Navigon 2000S User Manual

For use with models:

NAVIGON 2000S
NAVIGON 2090S
NAVIGON 2200T

NAVIGON 2000S | 2200T Series

User’s Guide

English (US)

September 2008

Imprint

NAVIGON, INC
200 W Madison Street
Suite 650
Chicago, IL 60606

The information contained herein may be changed at any time
without prior notification. This manual nor any parts thereof
may not be reproduced for any purpose whatsoever without the
express written consent of NAVIGON, INC, nor transmitted in
any form either electronically or mechanically, including photo­copying and recording. All technical specifications, drawings,
etc., are subject to copyright law.

© 2008, NAVIGON, INC
All rights reserved.

ii NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

End User License Agreement (EULA)

(SINGLE USE LICENSE)

PLEASE READ THE FOLLOWING SOFTWARE LICENSE (THE “LICENSE”) BEFORE USING
YOUR NAVIGON PRODUCT. BY USING YOUR NAVIGON PRODUCT, YOU ARE AGREEING
TO BE BOUND BY THE TERMS OF THIS LICENSE. IF YOU DO NOT AGREE WITH THEM,
OR DO NOT WANT THEM TO BE BINDING ON YOU, YOU SHOULD PROMPTLY RETURN
THE NAVIGON PRODUCT TO THE PLACE WHERE YOU OBTAINED IT FOR A REFUND.

1. OWNERSHIP

It is hereby understood and agreed by you that NAVIGON, Inc. (“NAVIGON”) is the owner of all
title, ownership rights, intellectual property rights and copyrights in and to the software (“Soft­ware”), including, but not limited to, any source codes, object codes, codifications, methods, for­mulas, images, photographs, animation, video, audio and text incorporated into the Software and
the accompanying printed materials. The Software shall remain the sole and exclusive property
of NAVIGON and its licensors' and NAVIGON and its licensors’ will retain all pa tents, copyrights
and other intellectual property rights in the Software, as applicable. For the avoidance of doubt,
you also hereby understand and agree that NAVIGON and/or its third party licensors own all right,
title and interest in and to all accessories and content which work with, are included in or subse­quently enabled on the Software, including, but not limited to, all intellectual property rights therein
(the “Content”).

You through your purchase of this product do not acquire any ownership rights to the Software or
Content. You own the hardware device (the “Hardware Device”) on which the Software is
recorded, but NA VIGON or it s licensors’, as applicable, retain ownership of all copies of the Soft­ware and Content at all times.

2. LICENSE

2.1 In consideration of the p ayment of a lic ense fee, which is a percentage of the price paid by
you for this Software and Hardware Device, NAVIGON hereby grants you a limited and non-exclu­sive right to use and display this copy of the Software and Content on this single Hardware
Device. This License does not grant any rights to obtaining future upgrades, updates or supple­ments of the Software or Content. If upgrades, updates or supplements of the Software are
obtained, however, the use of such upgrades or updates is governed by this License and the
amendments that may accompany them and may be subject to additional payments and condi­tions.

2.2 NAVIGON hereby reserves any and all rights to and may require that Software and Con­tent upgrades (including, but not limited to, version changes) be downloaded into your Hardware
Device to receive applicable updates. These software upgrades may potentially change your
user experience.

2.3 All rights not expressly granted are hereby reserved by NAVIGON.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide iii

NAVIGON, INC.

3. TERM

The License is effective until terminated. Your rights under this License will terminate automati­cally without notice from NAVIGON if you fail to comply with any term(s ) of this Licen se. Upon the
termination of this License, you shall cease all use of the Software.

4. RESTRICTIONS ON USE

4.1 Y ou shall not transfer the Software to other suitable hardware devices without NAVIGON’s
express, prior written consent.

4.2 You shall not, without NAVIGON's express written consent:
(a) Copy or reproduce the Software;

(b) Electronically transfer the Software through area or other network systems or any

other system or use the Software on a server or any other device that permits simul­taneous use of the Software by multiple users;

(c) Reproduce, copy, modify, adapt, reverse engineer, decompile or create derivative

works based on the Software or any accompanying materials; or

(d) Remove, destroy, cover-up or obliterate any notices on the Software with regard to

patent, trademark, trade dress or any other intellectual property or proprietary right.

4.3 You may not transfe r the Content includ ed within the Software apart from a permitted

transfer of the Software itself. You also may not extract or remove the Content from the Software
or otherwise make use of the Content apart from the Software.

4.4 You agree to use the Content with the Hardware Device solely for personal, non-commer-

cial purposes for which you were licensed, and not for service bureau, time-sharing or other simi­lar purposes. Accordingly, but subject to the restrictions set forth in Sections 4 and 5, you may
copy the Content only as necessary for your personal use to (a) view it, and (b) save it, provided
that you do not remove any copyright notices that appear and do not modify the Content in any
way. You agree not to otherwise reproduce, copy, modify, adapt, decompile, disassemble or
reverse engineer any portion of the Content, and may not transfer or distribute it in any form, for
any purpose, except to the extent permitted by mandatory laws.

4.5 THE SOFTWARE, CONTENT AND THE HARDWARE DEVICE ARE NOT DESIGNED

OR INTENDED FOR USE IN ON-LINE CONTROL OF AIRCRAFT, AIR TRAFFIC, AIRCRAFT
NAVIGATION OR AIRCRAFT COMMUNICATIONS, OR IN THE DESIGN, CONSTRUCTION,
OPERATION OR MAINTENANCE OF ANY NUCLEAR FACILITY OR FOR USE IN THE CON­TROL OF MASS TRANSIT OR MEDICAL APPLICATIONS OR IN ANY OTHER INHERENTLY
DANGEROUS APPLICA TION. NAVIGON AND ITS SUPPLIERS DISCLAIM ANY EXPRESS OR
IMPLIED WARRANTY OF FITNESS FOR SUCH USES AND SHALL NOT BE LI ABLE FOR ANY

iv NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

CLAIMS OR DAMAGES ARISING FROM SUCH USE IF YOU USE THE SOFTWARE, CON­TENT OR HARDWARE DE VIC E IN SUCH APPLICATIONS.

5. RESTRICTIONS ON TRANSFER

5.1 You may transfer, in whole, the Hardware Device, the Software and this License to

another party if the other party agrees to accept the terms and conditions of this License. For the
avoidance of doubt, you may not transfer the Software and related Content separately from the
Hardware Device.

5.2 You shall not sub-license, lease, assign, or transfer the Hardware Device, the Software

and this License except as expressly provided in this License. Any attempt otherwise to subli­cense, lease, assign, or transfer any of the rights, duties, or obligations hereunder renders this
License VOID.

6. EXPORT CONTROL

You may not use or otherwise export or re-export the Software except as authorized by the laws
of the United States law and the laws of the jurisdiction(s) in which the Software were obtained.
For the avoidance of doubt, the Software may not be exported or re-exported (a) into any U.S.
embargoed countries or (b) to anyone on the U.S. Treasury Department's list of Specially Desig­nated Nationals or the U.S. Department of Commerce Denied Person’s List or Entity List. By
using the Software, you represent and warrant that you are not located in any such country or on
any such list. You also agree that you will not use the Software for any purposes prohibited by
laws of the United States, including, without limitation, the development, design, manufacture or
production of missiles, nuclear, chemical or biological weapons.

7. WARRANTY DISCLAIMER

7.1 EXCEPT FOR THE LIMITED WARRANTY DOCUMENT INCLUDED WITH THE HARD-

WARE DEVICE, IF ANY, AND T O THE MAXIMUM EXTENT PERMITTED B Y APPLICABLE LA W ,
ALL SOFTWARE, OTHER COMPONENTS THEREOF AND CONTENT ARE PROVIDED ON AN
“AS IS” BASIS. YOU EXPRESSLY ACKNOWLEDGE AND AGREE THAT YOUR USE OF THE
SOFTWARE IS AT YOUR SOLE RISK AND THAT THE ENTIRE RISK AS TO SATISFACTORY
QUALITY, PERFORMANCE, ACCURACY AND EFFORT IS WITH YOU. EXCEPT AS OTHER­WISE EXPRESSLY STATED IN THIS LICENSE, NAVIGON DOES NOT MAKE, AND HEREBY
EXPRESSLY DISCLAIMS, ANY AND ALL EXPRESS AND/OR IMPLIED WARRANTIES,
INCLUDING, BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, NONINFRINGEMENT AND TITLE, AND ANY WARRANTIES ARIS­ING FROM A COURSE OF DEALING, USAGE OR TRADE PRACTICE. WITHOUT LIMITING
THE FOREGOING, (A) NAVIGON DOES NOT WARRANT THAT (i) THE SOFTWARE OR CON­TENT WILL MEET YOUR REQUIREMENTS, (ii) THE SOFTWARE OR CONTENT WILL BE
UNINTERRUPTED, TIMELY, SECURE OR ERROR-FREE, (iii) THE RESULTS THAT MAY BE
OBTAINED FROM THE USE OF THE SOFTWARE OR CONTENT WILL BE ACCURATE OR
RELIABLE, OR (iv) ANY ERRORS IN THE SOFTWARE OR CONTENT WILL BE CORRECTED;
AND (B) NO ADVICE OR INFORMATION, WHETHER ORAL OR WRITTEN, OBTAINED BY

September 2008 NAVIGON 2000S | 2200T Series User’s Guide v

NAVIGON, INC.

YOU FROM NAVIGON OR THROUGH THE USE OF THE SOFTWARE OR CONTENT SHALL
CREATE ANY WARRANTY NOT EXPRESSLY STATED IN THIS LICENSE. YOU UNDER­ST AND AND AGREE THAT THE USE OF THE SOFTWARE AND CONTENT IS DONE AT YOUR
OWN DISCRETION AND RISK AND THAT YOU WILL BE SOLELY RESPONSIBLE FOR ANY
DAMAGES. SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OF IMPLIED WAR­RANTIES OR LIMITATIONS ON APPLICABLE STATUTORY RIGHTS OF A CONSUMER, SO
THE ABOVE EXCLUSION AND LIMITATIONS MAY NOT APPLY TO YOU.

7.2 This exclusion does not apply to (a) any implied condition as to title and (b) any implied

warranty as to conformity with description. If applicable law requires any implied warranties with
respect to the Software, Content or the Hardware Device, all such warranties are limited in dura­tion to ninety (90) days unless stated otherwise in writing.

7.3 Any suggestions by NAVIGON or NAVIGON's agents regarding use, application, or suit-

ability of the Software shall not be construed as an express warranty unless confirmed to be such
in writing by NAVIGON.

8. LIMITATION OF LIABILITY

8.1 TO THE MAXIMUM EXTENT PERMITTED BY LA W AND EXCEPT AS OTHERWISE

EXPRESSLY STATED IN THIS LICENSE, NAVIGON WILL NOT BE LIABLE OR RESP ONSIBLE
TO YOU OR ANY OTHER PERSON OR ENTITY FOR ANY TYPE OF DIRECT, INCIDENTAL,
SPECIAL, PUNITIVE, INDIRECT OR CONSEQUENTIA L DAMAGES, INCLUDING, BUT NOT
LIMITED TO, LOST REVENUE, LOST PROFITS, REPLACEMENT GOODS, LOSS OF PROPRI­ETARY MATERIAL, RIGHTS OR SERVICES, BUSINESS INTERRUPTION, LOSS OR COR­RUPTION OF ELECTRONIC COMMUNICATIONS, OR INTERRUPTION OR LOSS OF USE OF
SERVICES OR EQUIPMENT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES,
OTHER PECUNIARY LOSS, AND WHETHER ARISING UNDER THEORY OF CONTRACT,
TORT (INCLUDING NEGLIGENCE), STRICT LIABILITY OR OTHERWISE. SOME JURISDIC­TIONS DO NOT ALLOW THE LIMIT ATION OF LIABILITY FOR PERSONAL INJURY, OR OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THIS LIMITATION MAY NOT APPLY TO
YOU.

8.2 IN NO EVENT SHALL NAVIGON’S TOTAL LIABILITY (WHETHER ARISING UNDER A

THEORY OF CONTRACT, TORT, INCLUDING NEGLIGENCE, STRICT LIABILITY OR OTHER­WISE) UNDER OR IN CONNECTION WITH THIS LICENSE OR BASED ON ANY CLAIM FOR
INDEMNITY OR CONTRIBUTION EXCEED THE AMOUNT OF PURCHASE PRICE OF THE
LICENSE. NOTWITHSTANDING ANY OF THE FOREGOING, YOU EXPRESSLY ACKNOWL­EDGE AND AGREE THAT NAVIGON WILL NOT BE LIABLE FOR ANY CLAIMS OR DAMAGES
WHA TSOEVER, WHICH ARISE MORE THAN ONE (1) YEAR PRIOR TO THE I NSTITUTION OF
A LAWSUIT. THE FOREGOING LIMITATIONS WILL APPLY EVEN IF THE ABOVE STATED
REMEDY FAILS OF ITS ESSENTIAL PURPOSE.

8.3 Without limiting the foregoing, NAVIGON shall not be liable for any loss resulting from a

cause over which NAVIGON does not have sole and direct control, including, but not limited to,
failure of electronic or mechanical equipment or communication lines; telephone or other intercon­nection problems; bugs, errors, configuration problems or incompatibility of computer hardware or

vi NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

software; problems with equipment or services relating to your computers; problems with interme­diate computer or communications networks or facilities; problems with data transmission facilities
or your telephone or telephone services; unauthorized access, theft, operator errors, severe
weather, earthquakes or labor disputes; or the termination of traffic data services or networks by
service providers of same.

9. THIRD PARTY SOFTWARE LICENSES

NAVIGON and the Hardware Device may make use of third party software. Notwithstanding the
terms and conditions of this License, use of some third party materials included in the Software
may be subject to other terms and conditions. The official third party copyright notices and spe­cific license conditions of these third party software codes and algorithms are provided at the end
of this License. You hereby agree to the terms and conditions for such third party software.

10. REMEDIES FOR BREACH

You understand and agree that NAVIGON will not have adequate remedy at law for the material
breach or threatened breach by you, or your, agents, employees, representatives or subcontrac­tors, of any one or more of the covenants set forth in this License, including, but not limited to,
Sections 3, 4, 5 and 6 of this License. You agree that in the event of any such material breach or
threatened breach, NAVIGON may, in addition to (but not in substitution for) the other remedies
which may be available to it either at law or in equity, file suit in equity to enjoin you from the
breach of or threatened breach of said covenants.

11. JURISDICTION AND DISPUTES; SEVERABILITY

11.1 This License is governed by the laws of the State of Illinois without regard to its conflict of

laws rules.

11.2 All disputes hereunder shall be resolved in the applicable state or federal courts of the

St ate of Illinois located within Cook County, Illinois. T o the extent permitted by law the parties con­sent to the jurisdiction of such courts, agree to accept service of process by mail, and waive any
jurisdictional or venue defenses otherwise available.

1.3 If at any time any one or more of the provisions of this License become invalid, illegal or

unenforceable in any respect for any reason, the validity, legality and enforceability of any such
provision in every other respect and of the remaining provisions of this License shall not be in any
way impaired.

12. INTEGRATION

This License constitutes the entire understanding of the parties, and revokes and supersedes all
prior agreements, oral or written, between the parties, and is intended as a final expression of
their agreement. This License shall not be modified or amended except in writing signed by NAV-

September 2008 NAVIGON 2000S | 2200T Series User’s Guide vii

NAVIGON, INC.

IGON. This License shall take precedence over any other documents that may be in conflict
therewith.

ADDITIONAL TERMS AND CONDITIONS OF USE RELATING TO THE TOTAL TRAFFIC NET­WORK DATA PROVIDED WITH YOUR NAVIGON PRODUCT:

A. Total Traffic Network, a division of Clear Channel Broadcasting, Inc., holds the rights to
the traffic incident data and RDS-TMC network through which it is delivered. Yo u may not modify,
copy, scan or use any other method to reproduce, duplicate, republish, transmit or distribute in
any way any portion of traffic incident data. You agree to indemnify, defend and hold harmless
Clear Channel Broadcasting, Inc. (and its affiliates) against any and all claims, damages, costs or
other expenses that arise directly or indirectly out of (1) your unauthorized use of the traffic inci­dent data or the RDS-TMC network, (2) your violation of this directive and/or (3) any unauthorized
or unlawful activities by you in connection herewith.

B. Total Traffic Network traffic data is inform ationa l only. User assumes all risk of use. Total
Traffic makes no representations about content, traffic and road conditions, route usability, or
speed.

C. T OTAL TRAFFIC NETWORK TRAFFIC DATA IS PROVIDED "AS IS," AND "WHERE IS".
TOTAL TRAFFIC NETWORK EXPRESSLY DISCLAIMS ALL WARRANTIES OR WITH
RESPECT TO THE TRAFFIC DATA (INCLUDING, WITHOUT LIMITATION, THAT THE TRAFFIC
DATA WILL BE ERROR-FREE OR WILL OPERATE WITHOUT INTERRUPTION), EXPRESS,
IMPLIED OR STATUTORY, INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES
OF MERCHANTABILITY, NON-INFRINGEMENT, FITNESS FOR A PARTICULAR PURPOSE,
OR THOSE ARISING FROM A COURSE OF DEALING OR USAGE OF TRADE.

D. TOTAL TRAFFIC NETWORK WILL NOT BE LIABLE TO YOU FOR ANY INDIRECT,
SPECIAL, CONSEQUENTIAL, EXEMPLARY, OR INCIDENTAL DAMAGES (INCLUDING, WITH­OUT LIMIT ATION, LOST REVENUES, ANTICIP ATED REVENUES, OR PROFITS RELATING TO
THE SAME) ARISING FROM ANY CLAIM RELATING DIRECTLY OR INDIRECTLY TO USE OF
THE TRAFFIC DATA, WHETHER A CLAIM FOR SUCH DAMAGES IS BASED ON WARRANTY,
CONTRACT, TORT (INCLUDING, WITHOUT LIMITATION, NEGLIGENCE OR STRICT LIABIL­ITY).

E. IN SOME AREAS A PORTION OF THE TRAFFIC INFORMATION IS PROVIDED BY
INRIX, INC. AND (IN CERTAIN STATES) VIRGINIA DEPARTMENT OF TRANSPORTATION,
UDOT COMMUTERLINK™, AND/OR LOS ANGELES METRO AND CALTRANS. ALL RIGHTS
RESERVED.

NOTICE REGARDING NAVIGON FRESHMAPS FEATURE:

Internet access is required to use the FreshMaps feature on your NAVIGON enabled product.
Download performance can vary based on bandwidth speeds. When applicable, your NAVIGON
FreshMaps subscription includes three years of complimentary map downloads (up to twelve

viii NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

sequential map updates). For NAVIGON FreshMaps accessory activation cards purchased, you
must register your product at www.navigon.com/freshmaps within 60 days from the date of pur­chase of the accessory to qualify for updates. NAVIGON hereby reserves any and all rights to and
may require that software upgrades (including, but not limited to, version changes) be down­loaded into your device to receive NAVIGON FreshMaps updates. These software upgrades may
potentially change your user experience. Retain proof of purchase to assist with future customer
support.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide ix

NAVIGON, INC.

This page intentionally left blank.

x NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Contents

End User License Agreement (EULA) ....................................................................... iii

Introduction

About this User Guide..............................................................................1

Conventions........................................................................................1

Symbols ..............................................................................................1

Legal notice .............................................................................................2

Liability................................................................................................2

Trademarks.........................................................................................2

Customer Service....................................................................................3

Telephone Support..............................................................................3

E-mail..................................................................................................3

The NAVIGON Shop................................................................................4

Welcome

Introducing Your NAVIGON Device.........................................................5

About GPS navigation.........................................................................6

Getting Started

What’s included .......................................................................................7

Important safety information....................................................................8

Navigation safety information..............................................................8

Safety information for the navigation device.......................................9

Safety guidelines for Installation .........................................................9

Preparing your Device for use...............................................................10

Charging the battery..........................................................................10

Power Interruptions ........................................................................................10

Memory Card (Optional)....................................................................11

Installing the Car Mount.........................................................................12

Assembling the Cradle......................................................................12

Securing the Cradle ..........................................................................12

Placing the Navigation Device in the Cradle.....................................13

Powering the navigation device ........................................................14

Using the Screensaver......................................................................14

Selecting Day/Night Viewing Mode...................................................14

Viewing Version Information .............................................................15

September 2008 NAVIGON 2000S | 2200T Series User’s Guide xi

NAVIGON, INC.

Optional Accessory Services.................................................................16

Service Activation..............................................................................16

Activating ZAGAT POI Accessory Service.....................................................16

Activating NAVIGON FreshMaps Accessory Service.....................................17

Activation Confirmation.....................................................................18

Confirming ZAGAT POI Accessory Service Activation...................................18

Basic Operations

First Time Startup..................................................................................19

Starting the Device ................................................................................20

The Main Window .............................................................................21

New Destination .............................................................................................21

My Destinations..............................................................................................21

Take Me Home...............................................................................................21

Show Map.......................................................................................................21

The Standby Button........................................................................................21

The Options Button.........................................................................................22

Initializing the GPS receiver..............................................................23

Setting the volume ............................................................................23

Using Standby Mode ........................................................................24

From the Main Window...................................................................................24

From Any Device Window..............................................................................24

Switching the Device Back On From Standby................................................24

Turning the Device Off .....................................................................25

Viewing device status............................................................................26

GPS...................................................................................................26

Power ...............................................................................................26

Traffic Information (TMC) (NAVIGON 2200T only)...........................27

Using Keyboards ...................................................................................28

Alphabetic keyboard .........................................................................28

Numeric keyboard ............................................................................28

Special character/symbol keyboard .................................................28

Special keys......................................................................................29

Using menus..........................................................................................29

DirectHelp

The DirectHelp Window ....................................................................31

Using DirectHelp....................................................................................34

xii NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Destination Selection

Using auto-complete to select a destination .....................................35

The Search Area Tab........................................................................36

Search Areas.........................................................................................36

Selecting a Search Area Using the Keyboard...................................36

Selecting a Search Area From a List ................................................37

Ways to Search for Destinations ...........................................................38

Enter an Address............................................................................................38

Search for a POI.............................................................................................38

Select a Direct Access POI ............................................................................38

Tap on the Map ..............................................................................................38

Entering an address...............................................................................39

Selecting a Point of Interest (POI) destination.......................................42

POIs nearby......................................................................................42

POIs in a specified city......................................................................44

Statewide POIs .................................................................................47

Selecting a Direct Access POI...............................................................49

Specify Direct Access POI categories............................................................50

Information about the POI.................................................................51

Searching for POIs Near a Selected Location.......................................52

Selecting a destination by tapping the map...........................................55

Starting navigation.................................................................................57

Quitting navigation ............................................................................57

No GPS reception.............................................................................57

Arriving at your destination....................................................................57

ZAGAT POIs (Optional Accessory)

ZAGAT POI Categories.........................................................................59

Search for ZAGAT POIs....................................................................59

View ZAGAT POI Information...........................................................60

My Destinations

Saving a destination to the Favorites List..............................................61

Saving the current location using GPS .............................................62

Saving your home address as a Favorite Destination.......................62

Navigating Home...................................................................................64

Selecting a saved destination................................................................65

Selecting a destination from the Favorites list...................................65

Selecting a destination from the Last Destinations list......................66

September 2008 NAVIGON 2000S | 2200T Series User’s Guide xiii

NAVIGON, INC.

Routes

Accessing the Route Planning Window.................................................67

Entering the starting point.................................................................67

Changing the starting point...............................................................68

Entering route points.........................................................................68

Changing the order of route points....................................................69

Managing routes....................................................................................70

Saving routes....................................................................................70

Loading routes ..................................................................................70

Navigation..............................................................................................71

Calculating and displaying routes .....................................................71

Viewing or Changing the Route Profile.............................................71

Simulating routes...................................................................................72

Starting a route simulation ................................................................72

Ending simulation..............................................................................72

Viewing a Turn-by-Turn List...................................................................73

Blocking route sections.....................................................................73

Removing blocks and using original routes.......................................74

Maps

Forty-Eight Contiguous United States Map....................................................75

North America Map .......................................................................................75

View information on the current map.....................................................76

Map Preview mode................................................................................77

Map Navigation mode............................................................................79

Map functions in Navigation mode....................................................81

Destination Search mode ......................................................................82

Operating in Destination Search mode.............................................83

Reality View (Junction View) .................................................................84

NAVIGON Lifetime Traffic (NAVIGON 2200T only)

Accessing the TMC (Traffic Message Channel) Window..................85

The TMC (Traffic Information) Window..................................................86

Types of Messages...........................................................................86

Specify the type of traffic messages to display...............................................86

Traffic Flow Severity Indicators.........................................................87

Event or Incident Icons......................................................................88

Displaying traffic messages ..............................................................89

xiv NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Select Reroute Settings ....................................................................90

Reroutes................................................................................................91

Requesting a route recalculation.......................................................91

Canceling a Reroute Calculation for a Traffic Event.........................92

TMC Settings Window...........................................................................93

Select another station .......................................................................93

Select Tuning Mode Settings............................................................93

Recalculating Route..........................................................................93

Customization

Accessing the Settings window.........................................................95

The Settings Window.............................................................................95

Navigation Settings...........................................................................95

Route Profile Settings .......................................................................96

Map Display Settings ........................................................................96

General Settings ...............................................................................97

Options Button ..................................................................................98

Selecting options ...................................................................................99

Moving between pages.....................................................................99

Viewing a list of options for a setting.................................................99

Viewing information about a setting..................................................99

Toggling between options.................................................................99

Changing an option setting .............................................................100

Legal Notices

NOTICE TO DRIVERS IN CALIFORNIA AND MINNESOTA .........101

GPS.................................................................................................101

Technical Data

Specifications.......................................................................................103

Compliance Notices.............................................................................104

Federal Communication Commission Interference Statement........104

Canada C Request..........................................................................104

Index

September 2008 NAVIGON 2000S | 2200T Series User’s Guide xv

NAVIGON, INC.

This page intentionally left blank.

xvi NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Introduction

About this User Guide

Conventions

For better legibility and clarification, the following styles are used in this manual:

Italics: Registered names, company and product de scriptions.

SMALL CAPITALS:WINDOW, LIST, AND DIALOG BOX TITLES.

Symbols

Bold Italics:

Bold: Descriptions of buttons, tabs, input fields and other

The following symbols refer to specific passages of text:

Warnings.

Instructions and tips for operating the software.

More detailed information and explanations.

View modes.

elements on the screen.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 1

NAVIGON, INC.

Introduction

Legal notice

Legal notice

Liability

The software and the manual are subject to change without notice. NAVIGON, INC is
not liable for the accuracy of the informat ion contained in this manual or for damages
resulting from the use of this manual.

Trademarks

All brands and trademarks mentioned in this document are possibly registered by third
parties and are subject to the current legislation and to the rights of their respective
owners without reservation. All mentioned names of products, societies, or brands
may be registered trademarks of their respective owners. Every right that is n ot expli c­itly accorded is reserved.

The absence of the explicit labeling of registered trademarks used in this manual does
not imply that the brand is not subject to the rights of a third party.

NAVIGON, DirectHelp, and Reality View are trademarks of NAVIGON, INC.
NAVIGON Lifetime Traffic is a service mark of NAVIGON, INC.
Microsoft, Windows, and Excel are trademarks of the Microsoft Corporation.
NAVTEQ is a registered trademark of NAVTEQ.
ZAGAT SURVEY Ratings and Reviews is a registered trademark of ZAGAT Survey,

LLC.
Total Traffic Network is a registered trademark of Total Traffic Network.
Clear Channel is a registered trademark of Clear Channel Communications.
ZENRIN is a registered trademark of ZENRIN EUROPE GmbH.

2 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Customer Service

Visit the NAVIGON website (www.navigonusa.com/support/) to view our support page.
On this page you can:

• Register your device.

• Search the NAVIGON database for commonly asked questions.

• Download navigation software updates.

• Send an e-mail to the support team.

• Call Customer Service.

• View or download User Guides.

• Report a problem.

• Report a map inaccuracy.

Introduction

Customer Service

Telephone Support

Telephone: [phone] (Toll Free)
Service Hours: Monday through Friday, 7 a.m. to 9 p.m. CT

(except official holidays)

E-mail

To ensure a timely response use e-mail at www.navigonusa.com/support/ and select
By Email. Customers will receive a response within 2 business days.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 3

NAVIGON, INC.

Introduction

The NAVIGON Shop

The NAVIGON Shop

If you need accessories or replacement parts for your device, please visit the NAV­IGON web store at

www.navigonusa.com/store/.

4 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Welcome

Introducing Your NAVIGON Device

Wecome to the exciting world of handheld navigation. The NAVIGON device offers
Global Positioning System (GPS)-based navigation and millions of Points Of Interest
(POIs).

With NAVIGON Lifetime Traffic accessory service (NAVIGON 2200T only), your navi-
gation system can receive the latest traffic information available. If necessary, it can
change your route dynamically in order to avoid traffic congestion.

With the optional ZAGAT Survey Ratings and Reviews POI accessory service, you
receive ratings on thousand s of POI s fr om the world's leading provider of consumer
survey-based dining, travel and leisure information.

With NAVIGON FreshMaps, you can receive quarterly map updates for three years.

1 On/Standby/Off

2 Touch screen
3 MicroSD memory card slot (card not included)

4 Power Connector Port (with integrated TMC antenna NAVIGON 2200T only)

5 Reset

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 5

NAVIGON, INC.

Welcome

Introducing Your NAVIGON Device

About GPS navigation

The Global Positioning System (GPS) uses a constellation of 32 satellites that enable
a GPS receiver to calculate its geographical position.

For a sufficiently precise positioning it is necessary to obtain the data from at least
three satellites. With the data from 4 or more satellites the altitude above sea level can
also be ascertained. The positioning has an accuracy of about 3 yards.

Geographical terrain (such as mountains), man-made structures (such as highway
overpasses, bridges and tall buildings), and even weather can interfere with or disrupt
the GPS signal.

Once the navigation device has determined your position, it can be used as a starting
point for route calculation.

The map data on your navigation device includes the geographical coordinates of all
digitally recorded Points Of Interest (POIs), streets and places. This enables the
device to calculate a route between a starting point and a destination.

The calculation of the current position and its representation on the map takes place
once every second so your current position is always shown on the map.

If GPS reception is impaired, navigation is interrupted but the navigation software
remains active. As soon as GPS reception is restored, the navigation system calcu­lates any change of position which has occurred in the meantime and navigation may
simply be continued.

Caution! The United States government operates the Global Positioning System
(GPS) and is solely responsible for its accuracy and maintenance. Changes by the
United States government may affect the accuracy and performance of all GPS
equipment, including your personal navigation device.
Caution! Ordinances or laws may restrict use of certain abilities of your navigation
device on public or private land

.

6 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Getting Started

What’s included

Your NAVIGON device comes with the following accessories. If the contents are
incomplete, please notify us within 14 days of purchase. The purchased product
includes:

• NAVIGON navigation device

• Car mount and device holder

• Car charger cable (12 volt adapter) with integrated TMC antenna (NAVIGON
2200T only).

•Quick Start Guide

• Warranty and Safety Flyer

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 7

NAVIGON, INC.

Getting Started

Important safety information

Important safety information

Please read the following notices and safety information carefully before starting to
use your navigation system.

Navigation safety information

Use this navigation system at your own risk.

Caution!
Caution! Do not look at the display unless it is absolutely safe to do so!
Caution! Traffic regulations have priority over any instructions from the navigation sys-

tem.

Caution! Follow the instructions of the navigation system only when the circumstances

and the road traffic regulations allow you to do so! The navigation system guides you to
your destination even if you deviate from the calculated route.

Caution! Check that the mount is secured and adjusted properly before each journey.

Note: If you have not understood the spoken instructions, or you're not sure about what

to do next, you can briefly refer to the map or arrow view of your navigation system.

To prevent accidents, do not operate the navigation system while driving.

8 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Safety information for the navigation device

Caution! Do not use pointed or sharp-edged objects on your device’s touch screen.

Your NAVIGON device is designed for use by simply tapping the touchscreen with your
finger.

Caution! Protect the device from moisture. The device is not waterproof a nd is not p ro -

tected against water damage.

Caution! Do not run cables directly next to safety-relevant devices and supply lines.
Caution! After installation, check all safety-relevant equipment in the car.
Caution! Unplug the navigation device's power supply when you park the vehicle. The

navigation device requires power in standby mode, and may drain the vehicle's battery.
When not using your device for an extended of time see “Turning the Device Off” on
page 25.

Caution! Do not open the navigation device's casing under any circumstances.
Caution! Do not attempt to replace the battery. For problems related to the battery,

contact NAVIGON Customer Support.

Caution! Always follow local regulations when disposing of this device.
Caution! Do not expose the navigation device to extreme heat or cold. This may dam-

age the device or impair its function.

Caution! Use only the charger provided or one that has been approved by the manu-

facturer.

Caution! Connect the charger to a suitable power supply. The voltage requirements

can be found on the device case and/or the packaging.

Getting Started

Important safety information

Note: Ensure that there are no kinks in the cable and that it will not be damaged by any

sharp objects.

Note: To clean the navigation device, use a moist cloth only.
Note: Do not unplug by pulling on the cable. Doing so could damage the cable!

Safety guidelines for Installation

Caution! Secure the mount in such a way that the driver's visibility is not impaired.
Caution! Do not attach the mount within the deployment zone of airbags.
Caution! When installing the mount, ensure that it does not represent a risk in the

event of an accident.

Caution! Do not run cables directly next to safety-relevant devices and power supplies.
Caution! After installation, check all safety-relevant equipment in the car.
Caution! The car charger cable is to be connected to cigarette lighters with an operat-

ing voltage of 12V only.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 9

NAVIGON, INC.

Getting Started

Preparing your Device for use

Preparing your Device for use

Caution!

“Important safety information” on page 8.

Please be sure to read, understand, and follow the safety information in

Charging the battery

Note: A 12 volt car charger cable is included with your device. An A/C wall charger is

also available as an optional accessory. To find a retailer, visit our web store

www.navigonusa.com/store/

• Connect the car charger cable to the navigation device and to the vehicle’s ciga­rette lighter.

Power Interruptions

For more information on setting this option, see Automatic Standby in “General Set­tings” on page 97.

When power to the device is interrupted, the NAVIGON device can be configured to
put itself into Standby mode to save power. This occurs when the device is on and is
disconnected from a power source, such as:

• The ve hicle cigarette lighter, or

• A wall outlet.

With this option, after a power interruption, the device waits 30 seconds, then puts
itself into St andby mode. When one of the above power interruptions occur, the follow­ing message displays a 30 second countdown:

.

Tap:

• OK or wait until the 30 seconds countdown completes to allow the device to enter
Standby mode.

• Cancel to end the countdown and continue using the device.

10 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Memory Card (Optional)

A memory card is not provided with the NAVIGON device as all of the data are stored
in the internal memory of the device. When your device is connected to a computer
using a USB cable, the internal memory is detected as the 'NAVIGON' drive. The slot
for the memory card is detected as a removable disc.

Data backups, software updates and navigation map updates can be carried out
quickly and conveniently with NAVIGON Fresh, which you can download free of
charge from our website (http://navigonusa.com/support/).

If you purchase additional navigation maps but no longer have enough space for them
in the internal mem ory of your naviga tion device, you can save these maps on a mem­ory card. The NAVIGON device uses a MicroSD card with a maximum size of 2 GB.

Getting Started

Preparing your Device for use

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 11

NAVIGON, INC.

Getting Started

Installing the Car Mount

Installing the Car Mount

Assembling the Cradle

• Assemble the cradle as shown below. (No tools are required.)

Securing the Cradle

Clean and dry the mounting surface and the suction cup on the base of the mount.
These areas must be dry and free of dirt and grease.

1. Open the lever on the suction cup as far a possible.

2. Place the cradle suction cup against the mounting surface.

3. Press the suction cup lever down towards the mounting surface.

12 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Placing the Navigation Device in the Cradle

The holder has two small projections on the bottom and one on the top. These projec­tions are designed to fit into corresponding slots on the bottom and top of the NAV-
IGON device.

1. Insert the navigation device into the holder by aligning the bottom projection slots

on the bottom of the device.

2. Press the device towards the cradle until you hear the upper clip latch into place.

3. Adjust the navigation device so that it can be seen easily.

Getting Started

Installing the Car Mount

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 13

NAVIGON, INC.

Getting Started

Installing the Car Mount

Powering the navigation device

Included with the NAVIGON device is a car charger cable with which power can be
supplied to the navigation device using the vehicle's cigarette lighter.

The car charger cable is connected to the NAVIGON device using the power connec-
tion port (Power) on the bottom of the device.

Caution!

ing voltage of 12V only.

The car charger cable is to be connected to cigarette lighters with an operat-

Using the Screensaver

Note: When enabled, the screensaver displays a slide show of pictures whe n you have

not touched the device after an extended period of inactivity.

Note: The screensaver is automatically disabled during navigation.

In the MAIN WINDOW:

1. Tap Options > Settings > General.

The G

ENERAL OPTIONS PAGE 1 displays.

2. On P

AGE 3, in the Screensaver field, tap Yes.

3. Tap OK to save the change.

Selecting Day/Night Viewing Mode

In the MAIN WINDOW:

1. Tap Options > Settings > General.

On G

ENERAL PAGE ONE:

2. In the Display mode field, set the viewing mode. Options are:

Automatic Automatically switch between day and night display, based on

sunrise and sunset times.

Night Display with darker colors for night viewing.
Day Display normally for daytime use.

Note:

Change day and night brightness levels in the Brightness Day and the

Brightness Night fields.

3. When finished, tap OK to return to P

AGE ONE.

4. Tap OK to save changes.

14 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Viewing Version Information

You can view software version information. This information may be requir ed if you
call for customer support. Version information is also be useful when NAVIGON offers
software and map updates.

In the MAIN WINDOW:

1. Tap Options > Settings.

Getting Started

Installing the Car Mount

On the S

ETTINGS WINDOW:

2. Tap Options > Product Information.

3. Use (Up

) and (Down) to view all of the information.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 15

NAVIGON, INC.

Getting Started

Optional Accessory Services

Optional Accessory Services

These optional accessory services are available for your NAVIGON device:

• ZAGAT Survey Ratings and Reviews Points of Interest (POIs).

• NAVIGON FreshMaps (standard with some models)

Optional services are purchased separately.

Service Activation

Activating ZAGAT POI Accessory Service

At a retail outlet where NAVIGON devices are sold:

1. Purchase an accessory card.

2. On the Accessory card is the 15 character activation key, t hree blo cks of five char-

acters separated by hyphens. This key is used to obtain a device unlock code.

3. Switch on the device by pressing and releasing the (On/Standby/Off) button.

AIN WINDOW displays.

The M

4. Tap Options > Service Activation.

RODUCT ID WINDOW displays the 15 character product ID.

The P

5. Record the product ID for the next step.

On a computer with internet access:

6. Go to

7. On the H

8. Select REGISTER YOUR NAVIGON DEVICE and prov

www.navigonusa.com.

OME PAGE, select the Registration & Activation tab.

ide the requested information.

9. When finished, select ACTIVATE YOUR SERVICE ACCESSORIES.

The website requests your e-mail address, NAVIGON device product ID, and the
Accessory card activation key.

16 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Getting Started

Optional Accessory Services

10. Enter the requested informa tion in the appropriate fields.

The website returns your device unlock code, used to unlock the service on the
device. The unlock code is also sent to your e-mail address.

On your NAVIGON device:

11. On the P

The D

RODUCT ID WINDOW, tap Next.

EVICE UNLOCK WINDOW displays.

12. In the Enter Unlock Code fields, enter the 18 character device unlock code, in

blocks of six characters.

13. Tap OK.

The A

CTIVATION COMPLETE WINDOW displays. The accessory service is now avail-

able for use.

14. Tap OK to close the window.

Activating NAVIGON FreshMaps Accessory Service

Note:

device. For the NAVIGON 2090S model only, quarterly map updates are provided for 2
(two) years. You must still activate the service before you can receive updates.

For the NA VIGON 2090S m odel, NAVIGON FreshMaps comes standard with the

Y ou must activate your product at www .navigon.com/freshmaps to qualify for updates.
You must activate your service within 60 days from the date of purchase of the acces­sory card or , if FreshMap s com es with you r device, 60 days from the purchase date of

the device.

Note: A USB cable is required for use with this accessory. To find a retailer, visit our

web store at www.navigonusa.com/store/

.

To activate:

1. Go to www.navigon.com

2. Select the Registration & Activation tab.

3. Select REGISTER YOUR NAVIGON DEVICE and prov

tion.

ide the requested informa-

4. Select ACTIVATE YOUR SERVICE ACCESSORIES.

5. Follow on-screen instructions for activating this accessory service.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 17

NAVIGON, INC.

Getting Started

Optional Accessory Services

Activation Confirmation

Confirming ZAGAT POI Accessory Service Activation

Select a POI destination (as described in “Selecting a Point of Interest (POI) destina­tion” on page 42). ZAGAT POIs are available for most major cities, such as Chicago,
Los Angeles, New York, etc.

All available ZAGAT POIs appear at the top of the returned list. A ZAGAT Icon
( ) appears in front of the POI. Tap the Information button ( ) to view POI

details. For more information on ZAGAT POIs, see “ZAGAT POIs (Optional Acces­sory)” on page 59 .

Note:

ZAGAT POI information is not available for all locations.

18 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Basic Operations

First Time Startup

When you first start your device, the LANGUAGE SELECTION WINDOW displays.

Caution! Selecting the (Cancel) button during these steps will cause the NAV­IGON device to cease operation and will require the user to reset the device.

1. Select the appropriate language and tap OK.

ISTANCE UNIT SELECTION WINDOW displays.

The D

2. Select either Kilometers or Miles and tap OK.

The C

LOCK SETTING WINDOW displays.

3. Select either 12h (am/pm) or 24h and tap OK.

The selected options will be used by the device.
The following message displays:

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 19

NAVIGON, INC.

Basic Operations

Starting the Device

4. After you have read and fully understood the text, tap OK.

Note: If you do not accept these instructions, tap Cancel to exit the navigation soft-

ware.

The M

AIN WINDOW displays.

Y o u can change thes e settings at any time. For more information, see General settings
in “Customization” on page 95.

Starting the Device

1. Press and hold the (On/Standby/Off) butt on f o r two (2) seconds, then

release.
After being turned off, when the navigation device is turned back on, the following

message appears:

Note: This message does not display if the device is turned back on from Standby.

2. After you have read and fully understood the text, tap OK.

AIN WINDOW displays.

The M

Note:

If you do not accept these instructions, tap Cancel to exit the navigation soft-

ware.

20 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

The Main Window

The MAIN WINDOW opens when the navigation software starts.
You can reach all of the navigation software functions from this window.

New Destination

Tap this button to:

• Select an address as a destination. (See page 39.)

• Select a POI as a destination. (See page 42.)

• Select a Direct Access POI. (See page 49.)

Basic Operations

Starting the Device

My Destinations

Tap this button to select a destination from:

• A list of destinations you have saved. (See page 65.)

• A list of the most recently entered destinations. (See page 66.)

Take Me Home

Tap this button to:

• Specify your home address as a destination. (See page 62.)

• Quickly create a route back to your home address from your present location. (See
page 55.)

Show Map

Tap this button to:

• Show your location on the current map. (GPS reception required.)

• Select a destination by tapping on the map. (See page 55.)

The Standby Button

• Tap this button to place the device on Standby and conserve power. (See
“The Standby Button” on page 21 for more information.)

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 21

NAVIGON, INC.

Basic Operations

Starting the Device

The Options Button

Tap this button to:

Access the Route Planning window to:

• Create a route. (See page 67.)

• Save a route. (See page 70.)

• Load a saved route. (See page 70.)

• Run a simulatio n of a route. (See page 72.)
Access the Settings window to set:

• Navigation options. (See page 95.)

• Route Profile options. (See page 97.)

• Map display options. (See page 96.)

• General options. (See page 96.)

• Additio nal Options butto n. (See page 98.)
iew the TMC Traffic window information. (See page 89.)

V
(NAVIGON 2200T only)

Activate an accessory service

:

• Activate ZAGAT Survey Ratings and Reviews POIs.

• Instructions to activate NA VIGON FreshMaps.

o to the DirectHelp window. (See page 31.)

G
Go to the GPS Status window to:

• View current GPS status and location information.

• Save the current location as a destination (GPS reception required).

(See page 62.)

22 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Initializing the GPS receiver

Note: If possible, position the device with a clear line of sight to the sky to successfully
receive navigation messages from the GPS satellites.
Note: GPS initialization requires data from at least three satellites. If GPS data is not
available, the receiver will not initialize.
Note: It can take up to 20 minutes to initialize the integrated GPS receiver for the first
time.
Note: Each time you turn on the device, GPS receiver initialization begins. When GPS
data is available, reception starts within one minute.
If the navigation device has been switched to standby for more than a week, the next ini­tialization can take up to 10 minutes.

In the upper right-hand corner of the display, the GPS symbol appears. As soon as
data from at least 3 satellites is received, the symbol changes to (

Note: If the GPS symbol displays GPS Ready after considerably less than 20 min­utes, it is advisable to leave the receiver switched on for at least an additional 15 min­utes to ensure reliable operation.

Basic Operations

Starting the Device

GPS Ready).

Caution! The GPS receiver requires a constant supply of power. Leaving the device

plugged into your cigarette lighter for a longer period with the vehicle turned off could
drain the vehicle battery.

Setting the volume

The volume of the spoken driving instructions can be adjusted during navigation.
With a map displayed:

1. Tap (Volume
The volume bar opens. It contains three buttons for adjusting the volume:

2. Tap (Volume
The volume bar closes.

Note: When you mute the volume, an icon appears in the upper right corner of
the screen, next to the battery, traffic, and GPS icons. The icon disappears when the
volume mute is turned off.

).

(Louder)
(Softer)

(Mute on/off).

) again.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 23

NAVIGON, INC.

Basic Operations

Starting the Device

Using Standby Mode

Note: Use Standby mode only when your device will be unused for a very short time. If
left in Standby mode for an extended period, battery drain can occur as the GPS
receiver continues to draw power. For longer periods of inactivity, see “Turning the
Device Off” on page 25.
Note: To further conserve battery power, the device reset s itself if left in S t andby mode
for a longer time.

Standby mode conserves battery time. When the device is switched back on from
Standby, the window that displayed when the device was set to Standby re-displays.

There are two ways to switch your device to Standby.

From the Main Window

On the MAIN WINDOW:

• Tap the (Standby) button.

From Any Device Window

• Press and hold the (On/Standby/Off) button for two (2) seconds, then

release.

Switching the Device Back On From Standby

To switch the Device back on:

• Press and hold the (On/Standby/Off) button for two (2) seconds, then

release.

24 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Turning the Device Off

Note: When your device is not in use for an extended period, use this procedure to
turn off your device and conserve battery power.

After the device has been turned off, the splash screen re-displays when the device is
turned back on.

1. Press and hold the (On/Standby/Off) button on the top of the device for
eight (8) seconds, then release.

Basic Operations

Starting the Device

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 25

NAVIGON, INC.

Basic Operations

Viewing device status

Viewing device status

Symbols located at the top right of the screen are used to display information.

GPS

The GPS symbol can show the following GPS reception status:

No Symbol The built-in GPS receiver is not operational. Contact customer

service if the problem persists.

Power

No Signal Data is being received from less than three satellites. Position

cannot be calculated.

GPS Ready Data is being received from at least three satellites. Position can

be calculated.

For more information, see “About GPS navigation” on page 6.

For more information on recharging your device, see “Charging the battery” on
page 10.

The Power symbol can display the following conditions of the built-in battery:

The device is powered by an external power source. The battery is charging.
The device is powered by its internal battery. Battery is fully charged.
The device is powered by its internal battery. Battery charge is sufficient.
The device is powered by its internal battery. Battery charge is low.

Caution! Do not attempt to replace the battery. For problems related to the battery , con­tact NAVIGON Customer Support.

26 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Traffic Information (TMC) (NAVIGON 2200T only)

The NA VIGON 2200T, with a car charger cable with integrated TMC antenna, pro­vides the navigation system with up to date traffic messages. If necessary, it can alter
the route dynamically in order to avoid a traffic jam.

Note: This function is only available if TMC traffic messages are being transmitted in
the map area in which you are traveling. Traffic messages are not available in all areas.
Note: The charger cable does not need to be connected to the

for the antenna to be operational.

lighter

Note: Without the antenna, TMC messages may not be received when the device is
operating on battery power only.

The TMC symbol can display the following TMC reception status:

No Symbol TMC is not operational.

Tuning TMC is operational, but cannot find a station that is

transmitting TMC signals.

No

Reception Traffic messages are no longer being received, but there

are still traffic messages in the queue that have not
expired.

Basic Operations

Viewing device status

vehicle's cigarette

TMC Ready Traffic messages can be received.

For more information, see “Displaying traffic messages” on page 89.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 27

NAVIGON, INC.

Basic Operations

Using Keyboards

Using Keyboards

Software keyboards appear on the screen when text entries are necessary . All entries
can be made on the software keyboard using the fingertips. Only capital letters can be
entered. Three keyboards are available for entering destination information.

Note: When you need to enter a hyphen, use the space button in place of the
hyphen. For example, to enter a hyphenated house number of 20-36 tap two, zero,

space, three, six.

Alphabetic keyboard

Tap to display the alphabetic
keyboard.
Only capital letters can be entered.

Numeric keyboard

Tap to display the numeric
keyboard.

Special character/symbol keyboard

Tap to display the special
character keyboard.
As soon as you have entered a spe­cial character, the Alphabetic key­board reappears automatically.

28 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Special keys

On the Alphabetic keyboard, enters a space character.
This key is also used to enter a space in place of a hyphen.

On the Alphabetic and Numeric keyboards, deletes the previous character and
moves the cursor back one space.

On the Alphabetic and Special Character keyboards, opens the Numeric key­board.

On the Numeric and Special Character keyboards, opens the Alphabetic key­board.

On the Alphabetic and Numeric keyboards, opens the Special Character key­board.

Using menus

Some buttons display menus with options that can be selected.

Basic Operations

Using menus

To open a menu:

• Tap on a button to show the menu options.

To close a menu without selecting a function:

• Tap on the button again.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 29

NAVIGON, INC.

This page intentionally left blank.

30 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

DirectHelp

The NAVIGON DirectHelp feature offers speedy access to emergency POIs. You ca n
quickly find a telephone number, find an address, get directions, and drive to help.
DirectHelp also provides you with directional distance to the nearest intersection, and
your latitude/longitude location. This information can help emergency personnel
quickly come to your assistance.

DirectHelp is available at any time, while you are on-route or off, and with or without
GPS reception. The last known GPS position is used when GPS reception is not avail­able. With GPS, you can quickly find help and calculate a route to a DirectHelp POI.

The DirectHelp Window

DirectHelp

GPS Position Type

The location type indicates whether GPS reception is available or not. If the location
type is:

Simulated Position: Displays only once when neither current or historical GPS

Your current location: GPS reception is available. Your current location is shown

Your last location: GPS reception has been lost. The last GPS location is

Location Address

With GPS reception, the distance to the intersection closest to your present location is
shown. If GPS is not available, this is the approximate distance to the closest intersec­tion from the last known GPS position. If the device is located:

On an Unnamed Road

Off Road

position is available. Shown at time of purchase or when­ever the device is reset.

Location Address field.

in the

shown in the

Unnamed Road appears with the distance and direction to

the nearest navigable intersection.

Off Road appears with the distance and direction to the

nearest navigable intersection.

Location Address field.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 31

NAVIGON, INC.

DirectHelp

Longitude/Latitude

The longitude and latitude of the location.

Note: The format of the longitude and latitude can be changed. See “Selecting
options” on page 99.

Show on Map

View your location on a map. Once a DirectHelp POI is selected, tapping this button
centers the map on the location of the selected POI. The selected POI is shown as a
gray circle. If you have enabled the display of the particular POI icon category (such
as Healthcare for Hospital) in map display, the icon and label of the selected POI
appears on the map. Changing the zoom level ( (

affects whether the icons display.
The crosshairs indicate the center of the map. The name of the POI closest to the

center of the map is shown.

Zoom In) or (Zoom Out))

DirectHelp buttons

Four DirectHelp POI categories are available:

Roadside assistance

Police Station

Hospital

Pharmacy

32 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

DirectHelp

DirectHelp returns up to 10 POIs within a 30 mile radius of your location, with the clos­est POI shown first. If no POIs are fo und, the following message displays:

If no emergency POIs are found, follow established procedures to seek assistance.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 33

NAVIGON, INC.

DirectHelp

Using DirectHelp

Using DirectHelp

From the MAIN WINDOW:

1. Tap Options > DirectHelp.

IRECTHELP WINDOW opens.

The D

2. Tap on the DirectHelp category button fo r the type of help you need.

IRECTHELP DETAIL WINDOW displays.

The D

3. Use the (

4. Tap the (

5. Tap the

Note:

GPS location.

34 NAVIGON 2000S | 2200T Series User’s Guide September 2008

Navigation button to calculate a route to the POI.

If GPS reception has been lost, the route is calculated from the last recorded

Down) and (Up) buttons to select an emergency POI.

Map) button to show the location of the selected emergency POI.

NAVIGON, INC.

Destination Selection

Caution! Please be sure to refer to the safety information in “Important safety informa-

tion” on page 8.

New destinations for the NAVIGON device are destinations that you have not yet navi-
gated to or those that you have not yet stored.

You can enter an address, select a POI, or select a destination from the quick search func­tion.

Using auto-complete to select a destination

When you enter a city name, after you type the first letter, the largest city in the search
area appears on the

are for the next valid character in a search area name.

CITY OR ZIP CODE TAB. On the keyboard, the only keys available

1. To select:

• The city shown, tap (OK).

• A different city , co ntin ue ty pi ng th e ci ty na me un til th e c orrec t c ity is sh own on

ITY OR ZIP CODE TAB. Tap (OK) to select the city.

the C

Note: The auto-complete feature is not available for all locations.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 35

NAVIGON, INC.

Destination Selection

Search Areas

The Search Area Tab

When you enter the New Destination button on the MAIN WINDOW, the SEARCH AREA
keyboard opens.

The
the destination selection window.
Once an area is selected, a code on the button reflects the selection and the flag of the

country appears above it. For examp le:

If “IL - Illinois” is selected, the tab displays as:

If “QC-Quebec” is selected, the tab displays as:

Note: Only areas that are represented in the currently loaded map can be selected.

(Search Area) tab, used to select a map area, is located at the top left corner of

Search Areas

Selecting a Search Area Using the Keyboard

To select an area, do the following:
On the

MAIN WINDOW:

1. Tap New Destination > Enter an Address.

ESTINATION SELECTION WINDOW opens and displays the Alphabetic key-

The D
board.

2. Tap the key of the first character in the state/province within which your location is
located.

For example, tap “I” for Idaho.

36 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Destination Selection

Search Areas

The name of the first search area beginning with the selected character is shown.
On the keyboard, the only keys available are for the next valid character in a
search area name.

3. Tap the next characters in the search area name.

4. When the correct state/province name is shown, tap (

Selecting a Search Area From a List

When you enter the New Destination button on the Main window, the SEARCH AREA key-
board opens. To select an area, do the following:

On the

1. Tap New Destination > Enter an Address.

2. Tap (Area List).

MAIN WINDOW:

ESTINATION SELECTION WINDOW opens.

The D

A list of search areas displays.

OK).

3. Tap on the state/province in which your destination is located.

4. Tap (

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 37

OK).

NAVIGON, INC.

Destination Selection

Ways to Search for Destinations

Ways to Search for Destinations

Enter an Address

You can find an address by entering the state/province, city, street and house number.

Search for a POI

Note: Optional lifetime ZAGAT Survey Ratings and Reviews POI accessory service is

available. For more information see “ZAGAT POIs (Optional Accessory)” on page 59.

Points of Interest, (POIs) are useful locations that are organized according to particular cri­teria. POIs include airports, restaurants, hotels, gas stations, government offices, banks,
hospitals, shopping centers, etc. Icons representing the POIs can be displayed on the
map.

You can search for POIs:

Nearby POIs nearby are special destinations that are located within a

given radius of your current location. This means you can
always find the nearest gas station, for example, no matter
where you are.

In a City POIs in a given location can be useful when navigating in an

Statewide Popular POIs and POIs of national significance in a state/prov-

Near a Selected POI

Select a Direct Access POI

POI direct access system contains three categories of special destinations. POIs in your
vicinity that correspond to these categories can be listed quickly , without the nee d for addi­tional entry.

Tap on the Map

You may indicate a destination directly on the map. In addition to towns and streets, you
may also select POIs.

Note: Only areas that are represented in the currently loaded map can be selected.

unfamiliar town.

ince. Includes airports, national parks, historic sites, etc. This
enables you to find places of interest within a state/province.

Select a location, then search for POIs near it. For example,
search for restaurants close to an airport. No GPS reception is
required for this type of search.

38 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Entering an address

When searching for a location, you do not have to enter all of the address details.
If you do not know the house number, leave the No. tab blank to display the Intersection

tab. On this tab, enter the name of a nearby cross street and the navigation system calcu­lates a route to the intersection of the specified streets.

In the

MAIN WINDOW:

1. Tap New Destination > Enter an Address.
The D

ESTINATION SELECTION WINDOW opens. The search area used in the previous

search is shown on the Search Area tab.

Destination Selection

Entering an address

2. To select a different search area, tap on the S

EARCH AREA TAB, select the state/

province.
The C

ITY OR ZIP CODE tab opens.

3. Enter the city name or Postal code, then tap (OK).

• Use the Alphabetic keyboard to type a city name, or

• Use the Numeric keyboard to type th e zip or postal code

• Switch between the Alphabetic and Numeric keyboards to type a Canadian

postal code.

Note: You can specify just a city name if you prefer a route to the center of the city.
Note: Only the first three characters of a Canadian postal code are supported.

TREET TAB opens.

The S

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 39

NAVIGON, INC.

Destination Selection

Entering an address

4. Enter the name of the destination street, then tap (OK).
The N

O. TAB opens.

5. Enter the house number, then tap (

OK).

• If you don't know the number of the house, leave the No. tab blank and tap on

the

Intersection tab.

If more than one location is found that matches your destination selection info, the

NAVIGON device displays a list of locations.

Note: The search is performed on the street name and type, directional information
(such as North, South, East and West) is not used in the search. The returned list of
addresses will have specified street name with any directional indicator.

6. Tap on a location to select it.

7. Tap

40 NAVIGON 2000S | 2200T Series User’s Guide September 2008

Navigation.

NAVIGON, INC.

The map opens in Preview mode.

For more information, see “Starting navigation” on page 57.

Destination Selection

Entering an address

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 41

NAVIGON, INC.

Destination Selection

Selecting a Point of Interest (POI) destination

Selecting a Point of Interest (POI) destination

POIs nearby

Note: GPS reception must be sufficient to dete rmine your cu rrent position. You can see
if GPS reception is sufficient by looking at the (GPS Ready) symbol. For more infor-

mation, see “GPS” on page 26.

In the MAIN WINDOW:

1. Tap New Destination > Search for POI.
The C

ATEGORY tab opens.

2. Tap on the category from which you would like to select a POI.
The SUB CATEGORY tab opens.

3. Tap on the subcategory from which you would like to select a POI.

ESTINATION TAB opens.

The D
If more than one location is found that matches your destination selection info, the

NAVIGON device displays a list of locations.

42 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

4. Tap on the name of the destination.
Information for the selected POI displays.

Destination Selection

Selecting a Point of Interest (POI) destination

5. Tap

Navigation.

The map opens in Preview mode.

For more information, see “Starting navigation” on page 57.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 43

NAVIGON, INC.

Destination Selection

Selecting a Point of Interest (POI) destination

POIs in a specified city

On the MAIN WINDOW:

1. Tap New Destination > Search for POI > in a City.

ESTINATION SELECTION WINDOW opens. The search area used in the previous

The D
search is shown on the Search Area tab.

2. To select a different search area, tap on the S

EARCH AREA TAB, select the state/

province.

ITY OR ZIP CODE tab opens.

The C

3. Enter the city name or ZIP code, then tap (

OK).

• Use the Alphabetic keyboard to type a city name, or

• Use the Numeric keyboard to type the zip code.

• Switch between the Alphabetic and Numeric keyboards to type a Canadian

postal code.

Note: Only the first three characters of a Canadian postal code are supported.

The C

ATEGORY TAB displays.

4. Tap on the category from which you would like to select a POI.

UB CATEGORY TAB displays.

The S

44 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Destination Selection

Selecting a Point of Interest (POI) destination

5. Tap on the subcategory from which you would like to select a POI.
The D

ESTINATION TAB opens.

6. Tap on the name of the destination.
If more than one location is found that matches your destination selection info, the

NAVIGON device displays a list of locations.

7. Tap on the location you want.
The D

ESTINATION TAB displays information on the selected POI.

For more on POI information, see “Information about the POI” on page 51.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 45

NAVIGON, INC.

Destination Selection

Selecting a Point of Interest (POI) destination

8. Tap Navigation.
The map opens in Preview mode.

For more information, see “Starting navigation” on page 57.

46 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Statewide POIs

In the MAIN WINDOW:

1. Tap New Destination > Search for POI > Statewide.
The S

2. Tap on the category from which you would like to select a POI.
The D

If more than one location is found that matches your destination selection info, the

NAVIGON device displays a list of locations.

Destination Selection

Selecting a Point of Interest (POI) destination

TATEWIDE POI WINDOW opens.

ESTINATION TAB opens.

3. Tap on the name of the POI.

ESTINATION TAB displays information on the selected POI.

The D

For more on POI information, see “Information about the POI” on page 51.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 47

NAVIGON, INC.

Destination Selection

Selecting a Point of Interest (POI) destination

4. Tap Navigation.
The map opens in Preview mode.

For more information, see “Starting navigation” on page 57.

48 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Selecting a Direct Access POI

Note: Sufficient GPS reception is required for Direct Access POIs. You can check GPS

reception by looking at the (GPS Ready) symbol.

When you receive your device, the following 3 POI categories are selected for direct
access:

• Gas Stations

•Parking

• Restaurants.

Note: To select other types of POIs for direct access, see “Specify Direct Access POI
categories” on page 50.

In the MAIN WINDOW:

1. Tap New Destination.

Destination Selection

Selecting a Direct Access POI

The N

EW DESTINATION MENU opens.

The symbols of the categories which have been selected for direct access can be
seen in the menu at the bottom.

2. Tap on a category from which you would like to select a POI.

Name of the Destination list opens. It contains the nearest POIs in the speci-

The
fied category, sorted by distance.

3. Tap on the name of the destination.
The map opens in

Preview mode.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 49

NAVIGON, INC.

Destination Selection

Selecting a Direct Access POI

For more information, see “Starting navigation” on page 57.

Specify Direct Access POI categories

In the MAIN WINDOW:

1. Tap Options > Settings > General.

2. Use (Next Page) to go to P

3. In the

4. Repeat the above step in the

5. When finished, tap

Direct Access 1 field, tap (List) and select a POI category.

Direct Access 2 and Direct Access 3 fields.

OK to save the changes.

AGE TWO.

50 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Information about the POI

For many POI destinations, additional information is available. For example, telephone
numbers are provided for many restaurants, allowing you to call the restaurant and
reserve a table ahead of time.

Destination Selection

Selecting a Direct Access POI

On the

DESTINATION SELECTION WINDOW, the following buttons are available:

Opens the
information about a POI, including address and phone
number.

DESTINATION INFO WINDOW and shows basic

Postal codes in Canada will only display the first three
numbers.

Show the POI on a map. (GPS reception required.)

Not available.

Calculate a route and start navigation to the selected POI.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 51

NAVIGON, INC.

Destination Selection

Searching for POIs Near a Selected Location

Searching for POIs Near a Selected Location

With the NAVIGON device you can select a location, then search for POIs nearby. For
example, if you are traveling for business you can search for restaurants close to your
hotel. You can perform this type of search from anywhere - your home, hotel room, air port,
etc. No GPS reception is required for this type of search.

On the

MAIN WINDOW:

1. Select the location. (See the corresponding section of “Destination Selection” on
page 35.)

2. Tap Map.
The map displays the selected POI centered on the map and the street name of

the POI appears below it.

3. Tap (OK).

ESTINATION SEARCH MODE WINDOW displays.

The D

52 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

4. Tap the Search Nearby button.

ATEGORY TAB opens.

The C

5. Select the POI category
The S

UB CATEGORY tab opens.

Destination Selection

Searching for POIs Near a Selected Location

6. Tap on the subcategory from which you would like to select a POI.

ESTINATION TAB opens. The distance from your current location and the POI

The D
is shown.

7. Tap on the location you want.

ESTINATION TAB displays information on the selected POI.

The D

For more on POI information, see “Information about the POI” on page 51.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 53

NAVIGON, INC.

Destination Selection

Searching for POIs Near a Selected Location

8. Tap Navigation.

For more information, see “Starting navigation” on page 57.

54 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Selecting a destination by tapping the map

Selecting a destination by tapping the map

You can select towns, streets, and even POIs by tapping on the map.

On the MAIN WINDOW:

1. Tap > Show Map.
The map opens in

Preview mode.

Destination Selection

2. Tap (

For more information on using destination search tools, see “Destination Search mode”
on page 82.

Destination search) to display destination search tools.

3. Use the Destination search tools (zoom in, zoom out, pan, etc.) to view the gen­eral map area you are interested in.

4. Tap on the point to which you wish to navigate.
The name of the location displays. The selected destination is centered in the map

and appears under the cross hairs.

5. Tap (

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 55

OK).

NAVIGON, INC.

Destination Selection

Selecting a destination by tapping the map

The DESTINATION ON MAP WINDOW opens. Detailed address information for the
selected destination displays in the upper left-hand corner.

6. Tap the
The map opens in

Take Me There button.

Preview mode and shows the route calculated from your cur-

rent location to this destination.

For more information, see “Starting navigation” on page 57.

56 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Starting navigation

With the map open in Preview mode, the destination is shown as a small flag. The
route and the estimated trip time are displayed.

Destination Selection

Starting navigation

With the map open in

• Tap the

Navigation button or simply start driving.

Quitting navigation

•Tap (Back) to quit navigation.

A window prompts you to confirm.

No GPS reception

If GPS reception is insufficient when the Navigation button is tapped, the following
message appears:

Preview mode:

You can:

• Wait until GPS reception resumes for determining position. Navigation begins

automatically once GPS reception is sufficient.

• Tap the

LAST DESTINATIONS list.

• Tap the

point. The simulation of the calculated route begins. Tap (
demonstration. (The Demo button does not appear when the destination was
selected by tapping on the map.)

Cancel button. The MAIN WINDOW opens. Your destination is saved in the

Demo button. The route is calculated using a nearby location as a starting

Arriving at your destination

A voice announcement tells you that you have reached your destination. If available, the
street name is also given.

Your current position (indicated by an orange triangle) is shown on the map.
If the destination has a house number, the NAVIGON device anno unce s wh ich side of the

street the destination is on.

Back) to end the

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 57

NAVIGON, INC.

This page intentionally left blank.

58 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

ZAGAT POIs (Optional Accessory)

ZAGAT Survey Ratings and Reviews POIs can be purchased
as an optional accessory service.

Once purchased, ZAGAT information is provided for the life­time of your NAVIGON device at no additional charge.

For more on purchasing and activating this accessory, see
“Optional Accessory Services” on page 16.

With ZAGAT Survey Ratings and Reviews POIs, you can select from thousands of
POIs and view customer survey ratings for a selected POI.

ZAGAT POI Categories

ZAGAT survey information features over 30,000 points of interest (POIs) in hundreds
of cities. ZAGAT Survey information is provided in the following five categories:

Attractions Shopping centers and entertainment venues.

Golf Courses Public, semi-private and resort courses.

Hotels Hotels, resorts and spas.

Nightlife Nightspots and dance clubs.

Restaurants Food, decor, service, and cost.

Search for ZAGAT POIs

Once the ZAGAT POI accessory service is purchased and activated, ZAGAT POIs are
returned with any POI search.

Note: ZAGAT POI information is not available for all locations.

ZAGAT categories appear first in the list of returned locations. A
appears in front of a ZAGAT category.

(ZAGAT POI)

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 59

NAVIGON, INC.

ZAGAT POIs (Optional Accessory)

ZAGAT POI Categories

View ZAGAT POI Information

On a POI DESTINATION SELECTION WINDOW:

1. Tap on a ZAGAT POI category.

2. If sub-categories exist for the category, tap the subcategory.

3. Tap on the name of a POI.

ESTINATION INFO WINDOW opens and displays basic POI information.

The D

4. Tap Info to view ZAGAT survey information about the POI.

AGAT DETAIL WINDOW opens and displays detail information for the POI

The Z
including hours of operation, costs, offered services, etc.

5. Use the (Down) and (Up) buttons to view all of the information.

6. When finished, tap Close.

60 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

My Destinations

My Destinations include a Favorites list of locations you have saved and a Last Desti­nations list of the last locations your performed a search for. These lists can be useful
if you often navigate to particular locations.

Saving a destination to the Favorites List

1. Enter a destination. (See “Destination Selection” on page 35.)

2. Tap

- OR –

1. Select a destination from MY DESTINATIONS. (See page 66.)

2. Tap

Options > Save Destination.

Options > Save Destination.

The SAVE DESTINATION AS window displays.

3. Enter the name for the destination.

4. Tap Save.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 61

NAVIGON, INC.

My Destinations

Saving a destination to the Favorites List

Saving the current location using GPS

The GPS STATUS WINDOW provides you with an overview of the data the navigation sys-
tem calculates from the received GPS signals.

GPS status is available from several windows.
In the

GPS STATUS WINDOW:

1. Tap

Options > GPS status.

The current location can be stored in the FAVORITES list.

2. Tap the Save Position button.

The SAVE DESTINATION AS WINDOW opens.

3. In the Name field, enter the name for the destination.

4. Specify whether your current position should be stored as the home address.

5. Tap the Save button.

Saving your home address as a Favorite Destination

You can begin navigation to this destination quickly by tapping the Take Me Home but-
ton in the
your home address.

MAIN WINDOW. Only one destination from the FAVORITES list can be defined as

On the

1. Tap the

62 NAVIGON 2000S | 2200T Series User’s Guide September 2008

MAIN WINDOW:

Take Me Home button.

The following message displays:

NAVIGON, INC.

Saving a destination to the Favorites List

2. Use the (Toggle) button to select:

• Enter an Address - To enter your home address, or

• Favorites - To select an address from your Favorites List.

3. Tap the

OK button.

If you selected Enter an Address, the DESTINATION SELECTION WINDOW displays.

4. Follow procedures for “Entering an address” on page 39.

If you selected FAVORITES, the FAVORITES WINDOW displays.

My Destinations

5. Select your home address and tap (OK).

6. Tap Home Address.

The selected destination is saved as your home address. On the FAVORITES LIST, a
house icon displays next to your home address.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 63

NAVIGON, INC.

My Destinations

Navigating Home

Navigating Home

After saving an home address, you can navigate to your home from anywhere by tap­ping a single button.

The first time you tap the

1. Follow procedures for

page 62.

Take Me Home button, you are asked to enter your address.

“Saving your home address as a Favorite Destination” on

In the MAIN WINDOW:

2. Tap the Take Me Home button.

Navigation, using the current route profile information to calculate the route, begins.

For more information, “Starting navigation” on page 57.

64 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Selecting a saved destination

The following lists of destinations and addresses are available under My Destinations.

Favorites Destinations you have stored in your NAVIGON device.
Last Destinations Destinations you have previously navigated to.

Selecting a destination from the Favorites list

Destinations to which you often travel can be saved in the FAVORITES list.
In the

FAVORITES LIST, up to 300 destinations can be saved.

Information on how to store a destination ca n be found in “Saving a destination to the
Favorites List” on page 61.

MAIN WINDOW:

In the

My Destinations

Selecting a saved destination

1. Tap

My Destinations > Favorites.

The FAVORITES WINDOW displays.

2. Tap the destination to which you would like to navigate.

3. Tap the

The map opens in Preview mode.

For more information, see “Starting navigation” on page 57.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 65

Navigation button.

NAVIGON, INC.

My Destinations

Selecting a saved destination

Selecting a destination from the Last Destinations list

Your NAVIGON device saves the last 30 destinations to which you have navigated in

LAST DESTINATIONS LIST.

the
In the

MAIN WINDOW:

1. Tap

My Destinations > Last Destinations.

The LAST DESTINATIONS WINDOW displays.

2. Tap the destination to which you would like to navigate.

3. Tap the

The map opens in

For more information, see “Starting navigation” on page 57.

66 NAVIGON 2000S | 2200T Series User’s Guide September 2008

Navigation button.

Preview mode.

NAVIGON, INC.

Routes

With the NAVIGON device, you can preplan routes. Planned routes can be saved for later
use, allowing you to create as many routes as you like.

Route calculations and arrival times are based on the type of vehicle and the rout e type.
Vehicle types (Speed Profiles) are: Standard car, Bicycle, or Pedestrian. Route types
are Fast, Short, or Optimum. For more information on these settings See “Route Profile
Settings” on page 96.

Accessing the Route Planning Window

In the MAIN WINDOW:

1. Tap the Options button.

OPTIONS LIST opens.

The

2. Tap the
The

Route Planning option.

ROUTE PLANNING WINDOW opens.

Entering the starting point

The starting point, the point at which you want to begin your trip, is required. This does not
need to be your current location. If you are at home planning a r oute for your vacatio n, you
could, for example, enter your hotel as the starting point.

The starting point is only important if you want to see a planned route on the map, but cur­rently have no GPS reception, or you are not currently at the planned starting point. The
starting point that you enter has the flow number "0".

As soon as you begin navigation, your current location is used as the starting point fo r the
route calculation.

Route calculation to the first route point is shown as flow number "1".
On the R

OUTE PLANNING WINDOW:

1. Tap the Specify Starting Point button.

STARTING POINT menu opens.

The

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 67

NAVIGON, INC.

Routes

Accessing the Route Planning Window

2. Select:

Enter an Address to search for a location address.

•

Search for a POI to search for a POI.

•

•

My Destinations to select a location from the FAVORITES or LAST DESTINATIONS

lists.

•

My Address to select your home address. (Only available if you have already

specified a home address.)

Current Location to specify your current position as the starting point.

•

3. Enter the starting point. (See the corresponding section of “Destination Selection”
on page 35.)

4. Tap the Options button.

5. Tap the Add to Route button.
The selected destination appears next to the “0”, indicating that it is the starting

point of the route.

Changing the starting point

On the ROUTE PLANNING WINDOW:

1. Tap the Specify Starting Point button.
The

STARTING POINT menu opens.

2. Select a different starting point by following the above steps.

Entering route points

Route points are destinations on the route that you want to navigate to.
The flow number for each route point can be found on a button in front of it.
On the R

1. Tap the Add Route Point field.

2. Tap on the button for the desired destination entry type.

3. Enter the route point. (See the corresponding section of “Ways to Search for Des-

4. Tap the

5. Tap Add to Route button.

6. Repeat these steps for each additional destination that you want to add to your

OUTE PLANNING WINDOW:

The

ROUTE POINT MENU opens.

tinations” on page 38.)

Options button.

The selected route point is shown next to its flow number.

route.

68 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Changing the order of route points

Route points can be deleted from a route. The order of the route points can be varied as
you wish.

Note: The starting point (flow number "0") cannot be moved or deleted. To change the
starting point, create a route point and move the new route point up to the top of the
route. The old starting point can now be moved or deleted.

Routes

Accessing the Route Planning Window

On the R

OUTE PLANNING WINDOW:

• Tap on the route point that you want to edit.

The context menu contains the following buttons:

Route Point Up Moves the selected route stage forwards.

(Example: route point 2 becomes route point 1).

Route Point Down Moves the selected route point backwards.

(Example: route point 2 becomes route point 3).

Delete Deletes the selected route point. A window

prompts you to confirm deletion.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 69

NAVIGON, INC.

Routes

Managing routes

Managing routes

You can save eac h pla nn e d ro ut e un de r a particular nam e.

Note: Only the start point and route points are saved. The calculated route is not. If you
load a route that has been saved, it must be recalculated before navigation can begin.

You can load, rename or delete stored routes.

Saving routes

You can save a route after you have entered the starting point and at least one route poin t.
On the R

1. Tap Options > Save Route.

2. Enter a name for the route.

3. Tap the Save button.
The route is saved to the

Loading routes

On the ROUTE PLANNING WINDOW:

1. Tap Options > Saved Routes.

2. Tap the route you want to load.

3. Tap the
The

ROUTE PLANNING WINDOW displays the starting point and the route points of the

selected route.

OUTE PLANNING WINDOW:

SAVED ROUTES LIST.

Load Route button.

70 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Navigation

After the route is calculated, you can begin navigation or view a simulation of the route.

Calculating and displaying routes

On the ROUTE PLANNING WINDOW:

1. Load a saved route.

- OR -

2. Enter a starting point and at least one route point.

3. Tap the
The map opens in

The starting point and the route points are marked by flags. For each stage, the
distance and the estimated trip time is given. This information is also displayed for
the entire route.

Show Route button.

Preview mode.

Routes

Navigation

4. Tap the

Navigation button or simply start driving.

Viewing or Changing the Route Profile

The calculation of a route is based on route options.
On the R

1. Create a route or load a previously saved route.

2. Tap the Show Route button.

3. Tap

OUTE PLANNING WINDOW:

The map opens in

the Route Profile button.

Preview mode and displays the calculated route.

You can view and, if necessary, change any of the displayed options.

Note: Once options are changed, they remain in effect for all subsequent routes.
You can get information regarding changing individual route profiles by tapping the cor-

responding (Help) button.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 71

NAVIGON, INC.

Routes

Simulating routes

Simulating routes

You can also view a simulation of a calculated route.

Note: GPS signal reception is not required for simulation.

Starting a route simulation

You have calculated and displayed a route.
With the route displayed in Preview mode:

•Tap Options > Simulation.
The route is recalculated for simulation purposes. Simulation begins once calcula-

tions have completed.

Ending simulation

You can end simulation at any time.
While viewing the route simulation:

•Tap (Back).
The

ROUTE PLANNING WINDOW re-displays.

72 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Viewing a Turn-by-Turn List

You can display detailed directions of the calculated route before starting navigation or at
any time during navigation. This list displays all of the driving instructions in table form.

With the route displayed in Preview mode:

• Tap the Turn-by-Turn List button.

- or -

With the route displayed in Navigation mode or Reality View mode:

•Tap Options > Tur n-By-Turn List.

TURN-BY-TURN LIST WINDOW opens.

The

Routes

Viewing a Turn-by-Turn List

1. Distance to this junction.

2. Schematic depiction of the next junction where you must turn.

3. Name of the street onto which you must turn.

4. Indicates whether you want to travel on the section of the route.

(

Allow) Include this section in the route.

Forbid) Exclude this section from the route.

(

Blocking route sections

On the TURN-BY-TURN LIST WINDOW:

1. Tap on the route section you do not want to travel on, so that the (Forbid)
symbol appears next to them.

2. Tap (
The navigation system calculates an alternative route avoiding (if possible) the

route sections selected. The new driving instructions are displayed in the

T

URN LIST WINDOW.

3. Tap (

Modify Route).

Back) to close the TURN-BY-TURN LIST WINDOW.

TURN-BY-

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 73

NAVIGON, INC.

Routes

Viewing a Turn-by-Turn List

Removing blocks and using original routes

Section blocks can be removed at anytime.
On the T

URN-BY-TURN LIST WINDOW:

•Tap Options > Calculate the Original Route.

74 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Maps

Depending on where your device was purchased, your NAVIGON device comes with
either a 48 contiguous United States map, or with a full North American map (48 con­tiguous United States, Alaska, Hawaii, Puerto Rico, Virgin Islands, and all 13 Cana­dian provinces/territories).

Forty-Eight Contiguous United States Map

North America Map

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 75

NAVIGON, INC.

Maps

View information on the current map

View information on the current map

On the MAIN WINDOW:

1. Tap

Options > Settings > Map Display.

The

MAP DISPLAY WINDOW opens.

2. Use (Next Page) to go to P

AGE TWO.

76 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Map Preview mode

You have entered a destination and tapped the Navigation button.

- OR –

Maps

Map Preview mode

Create a route or load a saved route, then tap the
The map opens in

Preview mode. The entire route is visible.

Show Route button.

1. The route is highlighted in orange.

2. A triangle in orange shows your current position.
If you display a route and the specified starting point is not the same as your cur-

rent location, the current position may not be shown on the preview.

3. The destination is marked with a small flag.
When you have planned or loaded a route and displayed it, the starting point and

each route point is marked with a small flag.

4. The remaining distance to the destination is shown. Tap the box to to ggle to dis­play the estimated time of arrival ( ) and the time remaining ( ).
If you are navigating a route with several stages, you see the remaining distance,

estimated duration of the trip, and the estimated time of arrival for the next interim
destination.

This information can be displayed or hidden by tapping on

Navigation.

Options > Settings >

If you display a route with several stages, information for each stage is shown.

Tap:

• The

Route Profile button to view or change settings used to calculate the

route.

•The

Navigation button to begin the journey.

When you display a planned or loaded route, the route may be recalculated.
St ar ti ng poi nt for t he ca lcul at ion is you r cur re nt loc atio n. Onc e th e ro ute is ca l­culated, you are guided to the first route point.

Options > Turn-by-Turn List to view detailed directions for the route. (See

•

“Viewing a Turn-by-Turn List” on page 73.)

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 77

NAVIGON, INC.

Maps

Map Preview mode

For more information on using this feature, see “Destination Search mode” on page82.

• (Destination search) to view the map in Destination search mode.

78 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Map Navigation mode

After the route has been viewed in Preview mode, navigation starts.

Maps

Map Navigation mode

Navigation is shown in

Navigation mode.

1. Signage to be followed is displayed here.

2. Posted speed limits are displayed here (where available).

3. The route is marked in orange.

4. When two maneuvers need to be executed in quick succession, the small arrow
indicates the second maneuver to be executed.

5. The large arrow shows a schematic depiction of the next maneuver. The remain­ing distance to the junction is displayed below the arrow.

As you get closer to the junction, a vertical bar appears to indicate proximity.

The nearer you get to the junction, the vertical bar fills with orange.
If you don't have to change direction for a longer period, you see only a forward-

facing arrow. The distance you travel on the road you are on displays beneath the
arrow.

• Tap the large arrow to hear current route instructions.

6. An orange triangle shows your current position. The display refreshes as you
move so that, in 3-D mode, a greater part of the screen shows the area ahead of
you.

7. The traffic lanes to be followed to your destination are shown in orange.

8. The remaining distance to the destination is shown. Tap the box to to ggle to dis­play the estimated time of arrival ( ) and the time remaining ( ).
If you are navigating a route with several stages, you see the remaining distance,

estimated duration of the trip, and the estimated time of arrival for the next interim
destination.

9. The name of the next stretch of road that you must travel on next.

10. The name of the street yo u are currently traveling on.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 79

NAVIGON, INC.

Maps

Map Navigation mode

11. (NAVIGON 2200T only) (TMC shortcut button). The TMC shortcut button
displays when traffic messages have been received and are currently available.
Tap the button to display the

Note: The displays for many of the above mentioned fields can be configured using
Options > Settings > Map Display. Information only displays when available.
Note: If you tap on the large arrow, the current route instruction is repeated.

•Tap Options > Show Turn-by-Turn List to view detailed directions for the route.

(See “Viewing a Turn-by-Tu rn List” on page 73.)

TRAFFIC INFORMATION WINDOW.

•Tap (

Destination search) to view the map in Destination Search mode.

(See “Destination Search mode” on page 82.)

•Tap (

Back) to quit navigation.

80 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Map functions in Navigation mode

When the map is open in Navigation mode , tap any point on the map. Buttons with
various functions are displayed.

2D/3D Changes between 2D and 3D map views. The symbol for the

view currently set is marked orange.

Day/Night Changes between "day" and "night" display. The symbol for

the display currently set is marked orange.

Maps

Map Navigation mode

Interim Destination Opens a menu for entering an interim destination. The naviga-

tion system first guides you to this interim destination. After­wards, you can simply continue navigation to your original
destination.

Skip Route Point Tap this button to omit the next route point. This button is inac-

tive when less than 2 route points are pending.

Block Tap this button in order to block a section of the route that lies

in front of you, that is, to recalculate the route to attempt to
avoid this section of the route, such as, if you have encoun­tered a stretch of road that is impassable due to its condition
and/or your vehicle’s capabilities.

POI on Route Tap this button to display POIs on your route. This enables you

to find out, for example, how far it is to the nearest services. A
destination shown here can be added as an interim destination

by tapping the (

Interim Destination) button to the right of

its entry in the list. The three POI categories selected for Direct
Access are available.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 81

NAVIGON, INC.

Maps

Destination Search mode

Destination Search mode

When in Destination Search mode, a pair of cross hairs are shown and the map is
always oriented with north up.

Destination search tools include:

Zoom Out The map section shown becomes larger, but fewer details

are shown.

Zoom In The map section becomes smaller, but shows more

details.

Zoom Mode When this button is active, you can plot a map section with

your finger.

Plot the map section from upper left to bottom right and it

zooms to fit the size of the screen.

Plot the map section from bottom right to top left, and the

map zooms out.

Pan Mode When this button is active, you can move the map section

with your finger. Tap on the map and drag it in the desired
direction.

Entire Route Zooms the map so that the entire route is visible.

Current Position Show your current position on the map.

82 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.

Operating in Destination Search mode

1. Tap on the point to which you wish to navigate.
The destination that you have selected appears under the cross hairs.

Maps

Destination Search mode

2. Tap (

OK).

Buttons with various functions appear.

Detailed address information for the selected destination displays in the upper left­hand corner. Tap for more information about the POI.

Take Me There Begins navigation to the selected point. If you are currently

navigating, navigation stops.

Interim Destination Sets the selected point as an interim destination. The navi-

gation system first guides you to this interim destination.
Afterwards, you can continue navigation to your original
destination.

This function is only active during navigation.

Set as Destination Sets the selected point as the destination.
Save Opens the SAVE DESTINATION AS... WINDOW. You can enter a

name for the selected point to be stored in the

FAVORITES

list.

Search Nearby Opens the POI NEARBY WINDOW. Here you can search for

destinations near the specified point. (See “POIs nearby” on
page 42.)

•Tap (

Destination search) to quit the Destination Search mode. You are

returned to the window from which you started this mode.

•Tap (

Back) to return to the MAIN WINDOW. If you are currently navigating,

you are prompted to confirm your decision to quit navigation.

September 2008 NAVIGON 2000S | 2200T Series User’s Guide 83

NAVIGON, INC.

Reality View (Junction View)

When, during navigation, you approach a highway junction, the map changes to Real-

ity View mode

Reality View mode shows the signage and lanes you must follow . This mode displays

until you pass the highway junction. Once past the junction, the map returns to

gation

mode.

While traveling through the highway junction to:

.

This page intentionally left blank.

Navi-

• Change from

• Change from

Reality View back to Navigation mode, tap anywhere on the screen.
Navigation Mode back to Reality View, tap the Next Maneuver but-

ton.

Note: Reality View mode is not available for every highway junction. Availability is
dependent on the map data currently in use.

84 NAVIGON 2000S | 2200T Series User’s Guide September 2008

NAVIGON, INC.
