Installation of Navitar/NuView Series 594 lens on
A Christie DS+60 projector.
TOOLS REQUIRED: None
Disassembly:
1. Disconnect unit from power source.
2. Remove the prime lens, if applicable, per the manufacturer instructions.
Assembly:
1. Remove the Navitar lens from lens adapter by gently rotating counter-clockwise and
set aside.
2. Insert the keyed portion of the lens adapter into the projector and rotate the lens
adapter clockwise.
3. Insert the lens into the lens adapter by gently turning clockwise.
4. To focus, gently twist the front of the lens. To zoom, loosen thumbscrew and twist
the knurled zoom ring and re-tighten the thumbscrew. CAUTION: When focusing,
be sure not to twist lens completely out of the adapter!
REV 03/13/06 REP
