National Instruments NI USB-6008, NI USB-6009 User Manual

USER GUIDE AND SPECIFICATIONS

NI USB-6008/6009

This user guide describes how to use the National Instruments USB-6008/6009 data acquisition (DAQ) devices and lists specifications.

Introduction

The NI USB-6008/6009 provides connection to eight analog input (AI) channels, two analog output (AO) channels, 12 digital input/output (DIO) channels, and a 32-bit counter with a Full-Speed USB interface.

Note This manual revision updates naming conventions to reflect the conventions used in

NI-DAQmx. Table 1 notes the correlation between the old and updated names.

Table 1. Digital Output Driver Type Naming Conventions

Hardware Functionality NI-DAQmx Terminology

Open-drain Open collector

Push-pull Active drive

Table 2. Differences Between the NI USB-6008 and NI USB-6009

Feature NI USB-6008 NI USB-6009

AI Resolution 12 bits differential,

11 bits single-ended

Maximum AI Sample Rate, Single Channel

Maximum AI Sample Rate, Multiple Channels (Aggregate)

10 kS/s 48 kS/s

14 bits differential,

13 bits single-ended

DIO Configuration Open collector Open collector or active drive

System dependent.

1 Analog 16

NI USB-6009

8 Inputs, 14-bit, Multifunction I/O

32 Digital 17

1 USB Cable Strain Relief

Figure 1. NI USB-6008/6009 Top View

Figure 2. NI USB-6008/6009 Back View

NI USB-6008/6009 User Guide and Specifications 2 ni.com

Dimensions

Figure 3 illustrates the dimensions of the NI USB-6008/6009 device.

Safety Guidelines

81.81 mm (3.221 in.)

85.09 mm

NATIONAL INSTRUMENTS

63.50 mm (2.500 in.)

72.65 mm

(2.860 in.)

Figure 3. NI USB-6008/6009 in Millimeters (Inches)

(3.350 in.)

76.09 mm (2.996 in.)

23.19 mm (0.913 in.)

Caution Operate the NI USB-6008/6009 only as described in these operating instructions.

The following section contains important safety information that you must follow when installing and using the NI USB-6008/6009.

Do not operate the NI USB-6008/6009 in a manner not specified in this document. Misuse of the device can result in a hazard. You can compromise the safety protection built into the device if the device is damaged in any way. If the device is damaged, contact National Instruments for repair.

Do not substitute parts or modify the device except as described in this document. Use the device only with the chassis, modules, accessories, and cables specified in the installation instructions. You must have all covers and filler panels installed during operation of the device.

Do not operate the device in an explosive atmosphere or where there may be flammable gases or fumes. If you must operate the device in such an environment, it must be in a suitably rated enclosure.

If you need to clean the device, use a dry cloth. Make sure that the device is completely dry and free from contaminants before returning it to service.

Operate the device only at or below Pollution Degree 2. Pollution is foreign matter in a solid, liquid, or gaseous state that can reduce dielectric strength or surface resistivity. The following is a description of pollution degrees:

• Pollution Degree 1 means no pollution or only dry, nonconductive pollution occurs. The pollution has no influence.

• Pollution Degree 2 means that only nonconductive pollution occurs in most cases. Occasionally, however, a temporary conductivity caused by condensation must be expected.

• Pollution Degree 3 means that conductive pollution occurs, or dry, nonconductive pollution occurs that becomes conductive due to condensation.

You must insulate signal connections for the maximum voltage for which the device is rated. Do not exceed the maximum ratings for the device. Do not install wiring while the device is live with electrical signals. Do not remove or add connector blocks when power is connected to the system. Avoid contact between your body and the connector block signal when hot swapping modules. Remove power from signal lines before connecting them to or disconnecting them from the device.

Operate the device at or below the Measurement Category I circuits are subjected to working voltages

and transient stresses

. Measurement

(overvoltage) from the circuit to which they are connected during measurement or test. Measurement categories establish standard impulse withstand voltage levels that commonly occur in electrical distribution systems. The following is a description of measurement categories:

• Measurement Category I is for measurements performed on circuits not directly connected to the electrical distribution system referred to as MAINS

voltage. This category is for measurements of voltages from specially protected secondary circuits. Such voltage measurements include signal levels, special equipment, limited-energy parts of equipment, circuits powered by regulated low-voltage sources, and electronics.

Measurement Category as defined in electrical safety standard IEC 61010-1. Measurement Category is also referred to as Installation Category.

Working Voltage is the highest rms value of an AC or DC voltage that can occur across any particular insulation.

MAINS is defined as a hazardous live electrical supply system that powers equipment. Suitably rated measuring circuits may be connected to the MAINS for measuring purposes.

NI USB-6008/6009 User Guide and Specifications 4 ni.com

• Measurement Category II is for measurements performed on circuits directly connected to the electrical distribution system. This category refers to local-level electrical distribution, such as that provided by a standard wall outlet (for example, 115 V for U.S. or 230 V for Europe). Examples of Measurement Category II are measurements performed on household appliances, portable tools, and similar E Series devices.

• Measurement Category III is for measurements performed in the building installation at the distribution level. This category refers to measurements on hard-wired equipment such as equipment in fixed installations, distribution boards, and circuit breakers. Other examples are wiring, including cables, bus-bars, junction boxes, switches, socket-outlets in the fixed installation, and stationary motors with permanent connections to fixed installations.

• Measurement Category IV is for measurements performed at the primary electrical supply installation (<1,000 V). Examples include electricity meters and measurements on primary overcurrent protection devices and on ripple control units.

Installing the Software

Software support for the NI USB-6008/6009 for Windows Vista/XP/2000 is provided by NI-DAQmx. The DAQ Getting Started Guide, which you can download at instructions for installing software and hardware, configuring channels and tasks, and getting started developing an application.

ni.com/training.

ni.com/manuals, offers NI-DAQmx users step-by-step

Note For information about non-Windows operating system support, refer to ni.com/

info

and enter BaseGSGML.

Installing Other Software

If you are using other software, refer to the installation instructions that accompany your software.

Example Programs

The NI-DAQmx CD contains example programs that you can use to get started programming with the NI USB-6008/6009. Refer to the NI-DAQmx for USB Devices Getting Started Guide that shipped with your device, and is also accessible from Start»All Programs»National Instruments» NI-DAQ, for more information.

The NI-DAQmx Base software ships with example programs you can use to get started programming with the NI USB-6008/6009. Refer to the NI-DAQmx Base Getting Started Guide that shipped with your device, and is also accessible from Start»All Programs»National Instruments» NI-DAQmx Base»Documentation, for more information.

Note For information about non-Windows operating system support, refer to ni.com/

info

and enter BaseGSGML.

Installing the NI USB-6008/6009 Device

Before installing the device, you must install the software you plan to use with the device. Refer to the Installing the Software section of this guide and the documentation included with the software for more information.

Figure 4 shows key functional components of the NI USB-6008/6009.

Full-Speed USB Interface

Vbus

USB

External

Powe r

Supply

USB Microcontroller

SPI

8 Channel

12/14b ADC

12b DAC

+5 V/200 mA

PFI 0

P1.<0..3>

P0.<0..7>

+2.5 V/CAL

AI <0..7>

AO 0

AO 1

Digital I/O Terminal Block

Analog I/O Terminal Block

Figure 4. Device Block Diagram

NI USB-6008/6009 User Guide and Specifications 10 ni.com

Setting Up the NI USB-6008/6009 Device

Complete the following steps to set up the NI USB-6008/6009:

1. Install combicon screw terminal blocks by inserting them into the combicon jacks.

2. Figure 5 illustrates the signal labels that ship in the NI USB-6008/6009 kit. You can apply the signal labels to the screw terminal blocks for easy signal identification.

1 Terminal Number Labels (Use Both Together) 2 Digital I/O Label

ANALOG DIGITAL

3. Refer to Table 4 and Figures 5 and 6 for signal label orientation and affix the provided signal labels to the screw terminal blocks. Until the signal labels are applied, you can insert the screw terminal blocks into either of the combicon jacks.

3 Single-Ended Signal Name Label (Use Either) 4 Differential Signal Name Label (Use Either)

Figure 5. NI USB-6008/6009 Signal Labels

lat

-B

gol

1 Overlay Label with Pin Orientation Guides 2 Combicon Jack

upn

3 Signal Labels 4 USB Cable

Figure 6. Signal Label Application Diagram

Note

Once you label the screw terminal blocks, you must only insert them into the matching combicon jack, as indicated by the overlay label on the NI USB-6008/6009 device.

4. Connect the wiring to the appropriate screw terminals.

NI USB-6008/6009 User Guide and Specifications 12 ni.com

Connecting the NI USB-6008/6009 to a Computer

Plug one end of the USB cable into the NI USB-6008/6009 and the other end into an available USB port on the computer.

LED Indicator

The NI USB-6008/6009 device has a green LED next to the USB connector. The LED indicator indicates device status, as listed in Table 3. When the device is connected to a USB port, the LED blinks steadily to indicate that the device is initialized and is receiving power from the connection.

If the LED is not blinking, it may mean that the device is not initialized or the computer is in standby mode. In order for the device to be recognized, the device must be connected to a computer that has NI-DAQmx installed on it. If your device is not blinking, make sure your computer has the latest version of NI-DAQmx installed on it, and the computer is not in standby mode.

Table 3. LED State/Device Status

LED State Device Status

Not lit Device not connected or in suspend.

On, not blinking Device connected.

Single-blink Operating normally.

I/O Connector

The NI USB-6008/6009 ships with one detachable screw terminal block for analog signals and one detachable screw terminal block for digital signals. These terminal blocks provide 16 connections that use 16 AWG to 28 AWG wire.

Table 4 lists the analog terminal assignments, and Table 5 lists the digital terminal assignments.

Table 4. Analog Terminal Assignments

Module Ter mi na l

1 GND GND

2 AI 0 AI 0+

3 AI 4 AI 0–

4 GND GND

12345678 9 10111213141516

5 AI 1 AI 1+

6 AI 5 AI 1–

7 GND GND

8 AI 2 AI 2+

9 AI 6 AI 2–

10 GND GND

11 AI 3 AI 3+

12 AI 7 AI 3–

Signal,

Single-Ended Mode

Signal,

Differential Mode

13 GND GND

14 AO 0 AO 0

15 AO 1 AO 1

16 GND GND

NI USB-6008/6009 User Guide and Specifications 14 ni.com

Table 5. Digital Terminal Assignments

Module Terminal Signal

17 P0.0

18 P0.1

19 P0.2

20 P0.3

21 P0.4

22 P0.5

23 P0 6

24 P0.7

25 P1.0

26 P1.1

27 P1.2

28 P1.3

32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17

29 PFI 0

30 +2.5 V

31 +5 V

32 GND

Signal Descriptions

Table 6 describes the signals available on the I/O connectors.

Table 6. Signal Descriptions

Signal Name Reference Direction Description

GND — — Ground—The reference point for the

single-ended AI measurements, bias current return point for differential mode measurements, AO voltages, digital signals at the I/O connector, +5 VDC supply, and the +2.5 VDC reference.

AI <0..7> Va r ie s Input Analog Input Channels 0 to 7—For

single-ended measurements, each signal is an analog input voltage channel. For differential measurements, AI 0 and AI 4 are the positive and negative inputs of differential analog input channel 0. The following signal pairs also form differential input channels: <AI 1, AI 5>, <AI 2, AI 6>, and <AI3,AI7>.

AO 0 GND Output Analog Channel 0 Output—Supplies the

voltage output of AO channel 0.

AO 1 GND Output Analog Channel 1 Output—Supplies the

voltage output of AO channel 1.

P1.<0..3> P0.<0..7>

+2.5 V GND Output +2.5 V External Reference—Provides a

+5 V GND Output +5 V Power Source—Provides +5 V

PFI 0 GND Input PFI 0—This pin is configurable as either a

NI USB-6008/6009 User Guide and Specifications 16 ni.com

GND Input or

Output

Digital I/O Signals—You can individually configure each signal as an input or output.

reference for wrap-back testing.

power up to 200 mA.

digital trigger or an event counter input.

Analog Input

You can connect analog input signals to the NI USB-6008/6009 through the I/O connector. Refer to Table 6 for more information about connecting analog input signals.

Analog Input Circuitry

Figure 7 illustrates the analog input circuitry of the NI USB-6008/6009.

+2.5 V

REF

30.9 kΩ

127 kΩ

39.2 kΩ

MUX

PGA

Input Range

Selection

Figure 7. Analog Input Circuitry

ADC

AI FIFO

MUX

The NI USB-6008/6009 has one analog-to-digital converter (ADC). The multiplexer (MUX) routes one AI channel at a time to the PGA.

PGA

The progammable-gain amplifier provides input gains of 1, 2, 4, 5, 8, 10, 16, or 20 when configured for differential measurements and gain of 1 when configured for single-ended measurements. The PGA gain is automatically calculated based on the voltage range selected in the measurement application.

A/D Converter

The analog-to-digital converter (ADC) digitizes the AI signal by converting the analog voltage into a digital code.

Analog Input Modes

AI FIFO

The NI USB-6008/6009 can perform both single and multiple A/D conversions of a fixed or infinite number of samples. A first-in-first-out (FIFO) buffer holds data during AI acquisitions to ensure that no data is lost.

You can configure the AI channels on the NI USB-6008/6009 to take single-ended or differential measurements. Refer to Table 6 for more information about I/O connections for single-ended or differential measurements.

Connecting Differential Voltage Signals

For differential signals, connect the positive lead of the signal to the AI+ terminal, and the negative lead to the AI– terminal.

AI+

Vol tage Source

Figure 8. Connecting a Differential Voltage Signal

NI USB-6008/6009

AI–

The differential input mode can measure ±20 V signals in the ±20 V range. However, the maximum voltage on any one pin is ±10 V with respect to GND. For example, if AI 1 is +10 V and AI 5 is –10 V, then the measurement returned from the device is +20 V.

NI USB-6008/6009 User Guide and Specifications 18 ni.com

–5

Amplitude (V) –10

–15

–20

AI 1 AI 5

Result

Figure 9. Example of a Differential 20 V Measurement

Connecting a signal greater than ±10 V on either pin results in a clipped output.

–5

Amplitude (V)

–10

–15

–20

AI 1 AI 5

Result

Figure 10. Exceeding ±10 V on AI Returns Clipped Output

Connecting Reference Single-Ended Voltage Signals

To connect reference single-ended voltage signals (RSE) to the NI USB-6008/6009, connect the positive voltage signal to the desired AI terminal, and the ground signal to a GND terminal, as illustrated in Figure 11.

When no signals are connected to the analog input terminal, the internal resistor divider may cause the terminal to float to approximately 1.4 V when the analog input terminal is configured as RSE. This behavior is normal and does not affect the measurement when a signal is connected.

Digital Trigger

When an AI task is defined, you can configure PFI 0 as a digital trigger input. When the digital trigger is enabled, the AI task waits for a rising or falling edge on PFI 0 before starting the acquisition. To use ai/Start Trigger with a digital source, specify PFI 0 as the source and select rising or falling edge.

Analog Output

The NI USB-6008/6009 has two independent AO channels that can generate outputs from 0–5 V. All updates of AO lines are software-timed.

Analog Output Circuitry

Figure 12 illustrates the analog output circuitry for the NI USB-6008/6009.

Vol tage Source

Figure 11. Connecting a Reference Single-Ended Voltage Signal

NI USB-6008/6009

GND

+5 V

REF(+) REF(–)

12-Bit

DAC

GND

Figure 12. Analog Output Circuitry

NI USB-6008/6009 User Guide and Specifications 20 ni.com

Output

Buffer

50 Ω

DACs

Digital-to-analog converts (DACs) convert digital codes to analog voltages.

Connecting Analog Output Loads

To connect loads to the NI USB-6008/6009, connect the positive lead of the load to the AO terminal, and connect the ground of the load to a GND terminal.

NI USB-6008/6009

Figure 13. Connecting a Load

Minimizing Glitches on the Output Signal

When you use a DAC to generate a waveform, you may observe glitches in the output signal. These glitches are normal; when a DAQ switches from one voltage to another, it produces glitches due to released charges. The largest glitches occur when the most significant bit of the DAC code changes. You can build a lowpass deglitching filter to remove some of these glitches, depending on the frequency and nature of the output signal. Refer to glitches.

ni.com/support for more information about minimizing

Digital I/O

The NI USB-6008/6009 has 12 digital lines, P0.<0..7> and P1.<0..3>, which comprise the DIO port. GND is the ground-reference signal for the DIO port. You can individually program all lines as inputs or outputs.

Load

GND

Digital I/O Circuitry

Figure 14 shows P0.<0..7> connected to example signals configured as digital inputs and digital outputs. You can configure P1.<0..3> similarly.

+5 V

LED

1 P0.0 configured as an open collector digital output driving a LED 2 P0.2 configured as a active drive digital output driving a LED 3 P0.4 configured as a digital input receiving a TTL signal from a gated invertor 4 P0.7 configured as a digital input receiving a 0 V or 5 V signal from a switch

+5 V

TTL Signal

Switch

GND

I/O Connector

P0.0 P0.1 P0.2 P0.3 P0.4 P0.5 P0.6 P0.7

Figure 14. Example of Connecting a Load

Caution

Exceeding the maximum input voltage ratings or maximum output ratings, which are listed in the Specifications section, can damage the device and the computer. National Instruments is not liable for any damage resulting from such signal connections.

Source/Sink Information

The default configuration of the NI USB-6008/6009 DIO ports is open collector, allowing 5 V operation, with an onboard 4.7 kΩ pull-up resistor. An external user-provided pull-up resistor can be added to increase the source current drive up to a 8.5 mA limit per line as shown in Figure 15.

The NI USB-6009 ports can also be configured as active drive using the NI-DAQmx API, allowing 3.3 V operation with a source/sink current limit of ±8.5 mA. Refer to the NI-DAQmx Help for more information about how to set the DIO configuration.

NI USB-6008/6009 User Guide and Specifications 22 ni.com

+5 V

NI USB-6008/6009

External

Pull-Up

Resistor

Load

4.7 KΩ Onboard Resistor

P0.0

GND

Por t Pad

Figure 15. Example of Connecting an External User-Provided Resistor

Complete the following steps to determine the value of the user-provided pull-up resistor:

1. Place an ammeter in series with the load.

2. Place a variable resistor between the digital output line and the +5 V.

3. Adjust the variable resistor until the ammeter current reads as the intended current. The intended current must be less than 8.5 mA.

4. Remove the ammeter and variable resistor from your circuit.

5. Measure the resistance of the variable resistor. The measured resistance is the ideal value of the pull-up resistor.

6. Select a static resistor value for your pull-up resistor that is greater than or equal to the ideal resistance.

7. Re-connect the load circuit and the pull-up resistor.

I/O Protection

Power-On States

To protect the NI USB-6008/6009 against overvoltage, undervoltage, and overcurrent conditions, as well as ESD events, you should avoid these fault conditions by using the following guidelines:

• If you configure a DIO line as an output, do not connect it to any external signal source, ground signal, or power supply.

• If you configure a DIO line as an output, understand the current requirements of the load connected to these signals. Do not exceed the specified current output limits of the DAQ device.

National Instruments has several signal conditioning solutions for digital applications requiring high current drive.

• If you configure a DIO line as an input, do not drive the line with voltages outside of its normal operating range. The DIO lines have a smaller operating range than the AI signals.

• Treat the DAQ device as you would treat any static sensitive device. Always properly ground yourself and the equipment when handling the DAQ device or connecting to it.

At system startup and reset, the hardware sets all DIO lines to high-impedance inputs. The DAQ device does not drive the signal high or low. Each line has a weak pull-up resistor connected to it.

Static DIO

Each of the NI USB-6008/6009 DIO lines can be used as a static DI or DO line. You can use static DIO lines to monitor or control digital signals. All samples of static DI lines and updates of DO lines are software-timed.

Event Counter

You can configure PFI 0 as a source for a gated invertor counter input edge count task. In this mode, falling-edge events are counted using a 32-bit counter. For more information about event timing requirements, refer to the

Specifications section.

NI USB-6008/6009 User Guide and Specifications 24 ni.com

Reference and Power Sources

The NI USB-6008/6009 creates an external reference and supplies a power source. All voltages are relative to COM unless otherwise noted.

+2.5 External References

The NI USB-6008/6009 creates a high-purity reference voltage supply for the ADC using a multi-state regulator, amplifier, and filter circuit. The resulting +2.5 V reference voltage can be used as a signal for self test.

+5 V Power Source

The NI USB-6008/6009 supplies a 5 V, 200 mA output. This source can be used to power external components.

Note While the device is in USB suspend, the output is disabled.

Specifications

The following specifications are typical at 25 °C, unless otherwise noted.

Analog Input

Converter type........................................ Successive approximation

Analog inputs ......................................... 8 single-ended, 4 differential,

software selectable

Input resolution

NI USB-6008 .................................. 12 bits differential,

11 bits single-ended

NI USB-6009 .................................. 14 bits differential,

13 bits single-ended

Max sampling rate (aggregate)

NI USB-6008 .................................. 10 kS/s

NI USB-6009 .................................. 48 kS/s

AI FIFO.................................................. 512 bytes

Timing resolution................................... 41.67 ns (24 MHz timebase)

System dependent.

Timing accuracy .....................................100 ppm of actual sample rate

Input range

Single-ended....................................±10 V

Differential ......................................±20 V

, ±10 V, ±5 V, ±4 V,

±2.5 V, ±2 V, ±1.25 V, ±1 V

Working voltage .....................................±10 V

Input impedance .....................................144 kΩ

Overvoltage protection ...........................±35

Trigger source.........................................Software or external digital

trigger

System noise

Single-ended

±10 V range..............................5 mVrms

Differential

±20 V range .............................5 mVrms

±1 V range................................0.5 mVrms

Absolute accuracy at full scale, single ended

Range

Typical at 25 °C

(mV)

Maximum over Temperature

±10 14.7 138

Maximum over Temperature

Range

Absolute accuracy at full scale, differential

Typical at 25 °C

(mV)

±20 14.7 138

±10 7.73 84.8

±5 4.28 58.4

±4 3.59 53.1

(mV)

±2.5 2.56 45.1

±20 V means that |AI+ – (AI–)| <= 20 V. However, AI+ and AI– must both be within ±10 V of GND. Refer to the Connecting

Differential Voltage Signals for more information.

System noise measured at maximum sample rate.

Input voltages may not exceed the working voltage range.

NI USB-6008/6009 User Guide and Specifications 26 ni.com

Range

±2 2.21 42.5

±1.25 1.70 38.9

±1 1.53 37.5

Analog Output

Typical at 25 °C

(mV)

Analog outputs ....................................... 2

Output resolution.................................... 12 bits

Maximum update rate ............................ 150 Hz, software-timed

Output range........................................... 0 to +5 V

Output impedance .................................. 50 Ω

Output current drive ............................... 5 mA

Power-on state........................................ 0 V

Slew rate................................................. 1 V/μs

Maximum over Temperature

(mV)

Short circuit current ...............................50 mA

Absolute accuracy (no load) .................. 7 mV typical,

36.4 mV maximum at full scale

Digital I/O

P0.<0..7>......................................... 8 lines

P1.<0..3>......................................... 4 lines

Direction control .................................... Each channel individually

programmable as input or output

Output driver type

NI USB-6008 ..................................Open collector (open-drain)

NI USB-6009 .................................. Each channel individually

programmable as active drive (push-pull) or open collector (open-drain)

Compatibility ..........................................TTL, LVTTL, CMOS

Absolute maximum voltage range ..........–0.5 to 5.8 V with respect to GND

Pull-up resistor........................................4.7 kΩ to 5 V

Power-on state ........................................Input

Digital logic levels

Level Min Max Units

Input low voltage Input high voltage Input leakage current

Output low voltage (I = 8.5 mA) Output high voltage

Active drive (push-pull), I = –8.5 mA Open collector (open-drain), I = –0.6 mA, nominal Open collector (open-drain), I = –8.5 mA, with external pull-up resistor

External Voltage

+5 V output (200 mA maximum) ...........+5 V typical, +4.85 V minimum

+2.5 V output (1 mA maximum) ............+2.5 V typical

+2.5 V accuracy......................................0.25% max

Reference temperature drift ....................50 ppm/°C max

Counter

Number of counters ................................1

Resolution...............................................32 bits

–0.3

2.0 —

—

2.0

0.8

5.8 50

0.8

3.5

5.0 —

V V

μA

V V V

Counter measurements ...........................Edge counting (falling-edge)

Counter direction ....................................Count up

Pull-up resistor........................................4.7 kΩ to 5 V

Maximum input frequency .....................5 MHz

Minimum high pulse width.....................100 ns

NI USB-6008/6009 User Guide and Specifications 28 ni.com

Minimum low pulse width ..................... 100 ns

Input high voltage .................................. 2.0 V

Input low voltage ................................... 0.8 V

Bus Interface

USB specification .................................. USB 2.0 Full-Speed

USB bus speed .......................................12 Mb/s

Power Requirements

USB

4.10 to 5.25 VDC............................ 80 mA typical, 500 mA max

USB suspend................................... 300 μA typical, 500 μAmax

Physical Characteristics

Dimensions

Without connectors ......................... 6.35 cm × 8.51 cm × 2.31 cm

With connectors .............................. 8.18 cm × 8.51 cm × 2.31 cm

(2.50 in. × 3.35 in. × 0.91 in.)

(3.22 in. × 3.35 in. × 0.91 in.)

I/O connectors ........................................ USB series B receptacle,

(2) 16 position terminal block plug headers

Weight

With connectors .............................. 84 g (3 oz)

Without connectors ......................... 54 g (1.9 oz)

Screw-terminal wiring............................ 16 to 28 AWG

Torque for screw terminals .................... 0.22–0.25 N · m

(2.0– 2.2 lb · in.)

Safety

If you need to clean the module, wipe it with a dry towel.

Safety Voltages

Connect only voltages that are within these limits.

Channel-to-GND ....................................±30 V max,

Measurement Category I

Measurement Category I is for measurements performed on circuits not directly connected to the electrical distribution system referred to as MAINS voltage. MAINS is a hazardous live electrical supply system that powers equipment. This category is for measurements of voltages from specially protected secondary circuits. Such voltage measurements include signal levels, special equipment, limited-energy parts of equipment, circuits powered by regulated low-voltage sources, and electronics.

Caution Do not use this module for connection to signals or for measurements within

Measurement Categories II, III, or IV.

Safety Standards

This product is designed to meet the requirements of the following standards of safety for electrical equipment for measurement, control, and laboratory use:

• IEC 61010-1, EN 61010-1

• UL 61010-1, CSA 61010-1

Note For UL and other safety certifications, refer to the product label or visit

ni.com/certification, search by model number or product line, and click the

appropriate link in the Certification column.

Hazardous Locations

The NI USB-6008/6009 are not certified for use in hazardous locations.

Environmental

The NI USB-6008/6009 device is intended for indoor use only.

Operating temperature

(IEC 60068-2-1 and IEC 60068-2-2)......0 to 55 °C

Operating humidity

(IEC 60068-2-56) ...................................5 to 95% RH, noncondensing

NI USB-6008/6009 User Guide and Specifications 30 ni.com

Maximum altitude .................................. 2,000 m (at 25 °C ambient

Storage temperature

(IEC 60068-2-1 and IEC 60068-2-2) ..... –40 to 85 °C

Storage humidity

(IEC 60068-2-56) .................................. 5 to 90% RH, noncondensing

Pollution Degree (IEC 60664) ............... 2

Electromagnetic Compatibility

This product is designed to meet the requirements of the following standards of EMC for electrical equipment for measurement, control, and laboratory use:

• EN 61326 EMC requirements; Minimum Immunity

• EN 55011 Emissions; Group 1, Class A

• CE, C-Tick, ICES, and FCC Part 15 Emissions; Class A

Note For EMC compliance, operate this device with double-shielded cables.

CE Compliance

This product meets the essential requirements of applicable European Directives, as amended for CE marking, as follows:

• 2006/95/EC; Low-Voltage Directive (safety)

• 2004/108/EC; Electromagnetic Compatibility Directive (EMC)

temperature)

Note Refer to the Declaration of Conformity (DoC) for this product for any additional

regulatory compliance information. To obtain the DoC for this product, visit

ni.com/certification, search by module number or product line, and click the

appropriate link in the Certification column.

Environmental Management

National Instruments is committed to designing and manufacturing products in an environmentally responsible manner. NI recognizes that eliminating certain hazardous substances from our products is beneficial not only to the environment but also to NI customers.

For additional environmental information, refer to the NI and the Environment Web page at environmental regulations and directives with which NI complies, as well as other environmental information not included in this document.

ni.com/environment. This page contains the

Waste Electrical and Electronic Equipment (WEEE)

⬉ᄤֵᙃѻક∵ᶧ᥻ࠊㅵ⧚ࡲ⊩ ˄Ё೑

Ё೑ᅶ᠋

EU Customers At the end of their life cycle, all products must be sent to a WEEE recycling

center. For more information about WEEE recycling centers and National Instruments WEEE initiatives, visit

National Instruments

݇Ѣ

National InstrumentsЁ೑RoHS

(For information about China RoHS compliance, go to

ni.com/environment/weee.htm.

Where to Go for Support

The National Instruments Web site is your complete resource for technical support. At troubleshooting and application development self-help resources to email and phone assistance from NI Application Engineers.

National Instruments corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas, 78759-3504. National Instruments also has offices located around the world to help address your support needs. For telephone support in the United States, create your service request at instructions or dial 512 795 8248. For telephone support outside the United States, contact your local branch office:

ni.com/support you have access to everything from

RoHS

ヺড়Ё೑⬉ᄤֵᙃѻકЁ䰤ࠊՓ⫼ᶤѯ᳝ᆇ⠽䋼ᣛҸ

ড়㾘ᗻֵᙃˈ䇋ⱏᔩ

ni.com/support and follow the calling

ni.com/environment/rohs_china

(RoHS)

Australia 1800 300 800, Austria 43 662 457990-0, Belgium 32 (0) 2 757 0020, Brazil 55 11 3262 3599, Canada 800 433 3488, China 86 21 5050 9800, Czech Republic 420 224 235 774, Denmark 45 45 76 26 00, Finland 358 (0) 9 725 72511, France 01 57 66 24 24, Germany 49 89 7413130, India 91 80 41190000, Israel 972 3 6393737, Italy 39 02 41309277, Japan 0120-527196, Korea 82 02 3451 3400, Lebanon 961 (0) 1 33 28 28, Malaysia 1800 887710, Mexico 01 800 010 0793, Netherlands 31 (0) 348 433 466, New Zealand 0800 553 322, Norway 47 (0) 66 90 76 60, Poland 48 22 3390150, Portugal 351 210 311 210, Russia 7 495 783 6851, Singapore 1800 226 5886, Slovenia 386 3 425 42 00, South Africa 27 0 11 805 8197, Spain 34 91 640 0085, Sweden 46 (0) 8 587 895 00, Switzerland 41 56 2005151, Taiwan 886 02 2377 2222, Thailand 662 278 6777, Turkey 90 212 279 3031, United Kingdom 44 (0) 1635 52354

National Instruments, NI, ni.com, and LabVIEW are trademarks of National Instruments Corporation. Refer to the Terms of Use section on ni.com/legal for more information about National Instruments trademarks. Other product and company names mentioned herein are trademarks or trad e names of their respective companies. For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your CD, or ni.com/patents.

371303K-01 Dec07

National Instruments NI USB-6008, NI USB-6009 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

Table 1. Digital Output Driver Type Naming Conventions

Table 2. Differences Between the NI USB-6008 and NI USB-6009

Figure 1. NI USB-6008/6009 Top View

Figure 2. NI USB-6008/6009 Back View

Dimensions

Safety Guidelines

Figure 3. NI USB-6008/6009 in Millimeters (Inches)

Related Documentation

NI-DAQmx for Windows

LabVIEW

LabWindows/CVI

Measurement Studio

Device Documentation and Specifications

Training Courses

Technical Support on the Web

Installing the Software

Installing Other Software

Example Programs

Installing the NI USB-6008/6009 Device

Figure 4. Device Block Diagram

Setting Up the NI USB-6008/6009 Device

Figure 5. NI USB-6008/6009 Signal Labels

Figure 6. Signal Label Application Diagram

Connecting the NI USB-6008/6009 to a Computer

LED Indicator

Table 3. LED State/Device Status

I/O Connector

Table 4. Analog Terminal Assignments

Table 5. Digital Terminal Assignments

Signal Descriptions

Table 6. Signal Descriptions

Analog Input

Analog Input Circuitry

Figure 7. Analog Input Circuitry

A/D Converter

Analog Input Modes

AI FIFO

Connecting Differential Voltage Signals

Figure 8. Connecting a Differential Voltage Signal

Figure 9. Example of a Differential 20 V Measurement

Figure 10. Exceeding ±10 V on AI Returns Clipped Output

Connecting Reference Single-Ended Voltage Signals

Digital Trigger

Analog Output

Analog Output Circuitry

Figure 11. Connecting a Reference Single-Ended Voltage Signal

Figure 12. Analog Output Circuitry

DACs

Connecting Analog Output Loads

Figure 13. Connecting a Load

Minimizing Glitches on the Output Signal

Digital I/O

Digital I/O Circuitry

Figure 14. Example of Connecting a Load

Source/Sink Information

Figure 15. Example of Connecting an External User-Provided Resistor

I/O Protection

Power-On States

Static DIO

Event Counter

Reference and Power Sources

+2.5 External References

+5 V Power Source

Specifications

Analog Input

Analog Output

Digital I/O

External Voltage

Counter

Bus Interface

Power Requirements

Physical Characteristics

Safety

Safety Voltages

Safety Standards
