Personal Access Terminal / PAT490 User Manual
Personal Access Terminal User Manual
For PAT490
Notice to Users
Today's PCs are like supercomputers. And most PC users only use a small fraction as low as 5% of
the power of their machines. NComputer takes the excess capacity and allows up to 30 users to
each enjoy their own rich PC experience. They feel like they have their own PC, but at a fraction
of the cost and without all of the maintenance headaches.
Contents:
PAT490 Specifications …………………………………………………….............2
Wireless Specification …………………………………………………….............3
Terminal Configuration ……………………………………………………………4
Simple Connect To Server ……………………………………………………4
Device Settings ……………………………………………………………….4
Network ………………………………………………………………………5
Upgrade ………………………………………………………………………5
Password ……………………………………………………………………..6
Connect T o PC ……………………………………………………………….7
1
Personal Access Terminal / PAT490 User Manual
PAT490 Specifications:
Resource PAT490/PAT490L
Stand-alone operating system WIN CE 6.0 OS
Maximum Users Each Terminal For One Users
CPU ARM11 800HZ
RAM 128MB
STORAGE 128MB
Audio output
Have
Audio input Have (except remote desktop connection)
USB Port
3
COM TAP
Derivable
Support scanning gun YES
Support touch screen YES
Support printer Only network printer
Power input 5V~2A power 5W
Communication connection mode Straight-through Twisted Pair
Size（mm)
115*115*26
Support Max resolution
1280*1024or1440*900@24 color
WIFI 802.11n
Wireless Output Power
74 mWatt
Support of the operating system
win XP/2000/2003/7/vista/2008/linux
Keyboard mouse port USB
Whether could do USB upgrade YES
2
Personal Access Terminal / PAT490 User Manual
Wireless Specification:
Features
CMOS Technology with RF, Baseband, and MAC integrated.
1T1R Mode with 150Mbps PHY Rate for Both Transmit and Receiving.
802.11n Standard
Legacy and High Throughput Modes 20 MHZ Bandwidth.
Reverse Direction Grant Data Flow and Frame Aggregation.
WEP 64/128, WPA, WPA2, TKIP, AES, QOS-WMM, WMM-PS
WEP 64/128, WPA, WPA2, TKIP, AES, QOS-WMM, WMM-PS
WPS, PIN, PBC
Multiple BSSID Support
USB 2.0
International Regulation - 502.11 d + h
Wireless Output Power: 74 mWatt
Low Power with Advanced Power Management
Channel Range:
Channel Channel Range
Channel 01 2414.5 MHz - 2439.5 MHz
Channel 02
2419.5 MHz - 2444.5 MHz
Channel 03
2424.5 MHz - 2449.5 MHz
Channel 04
2429.5 MHz - 2454.5 MHz
Channel 05
2434.5 MHz - 2459.5 MHz
Channel 06
2439.5 MHz - 2464.5 MHz
Channel 07 2444.5 MHz - 2469.5 MHz
Channel 08 2449.5 MHz - 2474.5 MHz
Channel 09 2454.5 MHz - 2479.5 MHz
Channel 10 2459.5 MHz - 2484.5 MHz
3
Personal Access Terminal / PAT490 User Manual
Terminal Configuration:
1. Device Setup: connecting with the server
2. Device and Time setup ，
①Setting a regular time---Set time manually,select your region in control panel.
②Sync time with server---input IP address of the server ( keep networking)
③Sync Internet---Select one number(3 number is recommended,it depends on your country)
(Save the setting)
3.Log-in setting
4
Personal Access Terminal / PAT490 User Manual
4.Network setting
1)Assign IP addresses automatically if DHCP
2)Enter IP address manually if STATIC
5. Update setting
Here you can change boot image and upgrade system manually
The password for changing boot image.Password for changing logo: thinclientadmin
5
Personal Access Terminal / PAT490 User Manual
6, Password setting
Pls set password only in necessary. Keep your password in mind,it can not reset.
6
Personal Access Terminal / PAT490 User Manual
7.Connect T o PC: Pls choose desktop mode, to enter into local desktop.
Here it is available for RDP connection.
Click this option
7
Personal Access Terminal / PAT490 User Manual
8.Connecting with the server
Enter into IP address
Enter into user name and password that you creates in the server
8
Personal Access Terminal / PAT490 User Manual
Click Yes,pls tick it if you do not want to see the notice next time.
Now RDP connects.
If you fail to connect with the server.
Pls check if.
1,The network is connected.
2,The date & time of thin client is the same as the server.
3,You have created a user and password in the server,the password field can not be empty.
9
