disconnect a cable from the server.

To turn UID LED on, press UID Switch. When it is pressed again, the LED will be off.

UID switch

Page 43

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.4

Removing Front Bezel

Remove the front bezel when pressing the POWER switch or removing Top Cover.

1. To unlock the bezel, insert the attached Bezel Lock Key into the key slot and turn the key while pressing it lightly.

2. Hold the left end of front bezel and pull the right end toward you about 10 cm. Check that the hook in left is removed as illustrated in the figure below and remove the left end from the chassis.

Note

Be careful not to press the POWER Switch.

Important

If you fail to remove the front bezel properly, the front bezel might be

damaged.

解除ロック

Locked

Unlocked

(1) Hold the

handle

(2) Pull and rotate about 10

degrees

(3) Pull the bezel

Hook

Views from above

Page 44

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.5

Removing Top Cover

Remove Top Cover when installing or removing the optional component or change internal cable connection.

1. See steps 1 to 5 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Slide Top Cover (front) toward the front of the server while pressing Release Button on the cover.

3. Lift Top Cover (front), and remove it from the server.

Tips

Screw holes on the place where front and rear top covers overlap each other, are not

used.

4. Loosen the cap screw of Top Cover (rear), and slide the cover toward the rear of the server.

5. Lift Top Cover (rear) and remove it from the server.

Page 45

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.6

Removing PCI Riser Card Unit

Remove the PCI riser card unit when installing or removing the following component:

LOM card DIMM (memory module)

Processor (CPU) TPM kit

2.5-inch additional HDD cage PCI riser card

PCI card RAID controller

Flash Backup Unit for RAID controller

1. See steps 1 to 6 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Remove the four screws from PCI riser card unit.

3. Lift the PCI riser card unit, and remove it from the server.

Page 46

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.7

Removing Support Bar

Remove the support bar when installing or removing the following component:

DIMM (memory module) Processor (CPU)

2.5-inch additional HDD cage PCI card

Flash Backup Unit for RAID controller 3.5-inch backup device

1. See steps 1 to 7 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Remove the two screws from support bar.

3. Lift the support bar, and remove it from the server.

Page 47

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.8

Removing Air Duct

Remove the air duct when installing or removing the following component or changing internal cable connection:

DIMM (memory module) Processor (CPU)

2.5-inch additional HDD cage

1. See steps 1 to 8 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Lift the air duct, and remove it from the server.

Important

Before removing the air duct, pull the cables upward and remove it. Otherwise,

cables may be damaged if they are pulled together with air duct.

Page 48

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.9

TPM Kit

This section describes the procedure for installing optional TPM Kit.

Installation

1.9.1

Install TPM Kit in the following procedure.

1. See steps 1 to 7 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Install TPM Kit and secure it by pushing the nylon rivet attached to TPM Kit.

Important

TPM Kit once installed cannot be removed.

Ask your sales representative if you want to remove the TPM kit.

Page 49

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.10

Processor (CPU)

You can configure the multi-processor system by adding an optional processor.

Important

 To avoid static electricity, see Chapter 1 (1.8 Anti-static Measures) in Safety

Precautions ans Regulatory Notices.

 Make sure to use the CPU authorized by NEC. Installing a third-party CPU

may cause a failure of the CPU as well as the motherboard. Repair of the

server due to failures or damage resulted from installing such a CPU will be

charged.

Tips

After adding the CPU, Windows may record the event log to System catogory of

Event Viewer, but it is no problem for operation.

Maximum number of processor cores supported by this server

1.10.1

The maximum number of processor cores (logical processors) available on the server depends on the architecture (x86 architecture) and OS specs.

Maximum number of processor cores

The maximum number of

logical processors

supported by OS

The maximum number of logical

processors supported by this

server

Microsoft Windows Server 2008 R2 Standard (x64) Microsoft Windows Server 2008 R2 Enterprise (x64)

256 *1 88

Microsoft Windows Server 2012 Standard Microsoft Windows Server 2012 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Datacenter

640 *1 88

VMware ESXi 5.5 320 88

VMware ESXi 6.0 480 88

*1: When Hyper-V is used, the maximum number of logical processors is as shown below:

- Windows Server 2008 R2: 64

- Windows Server 2012, Windows Server 2012 R2: 320

Page 50

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Installation

1.10.2

Follow the steps below to install the CPU.

1. See steps 1 to 6 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Locate the CPU socket to which you are going to install a CPU.

3. Remove the screws that secure the dummy cover, and remove the cover.

Note

Keep the removed dummy cover for future use.

4. Remove the protective cover from the CPU socket.

Note

Keep the removed protective cover for future use.

5. Push down the socket lever marked with " " once to unlatch it from the hook, and then slowly open the lever until it stops.

Page 51

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

6. Push down the socket lever marked with " " once to unlatch it from the hook, and then slowly open the lever until it stops.

7. Lift the plate.

Important

Do not touch the socket contacts.

8. Put the additional CPU on the CPU socket slowly and gently.

For easy installation, hold edges of CPU with your thumb and index fingers so that the notch is aligned with the key on the CPU socket.

Important

 Be sure to hold the CPU only at the edges.  Pay attention not to touch the bottom of the CPU.

Note

 Insert the CPU while aligning the notch on the CPU with the key on the CPU

socket.

 Bring down the CPU straight without tilting or sliding it in the socket.

Page 52

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

9. Lightly push the CPU to the CPU socket, and close the plate.

10. Close the socket lever marked with " " to fix it.

11. Close the socket lever marked with " " to fix it.

12. Put the heat sink on the CPU and temporarily tighten the four screws diagonally, and then tighten them securely.

Make sure that the screw aligns with the screw hole. If not, the screw may damage the motherboard.

Page 53

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

13. Make sure that the heat sink is installed on a level with the motherboard.

Note

 If the heat sink is not level, remove it, and then install it again.

The following probably causes the heat sink not to be level:

– The CPU is not positioned correctly.

– All screws are not completely tightened.

 Do not move the secured heat sink.

14. Install an additional fan unit provided with additional CPU kit. See Chapter 2 (1.14 Additional / Redundant Fan Unit) for how to install an additional fan unit.

15. Continue to install or remove internal optional devices, mount and connect the server, and turn on the server.

16. Run BIOS Setup Utility (SETUP) to confirm the following settings. See Chapter 2 (1. System BIOS) in "Maintenance Guide".

Advanced  Processor Configuration  Processor Information

[CPU ID] [L2 Cache RAM] [L3 Cache RAM]

17. Select Server  Power Measurement Policy, set One Time, and then select Save Changes and Exit.

Replacement / Removal

1.10.3

Important

 Do not remove any CPU unless it is failed.  To remove the heat sink from the CPU, first turn the heat sink to the left and

right lightly to make sure that the heat sink can be apart from the CPU.

Removing the heat sink with it adhering to the CPU may cause the CPU

and/or CPU socket to be defected.

To remove CPU, reverse the installation procedure.

After replacement or removal, select Server  Power Measurement Policy, set One Time, and then select Save Changes and Exit.

Also follow the steps below if the CPU was removed.

1. Mount the protective cover to CPU socket.

2. Secure the dummy cover to the socket with four screws.

3. Remove the additional fan unit.

4. Mount the fan cover.

Page 54

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.11

DIMM

Install a Dual Inline Memory Module (DIMM) to a DIMM slot on the motherboard in the server. The motherboard provides 24 slots to install DIMMs.

Important

 To avoid static electricity, see Chapter 1 (1.8Anti-static Measures) in Safety

Precautions and Regulatory Notices.

 Use only the specified DIMMs. Installing a DIMM from a third party may

damage not only the DIMM but the motherboard. You will be charged to

repair failures or damages caused by the use of such products even within

the warranty period.

Tips

Up to 1536GB (64 GB x 24) can be installed in 2-CPU configuration. Up to 768 GB

(64 GB x 12) can be installed in 1-CPU configuration. No DIMM is factory installed

in standard configuration.

Maximum supported memory size

1.11.1

The maximum available memory size on the server depends on the architecture and OS specs.

Maximum memory sizes

The maximum

memory size

supported on each OS

The maximum memory size

supported on the server

Microsoft Windows Server 2008 R2 Standard *1 32GB 32GB

Microsoft Windows Server 2008 R2 Enterprise *1 2TB 1.5TB

Microsoft Windows Server 2012 Standard *1 Microsoft Windows Server 2012 Datacenter *1 Microsoft Windows Server 2012 R2 Standard *1 Microsoft Windows Server 2012 R2 Datacenter *1

4TB 1.5TB

VMware ESXi 5.5 *2 4TB 1.5TB

VMware ESXi 6.0 *3 6TB 1.5TB

*1: Shown below is the maximum memory size when Hyper-V is used:

- Windows Server 2008 R2 Standard : 32GB

- Windows Server 2008 Enterprise, Windows Server 2008 R2 Enterprise : 1TB

- Windows Server 2012 ,Windows Server 2012 R2: 4TB

*2: Up to 1 TB on virtual machine *3: Up to 4 TB on virtual machine. .

Page 55

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Memory Clock

1.11.2

The actual memory clock speed depends on CPU and memory configuration.

Code number

(CPU)

DIMM type Clock speed

N8101-1029F (E5-2603v4)

N8102-663F 8GB DDR4-2400 REG Memory Kit (2x4GB)

1866 MHz

N8102-664F 16GB DDR4-2400 REG Memory Kit (2x8GB)

N8102-665F 32GB DDR4-2400 REG Memory Kit (2x16GB)

N8102-666F 64GB DDR4-2400 REG Memory Kit (2x32GB)

N8102-667F 128GB DDR4-2400 TSV REG Memory Kit (2x64GB)

N8102-669 16GB DDR4-2400 REG Memory Kit (2x8GB)

N8102-670 32GB DDR4-2400 REG Memory Kit (2x16GB)

N8102-672 24GB DDR4-2400 REG Memory Kit (3x8GB)

N8102-673 48GB DDR4-2400 REG Memory Kit (3x16GB)

N8101-1030F (E5-2620v4)

N8101-1031F

(E5-2623v4)

N8101-1032F

(E5-2630v4)

N8101-1034F (E5-2640v4)

N8102-663F 8GB DDR4-2400 REG Memory Kit (2x4GB)

2133 MHz

N8102-664F 16GB DDR4-2400 REG Memory Kit (2x8GB)

N8102-665F 32GB DDR4-2400 REG Memory Kit (2x16GB)

N8102-666F 64GB DDR4-2400 REG Memory Kit (2x32GB)

N8102-667F 128GB DDR4-2400 TSV REG Memory Kit (2x64GB)

N8102-669 16GB DDR4-2400 REG Memory Kit (2x8GB)

N8102-670 32GB DDR4-2400 REG Memory Kit (2x16GB)

N8102-672 24GB DDR4-2400 REG Memory Kit (3x8GB)

N8102-673 48GB DDR4-2400 REG Memory Kit (3x16GB)

Page 56

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Code number

(CPU)

DIMM type Clock speed

N8101-1033F (E5-2637v4)

N8101-1035F (E5-2643v4)

N8101-1036F (E5-2650v4)

N8101-1038F (E5-2667v4)

N8101-1039F (E5-2680v4)

N8101-1040F (E5-2690v4)

N8101-1041F (E5-2697v4)

N8101-1042F (E5-2697Av4)

N8101-1043F

(E5-2698v4)

N8101-1044F (E5-2699v4)

N8102-663F 8GB DDR4-2400 REG Memory Kit (2x4GB)

2400 MHz

N8102-664F 16GB DDR4-2400 REG Memory Kit (2x8GB)

N8102-665F 32GB DDR4-2400 REG Memory Kit (2x16GB)

N8102-666F 64GB DDR4-2400 REG Memory Kit (2x32GB)

N8102-667F 128GB DDR4-2400 TSV REG Memory Kit (2x64GB)

N8102-669 16GB DDR4-2400 REG Memory Kit (2x8GB)

N8102-670 32GB DDR4-2400 REG Memory Kit (2x16GB)

N8102-672 24GB DDR4-2400 REG Memory Kit (3x8GB)

N8102-673 48GB DDR4-2400 REG Memory Kit (3x16GB)

Page 57

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Memory RAS Feature

1.11.3

The server supports the following RAS features. See Chapter 2 (1.11.8 Using Memory RAS Feature) for conditions of using each feature.

 Standard memory feature (x4 SDDC ECC memory)  Memory Mirroring feature  Memory LockStep feature (x8 SDDC ECC memory)  Memory Sparing feature

Supported RAS features depend on additiional memory board. See the table below for RAS features supported by additiional memory board.

Memory RAS features supported by additiional memory board

Model number and

Product name

Standard

feature

(x4 SDDC)

Memory

Mirroring

feature

Memory

LockStep

feature

(x8 SDDC)

Memory Sparing

feature

N8102-663F 8GB DDR4-2400 REG Memory Kit (2x4GB)



N8102-664F 16GB DDR4-2400 REG Memory Kit (2x8GB)



N8102-665F 32GB DDR4-2400 REG Memory Kit (2x16GB)



N8102-666F 64GB DDR4-2400 REG Memory Kit (2x32GB)



N8102-667F 128GB DDR4-2400 TSV REG Memory Kit (2x64GB)



N8102-669 16GB DDR4-2400 REG Memory Kit (2x8GB)

 

N8102-670 32GB DDR4-2400 REG Memory Kit (2x16GB)

 

N8102-672 24GB DDR4-2400 REG Memory Kit (3x8GB)



N8102-673 48GB DDR4-2400 REG Memory Kit (3x16GB)



: Supported

Page 58

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

DIMM installation order

1.11.4

Note

See Memory RAS features supported by additiional memory board in 1.11.3

Memory RAS Feature before using memory RAS feature.

In 1-CPU configuration, install two DIMMs starting from the smallest slot number. If CPU2 is not installed, CPU2_DIMM1 to CPU2_DIMM12 are not available.

In 2-CPU configuration, alternately install two DIMMs starting from the smallest slot number of each CPU.

See the table below to find allowable combination of DIMMs. Any other combination of DIMMs than described in this table is not allowed.

Code number

N8102-

663F 664F 665F 666F 667F 669 670 672 673

N8102-663F

   

N8102-664F    

N8102-665F    

N8102-666F

   

N8102-667F 

N8102-669  

N8102-670

 

N8102-672 

N8102-673 

: Allowed to be install together.

1CPU

configuration

2CPU

configuration

2 4 6 2 4 6

5 3 1 5 3 1

3 7

9 5 1 9 5 1 4 8

4 8

6 2

CPU1_DIMM 3 CPU1_DIMM 7 CPU1_DIMM 11 CPU1_DIMM 4 CPU1_DIMM 8 CPU1_DIMM 12

CPU1_DIMM 10 CPU1_DIMM 6 CPU1_DIMM 2 CPU1_DIMM 9 CPU1_DIMM 5 CPU1_DIMM 1 CPU2_DIMM 3 CPU2_DIMM 7 CPU2_DIMM 11 CPU2_DIMM 4 CPU2_DIMM 8 CPU2_DIMM 12

CPU2_DIMM 10 CPU2_DIMM 6 CPU2_DIMM 2 CPU2_DIMM 9 CPU2_DIMM 5 CPU2_DIMM 1

Page 59

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Installation

1.11.5

Follow the steps below to install a DIMM.

1. See steps 1 to 6 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Open levers on left and right sides of DIMM slot, and remove the dummy cover.

Note

Keep the removed dummy cover for future use.

3. Push the DIMM straight into the slot. When a DIMM is inserted into the slot, the lever automatically closes.

Important

 Make sure the orientation of the DIMM. The DIMM has a notch, preventing

being incorrectly inserted.

 Do not apply too much pressure when you push a DIMM into the slot.

Doing so can damage the socket or terminal part.

4. Continue to install or remove internal optional devices, mount and connect the server, and turn on the server.

5. Confirm that no error messages are displayed in POST screen. If any error messages are displayed, see Chapter 3 (1. POST Error Message) in "Maintenance Guide".

6. Run BIOS Setup Utility, and select Advanced  Memory Configuration  Memory Information. Make sure the capacity of added DIMM is displayed properly. See Chapter 2 (1. System BIOS) in "Maintenance Guide".

7. Select Advanced  Memory Configuration  Memory Retest, and set Yes.

8. Select Server  Power Measurement Policy, set One Time, and then select Save Changes and Exit.

9. Set the size of Paging File to the recommended size (1.5x total memory size) or more. If using a Windows OS, see Chapter 1 (6.1 Specifying Memory Dump Settings (Debug Information)) in "Installation Guide (Windows)". For other OS, follow the manual of the OS.

Key

Notch

Page 60

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Removal / Replacement

1.11.6

To remove DIMM, reverse the installation procedure.

Be sure to install dummy cover to the slots from where DIMMs are removed.

Important

Failing to install dummy cover to vacant slot may cause malfunction of the

server due to insufficient cooling effect.

Note

When removing a defective DIMM, check error messages displayed at POST or

NEC ESMPRO and check the DIMM socket where the defective DIMM is installed.

Follow the steps below after replacing or removing DIMMs.

1. Confirm that no error messages are displayed on POST. If any error message is displayed, see Chapter 3 (1. Post Error Message) in "Maintenance Guide".

2. Run BIOS Setup Utility, select Advanced  Memory Configuration  Memory Retest, and set Yes.

3. Select Server  Power Measurement Policy, set One Time, and then select Save Changes and Exit.

4. Set the size of Paging File to the recommended size (1.5x total memory size) or more. If using a Windows OS, see Chapter 1 (6.1 Specifying Memory Dump Settings (Debug Information)) in "Installation Guide (Windows)". For other OS, follow the manual of the OS.

Cluster On Die and Early Snoop features

1.11.7

Advanced  Memory Configuration submenu in BIOS Setup Utility has two options, listed in the following table.

Option Parameter Description Cluster On Die [Disabled]

Enabled

Enables or disables the Cluster On Die feature. This option can be set to Enabled when NUMA is enabled and the processor(s) support(s) the Cluster On Die feature.

- Note: If you use the OS below, this item must be disabled.

- VMware ESXi 5

Early Snoop Disabled

[Enabled]

Enables or disables the early snoop mode for processor(s) snoop mode. This option can be set to Enabled when Cluster On Die is disabled.

[ ] : Factory setting

Read the following when enabling the Cluster On Die feature.

1CPU configuration

Memory RAS Mode: Independent / Mirroring / Lockstep

At least, all of CPU1_DIMM1 to DIMM4 must be filled by DIMM.

Memory RAS Mode: Sparing

At least, all of CPU1_DIMM1 to DIMM3, DIMM5 to DIMM7, DIMM9 to DIMM11 must be filled by DIMM.

2CPU configuration

Memory RAS Mode: Independent / Mirroring / Lockstep

At least, all of CPU1_DIMM1 to DIMM4 and CPU2_DIMM1 to DIMM4 must be filled by DIMM.

Memory RAS Mode: Sparing

At least, all of CPU1_DIMM1 to DIMM3, DIMM5 to DIMM7, DIMM9 to DIMM11 and CPU2_DIMM1 to DIMM3, DIMM5 to DIMM7, DIMM9 to DIMM11 must be filled by DIMM.

In order to effectively utilize the Cluster On Die feature, the following DIMM installed number is recommended.

1CPU configuration

Memory RAS Mode: Independent / Mirroring / Lockstep

Mount DIMMs to CPU1_DIMM1 to DIMM8 slot, or mount DIMMs to CPU1_DIMM1 to DIMM12 slot.

Memory RAS Mode: Sparing

Mount DIMMs to CPU1_DIMM1 to DIMM12 slot.

Page 61

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

- 2CPU configuration

Memory RAS Mode: Independent / Mirroring / Lockstep

Mount DIMMs to CPU1_DIMM1 to DIMM8 and CPU2_DIMM1 to DIMM8 slot, or mount DIMMs to CPU1_DIMM1 to DIMM12 and CPU2_DIMM1 to DIMM12 slot.

Memory RAS Mode: Sparing

Mount DIMMs to CPU1_DIMM1 to DIMM12 and CPU2_DIMM1 to DIMM12 slot.

See 1.11.4 DIMM installation order.

In 1-CPU configuration (Memory RAS Mode: Independent / Mirroring / Lockstep)

DIMMs

count

Cluster On Die

feature

DIMM slot number to be installed

1 set Not available N/A 2 set Available CPU1_DIMM1 to DIMM4 3 set Available CPU1_DIMM1 to DIMM6

4 set

Available (recommended)

CPU1_DIMM1 to DIMM8

5 set Available CPU1_DIMM1 to DIMM10

6 set

Available (recommended)

CPU1_DIMM1 to DIMM12

In 1-CPU configuration (Memory RAS Mode: Sparing)

DIMMs

count

Cluster On Die

feature

DIMM Slot number to be installed

1 set Not available N/A 2 set Not available N/A

3 set Available

CPU1_DIMM1 to DIMM3, CPU1_DIMM5 to DIMM7,

CPU1_DIMM9 to DIMM11

4 set

Available (recommended)

CPU1_DIMM1 to DIMM12

In 2-CPU configuration (Memory RAS Mode : Independent / Mirroring / Lockstep)

DIMMs

count

Cluster On Die

feature

DIMM slot number to be installed

2 set Not available N/A 3 set Not available N/A 4 set Available CPU1_DIMM1 to DIMM4, CPU2_DIMM1 to DIMM4 5 set Available CPU1_DIMM1 to DIMM6, CPU2_DIMM1 to DIMM4 6 set Available CPU1_DIMM1 to DIMM6, CPU2_DIMM1 to DIMM6 7 set Available CPU1_DIMM1 to DIMM8, CPU2_DIMM1 to DIMM6

8 set

Available (recommended)

CPU1_DIMM1 to DIMM8, CPU2_DIMM1 to DIMM8

9 set Available CPU1_DIMM1 to DIMM10, CPU2_DIMM1 to DIMM8 10 set Available CPU1_DIMM1 to DIMM10, CPU2_DIMM1 to DIMM10 11 set Available CPU1_DIMM1 to DIMM12, CPU2_DIMM1 to DIMM10

12 set

Available (recommended)

CPU1_DIMM1 to DIMM12, CPU2_DIMM1 to DIMM12

In 2-CPU configuration (Memory RAS Mode: Sparing):

DIMMs

count

Cluster On Die

feature

DIMM Slot number to be installed

2 set Not available N/A 3 set Not available N/A 4 set Not available N/A 5 set Not available N/A

6 set Available

CPU1_DIMM1 to DIMM3, CPU1_DIMM5 to DIMM7,

CPU1_DIMM9 to DIMM11

CPU2_DIMM1 to DIMM3, CPU2_DIMM5 to DIMM7,

CPU2_DIMM9 to DIMM11

7 set Available

CPU1_DIMM1 to DIMM12,

CPU2_DIMM1 to DIMM3,CPU2_DIMM5 to DIMM7,

CPU2_DIMM9 to DIMM11

8 set

Available (recommended)

CPU1_DIMM1 to DIMM12, CPU2_DIMM1 to DIMM12

Page 62

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Using Memory RAS Feature

1.11.8

This server has RAS feature including Standard Memory feature (x4 SDDC ECC memory), Memory Mirroring feature, Memory Sparing feature, and Memory Lock Step (x8 SDDC ECC memory) feature. SDDC (Single Device Correction) allows automatic correction of memory error (multi-bit error).

Note

 See Memory RAS features supported by additiional memory board in 1.11.3

Memory RAS Feature before using memory RAS feature.

 Only the features that additiional memory board support can be used.

The memory area on the motherboard of the server is divided into four memory channels.

Memory Mirroring, Memory Lock Step, and Memory Sparing features keep memory redundancy between memory channels by monitoring or altering memory active/inactive status, respectively.

Memory controller

Page 63

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

(1)

Memory Mirroring Feature

Memory Mirroring feature writes the same data into two groups of DIMMs (mirror set) corresponding with each other between memory channels (channels 0 and 1 or channel 2 and 3) to provide data redundancy.

Note

 Memory Mirroring feature uses channels 0 and 1 or channels 2 and 3.  To use Memory Mirroring feature, install N8102-669/670 additional memory

board (two DIMMs of same model).

 DIMMs used in mirror set must be of the same model number.

Example: 2-CPU configuration

Tips

The operating system recognizes a half of the total physical capacity.

Memory controller

Mirror set

#11

Mirror set

#12

Mirror set

#10

Mirror set

Data 1

Data 2

Data 3

Data 4

Data 1

Data 2

Data 3

Data 4

Page 64

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Memory Mirroring feature can be used under the following conditions:

 Install DIMMs in DIMM slots to configure a mirror set.

 All the installed DIMMs should have the same capacity.

 Run BIOS Setup Utility (SETUP), change parameters as shown below, save the settings, and exit.

Advanced  Memory Configuration  Memory RAS Mode  Mirroring Server  Power Measurement Policy  One Time

 After restart, run SETUP again, and check if "Mirrored" is displayed for the following parameter.

Advanced  Memory Configuration  Memory Information  CPUx_DIMMx Status

 Installation order depends on CPU configuration. See the figure below.

Memory Mirroring cannot be configured in the following case:

 Memory Mirroring within the same memory channel

Notes on Configuring Memory Mirroring

In Memory Mirroring configuration, Memory RAS Mode menu is changed from "Mirroring" to "Independent" in the following cases:

 When you additionally install DIMMs that unable to configure Memory Mirroring  When you remove DIMMs that takes down Memory Mirroring

1CPU 構成

搭載順序

2CPU 構成

搭載順序

2 4 6 2 4 6

5 3 1 5 3 1

3 7

9 5 1 9 5 1 4 8

4 8

6 2

CPU1_DIMM 3 CPU1_DIMM 7 CPU1_DIMM 11 CPU1_DIMM 4 CPU1_DIMM 8 CPU1_DIMM 12

CPU1_DIMM 10 CPU1_DIMM 6 CPU1_DIMM 2 CPU1_DIMM 9 CPU1_DIMM 5 CPU1_DIMM 1 CPU2_DIMM 3 CPU2_DIMM 7 CPU2_DIMM 11 CPU2_DIMM 4 CPU2_DIMM 8 CPU2_DIMM 12

CPU2_DIMM 10 CPU2_DIMM 6 CPU2_DIMM 2 CPU2_DIMM 9 CPU2_DIMM 5 CPU2_DIMM 1

1CPU

configuration

2CPU

configuration

Page 65

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

(2)

Memory Lock Step Feature (x8 SDDC)

In Memory Lock Step feature, the DIMMs in two groups corresponding to two memory channels (channels 0 and 1, or channels 2 and 3) is multiplexed and operated in parallel to enable x8 SDDC (x8 Single Device Data Correction). With this feature, one DIMM can detect and correct one to eight-bit error.

Note

 Memory LockStep feature uses channels 0 and 1 or channels 2 and 3.  To use Memory LockStep feature, install N8102-669/670 additional memory

board (two DIMMs of same model).

 DIMMs used in LockStep set must be of the same model number.

LockStep Set

#10

LockStep Set

#11

LockStep Set

#12

LockStep Set

Memory controller

Page 66

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Memory Lock Step feature can be used under the following conditions:

 Install DIMMs in DIMM slots to configure a Lock Step set.

 All the installed DIMMs should have the same capacity.

 Run BIOS Setup Utility (SETUP), change parameters as shown below, save the settings, and exit.

Advanced  Memory Configuration  Memory RAS Mode  LockStep Server  Power Measurement Policy  One Time

 After restart, run SETUP again, and check if "Lock Step" is displayed for the following parameter.

Advanced  Memory Configuration  Memory Information  CPUx_DIMMx Status

 Installation order depends on CPU configuration. See the figure below.

Memory Lock Step cannot be configured in the following cases:

 Memory Lock Step between memory channels of different memory controllers (CPU)  Memory Lock Step within the same memory channel

Notes on Configuring Lock Step

In Memory Lock Step configuration, Memory RAS Mode menu is changed from "Lock Step" to "Independent" in the following cases:

 When you additionally install DIMMs that unable to configure Memory Lock Step  When you remove DIMMs that takes down Memory Lock Step

1CPU 構成

搭載順序

2CPU 構成

搭載順序

2 4 6 2 4 6

5 3 1 5 3 1

3 7

9 5 1 9 5 1 4 8

4 8

6 2

CPU1_DIMM 3 CPU1_DIMM 7 CPU1_DIMM 11 CPU1_DIMM 4 CPU1_DIMM 8 CPU1_DIMM 12

CPU1_DIMM 10 CPU1_DIMM 6 CPU1_DIMM 2 CPU1_DIMM 9 CPU1_DIMM 5 CPU1_DIMM 1 CPU2_DIMM 3 CPU2_DIMM 7 CPU2_DIMM 11 CPU2_DIMM 4 CPU2_DIMM 8 CPU2_DIMM 12

CPU2_DIMM 10 CPU2_DIMM 6 CPU2_DIMM 2 CPU2_DIMM 9 CPU2_DIMM 5 CPU2_DIMM 1

1CPU

configuration

2CPU

configuration

Page 67

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

(3)

Memory Sparing Feature

Memory Sparing feature puts a memory channel 2 of a memory controller in each CPU into standby status as spare devices. If a correctable error occurs in a DIMM in the running memory controller, the feature automatically changes the running DIMM from the failed one to a DIMM in the standby state to continue the processing.

Note

To use Memory Sparing feature, install N8102-672/673 additional memory board

(three DIMMs of same model).

DIMMs installed in the system must be of the same model number.

The following table shows configuration allowable for memory sparing and system logical memory capacity.

Number of

CPUs

Number of

DIMMs

Memory capacity

8GB DIMM 16GB DIMM

1 3 20GB 40GB

6 40GB 80GB

9 60GB 120GB

12 80GB 160GB

2 6 40GB 80GB

12 80GB 160GB

18 120GB 240GB

24 160GB 320GB

Page 68

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Memory Sparing feature can be used under the following conditions:

 Install DIMMs in DIMM slots to configure a spare set.

 DIMMs to be installed should have the same capacity.

 Run BIOS Setup Utility (SETUP), change parameters as shown below, save settings, and exit.

Advanced  Memory Configuration  Memory RAS Mode  Sparing Server  Power Measurement Policy  One Time

 After restart, run SETUP again, and check if "Spared" is displayed for the following parameter.

Advanced  Memory Configuration  Memory Information  CPUx_DIMMx Status

 Installation order depends on CPU configuration. See the figure below.

Memory controller

Standby

Running

Standby

Running

Spare set

Page 69

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

The following Memory Sparing cannot be configured.

 A DIMM of different capacity is installed.  Sparing with DIMMs in different memory channel

Notes on Configuring Memory Sparing

In Memory Sparing configuration, Memory RAS Mode menu is changed to "Independent" in the following cases:

 When you additionally install DIMMs that unable to configure Memory Sparing  When you remove DIMMs that takes down Memory Sparing

1CPU 構成

搭載順序

2CPU 構成

搭載順序

3 3 3 4 4 4

2 2 2 1 1 1

5 5 5 7 7 7

3 3 3 1 1 1 6 6 6 8 8 8

4 4 4 2 2 2

CPU1_DIMM 3 CPU1_DIMM 7 CPU1_DIMM 11 CPU1_DIMM 4 CPU1_DIMM 8 CPU1_DIMM 12

CPU1_DIMM 10 CPU1_DIMM 6 CPU1_DIMM 2 CPU1_DIMM 9 CPU1_DIMM 5 CPU1_DIMM 1 CPU2_DIMM 3 CPU2_DIMM 7 CPU2_DIMM 11 CPU2_DIMM 4 CPU2_DIMM 8 CPU2_DIMM 12

CPU2_DIMM 10 CPU2_DIMM 6 CPU2_DIMM 2 CPU2_DIMM 9 CPU2_DIMM 5 CPU2_DIMM 1

1CPU

configuration

2CPU

configuration

Page 70

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.12

Flash Backup Unit for RAID Controller

If a RAID Controller (N8103-176/177/178/179) is installed, use the flash backup unit (FBU) to avoid data loss caused by accidents including temporary blackout during a Write Back operation. The model of the flash backup unit to be used depends on RAID Controller.

 For N8103-176/177/178, use N8103-181 Flash Backup Unit  For N8103-179, use FBU provided with N8103-179.

Handling precautions

1.12.1

Observe the following when using FBU. Ignoring these precautions may cause damage to your data or other devices.

 Use the FBU appropriate to the RAID Controller to be used.

 The FBU is an electronic device sensitive to static electricity. Before installation, touch the metal frame part

of the server to discharge the static electricity from your body.

 Do not drop or bump the FBU.

 For recycling and disposing of the FBU, refer to the User’s Guide that comes with the RAID Controller or

Flash Backup Unit.

Installing N8103-181 Flash Backup Unit

1.12.2

This section describes the procedure of installing an FBU for RAID Controller.

1. See steps 1 to 6 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Put the FBU on support bar. Secure the FBU bracket that comes with FBU with the screw.

3. Connect the FBU control cable (650 mm) that comes with FBU.

Page 71

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

4. Remove the two screws from RAID Controller, and remove the PCI bracket.

5. Mount the adapter to RAID Controller.

6. Connect the control cable of FBU to RAID Controller.

7. Remove the two screws from server chassis, and remove the RAID Controller bracket.

8. Install the RAID Controller bracket to RAID Controller using two screws you have removed in Step 4.

9. Install RAID Controller to the RAID Controller connector on motherboard, using two screws you have removed in Step 7.

Page 72

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

10. Connect Mini SAS HD cable to RAID Controller.

11. Disconnect USB cable (for front) from motherboard.

12. Connect Mini SAS HD cable to RAID Controller.

13. Connect USB cable (for front) to motherboard.

14. Connect PCI riser card unit to a slot on motherboard and secure it with screws.

Page 73

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Removal

1.12.3

For removing the FBU for RAID Controller, reverse the installation procedure.

Installing FBU for N8103-179

1.12.4

Take the steps below to install FBU.

1. See steps 1 to 6 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Put the FBU, provided as the standard accessory of RAID Controller, on the support bar. Then, mount the FBU bracket, provided as the standard accessory of RAID Controller, and secure it with a screw.

3. Connect the FBU control cable (750 mm), provided as the standard accessory of RAID Controller, to FBU.

4. Connect the FBU control cable (750 mm in length) and Mini SAS cable to RAID Controller.

5. Remove one screw from the blank cover on the PCI riser card unit on which you are going to mount the RAID Controller, then remove the blank cover.

Page 74

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

6. Mount the RAID Controller to PCI riser card unit, and secure it with one screw you have removed in Step 5.

7. Connect the PCI riser card unit to the slot on motherboard, and secure it with screws.

Removing FBU

1.12.5

Remove the FBU in reverse order of installation procedure.

Page 75

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.13

LOM Card

The server supports LOM Card which is the replaceable onboard network adapter.

Install LOM Card to the LOM Card slot on motherboard. The motherboard has one slot to install LOM Card.

Important

You must avoid static electricity to work with the procedure below. For

details, see Chapter 1 (1.8 Anti-static Measures) in Safety Precautions and

Regulatory Notices.

Installation

1.13.1

Follow steps below to install LOM Card.

1. See steps 1 to 6 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Remove the screw from the bracket.

3. Undo two screws and then remove the bracket.

Screw

Page 76

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

4. Align the pin terminals of LOM Card with the LOM Card slot, insert the card firmly, and secure the card with three screws.

5. Mount the LOM Card bracket to motherboard and secure it with two screws you have removed in step 3.

6. Use the two screws you have removed in Step 2 to mount the port cover that comes with LOM Card.

Removal

1.13.2

Remove LOM Card in reverse order of installation steps.

Important

To maintain the cooling effect in the server, install the blank cover in the

vacant LOM Card slot.

Page 77

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.14

Additional / Redundant Fan Unit

This server can work with additional redundant cooling fan system by adding an additional fan unit.

The fan units are hot-swappable even while the system is powered-on and running.

Adding an additional CPU requires additional fan unit to be installed.

The figure below shows the slot numbers assigned to the slots of standard cooling fans and optional cooling fans.

*1 Slots to install additional fan unit when additional CPU board is installed.

*2 Slots to install redundant (additional) fan unit.

Install fan units in the slot FAN1F to 4F in 1-CPU configuration.

Install fan units in the slot FAN1F to 5F in 2-CPU configuration.

Important

If adding a fan unit along with additional CPU, see Chapter 2 (1.10 Processor (CPU)

for preparation.

Slots for additional fan unit (Option)* 2

Slots for standard fan unit

Slot for additional fan unit (Option) *1

REAR

FRONT

FAN 1F FAN 1 R

FAN 2F FAN 2R

FAN 3F FAN 3 R

FAN 4F FAN 4 R

FAN 5F FAN 5 R

Page 78

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Installation

1.14.1

Take the steps below to install the fan unit.

(1)

Additional fan unit for additional CPU

1. See steps 1 to 6 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Remove the fan cover.

3. Locate the slot to install an additional fan unit (FAN 5R).

4. Insert fan unit straight into slot. When the fan unit is inserted to the end, it is locked with clicking sound.

Important

Keep the removed fan cover for future use.

(2)

Additional fan unit for redundant configuration

1. See steps 1 to 6 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Locate the slots to install an additional (redundant) fan unit. In 1-CPU configuration: Install redundant fan units to slots FAN 1F to 4F. In 2-CPU configuration: "Install redundant fan units to slots FAN 1F to 5F.

3. Insert fan unit straight into the slot for additional fan unit. When the fan unit is inserted to the end, it is locked with clicking sound.

Page 79

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Replacement / Removal

1.14.2

To remove additional/redundant fan unit, reverse the installation procedure.

The fan units are hot-swappable even while the system is powered-on and running.

You can identify the failing fan unit by using the management tool such as EXPRESSSCOPE Engine 3.

While the system is powered-on or running, the LED of failed fan unit is lit.

CAUTION

Be sure to observe the following precautions to use the server safely. Failure to

observe the precautions may cause burns, injury, and property damage. For

details, refer to Safety Precautions and Regulatory Notices.

 Pay attention to electric hazard.

Page 80

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.15

Backup Device

The server supports backup device such as magnetic tape drive.

Important

 Use only the backup device specified by NEC.  Available unit size is 3.5 inch (about 9 cm) in width, 1.6 inch (about 4 cm) in height.

Installation

1.15.1

Take the steps below to install the backup device.

1. See steps 1 to 8 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Push the lever to unlatch the expansion bay, and remove the carrier toward the front of chassis.

3. Push the blank cover to remove it.

Important

Keep the removed blank cover for future use.

Page 81

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

4. Insert the backup device into the carrier.

5. Secure the backup device with the four screws that come with the server.

Important

 Be sure to use the screws that come with your server.  Adjust the mounting position of backup file unit so that their screw holes are

aligned with those on the carrier.

 If you feel difficult to connect a cable because the depth of backup device is too

long, move the device toward front, then connect the cable.

6. Insert the carrier into expansion bay. When the device is completely inserted, it is locked with clicking sound.

Note

Pay attention not to pinch the cable when inserting the device.

Page 82

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

7. Connect an interface cable and power cable that come with the backup device.

Note

Use the power cable that extends to the expansion bay of the server.

8. Connect the USB cable to the connector on motherboard.

Note

Make sure that the USB cable does not come in contact with electronic component on

motherboard.

9. Continue to install or remove internal optional devices, mount and connect the server, and power on the server.

Important

When N8151-125 Internal RDX (USB) is connected, the boot device priority may be

changed. On the Boot menu of BIOS SETUP, specify the boot priority of removable

device lower than that of boot device.

10. Make sure that no error messages are displayed on POST screen.

For details on POST error messages, refer to Chapter 3 (1. POST Error Message) in "Maintenance Guide".

11. Install the driver for backup device.

Removal

1.15.2

Remove the backup device in reverse order of installation steps.

USB cable

Power cable

Page 83

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.16

PCI Riser Card

The PCI slot performance can be updated from x8 lane to x16 lane by exchanging the PCI riser card to which a PCI board is attached

Important

You must avoid static electricity to work with the procedure below. For

details, see Chapter 1 (1.8 Anti-static Measures) in Safety Precautions and

Regulatory Notices.

Notes

1.16.1

Read the following notes when installing or removing a PCI riser card.

 Do not touch the terminals of the riser cards and the leads of electronic components with your bare hand.

Fingerprints and dust left on them cause the server to malfunction due to a connection failure or damage to the leads.

 Available type of PCI card depends on the type of a PCI riser card. Make sure the card type before

connecting it to riser card.

Installation

1.16.2

Follow steps below to install a PCI riser card.

1. See steps 1 to 6 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Remove the screw that secures the PCI riser card unit, and remove the PCI riser card unit.

3. Remove the two screws securing the PCI riser card. Slide the PCI riser card to the direction and lift it off.

4. Remove the two screws securing the PCI riser card. Slide the PCI riser card to the direction of the arrow and remove it.

5. Reverse the procedure in step 4 to install the PCI riser card to the PCI riser card unit.

Screws Screws

Removal

1.16.3

To remove a PCI riser card, reverse the installation procedure.

Page 84

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.17

PCI Card

This server provides PCI slots for riser card (2 types), a slot dedicated for LOM card, and a slot dedicated for RAID controller (total four PCI cards can be mounted).

Riser card can connect with two or three full-height PCI cards and three low-profile PCI cards. A slot dedicated for LOM card can contain one LOM card. A slot dedicated for RAID controller can contain one RAID Controller. (Seven or eight PCI cards can be mounted in total.)

Important

You must avoid static electricity to work with the procedure below. For

details, see Safety Precautions and Regulatory Notices (1.8 Anti-static

measures).

Notes

1.17.1

Read the following notes when installing or removing a PCI card.

 Do not touch the terminals of the PCI riser cards and the leads of electronic components with your bare

hand. Fingerprints and dust left on them cause the server to malfunction due to a connection failure or damage to the leads.

 Available type of PCI card depends on a PCI riser card. Make sure the card type before connecting it to

riser card.

 The server provides no connector to connect an LED connector which is supplied in RAID Controller

used to indicate disk access.

 PCI slot number "1A" is assigned to the RAID controller slot, "1B" is assigned to the LOM card slot. "1C,

2C, 3C" (from bottom slot) are assigned to the PCI riser card for full-height PCI card. "1C, 2C" (from bottom slot) are assigned to full-height optional riser card (PCIe x16), and "1D, 2D, 3D" (from bottom slot) are assigned to low-profile optional riser card.

 The search order for PCI bus slot on boot is as follows.

Slot 1A (dedicated to RAID Controller)  Slot 1B (LOM card slot)  Slot 1C (Full height card slot)  Slot 1D (Low profile card slot)  2C (Full height) card slot)  3C (Full height card slot)  2D (Low profile card slot)  3D (Low profile card slot)

 The PCI devices of the same type (including onboard PCI device) may be recognized in different order

from those described above, depending on OS or RAID Configuration Utility. Check the slot location of PCI device by PCI bus number, device number and function number shown in the table below.

PCI device Bus number Device number Function number

LOM card LAN1 (when N8104-154F/155F/156F is installed)

05h 0 0

LOM card LAN2 (when N8104-154F/155F/156F is installed)

05h 0 1

LOM card LAN3 (when N8104-154F/156F is installed) 05h 0 2

LOM card LAN4 (when N8104-154F/156F is installed) 05h 0 3

Slot 1A dedicated for RAID Controller 01h 0 X

PCIe slot 1C (Full height) 0Ch 0 X

PCIe slot 2C (Full height) 83h 0 X

PCIe slot 3C (Full height) A0h 0 X

PCIe slot 1C (N8116-34/34A) 0Ch 0 X

PCIe slot 2C (N8116-34/34A) 83h 0 X

PCIe slot 1C (N8116-45) 0Ch 0 X

PCIe slot 2C (N8116-45) 2Eh 0 X

PCIe slot 3C (N8116-45) 83h 0 X

Page 85

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

PCI device Bus number Device number Function number

PCIe slot 1D (Low profile) 40h 0 X

PCIe slot 2D (Low profile) C0h 0 X

PCIe slot 3D (Low profile) E0h 0 X

PCIe slot 1D (N8116-46) 40h 0 X

PCIe slot 2D (N8116-46) 62h 0 X

PCIe slot 3D (N8116-46) C0h 0 X

 If an additional LAN card is installed, it is hard to push the catch of the connector with your finger that is

connected to the LAN card. Disconnect the connector pushing the catch with a standard screwdriver. At this time, be very careful for the screwdriver not to damage the LAN card.

 If a bootable device such as a PCI card or USB device is added, or boot mode is changed the boot order

may change. Check priority for the boot device in BIOS Setup Utility.

[Boot] - [CD/DVD Priorities] → Check the display [Boot] - [Removable Priorities] → Check the display [Boot] - [HDD Priorities] → Check the display [Boot] - [ Network Priorities] → Check the display

 If the boot device is an HDD and located under an optional RAID Controller, the display is (Bus xx Dev

00) PCI RAID Adapter. Note that the value for xx changes depending on the PCI slot where a RAID

Controller is installed.

 For a RAID Controller, LAN card (network boot), or Fibre Channel controller, if a hard disk drive on which

an OS is installed is connected, set the option ROM for that slot to Enabled. See Chapter 2 (1. System BIOS) in "Maintenance Guide" for how to specify it.

Page 86

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Supported PCI cards and available slots

1.17.2

The following tables list supported cards and slots available for them. For details of the features of each card, see the manual supplied with the card.

Tips

 Different cards mounted on the same bus operate at the lower frequency.  If the operation performance of PCI card differs from that of PCI Slot, the PCI

card operates at lower frequency.

(1)

Standard PCI riser card

Product number

Product

name

Slot number #1A #1B #1C #2C #3C #1D #2D #3D

Remarks

CPU connected CPU1 CPU2 CPU1 CPU2

PCI standard P CI e 3. 0

PCI slot performance *1 x8 l ane

Transfer bandwidth (per

lane) *1

8Gb/s

PCI card type *2 x8 socket

Slot size

Dedicated

to RAID

Controller

Dedicated

to LOM

card

Full height Low profile

Available card size

220 mm

max.

220 mm

max. *4

312 mm

max.

220 mm max.

N8103-176 RAID Controller

(1GB, RAID 0/1) [PCI Express 3.0(x8)]



– – – – – – – Dedicated to connect

with internal hard disk drive. Flash Backup Unit [N8103-181] can be mounted.

N8103-177 RAID Controller

(1GB, RAID 0/1/5/6) [PCI Express 3.0(x8)]



– – – – – – –

N8103-178 RAID Controller

(2GB, RAID 0/1/5/6) [PCI Express 3.0(x8)]



– – – – – – –

N8103-179 RAID Controller

(2GB, RAID 0/1/5/6) [PCI Express 3.0(x8)]

– –

     

Dedicated to connect with external devices. Up to 2 cards can be mounted. Flash Backup Unit is factory installed

N8103-142 SAS Controller

[PCI Express 2.0(x8)]

– –

     

Dedicated to connect with external devices.

Up to 3 cards can be mounted.

N8103-184 SAS Controller

[PCI Express 3.0(x8)]

– –

     

N8118-301 2.5-inch PCIe SSD Installation Kit – –

     

For connecting PCIe SSD; Up to 1 card can be

mounted.

N8190-159 Fibre Channel Controller

(8Gbps/Optical) [PCI Express 2.0(x8)]

– –

     

N8190-160 Fibre Channel Controller (2ch)

(8Gbps/Optical) [PCI Express 2.0(x8)]

– –

     

N8190-157A Fibre Channel Controller

(16Gbps/Optical) [PCI Express 3.0(x8)]

– –

     

N8190-158A Fibre Channel Controller

(2ch)(16Gbps/Optical) [PCI Express 3.0(x8)]

– –

     

N8104-150 1000BASE-T Adapter (1ch)

[PCI Express 2.0(x1)]

– –

     

For additional LAN port. Card type: PCI Express

2.0 (x4)

N8104-151 1000BASE-T Adapter (2ch)

[PCI Express 2.0(x1)]

– –

     

N8104-152 1000BASE-T Adapter (4ch)

[PCI Express 2.0(x4)]

– –

     

For additional LAN port.

N8104-145 1000BASE-T Adapter (2ch)

[PCI Express 2.0(x4)]

– –

     

For additional LAN port.

Page 87

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Product number

Product

name

Slot number #1A #1B #1C #2C #3C #1D #2D #3D

Remarks

CPU connected CPU1 CPU2 CPU1 CPU2

PCI standard PCI e 3. 0

PCI slot performance *1 x8 l ane

Transfer bandwidth (per

lane) *1

8Gb/s

PCI card type *2 x8 socket

Slot size

Dedicated

to RAID

Controller

Dedicated

to LOM

card

Full height Low profile

Available card size

220 mm

max.

220 mm

max. *4

312 mm

max.

220 mm max.

N8104-149 10GBASE Adapter(SFP+/2ch)

[PCI Express 2.0(x8)]

– –

     

For additional LAN port.

Prepare SFP+ module N8104-129 if needed.

N8104-148 10GBASE Adapter(SFP+/2ch)

[PCI Express 2.0(x8)]

– –

     

For additional LAN port.

Prepare SFP+ module N8104-129 if needed.

N8104-153 10GBASE-T Adapter (2ch)

[PCI Express 2.0(x8)]

– –

     

N8104-154F 1000BASE-T LOM Card (4ch)

[PCI Express 2.0(x4)]

–



– – – – – – For additional LAN

port. Card type: PCI Express

2.0 (x8)

N8104-155F 10GBASE-T LOM Card (2ch)

[PCI Express 2.0(x8)]

–



– – – – – – For additional LAN

port.

N8104-160F

10GBASE-TLOM Card (2ch) [PCI Express 2.0(x8)]

－  －－－－－－

For additional LAN port

N8104-156F 10GBASE-SFP+(2ch) +

1000BASE-T(2ch) LOM Card [PCI Express 2.0(x8)]

–



– – – – – – For additional LAN

port. Prepare SFP+ module

N8104-129 if needed.

N8104-157 10GBASE-T Adapter (2ch)

－－      

For additional LAN port

(Intel NIC). Supports teaming (AFT/SFT/ALB) and bonding with an additional 10-BASE-T adapter

N8104-146 InfiniBand Adapter(1ch)

(FDR/Optical) [PCI Express 3.0(x8)]

– –

     

For Infiniband connection

Cannot be used together with each other..

Up to two cards can be mounted.

N8104-147 InfiniBand Adapter(2ch)

(FDR/Optical) [PCI Express 3.0(x8)]

– –

     

N8104-158 10GBASE Adapter(SFP+/2ch) – –

     

For additional LAN port (Intel NIC). Prepare SFP+ module N8104-129 if needed. Supports teaming (AFT/SFT/ALB) and bonding with an additional 10-BASE-SFP+ adapter.

N8104-159 10GBASE Adapter (SFP+/4ch)

－－      

For additional LAN port (Intel NIC). Prepare QSFP+ module N8104-161 if needed. Supports teaming (AFT/SFT/ALB) and bonding with an additional 10-BASE-SFP+ adapter.

N8117-01A Additional RS-232C connector *3 – –



– –

  

For additional serial port B (RS-232C).

Only one card can be mounted.

Page 88

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

: Can be mounted, –: Cannot be mounted

*1 Data transfer rate of PCI slot = Transfer bandwidth  Number of lanes

<Example> x8 lane = 64 Gbps (one-way)

*2 Connector size. Cards exceeding the number of sockets cannot be connected.

<Example> x4 socket can connect with x1 and x4 cards, but not x8 card. *3 Use RS-232C cable (B). *4 To install a 312 mm full-length PCI card into slot #2C, the N8116-37 Full Length PCI Card Installation Kit must be prepared in advance.

- For functional details of each card, refer to the technical guide.

- The text in square brackets in the Product name column indicates the maximum performance of the card.

- If the performance of the PCI slot and the installed PCI card differs, the PCI card operates with a lower performance.

(2)

N8116-34/34A PCI riser card (PCIex16) (option)

Product

number

Product name

Slot number #1A #1B #1C #2C #1D #2D #3D

Remarks

CPU

connected

CPU1 CPU2 CPU1 CPU2

PCI standard PCIe 3.0

PCI slot

performance *1

x8 lane

Transfer

bandwidth (per

lane) *1

8Gb/s

PCI card type

x8 socket x16 socket x8 socket

Slot size

Dedicated

to RAID

Controller

Dedicated

to LOM

card

Full height Low profile

Available card

size

220 mm

max.

220 mm max.

(312 mm

max.)

220 mm max.

N8103-176 RAID Controller

(1GB, RAID 0/1) [PCI Express 3.0(x8)]



– – – – – – Dedicated to connect

with internal hard disk drive. Flash Backup Unit [N8103-181] can be mounted.

N8103-177 RAID Controller

(1GB, RAID 0/1/5/6) [PCI Express 3.0(x8)]



– – – – – –

N8103-178 RAID Controller

(2GB, RAID 0/1/5/6) [PCI Express 3.0(x8)]



– – – – – –

N8103-179 RAID Controller

(2GB, RAID 0/1/5/6) [PCI Express 3.0(x8)]

– –

    

Dedicated to connect with external devices.

Up to 2 cards can be mounted.

Flash Backup Unit is factory installed

N8103-142 SAS Controller

[PCI Express 2.0(x8)]

– –

    

Dedicated to connect with external devices.

Up to 3 cards can be mounted.

N8103-184 SAS Controller

[PCI Express 3.0(x8)]

– –

    

N8118-301 PCI SSD Adapter

[PCI Express 2.0(x4)]

– –

    

Forconnecting PCIe SSD. Only one card can be mounted. Cannot be used as OS boot area. Card type: PCI Express

2.0 (x8)

N8190-159 Fibre Channel Controller

(8Gbps/Optical) [PCI Express 2.0(x8)]

– –

    

N8190-160 Fibre Channel Controller (2ch)

(8Gbps/Optical) [PCI Express 2.0(x8)]

– –

    

N8190-157A Fibre Channel Controller

(16Gbps/Optical) [PCI Express 3.0(x8)]

– –

    

N8190-158A Fibre Channel Controller (2ch)

(16Gbps/Optical) [PCI Express 3.0(x8)]

– –

    

N8104-150 1000BASE-T Adapter (1ch)

[PCI Express 2.0(x1)]

– –

    

For additional LAN port.

Page 89

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Product

number

Product name

Slot number #1A #1B #1C #2C #1D #2D #3D

Remarks

CPU

connected

CPU1 CPU2 CPU1 CPU2

PCI standard PCIe 3.0

PCI slot

performance *1

x8 lane

Transfer

bandwidth (per

lane) *1

8Gb/s

PCI card type

x8 socket x16 socket x8 socket

Slot size

Dedicated

to RAID

Controller

Dedicated

to LOM

card

Full height Low profile

Available card

size

220 mm

max.

220 mm max.

(312 mm

max.)

220 mm max.

N8104-151 1000BASE-T Adapter (2ch)

[PCI Express 2.0(x1)]

– –

    

Card type: PCI Express

2.0 (x4)

N8104-152 1000BASE-T Adapter (4ch)

[PCI Express 2.0(x4)]

– –

    

For additional LAN port.

N8104-145 1000BASE-T Adapter (2ch)

[PCI Express 2.0(x4)]

– –

    

For additional LAN port.

N8104-149 10GBASE Adapter(SFP+/2ch)

[PCI Express 2.0(x8)]

– –

    

For additional LAN port.

Prepare SFP+ module N8104-129 if needed.

N8104-148 10GBASE Adapter(SFP+/2ch)

[PCI Express 2.0(x8)]

– –

    

For additional LAN port.

Prepare SFP+ module N8104-129 if needed.

N8104-153 10GBASE-T Adapter(2ch)

[PCI Express 2.0(x8)]

– –

    

N8104-154F 1000BASE-T LOM Card (4ch)

[PCI Express 2.0(x4)]

–



– – – – – For additional LAN

port. Card type: PCI Express

2.0 (x8)

N8104-155F 10GBASE-T LOM Card (2ch)

[PCI Express 2.0(x8)]

–



– – – – – For additional LAN

port.

N8104-160F

10GBASE-T LOM Card (2ch) [PCI Express 2.0(x8)]

－  －－－－－

For additional LAN port.

N8104-156F 10GBASE-SFP+(2ch) +

1000BASE-T(2ch) LOM Card [PCI Express 2.0(x8)]

–



– – – – – For additional LAN

port. Prepare SFP+ module

N8104-129 if needed.

N8104-157 10GBASE-T Adapater (2ch)

－－ 

–

  

For additional LAN

port (Intel NIC). Supports teaming (AFT/SFT/ALB) and bonding with an additional 10-BASE-T adapter

N8104-146 InfiniBand Adapter(1ch)

(FDR/Optical) [PCI Express 3.0(x8)]

– –



–

  

For Infiniband connection

Cannot be used together with each other.

Up to two cards can be mounted.

N8104-147 InfiniBand Adapter(2ch)

(FDR/Optical) [PCI Express 3.0(x8)]

– –



–

  

N8104-158

10GBASE Adapter (SFP+/2ch) – –

    

For additional LAN port (Intel NIC). Prepare SFP+ module N8104-129 if needed. Supports teaming (AFT/SFT/ALB) and bonding with an additional 10-BASE-SFP+ adapter.

Page 90

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Product

number

Product name

Slot number #1A #1B #1C #2C #1D #2D #3D

Remarks

CPU

connected

CPU1 CPU2 CPU1 CPU2

PCI standard PCIe 3.0

PCI slot

performance *1

x8 lane

Transfer

bandwidth (per

lane) *1

8Gb/s

PCI card type

x8 socket x16 socket x8 socket

Slot size

Dedicated

to RAID

Controller

Dedicated

to LOM

card

Full height Low profile

Available card

size

220 mm

max.

220 mm max.

(312 mm

max.)

220 mm max.

N8104-159 10GBASE Adapter (SFP+/4ch)

－－     

For additional LAN port (Intel NIC). Prepare QSFP+ module N8104-161 if needed. Supports teaming (AFT/SFT/ALB) and bonding with an additional 10-BASE-SFP+ adapter.

N8117-01A Additional RS-232C

connector *3

– –



–

  

For additional serial port B (RS-232C).

Only one card can be mounted.

: Can be mounted, –: Cannot be mounted

*1 Data transfer rate of PCI slot = Transfer bandwidth  Number of lanes

<Example> x8 lane = 64 Gbps (one-way) *2 Connector size. Cards exceeding the number of sockets cannot be connected.

- For functional details of each card, refer to the technical guide.

- The text in square brackets in the Product name column indicates the maximum performance of the card.

- If the performance of the PCI slot and the installed PCI card differs, the PCI card operates with a lower performance.

Page 91

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

(3)

N8116-49 PCI riser card(PCIe x4/x16) (option)

Product

number

Product

name

Slot number #1A #1B #1C #2C #3C #1D #2D #3D

Remarks

CPU connected

CPU1 CPU2 CPU1 CPU2

PCI standard

PCIe 3.0

PCI slot performance *1

x8 lane x4 lane

x16

lane

x4 lane

x16

lane

Transfer bandwidth

(per lane) * 1

8Gb/s

PCI card type *2

x8 socket

x16

socket

x8 socket

x16

socket

Slot size

Dedicated

to RAID

Controller

Dedicated

to LOM

card

Full height Low profile

Available card size

220 mm

max.

220 mm

max. *4

312 mm

max.

220 mm max.

N8103-176 RAID Controller

(1GB, RAID 0/1) [PCI Express 3.0(x8)]



– – – – – – – Dedicated to connect

with internal hard disk drive. Flash Backup Unit [N8103-181] can be mounted.

N8103-177 RAID Controller

(1GB, RAID 0/1/5/6) [PCI Express 3.0(x8)]



– – – – – – –

N8103-178 RAID Controller

(2GB, RAID 0/1/5/6) [PCI Express 3.0(x8)]



– – – – – – –

N8103-179 RAID Controller

(2GB, RAID 0/1/5/6) [PCI Express 3.0(x8)]

– –

     

Dedicated to connect with external devices. Up to 2 cards can be mounted. Flash Backup Unit is factory installed

N8103-142 SAS Controller

[PCI Express 2.0(x8)]

– –

     

Dedicated to connect with external devices.

Up to 3 cards can be mounted.

N8103-184 SAS Controller

[PCI Express 3.0(x8)]

– –

     

N8118-301 2.5-inch PCIe SSD Installation Kit – –

     

For connecting PCIe SSD; Up to 1 card can be

mounted.

N8190-159 Fibre Channel Controller

(8Gbps/Optical) [PCI Express 2.0(x8)]

– –

     

N8190-160 Fibre Channel Controller (2ch)

(8Gbps/Optical) [PCI Express 2.0(x8)]

– –

     

N8190-157A Fibre Channel Controller

(16Gbps/Optical) [PCI Express 3.0(x8)]

– –

     

N8190-158A Fibre Channel Controller

(2ch)(16Gbps/Optical) [PCI Express 3.0(x8)]

– –

     

N8104-150 1000BASE-T Adapter (1ch)

[PCI Express 2.0(x1)]

– –

     

For additional LAN port. Card type: PCI Express

2.0 (x4)

N8104-151 1000BASE-T Adapter (2ch)

[PCI Express 2.0(x1)]

– –

     

N8104-152 1000BASE-T Adapter (4ch)

[PCI Express 2.0(x4)]

– –

     

For additional LAN port.

N8104-145 1000BASE-T Adapter (2ch)

[PCI Express 2.0(x4)]

– –

     

For additional LAN port.

N8104-149 10GBASE Adapter(SFP+/2ch)

[PCI Express 2.0(x8)]

– –

     

For additional LAN port.

Prepare SFP+ module N8104-129 if needed.

N8104-148 10GBASE Adapter(SFP+/2ch)

[PCI Express 2.0(x8)]

– –

     

For additional LAN port.

Prepare SFP+ module N8104-129 if needed.

N8104-153 10GBASE-T Adapter (2ch)

[PCI Express 2.0(x8)]

– –

     

N8104-154F 1000BASE-T LOM Card (4ch)

[PCI Express 2.0(x4)]

–



– – – – – – For additional LAN

port. Card type: PCI Express

2.0 (x8)

Page 92

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Product

number

Product

name

Slot number #1A #1B #1C #2C #3C #1D #2D #3D

Remarks

CPU connected

CPU1 CPU2 CPU1 CPU2

PCI standard

PCIe 3.0

PCI slot performance *1

x8 lane x4 lane

x16

lane

x4 lane

x16

lane

Transfer bandwidth

(per lane) * 1

8Gb/s

PCI card type *2

x8 socket

x16

socket

x8 socket

x16

socket

Slot size

Dedicated

to RAID

Controller

Dedicated

to LOM

card

Full height Low profile

Available card size

220 mm

max.

220 mm max. *4

312 mm

max.

220 mm max.

N8104-155F 10GBASE-T LOM Card (2ch)

[PCI Express 2.0(x8)]

–



– – – – – – For additional LAN

port.

N8104-160F

10GBASE-TLOM Card (2ch) [PCI Express 2.0(x8)]

－  －－－－－－

For additional LAN port

N8104-156F 10GBASE-SFP+(2ch) +

1000BASE-T(2ch) LOM Card [PCI Express 2.0(x8)]

–



– – – – – – For additional LAN

port. Prepare SFP+ module

N8104-129 if needed.

N8104-157 10GBASE-T Adapter (2ch)

－－      

For additional LAN port

(Intel NIC). Supports teaming (AFT/SFT/ALB) and bonding with an additional 10-BASE-T adapter

N8104-146 InfiniBand Adapter(1ch)

(FDR/Optical) [PCI Express 3.0(x8)]

– –

     

For Infiniband connection

Cannot be used together with each other..

Up to two cards can be mounted.

N8104-147 InfiniBand Adapter(2ch)

(FDR/Optical) [PCI Express 3.0(x8)]

– –

     

N8104-158 10GBASE Adapter(SFP+/2ch) – –

     

For additional LAN port (Intel NIC). Prepare SFP+ module N8104-129 if needed. Supports teaming (AFT/SFT/ALB) and bonding with an additional 10-BASE-SFP+ adapter.

N8104-159 10GBASE Adapter (SFP+/4ch)

－－      

For additional LAN port (Intel NIC). Prepare QSFP+ module N8104-161 if needed. Supports teaming (AFT/SFT/ALB) and bonding with an additional 10-BASE-SFP+ adapter.

N8117-01A Additional RS-232C connector

– –



– –

  

For additional serial port B (RS-232C).

Only one card can be mounted.

: Can be mounted, –: Cannot be mounted

*1 Data transfer rate of PCI slot = Transfer bandwidth  Number of lanes

<Example> x8 lane = 64 Gbps (one-way) *2 Connector size. Cards exceeding the number of sockets cannot be connected.

- For functional details of each card, refer to the technical guide.

- The text in square brackets in the Product name column indicates the maximum performance of the card.

- If the performance of the PCI slot and the installed PCI card differs, the PCI card operates with a lower performance.

Page 93

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Installation

1.17.3

Install a PCI card to the riser card unit in the following procedure.

Important

When installing a PCI card, make sure the connector of the card fits the

connector of the riser card.

Note

 Check the card type (Low Profile or Full Height) which respective riser card

supports and the type of PCI card to be installed.

 When installing an FBU, see Chapter 2 (1.12 Flash Backup Unit for RAID

Controller).

1. See steps 1 to 6 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Remove one screw from the PCI riser card unit and remove the blank cover.

Note

Keep the removed blank cover for future use.

3. Install a PCI card to the PCI riser card unit. Position the terminal part of the PCI card to the PCI riser card slot and insert it.

Important

Do not touch the terminal part of riser card or PCI card and the signal pins of

electric parts installed on the board. Installing boards with dirt or oil can

cause malfunction.

Note

 Make sure that the edge of a PCI card bracket is seated into the fixed slot of the

PCI riser card unit.

 Depending on type of PCI cards, the terminal part of the PCI card may be too

large to fit in the connector.

 If you have trouble installing the card, remove the card once and try again. If you

apply excessive pressure on the card, a PCI card or riser card might break.

4. Secure the PCI card with the screw you removed in step 4.

Page 94

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Tips

To connect a PCI card to the connector on motherboard with cable, connect a

cable to PCI card before installing PCI riser card unit.

5. Connect the PCI riser card unit to the slot on motherboard and secure the card with the screw you removed in step 2. Position the terminal part of the PCI riser card to the slot on the motherboard and insert it.

6. Continue to install or remove internal optional devices, mount and connect the server, and turn it on.

7. Make sure that no error messages are displayed on POST screen. For details on POST error messages, see Chapter 3 (1. POST Error Message) in "Maintenance Guide".

8. Run the configuration utility of the card to set up the board as needed. Availability or startup and operation procedure of the utility depends on card. For details, see the manual that comes with the card. If a PCI card including RAID Controller, SAS controller, and LAN adapter

which connects to any bootable device is added, the boot priority might or changed to the default setting. In that case, configure the boot priority in Boot menu of BIOS Setup Utility. For details, see

Chapter 2 (1. System BIOS) in "Maintenance Guide".

Removal

1.17.4

To remove a PCI card, reverse the installation procedure.

Run SETUP and change boot order in Boot menu as needed. See Chapter 2 (1. System BIOS) in "Maintenance Guide" for how to specify it.

If using the server with the PCI card removed, attach the blank cover that comes with the riser card unit.

Page 95

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

Installing RAID Controller

1.17.5

This section describes how to install an optional RAID Controller to the slot dedicated to RAID Controller.

(1)

When using the optional RAID controller (N8103-176/177/178)

For details, see the manual that comes with optional RAID Controller (N8103-176/177/178).

Important

 You must avoid static electricity to work with the procedure below. For

details, see Chapter 1 (1.8 Anti-static Measures) in Safety Precautions ans

Regulatory Notices.

 Up to 31 logical drives can be created. Do not create 32 or more logical

drives

Note

 When installing an optional RAID Controller, run the BIOS Setup utility, select

PCI Configuration from the Advanced menu, and then make sure that the

parameter of PCI Slot xx ROM (xx is PCI slot number) is set to Enabled.

 When connecting a RAID Controller, set the boot priority to 8th or higher in the

Boot menu of the BIOS Setup utility. If the setting is 9th or lower, the

configuration menu for RAID Controllers cannot be launched.

Installation

Take the following procedure to install RAID Controller (N8103-176/177/178).

1. See steps 1 to 6 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Remove the four screws and remove PCI riser card unit.

3. Remove the two screws from RAID Controller, and remove PCI bracket.

4. Remove the two screws from server chassis, and remove RAID Controller bracket.

Page 96

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

5. Attach the RAID Controller bracket to RAID Controller with two screws you have removed in Step 3.

6. Insert the RAID Controller slightly into the dedicated slot while tilting the card.

7. Gently place the RAID Controller on bottom plate of chassis so that it become horizontal to the motherboard.

8. Insert the RAID Controller into the slot while keeping horizontal state.

9. Secure the RAID Controller bracket with two screws you have removed in Step 4.

10. Disconnect SAS/SATA cable from SATA connector on motherboard.

 When four or less hard disk drives are installed:

Connect SAS/SATA cable removed in Step 8 to connector (Ports 0-3) on RAID Controller.

 When five or more hard disk drives are installed:

Connect SAS/SATA cable removed in Step 8 to connector (Ports 0-3) on RAID Controller.

Connect SAS/SATA cable provided with the server to connector (Ports 4-7) on RAID Controller.

Remove a single screw from server chassis, and remove battery tray for RAID Controller.

Connect another end of SAS/SATA cable that has been connected to connector (Ports 4-7) on RAID Controller, to the connector on backplane.

11. Continue to install or remove internal optional devices, mount and connect the server, and turn it on.

(2)

When using optional RAID Controller (N8103-179)

See Chapter 2 (1.12.4 Installing FBU).

Page 97

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

1.18

Additional 2.5-inch HDD Cage

This server can have additional 2.5-inch HDD cage for installing additional hard disk drives.

Installation

1.18.1

Follow steps below to install an additional HDD cage.

1. See steps 1 to 7 in Chapter 2 (1.2 Overview of Installation and Removal) for preparations.

2. Remove the six screws from protective cover, and remove the protective cover.

3. Remove the blank cover of 2.5-inch HDD cage by pulling it toward you.

4. Install the additional 2.5-inch HDD cage.

Page 98

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

5. Secure the protective cover with six screws you have removed in Step 2.

6. Disconnect SAS cable from the factory-installed HDD cage.

7. Install expander board to Expansion Bay and secure it with four screws provided with 2.5-inch HDD cage.

8. Connect the SAS cable (short) provided with 2.5-inch additional HDD cage to RAID Controller and Expander board.

Page 99

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

Chapter 2 Preparations

9. Connect the provided DC cable to Expander board and additional HDD cage.

10. Connect the SAS cable (long) provided with 2.5-inch additional HDD cage to Expander Board, factory-installed HDD cage, and additional HDD cage.

11. Connect the provided SGPIO cable to factory-installed HDD cage and additional HDD cage.

12. Install support bar, PCI riser card unit, and then install the top cover.

13. Attach the ID label to the front face of chassis.

Note

Keep the removed blank cover for future use.

01234567

Page 100

1. Installing Internal Optional Devices

Express5800/R120g-2M User’s Guide

100

Chapter 2 Preparations

Removal

1.18.2

To remove an additional HDD cage, reverse the installation procedure above.

Important

To maintain the cooling effect in the server, install the blank cover in the vacant slot.
