NAVIGON 20 EASY, 20 PLUS User Guide
NAVIGON 20 EASY
NAVIGON 20 PLUS
User's manual
English (United Kingdom)
June 2010
The crossed-out wheeled bin means that within the European Union
the product must be taken to separate collection at the product end-oflife. This applies to your device but also to any enhancements marked
with this symbol. Do not dispose of these products as unsorted
municipal waste.
Imprint
NAVIGON AG
Schottmüllerstraße 20A
D-20251 Hamburg
The information contained herein may be changed at any time without prior
notification. Neither this manual nor any parts thereof may be reproduced for any
purpose whatsoever without the express written consent of NAVIGON AG, nor may
they be transmitted in any form either electronically or mechanically, including
photocopying and recording. All technical specifications, drawings etc are subject to
copyright law.
© 2010, NAVIGON AG
All rights reserved.
User's manual NAVIGON 20 EASY | 20 PLUS
Table of contents
1 Introduction.......................................................................................6
1.1 About this manual ...................................................................................6
1.1.1 Conventions ..............................................................................6
1.1.2 Symbols ....................................................................................6
1.2 Legal notice.............................................................................................6
1.2.1 Liability ......................................................................................6
1.2.2 Trade marks..............................................................................7
1.3 Questions about the product...................................................................7
2 Before you begin...............................................................................7
2.1 Scope of Delivery....................................................................................7
2.2 Description of the navigation device .......................................................8
2.3 Important safety information....................................................................8
2.3.1 Navigation safety information....................................................9
2.3.2 Safety information for the navigation device .............................9
2.3.3 Safety guidelines when installing the device in your car......... 10
2.4 Preparing the navigation device for use................................................10
2.4.1 Installing the NAVIGON 20 EASY in the vehicle.....................11
2.4.2 Installing the NAVIGON 20 PLUS in the vehicle.....................12
2.4.3 Supplying power to the navigation device...............................13
2.4.4 Memory card ...........................................................................14
2.5 Navigating with GPS .............................................................................14
3 Switching on the navigation device..............................................15
3.1 Options..................................................................................................17
4 Operating the navigation system ..................................................17
4.1 Information ............................................................................................17
4.2 Software keyboard ................................................................................ 19
4.2.1 Special keys............................................................................19
4.2.2 Entering data...........................................................................20
4.3 Options..................................................................................................21
4.4 Menus ...................................................................................................21
5 Navigation .......................................................................................21
5.1 Starting the navigation application ........................................................22
5.2 Specifying a destination ........................................................................23
5.2.1 Specifying the country in which the destination is situated.....24
5.2.2 Entering a destination address ...............................................24
5.2.3 Enter Coordinates ...................................................................25
5.2.4 Points of interest .....................................................................27
User's manual Table of contents III
User's manual NAVIGON 20 EASY | 20 PLUS
5.2.5 Information about the destination............................................31
5.2.6 Favourites ...............................................................................31
5.2.7 Last Destinations ....................................................................32
5.2.8 Imported Addresses: Outlook / Internet ..................................32
5.2.9 Navigating home .....................................................................33
5.2.10 Selecting destinations on the map ..........................................33
5.2.11 Route preview .........................................................................34
5.3 Managing destinations ..........................................................................36
5.3.1 Saving destinations.................................................................36
5.3.2 Deleting a destination from the Favourites list ........................37
5.3.3 Defining the home address .....................................................37
5.3.4 Changing the home address...................................................38
5.4 Tracks and multi-leg routes...................................................................38
5.4.1 Entering the starting point .......................................................38
5.4.2 Entering route points...............................................................39
5.4.3 Editing route points .................................................................40
5.4.4 Managing routes .....................................................................40
5.4.5 Loading routes or tracks .........................................................40
5.4.6 Calculating and displaying routes ...........................................41
5.4.7 Simulating routes ....................................................................41
5.4.8 Route preview .........................................................................42
6 Options ............................................................................................44
7 Working with the map.....................................................................47
7.1 Selecting the navigation map................................................................47
7.2 Button bar..............................................................................................47
7.2.1 Static button bar......................................................................47
7.2.2 Dynamic button bar.................................................................48
7.3 Motion Sensor.......................................................................................49
7.3.1 Configuring the proximity sensor ............................................50
7.4 Map in Standard mode.......................................................................... 50
7.5 Map in Preview mode............................................................................51
7.6 Map in Navigation mode .......................................................................53
7.6.1 Navigation in Vehicle mode ....................................................53
7.6.2 Navigation in Pedestrian mode ...............................................57
7.6.3 Navigation in Track mode .......................................................59
7.6.4 Navigation in Offroad mode ....................................................59
7.6.5 Map options in Navigation mode.............................................60
7.6.6 Quitting navigation ..................................................................60
7.7 Map in Destination search mode...........................................................60
7.7.1 Operating in Destination search mode....................................61
8 Useful functions..............................................................................62
8.1 Route profiles........................................................................................62
IV Table of contents User's manual
User's manual NAVIGON 20 EASY | 20 PLUS
8.1.1 Route profile settings ..............................................................62
8.1.2 NAVIGON basic profiles .........................................................63
8.1.3 Creating a new route profile....................................................64
8.1.4 Selecting a route profile ..........................................................64
8.1.5 Managing route profiles ..........................................................64
8.2 MyPOIs .................................................................................................66
8.2.1 Creating your own destinations...............................................66
8.2.2 Symbols for your own POIs ....................................................67
8.2.3 POI-Import: Importing your own POIs onto the navigation
8.3 Screenshots ..........................................................................................67
8.3.1 Enabling screenshots..............................................................68
8.3.2 Creating a screenshot.............................................................68
8.4 Tracks ...................................................................................................68
8.5 Parking near the destination .................................................................69
8.6 Nearby...................................................................................................71
8.7 MyBest POI: POI on Your Route...........................................................71
8.7.1 Displaying POIs along the route .............................................72
8.7.2 Navigating to one of the destinations......................................73
8.7.3 Selecting categories................................................................73
8.8 NAVIGON Sightseeing..........................................................................74
8.9 Sightseeing Tours .................................................................................75
8.10 Direct Help ............................................................................................77
8.11 GPS Status, saving the current location ...............................................78
8.12 Block .....................................................................................................78
8.13 Turn-by-Turn List...................................................................................79
8.14 TMC (Traffic Information)......................................................................80
8.14.1 Preview TMC...........................................................................80
8.14.2 Displaying traffic information...................................................82
8.14.3 Showing a single message in detail........................................83
8.14.4 TMC Settings ..........................................................................84
device......................................................................................
67
9 Configuring the navigation system...............................................85
10 Appendix .........................................................................................87
10.1 Technical data.......................................................................................87
10.2 NAVIGON Licensing Policy...................................................................88
10.3 Declaration of conformity ......................................................................92
11 Troubleshooting..............................................................................92
12 Index ................................................................................................95
User's manual Table of contents V
User's manual NAVIGON 20 EASY | 20 PLUS
1 Introduction
1.1 About this manual
1.1.1 Conventions
For better legibility and clarification, the following styles are used in this
manual:
Bold and italics: Names of products
S
MALL CAPITALS: Names of windows and dialogue boxes
Bold: Highlighting of important parts in the text
Underlined
Underlined and italics
1.1.2 Symbols
: Descriptions of buttons, input boxes and other
elements on the user interface
: Names of control elements on the navigation
device
The following symbols refer to specific passages of text:
Instructions and tips for operating the software
More detailed information and explanations
Warnings
1.2 Legal notice
1.2.1 Liability
The software and manual are subject to change without notice.
NAVIGON AG is not liable for the accuracy of the information contained
in this manual or for damages resulting from the use of this manual.
Suggestions for improvements and information regarding errors are
always welcome so that we can supply you with even better products in
the future.
- 6 - Introduction
User's manual NAVIGON 20 EASY | 20 PLUS
1.2.2 Trade marks
All brand and trade marks mentioned in this document and registered
by third parties are subject without reservation to copyright law and the
proprietary rights of their respective owners. All trade marks, trade
names and company names used in this document are or may be trade
marks or registered trademarks of their respective owners. All rights
reserved except those explicitly granted.
If the registered trade marks used in this manual are not explicitly
identified as such, this does not imply that the name is not subject to the
rights of a third party.
► Microsoft, Outlook, Excel and Windows are registered trade marks
of the Microsoft Corporation.
► NAVIGON is a registered trade mark of NAVIGON AG.
1.3 Questions about the product
You have a question concerning your product? Then visit our website
www.navigon.com and click on "Customer Services". There you will find
an area with frequently asked questions (FAQ Center) along with details
of how to contact us by phone or e-mail.
2 Before you begin
2.1 Scope of Delivery
Please check that the contents are complete. If anything is missing, get
in touch immediately with the dealer who sold you the product.
The purchased product includes the following:
► Navigation device
► Car cradle:
► NAVIGON 20 EASY: Standard car cradle (in parts, refer to
"
Installing the NAVIGON 20 EASY in the vehicle", page 11)
► NAVIGON 20 PLUS: Designer car cradle (refer to "Installing the
NAVIGON 20 PLUS in the vehicle", page
► Car charger cable (10-24V adapter for the vehicle's cigarette lighter)
with integrated TMC antenna
► USB cable
► Carry-loop
► Illustrated installation instructions
Only NAVIGON 20 PLUS:
Some versions of the NAVIGON 20 PLUS also include a DVD with
the following contents:
12)
Before you begin - 7 -
User's manual NAVIGON 20 EASY | 20 PLUS
► Navigation maps
► Sound files for driving instructions
► Manuals as PDF files
► NAVIGON Fresh, with which you can keep your navigation
system up to date at all times and use additional services
► NAVIGON Sync, with which you can transfer contact
addresses from Microsoft Outlook to your navigation system
2.2 Description of the navigation device
1
Touch-screen
2
3
4
5
6
7
Ring for carry-loop
LED
Reset
Mini USB socket for USB cable / mains adapter
Slot for microSD memory card
On/Off
2.3 Important safety information
In your own interest, please read the following safety information and
warnings carefully before starting up your navigation system.
- 8 - Before you begin
User's manual NAVIGON 20 EASY | 20 PLUS
2.3.1 Navigation safety information
Use the navigation system at your own risk.
Caution! To prevent accidents, do not operate the navigation system
while driving.
Caution! Do not look at the display unless it is absolutely safe to do so!
Caution! Traffic regulations have priority over any instructions from the
navigation system.
Caution! Follow the instructions of the navigation system only when the
circumstances and the road traffic regulations allow you to do so! The
navigation system will still guide you to your destination even if you
deviate from the calculated route.
Caution! Check that the cradle is secured and adjusted properly before
each journey.
2.3.2 Safety information for the navigation device
Caution! Protect the device from moisture. The device is neither
waterproof nor protected against splash water.
Caution! Do not open the case of the navigation device under any
circumstances.
Caution! Do not expose the navigation device to extreme heat or cold.
This may damage the device or impair its function. (Refer to "
data" on page
Caution! Never unplug by pulling the cable. Doing so could severely
damage or destroy the device.
Caution! Do not subject the navigation device to severe temperature
fluctuations.
This can cause condensation to form.
Note: Do not kink the cable. Make sure that the cable cannot be
damaged by sharp-edged objects.
87.)
Technical
Before you begin - 9 -
User's manual NAVIGON 20 EASY | 20 PLUS
Note: Create a backup of the data which exist in the internal memory of
your navigation device.
This is very easy to do with the NAVIGON Fresh software which can be
downloaded free of charge from our website
the delivery package of your navigation system includes a DVD, you
can also install the NAVIGON Fresh software from this DVD.
www.navigon.com/fresh. If
2.3.3 Safety guidelines when installing the device in your car
Caution! Fasten the cradle so that the navigation device is easy to see
and operate by the driver. Make sure that the driver's view of the traffic
is not impeded.
Caution! Do not attach the cradle within the working zone of any
airbags.
Caution! Do not fasten the cradle too close to the steering wheel or
other controls. The driver must not be obstructed in operating any car
functions.
Caution! When installing the cradle, make sure that it will not pose a
risk in the event of an accident.
Caution! Do not run cables directly next to safety-relevant devices and
power supplies.
Caution! Check that the cradle is secured and adjusted properly before
each journey. The suction cup may become loose after a while.
Caution! After installation, check all safety-relevant equipment in the
car.
Caution! Connect the car charger cable only to cigarette lighters with
an operating voltage of 10-24V.
Caution! Disconnect the car charger cable from the cigarette lighter
whenever you park the car. The integrated mains adapter always
consumes a small amount of energy and could drain the car battery.
2.4 Preparing the navigation device for use
Caution! Be sure to refer to all the safety information in chapter
"
Important safety information" on page 8.
- 10 - Before you begin
User's manual NAVIGON 20 EASY | 20 PLUS
2.4.1 Installing the NAVIGON 20 EASY in the vehicle
Assembling the cradle
► Assemble the cradle as shown in the illustration. No tools are
needed for this.
Securing the cradle
1. Clean the suction cup and that part of the windscreen to which you
want to secure the cradle. Both must be dry and free of dirt and
grease.
2. Open the lever on the suction cup as far as possible.
3. Place the cradle suction cup against the windscreen.
4. Press the lever towards the windscreen.
Before you begin - 11 -
User's manual NAVIGON 20 EASY | 20 PLUS
Inserting the navigation device into the cradle
On the back of the navigation device you will see a circle with two
recesses.
1. Hang the navigation device by the upper recess on the upper lug of
the cradle. (See illustration)
2. Then press it towards the cradle so that it latches in place.
2.4.2 Installing the NAVIGON 20 PLUS in the vehicle
Securing the cradle
1. Clean the suction cup and that part of the windscreen to which you
want to secure the cradle. Both must be dry and free of dirt and
grease.
2. Open the lever on the suction cup as far as possible.
3. Place the cradle suction cup against the windscreen.
4. Press the lever towards the windscreen.
- 12 - Before you begin
User's manual NAVIGON 20 EASY | 20 PLUS
Inserting the navigation device into the cradle
On the back of the navigation device you will see a circle with two
recesses.
1. Hang the navigation device by the upper recess on the upper lug of
the cradle. (See illustration)
2. Then press it towards the cradle so that it latches in place.
2.4.3 Supplying power to the navigation device
Included in delivery of the navigation device is a car charger cable with
which power can be supplied to the navigation device via the vehicle's
cigarette lighter.
► Connect the car charger cable to the vehicle's cigarette lighter and
to the mini USB socket of the navigation device.
The LED on the bottom of the navigation device lights up orange during
charging.
As soon as the battery is fully charged, the LED lights up green.
Caution! Connect the car charger cable only to cigarette lighters with
an operating voltage of 10-24V.
Note: It takes approx. 3 hours to charge the device when the battery is
flat.
A fully charged battery enables up to 2 hours of use depending on the
device configuration.
TMC antenna
The navigation device has an integrated TMC receiver. The TMC
antenna is integrated in the car charger cable. Once the car charger
cable is connected, the device can receive current traffic messages. If
Before you begin - 13 -
User's manual NAVIGON 20 EASY | 20 PLUS
required, it can change your route dynamically, e.g. in order to avoid a
traffic jam.
2.4.4 Memory card
A memory card is not required to operate the navigation system
because all the data needed for navigation are stored in the internal
memory of the device.
When you connect the navigation system to your computer using a USB
cable, the internal memory is detected as the 'NAVIGON' drive. The slot
for the memory card is detected as the 'NAVIGON SD' drive.
Data backups, software updates and navigation map updates can be
carried out quickly and conveniently with the NAVIGON Fresh software,
which you can download free of charge from the website
www.navigon.com/fresh.
If you purchase additional navigation maps but no longer have enough
space for them in the internal memory of your navigation device, it is
also possible for you to save these maps on a memory card which you
then insert in the device. The navigation system can use navigation
maps from both memories.
Only NAVIGON 20 PLUS:
In the case of devices with a DVD included in the delivery package it is
not possible to save all the maps in the internal memory of the
navigation device. On the DVD you will find all the maps you have
purchased along with other items. To use the maps with your navigation
system, save them on a memory card. This can be done quickly and
conveniently with the NAVIGON Fresh software, which you can install
on your PC from the supplied DVD.
2.5 Navigating with GPS
GPS is based on a total of at least 24 satellites orbiting the Earth and
continuously transmitting signals of their position and time. The GPS
receiver receives this data and calculates its own geographical position
on the basis of the information transmitted by the various satellites.
Data from at least three satellites is required for positioning with an
acceptable degree of accuracy. With data from four or more satellites it
is possible in addition to determine the position's altitude above sea
level. Positioning is accurate to within three metres.
Once the navigation device has determined your position, this position
can be used as a starting point for calculating a route.
The map data on your navigation device includes the geographical
coordinates of all digitally recorded points of interest, streets and
places. This enables the device to calculate a route between a starting
point and a destination.
- 14 - Before you begin
User's manual NAVIGON 20 EASY | 20 PLUS
Calculation of the current position and its representation on the map
take place approximately once every second. In other words, your
current position is always shown on the map.
3 Switching on the navigation device
► Press the (On/Off) key and keep it pressed until the device
switches on.
AVIGATION window opens.
The N
Note: The display lights up briefly in white, indicating that you have
started the device.
When you switch on the navigation system for the first time, you will be
asked to make the following settings:
► your preferred language for using for the software
► the unit of length for distances
► the time format
► the date format
Note: When you start the navigation application for the first time, the
D
EMO MODE settings window opens.
Demo mode is intended only for demonstrating the product when no
GPS reception is possible.
When demo mode is active, navigation is not possible! Demo mode
is designed solely to simulate navigation to the centre of the
indicated destination.
► Make sure that the Start in Demo Mode setting is at No. If
necessary tap on the
the setting from Yes
► Tap on OK.
(Toggle) button in order to change
to No.
Note: How to deactivate demo mode is explained in "
in section "
Switching on the navigation device - 15 -
I have accidentally activated demo mode" on page 93.
Troubleshooting"
User's manual NAVIGON 20 EASY | 20 PLUS
Note: If you have not used the navigation device for a long time, the
battery may be flat.
When you connect the navigation device to the supplied car charger
cable, it can be switched on immediately even if the battery is flat. If you
use a different charger cable or have connected your device to a PC, it
may need charging for approx. 3 minutes before it can be switched on.
Chargers and other accessories are available in the NAVIGON online
shop at
www.navigon.com or in specialist stores.
Switching the navigation device to standby mode
► Press briefly on the (On/Off) key (max. 2 seconds).
A message will appear telling you that the device will be switched to
standby mode in several seconds.
► Wait for the device to be switched to standby mode or tap on
Automatic Standby
You can configure the navigation device so that it is automatically
switched to standby mode when not in use.
► In the NAVIGATION window tap on Options > Settings > General >
► Select after how much time you want the navigation device to be
► Select Power Loss in order to switch the device to standby mode
.
Standby
Automatic Standby
switched to standby mode (Never
After 30 mins.
.
, After 10 mins., After 20 mins.,
).
when the external power supply is interrupted. As soon as the
device is connected again to the external power supply it will switch
on again automatically.
Switching off the navigation device
1. Press briefly on the (On/Off) key (max. 2 seconds).
A message will appear telling you that the device will be switched to
standby mode in several seconds.
2. Tap on Off
- 16 - Switching on the navigation device
.
User's manual NAVIGON 20 EASY | 20 PLUS
Note: When you switch the navigation device to standby mode, the next
time it is switched on it will start very quickly and with the window which
was active when switched off. In standby mode the device still
consumes a small amount of energy however. Depending on how full
the battery is, it can become flat within a few days or a few weeks.
When you switch off the device, it consumes no energy. It can then take
several months for the battery to become flat. Switching the device on
again triggers a restart which can take some time (approx. 30 seconds).
Your settings and your saved destinations and routes will be retained.
3.1 Options
Some windows offer options that lead to more functions.
A description of all available options can be found in the chapter
Options" on page 44.
"
4 Operating the navigation system
4.1 Information
Various information symbols are located at the top of many windows.
GPS
The GPS symbol can show the following GPS reception status:
No GPS (No symbol): The built-in GPS receiver is not operational.
Contact us if the problem persists. (Refer to "
product" on page
7.)
Questions about the
No Signal: Data is being received from less than three satellites.
Position cannot be calculated.
GPS Ready: Data is being received from at least 3 satellites. Position
can be calculated.
For details of the GPS status refer to chapter "
current location" on page
78.
GPS Status, saving the
Compass
The Compass symbol indicates in which direction you are currently
heading. It can indicate the following points of the compass: N, NE, E,
SE, S, SW, W, NW.
Operating the navigation system - 17 -
User's manual NAVIGON 20 EASY | 20 PLUS
Track
The (Record Track) symbol indicates that a track is being recorded
at this moment.
For more information about tracks refer to chapter "
Tracks" on page 68.
TMC (Traffic Info)
The navigation system has an integrated TMC receiver which supplies
up-to-date traffic information. If necessary it can change your route
dynamically, for example in order to avoid a traffic jam.
Note: This function is only available if TMC traffic messages are being
transmitted in the country in which you are travelling. This is not the
case in all countries.
The TMC symbol can display the following TMC reception status:
Tuning (in red): The TMC receiver is operational but cannot find a
transmitter that is sending TCM signals. There are no active traffic
messages.
Tuning: The TMC receiver is operational but cannot find a station that
is transmitting TMC signals. Traffic messages are active however. This
can be the case, for example, when travelling through a tunnel.
TMC on Standby (in grey): Traffic messages can be receiverd.
Note: The TMC antenna is integrated in the car charger cable. The
Tuning symbol may still appear therefore when the car charger cable is
not connected to the navigation device.
For details of the TMC function refer to chapter "
Information)" on page
80.
TMC (Traffic
Energy
The Energy symbol can indicate the following states of the integrated
battery:
The device is being supplied by an external power source. The battery
is fully charged.
The battery cannot be charged because its temperature is too high or
too low.
The device is being supplied by an external power source. The battery
is being charged.
- 18 - Operating the navigation system
User's manual NAVIGON 20 EASY | 20 PLUS
The device is being supplied by its internal battery. The battery charge
is sufficient.
The device is being supplied by its internal battery. The battery charge
is low.
Muting
The Muting symbol can indicate the following states:
No symbol: The navigation application is not muted.
Muting: The navigation application is muted. If the device is navigating
at the moment, you will not hear any driving instructions.
4.2 Software keyboard
A software keyboard appears on the screen when text entries are
necessary.
All entries can be made on the software keyboard using your fingertips.
Only capital letters can be entered.
When entering town or street names you need not enter any special
characters or umlauts. The navigation system fills in these characters
for you automatically. For example, if you are looking for the town of
"Bärnau", then simply type in the word "Barnau". Special characters
may be helpful however when naming saved destinations and routes.
4.2.1 Special keys
inserts a space.
deletes the character in front of the cursor.
opens the keyboard with numerals.
Latin, Cyrillic and Greek alphabet
opens the keyboard with the Latin alphabet.
opens the keyboard with the Cyrillic alphabet.
opens the keyboard with the Greek alphabet.
When you want to enter addresses, names or POIs, the keyboard with
the alphabet for the country in question will open automatically.
When you want to save a destination to Favourites or when you enter a
POI category or a country, the keyboard with the alphabet of the user
interface will open automatically.
Operating the navigation system - 19 -
User's manual NAVIGON 20 EASY | 20 PLUS
You can also switch from the Cyrillic or Greek keyboard to the Latin
keyboard. Many addresses can then also be entered as transliterations
or in the language of the user interface.
Example: The language of the user interface is English. You want to
navigate to Moscow. You have the following options:
► "Москва" (Cyrillic)
► "Moskva" (transliterated)
► "Moscow" (English).
Note: Street names and place names can be entered only in the
language of the user interface if that is how they exist in the map's
database.
Note: The maximum number of keyboards is always 2.
Umlauts, accents and other letters
Another keyboard with special characters is available for each alphabet.
opens the keyboard with Latin special characters.
opens the keyboard with Cyrillic special characters.
opens the keyboard with Greek special characters.
As soon as you have entered a special character the letter keyboard
reappears.
4.2.2 Entering data
Often you can select an entry from a list. This is the case, for example,
when you enter a location.
As soon as you enter the first letter, the largest city in the given country
that begins with this letter appears.
Enter more letters and after each entry the first city which begins with
these letters will appear.
► When the correct location appears, tap on (OK) in order to
complete the entry.
You can open at any time a list containing all the locations which begin
with the letters or include the text already entered. The more letters you
enter, the shorter the list becomes.
- 20 - Operating the navigation system
User's manual NAVIGON 20 EASY | 20 PLUS
► Tap on (Open List) in order to call up this list.
You can use the
(Up) button and the (Down) button to
move through the list.
► Tap on an entry in the list to select it and transfer it to the input box.
The list closes once an entry has been selected. You are now
finished with entering the city.
► Tap on (Close List) in order to close the list without selecting
an entry.
Note: The list opens automatically as soon as it contains only 4 or less
entries.
4.3 Options
Some windows offer options that lead to more functions.
A description of all available options can be found in the chapter
Options" on page 44.
"
4.4 Menus
Some buttons have menus which open when activated.
► Tap on a menu point to execute its function.
If you would like to quit the options list without selecting a function, tap
on the button you used to open the menu.
5 Navigation
Use the navigation system at your own risk.
Caution! Be sure to refer to all the safety information in chapter
"
Important safety information" on page 8.
Impaired GPS reception
If GPS reception is impaired (e.g. because you are in a tunnel),
navigation will be continued. The navigation system will then calculate
your likely position from the route data and your previous driving profile.
As soon as GPS signals are received again, navigation will be
continued with real GPS data.
Navigation - 21 -
User's manual NAVIGON 20 EASY | 20 PLUS
Arriving at your destination
When you have reached your selected destination, a message to this
effect will be displayed.
Only your current position (orange arrow) and the destination flag will
now be shown on the map.
5.1 Starting the navigation application
You have switched on the navigation device.
The following message appears:
"Please note that the road traffic regulations are prior to the instructions
of the navigation system. Please do not operate the device while
driving."
► After you have read and fully understood the message, tap on OK.
If you do not accept the content of the message, tap on Cancel
order to exit the navigation application.
The N
AVIGATION window is opened. From here you can access all the
functions of the navigation application.
Initialising the GPS receiver
Note: Good reception of GPS data requires an unobstructed path from
the GPS receiver to the satellites. Tunnels, narrow thoroughfares
between buildings and reflecting house fronts can restrict GPS
reception greatly or make it impossible. If the GPS receiver or the
navigation device is inside a vehicle, a metallised windscreen or a
windscreen heater can be the cause of poor GPS reception.
As soon as the navigation device has been switched on, initialisation of
the GPS receiver will begin.
The integrated GPS receiver is not initialised for the first time until the
navigation application is started for the first time. It can take up to
5 minutes to initialise the GPS receiver for the first time.
Each time you switch on the navigation device after this, GPS reception
will start within a short time.
If the navigation device has not been switched on for more than a week,
it can take up to 5 minutes to re-initialise the receiver.
in
Note: Directly after the GPS
the accuracy of the positioning may be reduced for a few minutes.
In the top right hand corner of the display, you will see the GPS symbol.
symbol indicates the GPS Ready state,
As soon as data from at least three satellites is received, the symbol will
change to
- 22 - Navigation
(GPS Ready).
User's manual NAVIGON 20 EASY | 20 PLUS
Note: Initialisation takes the least time if you do not start driving until
the initialisation has finished.
For more details about the GPS
17.
page
symbol refer to chapter "GPS" on
Returning to the Navigation window
The NAVIGATION window opens when the navigation application is
started.
If another window of the navigation application is open, tap on
(Back). This will return you to the window you came from.
► Tap on (Back) repeatedly until the NAVIGATION window is
opened.
5.2 Specifying a destination
Under New Destination you can enter destinations to which you have
not yet navigated or which you have not saved. Here you can
► enter the address of the destination (refer to "Entering a destination
address " on page
► enter the coordinates of the destination (refer to "Enter Coordinates"
on page
► select a point of interest (refer to "Points of interest" on page 27.)
► select a destination with the Direct Access function (refer to "Direct
25).
access to POI" on page
24).
30).
Note: The first time that you want to enter a new destination you will be
asked to select the country in which your destination is situated.
Under My Destinations you can select from the following lists of
destinations and addresses:
► FAVOURITES: All destinations that you have entered and then saved
(refer to "
Three special destinations are also saved in the F
► My Address: The address which was saved as the home
► My Vehicle: The location of your vehicle is automatically saved
Favourites" on page 31).
address (refer to"
Defining the home address" on page 37).
AVOURITES list:
when you use the Parking Close to Destination function (refer
to "
Parking near the destination" on page 69).
► My Starting Point: The starting point of the last navigation is
automatically saved.
Navigation - 23 -
User's manual NAVIGON 20 EASY | 20 PLUS
► LAST DESTINATIONS: Destinations to which you have navigated on a
previous occasion (refer to "
► IMPORTED ADDRESSES: All destinations that you have imported from
Microsoft Outlook or from other data sources (refer to "
Addresses: Outlook / Internet" on page
Last Destinations" on page 32).
Imported
32).
5.2.1 Specifying the country in which the destination is situated
At top left in the ADDRESS, POI IN A CITY and POI NATIONWIDE windows
you will find the Country
you can currently select destinations for the navigation application.
If your destination is in a different country, then proceed as follows:
1. Tap on the Country
2. Enter the name of the country in which your destination is situated.
The button shows the flag of the destination country.
Note: The selection list contains only those countries whose maps are
available to the navigation device.
button. It bears the flag of the country in which
button.
5.2.2 Entering a destination address
1. In the NAVIGATION window, tap on New Destination > Enter an
Address.
Note: The following description is based on City First
entering the address.
If the navigation device contains the map of a country in which the
street is usually listed first (e.g. Sweden, Norway, ...), you can also
choose Street First
You can define the order in the N
> General > Input Mode for Address Data.
Settings
Please note however that the Street First
for all countries. In this case you must enter the city first.
The ADDRESS window opens.
as the order for entering the destination address.
AVIGATION window at Options >
order of entry is not possible
2. Enter the name or the postal code of the destination town.
3. Enter the name of the destination street.
4. Enter the house number. If you do not know the house number,
then leave this box empty.
If you don't know the house number but know the name of a nearby
side street, then tap on the Cross Street
box and enter the name of
this street. The navigation system will calculate a route to the
intersection of the streets you have entered.
The D
ETAILED INFORMATION ABOUT THE DESTINATION window opens.
as the order for
- 24 - Navigation
User's manual NAVIGON 20 EASY | 20 PLUS
Indicated on the Activate MyRoutes button is whether several route
suggestions are to be calculated (Yes
► Tap on Activate MyRoutes in order to change the setting.
Note: The Activate MyRoutes
button is available only when you have
) or not (No).
entered all the address information. You can also make this setting
under Options
5. Tap on Navigation in order to navigate to the stipulated address.
> Settings > Navigation > Activate MyRoutes.
- or Tap on Parking
in order to search for and navigate to a car park
near your destination.
Sometimes the destination cannot be found exactly because, for
example, the entered combination of place and street name exists
several times.
In this case a window will open with a list of all the addresses
matching your entry plus additional information.
► Tap on the address to which you want to navigate.
If the entered house number is not included on the map, the window
will show an address with the house number closest to the one
entered.
The map opens in Preview mode. The destination is indicated on
the map.
For detailed information on how to start navigation, please refer to
chapter "
Route preview" on page 34. Please read on there.
Note: It is not necessary to enter all the address details. You can tap on
(Navigation) before you get that far.
If you specify the town only, the navigation system will calculate a route
to the town centre.
If you specify only the town and street without specifying a house
number or cross street, the navigation system will calculate the best
route to this street.
5.2.3 Enter Coordinates
You can also enter the geographic coordinates of your destination. The
coordinates can be entered as decimal degrees or in degrees, minutes
and seconds.
1. In the N
Navigation - 25 -
AVIGATION window, tap on New Destination > Enter
Coordinates.
NTER COORDINATES window opens.
The E
User's manual NAVIGON 20 EASY | 20 PLUS
Entering as a decimal number
2. Enter the degree of latitude.
Begin the entry with a minus sign if you want to enter a southern
degree of latitude.
3. Enter the degree of longitude.
Begin the entry with a minus sign if you want to enter a western
degree of longitude.
Entering with minutes / seconds
2. Enter the degree of latitude.
Use the corresponding buttons shown on the keyboard in order to
enter the units:
(degrees), (minutes), (seconds).
The (N S) button alongside the entry box indicates whether it is a
northern or southern degree of latitude.
► Tap on the button if you want to change the current setting.
3. Enter the degree of longitude.
Use the corresponding buttons shown on the keyboard in order to
enter the units:
(degrees), (minutes), (seconds).
The (E W) button alongside the entry box indicates whether it is an
eastern or western degree of longitude.
► Tap on the button if you want to change the current setting.
The D
ETAILED INFORMATION ABOUT THE DESTINATION window opens.
Indicated on the Activate MyRoutes
suggestions are to be calculated (Yes
► Tap on Activate MyRoutes in order to change the setting.
4. Tap on Navigation
in order to navigate to the stipulated address.
- or Tap on Parking
in order to search for and navigate to a car park
near your destination.
Note: If the destination with the coordinates you entered does not lie on
the road system covered by the map, navigation will be performed as
far as the nearest road point using the mode defined by the selected
route profile. From this point on, the navigation system will automatically
switch to Offroad mode. (Refer to "
page
59.)
button is whether several route
) or not (No).
Navigation in Offroad mode" on
- 26 - Navigation
5.2.4 Points of interest
Points of Interest, called POI for short, are useful addresses that are
catalogued according to particular criteria.
POIs include ports, airports, restaurants, hotels, petrol stations, public
buildings, doctor's surgeries, hospitals, shopping centres, etc.
Points of interest can be displayed on the map by means of a symbol.
In the N
AVIGATION window tap on Options > Settings > Map Display >
Categories Shown
in order to select the categories you want to appear
on the map.
Note: If you have created your own POIs, they will be available under
the MyPOIs category. For more details about creating your own POIs
refer to chapter "
MyPOIs" on page 66.
POI nearby
POIs nearby are POIs located within a certain radius of your current
location. This means you can always find the nearest petrol station for
example, no matter where you are.
Note: GPS reception must be good enough for determining your
position. Check the
reception is good enough.
If GPS reception is not good enough, the system will look for POIs near
the last known position. If there is no last known position, the POI
Nearby function will not be available.
For more details refer to the chapter "
page
22.
Note: The direct access function offers 3 categories of nearby POIs
which can be searched for quickly and without additional entry.
For more details refer to the chapter "
1. in the NAVIGATION window tap on New Destination > Search for
POI > Nearby.
The POI
NEARBY window opens.
2. Select a category from which you would like to find a POI.
Categories in which no destinations are available nearby cannot be
selected.
If sub-categories exist for the category you have selected, the Sub
Category list opens.
3. Select the sub-category from which you would like to select a POI.
The Destination
specified category, sorted by distance.
User's manual NAVIGON 20 EASY | 20 PLUS
(GPS Ready) symbol to see whether GPS
Initialising the GPS receiver" on
Direct access to POI" on page 30.
list opens. It contains the nearest POIs in the
Navigation - 27 -
User's manual NAVIGON 20 EASY | 20 PLUS
4. If the list is very long:
► Tap on (Close List).
The keyboard appears.
► Enter a number of letters from the destination.
► Tap on (Open List).
The list now contains only those destinations which begin with the
letters entered.
5. Tap on the name of the destination.
The D
ETAILED INFORMATION ABOUT THE DESTINATION window opens.
Indicated on the Activate MyRoutes
suggestions are to be calculated (Yes
► Tap on Activate MyRoutes in order to change the setting.
6. Tap on Navigation
.
- or Tap on Parking
in order to search for and navigate to a car park
near your destination.
The map opens in Preview mode. The destination is indicated on
the map.
button is whether several route
) or not (No).
For detailed information on how to start navigation, please refer to
chapter "
Route preview" on page 34. Please read on there.
POI of nationwide significance
POIs of nationwide significance are airports, sights, national
monuments, large ports etc. This way you can find well-known places of
interest even if you don't know the name of their location.
1. In the N
2. Select a category from which you would like to find a POI.
3. If the list is very long:
- 28 - Navigation
AVIGATION window tap on New Destination > Search for
POI > Nationwide.
The POI
NATIONWIDE window opens.
The Destination
list opens. It contains the POI from the selected
category, sorted alphabetically.
► Tap on (Close List).
The keyboard appears.
► Enter a number of letters from the destination.
► Tap on (Open List).
User's manual NAVIGON 20 EASY | 20 PLUS
The list now contains only those destinations which begin with or
contain the letters entered.
4. Tap on the name of the destination.
The D
ETAILED INFORMATION ABOUT THE DESTINATION window opens.
Indicated on the Activate MyRoutes
suggestions are to be calculated (Yes
► Tap on Activate MyRoutes in order to change the setting.
5. Tap on Navigation
.
button is whether several route
) or not (No).
- or Tap on Parking
in order to search for and navigate to a car park
near your destination.
The map opens in Preview mode. The destination is indicated on
the map.
For detailed information on how to start navigation, please refer to
chapter "
Route preview" on page 34. Please read on there.
POI in a particular location
POIs in a particular location can be useful when navigating in an
unfamiliar town.
1. In the N
2. Enter the name or the postal code of the destination town.
3. Select a category from which you would like to find a POI.
4. Select the sub-category from which you would like to select a POI.
5. If the list is very long:
AVIGATION window tap on New Destination > Search for
POI > in a City.
The POI
IN A CITY window opens.
Categories in which no destinations are available in the selected
town cannot be entered.
If sub-categories exist for the category you have selected, the Sub
Category list opens.
The Destination
list opens. It contains POI from the specified
category, sorted alphabetically.
► Tap on (Close List).
The keyboard appears.
► Enter a number of letters from the destination.
► Tap on (Open List).
The list now contains only those destinations which begin with or
contain the letters entered.
Navigation - 29 -
User's manual NAVIGON 20 EASY | 20 PLUS
6. Tap on the name of the destination.
The D
ETAILED INFORMATION ABOUT THE DESTINATION window opens.
Indicated on the Activate MyRoutes
suggestions are to be calculated (Yes
► Tap on Activate MyRoutes in order to change the setting.
Sometimes the destination cannot be found exactly because, for
example, several restaurants with the same name exist in the town
in question.
In this case a window opens with all the destinations matching your
entry plus additional information.
► Tap on the destination to which you want to navigate.
7. Tap on Navigation
.
- or Tap on Parking
in order to search for and navigate to a car park
near your destination.
The map opens in Preview mode. The destination is indicated on
the map.
button is whether several route
) or not (No).
For detailed information on how to start navigation, please refer to
chapter "
Route preview" on page 34. Please read on there.
Direct access to POI
The direct access area contains 3 categories of POI. Destinations in
your vicinity that correspond to one of these categories can be viewed
here quickly and without further entry.
► In the NAVIGATION window tap on Options > Settings > General in
order to select which categories or sub-categories are to be
available for direct access.
Note: GPS reception must be good enough for determining your
position. Check the
reception is good enough.
If GPS reception is not good enough, the system will look for POIs near
the last known position. If there is no last known position, the Direct
Access function will not be available.
For more details refer to the chapter "
page
22.
1. In the NAVIGATION window tap on New Destination.
The N
EW DESTINATION menu opens.
In the Direct Access
categories that are available by direct access.
- 30 - Navigation
(GPS Ready) symbol to see whether GPS
Initialising the GPS receiver" on
area you are shown the symbols of those POI
Loading...
