Navico VHFRS40, HS40, VHFBC12 User Manual

V60 Fixed Mount VHF
User Guide
ENGLISH
bandg.com
*988-12098-001*
Disclaimer
As Navico is continuously improving this product, we retain the right to make changes to the product at any time which may not be reflected in this version of the manual. Please contact your nearest distributor if you require any further assistance.
It is the owner’s sole responsibility to install and use the equipment in a manner that will not cause accidents, personal injury or property damage. The user of this product is solely responsible for observing safe boating practices.
NAVICO HOLDING AS AND ITS SUBSIDIARIES, BRANCHES AND AFFILIATES DISCLAIM ALL LIABILITY FOR ANY USE OF THIS PRODUCT IN A WAY THAT MAY CAUSE ACCIDENTS, DAMAGE OR THAT MAY VIOLATE THE LAW.
Governing Language: This statement, any instruction manuals, user guides and other information relating to the product (Documentation) may be translated to, or has been translated from, another language (Translation). In the event of any conflict between any Translation of the Documentation, the English language version of the Documentation will be the official version of the Documentation.
This manual represents the product as at the time of printing. Navico Holding AS and its subsidiaries, branches and affiliates reserve the right to make changes to specifications without notice.
2 |
Copyright
Copyright © 2018 Navico Holding AS.
Warranty
The warranty card is supplied as a separate document.
In case of any queries, refer to the brand website of your unit or system: www.bandg.com
Regulatory Compliance Statements
European Union
Hereby, Navico Holding AS declares that the radio equipment type V60 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.bandg.com
| V60 User Guide
United States
Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Warning
The user is cautioned that any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
RF Emissions notice
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device’s antenna must be installed in accordance with provided instructions; and it must be operated with minimum 2 m spacing between the antennas and all person’s body (excluding extremities of hands, wrist and feet) during operation. Further, this transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
¼ Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio commu­nications. However, there is no guarantee that the interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that of the receiver is connected.
Consult the dealer or an experienced technician for help.
| V60 User Guide
| 3
Canada
This device complies with CAN ICES-3(B)/NMB-3(B) and contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s license­exempt RSS(s). Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that
may cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes:
1. L’appareil ne doit pas produire de brouillage.
2. L’appareil doit accepter tout brouillage radioélectrique subi, même si
le brouillage est susceptible d’en compromettre le fonctionnement.
Industry Canada Statement
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with minimum distance 2 m between the radiator and your body.
Cet équipement est conforme aux limites d’exposition aux radiations IC CNR-102 établies pour un environnement non contrôlé. Cet émetteur ne doit pas conjointement avec une autre antenne ou un autre émetteur. Cet équipement doit être installé et utilisé avec une distance minimale de 2 m entre le radiateur et votre corps.
être situé ou fonctionner
4 |
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
Conformément à la réglementation d’Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d’un type et d’un gain maximal (ou inférieur) approuvé pour l’émetteur par
| V60 User Guide
Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l’intention des autres utilisateurs, il faut choisir le type d’antenne et son gain de sorte que la puissance isotrope rayonnée quivalente (p.i.r.e.) ne dépassepas l’intensité nécessaire à l’établissement d’une communication satisfaisante.
This radio transmitter (V60) has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
Le présent émetteur radio (V60) a été approuvé par Industrie Canada pour fonctionner avec les types d’antenne énumérés ci­dessous et ayant un gain admissible maximal et l’impédance requise pour chaque type d’antenne. Les types d’antenne non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l’exploitation de l’émetteur.
Australia & New Zealand
Complies with the requirements of level 2 devices of the Radiocommunications (Electromagnetic Compatibility) standard 2017 and Radiocommunications (VHF Radiotelephone Equipment – Maritime Mobile Service) Standard 2014.
Countries of intended use in the EU
AT - Austria HU - Hungary PL - Poland
BE - Belgium IS - Iceland PT - Portugal
BG - Bulgaria IE - Ireland RO - Romania
CY - Cyprus IT - Italy SK - Slovak Republic
CZ - Czech Republic LV - Latvia SI - Slovenia
DK - Denmark LI - Liechtenstein ES - Spain
EE - Estonia LT - Lithuania SE - Sweden
FI - Finland LU - Luxembourg CH - Switzerland
FR - France MT - Malta TR - Turkey
DE - Germany NL - Netherlands UK - United Kingdom
GR - Greece NO - Norway
| V60 User Guide
| 5
Trademarks
!
B&G® and Navico® are registered trademarks of Navico.
NMEA® and NMEA 2000® are registered trademarks of the National Marine Electronics Association.
Navico recommends that you check the radio operating licensing requirements of your country before using this VHF radio. The operator is solely responsible for observing proper radio installation and usage practices.
Notes on MMSI and DSC
The user MMSI (Marine Mobile Service Identity) is a unique nine digit number. It is used on marine transceivers that are capable of using DSC (Digital Selective Calling). Digital Selective Calling offers significant safety and convenience advantages over older VHF radios without this functionality.
¼ Note: Many countries do not have radio repeaters that support DSC
message relaying. However DSC can still be useful for direct ship-to­ship communication, where the other vessel is also equiped with a DSC capable radio.
You must obtain a user MMSI and enter it into your radio in order to use the DSC functions. Contact the appropriate authorities in your country to obtain an MMSI number - charges may apply. If you are unsure who to contact, consult your B&G dealer.
¼ Note: DSC distress calls generated by this radio are limited to the
same range restrictions that apply to regular VHF transmissions. The vessel sending a distress can only rely upon DSC if within range of a GMDSS Coast Radio Station. Typical VHF range may be about 20NM, though this varies greatly depending upon installation, antenna type, meteorological conditions, etc.
About this manual
This manual is a reference guide for installing and operating a V60 VHF radio. Important text that requires special attention from the reader is emphasized as follows:
¼ Note: Used to draw the reader’s attention to a comment or some
important information.
Warning: Used when it is necessary to warn personnel that
they should proceed carefully to prevent risk of injury and/or damage to equipment/personnel.
6 |
| V60 User Guide
Contents
9 General Information
10 How to display and navigate menus 13 Key functions
19 Radio menus
19 Scan 20 Watch 21 Display 22 Radio setup 26 DSC setup 28 AIS setup 29 Alarms 30 Wireless handset 31 R eset
32 DSC call menu
32 DSC calls 35 Track buddy 36 Contacts
37 AIS menu
37 About AIS 38 Using the AIS receiver 38 AIS information and display
41 Hailer / Fog Horn / Intercom
41 Using the Hailer (PA) function 42 Using the FOG Horn 42 Using the Intercom
43 Wireless handset
43 Using the wireless handset 43 Using the Intercom
Contents | V60 User Guide
| 7
44 My channels
45 Shortcuts
46 Installation
46 Checklist 47 Installation options 47 Selecting a suitable mounting location 53 First startup configuration
56 Specications
60 Channel charts
60 EU and INTERNATIONAL channel chart 68 USA channel chart 70 CANADA channel chart
73 Dimensional drawings
73 V60 fixed mount VHF 74 V60 hand mic 75 H60 cradle 76 H60 wireless handset
8 |
77 NMEA 2000 compliant PGN list
Contents | V60 User Guide
1
General Information
Your V60 provides the following useful features:
AIS dual channel receiver to receive and display AIS targets
Ability to communicate with up to 2 optional wireless handsets (H60)
6-key removable handset microphone with built-in speaker. Can be
front or rear connected to the radio with optional extension cable
Built-in GPS receiver and antenna with connection for optional
external GPS antenna
Intercom, Fog Horn and Hailer functions
NAV/MOB key to display dedicated navigation or Man Over Board
screens
TRI key to select DUAL/TRI scan
Dedicated Wx (Weather) key
Favourite channels list to build your list of commonly used channels
Shortcuts list to build your list of commonly used radio features
Access to all currently-available marine VHF channel banks (USA,
Canada, International) including weather channels where available (model dependant)
Dedicated CH16/9 key for quick access to the priority (international
distress) channel
DSC (Digital Selective Calling) capability that meets Global DSC Class
D Standards
DISTRESS call button to automatically transmit the MMSI and
position until an acknowledgement is received
ATIS facility for inland waterways (EU mode)
With DSC Auto-Switch disable and DSC Test function
Contacts list that stores up to 50 names with MMSI numbers
MMSI storage for one favourite group
Group Call and All Ships Call facility
Weather alert facility where available (US mode)
Prominent channel display
Adjustable contrast settings for the LCD
Adjustable keypad backlighting for easy night-time use
Waterproof and submersible to comply with IPx7
Choice of High (25 W) or Low (1 W) transmission power
Powerful 4 W external audio output
GPS latitude and longitude (LL) and time display (with valid GPS
source)
LL position polling information.
General Information | V60 User Guide
| 9
How to display and navigate menus
1
4
1. Split screen display – showing Main menu.
2. Split screen display – showing Channel screen.
3. Scroll bar indicates additional options above and below displayed
text.
4. Current menu item is selected using the channel knob.
5. Arrow indicates additional sub-menu items in this menu option.
¼ Note: Press the X button to step backwards to the previous menu
page, or exit the menus completely.
3
2
5
Entry of alphanumeric data
Rotate the channel knob to scroll through the alphanumeric characters.
Press channel knob, to select and step to the next character.
To step backwards, press the MENU button. Press X to cancel entry and return to previous menu.
10 |
LCD symbols and meanings
When the V60 starts up it momentarily displays the brand, model, region, software version, and MMSI.
General Information | V60 User Guide
Symbol Meaning
Radio is transmitting
Receiver busy with incoming signal
Low Transmit power selected (1W)
High Transmit power selected (25W)
Current channel is Duplex (off when Simplex)
Current channel is receive only
Local mode enabled (used when in areas of high radio traffic, i.e. inner harbour)
Channel is saved as a favourite
Channel will be skipped during a scan
Weather channel stored by user (EU & INT only)
Channel bank is set to USA Channel bank is set to International. (Channels available depends on selected
Country mode) Channel bank is set to Canada
EU models only - must be enabled when in European inland waterways
During normal operation, the following icons may be displayed on the screen depending on setup:
DSC functionality is enabled
DSC functionality is enabled, auto switch is turned off
AIS function is enabled
Internal GPS is enabled, with valid 3D fix
Internal GPS is enabled, no fix
External GPS is enabled, with valid 3D fix
External GPS is enabled, no fix
Weather alert enabled (USA/CAN only)
Missed DSC call
Low Battery (vessel) warning (activates at 10.5 V)
Battery level (wireless handset)
Track your Buddy feature is active
Current channel is selected as the Watch channel
GPS simulator is active
General Information | V60 User Guide
| 11
A typical display:
3 6
4
2 1 18 15 19 17 16 14 13
24 5 12
23
8
9 22 21 20 10
1. Channel is set to high power transmit
2. Missed call in the DSC call log
3. Channel is busy
4. Volume is under active control
5. Current channel saved in ‘My Channels’
6. Track your buddy is enabled
7. Current channel will be skipped during a scan
8. Volume level indicator
9. Time (derived from GPS) - UTC offset is applied
10. Latitude/Longitude
11. Squelch level indicator
12. Channel number (2 or 4 digits)
13. The USA channel bank is active
14. DSC functionality is enabled, but autoswitch is off
15. Weather alert function is enabled
16. Internal GPS is enabled, with 3D fix
17. AIS receiver is enabled
18. Low vessel voltage alert
19. Sensitivity mode is set to LOCAL
20. Current channel is Duplex
21. GPS Simulate mode is active
22. Current channel is set as the Weather channel (use Wx key to select)
23. Current channel is set as the Watch channel (use TRI key to select)
24. MOB waypoint is active.
7 11
12 |
General Information | V60 User Guide
Key functions
The following describes the direct functions of the keys/knobs. Where necessary, additional detail on any menus accessed by keys is covered in following chapters.
4
1
5
7
3
2
8 9 10 11 12 13 18
13
17
5
10
4
19
24
17
24
12 15 20 21 11
15
9
12
23
22
6
15
14 1616 19
1. Channel knob / Press to Select
Tur n knob for channel selection, menu scrolling, alphanumeric entry, and fine adjustment of backlight level (dependent on active menu).
Short press to make selections in menus. Long press to open MY CHANNELS.
2. VOL / SQL
Volume and Squelch level. Short press knob to select which control to adjust. Which is currently selected is indicated by a small triangular arrow above the level bar for each option. Turning the knob clockwise increases setting, anti-clockwise decreases it. Volume control is common to
General Information | V60 User Guide
| 13
internal and external speaker. Long press to open SHORTCUTS.
3. X (EXIT)
Press X when navigating menus, to clear incorrect entries, to exit from a menu without saving changes, and to back up to the previous screen.
4. DSC CALL / MENU SELECT (Radio and wireless handset)
Short press to enter the DSC Call Menu and make DSC calls. Long press to open the MENU SELECT page.
5. AIS / IC (Radio and wireless handset)
Short press to enter the AIS (Automatic Identification System) mode. See page 28 for AIS setup or page 28 for AIS functionality. Long press to enter Intercom / Hailer / Fog Horn mode. See page 43 for Intercom functionality and page 41 for Fog Horn / Hailer functionality.
6. Zoom keys
Used in AIS mode. Press TRI (zoom in) or SCAN (zoom out) to change the scale of the AIS plotter. The scales available are: 1, 2, 4, 8, 16, 32 nm.
7. Power / Backlight
Short Press to adjust backlight level sequentially. Repeated short press of the power button will step through large
backlight adjustments. The Channel knob can be used to make finer adjustments. Long press to turn radio on or off.
14 |
8. NAV / MOB
Short press to enter the NAV (Navigation) mode. The screen will change to navigation mode displaying the vessel’s current SOG and COG.
Press X to exit NAV mode and return to normal radio operation mode. Long press to mark the current location with a Man-Over-Board (MOB) waypoint. The screen will change to MOB navigation mode to
General Information | V60 User Guide
help navigate back to the MOB location:
DST (Distance to MOB waypoint). BTW (Bearing to MOB waypoint) and direction indicators using for
turn to port, for straight ahead and for turn to stbd (starboard).
Long press the X button to exit MOB navigation. A pop up screen will appear with 2 choices:
1. KEEP CURRENT MOB: to return to normal operation mode without cancelling MOB navigation.
2. CANCEL CURRENT MOB: to cancel current MOB navigation and return to normal radio operation mode. Or, short press X to close the pop up and resume current MOB navigation.
Long press NAV/MOB to set a new MOB waypoint at the current location. A pop up screen will appear with 2 choices:
1. RESUME CURRENT MOB: to close pop up and resume current MOB navigation.
2. CREATE NEW MOB: to cancel current MOB navigation and create a
General Information | V60 User Guide
| 15
new Man-Over-Board (MOB) waypoint at the current location. Or, short press X to close the pop up and resume current MOB navigation.
¼ Note: Long press TRI and SCAN keys on the wireless handset to set a
MOB waypoint.
9. Weather Channel (Radio and wireless handset)
Short press (US/CAN models): press to hear the most recently selected NOAA/Canadian weather station. For all other models, changes channel to user programmed choice. Long press (non US/CAN models): to store current channel as the weather channel.
10. SCAN / ZOOM- (Radio and wireless handset)
Normal radio mode:
Short press to enter ALL SCAN mode. ALL SCAN sequentially scans all channels for activity. When a signal is received, scanning stops at that channel and the BUSY icon appears on the screen. If the signal ceases for more than 5 seconds, the scan automatically resumes. Turn the channel knob to temporarily skip over (lock out) a busy channel and resume the scan. The direction turned determines if the scan goes up or down the channel numbers (ie ‘forward’ or ‘reverse’). If it is still busy when the scan completes a full cycle, it will stop again at this channel. Note that it is not possible to skip over the priority channel. Press ENT to permanently skip over the channel. The SKIP icon will show on the LCD for this channel. To cancel a skipped channel, select the channel while in normal mode (non-scan mode) then press the ENT key - the SKIP icon will disappear. Repowering the radio also restores all skipped channels. Press SCAN or X while scanning is active to stop at the current channel and return to normal operation. Long press SCAN from normal operation to enter the SCAN menu.
AIS mode: Short press to increase (zoom out) the scale of the AIS plotter out one range at a time. The scales available are: 1, 2, 4, 8, 16, 32 nm.
11. TRI / ZOOM+ (Radio and wireless handset)
Normal radio mode:
Short press to start DUAL WATCH or TRI WATCH (if ‘watch’ channel set). Long press to set the current channel as the watch channel. When a short press is made on the TRI key, the radio will either
16 |
General Information | V60 User Guide
switch to DUAL or TRI watch mode depending on whether a watch channel has been setup. Without a watch channel the radio will go to DUAL WATCH, where the channels ‘watched’ are the current channel and the priority channel (the distress channel, CH16 for most countries). With a watch channel selected, TRI WATCH is enabled, where the channels ‘watched’ are the current channel the ‘watch’ channel, and the priority channel (the distress channel, CH16 for most countries). If the radio is set to ‘Country: USA’, two priority channels are watched
- Channel 9 and Channel 16.
AIS mode: Short press to reduce (zoom in) the scale of the AIS plotter out one range at a time. The scales available are: 1, 2, 4, 8, 16, 32 nm.
12. 16 / 9 (Radio, handset mic and wireless handset)
Short press to change to priority channel. Press again to return to original channel. The default Priority Channel is CH16. For US models: Long press to make Channel 09 the priority channel.
13. DISTRESS (Radio and wireless handset)
Short press to start a distress call, where the nature of distress can be selected from a list. Long press the distress button to initiate an ‘undesignated’ distress call. The Distress call is broadcast to all DSC equipped radios, so will create an alarm on every DSC radio within range. If position information is available it will be included in the transmition.
14. H/L (Transmission power) (Handset mic only)
Press to toggle between high (25 W) or low (1 W) transmission
power for the entire channel bank. The HI or LO selection is shown on the LCD. Some channels allow only low power transmissions. Error beeps will sound if attempting to change the transmission power while on one of these channels. Some channels allow only low power transmissions initially, but can be overridden to high power by pressing (and holding) H/L after depressing PTT. Keep the H/L button pressed down after releasing the PTT button, if wanting to transmit again on high power.
15. Channel change (Handset mic and wireless handset)
Short press () goes up one channel, or () goes down one
channel. Holding either key will, after a short delay, step rapidly through the channels.
General Information | V60 User Guide
| 17
16. VOL +/- (Volume) (Handset mic only)
Change the volume on the handset microphone. Short press (+) increases the volume, or (-) decreases the volume.
17. PTT (Push-to-talk) (Handset mic and wireless handset)
Press button to transmit. Only depress for duration of message to be
broadcast. Radio can’t receive while it is transmitting.
18. Handset microphone (front) connection. Plug in the removable
handset microphone. Alternatively, it can be connected to the rear of the radio.
19. MIC (Microphone) (Handset mic and wireless handset)
The microphone can be connected to the front MIC connector or rear MIC connector. An optional 5 m or 10 m extension cable is available for mounting the microphone in a different location.
20. POWER / EXIT (Wireless handset)
Short press to EXIT when navigating menus, to clear incorrect entries, to exit from a menu without saving changes, and to back up to the previous screen. Long press to turn radio on or off.
21. OK / H/L (Wireless handset)
Short press to make selections in menus. Long press to change transmission power - see item 14.
22. VOL / SQL (Wireless handset)
Short press to select which control (Volume and Squelch) to adjust. Use the + & - buttons to adjust.
18 |
23. +/- (Wireless handset)
Short press to adjust the selected control (Volume and Squelch).
24. LCD (Display) (Radio and wireless handset)
General Information | V60 User Guide
2
Radio menus
A long press of the MENU button opens MENU SELECT page. The following shows the menu structure (top and 2nd level only):
ALL SCAN ALL CHANNELS + 16
SCAN
WATC H
DISPLAY
RADIO SETUP
DSC SETUP
AIS SETUP
ALARMS
WIRELESS HS
RESET
MY CHANNELS MY CHANNELS + 16 EDIT MY CHANNELS (choose channels)
DUAL WATCH TRI WATCH SET WATCH CHANNEL (choose channel)
TIME DISPLAY (ON / OFF) POS DISPLAY (ON / OFF) COG/SOG (ON / OFF) BACKLIGHT (>) CONTRAST (0-10)
SENSITIVITY (DISTANT/LOCAL) UIC (USA/INT’L/CANADA) POWER OUTPUT (HIGH/LOW) CH NAME (>) KEY BEEP (0-10) UNITS (>) INT SPEAKER (ON/OFF) EXT SPEAKER (ON/OFF) GPS (>) COM PORT (>) TIME (>) VESSEL CALLSIGN (>) AUTO POWER ON (AUTO/MANUAL) MENU TIMEOUT (>)
DSC FUNCTION (X) USER MMSI (>) ATIS FUNCTION (ON/OFF) SEA/INLAND USE (SEA/INLAND) ATIS ID (>) INDIVIDUAL ACKN. (AUTO/MANUAL) POS ACKNOWLEDGE (>) AUTO SWITCH (ON/OFF) TEST ACKNOWLEDGE (AUTO/MANUAL) RX DISTR WHILE OFF ( X) DSC TIMEOUT (>)
AIS FUNCTION (X) AIS DISPLAY (MMSI/NAME) CPA (>) TCPA (>)
GPS ALERT (>) WX ALERT (>) DSC ALARM (>) CPA ALARM (>)
PAIR A HANDSET (>) REMOVE A HANDSET (>)
(YES/CANCEL)
(EU mode) (EU mode) (EU mode)
(US/CAN mode)
Key:
(>) further menu options
(X) toggle selection. ‘X’ means option enabled.
Scan
This menu is for choosing a scan mode to enable, as well as selection of the channels scanned per the MY CHANNELS list.
¼ Note: Scanning is not available if ATIS mode is turned on.
Radio menus | V60 User Guide
| 19
All scan
Scans all channels cyclically.
All channels + 16
Scans all channels cyclically, but checks the priority channel after every channel step.
My channels
Scan all channels selected in EDIT MY CHANNELS.
My channels + 16
Scans all channels selected in EDIT MY CHANNELS, while also checking the priority channel after every channel step.
Edit my channels
Allows creation of a custom list of channels - used in a MY CHANNELS scan.
20 |
Watch
This menu is for choosing a watch mode to enable, as well as selection of the watch channel. Watch modes can be thought of as a channel scan on a subset of channels, where scanned channels are ‘listened’ to briefly every 3 seconds, to determine if there is any active radio communication.
¼ Note: Watch modes are not available if ATIS mode is turned on.
Dual watch
Select this to watch the current channel and the priority channel (Channel 16).
Radio menus | V60 User Guide
TRI watch
Select this to watch the current channel, the user selected ‘watch’ channel, and the priority channel (Channel 16).
Set Watch Channel
Allows a watch channel to be selected from all available channels. Selected channel is used by TRI WATCH mode.
¼ Note: If the radio is configured for USA market, two priority channels
are watched: Channel 9 and Channel 16.
Display
This menu allows the user to partially customize the screen information displayed, and adjust the screen for best visibility to suit the user and operating conditions.
Time display
Select to switch the display of Time to ON or OFF. If turned ON, the display of COG/SOG is turned off, due to screen space constraints.
LOC (Local Time) is displayed below the time if a UTC (Coordinated Universal Time) offset has been entered; otherwise UTC is shown in it’s place if no offset has been applied.
POS display
Select to switch ON or OFF the display of position provided from connected GPS. If no GPS is connected and a manual entry has
been made, the position will be displayed prefixed with an ‘M‘.
COG/SOG
Select to switch ON or OFF the display of COG/SOG provided from the selected GPS source.
If turned ON, Time display is turned OFF, due to screen space constraints.
Backlight
Backlight level
Select to make adjustment to the backlight level using the Channel knob. Range is OFF, then 1 to 10.
Press MENU SELECT button to activate night mode (inverts display).
Radio menus | V60 User Guide
| 21
Network group
Set this value to the same as other B&G devices on NMEA 2000 in order to control backlight levels simultaneously. To keep backlight control inpedenent, set to a value not used elsewhere.
Contrast
Select to make adjustment of the screens contrast, using the Channel knob. Range is 00 to 10.
Radio setup
The Radio setup menu covers settings that are typically configured at installation, and seldom need changing.
Sensitivity
Use LOCAL/DISTANT to improve the sensitivity of the receiver either locally (LOCAL) or over distances (DISTANT).
LOCAL is not recommended for use in open sea conditions. It is designed for use in areas of high radio noise; for example, close to a busy port or city.
UIC
Select between USA, INT (International) or CAN (Canadian) channel banks. The selected channel bank is displayed on the LCD along with the last used channel. All the channel charts are shown in chapter 11.
22 |
¼ Note: UIC is not available on all models.
Power output
Select to toggle between HI (25 W) or LO (1 W) transmission power for the entire channel bank. The or is shown on the LCD, depending on your selection. Low power transmission draws significantly less current (about 1/4) from the battery, so is recommended for short range communication, and where battery capacity is limited.
¼ Note: Some channels can’t be switched to high power, and will
show LO regardless of power output setting in menu.
CH name
CH NAME gives you the option to edit or delete the channel name descriptions displayed on the screen. Select to edit the existing
Radio menus | V60 User Guide
description of the channel currently in use. It can be a maximum of 12 characters long.
Key beep
Select to allow adjustment of key beep volume.
Volume can be set from 00 - 10 (where 00 is off, and 10 is loudest).
Units
Select SPEED to choose whether displayed in KNOTS, MPH, or KPH.
Select COURSE to toggle between displaying in MAGNETIC or TRUE. A true north heading is corrected for magnetic variation. A magnetic north heading source must also output magnetic variation data if the heading is to be displayed as a true north value.
Int speaker
Select to switch the radio’s internal speaker ON or OFF.
Ext speaker
Select to switch the radio’s external speaker ON or OFF.
GPS
Manual
Select MANUAL to enter a GPS position (and time) from another source when radio is not receiving position data from an internal or networked source. The manually entered GPS position can be used in DSC calls.
If POS Display is turned ON, the latitude and longitude are shown on the screen with a prefix ‘M’ indicating manual entry.
¼ Note: The manual entry is automatically replaced when a real GPS
position is received via the NMEA 0183, NMEA 2000 or Internal GPS, depending on the GPS SOURCE setting.
GPS source
Choose NMEA 2000 for GPS via NMEA 2000 network. A list of
available devices installed on your NMEA 2000 network will be
Radio menus | V60 User Guide
| 23
Loading...
+ 55 hidden pages
