7” Core™ Tablet with 8GB Memory
NID-7014
Instruction Manual
Please read carefully before use and keep for future reference.
Table of Contents
Thank You ........................................................ 4
In the Box .........................................................4
Important Information About Your Tablet ... 5
At a Glance ....................................................... 6
Getting Started ................................................ 8
Power On/Power Off .........................................................8
Sleep Mode ................................................................... 8
Charging ........................................................................ 8
Connecting to a Wireless Network ................................. 8
Using the Touchscreen ...................................................... 9
Using the Home Screen ................................................... 10
Using the Navigation Icons ............................................. 10
About the Notication Panel .......................................... 11
About the Quick Settings Panel .....................................12
Using the Lock Screen ......................................................12
Using the On-Screen Keyboard ......................................12
Entering Text ............................................................... 12
Basic Editing ................................................................13
Entering Text by Swipe (Gesture Typing) ............... 14
Entering Text by Talking (Dictation) ....................... 14
Making Yourself at Home ..............................15
Adding an App Icon to the Home Screen .......................15
Adding Widgets to the Home Screen .............................15
Using Folders on the Home Screen ................................16
Changing the Wallpaper ..................................................16
Managing & Using Apps ..................................17
About the Apps ..................................................................18
Manage your Calendar ..............................................18
Using the Camera .......................................................19
Managing Downloads .......................................................19
Page 2 Naxa Electronics
Connecting to Wi-Fi Networks ..................... 20
Adding a Network ...........................................................20
Adding a Network Manually ...........................................21
Removing a Network ........................................................21
Setting Advanced Wi-Fi Options ................................... 22
Troubleshooting ............................................ 33
Warnings and Precautions ............................34
Specications .................................................37
Connecting to Bluetooth® Devices ............... 23
Support .......................................................... 38
Adjusting the System Settings ..................... 24
WIRELESS & NETWORKS ................................................24
DEVICE ............................................................................... 25
PERSONAL ......................................................................... 28
ACCOUNTS ......................................................................... 29
SYSTEM .............................................................................. 30
Other Connections .........................................30
Connect to a Computer via USB ....................................30
Using HDMI Out .................................................................31
Tuning Your Tablet’s Performance ................31
Optimizing battery life .....................................................31
To extend the life of your battery ...........................31
Check battery level and usage details ..................32
www.naxa.com Page 3
Thank You
In the Box
We know you have many choices when it comes to
technology; thank you for choosing us here at Naxa
Electronics. Established in 2001 in Los Angeles, California, we are dedicated to delivering products that entertain and delight.
We trust that you will be happy with your purchase.
Please read this manual carefully and save it for refer-
ence. You may also nd the latest FAQ, documentation,
and other product material at our website. Come visit
us on the web at www.naxa.com and see all that we
have to offer!
Please take a moment to make sure that you have everything in the list below. Although we make every effort to ensure that each Naxa device is securely packed
and sealed, we know a lot can happen in between us
and you. If anything is missing, check back with your
local retailer to get immediate assistance. If they cannot help you, please contact our Naxa Support team at
www.naxa.com/naxa_support.
• NID-7014
• USB cable
• AC power adapter
Page 4 Naxa Electronics
Important Information About Your Tablet
Please read the following carefully; these are important things to know about your tablet before you get
started.
1. Do not drop the unit. Avoid forceful shaking of the
display to prevent damage or unusual operation.
2. Do not touch the unit with metal objects to avoid
short circuits.
3. Schedule regular backup of your data to prevent
the loss of important data. Always backup your
data before upgrading the rmware.
4. Do not disassemble. Do not wipe the surface of the
unit with alcohol, thinner or benzene.
5. Do not disconnect the tablet while it is formatting
or uploading/downloading. Doing so may corrupt
your data.
6. Do not allow water or foreign objects to enter the
tablet.
7. Do not use the tablet in places that are extremely
hot, cold, dusty, or humid.
8. Specications are subject to change and improve-
ment without notice.
MEANING OF THE DUSTBIN SYMBOL
Protect our environment: do not dispose
of electrical equipment in your domestic waste. Please return any electrical
equipment that you will no longer use
to the collection points provided for
their disposal. These simple steps can help to avoid
the potential effects that incorrect waste disposal can
cause on the environment and human health. This will
contribute to recycling and other forms of re-use of
electrical and electronic equipment. Information concerning where the equipment can be disposed of can be
obtained from your local authorities.
Made in China
www.naxa.com Page 5
At a Glance
1 Touch screen Display and touch screen.
2 Front camera Designed for use with video chat apps.
Page 6 Naxa Electronics
3 Rear camera Great for taking quick pictures and
videos.
4 Reset Press to turn the tablet off and back on if
it should freeze or exhibit other abnormal behavior. (You may need something small like a paperclip to press the
button.)
5 Speaker Built-in speaker
6 (POWER) Press and hold to turn the tablet on.
Press and hold to access the power menu to
turn the tablet off.
7 3.5mm headphone output jack.
8 USB USB (micro type B) connector.
Connect to a power source with the included
power adapter to charge the tablet.
Connect to a computer to sync data.
9 HDTV out HDMI mini connector for output to an HDTV.
10 microSD
slot
www.naxa.com Page 7
Load a microSD card for additional storage.
Getting Started
Power On/Power O
Press and hold the button until the screen turns on
and displays the start-up logo (about 5 seconds).
Press and hold the button until the tablet presents
the power menu (about 3 seconds). Tap OK or Power
Off to turn the tablet off.
Sleep Mode
Place the tablet into Sleep mode to conserve power.
To place the tablet into Sleep mode, press the button
once while the tablet is on. The screen will turn off.
To wake the tablet from Sleep mode, press the button again. The screen will turn on. (It may take a second
or two for the tablet to wake from sleep.)
Charging
When the battery level is low, the tablet will prompt
you to charge the tablet. Connect the provided power
adapter to the USB port to charge the tablet.
To improve the performance and life of the
battery, charge the tablet for an additional
15 minutes after the tablet indicates that it
has been fully charged.
Connecting to a Wireless Network
Your tablet works best when it is connected to the Internet. Connect to a wireless network to experience
the best that your tablet has to offer. To learn how
to connect to a wireless network, refer to the section
“Connecting to Wi-Fi Networks”.
Page 8 Naxa Electronics
Using the Touchscreen
Use your ngers to manipulate icons, buttons, menus,
the onscreen keyboard, and other items on the touchscreen. You can also change the screen’s orientation.
To select or activate something, tap it gently with your
nger.
To type something (e.g., a name, password, or a website
address), just tap where you want to type. A keyboard
will appear on the screen; tap the keyboard to type.
Other common gestures include:
Tap & Hold Tap an item & hold your nger over
it until an action occurs. Do not lift
your nger from the screen.
Tap & Drag Tap an item & hold your nger over
it for a moment; then, without lifting
your nger, drag your nger along
the screen until you reach the target
position. Try using Tap & Drag to reposition icons on the Home screen.
Double Tap
Tap an item quickly twice. In some apps
(such as Browser), you can zoom in (and out)
by double tapping on an image or section of
text.
Swipe or Slide Slide your nger quickly across the
surface of the screen. Do not pause
when your nger rst touches the
screen to avoid dragging items accidentally. Swipe up or down to browse
a list of items, or try swiping left or
right on a Home screen to view other
Home screens.
Pinch-toZoom
In some apps (such as Browser and
Gallery), you can zoom in and out by
placing two ngers on the screen at
once and pinching them together (to
zoom out) or spreading them apart
(to zoom in)
Rotate the
Screen
On most screens, the orientation of
the display will automatically rotate
with your tablet as you turn it. You
can change this option from the Display setting screen.
www.naxa.com Page 9
Using the Home Screen
Using the Navigation Icons
The Home screen is the rst thing you’ll see when you
turn on the tablet. The Home screen can display app
icons, widgets, and folders.
• To open an app, folder, or widget (tools), tap its icon.
• To see additional Home screens, swipe the screen
left or right.
• To return quickly to the main, center Home screen,
tap the Home icon displayed in the bottom left
corner.
• At the bottom of each home screen is the Favor-
ites tray. At the center of the Favorites tray is the
All Apps icon.
• To open an app in the Favorites tray, tap it.
• You can customize the Favorites tray with apps
that you use a lot. To move apps in and out of
the Favorites tray (or anywhere else on a home
screen), tap and hold it, then drag it with your
nger into position.
The Navigation icons are displayed at the bottom of
the screen. These three icons are always accessible. No
matter what you are doing, you can always tap these
icons to browse the different screens of your tablet.
Icon Name Description
Switch
Apps
Screen
shot
Home Tap this icon to go to the Home screen. If
Back Tap this icon to return to the previous screen,
Tap this icon to display a list of apps that
you’ve worked with recently. Tap the thumbnail image of any app to switch to it.
Swipe up and down to browse the list. To remove an app from the list, swipe the thumbnail off the screen to the left or right.
Tap to save the current screen as a picture to
review or share.
there are multiple Home screens, tap Home
again to return to the center Home screen.
even if it was in a different app. Tapping
Back repeatedly will return you to the Home
screen; you cannot go back further than the
Home screen.
Page 10 Naxa Electronics
Icon Name Description
Volume
down
Volume upTap to raise the volume level. This icon is vis-
Tap to lower the volume level. This icon
is visible only when the tablet is held
horizontally.
ible only when the tablet is held horizontally.
The Navigation icons may fade away if the
screen has not been touched in a while –
for example, when watching a video. Simply
tap the lower left corner of the screen to
display them again.
About the Notication Panel
Notications from apps will appear at the top of your
screen. Notications may let you know that a message
or e-mail has arrived, or that it’s time for a meeting.
Swipe down from the top of the screen to open the No-
tication Panel.
Dismiss all notica-
tions
Some notications
have additonal actions
you can take.
Some notications can
be expanded by swiping down.
• Tap a notication to open the app that sent the no-
tication.
• Some notications may allow you to swipe down to
view more information about it. Place your nger
inside the notication and swipe down slowly to
expand the notication.
• Swipe the notication left or right to dismiss it, or
tap the “Dismiss all” icon at the top right.
www.naxa.com Page 11
System icons on the right show the current
wireless and network connection strength,
battery level, and more.
After you set a lock here, the tablet will display the
lock screen whenever you turn the screen on. You will
need to enter the pattern, PIN, or other password to
continue using the tablet.
About the Quick Settings Panel
The Quick Settings panel allows you to easily adjust
commonly used options (e.g., Wi-Fi settings, display
brightness, main settings).
Swipe down from the top right corner of any screen to
open the Quick Settings panel.
If your tablet is playing music when the screen locks,
you can continue listening or can pause the selection
without unlocking the screen.
Screen lock options are listed in the approximate order
of the strength of their security, starting with “None”
and “Slide,” which provide no security. Face Unlock and
Pattern provide minimal security, although it can be
more convenient than the stronger options.
Using the Lock Screen
Customize the lock screen settings to prevent unauthorized use of your tablet.
1. From Quick Settings Panel or the All Apps screen,
tap the Settings icon.
2. Browse to Personal > Security > Screen Lock.
3. Tap the type of lock to use on the Lock Screen (Slide,
Pattern, PIN, Password, or None).
Page 12 Naxa Electronics
Using the On-Screen Keyboard
Entering Text
Enter text using the onscreen keyboard. Some apps
automatically display the keyboard when necessary; in
Naxa recommends that you always establish a strong PIN or password for security.
⚠
others you display the keyboard by tapping where you
want to type.
As you type, the keyboard displays suggestions above
the top row of keys. To accept a suggestion, tap it.
To make the keyboard go away, tap the Close
icon found at the bottom of the screen.
• Selecting text: Tap & hold (or double-tap) within
the text. The nearest word will be highlighted with
tabs at each end of the highlighted selection. Tap
& drag the tabs to change the selection. The tabs
will disappear after a few moments; to make them
reappear, tap the text again.
• Deleting text: Tap to delete selected text or the
characters before the cursor.
• Cut, copy, paste: Select some text, then tap the
Paste icon.
Basic Editing
• Moving the insertion point: Tap where you want to
type. The cursor blinks in the new position, and a
green tab appears below it. Drag the tab to move
the cursor.
www.naxa.com Page 13
Tips & Shortcuts:
• To type in capital letters: Tap the Shift key once to
switch to capital letters for one letter. Tap & hold
the Shift key to type in capital letters. Release the
Shift key to return to typing in lower case letters.
• To turn caps lock on: Double-tap the Shift key to
turn Caps Lock on. The Shift key will be highlighted
to indicate that Caps Lock is active. To turn Caps
Lock off, tap the Shift key again.
It is not necessary to use the space bar be-
tween words. Simply start swiping the next
word when you’re ready and a space will be
entered between words.
• To show numbers or symbols: Tap the ?123 key. To
see more choices, tap the =\< key.
• To type special characters: Some keys can produce
alternate characters (e.g., accented vowels). Tap &
hold these keys to see alternate letters or symbols,
then tap the one you want to type.
• To change the input language or keyboard: Tap and
hold the microphone key to view the input options
menu.
Related settings
Settings > Personal > Language & input
Entering Text by Swipe (Gesture Typing)
To type words using a swipe type motion, slide your
nger across the letters of the word that you want to
type (as if drawing a line between each letter). Do not
release your nger from the screen until you have nished the word.
If a word is not recognized when gesture
typing, you can type it out manually.
Gesture typing works best in English. Other
languages may have partial support or may
not be supported at all.
Entering Text by Talking (Dictation)
To enter words by dicatation, tap the microphone key
on the keyboard. When you see the microphone image,
speak what you want to type.
Dicatation works best in English. Other
languages may have partial support or may
not be supported at all.
When speaking in English, you may say
“comma,” “period,” “full stop,” “question
mark,” or “exclamation mark” to enter
punctuation.
Page 14 Naxa Electronics
Making Yourself at Home
Personalize your home screens to make your tablet
work best for you!
Adding an App Icon to the Home Screen
Add icons of the apps you use the most to your Home
screen.
1. Go to the Home screen where you want to place the
app icon.
2. Tap the All Apps icon in the center of the Favorites
tray.
3. Find the app that you want. Apps are listed alphabetically; swipe left or right if necessary.
4. Tap and hold the app until the Home screen ap-
pears, drag it into place, then release your nger.
Adding Widgets to the Home Screen
Some apps have Widgets that can be placed on a Home
screen. Widgets are like windows into your apps; they
allow you to use some features of the app quickly from
the Home screen.
1. Go to the Home screen where you want to place the
widget.
2. Tap the All Apps icon in the center of the Favorites
tray.
3. Swipe to the right past your apps to nd the widget
that you want.
4. Tap and hold the widget until the Home screen ap-
pears, drag it into place, then release your nger.
If you have dragged the widget to a Home
screen that doesn’t have room for it, the
widget will not be added.
To remove an app icon from the Home
screen, tap & hold the icon, then drag it to
the Remove icon at the top of the screen.
www.naxa.com Page 15
Some widgets will prompt you to make
additional choices before it is added to the
Home screen.
To remove a widget from the Home
screen, tap & hold the icon, then drag
it to the Remove icon at the top of the
screen.
Using Folders on the Home
Changing the Wallpaper
Wallpapers are background images that you can use
to personalize your Home screens. Your wallpaper
can be a custom image, one of the wallpaper images
included with the tablet, or a Live Wallpaper (i.e., an
animated wallpaper).
Screen
You can combine several app icons in a folder. Drop
one app icon over another on a Home screen, and the
two icons will be combined.
On any Home screen, you can
• Open a folder: Tap it. The folder opens:
• Rename a folder: Tap the folder label.
• Reposition an icon on the screen: Tap & hold the
icon, then drag the icon to where you want it.
Place related app icons in the same folder
(e.g., video apps, game apps, communication apps, etc.).
To change the wallpaper:
1. Tap & hold on an empty part of a Home screen. A
list of wallpaper options will appear.
2. Tap a wallpaper source:
• Live Wallpapers: Choose an animated wall-
paper. (Using a live wallpaper may reduce
your tablet’s battery life.)
• Wallpapers: Choose an image that has been
designed for use as a wallpaper.
3. Tap Set Wallpaper to nish.
Additional wallpapers may be downloaded from the
Internet or Android application markets.
You may have additional wallpaper op-
tions to choose from if you have other
photo or imaging apps installed on your
tablet.
Related settings
Settings > Device > Display > Wallpaper
Managing & Using Apps
To see all your apps, tap the All Apps icon. (The All Apps
icon is on any Home screen at the center of the Favorites tray.) The All Apps screen will show you all of your
apps, including those you have downloaded yourself.
You can move app icons to any of your Home screens.
From All Apps, you can:
• See additional app screens: Swipe left or right.
• Launch an app: Tap its icon.
• Place an app icon on a Home screen: Tap & hold the
app icon, then drag the icon into place.
• Explore your widgets: Swipe right past the apps to
the widgets.
• Learn more about an app: Tap and hold the app
icon, drag it to the App Info icon at the top of the
screen, then release your nger.
• Uninstall an app: Tap and hold the app icon, drag it
to the Uninstall icon at the top of the screen, then
release your nger.
www.naxa.com Page 17
Some apps are required by your tablet and
cannot be uninstalled.
After you open an app, you can usually
adjust its settings by tapping the Menu icon
near the top or bottom of the screen.
on your Tablet, or from another device that is synced to
your Google Account. As you add events from different
sources, they are synced automatically across all the
places you need them.
To view your Calendar, tap on the Home screen or All
Apps screen.
About the Apps
Some apps have been preinstalled on the tablet for
your convenience. You can learn more about these
apps by reading this section.
Some apps may not work if certain region
and network service requirements are not
met.
Manage your Calendar
The Calendar app lets you view and edit your schedule.
When you sign into a Google Account, any existing calendar events from that account will be synced with
your Calendar app. After that, all of your events will
stay in sync automatically, whether you make changes
Page 18 Naxa Electronics
To change the Calendar view, tap the tabs at the top of
the screen labeled Day, Week, Month, or Agenda.
Swipe to scroll vertically or horizontally. In the Day or
Week views, spread your ngers apart or pinch them
together to zoom in or out.
From any of these views, you can:
• Read or edit event details. Tap an event to view its
details.
• Manage events and calendars. Tap the icons across
the top of the screen or tap Menu for additional
options.
Using the Camera
The Camera app is a combination camera and camcorder.
To take pictures and videos, rst tap the Camera icon
on a Home screen or the All Apps screen.
You can view photos and videos you take with the camera in the Super-HD Play app.
signed into your Google Account or other account
that allows picture sharing).
Managing Downloads
Files, apps, and other items you download from your
email, app marketplaces, or in other ways are saved to
your tablet’s internal storage. Use the Downloads app
to view, open, or delete what you’ve downloaded.
When Camera starts, you can:
• Take a picture (or start a video recording). Tap the
blue button.
• Switch between camera and camcorder modes. Tap
the camera or camcorder icons in the bottom right
corner of the screen.
• Switch between the front and rear camera. Tap the
switch camera icon.
• View the most recently taken picture. Tap the
thumbnail in the top right corner of the screen.
• Share the picture by tapping the icons displayed
along the right side of the image (you must be
www.naxa.com Page 19
Downloaded les are stored in the Download directory
that’s visible when your tablet is connected to a com-
puter. You can view and copy les from this directory.
To open Downloads and manage downloaded les:
1. Tap the Downloads icon from a Home screen or the
All Apps screen.
2. Tap an item to open it.
3. Tap the headings of earlier downloads to view them.
4. Check items you want to share. Then tap the Share
icon and choose a sharing method from the list.
5. Check items you want to delete. Then tap the Trash
icon.
6. At the bottom of the screen, tap Sort by size or Sort
by date to switch back and forth.
Connecting to Wi-Fi
Installing apps from unknown sources is
not recommended. Make sure you know
⚠
and trust the source of your apps.
To install apps from an unknown source,
you will need to allow your tablet to do so.
Go to Settings > Security > Device Administration to do so.
Networks
Your tablet works best when it is connected to the Internet. Your tablet can connect wirelessly to the Internet using Wi-Fi networks.
Wi-Fi is a wireless networking technology that can provide Internet access at distances of up to 100 meters,
depending on the Wi-Fi router and your surroundings.
To use Wi-Fi, you connect to a wireless access point, or
“hotspot.” Some hotspots are open and you can simply
connect to them. Others implement security features
that require other steps to set up, such as digital cer-
ticates or other ways to ensure that only authorized
users can connect.
Adding a Network
If you’re adding a Wi-Fi network when rst setting up
your device, Wi-Fi is turned on automatically.
Page 20 Naxa Electronics
1. Tap the Settings icon in the All Apps screen (or the
Quick Settings panel).
2. Under Wireless & networks, slide the Wi-Fi switch
to the On position. The device scans for available
Wi-Fi networks and displays the names of those it
nds. Secured networks are indicated with a Lock
icon.
Under Wireless & Networks, tap Wi-Fi to select it.
1. Tap the “+” icon found in the upper right of the
screen to open the Add Network settings.
2. Enter the SSID (name) of the network. If necessary,
enter security or other network conguration details.
3. Tap Save.
3. Tap a network name to see more details or to connect to it. If the network is secured, you will be
prompted to enter a password or other credentials.
(If you don’t know the password, you will need to
ask the owner of the network to provide it.) If the
tablet nds a network that you connected to previously, it will connect to it automatically.
Adding a Network Manually
Some Wi-Fi networks are congured so that the tablet cannot detect them automatically. These networks
need to be added manually.
www.naxa.com Page 21
The information about the network is saved. Your tablet will connect to this network automatically the next
time you come within range.
Removing a Network
To forget a network or to modify its settings, tap &
hold the network name.
• You may want the tablet to forget a network if you
don’t want to connect automatically or if you no
longer use the network.
• Modify a network’s settings to change the pass-
word or to congure its advanced options (i.e.,
Proxy and static IP settings). Networks are cong-
ured by default to not use proxy servers and to use
automatic IP addressing. Proxy settings need to be
added for each individual Wi-Fi network.
• Wi-Fi optimization: Minimize battery usage when
Wi-Fi is on. This screen also displays the following
information:
Setting Advanced Wi-Fi Options
Under Wireless & Networks, tap Wi-Fi to select it. Tap
the Menu icon and choose Advanced.
These are the settings you can adjust:
• Network notication: By default, when Wi-Fi is on,
you receive notications in the Status bar when
your device detects an open Wi-Fi network. Un-
check this option to turn off notications
• Keep Wi-Fi on during sleep: To conserve mobile
data usage, your device stays connected to Wi-Fi
when the screen goes to sleep. Tap this option to
change this default behavior: either to stay connected to Wi-Fi only when the device is connected
to a charger (when battery life isn’t a problem), or
to disconnect from Wi-Fi during sleep.
• Avoid poor connections: Don’t use a Wi-Fi network
unless it has a good internet connection.
• MAC address: The unique Media Access Control
(MAC) address of your tablet when connected
to a Wi-Fi network.
• IP address: The Internet Protocol (IP) address
assigned to the device by the Wi-Fi network
you are connected to (unless you used the IP
settings to assign it a static IP address).
Related settings
Settings > Wireless & networks > Wi-Fi
Settings > Wireless & networks > Data usage
Page 22 Naxa Electronics
Connecting to Bluetooth® Devices
Your Naxa tablet can connect to wireless Bluetooth
devices
Bluetooth technology works with computers, headsets, speakers, and other compatible devices to help
users stay connected wirelessly. Utilizing the 2.4GHz
ISM transmission spectrum for global audio & digital
data, Bluetooth has created a new wave in modern
communication.
To connect to a device, make sure that Bluetooth is
turned on. You will need to go through a one-time
“pairing” process to establish a secure connection to
your tablet.
1. Tap the Settings icon in the All Apps screen (or the
Quick Settings panel).
(that is, set it to “Discoverable” or “Pairing” mode).
This will allow the tablet to detect the device. Refer
to the documentation that came with your device
to learn more.
4. Tap Search for Devices in the upper right corner of
the screen. The tablet will attempt to detect the
device.
5. The name of the device will appear under the heading Available Devices. Tap on the device to pair it to
your tablet.
• If your device is protected by a PIN code, the
tablet will prompt you to enter the code in
order to connect. (Popular default codes are
“0000” and “1111”.)
6. Devices that have been paired to your tablet appears under the heading Paired Devices. Tap the
name of a paired device to connect to it.
2. Under Wireless & networks, slide the Bluetooth
switch to the On position.
3. Set the device to temporarily broadcast its identity
www.naxa.com Page 23
Adjusting the System Settings
1. Tap the Settings icon on a Home screen or the All
Apps screen.
2. The left column displays a list of the system settings. Tap a setting to display its options in the right
column.
The settings described here may change
slightly depending on which tablet version
you have.
Additional help is available online from
Google at https://support.google.com/
nexus/#topic=3415468.
WIRELESS & NETWORKS
Wi-Fi Options
To learn about the Wireless & Networks options, refer
to the section “Connecting to Wi-Fi Networks”.
Bluetooth Options
To learn about the Bluetooth options, refer to the section “Connecting to Bluetooth® devices”.
Data Usage Options
See how much data has been used by your tablet over
time, and how much data has been used by each of
your applications.
More Options
• Airplane Mode: Check this option to turn off ALL
wireless radios.
• Ethernet: This option is not used by your tablet.
• VPN: Add a VPN network for secure networking.
• Portable hotspot: Enable a connection to the Inter-
net over USB. This option is not used by your tablet.
• Mobile networks: This option is not used by your
tablet.
Page 24 Naxa Electronics
• 3G Support Information: This option is not used by
your tablet.
You’ll see four tabs at the top of the screen; swipe left/
right to change tabs. Each tab displays a list of apps or
their components.
DEVICE
Sound
Adjust the sound options of the tablet.
Display
Adjust the display options of the tablet.
Storage
Adjust the storage options of the tablet.
Battery
Adjust the battery options of the tablet.
Apps
The Apps settings allow you to adjust several aspects
of the way your tablet uses memory.
• Downloaded. Displays apps you’ve downloaded
from apps marketplaces.
• On SD Card. Displays apps that are installed on the
memory card.
• Running. Displays all apps, processes, and servic-
es that are currently running or that have cached
processes, and how much RAM they are using. The
graph at the bottom of the Running tab shows the
total RAM in use and the amount free. At the top
right corner of the screen, tap Show cached processes or Show running services to switch back and
forth.
• All. Displays all apps that came with your tablet
and all apps that you have downloaded from apps
marketplaces.
To switch the order of the lists displayed in the Downloaded or All tabs, tap Menu > Sort by name or Sort by
size.
www.naxa.com Page 25
To view details about an app or other item listed under any tab, tap its name. The information and controls
available vary among different types of apps, but commonly include:
• Force stop button: Stops an app that is misbehav-
ing. Stopping an app, process, or service may cause
your device to stop working correctly. You may
need to restart your tablet after doing this.
• Uninstall button: Deletes the app and all of its data
and settings.
• Disable button: Prevents the app from running, but
does not uninstall it. This option is available for
some apps and services that can’t be uninstalled.
• Move to SD card/Move to Device: Change where the
application is installed. Applications will work best
when installed to internal (device) memory. Not all
apps can be moved to the SD card.
• Clear data button: Delete an app’s settings and
other data without removing the app itself.
• Clear cache: If the app stores data in a temporary
area of the tablet’s memory, lists how much infor-
mation is stored, and includes a button for deleting
the data.
• Launch by default: If you have congured an app to
launch certain le types by default, you can clear
that setting here.
• Permissions: Lists the kinds of information about
your tablet and data the app has access to.
A note about memory usage
You typically don’t need to worry about managing apps
beyond installing, opening, and using them. But there
may be times when you want to know more about
what’s happening behind the scenes.
Apps use two kinds of memory: internal storage and
RAM. They use internal storage for themselves and any
les, settings, and other data they use. They also use
RAM (memory designed for temporary storage and fast
access) when they’re running.
Your tablet manages and carefully guards the portion
of internal storage where the system, apps, and most
data for those apps are stored, because this area may
contain your private information. It’s not possible to
Page 26 Naxa Electronics
view this portion of internal storage when you connect
your device to a computer with a USB cable. The other
portion of internal storage, where music, downloaded
les, and so on are stored, remains visible for your convenience.
Your tablet also manages how apps use RAM. It may
cache some things you’ve been using recently, for
quicker access if you need them again, but it will erase
the cache if it needs the RAM for new activities. You affect the way apps use internal storage directly and indirectly in many ways; for example, by:
• Installing or uninstalling apps.
• Downloading les in Browser, mail, and other apps.
• Creating les (for example, by taking pictures).
• Deleting downloaded les or les you created.
• Copying les between your device and a computer
via USB.
You rarely need to manage the way apps use RAM. But
you can monitor RAM usage and stop them if they misbehave.
Users
If you share your tablet with other people, you can set
up different proles for each user. Each user can have
a prole with their own accounts, customized lock
screens, home screens, and other settings.
Set up your own user account rst, then hand the tablet over to another person. Allow them to set up their
own space.
What each user can do with the tablet will be nearly
the same. However, only the tablet’s owner can remove
any user completely, or uninstall other user’s apps.
(The rst user is automatically set to be the owner.)
To add a new user, you must be the owner.
• Tap on Add User in the upper right corner of the
screen. Follow the on-screen instructions to complete the process.
• Users may customize their own info from the Us-
ers settings screen. Users may change their picture,
their nickname, or add/change additional text to
describe the user.
www.naxa.com Page 27
To switch between users:
• The lock screen will display each user’s image and
nickname. Choose a user by tapping their image
and then unlock the screen.
• Slide provides no protection, but lets you get to the
Home screen quickly, or open the Camera app to
start taking pictures immediately.
• Pattern lets you draw a simple pattern with your
nger to unlock the tablet.
PERSONAL
Location access
Adjust the location services options of your tablet.
Security
Set screen lock: Depending how you use your tablet,
you may want to set some form of automatic screen
lock to prevent unauthorized access. If a screen lock
has been set, the screen locks when your tablet’s display goes to sleep. Select one of the screen lock types
from the list and then
• PIN requires four or more numbers. Hold the tablet
vertically, enter your pin, and then enter your pin
once more to conrm.
• Password requires four or more letters or numbers.
Hold the tablet vertically, enter your password, and
then enter your password once more to conrm.
This is the most secure option, as long as you create a strong password. For best security, specify a
password that is at least 8 characters long, contains a mixture of numbers, letters, and special
symbols, and doesn’t contain any recognizable
words or phrases.
Language and Input
follow the onscreen instructions to set the lock. The
screen lock types are listed in approximate order of
strength.
Page 28 Naxa Electronics
Adjust the Language and Input options of your tablet.
Backup & Reset
Adjust the Backup & reset options of your tablet.
ACCOUNTS
You can use multiple Google Accounts and Microsoft
Exchange ActiveSync accounts on your tablet.
You may also be able to add other kinds of accounts,
depending on your apps. Some you can add in the Accounts & Sync screen, as described here. Others you
add using an app that works with those kinds of accounts. For example, you can add IMAP and POP3 email
accounts with the Email app.
• Add Account: Tap Add Account, then choose the
type of account to add. Follow the onscreen instructions to enter information about the account.
To add some accounts, you may need to obtain details from system administrator about the service to
which the account connects. For example, you may
need to know the account’s domain or server address. Most accounts require a username and password, but the details depend on the kind of account
and the conguration of the service you’re connecting to. Depending on the kind of account, you may
be asked to congure what kinds of data you want
to sync, the name of the account, and other details.
When you’re nished, the account is added to the
list in Accounts & sync. Depending on how you congured the account, email, contacts, and other information will start syncing to your tablet.
• Remove an account: Tap the account type in the left
column, then tap the name of an account to select
it. Tap the Menu icon at the top right corner of the
screen and choose “Remove account”. Remove an
account to delete it and all information associated
with it from your tablet, including email, contacts,
settings, and so on.
• Manually sync an account: Tap the name of an ac-
count, then tap the Menu icon at the top right corner of the screen and choose “Sync Now”.
• Account sync options: Tap the name of an ac-
count to choose which types of data to sync. Some
apps, such as Gmail and Calendar, have separate
synchronization settings that provide more ne-
www.naxa.com Page 29
grained control. In such cases, the settings you select at the account level are still valid. For some accounts, syncing is bi-directional; changes that you
make to the information on your tablet are made
to the copy of that information on the web. Your
Google Account works this way. Other accounts
support only one-way sync: the information on
your mobile device is read-only.
SYSTEM
Adjust the System options of your tablet.
• Date & Time
• Accessibility
• Developer options
• About Tablet
Other Connections
Connect to a Computer via USB
You can use a USB cable to connect your tablet to a
computer in order to transfer music, pictures, and oth-
er les in both directions.
When you connect your tablet to the USB port on your
computer, the tablet will prompt you to turn on USB
storage.
• Tap Turn on USB storage to make your tablet’s
storage available to your computer. You can now
copy les back and forth as you would with any
other external storage drive.
• Tap Turn off USB storage to use your tablet nor-
mally while your computer charges the battery.
Related Settings
Settings > Device > Storage > Menu > USB computer
connection
Page 30 Naxa Electronics
Using HDMI Out
Connect the tablet to an external display (like a TV)
with a mini HDMI to HDMI cable (type A to type C).
Tuning Your Tablet’s Performance
Optimizing battery life
You can extend your battery’s life between charges by
turning off features that you don’t need. You can also
monitor how much power your apps and system resources are using.
To adjust the settings described here, rst tap the Settings icon on a Home screen or the All Apps screen.
To extend the life of your battery
• If you aren’t using Wi-Fi, use the Settings app to
turn it off.
• If you have a navigation app, map, or other app that
uses Location services, do not leave it open when
you are not using it.
• Lower the screen brightness level and set a shorter
Sleep timeout (Settings > Device > Display).
www.naxa.com Page 31
• If you don’t need it, turn off automatic syncing for
all apps (Settings > Personal > Accounts & sync).
Note that this means you need to sync manually to
collect messages, email, and other recent information, and you won’t receive notications when updates occur.
• If you know you won’t be near a Wi-Fi network for a
while, switch to Airplane mode. Press and hold the
power button until the Tablet options dialog appears, then tap Airplane Mode.
Check battery level and usage details
Tap Settings > Device > Battery.
• The charge status and charge level of the battery
are displayed at the top of the screen. The discharge graph shows battery level over time since
you last charged the device, and how long you’ve
been running on battery power.
• The list at the bottom of the screen shows detailed
battery usage information for individual apps and
services. Tap a graph for more details. The details
screen for some apps includes buttons that allow
you to adjust settings affecting power usage, or to
stop the app completely.
Some apps or services are required for
your tablet to work correctly. Do not stop
⚠
apps or services that you do not recognize.
Restart your tablet if it starts behaving
abnormally.
Page 32 Naxa Electronics
Troubleshooting
This guide lists common problems and their solutions.
Please refer to this guide before requesting service.
If you need further assistance, please contact Naxa
Technical Support (www.naxa.com/naxa_support/).
What if the device is abnormal during operation?
Answer:
1. Reboot the device to see if it works OK.
2. Charge the device by the charger to activate the
battery. Make sure it has power before you operate it.
3. It is suggested to upgrade the OS of the device by
professional.
Why the standby time is so short sometimes?
Answer: the use time of the battery is all depend on
the temperature and use instance. If the temperature
is too high or too low, the use time of the battery might
be effected. It is suggest using the device in normal
temperature. The using time is also affected by increased volume and frequently operation.
Why does my tablet feel hot?
Answer: The tablet can get quite hot if it is running
a complex application, the screen is set to the highest brightness level, or when it is being charged. This
is normal and should not cause the tablet to function
abnormally.
Why is my tablet not working properly?
Answer: Some apps on that you may install on your
tablet could cause it to behave abnormally. If this happens to you, reset the tablet and then remove the app
in question.
www.naxa.com Page 33
Warnings and Precautions
Important Safety Information
1. Read Instructions: All the safety and operating instructions should be
2. Retain Instructions: The safety and operating instruction should be
3. Heed Warnings: All warnings on the product and in the operating in-
4. Follow Instructions: All operating and usage instructions should be
5. Cleaning: Unplug this product from the wall outlet before cleaning.
The lightning ash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that
may be of signicant magnitude to constitute risk of electric
shock
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operation and servicing instructions in the literature accompanying the appliance.
CAUTION
• Do not block the ventilation openings or holes.
• Do not place any naked ames (such as lighted candles) on the ap-
paratus.
• When discarding batteries, follow all local rules and laws governing the
disposal of batteries. Consider the environmental impact of your actions!
• To prevent re or shock hazard, do not expose this appliance to rain
or moisture.
6. Attachments: Use only attachments recommended by the manufac-
7. Water and Moisture: Do not use this product near water (e.g., near a
8. Ventilation: Slots and openings in the cabinet are provided for ven-
9. Power Sources: This product should be operated only from the type of
read before the product is operated.
retained for future reference.
structions should be adhered to.
followed.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
turer. Use of other attachments may be hazardous.
bathtub, washbowl, kitchen sink, laundry tub, in wet basements, or
near a swimming pool and the like).
tilation to ensure reliable operation of the product and to protect it
from overheating. These openings should never be blocked by placing
the product on a bed, sofa, rug, or other similar surface. This product
should not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturer instructions have been adhered to.
power source indicated on the rating label. If you are not sure of the
type of power supply to your home, consult your product dealer or
Page 34 Naxa Electronics
local power company. For products intended to operate from battery
power or other sources, refer to the operating instructions.
10. Grounding or Polarization: This product may be equipped with a polarized alternating-current line plug that has one blade wider than
the other. This plug will only t into the power outlet in one direction.
This is a safety feature. If you are unable to insert the plug fully into
the outlet, try reversing the direction of the plug. If the plug should
still fail to t, contact an electrician to replace the obsolete outlet. Do
not defeat the safety purpose of the polarized plug.
11. Power-Cord Protection: Power supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon
or against them, paying particular attention to cords at plugs, convenience receptacles, and at the point which they exit from the product.
12. Protective Attachment Plug: The product may be equipped with an attachment plug with overload protection. This is a safety feature. See
the operating instructions for replacement or directions to reset the
protective device. If replacement of the plug is required, be sure the
service technician has used a replacement plug that has the same over-
load protection as the original plug as specied by the manufacturer.
13. Lightning: For added protection for this product, unplug it from the
wall outlet and disconnect the antenna or cable system during a
lightning storm or when it is left unattended and unused for long periods of time. This will prevent damage to the product due to lightning
or power-line surges.
14. Overloading: Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of re or electric shock.
15. Object and Liquid Entry: Never push objects of any kind into this product through openings as they may touch dangerous voltage points or
short-out parts that could result in a re or electric shock. Never spill
liquid of any kind on the product.
16. Servicing: Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualied service personnel.
17. Damage Requiring Service: Unplug this product from the wall outlet
and refer servicing to qualied service personnel under the following conditions: a) when the power-supply or plug is damaged; b) if
liquid has been spilled or if objects have fallen into the product; c) if
the product has been exposed to rain or water; d) if the product does
not operate normally by following the operating instructions. Adjust
only those controls that are covered by the operating instructions as
improper adjustment of other controls may result in damage and will
often require extensive work by a qualied technician to restore the
product to its normal operation; e) if the product has been dropped or
damaged in any way; f) when the product exhibits a distinct change in
performance—this indicates a need for service.
18. Replacement Parts: When replacement parts are required, be sure
that your service technician has used replacement parts specied
by the manufacturer or have the same characteristics as the original
part. Unauthorized substitutions may result in re, electric shock, or
other hazards.
19. Safety Check: Upon completion of any service or repairs to this
product,ask the service technician to perform safety checks to ensure
that the product is in proper operating condition.
20. Wall or Ceiling Mounting: The product should be mounted to a wall or
ceiling only as recommended by the manufacturer.
21. Heat: The product should be situated away from heat sources such as
radiators,heat registers, stoves, or other products (including ampli-
ers) that produce heat.
www.naxa.com Page 35
WARNING:
This product contains lead, a chemical known to the State of California to
cause cancer and birth defects or other reproductive harm. Wash hands
after handling.
CAUTION ON MODIFICATIONS
Any changes or modications not expressly approved by the grantee of
this device may void the authority granted by the FCC to operate the
equipment.
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Trademark & Regulatory Statements
Bluetooth® is a registered trademark of Bluetooth SIG, Inc. Other trademarks and names are those of their respective owners.
Page 36 Naxa Electronics
Specications
Screen Type 7.0” LCD touchscreen
Screen Resolution 800x480
Built-in Memory 8GB
Memory Card
Support
Wireless Radios Wi-Fi 802.11b/g/n
Operating System Android 4.4
Front Camera 0.3MP
Rear Camera 2MP*
Output HDMI (mini type C)
Computer Interface USB (micro type B)
Processor Cortex A7 1.3 GHz (quad core)
Graphics Processor Mali 400
Chipset Rockchip 3128
RAM 512 MB DDR3
microSD, microSDHC
Bluetooth® 2.1
3.5mm headphone
Power Source Rechargeable battery (2600 mAh)
AC 100-240V adapter
Battery Life** 4 hours
* Maximum interpolated resolution.
** Estimated time; battery life will vary depending on use conditions.
Note: Product are improved continuously. We reserve the right to modify
the product and specications without prior notice.
www.naxa.com Page 37
Support
If you have problems with your device, please consult
the instructions in this manual. Please also visit us
on the web at www.naxa.com to get up to the minute
news, alerts, and documentation for your device. For
additional assistance, please contact Naxa Technical
Support.
NAXA Technical Support
2320 East 49th St.
Vernon, CA 90058
http://www.naxa.com/naxa_support/
Page 38 Naxa Electronics
www.naxa.com Page 39
Loading...
