N-Com B4 User Instructions

Firmware Version: 3.10

EN

USER INSTRUCTIONS AND SAFETY

Congratulations on your purchase of an N-Com product.

N-Com B4

B4B4

B4 was made using the most advanced technologies and the best materials.

Long-running tests and thorough system development have allowed the highest audio
quality to be achieved.

For additional information about B4

B4B4

B4, and to download high-definition instructions as

well as the latest Firmware version, visit the website www.n-com.it

REFERENCE STANDARDS

The products of the N-Com line are in compliance with standards as per the table below:

B4

B4B4

B4

The Bluetooth system complies with the main safety requirements and
other applicable provisions of Directive 99/5/CE, Directive 2002/95/CE,
Directive 2002/96/CE

Battery
charger

Directive 2006/95, 2004/108, 2002/95/CE, 2002/96/CE, 2009/125/CE

Battery Directive 2006/66
The Declarations of Compliance can be downloaded from the website www.n-com.it
(Download section).

FccID: Y6MNCOM4

N21550

Bluetooth is a registered trademark property of Bluetooth SIG, Inc.

---------------------------------------------------

FOR USA MARKET ONLY: SPECIAL WARNING

This device complies with part 15 of the FCC and Industry Canada Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.

Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s
authority to operate the equipment.

This product has been tested and complies with the specifications for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used according to the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which is
found by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment or devices

• Connect the equipment to an outlet other than the receiver’s

• Consult a dealer or an experienced radio/TV technician for assistance

FccID: Y6MNCOM4

N21550

Bluetooth is a registered trademark property of Bluetooth SIG, Inc.

B4

3

Contents

1. WARNINGS AND SAFETY ............................................................5

1.1.Road safety........................................................................................5

1.2.Switching on the system in safe environments .......................................5

1.3.Interferences .....................................................................................5

1.4.Appropriate use ..................................................................................5

1.5.Qualified personnel .............................................................................6

1.6.Accessories and batteries.....................................................................6

1.7.Disposal ............................................................................................6

2. CONTENT OF THE PACKAGING ....................................................7

3. INSTALLATION ...........................................................................8

3.1.Removing the B4 system from the helmet ...........................................10

4. BASIC FUNCTIONS....................................................................10

4.1.System menu ...................................................................................10

5. N-COM WIZARD ........................................................................11

6. PAIRING UP BLUETOOTH DEVICES ...........................................11

6.1.Affiliation reset function .....................................................................12

7. MOBILE PHONE FUNCTIONS .....................................................12

8. GPS SATELLITE NAVIGATOR FUNCTIONS .................................12

9. STEREO FM RADIO....................................................................13

10. BLUETOOTH A2DP MUSIC PLAYER ............................................13

11. AUDIO DEVICES WITH CABLE CONNECTION.............................14

12. RIDER-PASSENGER INTERCOM MODE.......................................14

12.1.Intercom affiliation ..........................................................................14

12.2.Intercom function ...........................................................................14

13. BIKE-TO-BIKE INTERCOM.........................................................14

13.1.Bike-to-Bike pair up ........................................................................15

13.2.Making a Bike-to-Bike call ................................................................15

13.3.Taking a Bike-to-Bike call ................................................................15

14. BATTERY...................................................................................16

14.1.Battery discharged signal.................................................................16

14.2.Recharging the system ....................................................................16

15. SUMMARY TABLE OF CONTROLS ...............................................17

16. LIMITED WARRANTY ................................................................18

16.1.Warranty coverage..........................................................................18

16.2.Exclusions and limitations of the coverage .........................................18

16.3.Validity of this limited warranty ........................................................19

16.4.Procedure for the forwarding of claims...............................................19

16.5.Product identification.......................................................................20

B4

5

1. WARNINGS AND SAFETY

Read this User Manual carefully, as well as the User Manuals for other N-Com kits that you will
be using with the N-Com B4

B4B4

B4. Read the simple rules listed below. Failure to comply with these

rules may lead to dangerous situations.

Caution: The product cannot be used in official or non-official competitions, motordromes,

circuits, racing tracks and the like.

Caution: Installation of the N-Com B4

B4B4

B4 system results in a weight increase of approximately

110g, which is added to the weight of the helmet and of the other accessories.

Warning: The electronic components of the N-Com system mounted inside the helmet are

not waterproof. Consequently, make sure the inside of the helmet, including the comfort
padding, does not get wet in order to avoid damage to the system. If it does, remove the
N-Com system and the helmet comfort padding and let it air dry. Remove the battery from
its housing and let it dry.

1.1. Road safety

Always obey all Traffic Regulations in force. While riding the motorcycle, your hands should
always be engaged in actually riding the vehicle. Any operation to the N-Com system must be

carried out with the vehicle stopped. Specifically:

• Set your cell phone on automatic answer (see the cell phone instructions to do this).

• If your cell phone is not equipped with this function, first stop your vehicle in a safe area,

in compliance with Traffic Regulations and then answer the call.

• Do not make any calls while riding. Stop your vehicle in a safe place in compliance with

Traffic Regulations, and then make the call.

• Adjust the volume so that it does not cause a disturbance or distraction while riding and

at the same time allows you to distinctively hear background noises.

• Do not operate your cell phone or other devices connected to N-Com while riding your

motorcycle.

• In all cases, obey the Traffic Regulations and remember that riding the motorcycle has

absolute priority over any other manoeuvre.

1.2. Switching on the system in safe environments

• When using the N-Com system, comply with all limitations and instructions related to the

use of cell phones.

• Do not turn on your cell phone or the N-Com system whenever their use is forbidden or

when the devices can cause interference or dangerous situations.

• Turn off while refuelling. Do not use the N-Com system in filling stations. Do not use the

device near combustible materials or chemical products.

• Turn off in proximity to explosive materials.

1.3. Interferences

All phones and devices with wireless signal transmission are subject to interferences that may
affect the performance of the device connected to them. These interferences are not
ascribable to a defect of the N-Com system.

1.4. Appropriate use

Use the device only in the normal position, as described in the product documentation. Do not
attempt to disassemble, tamper with or modify any part of the N-Com system.

Caution: Adjust the volume of the N-Com system (where provided) and of the audio sources

connected to it before you use the system on the road.

Caution: Adjusting the volume to very high levels may cause damage to your hearing.

Caution: Adjust the volume of the N-Com system (where provided) and of the audio sources

connected to it so as to avoid audio reproduction at high volumes. Constant exposure to
high audio volumes may damage your hearing.

6

Caution: An incorrect installation of the system in the helmet may alter the aerodynamic and

safety characteristics of the helmet itself, thus creating dangerous conditions. Install the
N-Com system according to the instructions provided in the product documentation. In
case of doubt, please contact your local N-Com dealer.

Warning: Listening to other equipment should not interfere with driving the vehicle, which

must be the top priority at all times. Carry out all operations on the electronic equipment
and on the N-Com system with the vehicle stopped, in compliance with Traffic Regulations.

Caution: B4

B4B4

B4 allows radio reception. Any radio licence fees are to the user’s charge.

1.5. Qualified personnel

• Only qualified personnel can carry out technical assistance on this product. In case of any

malfunction, always turn to your local dealer.

• The helmet is a safety device. Tampering with it and/or with the electronic system inside

the helmet, in addition to invalidating the product warranty, can also lead to dangerous
situations.

1.6. Accessories and batteries

• Only use the type of batteries, battery chargers and accessories approved by Nolan for

the specific model.

• The use of a battery type different from the recommended one may lead to dangerous

situations and invalidate the warranty.

• Contact your local dealer to see about the availability of approved accessories.

• When disconnecting the power supply cable of any accessory or of the battery charger,

always grab and pull the plug not the cable.

• Do not use batteries for purposes other than the prescribed ones.

• Never use batteries or battery chargers that turn out to be damaged.

• Do not short-circuit the battery.

• Keep the battery at a temperature between 0° / +45°C (charging); -20° / +60 °C

(in use).

• Danger of fire or explosion: do not throw the batteries into a fire nor expose them to high

temperatures!

• Do not throw out batteries together with household refuse. The batteries should be

disposed of in compliance with local regulations

• Do not wear the helmet while the battery is recharging.

• The helmet should never be left within the reach of unsupervised children in order to

prevent damage to their health caused by access to the batteries.

Battery Lithium Ion AB463651BU Lithium 3,7V – 800mAh
Battery charger AK00G-0500040VU 100/240V – 50/60 Hz 5V - 0.4 A

1.7. Disposal

Refer to this user manual and to manuals related to other parts of the N-Com system in order
to disassemble the system from the helmet. Once the system has been disassembled, dispose
of it according to the following instructions:

• The presence of a crossed-out wheelie bin indicates that in the European Union

the product is subject to separate collection at the end of its useful life
(European Directive 2002/96/EC).

• Do not dispose of these products together with undifferentiated urban waste.

• The proper disposal of obsolete equipment contributes to preventing possible negative

consequences on people’s health and on the environment.

• For more detailed information on the disposal of obsolete equipment, contact your

municipality, a waste disposal service or the store where the product was purchased.
