Navico WIFIBT1 User Manual

CONFIDENTIAL

OEM User’s Manual

Product: Mini-PCIe 802.11 b/g/n WiFi with BT4.0 Combo
Model: SX-PCEGN-BT

For Navico integration – this device is not be sold to the
general public
FCC ID: RAYWIFIBT1
IC: 4697A-WIFIBT1

The OEM must follow the following instructions and include
the following notices as required by FCC/IC on the product

and in the User’s Manual.

(1/4)

CONFIDENTIAL

1 Integrator Instructions

This mobile single modular approval allows this Mini-PCIe 1x1 802.11 bgn WLAN with Bluetooth 4.0 module to be used as
a client in a host product without further radio intentional/un-intentional emission testing, pursuant to the following
instructions.

Allowable Antennas

The antenna(s) used in testing is listed in the test report in the public FCC database website. Use of other antennas is
allowable without further testing or submission as long as it is an identical or equivalent type with equal or lower gain.
However, antennas with higher gain must be tested and submission for approval to the FCC is required.

OEM Integrators

 Antenna to user separation must be a minimum of 20 cm for mobile applications.
 End-users must be provided with specific information required to satisfy RF exposure compliance for

the final host product.

 End-users must not have access to instructions on how to remove or install the radio.
 The antenna of this radio must not be co-located or used in conjunction with any other antenna or

transmitter.

 Compliance of this radio in all final host configurations is the responsibility of the grantee.

Date： October 18, 2014

(2/4)
