TPC-2012/TPC-2512
User Manual
TPC-2012/TPC-2512 User Manual
July 2008
372052C-01
Support
Worldwide Technical Support and Product Information
ni.com
National Instruments Corporate Headquarters
11500 North Mopac Expressway Austin, Texas 78759-3504 USA Tel: 512 683 0100
Worldwide Offices
Australia 1800 300 800, Austria 43 662 457990-0, Belgium 32 (0) 2 757 0020, Brazil 55 11 3262 3599,
Canada 800 433 3488, China 86 21 5050 9800, Czech Republic 420 224 235 774, Denmark 45 45 76 26 00,
Finland 358 (0) 9 725 72511, France 01 57 66 24 24, Germany 49 89 7413130, India 91 80 41190000,
Israel 972 3 6393737, Italy 39 02 41309277, Japan 0120-527196, Korea 82 02 3451 3400,
Lebanon 961 (0) 1 33 28 28, Malaysia 1800 887710, Mexico 01 800 010 0793, Netherlands 31 (0) 348 433 466,
New Zealand 0800 553 322, Norway 47 (0) 66 90 76 60, Poland 48 22 3390150, Portugal 351 210 311 210,
Russia 7 495 783 6851, Singapore 1800 226 5886, Slovenia 386 3 425 42 00, South Africa 27 0 11 805 8197,
Spain 34 91 640 0085, Sweden 46 (0) 8 587 895 00, Switzerland 41 56 2005151, Taiwan 886 02 2377 2222,
Thailand 662 278 6777, Turkey 90 212 279 3031, United Kingdom 44 (0) 1635 523545
For further support information, refer to the Technical Support and Professional Services appendix. To comment
on National Instruments documentation, refer to the National Instruments Web site at
the info code
feedback.
ni.com/info and enter
© 2006–2008 National Instruments Corporation. All rights reserved.
Important Information
Warranty
The TPC-2012 and TPC-2512 are warranted against defects in materials and workmanship for a period of one year from the date of shipment,
as evidenced by receipts or other documentation. National Instruments will, at its option, repair or replace equipment that proves to be defective
during the warranty period. This warranty includes parts and labor.
The media on which you receive National Instruments software are warranted not to fail to execute programming instructions, due to defects in
materials and workmanship, for a period of 90 days from date of shipment, as evidenced by receipts or other documentation. National Instruments
will, at its option, repair or replace software media that do not execute programming instruc tions if National Instruments receives notice of such defects
during the warranty period. National Instruments does not warrant that the operation of the software shall be uninterrupted or error free.
A Return Material Authorization (RMA) number must be obtained from the factory and clearly marked on the outside of the package before any
equipment will be accepted for warranty work. National Instruments will pay the shipping costs of returning to the owner parts which are covered by
warranty.
National Instruments believes that the information in this document is accurate. The document has been carefully reviewed for technical accuracy. In
the event that technical or typographical errors exist, National Instruments reserves the right to make changes to subsequent editions of this document
without prior notice to holders of this edition. The reader should consult National Instruments if errors are suspected. In no event shall National
Instruments be liable for any damages arising out of or related to this document or the information contained in it.
E
XCEPT AS SPECIFIED HEREIN, NATIONAL INSTRUMENTS MAKES NO WARRANTIES, EXPRESS OR IMPLIED, AND SPECIFICALLY DISCLAIMS ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. CUSTOMER’S RIGHT TO RECOVER DAMAGES CAUSED BY FAULT OR NEGLIGENCE ON THE PART OF NATIONAL
I
NSTRUMENTS SHALL BE LIMITED TO THE AMOUNT THERETOFORE PAID BY THE CUSTOMER. NATIONAL INSTRUMENTS WILL NOT BE LIABLE FOR DAMAGES RESULTING
FROM LOSS OF DATA, PROFITS, USE OF PRODUCTS, OR INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF ADVISED OF THE POSSIBILITY THEREOF. This limitation of
the liability of National Instruments will apply regardless of the form of action, whether in contract or tort, including negligence. Any action against
National Instruments must be brought within one year after the cause of action accrues. National Instruments shall not be liable for any delay in
performance due to causes beyond its reasonable control. The warranty provided herein does not cover damages, defects, malfunctions, or service
failures caused by owner’s failure to follow the National Instruments installation, operation, or maintenance instructions; owner’s modification of the
product; owner’s abuse, misuse, or negligent acts; and power failure or surges, fire, flood, accident, actions of third parties, or other events outside
reasonable control.
Copyright
Under the copyright laws, this publication may not be reproduced or transmitted in any form, electronic or mechanical, including photocopying,
recording, storing in an information retrieval system, or translating, in whole or in part, without the prior written consent of National
Instruments Corporation.
National Instruments respects the intellectual property of others, and we ask our users to do the same. NI software is protected by copyright and other
intellectual property laws. Where NI software may be used to reproduce software or other materials belonging to others, you may use NI software only
to reproduce materials that you may reproduce in accordance with the terms of any applicable license or other legal restriction.
Trademarks
National Instruments, NI, ni.com, and LabVIEW are trademarks of National Instruments Corporation. Refer to the Terms of Use section
on
ni.com/legal for more information about National Instruments trademarks.
Other product and company names mentioned herein are trademarks or trade names of their respective companies.
Members of the National Instruments Alliance Partner Program are business entities independent from National Instruments and have no agency,
partnership, or joint-venture relationship with National Instruments.
Patents
For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file
on your media, or ni.com/patents.
WARNING REGARDING USE OF NATIONAL INSTRUMENTS PRODUCTS
(1) NATIONAL INSTRUMENTS PRODUCTS ARE NOT DESIGNED WITH COMPONENTS AND TESTING FOR A LEVEL OF
RELIABILITY SUITABLE FOR USE IN OR IN CONNECTION WITH SURGICAL IMPLANTS OR AS CRITICAL COMPONENTS IN
ANY LIFE SUPPORT SYSTEMS WHOSE FAILURE TO PERFORM CAN REASONABLY BE EXPECTED TO CAUSE SIGNIFICANT
INJURY TO A HUMAN.
(2) IN ANY APPLICATION, INCLUDING THE ABOVE, RELIABILITY OF OPERATION OF THE SOFTWARE PRODUCTS CAN BE
IMPAIRED BY ADVERSE FACTORS, INCLUDING BUT NOT LIMITED TO FLUCTUATIONS IN ELECTRICAL POWER SUPPLY,
COMPUTER HARDWARE MALFUNCTIONS, COMPUTER OPERATING SYSTEM SOFTWARE FITNESS, FITNESS OF COMPILERS
AND DEVELOPMENT SOFTWARE USED TO DEVELOP AN APPLICATION, INSTALLATION ERRORS, SOFTWARE AND HARDWARE
COMPATIBILITY PROBLEMS, MALFUNCTIONS OR FAILURES OF ELECTRONIC MONITORING OR CONTROL DEVICES,
TRANSIENT FAILURES OF ELECTRONIC SYSTEMS (HARDWARE AND/OR SOFTWARE), UNANTICIPATED USES OR MISUSES, OR
ERRORS ON THE PART OF THE USER OR APPLICATIONS DESIGNER (ADVERSE FACTORS SUCH AS THESE ARE HEREAFTER
COLLECTIVELY TERMED “SYSTEM FAILURES”). ANY APPLICATION WHERE A SYSTEM FAILURE WOULD CREATE A RISK OF
HARM TO PROPERTY OR PERSONS (INCLUDING THE RISK OF BODILY INJURY AND DEATH) SHOULD NOT BE RELIANT SOLELY
UPON ONE FORM OF ELECTRONIC SYSTEM DUE TO THE RISK OF SYSTEM FAILURE. TO AVOID DAMAGE, INJURY, OR DEATH,
THE USER OR APPLICATION DESIGNER MUST TAKE REASONABLY PRUDENT STEPS TO PROTECT AGAINST SYSTEM FAILURES,
INCLUDING BUT NOT LIMITED TO BACK-UP OR SHUT DOWN MECHANISMS. BECAUSE EACH END-USER SYSTEM IS
CUSTOMIZED AND DIFFERS FROM NATIONAL INSTRUMENTS' TESTING PLATFORMS AND BECAUSE A USER OR APPLICATION
DESIGNER MAY USE NATIONAL INSTRUMENTS PRODUCTS IN COMBINATION WITH OTHER PRODUCTS IN A MANNER NOT
EVALUATED OR CONTEMPLATED BY NATIONAL INSTRUMENTS, THE USER OR APPLICATION DESIGNER IS ULTIMATELY
RESPONSIBLE FOR VERIFYING AND VALIDATING THE SUITABILITY OF NATIONAL INSTRUMENTS PRODUCTS WHENEVER
NATIONAL INSTRUMENTS PRODUCTS ARE INCORPORATED IN A SYSTEM OR APPLICATION, INCLUDING, WITHOUT
LIMITATION, THE APPROPRIATE DESIGN, PROCESS AND SAFETY LEVEL OF SUCH SYSTEM OR APPLICATION.
Compliance
Compliance with FCC/Canada Radio Frequency Interference
Regulations
Determining FCC Class
The Federal Communications Commission (FCC) has rules to protect wireless communications from interference. The FCC
places digital electronics into two classes. These classes are known as Class A (for use in industrial-commercial locations only)
or Class B (for use in residential or commercial locations). All National Instruments (NI) products are FCC Class A products.
Depending on where it is operated, this Class A product could be subject to restrictions in the FCC rules. (In Canada, the
Department of Communications (DOC), of Industry Canada, regulates wireless interference in much the same way.) Digital
electronics emit weak signals during normal operation that can affect radio, television, or other wireless products.
All Class A products display a simple warning statement of one paragraph in length regarding interference and undesired
operation. The FCC rules have restrictions regarding the locations where FCC Class A products can be operated.
Consult the FCC Web site at
FCC/DOC Warnings
This equipment generates and uses radio frequency energy and, if not installed and used in strict accordance with the instructions
in this manual and the CE marking Declaration of Conformity*, may cause interference to radio and television reception.
Classification requirements are the same for the Federal Communications Commission (FCC) and the Canadian Department
of Communications (DOC).
Changes or modifications not expressly approved by NI could void the user’s authority to operate the equipment under the
FCC Rules.
Class A
Federal Communications Commission
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user is required to correct the interference
at their own expense.
www.fcc.gov for more information.
Canadian Department of Communications
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
Compliance with EU Directives
Users in the European Union (EU) should refer to the Declaration of Conformity (DoC) for information* pertaining to the
CE marking. Refer to the Declaration of Conformity (DoC) for this product for any additional regulatory compliance
information. To obtain the DoC for this product, visit
and click the appropriate link in the Certification column.
* The CE marking Declaration of Conformity contains important supplementary information and instructions for the user or
installer.
ni.com/certification, search by model number or product line,
Conventions
The following conventions are used in this manual:
» The » symbol leads you through nested menu items and dialog box options
to a final action. The sequence File»Page Setup»Options directs you to
pull down the File menu, select the Page Setup item, and select Options
from the last dialog box.
This icon denotes a note, which alerts you to important information.
This icon denotes a caution, which advises you of precautions to take to
avoid injury, data loss, or a system crash. When this symbol is marked on a
product, refer to the Safety section of Appendix A, Specifications, for
information about precautions to take.
When symbol is marked on a product, it denotes a warning advising you to
take precautions to avoid electrical shock.
bold Bold text denotes items that you must select or click in the software, such
as menu items and dialog box options. Bold text also denotes parameter
names.
italic Italic text denotes variables, emphasis, a cross-reference, or an introduction
to a key concept. Italic text also denotes text that is a placeholder for a word
or value that you must supply.
monospace Text in this font denotes text or characters that you should enter from the
keyboard, sections of code, programming examples, and syntax examples.
This font is also used for the proper names of disk drives, paths, directories,
programs, subprograms, subroutines, device names, functions, operations,
variables, filenames, and extensions.
Contents
Chapter 1
General Information
Introduction....................................................................................................................1-1
I/O Ports.........................................................................................................................1-1
Cleaning .........................................................................................................................1-2
Chapter 2
System Setup
Important Safety Information ........................................................................................2-1
Setup ..............................................................................................................................2-2
Touchscreen Calibration..................................................................................2-3
Panel Mounting..............................................................................................................2-4
Chapter 3
Jumpers and Connectors
Jumper and Connector Functions ..................................................................................3-1
Jumper and Connector Locations ..................................................................................3-3
Appendix A
Specifications
Appendix B
Serial Port Settings
Appendix C
Watchdog Timer Programming
Appendix D
Watchdog Timer Programming on WinCE (TPC-2012)
Appendix E
Features in Windows XP Embedded (TPC-2512)
© National Instruments Corporation vii TPC-2012/TPC-2512 User Manual
Contents
Appendix F
Accessory Kit Assembly Procedure
Appendix G
Touchscreen Configuration
Appendix H
Fuse Replacement
Appendix I
Technical Support and Professional Services
Index
TPC-2012/TPC-2512 User Manual viii ni.com
General Information
This chapter includes general information about the TPC-2012/TPC-2512
Human Machine Interface (HMI).
Introduction
The TPC-2012/TPC-2512 touch panel computer, a state-of-the-art HMI
based on an x86 platform, includes these key features:
• Fanless—Because the system uses a low-power processor, it does not
need fans, which often are unreliable and cause dust to circulate inside
the equipment.
• Bright display—The TFT LCD features a 12.1 in. display that meets
industrial demands for clear interfaces.
• Powerful communication capability—The TPC-2012/TPC-2512 is
a powerful I/O interface for easy communication with other devices.
The I/O interface includes serial ports, a parallel port, and Ethernet and
USB 1.1 support. The TPC-2012/TPC-2512 also supports the PCI/104
expansion slot, making it easy to expand with PCI/104 modules.
• Windows CE support—In addition to Windows XP support, the
TPC-2012/TPC-2512 supports the Windows CE and Windows XP
embedded platforms. An optional Windows CE operating system
specifically for the TPC-2012/TPC-2512 is available for Windows CE
application programmers.
1
I/O Ports
The TPC-2012/TPC-2512 includes the following ports:
• One parallel port that supports EPP/ ECP modes
• Four serial ports: RS232 (COM1, COM2, COM3) and RS232/422/485
(COM4)
• One RJ-45 Ethernet port
• Two PS/2 ports: 6-pin mini-DIN ports for keyboard and mouse
© National Instruments Corporation 1-1 TPC-2012/TPC-2512 User Manual
Chapter 1 General Information
1
2 3
• Two USB 2.0 ports compliant with USB 1.0 and 1.1.
• One PCI/104 slot
Figure 1-1 shows the I/O port arrangement.
4
5
1 PS/2 Mouse
2 PS/2 Keyboard
3USB
Cleaning
9
8 7
4LAN
5Parallel Port
6 COM1 (RS232)
6
7 COM2 (RS232)
8 COM3 (RS232)
9 COM4 (RS232/422/485)
Figure 1-1. I/O Port Arrangement
For more TPC-2012/TPC-2512 specifications, see Appendix A,
Specifications.
If you need to clean the unit, use a soft, nonmetallic brush. Make sure that
the unit is completely dry and free from contaminants before returning it to
service.
TPC-2012/TPC-2512 User Manual 1-2 ni.com
System Setup
This chapter includes setup information for the TPC-2012/TPC-2512.
Important Safety Information
Before setting up the TPC-2012/TPC-2512, read these safety instructions
carefully.
Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
For plug-in equipment, the power outlet socket must be located near the
equipment and must be easily accessible.
Keep this equipment away from excessive humidity.
Place this equipment on a reliable surface during installation. Dropping it
or letting it fall may cause damage.
The openings on the enclosure are for air convection. Protect the equipment
from overheating. Do not cover the openings.
2
Make sure the power source voltage is correct before connecting the
equipment to the power outlet.
Position the power cord so that it cannot be stepped on. Do not place
anything over the power cord.
All cautions and warnings on the equipment should be noted.
If the equipment is not used for a long time, disconnect it from the power
source to avoid damage by transient overvoltage.
Never pour any liquid into an opening. This may cause fire or electrical
shock.
Never open the equipment. For safety reasons, only qualified service
personnel should open the equipment.
© National Instruments Corporation 2-1 TPC-2012/TPC-2512 User Manual
Chapter 2 System Setup
Caution There is a danger of explosion if the battery is incorrectly replaced. Replace the
battery only with the same or equivalent type recommended by the manufacturer. Discard
used batteries according to the manufacturer’s instructions.
If one of the following situations arises, have service personnel check the
equipment:
• The power cord or plug is damaged.
• Liquid has penetrated into the equipment.
• The equipment has been exposed to moisture.
• The equipment does not work well, or you cannot get it to work
according to the user manual.
• The equipment has been dropped and damaged.
• The equipment has obvious signs of breakage.
Do not leave this equipment in an environment where the storage
temperature may go below –20 °C (–4 °F) or above 60 °C (140 °F). Doing
so could damage the equipment. The equipment should be in a controlled
environment.
The sound pressure level at the operator’s position according to
IEC 704-1:1982 is no more than 70 dB (A).
Caution The protection this equipment provides may be impaired if it is used in a manner
not described in this manual.
Setup
Follow these steps to set up the TPC-2012/TPC-2512:
1. Unpack the TPC-2012/TPC-2512. Be sure your kit includes the
following items:
• The TPC-2012/TPC-2512 HMI
• Eight panel mounting clamps
• Eight panel mounting screws
• One 3-pin power connector
• One HMI Resource CD
• One CompactFlash to IDE adapter card
If any items are missing or damaged, contact National Instruments.
TPC-2012/TPC-2512 User Manual 2-2 ni.com
Chapter 2 System Setup
Caution Be sure system power is off before plugging in or pulling out the CompactFlash
card.
2. Install a CompactFlash card containing Windows CE, embedded
Windows XP, or another operating system.
3. Connect the power connector to 24 VDC power lines. Be sure to
connect the positive, negative, and ground lines as shown in
Figure 2-1. The power lines can be from either a power adapter or
in-house power source.
4. Connect the power connector to the power receptor on the
TPC-2012/TPC-2512. The power receptor pin assignment is shown in
Figure 2-2.
5. Switch on the power switch to power on the system.
Touchscreen Calibration
The TPC-2012/TPC-2512 touchscreen should be correctly calibrated and
ready to use when you power on the system. However, if the calibration is
not correct or you want to choose custom calibration options, refer to
Appendix G, Touchscreen Configuration.
+
Figure 2-1. Power Connector
GND
Figure 2-2. Power Receptor and Pin Assignment
GND
–
+
–
© National Instruments Corporation 2-3 TPC-2012/TPC-2512 User Manual
Chapter 2 System Setup
Panel Mounting
Note The mounting panel thickness should be less than 6 mm (0.236 in.).
Follow these steps to mount the TPC-2012/TPC-2512 in a panel:
1. Be sure the adhesive waterproof gasket on the front bezel is in position.
2. Install the TPC-2012/TPC-2512 in the panel opening. (Refer to
Appendix A, Specifications, for cutout dimensions.)
3. Hook the clamps included in the accessory pack to the holes around the
four sides of the bezel.
4. Insert the screws included in the accessory pack into the clamps. To
fasten the TPC-2012/TPC-2512 to the panel, tighten the screws so they
push against the mounting panel.
TPC-2012/TPC-2512 User Manual 2-4 ni.com
Jumpers and Connectors
This chapter describes the TPC-2012/TPC-2512 jumpers and connectors.
Jumper and Connector Functions
Table 3-1 lists the jumper and connector functions.
Table 3-1. Mainboard Connectors and Jumpers
Label Function Description
CN2 LCD power LCD inverter connector
CN3 CF CompactFlash socket
CN4 IDE Internal IDE 44-pin (2 mm)
CN5 Ethernet RJ45 LAN port
CN6 LPT Printer port
3
connector
CN7 COM1 Serial port: COM2 RS232
CN8 COM2 Serial port: COM1 RS232
CN9 DC in DC power in connector
(5.08 mm, 3-pin housing)
CN10 USB2 Two USB type-A female
CN11 USB1 Two USB type-A female
CN12 PS2 mouse Standard mini-DIN 6-pin
CN13 PS2 keyboard Standard mini-DIN 6-pin
CN14 PCI104 PCI104 30*4 connector
CN15 COM3 Serial port: COM1 RS232
CN16 COM4 Serial port: COM1
RS232/485/422
© National Instruments Corporation 3-1 TPC-2012/TPC-2512 User Manual
Chapter 3 Jumpers and Connectors
JP1 Panel Panel connector
JP2 Touc h Touch connector
JP4 5 V/3 V PCI104 5 V/3 V select
J1 DDR DDR connector
J3 1*3 pin header Clear CMOS
SW1 Power switch System power switch
BH1 Battery RTC battery
FS1 Fuse Fuse holder
Table 3-1. Mainboard Connectors and Jumpers (Continued)
Label Function Description
TPC-2012/TPC-2512 User Manual 3-2 ni.com
Loading...
