Projection Dual Alarm Clock with
USB Charger
NRC-167
Instruction Manual
Please read carefully before use and keep for future reference.
Important Safety
Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that maybe of sufcient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has
two blades and a third grounding prong. The wide blade
or the third prong are provided for your safety. If the provided plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
Page 2 Naxa Electronics
12. Use only with the cart, stand, tripod,
bracket, or table specied by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in
any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
CAUTION ON MODIFICATIONS
Any changes or modications not expressly approved by the
grantee of this device may void the authority granted by the
FCC to operate the equipment.
www.naxa.com Page 3
Page 4 Naxa Electronics
At a Glance
1 PM Indicator
2 1st Alarm Indicator Buzzer
3 1st Alarm Indicator Music
4 Volume Increase/Alarm 1 Set
5 Volume Decrease/Alarm 2 Set
6 Preset Memory Selection/
Time Set
7 Tuning + Button/Hour Button
8 Tuning – Button/Minute But-
ton
9 AM/FM Button
10 On Off/Alarm Off Button
11 Snooze Indicator
12 2nd Alarm Indicator Radio
13 2nd Alarm Indicator Buzzer
14 Sleep Button
15 Snooze Button
16 Projection ON/OFF
17 Time Set For Projection
18 Hour Set For Projection
19 Minute Set For Projection
20 Focus
www.naxa.com Page 5
21 Antenna
22 Battery Backup Compartment
23 AC Adapter Plug in
24 Speaker
25 USB Charging
Page 6 Naxa Electronics
Connecting the Unit
to Power
Before plugging in the AC power cord to the AC
wall outlet, make sure that the voltage of your
electricity supply is same as that indicated on
the rating plate.
Battery Backup
Battery backup will preserve the current time,
alarm settings, and stored radio stations in the
case of power failure or interrupted AC power.
Insert two UM-4 batteries (AAA) into the battery compartment. Be sure to observe the
proper polarity (the “+” and “-” signs) as indicated inside the battery compartment.
Setting the Clock
1. You must switch off the radio before you
set the clock time.
2. Press and hold the “TIME SET” button un-
til the display begins to ash.
3. Press the Hour and Minute buttons to ad-
just the time. Take note of the PM indicator when setting the time.
4. Press the “TIME SET” button again to n-
ish setting the time.
To Use the Projector
The clock time must be set on the projector
separately. Press and hold the “TIME” button
on the projector unit, then press HOUR and
www.naxa.com Page 7
MINUTE to adjust the time. Aim the projector
lens at a at surface, and then turn the focus
dial to focus the image.
Setting the Alarm
1. You must switch off the radio before you
set the alarm time.
2. Press and hold the “ALARM 1” or “ALARM
2” button until the Hour display begins to
ash.
3. Press the ALARM 1 button again to select
a wake mode (wake by radio or by buzzer).
The display will show a picture of a bell to
indicate wake by buzzer; the music note
logo indicates wake by radio.
4. Set the alarm time after you select the
wake up mode. Press the “Hour” button
and the “Minute” button to adjust the
time.
5. Press the “ALARM 1” button once more to
nish setting the alarm time.
Canceling the Daily Alarm
Press the “ALARM OFF” button to stop the
alarm. The alarm will sound again at the same
time on the next day.
Canceling the Alarm
Press the “ALARM 1” or “ALARM 2” buttons.
The display will show “OFF” and all wake up
mode icons will also disappear. The alarm setting is canceled now.
Page 8 Naxa Electronics
Snooze and Alarm Reset
Press the SNOOZE button when the alarm is
sounding to stop the alarm and have it sound
again automatically after 9 minutes.
Radio
1. Press the “ON/OFF” button to turn the
clock radio on or off.
2. Press the “AM/FM” button to select radio
band.
3. Press the “TU+” or “TU-“ button to tune
to the desired station.
4. Press the “VOL +” or “VOL -“ button to
adjust the volume.
5. Press the “M+” button to save the current
station to preset memory. The display will
show “P01” to indicate that the station
has been saved as Preset #1. (If it displays
“P02” this means the station is saved as
Preset #2.
Please note that all 10 presets
must be saved with stations before preset tuning will work.
Setting the Sleep
Time
1. You must switch off the radio before you set
the sleep time. The radio will turn itself off
after the set amount of time has elaspsed.
2. Press the Sleep button repeatedly to set
the sleep time (90, 80, 70, 60, 50, 40, 30,
20, 10 min or OFF).
www.naxa.com Page 9
Charging Your Devices
Connect the standard end of a USB cable (not
included) to the USB port on the rear of the
unit and connect the other end to the charging port of your device. USB cables may differ by manufacturer, so be sure to use the one
provided with your device.
Some devices may not support
USB charging or may require a
higher power rating than this
product provides. Observe the
charging status on your device, or
refer to the manufacturer’s specications. There are many different devices with different power
requirements; we cannot guaran-
tee charge support for all devices.
Ensure that your device is working properly before attempting to
charge it.
Specications
Frequency Range AM 530 – 1700 kHz
FM 88 – 108 MHz
Power Supply AC 120V ~ 60Hz, 5W
USB Charge Output DC 5V, 1.2A
Back-Up Battery 2 pc. UM-4 (AAA)
Specications are subject to change without
prior notice.
Support
If you have problems with your device, please consult the instructions in this manual. Please
also visit us on the web at www.naxa.com to get up to the minute news, alerts, and documentation for your device. For additional assistance, please contact Naxa Technical Support.
NAXA Technical Support
2320 East 49th St.
Vernon, CA 90058
http://www.naxa.com/naxa_support/
