NEC V Series
Flat-panel monitors ideal for general business users
Series Features and Benefits
Exceptional screen performance provides
a more comfortable and productive visual
experience with crisp, sharp and accurate
text and images
Rapid Response technology delivers
virtually uninterrupted, undistorted
viewing of high-speed, full-motion video
Enhanced cable management helps prevent
unattractive, space-consuming wire clutters
On Screen Manager (OSM®) puts you in
complete control of your screen setting
adjustments
No Touch Auto AdjustTM reduces setup
time and provides optimal image settings
upon initial power-on
Step up to superior flat-panel display performance without emptying your pockets. With affordable
LCD monitors for a variety of users, NEC V Series monitors have set a new standard in value in the
display product category. In fact, with affordability akin to that of comparable CRT monitors, V Series
monitors offer you a perfect opportunity to take advantage of the many benefits offered by flat-panel
monitors without having to break your budget. The 17" NEC LCD17V and 19" NEC LCD19V deliver ideal
visual display solutions to general business users, adding clarity to presentation and document
creation, vibrant splashes of color to web surfing and exciting, lifelike action to gaming.
Enhanced screen performance. With contrast ratios as high as 550:1 (typical) and brightness quality
much higher than CRTs at 270 cd/m
2
, outstanding LCD monitor front-of-screen visual performance is
NEC’s #1 goal. The V Series delivers vibrant colors and flicker-free images that make your time in
front of the monitor more comfortable and productive. NEC’s Rapid Response
TM
technology provides
for uninterrupted display of full-motion video with response times as quick as 8ms. This remarkably
quick motion makes these models better than ever for gaming and video applications such as
presentations and streaming web video.
Intelligent power management ensures a smart investment. Using approximately 70% less power
and emitting less heat than comparable CRT monitors, V Series monitors allow you to conserve
energy and lower your total cost of ownership.
Wall/arm mounting capability adds
flexibility and comfort, while freeing up
valuable desktop space (using third-par ty
product)
ENERGY STAR 4.0 compliance/low power
consumption reduces electrical costs and
lowers total cost of ownership
NEC Display Solutions’ quality and
reliability provide peace of mind with a
1-year limited parts and labor warranty
(including backlight) and 24/7 customer
service and technical support
Page 2
V Series Specifications
Model
Display:
Viewable Image Size
Pixel Pitch
Pixels Per Inch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle (typical)
Response Time (typical)
Display Colors
Synchronization Range:
Horizontal
Vertical
Input Signal:
Video
Sync
Input
Resolutions Supported
Native Resolution
LCD17V
17"
0.264mm
96 @ native resolution
2
270 cd/m
500:1
130° Vert., 160° Hor. (60U/70D/80L/80R)
Rapid Response (8ms)
More than 16 million
31.5-81 kHz
56-76 Hz
Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level (positive/negative)
VGA 15 pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 70-75 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60-75 Hz
1280 x 1024 @ 60-75 Hz
1280 x 1024 @ 60 Hz
LCD19V
19"
0.294mm
86 @ native resolution
2
270 cd/m
550:1
145° Vert., 160° Hor. (75U/70D/80L/80R)
Rapid Response (8ms)
More than 16 million
31.5-81 kHz
56-76 Hz
Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level (positive/negative)
VGA 15 pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 70 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60-75 Hz
1280 x 1024 @ 60-75 Hz
1280 x 1024 @ 60 Hz
Additional Features
Touch-Capable
Voltage Rating
Power Consumption (typical):
On
Power Savings Mode
Dimensions (W x H x D):
Net (with stand)
Net (without stand)
Weight
Net (with stand)
Net (without stand)
VESA Hole Configuration
Specifications
Environmental Conditions:
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude
Limited Warranty
Thin-frame (bezel), tilt, No Touch Auto Adjust, cable management,
NaViSet software, digital smoothing, digital controls, user (OSM)
controls, Plug and Play (VESA DDC & 2Bi), AccuColor color control,
DDC/CI, VESA DPMS power management, ISO 13406-2 Class II
No
100-240V @ 50/60 Hz
36W
2W
14.5 x 15 x 8.1 in. / 368 x 381.5 x 205mm
14. 5 x 12.5 x 2.4 in. / 368 x 316.5 x 60.6mm
8.8 lbs. / 4 kg
7.9 lbs. / 3.6 kg
100 x 100mm
5-35°C / 41-95°F
10-80%
3048m / 10,000 ft.
-10-60°C / 1 4-140°F
10-85%
12,192m / 40,000 ft.
1 year parts and labor, including backlight
Thin- frame (bezel), tilt, No Touch Auto Adjust, cable management,
NaViSet software, digital smoothing, digital controls, user (OSM)
controls, Plug and Play (VESA DDC 1/2B), AccuColor color control,
DDC/CI, VESA DPMS power management, ISO 13406-2 Class II
No
100-240V @ 50/60 Hz
37W
2W
16 x 16 x 8.1 in. / 405.5 x 405.5 x 205mm
16 x 13.6 x 2.4 in. / 405.5 x 346 x 61.5mm
11.7 lbs. / 5.3 kg
10.8 lbs. / 4.9 kg
100 x 100mm
5-35°C / 41-95°F
10-80%
3048m / 10,000 ft.
-10-60°C / 1 4-140°F
10-85%
12,192m / 40,000 ft.
1 year parts and labor, including backlight
Technical Support
OSM is a registered trademark and NaViSet, No Touch Auto
Adjust and Rapid Response are trademarks of NEC Display
Solutions. All other brand or product names are trademarks or
registered trademarks of their respective holders. Product
specifications subject to change.
©2006 NEC Display Solutions of America, Inc.
All rights reserved. 8/06 ver. 1.
24 hours / 7 days
24 hours / 7 days
NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
