Instruction Manual
NAB-4001
Wireless Audio Adapter with Bluetooth® for
AUX Input Connectors
Page 2 Naxa Electronics
At a Glance
1 Pair status Indicator
2 Power Indicator
3 Power/Pair button
4 USB charge port
5 Line out jack
Press and hold the Power/Pair button to turn
the unit on or off.
www.naxa.com Page 3
Pair Status Indicator
Status Indicator
Searching Slowly ashing light
Pair mode Quick ashing light
Paired Steady light
Power Indicator
Status Indicator
Power off Light is off
Power on Steady green light
Low power Flashing green light
Charging Slowly ashing red light
Charging
Use the included micro USB cable to connect
the USB charge port [4] to the USB port of a
computer (or other USB charger).
The initial charge will take approximately 2.5
hours. Charge the unit fully before use.
Page 4 Naxa Electronics
Connecting
Use the included 3.5mm line cable to connect the Line out jack [5] to the line input jack of a speaker
system or other audio device. Then, press and hold the Power/Pair button [3] to turn the unit on.
Note: If the unit does not turn on, the battery level may be too low. Connect the USB
cable and charge the unit for at least 3 hours before trying again.
www.naxa.com Page 5
Pairing
Before using a wireless player with Bluetooth(r),
you will need to establish a connection between
it and your Naxa device. This process is called
“pairing” and you will only have to do it once.
Once two devices are paired, they will automatically connect when they detect each other.
Wireless players with Bluetooth may include
laptops, tablets, smartphones, and more. Make
sure that your player has its Bluetooth radio
enabled and that it is set to be discoverable.
1) Turn the unit on (press and hold the
Power/Pair button [3]).
2) When the NAB-4001 turns on, the Pair Sta-
tus indicator [1] will ash slowly (searching)
and then ash quickly (pairing).
• If the indicator does not ash
quickly, press the Power/Pair button
once to place the unit in Pair mode.
3) While the indicator is ashing quickly,
use the native controls of your Bluetooth
device to select the “NAB-4001”.
• If your device requires a password,
enter “0000”.
• Refer to the user’s manual of your de-
vice for specic instructions for pairing
and connecting Bluetooth devices.
Page 6 Naxa Electronics
Support
If you have problems with your device, please consult the instructions in this manual. Please
also visit us on the web at www.naxa.com to get up to the minute news, alerts, and documentation for your device. For additional assistance, please contact Naxa Technical Support.
NAXA Technical Support
2320 East 49th St.
Vernon, CA 90058
http://www.naxa.com/naxa_support/
www.naxa.com Page 7
Naxa Electronics
2320 E 49th St
Vernon, CA 90058
www.naxa.com
