Page 1
INTERNATIONAL
products meet or exceed
applicable BIFMA standards
products meet or exceed
applicable ANSI standards
INTERNATIONAL
products meet
or exceed applicable
ANSI/BIFMA standards
8"
16"
24"
32"
96"
18"
72"
78 1/2"
78 1/2"
RS · RT Series
10
ten year
warranty
MODEL RS3LC SHOWN
MODEL RS8C SHOWN
CHORAL RISERS
MODEL RS4LHB SHOWN
MODEL RS2LC SHOWN
JOINED TAPERED
STANDING RISERS
WITH OPTIONAL
GUARD RAILS
m
m
o
c
i
t
&
m
e
e
t
n
a
r
a
u
g
s
p
n
e
h
t
e
n
t
t
o
e
x
c
e
l
l
e
n
c
e
SPECS:
· Constructed with 3/4” solid plywood core
· Available with carpet in choice of 4 colors or 1/8”
thick tempered hardboard
· 16-gauge, 1-13/16” high formed steel channel frame
reinforced with 16-gauge steel angle welded to the
inside of the channel
· 14-gauge steel tubing capped at the point of floor
contact with high impact plastic glides
· Legs open and close using only one hand
· Equipped with drop-in couplings that allow units
of same or different heights to be joined together
· All ganging devices are per manently secured
to each unit
· Exceeds 200 lbs. per square foot load
bearing capacity
· Comes in 4 heights; 8”, 16”, 24” and 32”
· Straight and Tapered units for continuous
and semi-circle configurations
· Optional Guardrails recommended for safety
· 10-year warranty
CARPET COLOR OPTIONS
Box Pleat Skirting
MODEL SB8 SHOWN
Shirred Pleat Skirting
MODEL SS8 SHOWN
BLACK
BLUE
GREY
RED
Standing Choral Riser
SKIRTING COLOR OPTIONS
USE WITH:
Side Guard Rail
For Standing
Risers
Guard Rail
For Risers
NAVYBURGUNDYBLACK GREEN
800.261.4112 | www.nationalpublicseating.com
