VXIpc™ 800 Series

User Manual

VXIpc 800 Series User Manual

September 1997 Edition

Part Number 321744A-01

Internet Support

support@natinst.com

E-mail: info@natinst.com FTP Site: ftp.natinst.com Web Address: http://www.natinst.com

Bulletin Board Support

BBS United States: (512) 794-5422 BBS United Kingdom: 01635 551422 BBS France: 01 48 65 15 59

Fax-on-Demand Support

(512) 418-1111

Telephone Support (U.S.)

Tel: (512) 795-8248 Fax: (512) 794-5678

International Offices

Australia 03 9879 5166, Austria 0662 45 79 90 0, Belgium 02 757 00 20, Brazil 011 288 3336, Canada (Ontario) 905 785 0085, Canada (Québec) 514 694 8521, Denmark 45 76 26 00, Finland 09 725 725 11, France 01 48 14 24 24, Germany 089 741 31 30, Hong Kong 2645 3186, Israel 03 6120092, Italy 02 413091, Japan 03 5472 2970, Korea 02 596 7456, Mexico 5 520 2635, Netherlands 0348 433466, Norway 32 84 84 00, Singapore 2265886, Spain 91 640 0085, Sweden 08 730 49 70, Switzerland 056 200 51 51, Taiwan 02 377 1200, United Kingdom 01635 523545

National Instruments Corporate Headquarters

6504 Bridge Point Parkway Austin, TX 78730-5039 Tel: (512) 794-0100

Important Information

Warranty

The National Instruments VXIpc 800 Series embedded computers and accessories are warranted against defects in materials and workmanship for a period of one year from the date of shipment, as evidenced by receipts or other documentation. National Instruments will, at its option, repair or replace equipment that proves to be defective during the warranty period. This warranty includes parts and labor.

The media on which you receive National Instruments software are warranted not to fail to execute programming instructions, due to defects in materials and workm anship, f or a period of 90 days fr om date of ship ment, as evid enced by receipts or other documentation. National Instruments will, at its option, repair or replace software media that do not execute programming instructions if National Instruments receives notice of such defects during the warranty period. National Instruments does not warrant that the operation of the software shall be uninterrupted or error free.

A Return Material Authorization (RMA) number must be obtained from the factory and clearly marked on the outside of the package before any equipment will be accepted for warranty work. National Instruments will pay the shipping costs of returning to the owner p arts whic h are co vered by w arran ty.

National Instruments believes that the information in this manual is accurate. The document has been carefully reviewed for technical accuracy. In the event that technical or typographical errors exist, National Instruments reserves the right to make changes to subsequent editions of this document without prior notice to holders of this edition. The reader should consult National Instruments if errors are suspected. In no event shall National Instrum ents be liable for any damages arising out of or related to this document or the information contained in it.

XCEPT AS SPECIFIED HEREIN

SPECIFICALLY DISCLAIMS ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE

USTOMER’S RIGHT TO RECOVER DAMAGES CAUSED BY FAULT OR NEGLIGENCE ON THE PART OF NATIONAL

NSTRUMENTS SHALL BE LIMITED TO THE AMOUNT THERETOFORE PAID BY THE CUSTOMER

WILL NOT BE LIABLE FOR DAMAGES RESULTING FROM LOSS OF DATA, PROFITS, USE OF PRODUCTS, OR INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF ADVISED OF THE POSSIBILITY THEREOF

Instruments will apply regardless of the form of action, whether in contract or tort, including negligence. Any action against National Instruments must be brought within one year after the cause of action accrues. National Instruments shall not be liable for any delay in performance due to causes beyond its reasonable control. The warranty provided herein does not cover damages, defects, malfunctions, or service failures caused by owner’s failure to follow the National Instruments installation, operation, or maintenance instructions; owner’s modification of the product; owner’s abuse, misuse, or negligent acts; and power failure or surges, fire, flood, accident, actions of third parties, or other events outside reasonable control.

ATIONAL INSTRUMENTS MAKES NO WARRANTIES, EXPRESS OR IMPLIED, AND

, N

ATIONAL INSTRUMENTS

. N

. This limitation of the liability of National

Copyright

Under the copyright laws, this publication may not be reproduced or transmitted in any form, electronic or mechanical, including photocopying, recording, storing in an information retrieval system, or translating, in whole or in part, without the prior written consent of National Instruments Corporation.

Trademarks

CVI™, LabVIEW™, MANTIS™, MITE™, NI-488.2™, NI-VISA™, NI-VXI™, TNT™, and VXIpc™ are trademarks of National Instruments Corporation.

Product and company names listed are trademarks or trade names of their respective companies.

WARNING REGARDING MEDICAL AND CLINICAL USE OF NATIONAL INSTRUMENTS PRODUCTS

National Instruments products are not designed with components and testing intended to ensure a level of reliability suitable for use in treatment and diagnosis of humans. Applications of National Instruments products involving medical or clinical treatment can create a potential for accidental injury caused by product failure, or by errors on the part of the user or application designer. Any use or application of National Instruments products for or involving medical or clinical treatment must be performed by properly trained and qualified medical personnel, and al l traditional medical safeguards, equipment, and procedures that are appropriate in the particular situation to prevent serious injury or death should always continue to be used when National Instruments products are being used. National Instruments products are NOT intended to be a substitute for any form of esta blishe d process, proced ure, or equipm ent used to monitor or safeguard human health and safety in medical or clinical treatment.

FCC/DOC Radio Frequency Interference Class A Compliance

This equipment generates and uses radio frequency energy and, if not installed and used in strict accordance with the instructions in this manual, may cause interference to radio and television reception. Classification requirements are the same for the Federal Communications Commission (FCC) and the Canadian Department of Communications (DOC). This equipment has been tested and found to comply with the following two regulatory agencies:

Federal Communications Commission

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

Notices to User: Changes or modifications not expressly approved by National Instruments could void

If necessary, consult National Instruments or an experienced radio/television technician for additional suggestions. The following booklet prepared by the FCC may also be helpful: Interference to Home Electronic Entertainment Equipment Handbook. This booklet is available from the U.S. Government Printing Office, Washington, DC 20402.

the user’s authority to operate the equipment under the FCC Rules. This device complies with the FCC rules only if used with shielded interface cables of

suitable quality and construction. National Instruments used such cables to test this device and provides them for sale to the user. The use of inferior or nonshielded interface cables could void the user’s authority to operate the equipment under the FCC rules.

Canadian Department of Communications

This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.

Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.

About This Manual

Organization of This Manual........................................................................................ix

Conventions Used in This Manual................................................................................x

How to Use This Documentation Set ...........................................................................xi

Related Documentation........................................... .................................. ....................xii

Customer Communication............................................................... .............................xii

Chapter 1 Introduction

Overview.......................................................................................................................1-1

Optional Equipment.................................................................................. ....................1-3

Optional Software.............................................................. .................................. .........1-3

Hardware Description...................................................................................................1-4

Slot 0 Functionality ........................................................................................1-4

Custom Application-Specific Interface Chips................................................1-5

Front Panel Features..................................................... ................................. .1-6

Peripheral Expansion......................................................................................1-7

Table

Contents

Chapter 2 Functional Overview

VXIpc 800 Functional Description ...............................................................................2-1

Chapter 3 VXIpc 800 Series Configuration and Installation

Default Settings.............................................................................................................3-1

Configuring the VXIpc 800 Series ...............................................................................3-4

How to Remove the Metal Enclosure............................................................. 3-4

VXIbus Slot 0/Non-Slot 0..............................................................................3-4

VXIbus CLK10 Routing.................................................................................3-5

Trigger Input Termination..............................................................................3-8

EEPROM........................................................................................................3-8

How to Fix an Invalid EEPROM Configuration..............................3-9

Installed System RAM ............................................................ .......................3-10

Table of Contents

Configuring the PC....................................................................................................... 3-10

SCSI Termination ....................... .................................. .................................3-11

GPIB Interrupt Level .....................................................................................3-11

System CMOS................................................................................................3-12

Parallel Port DMA Level ...............................................................................3-12

Ethernet Power-On Defaults.......................................................................... 3-13

Installing the VXIpc 800 Series ...................................................................................3-13

Chapter 4 BIOS

Entering BIOS Setup.......................................................... .................................. ........ 4-1

Appendix A Specifications

Appendix B VXIpc 800 Series System Resources

Appendix C LED Indicators

Appendix D Front Panel and Connectors

Appendix E Modifying and Installing I/O Expansion Boards

Appendix F Common Questions

Appendix G Customer Communication

Glossary

VXIpc 800 Series User Manual vi © National Instruments Corporation

Index

Figures

Table of Contents

Figure 1-1. VXIpc-850 Embedded Computer..........................................................1-1

Figure 1-2. VXIpc-860 Embedded Computer..........................................................1-2

Figure 2-1. VXIpc 800 Series Block Diagram.........................................................2-2

Figure 3-1. VXIpc 800 Series Parts Locator Diagram .............................................3-2

Figure 3-2. VXIbus Slot Configuration....................................................................3-5

Figure 3-3. VXIbus CLK10 Routing........................................................................3-6

Figure 3-4. SMB CLK10 Direction..........................................................................3-6

Figure 3-5. SMB CLK10 Termination.....................................................................3-7

Figure 3-6. SMB CLK10 Polarity ............................................................................3-7

Figure 3-7. SMB Trigger Input Termination............................................................3-8

Figure 3-8. Power-On Self Configuration Status .....................................................3-8

Figure 3-9. EEPROM Configuration......................................................... ...............3-9

Figure 3-10. SCSI Termination................................................................... ...............3-11

Figure 3-11. GPIB Interrupt Level.............................................................................3-11

Figure 3-12. System CMOS .......................................................................................3-12

Figure 3-13. Parallel Port DMA Channel...................................................................3-12

Figure 3-14. Ethernet Power-On Defaults..................................................................3-13

Figure D-1. VXIpc-800 Front Panel Layout and Dimensions ..................................D-2

Figure D-2. Keyboard and Mouse Connectors Location and Pinout ........................D-3

Figure D-3. VGA Connector Location and Pinout....................................................D-4

Figure D-4. Ethernet Connector Location and Pinout...............................................D-5

Figure D-5. COM1 and COM2 Connectors Location and Pinout.............................D-7

Figure D-6. Parallel Port Connector Location and Pinout ........................................D-8

Figure D-7. SCSI Connector Location and Pinout (SCSI II)....................................D-10

Figure D-8. GPIB Connector Location and Pinout ...................................................D-12

Figure D-9. SMB Connectors Location and Pinout ..................................................D-14

Figure D-10. Speaker Connection Location................................................................D-15

Figure D-11. VXIbus Connectors Location and Pinout..............................................D-17

Figure E-1. I/O Board Dimensions for VXIpc-850 Expansion Slot.........................E-1

Figure E-2. Component Height Restrictions for PCI Plug-In Boards Used with the VXIpc-850

E-2

Figure E-3. Length Restrictions for ISA Plug-In Boards Used with the

VXIpc-850 when SIMMs Taller than 0.85 in. are Used........................E-3

Figure E-4. I/O Board Dimensions for VXIpc-860 Expansion Slot.........................E-4

Table of Contents

Figure E-5. Length Restrictions for PCI Plug-In Boards Used wit h the

Figure E-6. Length Restrictions for ISA Plug-In Boards Used with the

Figure E-7. PCI Board and ISA Board Installed in a VXIpc-800............................E-8

Figure E-8. Side View of PCI Board with Expansion Bracket ................................ E-8

Figure E-9. Front View of PCI Board Expansion Bracket....................................... E-9

Figure E-10. Side View of ISA Board with Expansion Bracket................................E-10

Figure E-11. Front View of ISA Board Expansion Bracket....................................... E-11

Tables

Table 1-1. VXIpc 800 Series Peripherals Overview............................................... 1-8

Table 3-1. VXIpc 800 Series Hardware Default Settings.......................................3-3

Table B-1. VXIpc 800 Series ISA Interrupt Resource Allocations.........................B-1

Table B-2. VXIpc 800 Series DMA Channel Resource Allocations ...................... B-2

Table B-3. VXIpc 800 Series I/O Address Map......................................................B-3

Table C-1. LEDs and System Startup Status........................................................... C-2

VXIpc-860.............................................................................................E-5

VXIpc-860 when SIMMs Taller than 0.85 in. are Used....................... E-6

Table D-1. Keyboard and Mouse Connector Signals..............................................D-3

Table D-2. VGA Connector Signals........................................................................D-4

Table D-3. Ethernet Connector Signals...................................................................D-6

Table D-4. COM1 and COM2 Connector Signals................................................... D-7

Table D-5. Parallel Port Connector Signals.............................................................D-9

Table D-6. SCSI Connector Signals........................................................................D-11

Table D-7. GPIB Connector Signals ....................................................................... D-13

Table D-8. SMB Connector Signals........................................................................ D-14

Table D-9. Signal Characteristics for SMB and Speaker Connections................... D-16

Table D-10. VXIbus P2 Connector Signals............................................................... D-17

Table D-11. VXIbus P1 Connector Signals............................................................... D-19

VXIpc 800 Series User Manual viii © National Instruments Corporation

This manual contains instructions for installing and configuring the National Instruments VXIpc 800 Series embedded computer kit. The VXIpc 800 Series includes all the models of the VXIpc-800 embedded computers.

Organization of This Manual

This manual is organized as follows:

• Chapter 1, embedded VXI computers, lists what you need to get started, describes the hardware, and lists optional equipment and software.

• Chapt er 2, of each major logic block on the VXIpc 800 Series embedded computers.

• Chapter 3, contains the instructions to configure and install the VXIpc 800 Series embedded computer.

• Chapter 4, interface between the hardware and PC software that configures and tests your hardware at boot up.

• Appendix A, electrical, and mechanical specifications of the VXIpc 800 Series embedded computer.

• Appendix B, system resources are available on the VXIpc 800 Series and where they are allocated.

• Appendix C, the front panel to interpret the status of the VXIpc 800 Series.

• Appendix D, panel and connectors on the VXIpc 800 Series.

Introduction

Functional Overview

VXIpc 800 Series Configuration and Installation

BIOS

, contains information on BIOS, the low-level

Specifications

VXIpc 800 Series System Resources

LED Indicators

Front Panel and Connectors

About

This

Manual

, describes the VXIpc 800 Series of

, contains functional descriptions

, describes the environmental,

, describes what

, describes how to read the LEDs on

, describes the front

About This Manual

• Appendix E, explains how to modify and install an I/O board in the VXIpc 800 Series.

• Appendix F, may have when using the VXIpc 800 Series.

• Appendix G, use to request help from National Instruments or to comment on our products and manuals.

•The

Glossary

used in this manual, including abbreviations, acronyms, metric prefixes, mnemonics, and symbols.

Index

in this manual, including the page where you can find each one.

Modifying and Installing I/O Expansion Boards

Common Questions

Customer Communication

contains an alphabetical list and description of terms

contains an alphabetical li st of key terms and to pics used

, answers common questions you

, contains forms you can

Conventions Used in This Manual

The following conventions are used in this manual:

< > Angle brackets enclose the name of a key on the keyboard (for example,

<Option>.

- A hyphen between two or more key names enclosed in angle brackets denotes that you should simultaneously press the named keys—for example, <Control-Alt-Delete>.

♦ The ♦ symbol indicates that the text following it applies only to a

specific product, a specific operating system, or a specific software version.

This icon to the left of bold italiciz ed text de notes a n ote, which alerts you to important information.

bold Bold text denotes the names of menus, menu items, dialog box buttons

bold italic Bold italic text denotes a note, caution, or warning.

bold monospace Bold text in this font denotes the messages and responses that the

This icon to the left of bold italiciz ed text de notes a ca ution, wh ich advises you of precautions to take to avoid injury, data los s, or a system crash.

This icon to the left of bold italiciz ed text de notes a w arning, wh ich advises you of precautions to take to avoid being elec trically shocked.

or options, or LEDs.

computer automatically prints to the screen.

VXIpc 800 Series User Manual x © National Instruments Corporation

About This Manual

italic

monospace Text in this font denotes text or characters that are to be literally input

VXIpc 800 Series The terms

Italic text denotes emphasis, a cross reference, or an introduction to a key concept. This font also denotes text from which you supply the appropriate word or value, as in Windows 3.x.

from the keyboard, sections of code, programming examples, and syntax examples. This font is also used for the proper names of disk drives, paths, directories, device names, functions, variables, filenames, and extensions.

VXIpc 800 Series

dual-slot VXI controllers. Currently, this series consists of the VXIpc-850 and VXIpc-860, with various processors and in different speeds.

Abbreviations, acronyms, metric prefixes, mnemonics, symbols, and terms are listed in the

Glossary

and

VXIpc-800

refer to a series of C-size,

How to Use This Documentation Set

Begin by reading the manual for basic instructions for setting up the hardware and software. This is a brief quick start manual that describes how to get started with your kit using the default hardware and software settings, and how to configure and use the NI-VXI software. Refer to the following manuals for more information about the hardware or software.

Getting Started with Your VXIpc 800/700 Series

This manual, the about changing the installation or configuration from the defaults, and using the hardware.

When you are familiar with the material in these manuals, you can begin to use the VXI and prepares you for detailed explanations of the NI-VXI functions. Study the descriptions of each function given in the

Programmer Reference Manual

syntax of each function. These two manuals are available in the

c:\NIVXI\Manuals directory under the names

NI-VXIUsersMan.pdf and NI-VXIProgrammerMan.pdf,

respectively. Use the Acrobat Reader 3.0 program to open and view these files. You can also access the NI-VXI online help for Windows 95/NT/3.1 in the NIVXI folder.

VXIpc 800 Series User Manual

NI-VXI User Manual

. This manual presents the concepts of

to fully understand the purpose and

, contains more details

NI-VXI

About This Manual

Refer to the it in your system. The NI-VISA online help describes the attributes, events, and operations you can use in NI-VISA. The user manual is available in the is either the Acrobat Reader program, Version 3 or later, to open this file.

NI-VISA User Manual

c:\VXIpnp\os\NIvisa\Manuals directory (where

Win95 or WinNT) under the name NI-VISAUsersMan.pdf. Use

Customer Communication

National Instruments wants to receive your comments on our products and manuals. We are interested in the applications you develop with our products, and we want to help if you have prob lems with them. To make it easy for you to contact us, this manual contains comment and configuration forms for you to complete. These forms are in Appendix G,

Customer Communication

VME64

to learn about VISA and how to use

IEEE Standard for a Versatile

IEEE VMEbus Extensions for

, Rev. 1.0,

, at the end of this manual.

VXIpc 800 Series User Manual xii © National Instruments Corporation

Chapter

Introduction

This chapter describes the VXIpc 800 Series of embedded VXI computers, lists what you need to get started, describes the hardware, and lists optional equipment and software.

Overview

Figure 1-1 shows a VXIpc-850 model with its cover removed.

Figure 1-1.

VXIpc-850 Embedded Computer

Chapter 1 Introduction

Figure 1-2 shows a VXIpc-860 model with its cover removed.

VXIpc-860

Figure 1-2. VXIpc-860 Embedded Computer

The VXIpc 800 Series controllers are C-size, embedded computers based on the Peripheral Component Interface (PCI) bus and Industry Standard Architecture (ISA). These computers are high-performance, easy-to-use platforms for controlling VXIbus systems, featuring complete VXI functionality through interactive utilities and C function calls. In addition, the VXIpc 800 Series has Ethernet capability plus an IEEE 488.2 interface that is compatible with the NI-488.2 architecture.

The VXIpc 800 Series is a custom computer that you install directly in two C-size slots of your VXIbus mainframe. An embedded computer can take full advantage of the VXI high-performance backplane capabilities and give you direct control of VXI registers, memory, interrupts, and triggers.

All models in the VXIpc 800 Series are fully VXI

plug&play

compliant and are compatible with PC-compatible software tools, the National Instruments LabVIEW and LabWindows

™

/CVI application software,

and the NI-VXI, NI-VISA, and NI-488.2 bus interface software.

VXIpc 800 Series User Manual 1-2 © National Instruments Corporation

Optional Equipment

You can contact National Instruments to order any of the following optional equipment:

• COM1/2 adapter cable

• Enhanced parallel port adapter cable

• Single-shielded 2 m GPIB cable

• Upgrades for the VXIpc 800 Series modular CPU card

Optional Software

National Instruments has developed several software kits that you can use with the VXIpc 800 Series. The NI-VXI bus interface software for the VXIpc 800 includes a Resource Manager, an interactive VXI resource editor program, a comprehensive library of software routines for VXI/VME programming, and an interactive control program for interacting with VXI/VME. You can use this software to seamlessly program multiple-mainframe configurations and have software compatibility across a variety of VXI/VME controller platforms.

Chapter 1 Introduction

The NI-488.2 software kit gives you accessibility to the industry-standard NI-488.2 software for controlling external GPIB instruments through the GPIB port on the front panel of your VXIpc 800 Series. The GPIB interface on your VXIpc controller is fully compatible with the NI-488.2 driver for a variety of operating systems. Any software using NI-488.2 will run on the VXIpc 800.

You can also use the National Instruments LabVIEW and LabWindows/CVI application programs and instrument drivers to ease your programming task. These standardized programs match the modular virtual instrument capability of VXI and can reduce your VXI/VMEbus software development time. These programs are fully

plug&play

VXI instrument drivers written to take full advantage of direct VXI control.

LabVIEW is a complete programming environment that departs from the sequential nature of traditional programming languages and features a graphical programming environment.

compliant and feature extensive libraries of VXI

Chapter 1 Introduction

LabWindows/CVI is an interactive C development environment for building test and measurement and instrument control systems. It includes interactive code-generation tools and a graphical editor for building custom user interfaces.

LabVIEW and LabWindows/CVI include all the tools needed for instrument control, data acquisition, analysis, and presentation. When you order the LabVIEW Full Development System for Windows or the LabWindows/CVI Full Development System for Windows, you also get more than 500 complete instrument drivers, which are modular, source-code programs that handle the communication with your instrument to speed your application development.

Hardware Description

The VXIpc 800 Series controllers feature a modular, PCI-based local bus design that makes it easy to use interchangeable daughterboards to upgrade your controller to new microprocessors, without having to replace the motherboard or enclosure.

The VXIpc 800 Series currently consists of two models—the VXIpc-850 and the VXIpc-860—which vary in p rocessors and sp eeds.

The CPU module and its memory sockets are easily accessible for you to install additional DRAM in the field:

• Up to 128 MB for the VXIpc-850

• Up to 256 MB for the VXIpc-860 The VXIpc 800 contains at least an 800 MB internal, enhanced IDE

hard disk. For information on adding RAM by installing SIMMs, refer to Appendix A,

Specifications

Slot 0 Functionality

You can use the VXIpc 800 Series computers to achieve full VXI Slot 0 control of your VXI system. You can also install the VXIpc 800 in another slot and use it in Non-Slot 0 mode. You do not have to change any switches or jumpers when moving between these two modes, as the VXIpc 800 can automatically detect whether it is installed in Slot 0 and it will automatically enable or disable the Slot 0 onboard circuitry.

VXIpc 800 Series User Manual 1-4 © National Instruments Corporation

Custom Application-Specific Interface Chips

The VXIpc 800 Series uses the MITE and MANTIS custom ASICs to deliver high VXI performance, and can achieve more than 20 MB/s DMA block-mode data transfer rates across the VXI backplane.

The VXIpc 800 Series has the TNT4882C custom ASIC to give full GPIB control of external instruments via a front-panel connector. GPIB capability is fully compatible with IEEE 488.2 and the industry-standard NI-488.2 driver for a variety of operating systems.

The MITE custom ASIC is a sophisticated dual-channel DMA controller with standard interfaces for VXI and PCI. By using MITE DMA to transfer data and commands to and from devices, the MITE frees the computer’s microprocessor to perform other tasks such as data analysis and presentation. In addition to DMA, the MITE incorporates the new VME64 MBLT (8-byte block transfers in which both the address bus and data bus are used to transfer data) directly into the ASIC to perform the fastest transfer operation to instruments. With the multiple windowing scheme of the MITE, you can easily access all of VXI address space.

The VXI trigger interface on the VXIpc 800 is based on the MANTIS custom ASIC. The VXIpc 800 front panel has two SMB trigger I/O connectors, which you can use to route any of the TTL trigger lines between the backplane and external devices. The MANTIS ASIC on the VXIpc 800 provides the complete VXI interface to the backplane connector in a single chip. The VXIpc 800 can respond to all VXI-defined protocols on all P2 TTL and ECL trigger lines at the same time. The MANTIS features an internal cross-matrix switching system for routing between lines as well as to and from the front panel and onboard clocks.

Chapter 1 Introduction

Note: The MANTIS ASIC contains the exact functionality of the TIC ASIC,

which appeared on the VXIpc-486 Model 500 Series controllers. Any application that currently uses any of the TIC functionality, such as the crosspoint switch and counter/timers, can run on a controller containing the MANTIS ASIC without modification.

Chapter 1 Introduction

Front Panel Features

The VXIpc 800 has the following front-panel features:

• PCMCIA slots

• One full-size expansion slot (on the VXIpc-850 only) that accepts

• One half-length expansion slot (on the VXIpc-860 only) that

• Internal 3.5 in. floppy drive

• System reset push-button

• 13 front-panel connectors as listed below

• Six front-panel LEDs that show VXI and PC status

– The VXIpc 800 Series has one Type I/II and one Type I/II/III

slot.

either a PCI or a PC ISA (XT-height) plug-in board

accepts either a PCI or a PC ISA (XT-height) plug-in board

– Two RS-232 Serial – Extended Capabilities Parallel (ECP) – VGA Controller – IEEE 488.2 – 10BaseT Ethernet – SCSI-2 – External Clock – Trigger Output – Trigger Input – Audio Output – PS/2-Style Keyboard – PS/2-Style Mouse

– SYSFAIL LED indicates that the VMEbus SYSFAIL line is

asserted.

– FAILED LED indicates that the VXIpc 800 is driving the

SYSFAIL signal.

– TEST LED indicates that the VXIpc 800 is performing its

self-tests or startup Resource Manager operations.

– ON LINE LED indicates that the VXIpc 800 is performing or

has completed its startup Resource Manager operations.

VXIpc 800 Series User Manual 1-6 © National Instruments Corporation

• Four front-panel LEDs that show Ethernet port status (VXIpc 800

Peripheral Expansion

The VXIpc 800 uses the PCI local bus and ISA bus for peripheral expansion. The PCIbus is a 32-bit multimaster bus that achieves a top throughput of 132 MB/s and can handle numerous peripherals. The ISA bus is the legacy peripheral bus found on current and older PCs.

Chapter 1 Introduction

– ACCESS LED indicates when the VXIpc 800 MODID line is

asserted or the VXIbus registers or shared memory are accessed by another bus master.

– DRIVE LED indicates when the internal hard drive is in use.

Series only) – RX LED indicates that the VXIpc 800 Series is receiving data

through its Ethernet port.

– TX LED indicates that the VXIpc 800 Series is transmitting

data through its Ethernet port.

– DSEL LED indicates that the Ethernet circuitry is being

accessed.

– LINK LED reflects Ethernet link status.

For information on installing and configuring these peripherals for use with the VXIpc 800, refer to the

drivers.txt file explains how to install support for each peripheral.

c:\images\manuals directory. The

This directory also contains manufacturer’s documentation for the video, PCMCIA, and SCSI peripherals. Also refer to the

readme files

for the most up-to-date information. Table 1-1 lists the various peripherals and describes the external

connector, its bus interface, and its function.

Chapter 1 Introduction

Table 1-1. VXIpc 800 Series Peripherals Overview

Peripheral External Connector

ISA

or PCI

Function

Video 15-pin DSUB

(standard VGA)

PCI High-resolution/ color support for a

Super VGA monitor IDE None PCI Supports internal fast ATA-2 hard drive Ethernet RJ-45 ISA 10BaseT Ethernet connection PCMCIA Type I/II and Type I/II/III PCI Supports two independent PCMCIA slots SCSI 36-pin SCSI-2 PCI External SCSI-2 connection for hard

drives, CD-ROM drives, and so on GPIB 24-pin CHAMP ISA IEEE 488.2 interface compatible with the

National Instruments AT-GPIB/TNT VXI Two 96-pin DIN

PCI High-performance VXIbus interface

(rear of board) Serial Serial Port (Mini DSUB) ISA 16550 serial ports Parallel Parallel Port (IEEE 1284) ISA Extended capabilities

VXIpc 800 Series User Manual 1-8 © National Instruments Corporation

Chapter

Functional Overview

This chapter contains functional descriptions of each major logic block on the VXIpc 800 Series embedded computer s.

VXIpc 800 Functional Description

The VXIpc 800 is a modular PC in a VXIbus C-size form factor. It includes many high-performance peripherals that normally require add-in cards on desktop PCs. In addition, it has a VXIbus interface that is controlled from the PCI local bus, providing extremely high performance and reliability.

Figure 2-1 is a functional block diagram of the VXIpc 800 Series. Following the diagram is a description of each logic block shown.

Chapter 2 Functional Overview

Memory

PCI-Based CPU Card

Cache

Chipset

32-bit, 5 V PCI Local Bus

CPU

Video

SCSI

PCI Expansion Slot

System I/O

ISA Expansion Slot

Ethernet GPIB PC Peripherals

Miniature

RJ-45

Connector

Miniature

GPIB

Connector

SCSI

SCSI-2

Connector

ECP

Parallel

Miniature Serial (2)

Speaker

Keyboard

Mouse

Reset

IDE

(Internal)

RTC

PCMCIA

Type I/II/III Slot

Type I/II Slot

Floppy

Figure 2-1. VXIpc 800 Series Block Diagram

VXI

MITE

MANTIS

VXI BusISA Bus

VXIpc 800 Series User Manual 2-2 © National Instruments Corporation

Chapter 2 Functional Overview

The VXIpc 800 consists of the following logic blocks: Video The video circuitry is a plug-in PCI card that has

a 64-bit data path to up to 4 MB of EDO DRAM.

IDE This is dedicated PCI-IDE circuitry providing

fast ATA-2 transfers to the internal hard drive.

PCMCIA This is a dedicated PCI-PCMCIA interface that

supports two independent PCMCIA cards. One socket can accommodate a Type I, II, or III card while the other accommodates a Type I or II card.

VXI This is the PCI-VXIbus interface circuitry.

The MITE is a National Instruments ASIC developed to efficiently manage data transfers between the VXIbus and the processor (via the PCI bus). The MANTIS ASIC (also developed by National Instruments) performs VXIbus arbitration and manages interrupts and triggers. Also part of the VXIbus interface a re the SMB connectors, which you can use to route triggers and the CLK10 signal to or from the VXIbus.

Ethernet This is an ISA-based Ethernet circuit on the

VXIpc 800 Series. It uses an RJ-45 connector for access to an external Ethernet-based LAN.

GPIB This logic block represents the IEEE 488.2 port

on the VXIpc 800 Series. It uses the National Instruments TNT4882 ASIC for maximum performance as an ISA-based GPIB controller.

PC Peripherals These blocks represent the other peripherals

supplied by the VXIpc 800. The VXIpc 800 Series has PS/2 mouse and keyboard ports, two miniature serial ports, and ECP/EPP parallel port, speaker jack, reset button, and a 1.44 MB,

3.5 in. floppy drive.

Chapter 2 Functional Overview

CPU Card The modular architecture of the VXIpc 800

Series contains a plug-in CPU card that can accommodate various Pentium/Pentium Pro-class processors. This card includes the CPU, chipset support that connects the CPU subsystem to the PCI bus, and the system cache and RAM.

System I/O This block has the bridge between the PCI bus

and the ISA bus. It also has PCI bus arbitration logic and integrates PC-specific hardware such as the DMA and interrupt controllers.

PCI Expansion Slot This is a general-purpose PCI slot. It can

accommodate any standard 5 V, 32-bit PCI card with a modified mounting bracket.

ISA Expansion Slot This is a general-purpose ISA expansion slot.

The VXIpc-860 can accommodate a half-length XT-size card, while the VXIpc-850 can accommodate a full-length XT-size card. However, the DRAM configuration may mechanically interfere with a full-length card. Refer to Appendix E,

I/O Expansion Boards

Modifying and Installing

, for more information.

SCSI The SCSI circuitry uses a PCI-SCSI bridge to

provide a flexible SCSI-2 connection on the front panel, usable for such devices as external hard disks and CD-ROM drives.

VXIpc 800 Series User Manual 2-4 © National Instruments Corporation

VXIpc 800 Series Configuration and

Chapter

Installation

This chapter contains the instructions to configure and install the VXIpc 800 Series embedded computer. Unless otherwise noted, these instructions apply to all models in the VXIpc 800 Series, which currently consists of the VXIpc-850 and the VXIpc-860.

Caution:

Default Settings

Electrostatic discharge can damage several components on your VXIpc-800 module. To avoid such damage in handling the module, touch the antistatic plastic package to a metal part of your VXI chassis before removing the module from the package.

This section summarizes the hardware default settings for the VXIpc 800 Series for easy reference. The module is set at the factory for the most commonly used configuration.

Figure 3-1 shows the location and factory-default settings of most of t he configuration switches and jumpers on the VXIpc 800 Series.

Chapter 3 VXIpc 800 Series Configuration and Installation

8 9

6 5

2 1

1 Trigger In Termination (S7) 2 CLK10 Inversion (S4) 3 Ethernet EEPROM Config. (S1) 4 LPT DMA Channel (W4) 5 MITE EEPROM Config. (S9) 6 MITE Self Config. (S2)

7 Slot 0 Identification (W13) 8 CLK10 Source (S3) 9 Serial Number 10 Product Name 11 Assembly Number 12 CLK10 Direction (S5)

12 13

13 GPIB IRQ Level (S8) 14 CMOS (W2) 15 SCSI Termination (W1) 16 CLK10 Termination (S6)

Figure 3-1. VXIpc 800 Series Parts Locator Diagram

VXIpc 800 Series User Manual 3-2 © National Instruments Corporation

Chapter 3 VXIpc 800 Series Configuration and Installation

Table 3-1 lists the factory-default settings and options for the onboard jumpers and switches.

Table 3-1. VXIpc 800 Series Hardware Default Settings

Jumper/

Switch

W1 Supply SCSI termination

Default

Setting

Optional

Setting

Disable SCSI termination

power W2 Normal CMOS operation Clear CMOS W4 LPT1 uses DMA Channel 1 LPT uses DMA Channel 3

W13 Enable automatic Slot 0

detection

S1 Enable Ethernet EEPROM

configuration

Force Slot 0; Force Non-Slot 0

Disable Ethernet EEPROM configuration (uses default power on values)

S2 Enable MITE

self-configuration

S3 Source CLK10 from

Disable MITE self-configuration

Source CLK10 from SMB

onboard oscillator

S4 Non-inverted CLK10

Inverted CLK10 output

output

S5 Receive CLK10 input from

SMB

S6 No termination on CLK10

input

S7 No termination on external

trigger input

Source CLK10 output to SMB

Terminate CLK10 input to 50 Ω

Terminate external trigger input to 50 Ω

S8 GPIB uses IRQ11 GPIB uses IRQ5 S9 MITE user configuration MITE factory configuration

Chapter 3 VXIpc 800 Series Configuration and Installation

Configuring the VXIpc 800 Series

This section describes how to configure the following options on the VXIpc-800:

• VXIbus Slot 0/Non-Slot 0

• VXIbus CLK10 routing

• Trigger input termination

• EEPROM

• Installed system RAM

How to Remove the Metal Enclosure

The VXIpc-800 is housed in a metal enclosure comprised of a top and bottom cover to improve EMC performance and to provide easy handling. You must remove the top cover to change many of t he switch and jumper settings. You must also remove the top cover to change the amount of DRAM installed on the module.

Remove the top cover by removing the 12 screws that attach it to the module.

VXIbus Slot 0/Non-Slot 0

The VXIpc-800 is configured at the factory to automatically detect if it is installed in Slot 0 of a VXIbus mainframe. With automatic Slot 0 detection, you can install the module into any VXIbus slot.

You can manually configure the VXIpc-800 for either Slot 0 or Non-Slot 0 operation by defeating the automatic-detection circuitry. Use the three-position jumper W13 to select automatic Slot 0 detection, Slot 0, or Non-Slot 0 operation. Figure 3-2 shows these three settings.

Caution: Do not install a device configured for Slot 0 into another slot without

VXIpc 800 Series User Manual 3-4 © National Instruments Corporation

first reconfiguring it to either Non-Slot 0 or automatic configuration. Neglecting to do this could result in damage to the device, the VXIbus backplane, or both.

Chapter 3 VXIpc 800 Series Configuration and Installation

When the VXIpc-800 is installed in Slot 0, it becomes the VXIbus System Controller. In this role, it has VXIbus Data Transfer Bus Arbiter circuitry that accepts bus requests on all four VXIbus request levels, prioritizes the requests, and grants the bus to the highest priority requester. As VXIbus System Controller, the VXIpc-800 also drives the 16 MHz VXIbus system clock by an onboard 16 MHz oscillator.

As required by the VXIbus specification, the VXIpc-800 drives the 10 MHz signal CLK10 on a differential ECL output when installed in Slot 0. When not installed in Slot 0, the VXIpc-800 only receives the CLK10 signal.

VXIbus CLK10 Routing

When the VXIpc-800 is installed in Slot 0 of your mainframe, it supplies the VXIbus CLK10 signal. The VXIpc-800 can use two different sources to generate this signal: an onboard oscillator, or the external CLK SMB connector. Use switch S3 to select these options, as shown in Figure 3-3.

W13

a. Manual Non-Slot 0

Configuration

Figure 3-2. VXIbus Slot Configuration

W13 W13

b. Automatic Slot 0 Detection (Default)

c. Manual Slot 0

Configuration

Chapter 3 VXIpc 800 Series Configuration and Installation

Notice that Figure 3-3b also shows switch S5. You must configure these switches as shown when using the corresponding CLK10 source setting of S3.

a. CLK10 Generated from Onboard

Oscillator (Default)

The VXIpc-800 can also be configured to drive the external CLK SMB signal from the VXIbus CLK10 signal. Switch S5 controls whether the VXIpc-800 drives or receives the external CLK SMB signal. If you change the S5 setting to drive CLK10 out the external CLK10 SMB connector (Figure 3-4b), do not set S3 to source CLK10 to the backplane from the SMB; instead use the setting shown in Figure 3-3a.

S3 S3

b. CLK10 Generated from SMB

Figure 3-3. VXIbus CLK10 Routing

S5S5

a. CLK10 SMB Receives 10 MHz

Signal (Default)

b. CLK10 SMB Drives 10 MHz

Signal from VXIbus CLK10

Figure 3-4. SMB CLK10 Direction

VXIpc 800 Series User Manual 3-6 © National Instruments Corporation

Chapter 3 VXIpc 800 Series Configuration and Installation

When switch S5 is set so that the VXIpc-800 receives the SMB CLK10 signal, you have the option to add a 50 Ω termination to the signal by setting switch S6. Switch S6 is unused—its setting does not matter— when S5 is configured to drive the external CLK SMB signal. Figure 3-5 shows the settings for switch S6.

S6S6

a. Does Not Terminate CLK10

SMB Input (Default)

b. Terminates CLK10

SMB Input

Figure 3-5. SMB CLK10 Termination

You can use an additional switch, S4, to control the polarity of the external CLK SMB signal when S5 is configured to drive it. S4 is unused—its setting does not matter—when S5 is configured to receive the external CLK SMB signal.

S4S4

a. Noninverted CLK10 Output

from SMB (Default)

b. Inverted CLK10 Output

from SMB

Figure 3-6. SMB CLK10 Polarity

Chapter 3 VXIpc 800 Series Configuration and Installation

Trigger Input Termination

You can use switch S7 to terminate the external trigger input SMB with 50 Ω to ground. Figure 3-7a shows the default setting for a non-terminated trigger input SMB. Use the setting of Figure 3-7b to terminate the trigger input SMB. Switch S7 is located above switches S4, S5, and S6, which have no effect on this configuration.

S7S7

EEPROM

a. Does Not Terminate

Trigger Input (Default)

Figure 3-7.

SMB Trigger Input Termination

b. Terminate Trigger Input

The VXIpc-800 has an onboard EEPROM, which stores default register values for the VXI circuitry. These values are loaded when you power up the computer. These values read from the EEPROM tell the PCI interface of the VXIbus registers so that the VXI interface is ready to respond to Resource Manager accesses within the required 5 s of SYSRST* deasserting. You can use switch S2 to disable this power-on self-configuration (POSC) circuit. Although this makes the VXI circuitry unusable, it is sometimes helpful in debugging address and interrupt conflicts with add-in boards. In general, howev er, you should leave switch S2 in its factory-default setting. Figure 3-8 shows the possible configurations for S2.

S2S2

a. VXI Circuitry Loads Power-on

Defaults from EEPROM (Default)

b. Power-on Self Configuration

Circuit is Disabled

Figure 3-8.

VXIpc 800 Series User Manual 3-8 © National Instruments Corporation

Power-On Self Configuration Status

Chapter 3 VXIpc 800 Series Configuration and Installation

The EEPROM is divided into two halves; one hal f is factory configured and one half is user configurable. Use switch S9 to control the operation of the EEPROM. The setting of this switch determines whether the VXIpc-800 boots off the factory-configured half or the user-modified settings. This is useful in the event that the user-configured half of the EEPROM becomes corrupted in such a way that the VXIpc-800 boots to an unusable state. In its default setting, the VXIpc-800 boots off the user-configurable half.

Figure 3-9 shows the configuration settings for EEPROM operation.

S9S9

a. Boot from User

Configuration (Default)

Figure 3-9. EEPROM Configuration

b. Boot from Protected

Configuration

How to Fix an Invalid EEPROM Configuration

The NI-VXI software includes a configuration utility you can use to edit the configuration of the VXIpc-800. Use T&M Explorer under Windows 95/NT, or VXIedit for all other platforms. Some of these settings are stored in files that are read by the NI-VXI software, while other settings are stored directly in the VXIpc-800 EEPROM. Certain EEPROM configurations can lock up your PCI computer while it is booting up. Generally, only the size and location of the memory windows can cause your VXIpc-800 to lock up your system. For example, many PCI-based computers will not boot if a board in its system requests more memory space than the computer can allocate. If you encounter this situation you should reduce the size of the VXIpc-800 user window.

Chapter 3 VXIpc 800 Series Configuration and Installation

If this situation occurs after you change the configuration, perform the following steps to reconfigure the VXIpc-800.

1. Turn your computer off.

Warning: To protect both yourself and the mainframe from electrical hazards, the

mainframe should remain off until you are finished changing the settings on the VXIpc-800 module.

2. Change switch S9 to the OFF position as shown in Figure 3-9b to restore the factory configuration.

3. Turn on the computer. The computer should boot this time because the factory-default configuration is being used to initialize the VXIpc-800 module.

4. Run your software configuration utility to re-adjust the VXIpc-800 configuration.

5. After saving the configuration, exit Windows and turn off the computer.

6. Change switch S9 to the ON position, as shown in Figure 3-9a.

7. Turn on the computer. If the computer does not boot with this configuration, you will have to repeat these steps, modifying your configuration until a final configuration is reached.

Installed System RAM

The 16 MB of installed RAM is factory configured per customer order. You can change the amount of installed RAM on the VXIpc 800 Series by installing DRAM SIMMs. Refer to Appendix A, more information on SIMMs.

Specifications

, for

Configuring the PC

This section describes how to configure the following options on the PC:

• SCSI termination

• GPIB interrupt level

• Syste m CMO S

• Parallel po rt DMA level

• Ethernet power-on defaults

VXIpc 800 Series User Manual 3-10 © National Instruments Corporation

SCSI Termination

Chapter 3 VXIpc 800 Series Configuration and Installation

The VXIpc-800 uses active termination on the SCSI-2 bus. Because the VXIpc-800 is always an end device, you should not need to disable the termination; however, for informational purposes Figure 3-10 shows the jumper settings for both enabled and disabled termination.

GPIB Interrupt Level

a. Terminate SCSI

Signals (Default)

Figure 3-10.

b. Do Not Terminate

SCSI Signals

SCSI Termination

You can program the GPIB interface on the VXIpc-800 to use one of two ISA interrupts—5 or 11. Switch S8 controls which interrupt line the GPIB interface uses. Figure 3-11 shows these settings.

S8S8

a. GPIB Uses IRQ11 (Default) b. GPIB Uses IRQ5

Figure 3-11.

GPIB Interrupt Level

Chapter 3 VXIpc 800 Series Configuration and Installation

System CMOS

The VXIpc-800 contains a backed-up memory use d to store BIOS defaults and configuration information.

To clear the CMOS contents, simply short the pins of W2 as shown in Figure 3-12b.

Caution: You should not keep these two pins shorted because the CMOS memory

cannot be sustained when the power is turned off if these two pins are shorted.

Parallel Port DMA Level

You can use jumper W4 to configure the parallel port for either DMA level 1 or DMA level 3. Refer to Figure 3-13 for the jumper settings.

a. Normal Operation

(Default)

Figure 3-12.

W4 W4

a. Parallel Port Uses DMA

Channel 1 (Default)

Figure 3-13.

Parallel Port DMA Channel

b. Clear CMOS

Contents

System CMOS

b. Parallel Port Uses

DMA Channel 3

VXIpc 800 Series User Manual 3-12 © National Instruments Corporation

Ethernet Power-On Defaults

The VXIpc-800 Ethernet circuitry loads its power-on settings from an EEPROM. You should not change switch S1 from its default setting; however, the switch setting required to do so is included in Figure 3-14 for informational purposes.

Chapter 3 VXIpc 800 Series Configuration and Installation

S1S1

a. Ethernet Power-On Defaults

Loaded from EEPROM

Figure 3-14.

Installing the VXIpc 800 Series

This section contains general installation instructions for the VXIpc-800. Consult your VXIbus mainframe user manual or technical reference manual for specific instructions and warnings.

1. Plug in your mainframe before installing the VXIpc-800. The power cord grounds the mainframe and protects it from electrical damage while you are installing the module.

Warning: To protect both yourself and the mainframe from electrical hazards,

the mainframe should remain off until you are finished installing the VXIpc-800 module.

2. Remove or open any doors or covers blocking access to the mainframe slots.

3. If you are installing the VXIpc-800 into a D-size mainframe, install a support designed for installing C-size boards in D-size mainframes. The VXIpc-800 has no P3 connector and cannot provide P3 Slot 0 control to VXI devices requiring this capability.

b. Hardwired Ethernet Values

Ethernet Power-On Defaults

Caution: If the VXIpc-800 is not configured for automatic Slot 0 detection, be

certain that the slot you select in your VXIbus mainframe matches the VXIpc-800 configuration as either a Slot 0 device or a N on-Slot 0 device. If you install your VXIpc-800 into a slot that does not correspond with the jumper setting, you risk damage to the VXIpc-800, the VXIbus backplane, or both.

Chapter 3 VXIpc 800 Series Configuration and Installation

4. Insert the VXIpc-800 in the slot you have selected b y aligning the top and bottom of the module with the card-edge guides inside the mainframe. Slowly push the VXIpc-800 straight into the slot until its plug connectors are resting on the backplane receptacle connectors. Using slow, evenly distributed pressure, press the module straight in until it seats in the expansion slot. The front panel of the VXIpc-800 should be even with the front panel of the mainframe.

5. Tighten the retaining screws on the top and bottom edges of the front panel.

6. Check the installation.

7. Connect the keyboard and mouse to the appropriate connectors. Use the keyboard adapter cable that your received with your kit to adapt AT-style keyboards to the VXIpc-800 mini-DIN connector.

8. Connect the VGA monitor video cable to the VGA connector.

9. Connect devices to ports as required by your system configuration. Some ports, such as the COM ports, have adapter cables that you can order from National Instruments.

10. Replace or close any doors or covers to the mainframe.

VXIpc 800 Series User Manual 3-14 © National Instruments Corporation

Chapter

BIOS

This chapter contains information on BIOS, the low-level interface between the hardware and PC software that configures and tests your hardware at boot up. This BIOS (Basic Input Output System) provides an easy-to-use graphical user interface to allow you to configure system aspects according to your needs.

Entering BIOS Setup

To enter the BIOS setup program, perform the following steps.

1. Turn on or reboot the system. A screen appears with a series of diagnostic checks.

2. When press the <DEL> key to enter the BIOS setup program.

3. Choose options with the keyboard. Modify the settings to reflect system options.

Hit <DEL> if you want to run SETUP appears,

Appendix

Specifications

This appendix describes the environmental, electrical, and mechanical specifications of the VXIpc 800 Series embedded computer. Unless otherwise specified, these specifications apply to all models in the VXIpc 800 Series.

Requirements

VXIbus Configuration Space 64 B A24 or A32 Space 16 KB Minimum (Programmable)

Electrical

Characteristic Specification

VXIpc-850

Current (A)

Voltage (V)

+5 5.82 A 12 A

-5.2 224.5 mA 2 A

-2 67.2 mA 2 A

+12 2.26 mA 2 A

-12 2.43 mA 2 A

Typical Maximum (Fused)

Appendix A Specifications

VXIpc-860

Current (A)

Physical

Voltage (V)

+5 8.52 A 12 A

-5.2 224.5 mA 2 A

-2 67.2 mA 2 A

+12 2.60 mA 2 A

-12 2.43 mA 2 A

Characteristic Specification

Size Two-slot VXIbus C-Size Module

Board Dimensions Fully Enclosed, Shielded VXI C-Size Board

Slot Requirements Two VXI C-Size Slots

Typical Maximum (Fused)

(233.35 by 340 by 60.96 mm)

233.35 by 340 mm (9.187 by 13.386 in.)

Compatibility Fully Compatible with VXI Specification VXI Keying Class Class 1 TTL MTBF VXIp c-850

22,094 hours

VXIpc-860

25,001 hours

Weight 2.5 Kg (5.5 lb) Typical

(16 MB DRAM Installed)

VXIpc 800 Series User Manual A-2 © National Instruments Corporation

Environmental

Appendix A Specifications

Characteristic Specification

Temperature 0° to 55° C Operating;

-20° to 70° C Storage

Relative Humidity

EMI FCC Class A Verified, EC Verified Vibration Operational: 5 to 500 Hz, 0.31 g, 3 axes

Functional Shock MIL-T-28800E Class 3 (per Section 4.5.5.4.1)

Note: Random vibration profiles were developed in accordance with

MIL-T-28800E and MIL-STD-810E Method 514. Test levels exceed those recommended in MIL-STD-810E for Category 1 (Basic Transportation, Figures 514.4-1 through 514.4-3). Test report available upon request.

VMEbus Capability Codes

Capability Code Description

A32, A24, A16 (master) VMEbus master A32, A24, and A16

0% to 95% Noncondensing, Operating; 0% to 95% Noncondensing, Storage

Non-operational: 5 to 500 Hz, 2.5 g, 3 axes

Half-Sine Shock Pulse (11 ms duration, 30 g peak, 3 shocks per face)

addressing

A32, A24, A16 (slave) VMEbus slave A32, A24, and A16

addressing

D64, D32, D16, D08(EO) (master)

D64, D32, D16, D08(EO) (slave)

VMEbus master D64, D32, D16, and D08 data sizes

VMEbus slave D64, D32, D16, and D08 data sizes

Appendix A Specifications

Capability Code Description

BLT, MBLT (master) VMEbus master block and D64 transfers BLT, MBLT (slave) VMEbus slave block and D64 transfers RMW (master) VMEbus master read/modify/write

transfers RMW (slave) VMEbus slave read/modify/write transfers RETRY (master) VMEbus master retry support RETRY (slave) VMEbus slave retry support FSD First slot detector SCON VMEbus System Controller

(Automatic Detection) PRI, RRS Prioritized or Round Robin Select arbiter ROR, FAIR Release on Request and FAIR bus requester IH(7-1) Interrupt handler for levels 7-1 I(7-1) Interrupt requester for levels 7-1 D32, D16, D08(O)

(Interrupt Handler) D32, D16, D08(O)

VMEbus D32, D16, D08(O) interrupt

handler

VMEbus D32, D16, D08(O) interrupter (Interrupter)

ROAK, RORA Release on Acknowledge or Register

Access interrupter BTO(x) VMEbus bus timer (programmable limit) LOCK Can lock the VMEbus for indivisible

transfers

VXIpc 800 Series User Manual A-4 © National Instruments Corporation

Adding RAM

Appendix A Specifications

To add RAM to the VXIpc 800, remove the top cover and add SIMM modules to the empty SIMM sockets.

National Instruments recommends the following types of SIMMs for use with the VXIpc-850 Series controller (Fast Page Mode):

8 MB: 2 MB x 36 SIMMs — 70 ns 16 MB: 4 MB x 36 SIMMs — 70 ns 32 MB: 8 MB x 36 SIMMs — 70 ns The VXIpc-860 can use Fast Page Mode (FPM), Extended Data Out

(EDO), or Bursts Extended Data Out (BEDO). National Instruments recommends the following types of SIMMs for use with the VXIpc-860:

8 MB: 2 MB x 32/36 SIMMs — 60 or 70 ns 16 MB: 4 MB x 32/36 SIMMs — 60 or 70 ns 32 MB: 8 MB x 32/36 SIMMs — 60 or 70 ns 64 MB: 16 MB x 32/36 SIMMs — 60 or 70 ns The height of SIMMs used with VXIpc 800 Series controllers should be

0.85 in. or less. Contact National Instruments for recommendations on specific manufacturers.

Note: The VXIpc-800 must be populated with pairs of SIMMs because the DRAM

interface is 64 bits wide.

VXIpc 800 Series

Appendix

System Resources

This appendix describes what system resources are available on the VXIpc 800 Series and where they are allocated. Because PCI is a relatively new addition to PCs, this appendix describes how PCI interrupts fit into a PC architecture before listing the devices that use them.

PCI Interrupts

PCI interrupts can be shared by multiple devices and are therefore more flexible than ISA interrupts. They do not actually connect to the processor directly; they are instead mapped through ISA interrupts in the system I/O module. The interrupt handler for a particular ISA interrupt must know if it will be acknowledging a PCI device.

Resource Tables

This section provides tables describing where system resources are assigned. Table B-1 lists how the ISA interrupts are allocated on the VXIpc 800 Series and whether they are driven by a PCI interrupt. Table B-2 lists DMA channel allocation, and Table B-3 gives the I/O address map.

Table B-1.

ISA Interrupt PCI Interrupt Device

NMI None Pari ty

0 None Timer 1 None Keyboard 2 None IRQ Expansion (8-15) 3 None COM2 4 None COM1

VXIpc 800 Series ISA Interrupt Resource Allocations

Appendix B VXIpc 800 Series System Resources

Table B-1. VXIpc 800 Series ISA Interrupt Resource Allocations (Continued)

ISA Interrupt PCI Interrupt Device

5 INTC,

INTB

GPIB/PCMCIA

Slot/Expansion 6 None Floppy Drive 7 None LPT1 8 None RTC 9 None Ethernet

10 INTA VXI, SCSI, PCMCIA 11 None GPIB/PCMCIA

Slot/Expansion

12 None Mouse 13 None FPERR 14 INTD IDE 15 None PCMCIA Slot/Expansion

Table B-2. VXIpc 800 Series DMA Channel Resource Allocations

DMA Channel Device

0 Free 1 Free 2 Floppy Drive 3 Free 4 Free 5 GPIB 6 Free 7 Free

VXIpc 800 Series User Manual B-2 © National Instruments Corporation

Appendix B VXIpc 800 Series System Resources

Table B-3. VXIpc 800 Series I/O Address Map

I/O Address Device

000-00F 8237 DMA #1 020-021 8259 PIC #1 040-043 8253 Timer 060-066 8742 Controller 070-077 CMOS RAM & NMI Mask Reg 078-07B BIOS Timer 080-090 DMA Page Registers

092 Reserved

094-09F DMA Page Registers

0A0-0A1 8259 PIC #2

0B2-0B3 Advanced Power Management

0C0-0DF 8237 DMA #2 (word mapped)

0F0-0FF Numeric Processor Error Reg 170-177 Reserved 1F0-1F7 IDE 200-270 Free 278-27F LPT*

280-2DF Free

2C0-2DF GPIB

2E8-2EF COM*

2F8-2FF COM* 300-30F Ethernet 310-36F Free 370-377 Reserved 378-37F LPT* 380-3B0 Free

3BC-3BF LPT*

Appendix

LED Indicators

This appendix describes how to read the LEDs on the front panel to interpret the status of the VXIpc 800 Series.

VXIbus Interface Status LEDs

The VXIbus interface status LEDs are located at the top of the module and include four LEDs: They indicate the various stages of initialization that occur as the VXIpc 800 boots. The following paragraphs describe each LED.

SYSFAIL LED

FAILED LED

The

SYSFAIL

asserted. It does not necessarily indicate that the VXIpc 800 is asserting SYSFAIL, only that there is a device in the system asserting SYSFAIL.

The

FAILED

signal. The VXIpc 800 asserts SYSFAIL when the PASSED bit in its VXIbus status register is clear. The PASSED bit is set by the power-on self configuration circuitry (POSC) when it has completed initializing the VXIbus interface.

LED is lit when the VMEbus SYSFAIL signal is

LED is lit when the VXIpc 800 is driving the SYSFAIL

FAILED, SYSFAIL, ONLINE

, and

TEST

ONLINE LED

The

ONLINE

completed and the VXIbus interface is ready for application programs.

LED is lit when the Resource Manager has successfully

TEST LED

The configuring the VXIbus interface.

LED is lit when the power-on self configuration circuitry is

TEST

Appendix C LED Indicators

LEDs and System Startup Cycle

Table C-1 shows a system startup cycle and possible points of failure, up to and including the state in which the program asserts the ONLINE LED.

VXIinit initialization

Table C-1.

LEDs and System Startup Status

Possible Problem if

Step LEDs Lit Status

VXIpc 800 Fails

1 None Machine just turned on. The VXIpc 800 is not receiving

power.

2 FAILED,

SYSFAIL

Now asserting SYSFAIL because VXIbus interface has not been initialized yet.

Power-on self configuration (POSC) cannot execute because of problems with system reset or because the POSCEN switch is incorrectly configured.

3 FAILED,

TEST

VXI interface is being initialized by MITE power-on self configuration

POSC has stalled.

(POSC) circuitry.

4 TEST POSC circuitry has initialized VXI

interface, setting PASSED and

POSC stalled before clearing the TEST LED.

DONE bits.

5 None POSC cycles are complete. VXI port

is ready to respond to Resource Manager inquiries.

POSC completed successfully; however, the Resource Manager either hung or was not executed.

6 ONLINE Resource Manager has been

executed, indicating that the VXI

Resource Manager interface

initialized successfully. software can now communicate with the VXI circuitry.

VXIpc 800 Series User Manual C-2 © National Instruments Corporation

If either the SYSFAIL or FAILED LED remains lit, perform the following steps.

1. Power off the mainframe.

2. Remove all other modules from the mainframe.

3. Make sure that the VXIpc 800 jumper settings are correct.

4. Make sure that the VXIpc 800 is seated properly in the mainframe.

5. Power on the mainframe and observe whether the SYSFAIL and FAILED LEDs become unlit some time before the operating system boots.

Board Access LEDs

The board access LEDs—ACCESS and DRIVE—indicate when board resources have been accessed. The following paragraphs describe these LEDs.

ACCESS LED

When lit, the ACCESS LED indicates that the VXIpc 800 MODID line is asserted or that another VXIbus master is accessing VXIbus shared registers or shared memory.

Appendix C LED Indicators

DRIVE LED

The DRIVE LED light indicates that an access to the internal hard disk drive is occurring.

Ethernet LEDs

The Ethernet LEDs (RX, TX, LINK, and DSEL) indicate the status of the Ethernet interface on the VXIpc 800 Series.

RX LED

The RX LED lights when the Ethernet interface is receiving a packet.

TX LED

The TX LED lights when the Ethernet interface is transmitting a packet.

Appendix C LED Indicators

LINK LED

DSEL LED

The LINK LED indicates LINK status and can generally be used to check if Ethernet activity is occurring.

The DSEL (Device Select) LED lights when Ethernet registers are being accessed.

VXIpc 800 Series User Manual C-4 © National Instruments Corporation

Appendix

Front Panel and Connectors

This appendix describes the front panel and connectors on the VXIpc 800 Series. This material contains the information relevant to

plug&play

Note:

VXI

Receiver Interconnection

The illustrations in this appendix show the mating face of the connectors. An asterisk suffix (*) on a signal name indicates that the signal is active low.

The VXIpc 800 Series has the following front panel connectors:

• Two RS-232 Serial

• Extended Capabilities Parallel (ECP)

• VGA Controller

• IEEE 488.2

• 10BaseT Ethernet

• SCSI-2

• External Clock

• Trigger Output

• Trigger Input

• Audio Output

• PS/2-Style Keyboard

• PS/2-Style Mouse

Specification VPP-8,

VXI Module/Mainframe to

Appendix D Front Panel and Connectors

Front Panel

Figure D-1 shows the front panel layout of the VXIpc-800. The drawing shows dimensions relevant to key elements on the front panel. Dimensions are shown in inches and millimeters, with millimeter dimensions in square brackets. The front panel thickness for all models in the VXIpc 800 Series is 2.49 mm (0.098 in.).

FAILED ONLINE

DSEL

SYSF TEST ACC

DRIVE

LNK

TRG

P I

TRG OUT

CLK

RESET

VXIpc-850

Figure D-1.

VXIpc-800 Front Panel Layout and Dimensions

VXIpc 800 Series User Manual D-2 © National Instruments Corporation

Keyboard and Mouse

Figure D-2 shows the location and pinouts for the keyboard and mouse connectors on the VXIpc 800 Series. Table D-1 gives the name and description for the keyboard and mouse connector signals.

Amp manufactures a mating connector with part numbers 212437-4 (housing), 212435-7 (ferrule), and 66735-4 (pin contact).

Appendix D Front Panel and Connectors

2 1

3 4

Keyboard

Mouse

Figure D-2.

Keyboard and Mouse Connectors Location and Pinout

Table D-1.

Keyboard and Mouse Connector Signals

Pin Signal Name Signal Description

1 DATA Data 2 NC Not Connected 3 GND Ground 4 +5V +5 volts 5 CLK Clock 6 NC Not Connected

Appendix D Front Panel and Connectors

VGA

Figure D-3 shows the location and pinouts for the VGA connector on the VXIpc 800 Series. Table D-2 gives the name and description for the VGA connector signals.

Amp manufactures a mating connector with part numbers 748364-1 (housing) and 748333-2 (pin contact).

1561015

VGA

Figure D-3.

VGA Connector Location and Pinout

Table D-2.

VGA Connector Signals

Pin Signal Name Signal Description

1 R Red 2 G Green 3 B Blue 4 NC Not Connected 5 GND Ground 6 GND Ground 7 GND Ground 8 GND Ground

VXIpc 800 Series User Manual D-4 © National Instruments Corporation

Appendix D Front Panel and Connectors

Ethernet

Table D-2.

VGA Connector Signals (Continued)

Pin Signal Name Signal Description

9 +5 VDC +5 VDC 10 GND Ground 11 NC Not Connected 12 SD Serial Data 13 HSync Horizontal Sync 14 VSync Vertical Sync 15 SC Serial Clock

Figure D-4 shows the location and pinouts for the Ethernet connector on the VXIpc-800. Table D-3 gives the name and description for the Ethernet connector signals.

Amp manufactures a mating connector, part number 554739-1.

Ethernet

Figure D-4.

Ethernet Connector Location and Pinout

Appendix D Front Panel and Connectors

COM1 and COM2

Figure D-5 shows the location and pinouts for the COM1 and COM2 connectors on the VXIpc 800. Table D-4 gives the name and description for the COM1 and COM2 connector signals.

ITT Cannon manufactures a serial port mating connector, part number MDSM-9SC-Z11, for the COM1 and COM2 connectors on the VXIpc-800.

Table D-3.

Pin Signal Description

1 Differential Transmit 2 Differential Transmit 3 Differential Receive 4 NC 5 NC 6 Differential Receive 7 NC 8 NC

Ethernet Connector Signals

VXIpc 800 Series User Manual D-6 © National Instruments Corporation

Appendix D Front Panel and Connectors

1596

COM1

1596

COM2

Figure D-5. COM1 and COM2 Connectors Location and Pinout

Table D-4. COM1 and COM2 Connector Signals

Pin Signal Name Signal Description

1 DCD* Data Carrier Detect

2 RXD* Receive Data

3 TXD* Transmit Data

4 DTR* Data Terminal Ready

5 GND Ground

6 DSR* Data Set Ready

7 RTS* Ready to Send

8 CTS* Clear to Send

9 RI* Ring Indicator

Appendix D Front Panel and Connectors

Parallel Port

Figure D-6 shows the location and pinouts for the IEEE-1284 connector on the VXIpc-800. Table D-5 gives the name and description for the IEEE-1284 connector signals.

Amp manufactures a parallel port compatible connector, part number 2-175677-5.

SYSF

FAILED

TEST

ONLINE

ACC

DRIVE

Parallel Port

Figure D-6.

Parallel Port Connector Location and Pinout

VXIpc 800 Series User Manual D-8 © National Instruments Corporation

Appendix D Front Panel and Connectors

Table D-5. Parallel Port Connector Signals

Pin Signal Name Signal Description

1 BUSY* Device Busy

2 SLCTIN* Select Input

3 ACK* Acknowledge

4 FAULT* Fault

5 ERROR Error

6 PD0 Data Bit 0

7 PD1 Data Bit 1

8 PD 2 Data Bit 2

9 PD3 Data Bit 3 10 PD4 Data Bit 4 11 PD5 Data Bit 5 12 PD6 Data Bit 6 13 PD7 Data Bit 7 14 INIT* Initialize Printer 15 STROBE* Strobe 16 SLCT Select 17 AUTOFD Auto Line Feed 18 +5V +5 Volts

19-35 GND Ground

36 NC Not Connected

Appendix D Front Panel and Connectors

SCSI

Figure D-7 shows the location and pinouts for the SCSI connector on the VXIpc-800. Table D-6 gives the name and description for the SCSI connector signals.

Amp manufactures a SCSI compatible connector, part number 749111-4.

Figure D-7.

SCSI

SCSI Connector Location and Pinout (SCSI II)

VXIpc 800 Series User Manual D-10 © National Instruments Corporation

Appendix D Front Panel and Connectors

Table D-6. SCSI Connector Signals

Pin Signal Name Signal Description

1–11, 15–25,

GND Ground

35–36, 40, 42 12–14, 37–39 NC Not Connected

26 D0 Data 0 27 D1 Data 1 28 D2 Data 2 29 D3 Data 3 30 D4 Data 4 31 D5 Data 5 32 D6 Data 6 33 D7 Data 7 34 DP Parity 38 TERMPWR Termination Power 41 ATN* Attention 43 BUSY* Busy 44 ACK* Acknowledge 45 RESET* Reset 46 MSG* Message 47 SEL* Select 48 CMD_DATA Command/Data 49 REQ* Request 50 IN_OUT In/Out

Appendix D Front Panel and Connectors

GPIB (IEEE-488.2)

Figure D-8 shows the location and pinouts for the GPIB connector on the VXIpc-800. Table D-7 gives the name and description for the GPIB connector signals.

ITT Cannon manufactures a GPIB mating connector, part number MDSM-255C-Z11.

Figure D-8.

GPIB

GPIB Connector Location and Pinout

VXIpc 800 Series User Manual D-12 © National Instruments Corporation

Appendix D Front Panel and Connectors

Table D-7. GPIB Connector Signals

Pin Signal Name Signal Description

1 DIO1* Data Bit 1

2 DIO2* Data Bit 2

3 DIO3* Data Bit 3

4 DIO4* Data Bit 4

5 EOI* End or Identify

6 DAV* Data Valid

7 NRFD* Not Ready for Data

8 NDAC* Not Data Accepted

9 IFC* Interface Clear 10 SRQ* Service Request 11 ATN* Attention 12 SHIELD Chassis ground 13 DIO5* Data Bit 5 14 DIO6* Data Bit 6 15 DIO7* Data Bit 7 16 DIO8* Data Bit 8 17 REN* Remote Enable

18-25 GND Logic Ground

Appendix D Front Panel and Connectors

External SMBs

Figure D-9 shows the location and pinouts for the SMB connectors on the VXIpc 800. The SMB connectors are used for an external clock signal and TTL trigger input and output. Table D-8 gives the name and description for the SMB connector signals. Also see Table D-9 for a description of the signal characteristics for the SMB connections.

Amp manufactures an SMB mating connector, part number 1-4 13985-0.

Center

SMB

Shield

Figure D-9.

SMB Connectors Location and Pinout

Table D-8.

SMB Connector Signals

Pin Signal Description

Center TTL Trigger or Clock Signal Shield Ground

VXIpc 800 Series User Manual D-14 © National Instruments Corporation

Speaker

Appendix D Front Panel and Connectors

Figure D-10 shows the location of the speaker connection on the VXIpc-800.

Switchcraft manufactures a mating speaker connector, part number 750.

Figure D-10.

Speaker

Speaker Connection Location

Appendix D Front Panel and Connectors

Signal Characteristics

Refer to the relevant standard for the signal characteristics for VGA, SCSI, Ethernet, keyboard, mouse, parallel, serial, and GPIB.

Table D-9 shows the signal characteristics for the SMB and speaker connections.

Table D-9.

SMB (TRIG out, CLK out) 0 to 3.4 V 200 mA DC-10 MHz Speaker 0 to 4.3 V 75 mA DC-20 kHz SMB (TRIG in) 0 to 5 V 100 mA* DC-10 MHz

* with 50 Ω termination

Signal Characteristics for SMB and Speaker Connections

Signal

Voltage

Range

Maximum

Current

Frequency

Range

VXIbus P1 and P2

Figure D-11 shows the location and pinouts for the VXIbus connector on the VXIpc 800 Series. Table D-10 gives the name and description for the VXIbus P2 connector signals. Table D -11 gives the name and description for the VXIbus P1 connector signals.

Appendix D Front Panel and Connectors

C32 B32 A32

P1 ConnectorP2 Connector

Figure D-11.

Table D-10.

VXIbus Connectors Location and Pinout

VXIbus P2 Connector Signals

C1 B1 A1

Pin Row C Row B Row A

1 CLK10+ +5 V ECLTRG0 2 CLK10- GND –2 V 3 GND Not Connected ECLTRG1 4 –5.2 V A24 GND 5 Not Connected A25 MODID12 6 Not Connected A26 MODID11 7 GND A27 –5.2 V 8 Not Connected A28 MODID10 9 Not Connected A29 MODID09

10 GND A30 GND 11 Not Connected A31 MODID08 12 Not Connected GND MODID07

Appendix D Front Panel and Connectors

Pin Row C Row B Row A

13 –2 V +5 V –5.2 V 14 Not Connected D16 MODID06 15 Not Connected D17 MODID05 16 GND D18 GND 17 Not Connected D19 MODID04 18 Not Connected D20 MODID03 19 –5.2 V D21 -5.2 V 20 Not Connected D22 MODID02 21 Not Connected D23 MODID01 22 GND GND GND 23 TTLTRG1* D24 TTLTRG0* 24 TTLTRG3* D25 TTLTRG2* 25 GND D26 +5 V

Table D-10. VXIbus P2 Connector Signals (Continued)

26 TTLTRG5* D27 TTLTRG4* 27 TTLTRG7* D28 TTLTRG6* 28 GND D29 GND 29 Not Connected D30 Not Connected 30 GND D31 MODID00 31 Not Connected GND GND 32 Not Connected +5 V Not Connected

Appendix D Front Panel and Connectors

Table D-11. VXIbus P1 Connector Signals

Pin Row C Row B Row A

1 D08 BBSY* D00 2 D09 BCLR* D01 3 D10 ACFAIL* D02 4 D11 BG0IN* D03 5 D12 BG0OUT* D04 6 D13 BG1IN* D05 7 D14 BG1OUT* D06 8 D15 BG2IN* D07 9 GND BG2OUT* GND

10 SYSFAIL* BG3IN* SYSCLK 11 BERR* BG3OUT* GND 12 SYSRESET* BR0* DS1* 13 LWORD* BR1* DS0* 14 AM5 BR2* WRITE* 15 A23 BR3* GND 16 A22 AM0 DTACK* 17 A21 AM1 GND 18 A20 AM2 AS* 19 A19 AM3 GND 20 A18 GND IACK* 21 A17 Not Connected IACKIN* 22 A16 Not Connected IACKOUT* 23 A15 GND AM4 24 A14 IRQ7* A07 25 A13 IRQ6* A06 26 A12 IRQ5 A05 27 A11 IRQ4 A04

Appendix D Front Panel and Connectors

Pin Row C Row B Row A

28 A10 IRQ3 A03 29 A09 IRQ2 A02 30 A08 IRQ1 A01 31 +12 V Not Connected –12 V 32 +5 V +5 V +5 V

Table D-11. VXIbus P1 Connector Signals (Continued)

Modifying and Installing

Appendix

I/O Expansion Boards

This appendix explains how to modify and install an I/O board in the VXIpc 800 Series. Notice that some material is different between the VXIpc-850 and the VXIpc-860.

Height of VXIpc-850 Plug-In Boards

In general, the VXIpc-850 can accommodate any standard-size PCI card and any XT-height ISA card. The height of an I/O card is measured from the bottom of the bus connector to the top of the board, as shown in Figure E-1.

Height

(4.2 in. max)

(13.415 in. maximum when using .85 in. high SIMMs on processor board)

Both XT-height ISA cards and PCI cards are 4.2 in. high. The VXIpc-850 does not support AT-height ISA cards, which are 4.8 in. high.

Length

Figure E-1.

I/O Board Dimensions for VXIpc-850 Expansion Slot

Appendix E Modifying and Installing I/O Expansion Boards

Length of VXIpc-850 Plug-In Boards

The VXIpc-850 will accommodate PCI or ISA I/O boards that are up to

4.2 in. high and up to 13.415 in. long when DRAM SIMMs 0.85 in. or shorter are used on the processor board (National Instruments provides

0.85 in. SIMMs). Due to slight variances in I/O board geometries, however, take care in every application to identify possible contact with the SIMMs. The maximum recommended board length is 7.72 in. if you are using SIMMs taller than 0.85 in. If you want to install a longer board with taller system DRAM SIMMs, you must consider the strong possibility of contact with the SIMMs.

Because DRAM SIMMs taller than 0.85 in. are more likely to interfere with ISA cards than PCI cards, the two are discussed separately in the following sections.

Length of PCI Plug-In Boards

The VXIpc-850 accommodates any standard 32-bit, 5 V PCI I/O board . The maximum standard dimensions of a PCI I/O board are 12.283 in. by

4.2 in. PCI cards are installed in the VXIpc-850 such that the board components face the processor card, which contains the processor and system RAM. Exceptionally tall PCI components (higher than 0.52 in.) on a plug-in board may physically cont act the DRAM SIMMs inst alled on the CPU card, as shown in Figure E-2.

PCI CardRiser Card

Heat SinkFront Panel

Figure E-2.

Possible Support

Bracket Positions

Component Height Restrictions for PCI Plug-In Boards

Used with the VXIpc-850

.62 in. max to Heat Sink.52 in. max to SIMMs

.85 in. High

SIMMs

VXI Connector

Because larger DRAM sizes may employ taller SIMMs, you must be careful that the component height of the PCI board does not interfere with the SIMMs in such a way that electrical shorts occur or that the PCI board is stressed enough to compromise its physical or electrical integrity.

Length of ISA Plug-In Boards

Because ISA boards mount with the components facing away from the CPU card, which contains the processor and system RAM, tall DRAM SIMMs may interfere with the circuit card of the plug-in board. Most SIMM modules are at least 1 in. high and would extend into the ISA circuit card keepout area. Therefore, National Instruments provides SIMMs of 0.85 in. high, and does not recommend the use of cards that are longer than 7.72 in. if you choose to use taller SIMMs. They can be made to fit; however, take care to ensure the following conditions:

• Contact of the board with the SIMMs should not cause electrical shorts (because of through-hole component leads on the side of the plug in board that contacts the SIMMs).

• Contact of the board with the SIMMs does not cause physical stress to the plug-in board.

• Contact of the board with the SIMMs does not cause physical stress to the riser board into which the plug-in board is inserted.

Figure E-3 shows the length restrictions for ISA cards for the VXIpc-850 when tall SIMMs are used.

Appendix E Modifying and Installing I/O Expansion Boards

Riser Card

7.72 in. max

Front Panel

Heat Sink

Figure E-3.

ISA Board

1.0 in. High SIMMs

Possible Support

Bracket Positions

Length Restrictions for ISA Plug-In Boards Used with the VXIpc-850

when SIMMs Taller than 0.85 in. are Used

VXI Connector

Appendix E Modifying and Installing I/O Expansion Boards

Height of VXIpc-860 Plug-In Boards

In general, the VXIpc-860 can accommodate any standard-size PCI card and any XT-height ISA card. The height of an I/O card is measured from the bottom of the bus connector to the top of the board, as shown in Figure E-4.

.48 in. Component Height (PCI Component Side) .07 in. Component Height (ISA Solder Side) With .85 in. Tall SIMMs

2.51 in.

1.50 in. 4.36 in.

Height

(4.2 in. max)

Length

Figure E-4.

(8.4 in. maximum for both ISA and PCI)

I/O Board Dimensions for VXIpc-860 Expansion Slot

Both XT-height ISA cards and PCI cards are 4.2 in. high. The VXIpc-860 does not support AT-height ISA cards, which are

4.8 in. high.

Appendix E Modifying and Installing I/O Expansion Boards

Length of VXIpc-860 Plug-In Boards

The VXIpc-860 can accommodate PCI or ISA I/O boards that are up to

4.2 in. high and up to 8.4 in. long. When DRAM SIMMs 0.85 in. are used on the processor board, the component-side component height on a PCI I/O board shall be 0.48 in. tall in the area shown in Figure E-4. For the same height DRAM SIMMs, the ISA I/O board solder-side component height shall be 0.07 in. tall in the area shown in Figure E-4. Be sure to allow for clearance if you want to use taller DRAM SIMMs.

Because DRAM SIMMs taller than 0.85 in. are more likely to interfere with ISA cards than PCI cards, the two are discussed separately in the following sections.

Length of PCI Plug-In Boards

The VXIpc-860 accommodates any 32-bit, 5 V PCI I/O boards that are a maximum of 8.4 in. long with the standard height of 4.2 in. (see Figure E-5). PCI cards are installed in the VXIpc-860 such that the board components face the processor board, which contains the processor and system RAM. PCI components (higher than 0.48 in. in the area shown in Figure E-4) on a plug-in board may physically contact the DRAM SIMMs installed on the CPU card, as shown in Figure E-5.

PCI Card Heat Sink

Possible Support

Bracket Positions

Length Restrictions for PCI Plug-In Boards Used with the VXIpc-860

VXI Connector

.48 in.

Front Panel

Riser Card

8.4 in. max

.85 in. High

SIMMs

Figure E-5.

Appendix E Modifying and Installing I/O Expansion Boards

Length of ISA Plug-In Boards

Because ISA boards mount with the components facing away from the CPU card, which contains the processor and system RAM, tall DRAM SIMMs may interfere with the circuit card of the plug-in board. Most SIMM modules are at least 1 in. high and would extend into the ISA circuit card. Therefore, National Instruments provides SIMMs of 0.85 in. high to give a clearance of 0.07 in. to the ISA circuit card only in the area shown in Figure E-4. If you choose to use taller SIMMs (0.92 maximum height), take care to ensure the following conditions:

• Contact of the board with the SIMMs should not cause electrical shorts (because of through-hole component leads on the side of the plug in board that contacts the SIMMs).

• Contact of the board with the SIMMs does not cause physical stress to the plug-in board.

• Contact of the board with the SIMMs does not cause physical stress to the riser board into which the plug-in board is inserted.

Figure E-6 shows the length restrictions for ISA cards for the VXIpc-860 when tall SIMMs are used.

Riser Card

8.4 in. max

Front Panel

.85 in. High

SIMMs

Figure E-6.

ISA Board

Possible Support

Bracket Positions

Length Restrictions for ISA Plug-In Boards Used with the VXIpc-860

when SIMMs Taller than 0.85 in. are Used

Heat Sink

VXI Connector

Installing an I/O Board

The following material applies equally to all models in the VXIpc 800 Series.

Materials Needed

You need the following pieces to install an expansion board in the VXIpc-800:

• A user-defined panel is required on the expansion boards based on National Instruments blank PCI or ISA panels. The panel should be manufactured from 0.03 in. (0.76 mm) thick 1010 cold rolled steel. The finish should be 0.0003 in. (0.008 mm) nickel plate over 0.0001 in. (0.003 mm) copper flash. Contact National Instruments if you have any questions about specifications for user-defined panels.

As an alternative, you can modify the blank panels provided with the VXIpc-800. Custom panel design services are available from National Instruments for a nominal fee.

• PEM nut or a 4-40 nut with lock washer (hole diameter should be 0.125 in. [3.18 mm]).

• 4-40 x 1/4 in. stainless steel panhead screw.

Appendix E Modifying and Installing I/O Expansion Boards

Installation Steps

Follow these steps to install the expansion board.

1. Notice that the VXIpc-800 includes one card guide that can be rotated to secure the top of either a PCI or an ISA plug-in board. You may use the card guide in either of two locations, depending on the length of your installed board. Notice the possible locations as shown previously (Figures E-2 and E-3 for the VXIpc-850, or Figures E-5 and E-6 for the VXIpc-860). Loosen the screw holding the guide and rotate the guide to the uppermost position for PCI boards or the lowermost position for ISA boards. See Figure E-7.

2. Replace the manufacturer-supplied panel bracket with the custom bracket. The two holes in the bracket align with existing holes in the VXIpc-800 front panel.

3. Seat the board firmly in one of the expansion bus connectors.

4. Attach the board to the front panel with the two screws. You can use a PEM nut on the back (far) side of the bracket, or a 4-40 nut

Appendix E Modifying and Installing I/O Expansion Boards

with a lock washer (hole diameter should be 0.125 in.). In either case, use a 4-40 x 1/4 in. stainless steel panhead screw to mount the board/bracket assembly to the front panel.

a. PCI Board Installed b. ISA Board Installed

Figure E-7. PCI Board and ISA Board Installed in a VXIpc-800

Figures E-8 and E-9 give dimensions and instructions for creating a connector cutout and expansion bracket for a PCI board.

Note: In the following drawings, dimensions are given in inches and millimeters,

with the millimeter dimensions in square brackets.

PCI Expansion

Bracket

4.200

[106.68]

12.283 [311.99]

3.224 [81.89]

(I/O Connector

Window)

.300 [7.62]

(.240 [6.10])

Figure E-8. Side View of PCI Board with Expansion Bracket

Appendix E Modifying and Installing I/O Expansion Boards

(I/O Connector Window)

.475 [12.07]

(.200 [5.08])

I/O Connector

Window, (.475 [12.07] X

3.224 [81.89])

3.464

[87.99]

4.080

[103.63]

.09 [2.3]

.240 [6.10]

.19 [4.8]

.180 [4.57] .560 [14.22]

.760 [19.30]

Install PEM self-clinching nut, P/N CLS-440-0, per manufacturer's specifications, far side, or drill through ø.125 [3.18] for 4-40 screw and nut.

4.46

[113.28]

Figure E-9. Front View of PCI Board Expansion Bracket

Appendix E Modifying and Installing I/O Expansion Boards

Figures E-10 and E-11 give dimensions and instructions for creating a connector cutout and expansion bracket for an ISA board.

ISA Expansion

Bracket

4.200 [106.68] (XT Card)

Length of XT ISA card shall be 7.72 [196.1] if SIMMs on processor card are taller than .85 [21.6]. Otherwise ISA specification length of 13.415 [340.74] may be used.

Figure E-10. Side View of ISA Board with Expansion Bracket

3.500 [88.90]

(I/O Connector

Window)

.300 [7.62]

(.050 [1.27])

Appendix E Modifying and Installing I/O Expansion Boards

(I/O Connector Window)

.490 [12.45]

I/O Connector

(.200 [5.08])

Window, (490 [12.45] X

3.500 [88.90])

3.550

[90.17]

4.080

[103.63]

.09 [2.3]

.050 [1.27]

.19 [4.8]

.180 [4.57]

.560 [14.22]

.760 [19.30]

Install PEM self-clinching nut, P/N CLS-440-0, per manufacturer's specifications, far side, or drill through ø.125 [3.18] for 4-40 screw and nut.

4.46

[113.28]

Figure E-11. Front View of ISA Board Expansion Bracket

Appendix

Common Questions

This appendix answers common questions you may have when using the VXIpc 800 Series.

What do the LEDs on the front of the VXIpc 800 mean?

Refer to Appendix C , panel LEDs.

Is something wrong with the VXIpc 800 if the red SYSFAIL and FAILED LEDs stay lit after booting the VXIpc 800?

If either the Appendix C,

Can I access 32-bit registers in my VXIbus system from the VXIpc 800?

Yes. The VXIpc 800 uses the 32-bit PCI bus to interface to the VXIbus. In fact, the VXIbus circuitry on the VXIpc 800 also supports the new VME64 standard for D64 accesses. Refer to your VXI software manual for more information.

SYSFAIL

LED Indicators

FAILED

, for troubleshooting steps.

, for a description of the front

LED remains lit, refer to

What kind of signal is CLK10 and what kind of signal do I need for an external CLK10?

CLK10 is a differential ECL signal on the backplane. However, the oscillator for the VXIpc 800 and the EXTCLK i npu t on the VXIpc-8 00 front panel use TTL levels; therefore, you need to supply a TTL-level signal for EXTCLK. Our voltage converters convert the signal to differential ECL.

What is the accuracy of the CLK10 signal?

The CLK10 signal generated by the VXIpc 800 is ±100 ppm (0.01%) as per the VXIbus specification. If you need a more accurate CLK10 signal on the VXIpc 800 Series, you can use the EXTCLK connector on its front panel.

Appendix F Common Questions

If I boot the computer without video, and then plug in the video, why is it in black and white?

When the computer first boots, the video chips try to synchronize with the monitor. If the monitor is not there, the video chips cannot synchronize and establish color. You need to have the monitor at tached at boot time to get color.

I’ve installed the SCSI software. Why doesn’t the VXIpc 800 Series recognize my SCSI device?

This problem usually occurs when SCSI has not been enabled in the BIOS. Enter your BIOS by pressing <DEL> at boot time. In the Setup window, click on the Chipset icon. Select the On Board PCI SCSI option and enable it.

What type of video interface is onboard the VXIpc 800? What video drivers are included with the VXIpc 800? Can I use Super VGA with my VXIpc 800? If my application requires a special type of video display, how do I configure my VXIpc 800?

The VXIpc 800 uses the Trident Microsystems TGUI96xx chip family, a combination graphics accelerator and RAMDAC. The TGUI9660 is the first chip used from this family. Subsequent pin-compatible chips will follow. The chips in this family are compatible with the Standard VGA video output MS Windows video driver, as well as the Trident Microsystems video driver. For more information on the video driver, refer to the

c:\images\manuals directory.

If your application requires a special type of video display, you can remove the PCI video card included with your VXIpc 800 Series. Contact National Instruments for information on how to do this.

What kind of monitor can I use with the VXIpc 800?

VXIpc 800 computers that use Super VGA video output will work o nly with monitors having a horizontal scan rate of at least 50 kHz and a vertical scan rate of 60 Hz.

Caution: Make sure that your monitor meets this specification. Enabling the Super

VGA option on a monitor that does not meet this specification will cause damage to your monitor.

Appendix F Common Questions

What if my keyboard connector does not fit into the keyboard port on the VXIpc 800?

You can plug keyboards that have a 6-pin Mini DIN PS/2 type connector directly into the VXIpc 800. You can use the keyboard adapter cable that is included with every VXIpc 800 kit to adapt the larger AT keyboard connector to the 6-pin Mini DIN connector.

How do I connect an external speaker to get audio capability?

A twisted-pair cable connects th e front pane l audio co nnector to the VXIpc 800 Series motherboard. Connect the external speaker to this front-panel connector. The center pin of the connector provides the audio signal. The shield of the connector is GROUND.

How do I add RAM to the VXIpc 800? What is the maximum amount of RAM that I can have on the VXIpc 800?

For information about adding RAM to the VXIpc 800, refer to Appendix A,

Specifications

Which interrupt levels are free to be used by ISA bus boards? Which area of upper memory (adapter space) is free for use by ISA bus boards or expanded memory manager software programs?

See Appendix B,

VXIpc 800 Series System Resources,

for information on the available port I/O register space, upper memory area, interrupts, and DMA channels.

How do I install the VXIpc 800 in a slot other than Slot 0?

The VXIpc 800 automatically detects whether it is in Slot 0 of a VXIbus mainframe. You do not need to change jumper settings to install the VXIpc 800 in a slot other than Slot 0 unless you h av e defeated the first slot detector (FSD) circuitry by changing the appropriate jumper setting on the VXIpc 800.

Refer to either Chapter 3,

Installation

, for information on enabling and defeating the FSD

VXIpc 800 Series Configuration and

circuitry.

Appendix F Common Questions

How do I check the configuration of the memory, floppy drive, hard drive, time/date, and so on?

You can view these parameters in the BIOS setup. To enter the BIOS setup, reboot the VXIpc 800 and press the <DEL> key during the memory tests. Refer to Chapter 4,

BIOS

, for more information.

Can I upgrade my VXIpc 800?

You can upgrade the modular CPU card to upgrade the processor. Contact National Instruments for information.

How can I boot from an external SCSI hard drive? In the Setup/Standard window change the Master drive setting from

User to SCSI, and make sure that SCSI is enabled in the Setup/Chipset

window.

Can I use the internal IDE drive and an external SCSI hard drive at the same time?

Yes, but you can only boot from the internal IDE drive in this configuration.

My CMOS is corrupted. How do I set it back to default?

1. Select Default/Optimal.

2. Save and exit.

Appendix

Customer Communication

For your convenience, this appendix contains forms to help you gather the information necessary to help us solve your technical problems and a form you can use to comment on the product documentation. When you contact us, we need the information on the Technical Support Form and the configuration form, if your manual contains one, about your system configuration to answer your questions as quickly as possible.

National Instruments has technical assistance through electronic, fax, and telephone systems to quickly provide the information you need. Our electronic services includ e a bulletin board service, an FTP site, a fax-on-demand system, and e-mail support. If you have a hardware or software problem, first try the electronic support systems. If the information available on these systems does not answer your questions, we offer fax and telephone su pport through our technical support centers, which are staffed by applications engineers.

Electronic Services

Bulletin Board Support

National Instruments has BBS and FTP sites dedicated for 24-hour support with a collection of files and documents to answer most common customer questions. From these sites, you can also download the latest instrument drivers, updates, and example programs. For recorded instructions on how to use the bulletin board and FTP services and for BBS automated information, call (512) 795-6990. You can access these services at:

United States: (512) 794-5422

Up to 14,400 baud, 8 data bits, 1 stop bit, no parity

United Kingdom: 01635 551422

Up to 9,600 baud, 8 data bits, 1 stop bit, no parity

France: 01 48 65 15 59

Up to 9,600 baud, 8 data bits, 1 stop bit, no parity

FTP Support

To access our FTP site, log on to our Internet host, ftp.natinst.com, as anonymous and use your Internet address, such as joesmith@anywhere.com, as your password. The support files and documents are located in the

/support

directories.

Fax-on-Demand is a 24-hour information retrieval system containing a library of documents on a wide

Fax-on-Demand Support

E-Mail Support (currently U.S. only)

range of technical information. You can access Fax-on-Demand from a touch-tone telephone at (512)418-1111.

You can submit technical support questions to the applications engineering team through e-mail at the Internet address listed below. Remember to include your name, address, and phone number so we can contact you with solutions and suggestions.

support@natinst.com

Telephone and Fax Support

National Instruments has branch offices all over the world. Use the list below to find the technical support number for your country. If there is no National Instruments office in your country, contact the source from which you purchased your software to obtain support.

Telephone Fax

Australia 03 9879 5166 03 9879 6277 Austria 0662 45 79 90 0 0662 45 79 90 19 Belgium 02 757 00 20 02 757 03 11 Brazil 011 288 3336 011 288 8528 Canada (Ontario) 905 785 0085 905 785 0086 Canada (Quebec) 514 694 8521 514 694 4399 Denmark 45 76 26 00 45 76 26 02 Finland 09 725 725 11 09 725 725 55 France 01 48 14 24 24 01 48 14 24 14 Germany 089 741 31 30 089 714 60 35 Hong Kong 2645 3186 2686 8505 Israel 03 6120092 03 6120095 Italy 02 413091 02 41309215 Japan 03 5472 2970 03 5472 2977 Korea 02 596 7456 02 596 7455 Mexico 5 520 2635 5 520 3282 Netherlands 0348 433466 0348 430673 Norway 32 84 84 00 32 84 86 00 Singapore 2265886 2265887 Spain 91 640 0085 91 640 0533 Sweden 08 730 49 70 08 730 43 70 Switzerland 056 200 51 51 056 200 51 55 Taiwan 02 377 1200 02 737 4644 United Kingdom 01635 523545 01635 523154 United States 512 795 8248 512 794 5678

Technical Support Form

Photocopy this form and update it each time you make changes to your software or hardware, and use the completed copy of this form as a reference for your current configuration. Completing this form accurately before contacting National Instruments for technical support helps our applications engineers answer your questions more efficiently.

If you are using any National Instruments hardware or software products related to this problem, include the configuration forms from their user manuals. Include additional pages if necessary.

Name __________________________________________________________________________ Company ______________________________________________ _________________________ Address ________________________________________________________________________

_______________________________________________________________________________ Fax (___ )___________________ Phone (___ ) __________________ ______________________ Computer brand ________________ Model ________________ Processor___________________ Operating system (include version number) ____________________________________________ Clock speed ______MHz RAM _____MB Display adapter __________________________ Mouse ___yes ___no Other adapters installed _________________ ____ __________________ Hard disk capacity _____MB Brand _____________________________________________ Instruments used _________________________________________________________________

_______________________________________________________________________________ National Instruments hardware product model________________ Revision _________ ____ ___ _ Configuration ___________________________________________________________________ National Instruments software product _______________________ ___ __ Version _ ___ ________ Configuration ___________________________________________________________________ The problem is: __________________________________________________________________

_______________________________________________________________________________

_______________________________________________________________________________ List any error messages: ___________________________________________________________

_______________________________________________________________________________

_______________________________________________________________________________ The following steps reproduce the problem: __ ___ ____ ___________________________________

_______________________________________________________________________________

Hardware and Software Configuration Form

Record the settings and revisions of your hardware and software on the line to the right of each item. Complete a new copy of this form each time you revise your software or hardware configuration, and use this form as a reference for your current configuration. Completing this form accurately before contacting National Instruments for technical support helps our applications engineers answer your questions more efficiently.

National Instruments Products

VXIpc 800 Series Hardware Settings

VXIpc 800 Series Model Number______ __________________________________________ _____ VXIpc 800 Series Part Number______________________________________________ _________ VXIpc 800 Series Serial Number _____________________________________________________ Processor Speed___________________________________________________________________ DRAM SIMMs Installed____________________________________________________________ Hard Drive Size_____________________ Video Memory ________________________________ Slot Location__________________________ ___________________________________________ W1 Setting: SCSI Termination _______________________________________________________ W2 Setting: CMOS ____ _________________________________________ ___________________ W4 Setting: LPT1 DMA _________________ _________________________________________ __ W13 Setting: Slot 0 Detection________________________________________________________ S1 Setting: Ethernet EEPROM _______________________________________________________ S2 Setting: MITE Self-Configuration __________________________________________________ S3 Setting: CLK10 Source __________________________________________________________ S4 Setting: Inverted/Non-inverted CLK10 Output ________________________________________ S5 Setting: CLK10 SMB____________________________________________________________ S6 Setting: CLK10 Input Termination _________________________________________________ S7 Setting: External Trigger Input Termination __________________________________________ S8 Setting: GPIB IRQ Level_________________________________________________________ S9 Setting: MITE User/Factory Configuration___________________________________________

Other Products

Mainframe make and model ___________________________________ _____________________ Microprocessor __________________________________________________________________ Clock frequency or speed ___________________________________________________________ Type of video board installed _______ ________________________________________________ Operating system and version _______________________________________________________ Operating system mode ____________________________________ ________________________ Programming language _______________________________________ _____________________ Programming language version _________ _____________________________________________ Other boards in system _________________________________ ___________________________ Monitor (manufacturer, model) ______________________________________________________ Mouse (manufacturer, model)________________________________________________________ Keyboard (manufacturer, model) _____________________________________________________ Other peripherals (manufacturer, model) ______________________________ ___ ______________

_______________________________________________________________________________ _______________________________________________________________________________ _______________________________________________________________________________

Documentation Comment Form

National Instruments encourages you to comment on the documentation supplied with our products. This information helps us provide quality products to meet your needs.

Title: VXIpc Edition Date: September 1997 Part Number: 321744A-01

Please comment on the completeness, clarity, and organization of the manual.

_______________________________________________________________________________

If you find errors in the manual, please record the page numbers and describe the errors.

_______________________________________________________________________________

™

800 Series User Manual

Thank you for your help. Name _________________________________________________________________________ Title __________________________________________________________________________ Company _______________________________________________________________________ Address _____________________________________ ___________________________________

________________________________________ ______________________________________ _ Phone (___ )__________________________ Fax (___ ) _________________________________

Mail to: Technical Publications Fax to: Technical Publications

National Instruments Corporation National Instruments Corporation 6504 Bridge Point Parkway (512) 794-5678 Austin, TX 78730-5039

Prefix Meaning Value

Glossary

n- nano- 10 µ- micro- 10

m- milli- 10

k- kilo- 10

M- mega- 10

G- giga- 10

–9

–6

–3

A Amperes address Character code that identifies a specific location (or series of locations)

in memory

address space A set of 2

VMEbus systems by six addressing lines known as address modifiers. n is the number of address lines required to uniquely specify a byte location in a given space. Valid numbers for n are 16, 24, and 32. In VME/VXI, because there are six address modifiers, there are 64 possible address spaces.

memory locations differentiated from other such sets in VXI/

ANSI American National Standards Institute ASIC application-specific integrated circuit

Glossary

b bits Bbytes backplane An assembly, typically a printed circuit board, with 96-pin connectors

and signal paths that bus the connector pins. A C-size VXIbus system will have two sets of bused connectors called J1 and J2. A D-size VXIbus system will have three sets of bused connectors called J1, J2,

and J3. BERR* Bus error signal BIOS Basic Input/Output System. BIOS functions are the fundamental level

of any PC or compatible computer. BIOS functions embody the basic

operations needed for successful use of the computer’s hardware

resources. bus error An error that signals failed access to an address. Bus errors occur with

low-level accesses to memory and usually involve hardware with bus

mapping capabilities. For example, nonexistent memory, a nonexistent

CLK10 A 10 MHz, ±100 ppm, individually buffered (to each module slot),

differential ECL system clock that is sourced from Slot 0 of a VXIbus

mainframe and distributed to Slots 1 through 12 on P2. It is distributed

to each slot as a single-source, single-destinati on signal with a matched

delay of under 8 ns. CMOS Complementary Metal Oxide Semiconductor; a process used in making

chips

DIN Deutsches Institut für Normung—German Standards Institute DMA Direct Memory Access; a method by which data is transferred between

devices and internal memory without intervention of the central

processing unit

Glossary

DRAM Dynamic RAM (Random Access Memory); storage that the computer

must refresh at frequent intervals

ECL Emitter-Coupled Logic EDO Extended Data Out; a DRAM architecture that shortens overall access

latency, improving performance EEPROM Electronically Erasable Programmable Read Only Memory embedded controller An intelligent CPU (controller) interface plugged directly into the VXI

backplane, giving it direct access to the VXIbus. It must have all of its

required VXI interface capabilities built in. EMC Electromagnetic Compliance

fair requester A VXIbus device that will not arbitrate for the VXIbus after releasing

it until it detects the bus request signal inactive. This ensures that all

requesting devices will be granted use of the bus. FPERR Floating Point Error

GPIB General Purpose Interface Bus (IEEE 488)

hex hexadecimal; the numbering system with base 16, using the digits 0 to 9

and letters A to F Hz hertz; cycles per second

Glossary

IDE Integrated Drive Electronics. Denotes the most common interface to the

hard drive on PCs. IEEE Institute of Electrical and Electronics Engineers in. inches I/O input/output; the techniques, media, and devices used to achieve

communication between machines and users instrument driver A set of routines designed to control a specific instrument or family of

instruments, and any necessary related files for LabWindows/CVI or

LabVIEW INT interrupt INTA PCI interrupt A INTB PCI interrupt B INTC PCI interrupt C INTD PCI interrupt D interrupt A means for a device to request service from another device interrupt handler A VMEbus functional module that detects interrupt requests generated

by interrupters and responds to those requests by requesting status and

identify information interrupt level The relative priority at which a device can interrupt IRQ* Interrupt signal ISA Industry Standard Architecture denotes a common expansion bus used

in PCs

KB kilobytes of memory

Glossary

LED Light-emitting diode

m meters master A functional part of a VME/VXIbus device that initiates data transfers

on the backplane. A transfer can be either a read or a write. MB megabytes of memory MITE A National Instruments custom ASIC, a sophisticated dual-channel

DMA controller that incorporates the Synchronous MXI and VME64

protocols to achieve high-performance block transfer rates MODID Module ID Lines. Used in VXI to geographically locate boards and to

dynamically configure boards MTBF Mean Time Between Failure

NI-VISA The National Instruments implementation of the VISA standard; an

interface-independent software that provides a unified programming

interface for VXI, GPIB, and serial instruments NI-VXI The National Instruments bus interface software for VME/VXIbus

systems NMI NonMaskable Interrupt Non-Slot 0 device A device configured for installation in any slot in a VXIbus mainframe

other than Slot 0. Installing such a device into Slot 0 can damage the

device, the VXIbus backplane, or both.

Glossary

PCI Peripheral Component Interconnect. The PCI bus is a high-performance

32-bit or 64-bit bus with multiplexed address and data lines. PCMCIA Personal Computer Memory Card International Association PEM Penn Engineering Manufacturing Corporation. A manufacturer of nuts

pressed into metal POSC Power-On Self Configuration. A process by which the MITE chip

programs its own registers from EEPROMs at power up PWB Printed Wire Board

Resource Manager A message-based Commander located at Logical Address 0, which

provides configuration management services such as address map

configuration, Commander and Servant mappings, and self-test and

diagnostic management

s seconds SCSI Small Computer System Interface SIMM Single In-line Memory Module slave A functional part of a VME/VXIbus device that detects data transfer

cycles initiated by a VMEbus master and responds to the transfers when

the address specifies one of the device’s registers Slot 0 device A device configured for installation in Slot 0 of a VXIbus mainframe.

This device is unique in the VXIbus system in that it performs the

VMEbus System Controller functions, including clock sourcing and

arbitration for data transfers across the backplane. Installing such a

device into any other slot can damage the device, the VXIbus

backplane, or both. SMB Sub Miniature Type B connector that features a snap coupling for fa st

connection

Glossary

trigger Either TTL or ECL lines used for intermodule communication TTL Transistor-Transistor Logic

VVolts VISA Virtual Instrument Software Architecture. This is the general name

given to VISA and its associated architecture. VME Versa Module Eurocard or IEEE 1014 VMEbus System A device configured for installation in Slot 0 of a VXIbus mainframe

Controller or Slot 1 of a VMEbus chassis. This device is unique in the VMEbus

system in that it performs the VMEbus System Controller functions,

including clock sourcing and arbitration for data transfers across the

backplane. Installing such a device into any o ther s lot can da mage th e

device, the VMEbus/VXIbus backplane, or both. VXIbus VMEbus Extensions for Instrumentation

Index

ACCESS LED, 1-7, C-3 address map, I/O (table), B-3 to B-4 application-specific interface chips, custom, 1-5 audio capability.

See

speaker.

National Instruments 800 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
