The information contained herein may be changed at any time without prior
notification. This manual nor any parts thereof may not be reproduced for any
purpose whatsoever without the express written consent of
NAVIGON AG, nor
transmitted in any form either electronically or mechanically, including photocopying
and recording. All technical specifications, drawings etc are subject to copyright law.
11 Index ................................................................................................38
II Table of contents User’s manual
User’s manual NAVIGON 3100 | 3110
1 Introduction
1.1 About this manual
1.1.1 Conventions
For better legibility and clarification, the following styles are used in this
manual:
Bold and italics: Registered names, company and product descriptions.
S
MALL CAPITALS: Window and dialogue box titles.
Bold: Highlighting important parts in the text.
Underlined
the user interface.
1.1.2 Symbols
: Descriptions of buttons, input fields and other elements in
The following symbols refer to specific passages of text:
Instructions and tips for operating the software
Further detailed information and explanations
Warnings
1.2 Legal notice
1.2.1 Liability
The software and documentation are subject to change without notice.
NAVIGON AG is not liable for the accuracy of the information contained
in this manual or for damages resulting from the use of this manual.
To improve the quality of our products and our services, we appreciate
all suggestions for improvement and all error notices.
Introduction - 3 -
User’s manual NAVIGON 3100 | 3110
1.2.2 Trademarks
All brands and trademarks mentioned in this document are possibly
registered by third parties and are subject to the current legislation and
to the rights of their respective owners without reservation. All
mentioned names of products, societies, or brands may be registered
trademarks of their respective owners. Every right that is not explicitly
accorded is reserved.
The absence of an explicit labelling of registered trademarks does not
allow the conclusion that this brand was not subject to the rights of third
party.
▶ Windows and ActiveSync are trademarks of the Microsoft
Corporation.
▶ NAVIGON is a registered trademark of
1.3 Support
Our service team employees are available via telephone or Email in
many countries.
You can find additional information at the
www.navigon.com) in the "Service & Support" section.
(
Telephone Support
Note: All quoted costs refer to calls made from a landline within the
relevant country.
Germany
Telephone: 01805-6284466
Service times: Monday to Saturday from 8 to 20 hrs CET
Costs: 0.14 €/min.
Belgium
Telephone: 0900-70016
Service times: Monday to Friday from 8 to 20 hrs CET
Costs: 0.45 €/min. + 0.05 €/ per call
Denmark
Telephone: 901-31033
Service times: Monday to Friday from 8 to 20 hrs CET
Costs: 3.00 DKK/min.
NAVIGON AG.
NAVIGON AG Website under
- 4 - Introduction
User’s manual NAVIGON 3100 | 3110
Finland
Telephone: 0600-413414
Service times: Monday to Friday from 9 to 21 hrs
(local time)
Costs: 0.50 €/min.
France
Telephone: 0891-650065
Service times: Monday to Saturday from 8 to 20 hrs CET
Costs: 0.225 €/min.
Great Britain
Telephone: 0905-8480701
Service times: Monday to Friday from 7 to 19 hrs
(local time)
Costs: 0.25 GBP/min.
Italy
Telephone: 166-205301
Service times: Monday to Friday from 8 to 20 hrs CET
Costs: 0.40 €/min. + 0.09 €/ per call
Netherlands
Telephone: 0900-0400468
Service times: Monday to Friday from 8 to 20 hrs CET
Costs: 0.30 €/min. + 0.045 €/ per call
Norway
Telephone: 820-33050
Service times: Monday to Friday from 8 to 20 hrs CET
Costs: 3.26 NOK/min.
Austria
Telephone: 0820-240437
Service times: Monday to Friday from 8 to 20 hrs CET
Costs: 0.145 €/min.
Sweden
Telephone: 0900-1001110
Service times: Monday to Friday from 8 to 20 hrs CET
Costs: 4.00 SEK/min.
Introduction - 5 -
User’s manual NAVIGON 3100 | 3110
Switzerland
Telephone: 0848-662544
Service times: Monday to Friday from 8 to 20 hrs CET
Costs: 08 - 17 hrs: 0.11 CHF/min
Spain
Telephone: 807-001205
Service times: Monday to Friday from 8 to 20 hrs CET
Costs: 08 - 20 hrs: 0.356 €/min. + 0.104 €/ per call
Other countries
Telephone: +49-221-2888-999
Service times: Monday to Friday from 8 to 20 hrs CET
Costs: dependent on telephone provider
Note: The memory card must remain in the device during operation of
the navigation system.
2. Press the ON button for at least 6 seconds.
The installation will now be carried out.
- 6 - Before you begin
User’s manual NAVIGON 3100 | 3110
2.2 Navigation with GPS
GPS is based on a total of 24 satellites that circle the earth and, in
doing so, are constantly transmitting their position and the current time.
The GPS receiver receives this data and calculates its own
geographical position on the basis of the information broadcast by the
various satellites.
For a sufficiently precise positioning it is necessary to obtain the data
from at least three satellites. With the data from 4 or more satellites the
altitude above sea level can also be ascertained. The determination has
an accuracy of about 3 yards.
Once
MobileNavigator has determined your position, this position can
be used as a starting point for a route calculation.
The map data on your navigation device includes the geographical
coordinates of all digitally recorded points of interest, streets and
places. From this the server can calculate a route from any given
starting point to a destination.
The calculation of the current position and its representation on the map
takes place once every second. So your current position is always
shown on the map.
2.3 Important safety information
In your own interest, read the following notices and safety information
carefully before starting up your navigation system.
2.3.1 Navigation safety information
The usage of the navigation system is at your own risk.
Caution! To prevent accidents, do not program the navigation system
while driving.
Caution! Do not look at the display unless it is absolutely safe to do so!
Caution! Traffic regulations have priority over any instructions from the
navigation system.
Caution! Only follow the instructions of the navigation system when the
circumstances and the road traffic regulations allow doing so. The
navigation system will guide you to your destination even if you deviate
from your calculated route.
Before you begin - 7 -
User’s manual NAVIGON 3100 | 3110
Note: If you have not understood the instructions or your'e not sure
about what to do next you may refer briefly to the map or arrow view of
your navigation system.
2.3.2 Safety information on the installation in the vehicle
Caution! Make sure you do not attach the cradle for the mobile
telephone or for the GPS receiver in the danger zone of the airbag.
Caution! When installing the cradle, ensure that it does not represent a
risk in the event of an accident.
3 Operating the navigation software
3.1 Volume
The volume of the spoken driving instructions from MobileNavigator
can be adjusted during the navigation.
You have started a navigation. The map is in Navigation or
Destination search mode.
1. Tap the
Volume button.
The volume bar opens. It contains three buttons for adjusting the
volume.
Louder, Quieter, Volume on/off.
2. Tap the Volume
button again.
The volume bar closes.
3.2 Information
Symbols located at the top of the screen are used to display
information.
GPS
The GPS symbol can show the following GPS-reception status:
No GPS: The built-in GPS reciever is not operational. Consult customer
service if the problem persists.
- 8 - Operating the navigation software
User’s manual NAVIGON 3100 | 3110
No Signal: Data is being received from less than three satellites. The
position cannot be calculated.
GPS Ready: Data is being received from at least three satellites. The
position can be calculated.
Refer to chapter "
regarding the GPS status.
GPS status" on page 33 for detailed information
Energy
The Energy symbol can display the following states of the built—in
battery:
The device is being supplied by an external power source. The battery
is being charged.
The device is being supplied by its internal battery. The battery charge
is sufficient.
The device is being supplied by its internal battery. The battery charge
is low.
Direction
The Direction symbol shows you in which direction you are currently
moving. It can show the following points of the compass:
N, NE, E, SE, S, SW, W, NW.
TMC (Traffic Information)
If your device has an integrated TMC receiver, or if you have connected
an external TMC receiver, the navigation system will have the latest
traffic information available. If required, it can dynamically change your
route, e.g. avoid a traffic jam.
The TMC
No Symbol: There is no TMC receiver connected, or the connected or
installed TMC receiver is not working.
symbol can display the following TCM states:
Tuning: The TMC receiver is operational but cannot find a transmitter
that is sending TCM signals.
TMC on Standby: Traffic messages can be receiverd.
Operating the navigation software - 9 -
User’s manual NAVIGON 3100 | 3110
For details of the TMC functions please refer to chapter
"
TMC (Traffic Information)" on page 33.
3.3 Software keyboard
A software keyboard appears at the bottom of the screen when text
entries are necessary.
All entries can be made on the software keyboard using the fingertips.
Only capital letters can be entered.
When entering town or street names you must not enter any special
characters or umlauts. MobileNavigator replaces these characters
automatically. If, for example, you are searching for "Würzburg", then
simply enter "WURZBURG". You need not enter special characters
when entering a destination's town or street name but they may be
helpful for entering names for saved destinations and itineraries.
Special keys
enters a space character.
deletes the character to the left of the cursor.
opens the numeric keypad.
opens the character keyboard.
entered a special character the letter keyboard reappears.
opens the special character keyboard. As soon as you have
3.4 Lists
There are many cases where you have to select an entry from a list.
This is the case, for example, when you enter a location.
As soon as you enter the first letter, the largest city in the given country
that begins with this letter appears.
As soon as you enter the second letter, a list appears with all locations
that begin with the given letters.
If you enter additional letters, the list adapts to your entries. It only
contains entries that begin with the text that has been entered or
contain the text in the name. The more letters you enter, the shorter the
list will become.
- 10 - Operating the navigation software
You can move around in the list by means of the Up and
Down buttons.
Tap on an entry in the list to confirm it.
The list will close as soon as you have confirmed an entry.
3.5 Options
Some windows have options which lead to further functions.
User’s manual NAVIGON 3100 | 3110
For detailed information on the options, please refer to the "
chapter on page
25.
3.6 Menus
Some buttons have menus which open when activated.
Tap on a menu button to select its function.
If you would like to quit the options list without selecting an option, tap
on the button which you used to open the menu.
4 Navigation
Use navigation system at your own risk.
Caution! Please be sure to refer to the safety information in the
Important safety information" chapter on page 7.
"
Obstructed GPS reception
If GPS reception is hindered, navigation will be interrupted. The
navigation sofware remains open.
As soon as GPS reception is restored, the navigation system registers
any change of position since the last signal received. You may simply
continue navigation.
Arriving at your destination
When you have reached the specified destination, a message to this
effect will be displayed.
Only your current position (triangle in orange) will now be shown on the
map.
Options"
Navigation - 11 -
User’s manual NAVIGON 3100 | 3110
4.1 Starting MobileNavigator
1. Switch the navigation device on.
Each time you start the navigation software , the following message
will appear:
"Please note that the road traffic regulations are prior to the
instructions of the navigation system. Please do not operate the
device while driving."
2. After you have read and fully understood the text, tap on the OK
button.
3. If you do not wish to confirm this information then tap on the Cancel
button in order to quit the navigation software.
The M
AIN WINDOW opens. You can reach any of the navigation
software functions via the M
4.1.1 Initialising the GPS receiver
Note: It can take up to 20 minutes to initialise the GPS receiver for the
first time.
Each time you switch on the receiver after this, the GPS reception will
start within one minute.
If the navigation device has been switched off for more than a week, the
next initialisation can take up to 10 minutes.
As soon as the navigation device has been switched on, initialisation of
the GPS-receiver will begin.
In the right-hand top corner of the display, you will see the
As soon as data from at least 3 satellites is received, the symbol
AIN WINDOW.
GPS symbol.
changes to
Note: If the
GPS Ready.
GPS symbol displays GPS Ready after considerably less
than 20 minutes, then it is best to switch off the receiver for at least 15
minutes so as to guarantee reliable operation of the receiver.
Caution! If you have connected the navigation device to the power
supply using a cigarette lighter, remove the connector before you leave
the vehicle standing for a long period of time.
As the GPS receiver requires a constant power supply, it could run
down the vehicle´s battery.
Opening the Main window
The MAIN WINDOW opens when the navigation software starts.
- 12 - Navigation
User’s manual NAVIGON 3100 | 3110
If another window is open, tap the (Back) button. The previous
window will open.
Tap repeatedly on the
(Back) button until the MAIN WINDOW
opens.
4.2 Specifying a new destination
New destinations for MobileNavigator are all destinations that you
have not yet navigated, or you have not yet stored.
You can enter an address here, select a special destination, or select a
destination from the quick search function.
If you are entering a new destination for the first time, the C
COUNTRIES
Tap on the country, in which your destination lies.
4.2.1 Specify destination country
Above the right-hand upper corner of the uppermost entry field of the
window A
the Country
current navigation destinations can be entered.
If your destination is in a different country, then proceed as follows:
1. Tap on the Country
2. Tap on the country in which your destination lies.
Note: Only countries of which at least a part is represented on the
currently loaded map may be selected.
list opens.
DDRESS, POI IN A CITY, and POI OF NATIONAL SIGNIFICANCE, is
button. It shows the country code of the country from which
button.
The C
OVERED COUNTRIES list opens.
The C
OVERED COUNTRIES list closes again.
The symbol will display the country code of the destination country.
OVERED
4.2.2 Address of destination
1. In the MAIN WINDOW, tap on New Destination > Enter an Address.
The
ADDRESS window opens.
2. Enter the name of the town or the postcode.
3. Enter the name of the street. You can also enter the name of a wellknown building, e.g. "Olympic stadium" or "Eiffel tower".
Navigation - 13 -
User’s manual NAVIGON 3100 | 3110
4. Enter the number of the house. If you don't know the number of the
house, or you specified an object in the preceding step, then leave
the field empty.
If you don't know the house number, but know the name of a nearby
side street, then tap on the
the street. The navigation system will calculate a route to the
intersection of the streets you have specified.
Note: It is not necessary to enter all the address details.
If you specify the town only, the navigation system will calculate a route
to the town centre.
If you specify the town and street, without specifying a house number or
side street, the navigation system will calculate a route to the centre of
the street entered.
5. Tap on the Start Navigation button.
The map screen opens in Preview mode.
Note: For detailed information on how to start the navigation system,
please refer to chapter "
Starting navigation" on page 19.
4.2.3 Special destination
Special destinations, also known as to POIs (Points Of Interest) are
useful addresses that are catalogued according to particular criteria.
Ports, airports, restaurants, hotels, petrol stations, public buildings, and
others belong to the special destinations.
Points of interest can be displayed on the map by means of a symbol.
Tap on Options
which categories are to be displayed on the map.
> Settings > POI in the MAIN WINDOW in order to select
Cross Street field and enter the name of
Special destinations nearby
Special destinations nearby are special destinations that are located
within a particular radius of your current location. This means you can
always find, for example, the nearest petrol station, no matter where
you are.
Note: The GPS-reception must be sufficient for position determination.
You can see if GPS-reception is sufficient by looking at the
Ready) symbol. For further information, please refer to chapter
"
GPS status" on page 33.
- 14 - Navigation
(GPS
User’s manual NAVIGON 3100 | 3110
Note: In quick access mode, there are three categories of special
destinations available from the current vicinity, which can be searched
quickly and without additional entry. For detailed information, please
refer to chapter "
1. In the MAIN WINDOW, tap on New Destination >Search for POI >
Quick Access Points of Interest" on page 17.
Nearby.
The
POINEARBY window opens.
2. Tap a category from which you would like to select a Point of
Interest.
If sub-categories exist for the category you have selected, the Sub
Category list will open.
3. Tap a sub-category from which you would like to select a Point of
Interest.
The Name of the Destination
list opens. It contains the nearest
special destinations in the given category, sorted by distance.
4. Tap on the name of the destination.
5. Tap on the Start Navigation
button.
The map screen opens in Preview mode.
For detailed information on how to start the navigation system, please
refer to chapter "
Starting navigation" on page 19.
Nationwide Points of Interest
Nationwide Points of Interest are airports, places of interest, national
monuments, large ports etc. This enables you to find places of interest
without having to know the name of the location.This enables you to
find places of interest without having to know the name of the location.
1. In the M
2. Tap a category from which you would like to select a Point of
3. Tap on the name of the destination.
4. Tap on the Start Navigation
AIN WINDOW, tap on New Destination > Search for POI >
Nationwide
The POI
.
OF NATIONAL SIGNIFICANCE window opens.
Interest.
The Name of the Destination
list opens. It contains the nearest
special destinations in the specified category, sorted by distance.
button.
The map screen opens in Preview mode.
Navigation - 15 -
User’s manual NAVIGON 3100 | 3110
For detailed information on how to start the navigation system, please
refer to chapter "
Starting navigation" on page 19.
Point of Interest in a given location
Points of Interest in a given location can be useful when navigating in
an unfamiliar town.
1. In the M
2. Enter the name of the town or the postcode.
3. Tap a category from which you would like to select a Point of
4. Tap a sub-category from which you would like to select a Point of
5. Tap on the name of the destination.
6. Tap on the Start Navigation
For detailed information on how to start the navigation system, please
refer to chapter "
AIN WINDOW, tap on New Destination > Search for POI >
in a City.
The
POI IN A CITY window opens.
Interest.
If sub-categories exist for the category you have selected, the
Sub Category
list will open.
Interest.
The Name of the Destination
destinations from the specified category, sorted alphabetically.
The map screen opens in Preview mode.
Starting navigation" on page 19.
list opens. It contains the special
button.
4.2.4 Information about the destination
For many destinations that you specify, there will be further information
available stored in the navigation system's database.
For example, for many restaurants, there is a telephone number
available. You can then phone up in order to reserve a table, for
example.
One of the destination entry windows described is open.
Tap the
ESTINATION INFO window opens. It contains all information about
The D
the specified destination that is stored in the navigation system's
database.
- 16 - Navigation
(Destination Info) button.
▶ Tap on the (Show on Map) button, in order to show the
destination on the map.
▶ Tap the Cancel
button to close the DESTINATION INFO window.
4.2.5 Quick Access Points of Interest
The quick access system contains three categories of special
destinations. Destinations in your vicinity that correspond to these
categories can be listed quickly, without the need for additional entry.
In the M
AIN WINDOW, tap on Options > Settings > POI in order to set
which categories are available in the quick access system.
Note: The GPS reception must be sufficient for position determination.
User’s manual NAVIGON 3100 | 3110
You can see if GPS-reception is sufficient by looking at the
Ready) symbol. For detailed information, please refer to chapter "
status" on page
1. In the MAIN WINDOW, tap the New Destination button.
The
33.
NEW DESTINATION menu opens.
The symbols of the categories which have been selected for quick
access can be seen in the menu at the bottom.
2. Tap a category from which you would like to select a Point of
Interest.
The Name of the Destination
list opens. It contains the nearest
points of interest in the specified category, sorted by distance.
3. Tip on the name of the destination.
The map screen opens in Preview mode.
For detailed information on how to start the navigation system, please
refer to chapter "
Starting navigation" on page 19.
4.3 Select a stored destination
The following lists of destinations and addresses are available for
selection from
▶ L
AST DESTINATIONS: destinations that you have previously
navigated.
▶ F
AVOURITES: all destinations that you have stored in
MobileNavigator.
My Destinations in MobileNavigator.
(GPS
GPS
Navigation - 17 -
User’s manual NAVIGON 3100 | 3110
4.3.1 Last Destinations
MobileNavigator saves the last 30 destinations to which you have
navigated, in the L
1. In the M
2. Tap the destination to which you would like to navigate.
3. Tap the Start Navigation
The map screen opens in Preview mode.
For detailed information on how to start the navigation system, please
refer to chapter "
AST DESTINATIONS list.
AIN WINDOW, tap on My Destinations > Last Destinations.
Starting navigation" on page 19.
4.3.2 Favourites
Preferred destinations can be saved in the FAVOURITES list.
In the F
AVOURITES list, up to 300 destinations can be saved.
button.
Information on how to store a destination can be found in the "
destination" chapter on page
1. In the MAIN WINDOW, tap on My Destinations > Favourites.
20.
Saving a
2. Tap the destination to which you would like to navigate.
3. Tap Start Navigation
.
The map screen opens in Preview mode.
For detailed information on how to start the navigation system, please
refer to chapter "
Starting navigation" on page 19.
4.4 Navigation homewards
In MobileNavigator you can save your address as Home Address. You
can navigate to your Home Address by tapping a single button.
The first time you tap the Take Me Home
to enter your address.
Further information about entering your home address can be found in
chapter "
1. In the MAIN WINDOW, tap the Take Me Home button.
Define destination as home address" on page 20.
If you have not entered an address, a pop-up window will notify you.
The navigation starts. The route profile of the previous navigation
applies.
- 18 - Navigation
button, you will be requested
User’s manual NAVIGON 3100 | 3110
4.5 Determine the destination on the map
You may indicate a destination directly on the map. In addition to towns
and streets, you may also select special destinations quickly.
1. In the M
2. Tap the destination to which you would like to navigate.
Note: Please refer to chapter "
page
destination can easily be seen.
AIN WINDOW, tap on Options > Show Map.
The map screen opens in Destination search mode.
Map in Destination search mode" on
31 for information about how to change the map view so that your
The destination that you have selected appears under the cross
hairs.
The geographical coordinates of the destination and the
corresponding address is shown in the bottom third of the screen.
3. Tap the
ESTINATION ON MAP window opens. The detailed address data
The D
(OK) button.
of the selected destination are displayed in the left-hand upper
corner.
4. Tap Take Me There
.
The map screen opens in Preview mode.
For detailed information on how to start the navigation system, please
refer to chapter "
Starting navigation" on page 19.
4.6 Starting navigation
The map is open in Preview mode.
The navigation destination is depicted by a small flag. The route and the
estimated trip time is displayed.
A so called route profile forms the basis of the route calculation.
Tap the Route Profile
route profile.
Note: If you change the route options, any changes made also remain
valid for subsequent navigations.
You can get information regarding the individual route profile settings by
clicking on the corresponding
Navigation - 19 -
button if you don't want to view or change the
(Help) button.
User’s manual NAVIGON 3100 | 3110
▶ Tap the Start Navigation button or just start driving.
No GPS reception
When the received GPS signal is not sufficient, the following message
appears: "No GPS signal available at present. Would you like to use the
last known position?"
You have the following possibilities:
▶ Tap OK
▶ Tap Cancel
. The route will be calculated with the last known position as
starting point. As soon as the GPS reception is sufficient for position
determination, the route will be re-calculated and you can begin the
navigation.
. The MAIN WINDOW opens. The destination is now
saved to the
LAST DESTINATIONS list.
5 Destination management
Every destination that you enter and the destinations from the LAST
DESTINATIONS list may be added to the FAVOURITES list. This makes
sense if you frequently navigate to a respective destination.
5.1 Saving a destination
1. Enter a destination as described in "Specifying a new destination"
on page
2. Tap .Options
- OR –
1. Enter a destination as described in "LDo not tap the Start Navigation
2. Tap Options
3. Enter a name for the destination.
4. If you want to define the destination as your home address, tap on
13. Do not tap the Start Navigation button!
> Save Destination.
AST DESTINATIONS", page 18.
button!
> Save as Favourite.
the button
black.
5. Tap Save
(Toggle), so that the Yes value is highlighted in
.
5.2 Define destination as home address
You can define precisely one destination from the FAVOURITES list as
your home address.
- 20 - Destination management
User’s manual NAVIGON 3100 | 3110
You can then begin navigation to this destination very quickly by
tapping the Take Me Home
1. Select the destination which you want to define as your home
address from the F
2. Tap Options
The selected destination has now been saved as your home address.
Your home address now appears in the F
house symbol.
> Home Address.
button in the MAIN WINDOW.
AVOURITES list. (See "Favourites", page 18)
AVOURITES list together with a
6 Routes with various stages
You may plan itineraries without receiving GPS-signals, e.g.
comfortably at home. Planned itineraries may be stored. Thus you may
plan as many itineraries as you want, e.g. for holidays.
6.1 Itinerary
1. In the MAIN WINDOW, tap the Options button.
The options list opens.
2. Tap the Route Planning
The R
OUTE PLANNING window opens.
6.1.1 Enter the starting point
The starting point of a route is the point at which you want to begin your
trip. This must not necessarily be the current location. If you want to
plan a route for a trip on your holidays, you could, for example, enter
your hotel as the starting point.
The starting point is only important if you want to see a planned route
on the map, but currently have no GPS reception or you are not
currently at the planned starting point. The starting point that you enter
therefore has the flow number "0".
As soon as you begin a navigation, your current location will be used as
the basis for the route calculation.
The first stage is therefore the trip to the route stage with the flow
number "1".
1. Tap on the field Specify Starting Point
The S
TARTING POINT menu opens up.
If you want to enter your current location as the starting point:
2. Tap on the menu point Current Position
option.
.
.
Routes with various stages - 21 -
User’s manual NAVIGON 3100 | 3110
If you want to enter a different starting point:
2 Tap on the corresponding button.
3. Enter the starting point according to the relevant section in chapter
"
Navigation" on page 11.
4. Tap the button Set Starting Point
The selected starting point will now be shown next to button 0
(Starting Point).
Change the starting point
▶ Tap Specify Starting Point.
The S
TARTING POINT menu opens. You can now enter a different
starting point. Proceed as described above.
6.1.2 Enter route stages
Route stages are points within the route that you want to navigate to.
In front of every route stage is its flow number on a button.
1. Tap on the field Add Route Point
The R
OUTE POINT menu opens.
2. Tap on the button for the desired destination entry type.
3. Enter the route stage. (See the corresponding section of chapter
"
Navigation" on page 11).
4. Tap Add
Repeat this step for each additional destination that you want to add to
your route.
.
The selected route stage will now be shown next to its flow number.
.
.
6.1.3 Edit route stages
Route stages can be deleted from a route. The order of the route stages
can be varied as you wish.
Note: The start point (flow number "0") can neither be moved or
deleted.
▶ Tap on the route stage that you want to edit.
The context menu contains the following buttons:
Route Point Up: Moves the selected route stage forwards
(Example: route stage 2 becomes route stage 1)
- 22 - Routes with various stages
Route Point Down: Moves the selected route stage back.
(Example route stage 2 becomes route stage 3).
Delete: Deletes the selected route stage. A dialog window will
prompt you to confirm the deletion.
6.2 Managing routes
You can save each planned route under a particular name.
Note: Only the route starting points and the route stages will be saved,
not the calculated route. If you load a route, you will have to recalculate
it before navigation begins.
You can load, rename or delete stored routes.
6.2.1 Save route
The ROUTE PLANNING window is open. You have entered the starting
point and at least one route stage.
1. Tap on Options
2. Enter a name for the route.
3. Tap Save
The destination is now entered into the S
dialog window closes.
> Save Route.
.
User’s manual NAVIGON 3100 | 3110
AVED ROUTES list. The
6.2.2 Load route
1. Tap Options > Saved Routes.
2. Tap the route that you want to load.
3. Tap the Load Route
OUTE PLANNING window opens. The starting point and the
The R
button.
route stages of the loaded route are entered.
6.3 Navigation
The system first has to calculate the route. Afterwards, you can begin
the navigation or just simulate it.
6.3.1 Calculate and display the route
A route may be calculated and displayed on the map even without GPS
reception in order to get an impression on the itinerary.
Routes with various stages - 23 -
User’s manual NAVIGON 3100 | 3110
The ROUTE PLANNING window is open. The starting point and at least
one stage has been entered.
1. Tap the Show Route
The map screen opens in Preview mode.
The starting point and the route stages are marked by flags. For
each stage, the distance and the estimated trip time is given. These
data are also given for the entire trip.
6.3.2 Simulating the route
You can also just simulate a navigation.
Note: The reception of GPS-signals is not necessary for the simulation.
Simulation is restricted to routes of 60 mi max.
You have calculated and displayed a route.
2. Tap Options
> Simulation.
The route will be recalculated for simulation purposes. Simulation
starts when calculation has finished.
End simulation
You may stop a simulation at any moment.
button.
1. Tap the
(Back) button.
A dialog box will prompt you to confirm the navigation cancel.
Afterwards, the M
AIN WINDOW opens.
6.3.3 Starting navigation
You have calculated and displayed a route.
The calculation of a route is based on so called route options.
1. If you want to view or change these options, click on the
Route Profile
Note: If you change the route options, these remain valid for
subsequent navigations.
You can get information regarding changing individual route profiles by
tapping the corresponding
2. Tap the Start Navigation button or simply start driving.
- 24 - Routes with various stages
button.
Help buttons.
User’s manual NAVIGON 3100 | 3110
No GPS reception
When the received GPS signal is not sufficient, the following message
appears:
"No GPS signal available at present. Would you like to use the last
known position?"
You have the following possibilities:
▶ Tap OK
▶ Tap the Cancel
. The route will be calculated using the last known position
as the starting point. As soon as the GPS reception is sufficient for
determining the position, the route will be re-calculated and you can
begin the navigation.
now saved to the
button. The MAIN WINDOW opens. The destination is
LAST DESTINATIONS list.
7 Options
Some windows have options which lead to further functions.
▶ Tap on the
▶ Tap on the options you would like to implement.
▶ If you would like to quit the options list without selecting an option,
tap on the
Delete All
Save as Favourite
Show on Map
Settings: Opens the SETTINGS window. Here you can configure the navigation
Saved Routes
GPS status: Opens the GPS STATUS window. Here you can see details
: Deletes all destinations from the LAST DESTINATIONS list. The list is
then empty. A dialog box prompts you to confirm.
For detailed information, please refer to chapter "
on page
: Shows the given address on the map.
system.
For detailed information, please refer to chapter "
MobileNavigator" on page
: Opens a dialog window with which you can load a stored route.
regarding GPS reception. You can also save data regarding your
current location.
For detailed information, please refer to chapter "
page
33.
Options button to open the options list.
Options button again.
: Saves the given destination to the FAVOURITES list.
Saving a destination"
20.
Configuring
35.
GPS status" on
Options - 25 -
User’s manual NAVIGON 3100 | 3110
Home Address: Saves the selected destination your home address. You can
then begin navigation to this destination very quickly by tapping the
Take Me Home
Calibration
: Opens a window in which you can re-calibrate the touchscreen (re-
button in the MAIN WINDOW.
align), should it become imprecise to the touch.
Show Map
: The map screen opens in Destination search mode. Here you can
determine your navigation destination directly on the map.
For detailed information, please refer to "
the map" chapter page
Delete
: Deletes the selected destination from the FAVOURITES list. A dialog box
19.
Determine the destination on
prompts you to confirm.
New Route
: Deletes the starting point and all route stages from the ROUTE
PLANNING window, so that you can plan a new route.
If necessary, save the previously planned route!
Product Information
: Opens a window in which you can obtain information
regarding the installed software. You can also see the navigation
system's clock.
Save Route
: Opens a window in which you can save the planned route under a
particular name.
For detailed information, please refer to chapter "
page
23.
Route Planning
: Opens the ROUTE PLANNING window. Here you can plan
Save route" on
routes, administer planned routes and start navigating to a planned
route.
For detailed information, please refer to chapter "
stages" on page
Route Profile
: Opens the ROUTE PROFILE window. Here you can view the
21.
Routes with various
options for route planning and, if necessary, change them.
Simulation
: Simulates a navigation based on the displayed route. This
simulation can be undertaken without GPS reception. However,
simulation is restricted to routes of 60 mi max.
Traffic
: Opens the TRAFFIC INFORMATION window, in which pending reports can
be listed.
For detailed information, please refer to chapter "
Information)" on page
Rename
: Opens a window in which you can change the name for the selected
33.
TMC (Traffic
destination or route.
- 26 - Options
User’s manual NAVIGON 3100 | 3110
Factory Settings: Opens a window in which you can reset all settings to the
original factory settings.
Delete Destination
DESTINATIONS or FAVOURITES) lists. A dialog box prompts you to
confirm.
Save Destination
For detailed information, please refer to chapter "
on page
Add to Route
entered as the first route stage of a new route.
For detailed information, please refer to chapter "
stages" on page
: Seletes the marked destination from the (LAST
: Saves the given address in the FAVOURITES list.
Saving a destination"
20.
: Opens the route planning system. The address entered will be
Routes with various
21.
8 Working with the map
8.1 Maps
Even if you have stored numerous navigation maps on the navigation
system's memory card, MobileNavigator can only work with one map
at a time.
Tap on Options
currently being used. You can also select another map.
8.2 Map in Preview mode
You have entered a destination and tapped on the Start Navigation
button.
- OR –
You have planned or loaded a route and tapped the Show Route
button.
The map screen opens in Preview mode. You can see the entire route.
> Settings > Current Map, in order to see which map is
Working with the map - 27 -
User’s manual NAVIGON 3100 | 3110
1 The destination is marked with a little flag.
When you have planned or loaded a route and displayed it, the starting
points and each route stage will be marked with a little flag.
2 The route is marked in orange.
3 A triangle in orange shows the current position.
If you display a planned or loaded route and the given starting point is
not the same as your current location, then the current position may not
be shown on the preview.
4 You will see the entire route in a small info box, together with the
estimated trip time and the estimated time of arrival.
This information can be displayed or hidden by means of Options
> Basic Settings.
Settings
If you display a route with various stages, you will see this information
for each stage.
▶ Tap the Route Profile
button, in order to view or change the profile
on which the route calculation is based.
▶ Tap on the Start Navigation
button in order to begin the trip.
When you display a planned or loaded route, the route may be
recalculated. Your current location will be integrated into the
calculation. The navigation will initially guide you to the first route
stage entered.
>
▶ Tap on
(Destination search), in order to view the map in
Destination search mode.
(see "
Map in Destination search mode", page 31)
- 28 - Working with the map
User’s manual NAVIGON 3100 | 3110
8.3 Map in Navigation mode
After the route has been viewed in Preview mode, the navigation has
been started.
The map screen opens in Navigation mode.
1 Here is shown what signposts should be followed.
2 Possible speed limits may be shown here.
3 If two manoeuvres need to be executed quickly one after the other, the
small arrow field indicates the manoeuvre to be executed immediately
after the next manoeuvre.
4 The large arrow field shows a diagram of the next junction which you
should turn on to. Underneath is the distance to the next junction.
When you approach the junction, you will see a spot diagram instead of
the distance.
The nearer you are to the junction, the more yellow spots are displayed.
If you don't have to change direction for a longer period, you will only
see a forward-facing arrow with the distance shown underneath, which
shows how long you are to follow the current road.
5 The route is depicted in the colour
6 The height above sea level and the current speed is shown here.
Working with the map - 29 -
orange.
User’s manual NAVIGON 3100 | 3110
7 The remaining distance to the destination, the estimated duration of the
trip, and the estimated time of arrival can be seen in the Total field.
8 A
triangle in orange shows the current position on the map. The
displayed sector of the map changes continually to show your current
position centred on the map whenever possible.
9 If you are navigating a route with several stages, you will see the
remaining distance to the next interim destination, the estimated
duration of the trip, and the estimated time of arrival in the Next field.
10 The traffic lanes that lead to your destination are depicted in the colour
orange.
11 The name of the route section that you need to drive onto next is shown
in the upper street field.
12 The name of the street you are currently driving on is shown in the
lower street field.
Note: The displays for many of the above mentioned areas can be
configured via Options
displays only work when the corresponding information is available on
the map.
> Settings > Basic Settings. A number of
Note: If you tap on the large arrow field, then the current route
instruction will be repeated.
Tap the (Destination search) in order to view the map in
Destination search mode (See "
page
31).
Map in Destination search mode" on
Quit navigation
Tap (Back), in order to end the navigation. A dialog box prompts
you to confirm.
Map functions in Navigation mode
When the map is open in the Navigation mode, tap any point on the
map. Various buttons with options will be displayed.
2D/3D
: Changes between 2D and 3D mode. The symbol of the currently set
mode is shown in orange.
Day/Night
- 30 - Working with the map
: Changes the display mode between "day" and "night". The symbol of
the mode currently set is displayed in orange.
User’s manual NAVIGON 3100 | 3110
Interim Destination: Opens the menu for entering a way point.
The navigation will then guide you to this way point. Then you can
simply continue navigation to your original destination.
Skip Route Point
is inactive when less than 2 stages are pending.
Block
: Tap this button in order to block a stage, i.e. to recalculate the route to
avoid the stage, e.g. if you have heard of a traffic jam relating to this
section on the radio.
Tap on this button once, in order to remove the block.
POI on Your Route
route. This enables you to find out, for example, how long you need or
how far it is to the nearest services. You can also add a destination
: Tap this icon to omit the next stage from the list. This button
: Tap this button to display the special destinations on your
shown here as a way point by tapping
right, next to its entry in the list.
(Interim Destination) to the
8.4 Map in Destination search mode
The map is always in Destination search mode, when a pair of cross
hairs are to be seen.
When you are driving, the map does not change direction. It is always
oriented with north shown at the top.
Zoom Out: The map section shown becomes larger, but you will see
fewer details.
Working with the map - 31 -
User’s manual NAVIGON 3100 | 3110
Zoom In: The map section becomes smaller, but you will see more
details.
Zoom Mode: When this button is active, you can draw a map section
with the pen or your finger.
Draw the map section from upper left to bottom right. and it will then
zoom to fit the screen size.
Draw the map section from bottom right to top left, and the map will
zoom out.
Pan Mode: When this button is active, you can change the map section
with the pen or with your finger. Simply push the map in the desired
direction.
Entire Route: Zooms the map so that the entire route is visible.
Current Position: Selects the map section shown, so that the current
location is centred.
8.4.1 Working in Destination search mode
1. Tap on the point to which you wish to navigate.
The destination that you have selected appears under the cross
hairs.
The geographical coordinates of the destination and the
corresponding address is shown in the bottom third of the screen.
2. Tap the
(OK) button.
Buttons with various functions will appear:
Take Me There
: Begins the navigation to the selected point. If you are currently
in a navigation, it will be aborted.
Interim Destination
: Sets the selected point as way point. The navigation system
will then guide you to this way point first. Afterwards, you can simply
continue your original navigation.
This function is only active when you are currently in a navigation.
- 32 - Working with the map
User’s manual NAVIGON 3100 | 3110
Set as Destination: Adds the selected point as the last point in the route plan. If
no route plan has been opened, the selected point will become the first
point in a new route plan.
Save
: Opens the SAVE DESTINATION AS... window. You can enter a name,
under which the selected point will be stored in the F
For detailed information, please refer to chapter "
on page
Search Nearby
destinations near the selected point. See "
on page
20.
: Opens the POINEARBY window. Here you can search for
14).
Special destinations nearby",
AVOURITES list.
Saving a destination"
Tap
mode. You will be returned to the window from which you started this
mode.
Tap on
currently in a navigation, you will be prompted to confirm the quitting of
the navigation.
(Destination search), in order to quit Destination search
(Back), in order to return to the MAIN WINDOW. If you are
9 Useful functions
9.1 GPS status, store current location
On the GPS STATUS screen you will find an overview of the data the
navigation system calculates from the received GPS signals.
GPS status is available from the options of many windows.
1. Tap Options
The current location can be stored in the F
2. Tap on the Save Position
The S
in the Name
3. Enter a name for the destination.
4. Enter whether the current address should be stored as the home
address.
5. Tap the Save
9.2 TMC (Traffic Information)
If your device has an integrated TMC receiver, or if you have connected
an external TMC receiver, the navigation system will have the latest
traffic information available. If required, it can dynamically change your
route, e.g. avoid a traffic jam.
> GPS status.
AVOURITES list.
button.
AVE DESTINATION AS... window opens up. The cursor flashes
field.
button.
Useful functions - 33 -
User’s manual NAVIGON 3100 | 3110
The current valid traffic reports are available via the options of many
windows.
1. Tap Options
The T
> Traffic.
RAFFIC INFORMATION window opens.
Above the list, the Traffic information
traffic messaging is listed and the number of messages received.
2. Tap the Traffic information
should be displayed.
For each traffic message, information about the location and type of
congestion will be shown.
Tap a message to display detailed information.
button shows which kind of
button to select which traffic messages
The navigation system can Avoid
on the route. The Avoid / Ignore
Tap the button to select the alternative setting.
Tap the
(Back) button to close the window.
9.3 TMC Settings
▶ In the TRAFFIC INFORMATION window, tap on Options >
TMC Settings
In the TMC
sender, this will determine the effect reception of a message concerning
your route will have on it's calculation.
Tuning Mode
Tap the Tuning Mode
from which you want to receive traffic information.
▶ Automatically
another station. The system will search for another sender if
reception becomes poor.
▶ Hold station
another station. The system will search for the same sender on a
different frequency if the signal becomes poor.
▶ Hold frequency
another station. The system will not search for another sender if the
reception becomes poor.
.
SETTINGS window you can set and configure the TMC-
button to determine which sender should be set,
: Use the arrow keys of the Station section to receive
: Use the arrow keys of the Station section to receive
: Use the arrow keys of the Station section to receive
() or Ignore () congestion
button shows the corresponding status.
- 34 - Useful functions
Recalculate Route
Tap on Recalculate Route
your route should be dealt with.
▶ Automatically
: An alternative route avoiding the traffic obstruction
will be calculated.
▶ On request
: The message is displayed. In this window you can
determine whether or not an alternative route should be calculated.
9.4 Logbook
You can keep a logbook on MobileNavigator. The logbook is stored in
the "Logbook.xls" file. You can open the file with Microsoft® Excel®.
Every trip recorded is entered into the file as a new entry at the end of
the table.
The "Logbook.xls" file is created by in the Logbook program directory
the first time a log is recorded. If you delete it, a new file will be set up
the next time a record is made.
Note: the trips are also recorded simultaneously in an additional file,
which is compatible with WISO Sparbuch 2007. This file is called
"MN6DriversLog.bin
in the MobileNavigator program directory.
Note: When logbook recording is started, every movement of the
vehicle will be recorded, even if a navigation has not been started.
Begin recording
1. Tap on Options
2. Enter the required details.
3. Tap the Start
Stopping the recording
1. Tap on Options
2. Tap the Stop
Note: A dialog window opens when you reach the destination of a
navigation. Enter whether you want to end the logbook recording at this
point or not.
button.
button.
User’s manual NAVIGON 3100 | 3110
to determine how new messages concerning
". It can also be found in the Logbook directory and
> Logbook.
> Logbook.
Useful functions - 35 -
User’s manual NAVIGON 3100 | 3110
10 Configuring MobileNavigator
The SETTINGS window is the point from which you can start customising
MobileNavigator to match your personal preferences.
The settings can be reached from the options of many windows.
▶ Tap on Options
ETTINGS window has various buttons:
The S
Current Map
▶ Tap one button to open the corresponding settings window.
The settings of the individual windows are split over various screens.
> Settings.
, POI, Basic Settings and Route Profile.
You can toggle between them with the
(To the Right) buttons.
Some settings can only accept two or three different values. You can
recognise these settings by means of the
possible values are visible. The curent valid value is highlighted in
black.
▶ Tap the
Some settings can accept many different values.
These settings are recognisable by means of the
The current valid value is visible.
1. Tap the
A list with all possible values opens up. The current valid value is
marked.
2. Tap on the desired value. It will now be marked.
3. Tap on the OK
The list closes again. The new value will be displayed.
(Toggle) to alternate between the possible values.
(List) button.
button.
(To the Left) and
(Toggle) button. All
(List) button.
- 36 - Configuring MobileNavigator
User’s manual NAVIGON 3100 | 3110
For each setting there is a (Help) button. When you tap on it, you
will see a precise explanation of the corresponding setting.
You can close the settings windows in two ways:
▶ Tap the Done
button.
Any changes you have made will be stored.
▶ Tap the Cancel
button.
Any changes you have made will not be stored.
The S
