Nec 60004223 Product Data Sheet

Datasheet

MultiSync® E221N

NEC LCD 22" Commercial Display

NEC MultiSync®E221N Ultra-Thin Bezel - The Office Workhorse, combining sleek and elegant design with health-conscious performance

The 22” ultra-thin bezel display targeting reliable office productivity, performance and quality, fulfils demand for future-ready design. Enduring
productivity requires high attention to healthcare. Thanks to the built-in Low Blue Light Plus technology your eyes are protected and ensure overall well­being. It filters out only the hazardous blue light emissions and eliminates flickering, keeping the eye safe while ensuring a true-to-life display colour
performance from all viewing angles. The LED backlight panel with AH-IPS technology supports a high display brightness of 250 cd/m² and in parallel
lowers power consumption.

The ultra-narrow bezel display reduces the display footprint without compromising on screen size and gives an office a fresh professional interior with its
sleek and elegant design.

Benefits

Future-Ready Design – best in form and function design with 3-sided 1 mm ultra-thin bezel gives an office a fresh professional interior.
Protecting your eyes from strain and damage – built-in Low Blue Light Plus technology filters out hazardous blue light emissions and eliminates

flickering protecting your eyes against cataracts and macular degeneration without compromise to true-to-life display colour performance.

Ergonomic Office – full height adjustability (110 mm), swivel, tilt and pivot functionality ensures perfect individual ergonomic set-up.
Business Class Image Quality – IPS (AH-IPS) panel provides the very best viewing angles as well as noticeably better colour production.
Your environmental and social responsibility – NEC`s TCO 7 and ENERGY STAR 7 certified display is environmentally designed with minimal

hazardous materila meeting the growing demand for more sustainable technologies.

NEC LCD 22 Commercial Display - MultiSync® E221N (1 / 3)

Product Information

Product Name MultiSync®E221N

Product Group NEC LCD 22" Commercial Display

Order Code 60004223 (WH) , 60004224 (BK)

Display

Panel Technology IPS TFT with W-LED backlight

Screen Size [inch/cm] 21.5 / 54.62

Screen Aspect Ratio 16:9

Pixel Pitch [mm] 0.248

Brightness (typ.) [cd/m²] 250

Contrast Ratio (typ.) 1000:1

Viewing Angle [°] 178 horizontal / 178 vertical (typ. at contrast ratio 10:1)

Response Time (typ.) [ms] 6

Colours [Mio.] 16.77

Synchronisation Rate

Horizontal Frequency [kHz] 31.5 - 81.1

Vertical Frequency [Hz] 56 - 76

Resolution

Optimum Resolution 1920 x 1080 at 60 Hz

Connectivity

Digital 1 x DisplayPort; 1 x HDMI

Analog 1 x D-sub 15 pin

Electrical

Power Consumption on Mode [W] 15 (Eco Mode 1); 17 (typ.); 25 (max.)

Power Savings Mode [W] 0.29

Environmental Conditions

Operating Temperature [°C] +5 to +25

Operating Humidity [%] 20 to 80

Ergonomics

Height adjustable stand [mm] 110

Screen Tilt [°] 5 to 20

Screen Swivel [°] 45 to 45

Mechanical

Bezel Width [mm] 1 (left and right); 1 (top)

Dimensions (W x H x D) [mm] 488.1 x 359.8 x 213.9

Weight [kg] With stand: 5

VESA Mounting [mm] 100 x 100

NEC LCD 22 Commercial Display - MultiSync® E221N (2 / 3)
