Version 5.1 Addendum
LabVIEW 5.1 Addendum
February 1999 Edition
Part Number 322179A-01
Internet Support
E-mail: support@natinst.com
FTP Site: ftp.natinst.com
Web Address: http://www.natinst.com
Bulletin Board Support
BBS United States: 512 794 5422
BBS United Kingdom: 01635 551422
BBS France: 01 48 65 15 59
Fax-on-Demand Support
512 418 1111
Telephone Support (USA)
Tel: 512 795 8248
Fax: 512 794 5678
International Offices
Australia 03 9879 5166, Austria 0662 45 79 90 0, Belgium 02 757 00 20, Brazil 011 288 3336,
Canada (Ontario) 905 785 0085, Canada (Québec) 514 694 8521, Denmark 45 76 26 00, Finland 09 725 725 11,
France 01 48 14 24 24, Germany 089 741 31 30, Hong Kong 2645 3186, Israel 03 6120092, Italy 02 413091,
Japan 03 5472 2970, Korea 02 596 7456, Mexico 5 520 2635, Netherlands 0348 433466, Norway 32 84 84 00,
Singapore 2265886, Spain 91 640 0085, Sweden 08 730 49 70, Switzerland 056 200 51 51, Taiwan 02 377 1200,
United Kingdom 01635 523545
National Instruments Corporate Headquarters
6504 Bridge Point Parkway Austin, Texas 78730-5039 USA Tel: 512 794 0100
© Copyright 1999 National Instruments Corporation. All rights reserved.
Important Information
Warranty
The media on which you receive National Instruments software are warranted not to fail to execute programming
instructions, due to defects in materials and work man ship, for a peri od of 90 d ays from da te o f sh ipm ent, as evi denced
by receipts or other documentation. National Instruments will, at its option, repair or replace software media that do not
execute programming instructions if National Instruments receives noti ce of su ch defect s d uring th e warranty perio d.
National Instruments does not warrant that the op eration of t he soft ware shall b e uni nterrup ted or erro r free.
A Return Material Authorization (RMA) number must b e ob tain ed fro m th e facto ry an d clearl y mark ed on t he outsi de
of the package before any equipment wil l be accepted for warranty work. National Instruments will pay the shippi ng costs
of returning to the owner parts which are covered by warran ty.
National Instruments believes that the information in this manual is accurate. The document has been c arefully reviewed
for technical accuracy. In the event that technical or typographical errors exist, National Instruments reserves the right to
make changes to subsequent editions of th is do cume nt with ou t p rio r no ti ce to hold ers o f thi s ed itio n. The read er sh ou ld
consult National Instruments if errors are suspected. In no event shall National Instruments be liable for any damages
arising out of or related to this docume nt o r th e in form ati on con tai ned in i t.
XCEPT AS SPECIFIED HEREIN
E
ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
BY FAULT OR NEGLIGENCE ON THE PART OF NATIONAL INSTRUMENTS SHALL BE LIMITED TO THE AMOUNT THERETOFORE PAID BY THE
CUSTOMER
OR INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF ADVISED OF THE POSSIBILITY THEREOF
National Instruments will apply regardless of the form of action, wh ether in con tract or tort , incl udin g n egli gen ce.
Any action against National Instruments must be brought within one year after the cause of action accrues. National
Instruments shall not be liable for any delay in performance due to causes beyond its reasonable control. The warranty
provided herein does not cover damages, defects, malfuncti ons, or s ervice failur es caused by own er’s fai lure to fol low
the National Instruments installation, operation, or maintenance instructions; owner’s modification of the product;
owner’s abuse, misuse, or negligent acts; and power failure or surges, fire, flood, accident, actions of third parties,
or other events outside reasonable control.
ATIONAL INSTRUMENTS WILL NOT BE LIABLE FOR DAMAGES RESULTING FROM LOSS OF DATA, PROFITS, USE OF PRODUCTS
. N
ATIONAL INSTRUMENTS MAKES NO WARRANTIES, EXPRESS OR IMPLIED, AND SPECIFICALLY DISCLAIMS
, N
Copyright
Under the copyright laws, this publication may not be reproduced or transmitted in any form, electronic or mechanical,
including photocopying, recording, storing in an information retrieval system, or translating, in whole or in part, without
the prior written consent of National Instruments Corporation.
USTOMER’S RIGHT TO RECOVER DAMAGES CAUSED
. C
. This limitation of the liability of
,
Trademarks
ComponentWorks™, CVI™, DataSocket™, HiQ™, LabVIEW™, natinst.com™, National Instruments™, NI-488.2™,
™
NI-DAQ
Product and company names listed are trademarks or trade names of their respective companies.
, and NI-VXI™ are trademarks of National Instruments Corporation.
WARNING REGARDING MEDICAL AND CLINICAL USE OF NATIONAL INSTRUMENTS PRODUCTS
National Instruments products are not designed with com ponent s and tes ting inten ded to ensure a l evel of reliab ilit y
suitable for use in treatment and diagnosis of humans. Applications of National Instruments products invol ving m edical
or clinical treatment can create a potential for accidental injury caused by product failure, or by errors on the part of the
user or application designer. Any use or application of National Instruments products for or involving medical or clinical
treatment must be performed by properly trained and qualified medical personnel, and all traditional medical safeguards,
equipment, and procedures that are appropriate in the particular situation to prevent serious injury or death should always
continue to be used when National Instruments products are being used . National Instrum ents product s are NOT intended
to be a substitute for any form of established process, procedure, or equipment used to monitor or safeguard human health
and safety in medical or clinical treatment.
Contents
About This Addendum
Chapter 1
Required Configuration, Installation, and Upgrade Information
Required System Configuration......................................... ............................................1-1
Operating System Patches .............................................................................................1-4
Concurrent PowerMAX...................................................................................1-4
Distribution Changes in LabVIEW 5.1..........................................................................1-5
LabVIEW 5.1 Platforms..................................................................................1-5
Discontinued Media.........................................................................................1-5
Installing LabVIEW.......................................................................................................1-6
LabVIEW RT ...................................................... ............................................1-6
Windows..........................................................................................................1-6
Macintosh........................................................................................................1-7
UNIX...............................................................................................................1-7
For More Information about LabVIEW..........................................................1-10
Data Acquisition, VXI, and GPIB Installation Notes......................................1-10
Installing HiQ for Windows ..........................................................................................1-12
Examples and Solutions for Your LabVIEW Programs................................................1-12
Low-Level Register I/O for Windows 95/98.................................................................1-13
Common LabVIEW Launch Errors on UNIX...............................................................1-13
Configuring LabVIEW Windows on UNIX..................................................................1-14
Configuring LabVIEW with the Tab Window Manager.................................1-14
Configuring LabVIEW with the HP VUE Window Manager.........................1-14
Configuring LabVIEW with the Motif or CDE Window Manager ................1-14
Notice to Sun SPARCstation 5 Users............................................................................1-15
Compatibility Issues between Versions 4.1 and 5.x ......................................................1-16
Compatibility VIs for New Server Functionality............................................1-16
Compatibility VIs for ActiveX Functions.......................................................1-16
Additional Resources.....................................................................................................1-17
Upgrading to LabVIEW 5.1...........................................................................................1-17
Converting VIs ................................................................................................ 1-18
Upgrading Application Libraries and Toolkits................................................1-18
©
National Instruments Corporation v LabVIEW 5.1 Addendum
Contents
Chapter 2
New Features in LabVIEW 5.1
Dialog Box, Menu, and Window Enhancements ..........................................................2-1
Scaling Front Panel Objects............................................................................2-1
Saving for a Previous Version ........................................................................2-4
Accessing Recently Opened Files................................................................... 2-4
Searching in LabVIEW...................................................................................2-5
Macintosh Navigation Services in LabVIEW.................................................2-6
New VIs, Functions, and Controls ................................................................................2-7
Changes to Controls and Indicators................................................................2-7
3D Graph Controls for Windows....................................................................2-9
Enhancements to Property and Invoke Nodes ................................................2-9
Improvements to VI Server Properties in Reserved VIs and
Runtime Systems..........................................................................................2-9
Ring Enhancements.........................................................................................2-11
ActiveX Enhancements for Windows.............................................................2-13
ActiveX Event Functions for Windows..........................................................2-14
HiQ and MATLAB Functionality for Windows.............................................2-15
Integration of Mathematics and Signal Processing VIs..................................2-22
Integration of the Picture Control VIs.............................................................2-24
Sound VIs for Windows and Macintosh.........................................................2-25
Generating Reports in LabVIEW for Windows..............................................2-25
Report Generation VI Descriptions.................................................................2-28
Enhancements to DAQ..................................................................................................2-39
DAQ Solution Wizard.....................................................................................2-39
Support for NI-DAQ for Windows and Macintosh ........................................2-39
New Syntax Element for Nonsequentially Scanned SCXI
Module Channels .........................................................................................2-39
Enhancements to VISA .................................................................................................2-40
Enhancements for Building and Distributing Applications...........................................2-41
Building Executable Programs........................................................................2-41
Run-Time Engine for the Application Builder for Windows .........................2-46
Enhancements to Networking........................................................................................2-47
DataSocket VIs for Windows .........................................................................2-47
Internet/HTTP Services...................................................................................2-47
Enhancements to Examples and Activities....................................................................2-62
LabVIEW 5.1 Addendum vi
©
National Instruments Corporation
Appendix A
Manual Clarifications and Additions
Multithreading ...............................................................................................................A-1
ActiveX..........................................................................................................................A-1
Instrumentation..............................................................................................................A-2
General Interface Features.............................................................................................A-2
Icon and Text Palettes .....................................................................................A-2
File Manager Tool...........................................................................................A-3
Other General Interface Features.....................................................................A-5
Support for Template VIs and Controls.........................................................................A-7
Adding VIs to the Project and Help Menus...................................................................A-7
Allocation of Threads on Concurrent PowerMAX and Solaris 2..................................A-7
Clarifications to the LabVIEW User Manual................................................................A-8
VISA Error Codes..........................................................................................................A-9
Index
Figures
Figure 2-1. Dialog Palette........................................................................................ 2-8
Figure 2-2. Ring Constant Examples.......................................................................2-11
Figure 2-3. Setting a Data Value with a Numeric Constant.....................................2-12
Figure 2-4. Setting a Data Value with a Ring Constant...........................................2-12
Figure 2-5. ActiveX Events Palette..........................................................................2-14
Figure 2-6. Web Server Browser Access Dialog Box..............................................2-49
Figure 2-7. Web Server Visible VIs Dialog Box.....................................................2-52
Contents
Figure A-1. File Manager Tool Dialog Box .............................................................A-4
©
National Instruments Corporation vii LabVIEW 5.1 Addendum
Contents
Tables
Table 1-1. Installation Requirements ....................................................................1-2
Table 1-2. Common LabVIEW Launch Errors on UNIX .....................................1-13
Table 2-1. HiQ and MATLAB Datatypes in LabVIEW .......................................2-21
Table 2-2. Script Node Runtime Error Messages ..................................................2-22
Table 2-3. Mathematics VIs Current and Previous Locations ..............................2-23
Table 2-4. Signal Processing VIs Current and Previous Locations ......................2-24
Table 2-5. Token Descriptions ..............................................................................2-27
Table 2-6. Web Server Configuration Dialog Box Options ..................................2-48
Table 2-7. Web Server Browser Access Dialog Box Options .............................. 2-50
Table 2-8. Examples of Access List Entries ..........................................................2-51
Table 2-9. Web Server Visible VIs Dialog Box Options ......................................2-53
Table 2-10. Wildcard Characters in Visible VIs List ..............................................2-54
Table 2-11. Examples of Visible VI List Entries ....................................................2-54
LabVIEW 5.1 Addendum viii
©
National Instruments Corporation
About This Addendum
This addendum describes all of the new LabVIEW 5.1 features,
compatibility issues, and configuration, installation, and upgrade
information. Upgrade issues pertain to LabVIEW 5.1 only.
Note
LabVIEW 5.1 ships with the same manual set that shipped with LabVIEW 5.0.
This addendum updates that documentation. However, enhancements to
LabVIEW 5.1 have rendered some information in the manuals incorrect. Please
refer to Appendix A, Manual Clarifications and Additions, for corrections and
important information.
This document is divided into the following sections:
• Chapter 1, Required Configuration, Installation, and Upgrade
Information, describes the system requirements for the LabVIEW
software and contains installation instructions and updated
documentation information.
• Chapter 2, New Features in LabVIEW 5.1, describes the features added
and the significant changes made between versions 5.0 and 5.1. T o help
you learn more about LabVIEW, version 5.1 offers extensive online
documentation, which you can access by choosing Help»Online
Reference....
• Appendix A, Manual Clarifications and Additions, clarifies and
corrects information in the LabVIEW manual set.
• The Index contains an alphabetical list of key words and topics in this
manual, including the page where you can find each one.
Regardless of whether you are a new or upgrade user, begin by reading
Chapter 1, Required Configuration, Installation, and Upgrade Information
before continuing with this installation.
If you are upgrading from a previous version of LabVIEW, carefully read
the Upgrading to LabVIEW 5.1 section in Chapter 1, Required
Configuration, Installation, and Upgrade Information.
Note
©
National Instruments Corporation ix LabVIEW 5.1 Addendum
LabVIEW is Year-2000 compliant. Because LabVIEW has never stored two-digit
years, the change to 2000 does not affect any internal storage of dates.
Required Configuration,
Installation, and Upgrade
Information
This chapter describes the system requirements for the LabVIEW software
and contains installation instructions and updated documentation
information.
Read the Required System Configuration section, then follow the
instructions in the Installing LabVIEW section of this chapter.
Required System Configuration
Table1-1 describes the minimum system requirements needed to run
LabVIEW 5.1.
1
©
National Instruments Corporation 1-1 LabVIEW 5.1 Addendum
Chapter 1 Required Configuration, Installation, and Upgrade Information
Table 1-1. Installation Requirements
Media and System
Platform
Requirements
Important Notes
All Windows
Versions
Distributed on CD-ROM.
A separate CD contains the
complete instrument driver
library.
You need a minimum of
60 MB of disk storage space
for the Base package or
85 MB for the Full
Development System.
You need a minimum of
16 MB of RAM.
Windows 95/98 LabVIEW runs on any
system that supports
Windows 95/98.
The LabVIEW Online Tutorial default
configuration requires the LabVIEW 5.1
distribution CD to be in your CD-ROM
drive. You also can install the LabVIEW
Online Tutorial files on your hard dri ve. This
installation requires approximately 40 MB
of hard disk space.
The LabVIEW Online Tutorial and
LabVIEW Help files contain 256-color
graphics. Your video driver, configured
through Control Panels»Display, must be
configured for at least 256 colors. Minimum
requirements to view the tutorial are
800 × 600 pixel resolution and the Microsoft
Video for Windows driver. To view Help
files, configure your video dri v er for at least
256 colors with 800 × 600 pixel resolution.
National Instruments recommends 32 MB of
RAM and a Pentium processor for this
version to run effectively.
Windows NT LabVIEW runs on
Windows NT 4.0 Service
Pack 3 or later.
DEC Alpha, MIPS, and
PowerPC 80x86 emulators
must emulate 80386
instructions to run
LabVIEW.
LabVIEW 5.1 Addendum 1-2
©
National Instruments Corporation
Platform
Chapter 1 Required Configuration, Installation, and Upgrade Information
Table 1-1. Installation Requirements (Continued)
Media and System
Requirements
Important Notes
Power Macintosh Distributed on CD.
LabVIEW requires
System 7 or 8.
You need a minimum of
24 MB of RAM and at least
100 MB of disk storage
space for the minimal
installation of LabVIEW
or 120 MB for the full
installation.
All UNIX Versions LabVIEW requires an X
Window System server,
such as OpenWindows 3.x,
HP-VUE, or X11R6.
You need a minimum of
32 MB of RAM with 32 MB
of swap space storage.
You need a minimum of
65 MB of disk storage space
for the entire LabVIEW
package.
National Instruments recommends that you
have at least 32 MB of RAM. You might
need more memory, depending on the size of
the application you design in LabVIEW and
the amount of data that your application
manipulates.
For more accurate timing, install the Apple
QuickTime extension. When you use
QuickTime, timing accuracy should increase
from 16.6 ms resolution to approximately
1 ms resolution. Sy s tem response varies
depending on background applications,
other extensions, networking activity, and
disk caching.
LabVIEW uses a directory for storing
temporary files. Some of the temporary files
are large, so keep several megabytes of disk
space available for this temporary directory.
The default for the temporary directory is
/tmp. You can change the temporary
directory by selecting Edit»Preferences....
If LabVIEW aborts unexpectedly, it might
leave files behind in the temporary directory .
Remove old files occasionally to avoid
depleting your disk space.
To save space, install only the VIs you plan
to use.
LabVIEW does not require a specific
graphical user interface (GUI) such as Motif
or OpenLook, because LabVIEW uses
Xlib
to create its own GUI.
Sun Distributed on CD.
LabVIEW runs on
SPARCstations with
Solaris 2.4 or later.
©
National Instruments Corporation 1-3 LabVIEW 5.1 Addendum
Chapter 1 Required Configuration, Installation, and Upgrade Information
Table 1-1.
Media and System
Platform
HP-UX Distributed on CD.
Linux Distributed on CD.
Concurrent PowerMAX
Requirements
LabVIEW runs on
Hewlett-Packard
Model9000 Series 700
computers with HP-UX
10.20 or later.
LabVIEW runs on Linux for
Intel x86 processors,
version2.0.x or later.
Distributed on 4 mm
DATtape.
LabVIEW runs on
PowerMAX version4.2
orlater.
Installation Requirements (Continued)
Operating System Patches
Important Notes
HP workstations limit the size of a process
such as LabVIEW to 64 MB. You may need
to increase this setting to accommodate your
LabVIEW application. For information on
changing this setting, see the HP-UX 10.x
section under Installing LabVIEW.
Requires GNU C Library Version 2
(
glibc2, also known as libc.so.6).
RedHat Linux 5.0 or later includes the
glibc2 runtime library.
See the Operating System Patches section
for Concurrent PowerMAX below for
information on the patches you must
download to run LabVIEW.
For your LabVIEW package to run effectively, be sure to install the
following patches.
Concurrent PowerMAX
LabVIEW 5.1 requires version 4.2 or later of the PowerMAX operating
system. In addition, you must install the following patches, available from
Concurrent, so that basic LabVIEW networking functions correctly:
• inet-005
• One of the following, depending on your system:
– base-007 for Power Hawk 610, Power Hawk 620, and all
single-processor PowerStack systems
– base-008 for Power Hawk 640 and multi-processor
PowerStackII systems
– base-009 for Night Hawk systems
LabVIEW 5.1 Addendum 1-4
©
National Instruments Corporation
Chapter 1 Required Configuration, Installation, and Upgrade Information
Distribution Changes in LabVIEW 5.1
This section explains changes in platform support and installation media
with this and subsequent versions of LabVIEW.
LabVIEW 5.1 Platforms
LabVIEW 5.1 is now available with limited support on Linux/x86. For
more information, see
LabVIEW 5.1 and planned future versions of LabVIEW are not available
on the following platforms:
• Windows 3.x
• Macintosh for the Motorola 680x0
• Solaris 1.x
•HP-UX 9.x
You can purchase LabVIEW 5.0.x for these platforms and maintenance
upgrades and fixes are available from National Instruments, but National
Instruments plans no new feature development for these platforms. Contact
National Instruments to purchase LabVIEW 5.0.x.
http://www.natinst.com/linux.
Note
LabVIEW 5.1 has a Save for Previous option that can ease this transition. Notice
that choosing this option only maintains window proportions. T o have the objects
maintain proportions, you must also choose Scale All Objects on Panel.
Alternatively, you could c hoose a single object to scale when the window changes
size. See the Saving for a Previous Version section of Chapter 2, New Features in
LabVIEW 5.1, for more information.
Discontinued Media
National Instruments ships LabVIEW 5.1 on CD-ROM only. If you do not
have a CD-ROM drive on your system, contact National Instruments.
©
National Instruments Corporation 1-5 LabVIEW 5.1 Addendum
Chapter 1 Required Configuration, Installation, and Upgrade Information
Installing LabVIEW
If you are upgrading from an earlier version of LabVIEW, read the
Upgrading to LabVIEW 5.1 section later in this chapter before installing
LabVIEW.
LabVIEW RT
(Windows)
LabVIEW Online Tutorial. Launch the tutorial by clicking LabVIEW
Tutorial in the LabVIEW dialog box.
To access the LabVIEW dialog box, either launch LabVIEW or close all
open LabVIEW VIs if you already are running LabVIEW.
(Windows)
appears, from which you can choose to install LabVIEW, install HiQ, or
run the toolkit demos.
LabVIEW RT works with National Instruments RT Series intelligent DAQ
hardware, and allows you to perform real-time, deterministic data
acquisition and to control applications on Windows PCs. With LabVIEW
RT, you can create embedded VIs that run in real-time on processor-based
RT Series hardware. Combined with the RT Series intelligent DAQ boards,
LabVIEW RT gives you the simple graphical programming of LabVIEW
with proven DAQ technology for a complete, integrated solution for
real-time applications.
If you are installing LabVIEW RT instead of LabVIEW 5.1, refer to the
RT Series Hardware and LabVIEW RT User Manual for complete
installation instructions.
For an introduction to the LabVIEW environment, complete the
When you insert the LabVIEW installation CD, a dialog box
Caution
!
LabVIEW RT is English only. If you are upgrading from a non-English version
of LabVIEW to LabVIEW RT, your version of LabVIEW will be in English.
Windows
Complete the following steps to install LabVIEW for Windows.
(Windows NT)
1.
with administrator privileges.
2. If you are installing LabVIEW for Windows 95/98/NT, run
x
:\AUTORUN.EXE, where
LabVIEW 5.1 Addendum 1-6
Log on to Windows NT as an administrator or as a user
x
is the drive letter for your CD-ROM dri ve.
©
National Instruments Corporation
Chapter 1 Required Configuration, Installation, and Upgrade Information
Note The installer gives you the option of performing a full installation or a minimal
installation. If you do not have sufficient disk space (approximately 85 MB),
choose the minimal installation and use your LabVIEW CD to access the
remaining components.
3. After you choose an installation, follow the instructions that appear on
your screen.
4. After you have completed the installation, LabVIEW is ready to run.
If you plan to use DAQ or GPIB devices with LabVIEW, you must
restart your computer to load the new drivers.
If you have installed LabVIEW on a server , new users might want to copy
the
Activity directory from the server to their local machine. You use the
Activity directory to complete activities that illustrate basic LabVIEW
concepts. You can find these activities in the LabVIEW User Manual and
the LabVIEW Online Reference, which you can access by selecting
Help»Online Reference….
Macintosh
Complete the following steps to install LabVIEW for Macintosh.
1. Insert the LabVIEW installation CD into your computer’s CD-ROM
drive.
2. Run the
Install mode, which installs all LabVIEW examples, DAQ VIs, and
NI-DAQ 6.1 with drivers. You can choose to install each component
separately by choosing Custom Install from the drop-down menu.
3. Follow the instructions that appear on your screen.
LV51 PMAC Installer. The installer defaults to the Easy
UNIX
Complete the following steps to install LabVIEW for UNIX.
Solaris 2
1. To enable superuser privileges, type su root and enter the root
password.
2. Insert the LabVIEW CD. On Solaris 2.x, the CD automatically mounts
as soon as the CD is inserted into the drive. If this feature is disabled
on your workstation, you must mount the CD by typing the following
command:
mount -o ro -F hsfs /dev/dsk/c0t6d0s2 /cdrom
©
National Instruments Corporation 1-7 LabVIEW 5.1 Addendum
Chapter 1 Required Configuration, Installation, and Upgrade Information
3. If your CD was mounted automatically, type the following command:
pkgadd -d /cdrom/cdrom0/solaris2
4. If you used the mount command in step 2, type the following
command:
pkgadd -d /cdrom/solaris2
Note
See the README file in /cdrom/cdrom0/solaris2 or /cdrom/solaris2 for
instructions on custom installation or other additional information.
5. Follow the instructions on your screen.
HP-UX 10.
x
By default, HP workstations limit the size of a process such as LabVIEW
to 64 MB. You can change this setting by adjusting a kernel configuration
parameter that limits the amount of data a process can use. To edit this
parameter, enable superuser privileges by typing
su root and entering the
root password. Use the SAM system administration utility to view the list
of kernel configuration parameters. From SAM, go to Kernel
Configuration»Configurable Parameters and change the value of the
maxdsiz, or Maximum Data Segment Size (bytes) parameter to a larger
value. If you need to rebuild the kernel and reboot for changes to take
effect, the SAM utility guides you through this process.
1. To enable superuser privileges, type
su root and enter the root
password.
2. Mount the LabVIEW CD on the
/cdrom directory with the SAM
system administration utility.
3. To change to the installation directory, type the following command:
cd /cdrom/HP-UX
4. To run the installation script, type the following command:
./INSTALL
5. Follow the instructions on your screen.
Linux
To install LabVIEW 5.1 for Linux/x86, perform the following steps.
1. Login to your system as
2. Mount the CD-ROM.
LabVIEW 5.1 Addendum 1-8
root.
©
National Instruments Corporation
Chapter 1 Required Configuration, Installation, and Upgrade Information
3. To change the current directory to the mounted CD-ROM, type the
following command:
cd /mnt/cdrom.
4. To run the installation script, type the following command:
./INSTALL.
The INSTALL script prompts you to enter the directory where you want
to install LabVIEW (typically
/usr/local or /opt). The script uses
RPM to install the RedHat package on RedHat Linux 5.0 or later
systems, or it extracts the
Note If your system does not have the required glibc2 libraries installed, you have the
option to install LabVIEW 4.1.1 instead. The file
detailed instructions on how to obtain and install
.tar.gz archives on other systems.
Glibc2-HOWTO on the CD gives
glibc2.
You also can install the files by hand, using either RPM or glint on RedHat
systems, or
4.1.1 and 5.1 simultaneously, use the
Note Refer to the README file on the CD for additional installation instructions.
tar/gunzip on other systems. To install LabVIEW versions
--force rpm option.
PowerMAX
1. Insert the 4 mm DAT tape into the tape drive.
2. To create the directory in which you will install LabVIEW, type the
following command:
mkdir /opt/lv51
3. To change to the new directory, type the following command:
cd /opt/lv51
4. Extract the files from the tape by typing the following command:
tar xv
5. To run the installation script, type the following command:
./INSTALL
6. Follow the instructions on your screen.
©
National Instruments Corporation 1-9 LabVIEW 5.1 Addendum
Chapter 1 Required Configuration, Installation, and Upgrade Information
For More Information about LabVIEW
After you have installed LabVIEW completely, it is ready to run.
The LabVIEW User Manual and the LabVIEW Online Reference, which
you can access by selecting Help»Online Reference…, pro vide activities
that illustrate basic LabVIEW concepts. If you want to complete these
activities, copy the
your home directory.
The LabVIEW documentation set, including the Code Interface Reference
Manual and the VXI VI Reference Manual, is available in Portable
Document Format (PDF) on the LabVIEW CD in the
directory. You can copy this directory or selected PDF files to the
LabVIEW\manuals directory on your hard drive. You must have Adobe
Acrobat Reader 3.0 or later installed to view these files.
If you are upgrading from a previous version of LabVIEW , read the
Upgrading to LabVIEW 5.1 section, later in this chapter. If you have one of
the add-on toolsets, consider installing those files at this time.
Activity directory from the LabVIEW directory to
Data Acquisition, VXI, and GPIB Installation Notes
All National Instruments GPIB interfaces and DAQ devices come with the
drivers and other software you need to use them. LabVIEW also comes
with the drivers and other software you need to use National Instruments
hardware. While the drivers included with LabVIEW are the same
NI-488.2 and NI-DAQ drivers National Instruments includes with its GPIB
and DAQ hardware, the version numbers might differ. Always use the
driver with the higher version number. You can determine which version
of NI-DAQ you are using with LabVIEW by running the Get Device
Information VI.
manuals
Windows
When you install LabVIEW, the installer places the application and most
of the related files in a directory you specify. The default name of this
directory is
additional files, described in the following sections.
Use the National Instruments Measurement & Automation Explorer, which
runs with LabVIEW, to configure your hardware. For information about
how to configure your particular DAQ device, refer to the Measurement &
Automation Explorer Help.
LabVIEW 5.1 Addendum 1-10
LABVIEW. If you install DAQ or GPIB VIs, the installer places
©
National Instruments Corporation
Chapter 1 Required Configuration, Installation, and Upgrade Information
You can find further information about the NI-DAQ driver in the NI-DAQ
Read Me File. To view this file, click the Start button and select
Programs»LabVIEW»NI-DAQ Read Me File.
Macintosh
The LabVIEW installation program installs a control panel and various
extensions in your system folder:
• For GPIB, LabVIEW installs the
NI-488 Config control panel,
which contains the driver code that communicates with your GPIB
devices. LabVIEW also installs extensions that your GPIB hardware
and software require.
• For DAQ, LabVIEW installs the
NI-DAQ extension, which contains
driver code that communicates with your DAQ devices, along with
several other libraries and extensions that support NI-DAQ 6.1.
• The
NI-DMA/DSP extension contains DSP and DMA drivers used by
DAQ, GPIB, and DSP drivers.
Sun
While installing LabVIEW, you can choose the NI-488.2M drivers for
the GPIB hardware you are using (one of the following: SB-GPIB-TNT,
GPIB-ENET, or GPIB-SCSI-A). The installer then installs that driver
for you.
If you have a GPIB-SCSI-A, follow the installation instructions in the
documentation that came with your original GPIB-SCSI-A hardware and
software kit, including the Getting Started with Y our GPIB-SCSI-A and the
NI-488.2M Software for the Sun SPARC station manual.
Note
LabVIEW does not work with the GPIB-1014 series (VME) devices or the original
GPIB-SCSI box. It does work with the newer GPIB-SCSI-A box.
A VXI device driver must be installed on your system to perform VXIbus
operations from LabVIEW. Install the device driver for Solaris 2.x before
beginning development. To install the VXI device driver, refer to the
Getting Started with Y our VXI/VME-PCI8022 and the NI-VXI Software for
Solaris manual.
Note
National Instruments periodically updates drivers for GPIB and VXI. If you add
new GPIB or VXI hardware for use with LabVIEW, the included drivers might
supersede those sent with LabVIEW. Compare the version numbers and use the
driver with the higher number.
©
National Instruments Corporation 1-11 LabVIEW 5.1 Addendum
Chapter 1 Required Configuration, Installation, and Upgrade Information
Installing HiQ for Windows
The Windows CD includes HiQ, a mathematics application from National
Instruments. If you install HiQ from the LabVIEW installation CD, a
registration dialog box prompts you to enter a registration number. Use
your LabVIEW registration number in the HiQ registration dialog box. The
latest version of LabVIEW includes functionality that supports HiQ. If you
would like to take advantage of this functionality, but do not yet have HiQ,
be sure to install HiQ after you have installed LabVIEW. For more
information about this functionality, see the HiQ and MATLAB
Functionality for Windows section in Chapter 2, New Features in
LabVIEW 5.1.
Examples and Solutions for Your LabVIEW Programs
Note
(Windows and Macintosh)
instrument I/O and want to find examples or generate solutions for your
LabVIEW programs, launch the DAQ Solution Wizard by clicking
Solution Wizard in the LabVIEW dialog box. For more information
about the Solution Wizard, see Chapter 3, Data Acquisition, and Chapter 4,
Instrumentation, of the LabVIEW QuickStart Guide.
(Windows)
Help file by clicking Search Examples in the LabVIEW dialog box.
The
you can find the av ailable example s. When you select a VI, you can see the
documentation that was entered for that VI by choosing Windo w»Show VI
Info.... To open a VI, choose File»Open....
Because the controls and functions palettes changed with this release of
LabVIEW, many paths to examples are listed incorrectly or not listed at all
in the LabVIEW documentation set. Please see Chapter 2, New Features in
LabVIEW 5.1, for more information on the updated activities and examples.
To find any other type of example, open the Search Examples
examples directory contains a VI named readme.vi. With this VI,
If you are using data acquisition (DAQ) or
LabVIEW 5.1 Addendum 1-12
©
National Instruments Corporation
Chapter 1 Required Configuration, Installation, and Upgrade Information
Low-Level Register I/O for Windows 95/98
LabVIEW is very similar on all Windows operating systems. Unless your
application communicates with hardware that is not supported by one of the
operating systems, you can transfer VIs to other operating systems without
any problems or having to make any modifications.
LabVIEW has two VIs named In Port and Out Port that you can use to
read or write hardware registers. These VIs work under Windows 95/98.
Windows NT applications, however, cannot manipulate hardware directly.
If you need to communicate with a hardware device in Windows NT, you
must write a Windows NT driver.
Common LabVIEW Launch Errors on UNIX
Table 1-2 lists common errors that might occur when you launch
LabVIEW for UNIX. See the Required System Configuration section of
this chapter for more information about solving these and other installation
problems.
Table 1-2.
Common LabVIEW Launch Errors on UNIX
Error Message/Description Error Message/Description
Xlib: connection to :0.0
refused by server
Client is not authorized
to connect to server
Internal error during
connection authorization
check
“Executable version
doesn’t match resource
file”
Probable Cause—Trying to run LabVIEW as a user who does
not have permission to open a window on the display server.
Typically seen after running the
su command to temporarily
become a different user, such as root (superuser).
Solution—Exit the
su command and launch LabVIEW as
the login user.
Probable Cause—Version of LabVIEW executable does
not match version of
Solution—Verify that the
labview.rsc.
appResFilePath parameter
in the configuration file correctly sets the path to the
labview.rsc file.
©
National Instruments Corporation 1-13 LabVIEW 5.1 Addendum
Chapter 1 Required Configuration, Installation, and Upgrade Information
Configuring LabVIEW Windows on UNIX
This section describes procedures for configuring LabVIEW windows on
UNIX operating systems.
Configuring LabVIEW with the Tab Window Manager
If you use the Tab Window Manager (twm), you can change environment
settings so that
you cannot close the floating palette menus in LabVIEW if these windows
do not have title bars. To correct this problem, add the following line to
your
.twmrc file in your home directory:
DecorateTransients
This line adds title bars to the floating windows so you can close them.
Configuring LabVIEW with the HP VUE Window Manager
If you use the HP VUE Window Manager (vuewm), you can change
environment settings so that
default,
application. Consequently, LabVIEW windows—such as the Panel,
Diagram, Help, and File dialog windows—do not appear in consistent
locations on your screen. To change the
command to set two
Vuewm.clientAutoPlace: False
Vuewm.positionIsFrame: False
twm interacts better with LabVIEW. Notice that with twm,
vuewm interacts better with LabVIEW. By
vuewm does not incorporate the window position requests of an
vuewm behavior, use the xrdb
vuewm settings:
To add the two entries, you also can edit the following files manually:
$HOME/.vue/sessions/home/vue.resources
$HOME/.vue/sessions/current/vue.resources
Configuring LabVIEW with the Motif or CDE Window Manager
If you use the Motif Window Manager (mwm) or the Common Desktop
Environment (CDE) Window Manager (
environment settings so that mwm or
By default, mwm and
dtwm do not incorporate the window position requests
of an application. Consequently, LabVIEW windows—such as the Panel,
Diagram, Help, and File dialog windows—do not appear in consistent
locations on your screen.
LabVIEW 5.1 Addendum 1-14
dtwm), you can change
dtwm interacts better with LabVIEW.
©
National Instruments Corporation
Chapter 1 Required Configuration, Installation, and Upgrade Information
(Motif) To change the behavior of mwm, use the
mwm settings:
mwm.clientAutoPlace: False
mwm.positionIsFrame: False
(CDE)
To change the behavior of dtwm, use the
dtwm settings:
dtwm.clientAutoPlace: False
dtwm.positionIsFrame: False
(Motif and CDE)
To add the two entries, you also can edit the following file
manually:
$HOME/.Xdefaults
Notice to Sun SPARCstation 5 Users
A bug exists in some early revisions of the SPARCstation 5. This bug can
cause LabVIEW and other programs to hang the system when executing
certain floating-point operations. When this condition occurs, you must
physically reset the computer to recover. The problem exists in the
firmware of the computer and can occur when running SunOS 4.1.3_U1,
SunOS 4.1.4, and Solaris 2.x.
command to set two
xrdb
command to set two
xrdb
Note This bug has been reported only on early revisions of the 70 MHz and 85MHz
SPARCstation 5.
To determine whether your SPARCstation 5 is affected, perform the
following steps.
Caution Following these steps temporarily interrupts the operation of your computer, so
!
you should warn anyone who might be using your computer remotely.
1. From your SPARCstation 5 console, hold down the <
Stop/L1
> key
(located near the upper left corner of your keyboard) and press the <
key to break into the PROM monitor.
2. One of the following two prompts appears:
Type b (boot), c (continue), or n (new command mode)>
Type 'go' to resume ok
In the first case, select n to go to new command mode, where you see
an
ok prompt. If you already have an ok prompt, skip to step 3.
©
National Instruments Corporation 1-15 LabVIEW 5.1 Addendum
>
A
Chapter 1 Required Configuration, Installation, and Upgrade Information
3. At the ok prompt, type:
module-info
You then see information similar to the following lines:
CPU FMI,MB86904 Rev. 2.5 : 70.0 MHz
SBus (Divide By 3) : 23.3 MHz
4. Type go to exit the monitor and resume operation of your system.
If your CPU Revision number (2.5 in this example) is earlier than 3.2, and
your CPU clock speed (70.0 MHz in this example) is less than 110 MHz,
then your computer has this problem. Contact Sun and ask to have your
CPU firmware upgraded to swift_pg 3.2 or later. (Swift is the code name
used by Sun for the SPARCstation 5 firmware.) The Sun Bug ID number
for this problem is 1151654.
If you have a SPARCstation 5 with this bug, National Instruments strongly
recommends upgrading your firmware.
Note This problem can affect programs other than LabVIEW. Notably, the GNU C
compiler also can produce code that hangs your system in versions prior to 2.6.0.
Compatibility Issues between Versions 4.1 and 5.
This section describes the compatibility issues between different
LabVIEW versions.
Compatibility VIs for New Server Functionality
LabVIEW now can act as a server, so you have expanded control over VIs.
You can control VIs across a TCP/IP network and, on Windows, the
ActiveX interface. LabVIEW includes Compatibility VIs for the VI
Control VIs that exist in previous versions. For information about how to
implement the functionality from the VI Control VIs using the new server
functions, open each VI Control VI and analyze the implementation of the
VI Server feature. You can copy this code to your new LabVIEW
applications.
Compatibility VIs for ActiveX Functions
The ActiveX functionality has expanded. The functions are more generic
because LabVIEW now can act as an ActiveX server as well as a client.
Compatibility VIs are provided for the ActiveX functions that exist in
©
LabVIEW 5.1 Addendum 1-16
National Instruments Corporation
x
previous versions. For more information about the new ActiveX
functionality, refer to the Improvements to ActiveX Automation section
in Chapter 2, New Features in LabVIEW 5.1.
Additional Resources
The LabVIEW documentation set, including the Code Interface Reference
Manual and the VXI VI Reference Manual, is available in Portable
Document Format (PDF) on the LabVIEW CD in the
directory. You can copy this directory or selected PDF files to the
LabVIEW\manuals directory on your hard drive. You must have Adobe
Acrobat Reader 3.0 or later installed to view these files.
Chapter 1 Required Configuration, Installation, and Upgrade Information
manuals
(Windows and Macintosh)
LabVIEW Data Acquisition Basics Manual, which contains important
information about using the DAQ VIs and examples you can find in
LabVIEW. For reference information about a particular DAQ VI, refer to
the LabVIEW Function and VI Refer ence Manual and the LabVIEW Online
Reference, which you can access by selecting Help»Online Reference….
Chapter 2, New Features in LabVIEW 5.1, also contains information about
new features and VIs.
The DAQ examples folder contains a VI library named
has a Getting Started example VI for analog input, analog output,
digital I/O, and counters. The
starting place for data acquisition.
Upgrading to LabVIEW 5.1
If you are upgrading from a version prior to 5.0, you can find upgrade
information on your LabVIEW CD and also on our web site. The
LabVIEW 5.0 Upgrade Notes are available as an Adobe Acrobat file
called
Upgrade.pdf in the LabVIEW\manuals directory. To find this
information on our web site
Product Manuals Library for the LabVIEW listings, where you will find
the LabVIEW 5.0 Upgrade Notes.
If you need to perform data acquisition, read the
RUN_ME.LLB that
RUN_ME.LLB examples give you an excellent
www.natinst.com/support/, search the
For more information about features, refer to the LabVIEW User Manual
and the G Programming Reference Manual. LabVIEW also offers
extensive online documentation, which you can access by choosing
Help»Online Reference....
©
National Instruments Corporation 1-17 LabVIEW 5.1 Addendum
Chapter 1 Required Configuration, Installation, and Upgrade Information
Converting VIs
Upgrading LabVIEW is an automated process. When you open a VI
created in a previous version, LabVIEW automatically converts and
compiles the VI.
Conversion is a memory-intensive operation. When LabVIEW loads a VI
saved in an earlier version, it loads all components of the converted VI
(front panel, block diagram, and data) into memory, then compiles the VI
in memory. In addition, LabVIEW loads into memory the components of
all subVIs needing conversion.
You can estimate the amount of memory required to convert VIs by
totalling the amount of memory your VIs and all of their subVIs occupy
on disk. If these VIs are in VI libraries, add approximately 30 percent of
the VI library size because the VIs are compressed. The conversion process
might require at least that much memory and an additional 3 MB of
memory to run LabVIEW.
If your computer does not have enough memory to convert your VIs all at
once, convert the VIs in stages, by components. Examine your hierarchy
of VIs and begin by loading and saving subVIs in the lower levels of the
hierarchy. You then can progress gradually to the higher levels of the
hierarchy . You also can choose File»Mass Compile to convert a directory
of VIs. Notice, however, that this option converts VIs in a directory or VI
library in alphabetical order. If a high-level VI is encountered first, Mass
Compile requires approximately the same amount of memory as if you
opened the high-level VI first.
You can monitor your memory usage with the Help»About LabVIEW...
option, which summarizes the amount of memory you have used.
(Macintosh)
Before converting VIs, increase the memory allocated to
LabVIEW from the Finder by selecting the LabVIEW icon, then choosing
Windows»Show VI Info... from the menu.
Upgrading Application Libraries and Toolkits
Most existing toolkits function with LabVIEW 5.1 without problems.
However, you need to move the VIs so they appear in the menus.
LabVIEW 5.1 is compatible with toolkits designed for 3.0, with the
following exceptions.
LabVIEW 5.1 Addendum 1-18
©
National Instruments Corporation
Chapter 1 Required Configuration, Installation, and Upgrade Information
You must upgrade the following add-ons for compatibility with
LabVIEW 5.1:
• LabVIEW Application Builder—You must upgrade to LabVIEW
Application Builder 5.1. This upgrade is free to existing users of the
LabVIEW Application Builder. If you have the Professional
Development System, the new version of the application builder
libraries is included in the installation.
• Professional G Developers Toolkit—If you have the Professional G
Developers Toolkit, you must upgrade to version 5.1. This upgrade is
free to existing users of the Professional G Developers Toolkit. If you
have the Professional Development System, the new version of the
Professional G Developers Toolkit is included in the installation.
• LabVIEW T e st Executive —If yo u use LabVIEW Test Executive 5.0
or earlier, you must upgrade to LabVIEW Test Executive 5.1. This
upgrade is free to existing users of LabVIEW Test Executive 5.0.
With minor exceptions, you can use the previous version of the following
toolkit with LabVIEW 5.0:
• Internet Developers Toolkit for G—You can use the Internet
Developers Toolkit 4.1 with LabVIEW 5.0, but you mus t delete
printvi.llb, located in the user.lib\internet\image
directory. Alternatively, upgrade to version 5.0 of this toolkit, which
includes this fix and is free to existing users.
The following toolkits do not install VIs in a location that causes them to
appear in the palettes. These toolkits are being updated to version 5.0.
You can use the existing toolkits by moving VIs to
user.lib. Alternatively, you can choose Edit»Edit Control and
vi.lib\addons or
Function Palettes and add them to the palette of your choice.
• Statistical Process Control Toolkit 1.0
• Proportional-Integral-Derivative (PID) Control Toolkit 1.0—
upgrading to version 5.0 of this toolkit is recommended
If you are using the LabVIEW Professional Development System or the
Full Development System, you already have two other toolkits—G Math
and Picture Control. LabVIEW Base Package users can get these toolkits
by upgrading to either of the higher-level LabVIEW de velopment systems.
©
National Instruments Corporation 1-19 LabVIEW 5.1 Addendum
New Features in LabVIEW 5.1
This chapter describes the features added and the significant changes made
between versions 5.0 and 5.1. To help you learn more about LabVIEW,
version 5.1 offers extensive online documentation, which you can access
by choosing Help»Online Reference....
Dialog Box, Menu, and Window Enhancements
This section describes changes to LabVIEW dialog boxes, menu items,
and behavior or appearance of front panel objects and windows.
Scaling Front Panel Objects
With LabVIEW 5.1, you can designate one particular front panel object
or all objects on an entire front panel to scale automatically when the front
panel window resizes. If you set a front panel object to scale with the
window, the object resizes itself automatically in proportion to any
changes in the front panel window size. Also, the other objects reposition
themselves to remain consistent with their previous placement on the
front panel.
2
Note
©
National Instruments Corporation 2-1 LabVIEW 5.1 Addendum
You cannot designate more than one particular object on a front panel to resize
automatically. You can designate either one particular object on the front panel,
or all objects on the front panel.
You can set any front panel object to scale automatically when the front
panel window is resized. The following list describes important
information you should know about scaling objects on the front panel:
• LabVIEW scales objects automatically in the same way you resize the
object manually. For example, because you can resize numeric boxes
horizontally only, they can scale horizontally only—never vertically.
• When a front panel object is resized, the font size never changes. Thus
when an object scales automatically, the font size remains the same.
• You cannot set multiple objects to scale on the front panel unless you
set all of them to scale. Y ou can either set one object on the front panel
to scale automatically, or set all objects to scale automatically.
Chapter 2 New Features in LabVIEW 5.1
• Once an object scales itself automatically, it might not scale back to
its exact original size, when you size the window back to its original
position. However, you can use the Undo command to restore the
original size.
• When scaling arrays, you can set scaling either on the array itself, or
on the objects within the array.
– When you set scaling on the array, you adjust the number of rows
– When you set scaling on the objects within the array, you always
Immediately after you designate an object to scale automatically, several
regions on the front panel appear outlined by dotted lines. When you resize
a window, objects selected to scale automatically reposition themselves in
a manner that is consistent with their previous placement within these
regions. To see these regions—to show the dotted lines on the front
panel—you must meet the following two conditions:
• You have selected one particular object on the front panel to scale
automatically.
• You are operating in Edit mode.
and columns you can see within the array.
see the same number of rows and columns—though different
sizes—within the array.
Setting an Object to Scale
You can designate any front panel object to scale automatically to match
changes in the front panel window.
1. Select the front panel object you want to scale.
2. Choose Edit»Scale Object W ith Window . This option appears with a
checkmark beside it when it has been selected.
Note
LabVIEW 5.1 Addendum 2-2
If you want to set automatic scaling for all objects on the front panel through the
VI Setup dialog, and you have already set a single object on the front panel to
scale, you must first deselect automatic scaling for the particular object. T o do this,
select the front panel object and then choose Edit»Scale Object With Window.
The checkmark disappears when you deselect this option.
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
Setting All Objects on a Front Panel to Scale
You can designate an entire front panel so that all of its objects scale
automatically to match changes to the front panel window.
1. From the front panel of the VI, select VI Setup.
2. Under Window Options, select Scale All Objects on Panel. With
this option selected, resizing the front panel auto matically causes all
objects on the front panel to resize and reposition themselves
accordingly .
Note
After you set Scale All Objects on Panel, you cannot set or unset scaling on an
individual object on the front panel. A dialog box appears that prompts you to
choose between setting automatic scaling for either one particular object or all
objects on the front panel.
Defining a Minimum Window Size
You can specify a minimum window size for front panels by following a
simple procedure.
1. From the front panel of the VI, select VI Setup.
2. Under Window Options, go to the Minimum Window Size options.
3. Enter the minimum Width and Height, in pixels, that you want to
define for the window.
Maintaining Window Proportions with Monitor Resolution
LabVIEW can maintain its front panel window proportions relative to the
resolution of your monitor. When you choose this setting for a VI, the
percentage of the screen used by that VI’s front panel window stays the
same no matter what the end user’s screen resolution. Complete the
following instructions to activate this option.
1. From the front panel of the VI, select VI Setup.
2. Under Window Options, select Maintain Window Proportions with
Monitor Resolution.
Notice that choosing this option only maintains window proportions. To
have the objects maintain proportions, you must also choose Scale All
Objects on Panel. Alternatively, you could choose a single object to scale
when the window changes size.
©
National Instruments Corporation 2-3 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
Saving for a Previous Version
With LabVIEW 5.1, you can save your VIs for the previous version of
LabVIEW (LabVIEW 5.0). This makes upgrading LabVIEW very
convenient, and helps you to maintain your VIs in multiple versions of
LabVIEW when necessary. You can upgrade to new versions and always
have the capability to go back to your previous version, should you ever
need to.
When you choose to save a VI for the previous version, LabVIEW attempts
to convert not just that VI, b ut all the VIs in its hierarchy , excluding
files. Complete the following steps to sa ve a hierarchy of VIs for a pre vious
version of LabVIEW.
1. For the top VI in your hierarchy of VIs, choose File»Save with
Options. The Save with Options dialog box appears.
2. Select the Save for LabVIEW 5.0.x option to save your VIs for the
previous version.
3. Click Save. Immediately after you save, the Choose a Directory
dialog box appears.
4. Choose the directory where you want to save the VIs.
5. Click Save.
vi.lib
Often a VI uses functionality that is not available in the previous version.
In such cases, LabVIEW saves as much as it can and produces a report of
what could not be converted. The report appears immediately in the Save
for LabVIEW 5.0.x Warnings dialog box. Click OK to acknowledge
these warnings and close the dialog box. Click Save... to save them to a text
file that you can review later.
Accessing Recently Opened Files
LabVIEW 5.1 gives you easy access to recently opened files. To find a file
that was open previously, instead of searching through various directories,
you can use the Recently Opened Files list. This list includes the following
file types:
•VI (
• control (
• VI template (
• control template (
LabVIEW 5.1 Addendum 2-4
*.vi)
*.ctl)
*.vit)
*.ctt)
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
When you choose File»Recently Opened Files, a submenu appears that
contains the list of recently opened files. Select the file name to open it. The
files are listed in chronological order, with the most recently opened file
listed first. If the list is empty, the Recently Opened Files option is
dimmed. The Recently Opened Files list displays up to 10 file names.
Note When two or more files have the same file name but reside in different directories,
the Recently Opened Files list displays the full path.
Searching in LabVIEW
LabVIEW 5.1 includes new options designed to help you find VIs, subVIs,
and text references more easily.
For more information on the Find dialog box in LabVIEW, refer to the
Find Dialog Box topic in the LabVIEW Online Reference, or refer to the
Finding VIs, Objects, and Text section in Chapter 3, Using SubVIs, of the
G Programming Reference Manual.
Find Dialog Box
The Find dialog box now includes the Include SubVIs option in the
Search Scope section. The Include SubVIs option lets you search for an
object or text within the subVIs of the VI you currently have open. By
default, this option is not enabled.
Also, the Search in Hierarchy W indow and Search VIs in vi.lib options
are now labeled Include Hierarchy Window and Include VIs in vi.lib,
respectively, in LabVIEW 5.1. The functionality of th ese two options has
not changed.
To bring up the Find dialog box, select Project»Find..., or press <Ctrl-f>
(Windows); <command-f> (Macintosh); <meta-f> (Sun); or <Alt-f> (HP-UX
and Linux).
Find All Instances and Search Results Dialog Box
To make it easier to search for all instances of a VI, LabVIEW now
includes the Find All Instances pop-up option. Y ou can right-click a subVI
or type definition (constant, control, or indicator) to find all instances of
that object. Also, you can right-click a connector pane or hierarchy window
object to find all instances of that object.
©
National Instruments Corporation 2-5 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
T o f ind all instances of an object, right-click the object for which you want
to find references:
• If you are searching for a reference to a type definition, select
Find»All Instances. (For more information about type definitions,
refer to the Type Definitions section in Chapter 24, Custom Controls
and Type Definitions, of the G Programming Reference Manual.)
• If you are searching for a reference to a subVI, right-click the VI icon
in the block diagram, hierarchy window , or connector pane, and select
Find All Instances.
If LabVIEW finds one or more references to the object, the Search Results
dialog box appears (otherwise the object is highlighted).
For more information on the Find dialog box in LabVIEW, refer to the
Find Dialog Box topic in the LabVIEW Online Reference, or refer to the
Finding VIs, Objects, and Text section in Chapter 3, Using SubVIs, of the
G Programming Reference Manual.
Macintosh Navigation Services in LabVIEW
LabVIEW 5.1 takes advantage of the Macintosh Navigation Services and
the Macintosh Appearance Manager to give you a more consistent
Macintosh user interface under MacOS 8.5.
Navigation Services comes standard with MacOS 8.5. With Navigation
Services in LabVIEW 5.1, you can save your VIs and create new directories
more easily.
Use Navigation Services with LabVIEW the same way you would with
any other Macintosh application. However, LabVIEW 5.1 includes the
following customizations to the Navigation Services dialog boxes:
• The Save dialog box includes the Use LLBs button, which lets you
switch to LabVIEW’s File Dialog dialog box for saving into libraries
(
.llb files).
• The A ppend File dialog box always includes the New... b utton, which
lets you create a new folder or file. (Standard Navigation Services
behavior displays a New Folder button in cases in which you can
create new folders only.)
By taking advantage of the Macintosh Appearance Manager under
MacOS 8.5, LabVIEW’s dialog controls take on the native look and feel
of the Macintosh.
LabVIEW 5.1 Addendum 2-6
©
National Instruments Corporation
New VIs, Functions, and Controls
This section describes the new functionality in LabVIEW 5.1 for advanced
mathematics, picture control, report generation, and image management.
Changes to Controls and Indicators
LabVIEW 5.1 has improved the appearance of controls and indicators.
Some controls in LabVIEW 5.1 look slightly different than in previous
versions when you drop them on the front panel. However, controls on
existing VIs you created in previous versions of LabVIEW are not updated.
You will notice improvements including the addition of color to many
controls, but each of these controls works the same way. The following two
sections—Labels and Dialog Controls—describe the changes to control
and indicator labels and the new dialog controls in more detail.
Labels
By default, when you create a new control or indicator, its name label
includes the name of the type of control or indicator (such as Slide or
String) and, if necessary, a number distinguishing it from other controls
and/or indicators of the same kind. For example, if you place a slide control
on the front panel, it is labeled Slide. If you place another slide control on
the front panel, it is labeled Slide2.
Chapter 2 New Features in LabVIEW 5.1
When you replace a control or indicator that has a default label (as
described above) with an object of a different type, the control or indicator
is renamed as well. For example, if you replace a slide control labeled
Slide2 with a knob control, the knob appears with the label Knob. If a slide
or control already exists on the front panel with the label Knob, the new
knob takes the label Knob2 instead.
By default, when you drop an object on the front panel, its name label is
highlighted to let you immediately type in a replacement for the default
name. Unlike in previous versions of LabVIEW, if you want to hide a name
label right after you place it on the front panel, right-click the control or
indicator and deselect Label from the Show menu.
By default, name labels appear transparent. To make a name label appear
ina raised box, select Edit»Preferences, select Front Panel from the
drop-down menu, and deselect Use transparent name labels.
©
National Instruments Corporation 2-7 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
Dialog Controls
All the dialog controls are now grouped together in a new Dialog palette,
shown in Figure 2-1 below. You can reach this palette from the front panel
by selecting Controls»Dialog.
This palette includes the dialog controls listed below. You can still find
these controls in the same palettes as in previous versions of LabVIEW.
• Dialog Numeric Control
• Dialog String Control
• Dialog Ring
• Dialog Button
• Cancel Button
• Dialog Checkbox
• Dialog Radio Button
Also, this palette includes two new controls: the Dialog Listbox control and
the Dialo g Recessed Frame control. The Dialog Listbox control behaves
like other listboxes, but matches the tabbed highlighting and bordering
functionality and appearance of the native system controls on your
LabVIEW 5.1 Addendum 2-8
Figure 2-1.
Dialog Palette
©
National Instruments Corporation
platform. The Dialog Recessed Frame control behaves like other
decoration objects found in the Decorations palette. You can use it as a
grouping border to put around other dialog controls.
3D Graph Controls for Windows
LabVIEW 5.1 adds a new way to represent data on your front panel:
the 3D graph. The LabVIEW 3D graph uses ActiveX technology and new
VIs that handle three-dimensional representation. You can set parameters
for the 3D graphs VIs to change behavior at runtime, including setting
basic, axes, grid, and projection properties.
For more detailed information about the 3D graphs VIs see the 3D Graphs
VIs topic in the LabVIEW Online Reference.
You can find examples of the 3D graphs VIs in the
Examples\General\graphs\3dgraph.llb directory.
Chapter 2 New Features in LabVIEW 5.1
Note
The 3D Graph controls are available for Windows only in the LabVIEW Full
Development System and Professional Development System.
Enhancements to Property and Invoke Nodes
With LabVIEW 5.1, VI Server and Application Class property and invoke
nodes do not always need a wired refnum input or output. This makes it
easier to program many common VI Server functions because you can drop
fewer diagram objects.
If you do not wire inputs or outputs, LabVIEW uses default values. The
default input value for the Application Class is your local LabVIEW. The
default value for the Virtual Instrument Class is your current VI—the VI
in which you have placed the property or invoke node.
Improvements to VI Server Properties in Reserved VIs and
Runtime Systems
In LabVIEW 5.1, the VI Server has been enhanced so you can set many
more properties while a VI is running or in run-time versions. These
properties are listed below. Also, the LabVIEW Help Window now
includes thorough explanations for each Virtual Instrument Class property
and any limitations they might have. Choose Help»Show Help to open the
Help Window. You can move your cursor over the property portion of any
Virtual Instrument Class property node, and documentation for that
property appears in the Help Window.
©
National Instruments Corporation 2-9 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
With LabVIEW 5.1, in addition to the VIs that previously worked at
runtime, you can set any of the following properties on running VIs and in
run-time versions:
• AutoLogging»Log File Path
• AutoLogging»Log at Finish
• AutoLogging»Print at Finish
• Edit Mode on Open
• Execution»Close after Call
• Execution»Show Front Panel on Call
• Front Panel Window»Allow Runtime Popup
• Front Panel Windo w»AutoCenter
• Front Panel Window»Closeable
• Front Panel Windo w»Highlight Return Button
• Front Panel Window»Is Dialog
• Front Panel Window»Resizeable
• Front Panel Window»Show Menu Bar
• Front Panel Window»Show Scroll Bars
• Front Panel Window»Size to Screen
• Front Panel Window»Title Bar Visible
• Help»Document Path
• Help»Document Tag
• Tool Bar»Show Abort Button
• Tool Bar»Show Free Run Button
• Tool Bar»Show Run Button
• Tool Bar»Visible
• VI Description
You also can set any of the following properties on running VIs in
LabVIEW 5.1 (but not in run-time versions):
• Execution»Show Front Panel on Load
• Execution»Run When Opened
• Execution»Suspend on Call
• History»Always Add Comments at Save
• History»Prompt for Comments at Close
LabVIEW 5.1 Addendum 2-10
©
National Instruments Corporation
Ring Enhancements
Chapter 2 New Features in LabVIEW 5.1
• History»Prompt for Comments at Save
• History»Record Application Comments
• History»Use Defaults
All ring and enum constants include a down arrow, which distinguishes
them from numeric constants. Also, rings and enums on panels or block
diagrams have scroll bars when the menus include many items.
LabVIEW 5.1 menus, like listboxes, now support type completion. Just
type the first few characters and LabVIEW finds a matching item in the list.
Use the <Tab> and <Shift-Tab> keys to move to the next and previous
matching item, respectively.
Figure 2-2 shows an example of a ring constant with many items in
its menu.
Figure 2-2.
©
National Instruments Corporation 2-11 LabVIEW 5.1 Addendum
Ring Constant Examples
Chapter 2 New Features in LabVIEW 5.1
IVI Instrument Drivers and ActiveX
Some parameters for ActiveX and IVI take a discrete list of valid values.
Previously, when building ActiveX and IVI applications, you used numeric
values to set parameters for properties and methods that control devices or
programs. You had to enter a particular numeric value in a numeric control
or constant, which required you to know which numeric values
corresponded to which settings.
With LabVIEW 5.1, you are not required to know these values. You can
choose from a descriptive name in a ring to set parameter values. The
selections available in the ring depend on the refnum passed to the node.
See Figure 2-3 and Figure 2-4 below for examples of using these numeric
and ring constants.
Figure 2-3.
Figure 2-4.
Setting a Data Value with a Numeric Constant
Setting a Data Value with a Ring Constant
In both examples, the Microsoft Excel application is accessed and a method
is invoked. The Index parameter has several options: MicrosoftAccess,
MicrosoftFoxPro, MicrosoftMail, MicrosoftPowerPoint, MicrosoftProject,
MicrosoftSchedulePlus, and MicrosoftWord.
Previously you were required to know that the Index parameter
corresponding to the MicrosoftAccess option is the data value 4. Now you
can select the Microsoft Access option from the drop-down menu in the ring
constant.
LabVIEW 5.1 Addendum 2-12
©
National Instruments Corporation
To access the ring constant when building an ActiveX or IVI application,
right-click the parameter that accepts data values and select Create
Constant. To see the corresponding numeric data value, right-click the
ring constant and select Show»Digital Display.
ActiveX Enhancements for Windows
This section describes the ActiveX enhancements in LabVIEW 5.1.
Ring Enhancements
With LabVIEW 5.1, you do not have to use numeric values when setting
parameters for properties and methods that control devices or programs.
You can use a ring constant as well. See the previous section, IVI
Instrument Drivers and ActiveX, for more information.
Support for ActiveX Events
LabVIEW 5.1 lets you access events associated with ActiveX objects.
Now, in addition to accessing the properties and methods associated with
an ActiveX object when building an Acti veX server VI, you also can access
the events. You can embed a control on a VI front panel, then ex ecute code
based on an event that occurs. For example, you can place a tree view
control that list the contents of a directory. Using events, you can specify
that when the user double-clicks on a particular file, the contents of that file
open.
Chapter 2 New Features in LabVIEW 5.1
You build VIs that accept events using the Activ eX Event functions, which
you find in the Functions»Communications»ActiveX»ActiveX Events
palette.
Working with ActiveX Events
This is the basic procedure for creating a VI designed to create and wait on
an ActiveX event queue, then destroy the event queue. An event queue is a
tag that corresponds to an internal list of events a control receives.
Note
©
National Instruments Corporation 2-13 LabVIEW 5.1 Addendum
If you generated an Automation Refnum using an Automation Client function,
omit Step 1.
1. On the front panel, select the Container control found on the
Control»ActiveX palette.
2. Create an ActiveX event queue using the Create ActiveX Event
Queue VI (described below).
Chapter 2 New Features in LabVIEW 5.1
3. Wire the Automation refnum from the container terminal or an
Automation function to the Create ActiveX Event Queue VI.
4. Place the Wait On ActiveX Event VI on the block diagram.
5. Wire the event queue to the Wait On ActiveX Event VI.
6. Dispose of the event queue using the Destroy ActiveX Event
Queue VI.
ActiveX Event Functions for Windows
You can use the other ActiveX Server Event functions to pass an event
queue from one task to another separate task. Figure 2-5 shows the ActiveX
event functions palette, which you access from the block diagram through
Functions»Communications»ActiveX»ActiveX Events.
Figure 2-5.
For more detailed information about the ActiveX event functions see the
ActiveX Event Functions topic in the LabVIEW Online Reference.
Improvements to ActiveX Automation
The Automation Open function now includes the optional machine name
string input. Use machine name to specify on which computer you want to
open an Automation Server object. If you do not specify a machine name,
LabVIEW creates the object on the local machine. See the Open
Automation Refnum description in Chapter 51, ActiveX Automation
Functions, in the LabVIEW Function and VI Reference Manual.
Also, LabVIEW 5.1 supports enumerations in the ActiveX Invoke and
Property Nodes. When you right-click an Invoke Node or Property Node’s
terminal that is part of an enumeration or is a constant, you create a ring
with the available enumeration values. See Ring Enhancements, earlier in
this chapter, for more information.
LabVIEW 5.1 Addendum 2-14
ActiveX Events Palette
©
National Instruments Corporation
HiQ and MATLAB Functionality for Windows
HiQ and MATLAB are software packages that help you organize and
visualize real-world math, science, and engineering problems. You can
use HiQ and MATLAB to express numeric formulas elegantly. Now with
LabVIEW you can load and edit HiQ and MATLAB scripts into your block
diagram code so LabVIEW works with their advanced mathematics
functionality.
Chapter 2 New Features in LabVIEW 5.1
Note
Note
You must have HiQ 4.1 or MATLAB 5.0 or later installed to use this new feature
successfully. You can install HiQ 4.1 from the LabVIEW CD-ROM. HiQ and
MATLAB functionality is available for Windows only in the LabVIEW Full
Development System and Professional Development System.
There is a new script node that works similarly to the formula node.
You can find a HiQ script node and a MATLAB script node in the
Functions»Mathematics»Formula palette. You can place a script node
on your block diagram and enter a script according to the syntax of HiQ or
MA TLAB. LabVIEW then communicates with that script server engine for
you. When you create inputs and outputs on the script node, those values
are passed between HiQ or MA TLAB and LabVIEW. If you already have a
script written, you can import it from HiQ or MATLAB. See the section
Importing or Exporting a Script for more information.
Although the basic functionality of the script node is similar to that of the
formula node, the script node can handle more datatypes than the formula
node. This script node supports the same HiQ or MATLAB datatypes as
supported by ActiveX.
Because of the nature of the HiQ and MATLAB script languages, you must choose
which LabVIEW datatype each terminal should be. For more information, see the
section Configuring the Datatype of a Terminal, later in this chapter.
The following two sections, Creating a HiQ Script and Creating a
MATLAB Script, contain procedures for creating a script that does the
following:
1. Generates a matrix of random values
2. Plots that information to a graph
3. Displays the graph in either product
4. Presents the generated random values on your front panel in LabVIEW
©
National Instruments Corporation 2-15 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
Creating a HiQ Script
Complete the following instructions to create and run a VI that uses a HiQ
script.
1. From the block diagram, choose Functions»Mathematics»
Formula»HiQ-Script. Place the node on the block diagram, and size
it according to the amount of script you want to include in the window.
The HiQ script node appears as shown below.
2. With the operating tool, enter the script in the HiQ script node.
For example, the following simple HiQ script creates a matrix of
random values, plots that information to a graph, and displays the
matrix in HiQ.
a = random({50, 50});
g = createGraph(a);
createView(g, true);
You can use a HiQ script window to edit, compile, and run your script
directly from HiQ to ensure that your script behaves properly.
3. Right-click the HiQ script node and select Edit In Server. This action
launches HiQ, and a script window appears containing your HiQ
script.
4. Within HiQ, right-click and choose compile from the pop-up menu.
A message window appears telling you of any compile time errors.
You do not have to compile the script explicitly; HiQ compiles the
script automatically when you run it.
5. Right-click and choose Run from the pop-up menu. A message
window informs you of any runtime errors.
To access HiQ context-sensitive online help, place the cursor inside any
function and press <F1>. You can use this information to help you build
your script.
6. Close the HiQ window to update and return to the HiQ script node on
the LabVIEW block diagram.
LabVIEW 5.1 Addendum 2-16
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
7. T o add inputs and outputs for variables, right-click the right side of the
node frame and select Add Input or Add Output. Type in
a to add an
output for the a variable that is included in your HiQ script. By default,
your node already includes one input and one output terminal for the
error in and error out parameters.
8. Verify the datatype of the inputs and/or outputs. The error-checking
input and output are already the correct datatype. In HiQ, the default
datatype for any new input or output is Real. Right-click the a output
and select Choose Type. From the submenu that appears, select an
available datatype: Integer, Real, Complex, Text, Integer Vector, Real
Vector, Complex Vector, Integer Matrix, Real Matrix, and Complex
Matrix. For the a output, choose Real Matrix.
9. Create controls and indicators for each input and output. Right-click
the a output terminal and select Create Indicator. Right-click the
error out output terminal and select Create Indicator . Indicators for
a and error out appear on the front panel, and terminals appear wired
to these outputs on the block diagram.
10. Go to the front panel. Resize your a indicator so you can see the
generated numbers when you run the VI.
11. Run the VI. LabVIEW launches HiQ and a new HiQ windo w appears,
labeled G in Notebook1, that displays the matrix. The values that make
up this matrix are displayed in the a indicator of your front panel in
LabVIEW.
The second parameter in the CreateView function specifies whether to
pause execution of the HiQ script while the view is visible. The HiQ script
in Step 2 does not finish until you click the Continue button in the HiQ
window to dismiss the view.
12. Change the
true parameter to false and re-run the VI to see the
difference.
©
National Instruments Corporation 2-17 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
Creating a MATLAB Script
Complete the following instructions to create and run a VI that uses a
MATLAB script.
1. From the block diagram, choose Functions»Mathematics»
Formula»MA TLAB Script. Place the node on the block diagram, and
size it according to the amount of script you want to include in the
window. The MATLAB script node appears as shown below.
2. With the operating tool, enter the script in the MATLAB script node.
For example, the follo wing simple MATLAB script creates a matrix of
random values, plots that information to a graph, and displays the
matrix in MATLAB.
a=rand(50)
surf(a)
3. T o add inputs and outputs for variables, right-click the right side of the
node frame and select Add Input or Add Output. Type in
output for the a variable that is included in your MATLAB script. By
default your node already includes one input and one output terminal
for the error in and error out parameters.
4. Verify the datatype of the inputs and/or outputs. The error-checking
input and output are already the correct datatype. In MATLAB, the
default datatype for any new input or output is Real. Right-click the a
output and select Choose T ype. From the submenu that appears, select
an available datatype: Real, Complex, Real Vector, Complex Vector,
Real Matrix, or Complex Matrix. For the a output, choose Real
Matrix.
5. Create controls and indicators for each input and output. Right-click
the a output terminal and select Create Indicator. Right-click the
error out output terminal and select Create Indicator . Indicators for
a and error out appear on the front panel and terminals appear wired
to these outputs on the block diagram.
6. Go to the front panel. Resize your a indicator so you can see the
generated numbers when you run the VI.
a to add an
LabVIEW 5.1 Addendum 2-18
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
7. Run the VI. LabVIEW launches MATLAB and a new MATLAB
window appears, labeled Figure No. 1, that displays the matrix. The
values that make up this matrix are displayed in the a indicator of your
front panel in LabVIEW.
Importing or Exporting a Script
Complete the following steps to import a script into a script node in
LabVIEW.
1. Right-click the HiQ or MATLAB script node.
2. Select Import….
3. Choose the file you want to import and click Open. The script text
appears in your node.
Complete the following steps to export a script to LabVIEW from
MATLAB or HiQ.
1. Right-click the HiQ or MATLAB script node.
2. Select Export…. The Save Script as dialog box appears.
3. Enter the name you want to save your f ile as or choose the file you want
to overwrite.
4. Click Save.
Note
HiQ and MATLAB script files are actually text files. Text files usually have the
extension
have a
.txt. However, HiQ files have a .hqs extension and MATLAB files
.m extension.
Choosing a Script Server
Complete the following steps to change the server behind your script node.
1. Right-click the HiQ or MATLAB script node.
2. Select Choose Script Server»HiQ-Script or Choose Script
Server»MATLAB Script depending on whether you want HiQ or
MATLAB.
Some datatypes in HiQ are not recognized by MATLAB and vice versa. If
you change the script server from one of these mathematics products to the
other after you have assigned datatypes, these datatypes do not change
automatically. The VI will be brok en. When you click the brok en arrow in
the toolbar of your VI, the Error List window reports these incorrect
datatypes.
©
National Instruments Corporation 2-19 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
Scrolling through a HiQ or MATLAB Script
Just as with a regular formula node, you can display a scrollbar within your
script node by right-clicking the node and selecting Show»Scrollbar.
A scrollbar appears on the right side of your script node.
Configuring the Datatype of a Terminal
Both HiQ and MATLAB are loosely typed script languages and do not
determine the datatype of a variable until after the script executes.
Therefore LabVIEW cannot determine a variable’s type in Edit mode.
However, LabVIEW does query the script server to find out possible
datatypes, and lets you choose which LabVIEW datatype each terminal
should be.
Note
Note
If you do not correctly configure a variable’s datatype, LabVIEW will produce
either an error or incorrect information at runtime.
Complete the following steps to change the datatype of an input or output
terminal on a script node.
1. Right-click the terminal of the input or output. A pop-up menu
appears.
2. Select Choose Type. A list of the available datatypes appears,
depending on whether you use HiQ or MATLAB.
3. Choose the preferred datatype.
LabVIEW recognizes all the datatypes that HiQ and MATLAB can use, although
they might be named differently.
T able 2-1 shows LabVIEW datatypes and their corresponding datatypes in
HiQ and MATLAB.
LabVIEW 5.1 Addendum 2-20
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
Table 2-1.
HiQ and MATLAB Datatypes in LabVIEW
LabVIEW Datatype HiQ Datatype MATLAB Datatype
Integer N/A
Real Real
Text N/A
Integer Vector N/A
Real Vector Real Vector
Integer Matrix N/A
Real Matrix Real Matrix
Complex Complex
Complex Vector Complex Vector
Complex Matrix Complex Matrix
Debugging a HiQ or MATLAB Script
Use the following programming techniques to make debugging your script
easier:
• Write your script and run it within the native engine (HiQ or
MATLAB) for testing and debugging purposes before you import it
into LabVIEW. In HiQ, right-click the script node and select Edit In
Server to debug in a native HiQ script window.
• Verify your datatypes. When you create a new input or output, make
sure that the datatype of the terminal is correct. Also, create controls
and indicators for your inputs and outputs so you can monitor what
values are being passed between LabVIEW and the native engine.
For more information about this topic, see the Configuring the
Datatype of a Terminal section.
• Take advantage of the error-checking parameters for debugging
information. Create an indicator for the error out terminal on a script
node before you run any VI so you can view the generated error
information at runtime.
©
National Instruments Corporation 2-21 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
Error Codes
The following table explains error messages you might receive at runtime
when working with a script node.
Table 2-2.
Script Node Runtime Error Messages
Error Code Error Code Message Description
1046
edScriptCantInitServer
LabVIEW failed to initiate a new session
with the server.
1047
edScriptCantSetValue
LabVIEW failed to set the value of a variable
to the server.
1048
edScriptCantGetValue
LabVIEW failed to retrieve the value of a
variable from the server.
1049
1050
edScriptCantSetScript
edScriptExecError
LabVIEW failed to set a script to the server.
LabVIEW encountered an execution
problem. The server returns a string to report
the problem.
Integration of Mathematics and Signal Processing VIs
LabVIEW 5.1 includes more VIs designed to help you solve advanced
mathematics problems. You can use these VIs to manipulate mathematical
formulas on the LabVIEW front panel, and then assemble your
problem-solving program graphically on the LabVIEW block diagram.
Previously, much of this functionality was available only with the G Math
Toolkit, which has been integrated into the LabVIEW Full Development
System.
Note
This functionality is available on all platforms and versions with the exception of
the Windows base version.
Integrating these VIs restructures the LabVIEW Functions palette. The
new Mathematics palettes includes the new Mathematics VIs, as well as
some of the VIs and functions formerly found in the Analysis and
Structures palettes.
The Analysis palette found in LabVIEW 5.0 has been replaced with the
Signal Processing palette. For information on the Signal Processing VIs,
see the Signal Processing Palette section.
LabVIEW 5.1 Addendum 2-22
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
For function and reference information about the Mathematics VIs and
functions, refer to the Mathematics VIs topic in the LabVIEW Online
Reference.
Mathematics Palette
Table 2-3 lists the subpalettes you find in the Functions»Mathematics
palette, and lists the previous location of the VIs or functions in
LabVIEW 5.0.
Table 2-3.
Mathematics VIs Current and Previous Locations
Mathematics Subpalettes Previously Located in...
Formula G Math Toolkit and Structures palette
1D and 2D Evaluation G Math Toolkit
Calculus
G Math Toolkit
Differential Equations subpalette
Probability and Statistics
Analysis palette
Probability subpalette
Analysis of Variance subpalette
Array Operations Analysis palette
Curve Fitting Analysis palette
Linear Algebra
Analysis palette
Advanced Linear Algebra subpalette
Complex Linear Algebra subpalette
Zeros G Math Toolkit, Analysis palette
Optimization G Math Toolkit
Numeric Functions G Math Toolkit
You can find examples of the Mathematics VIs in the
Examples\Math\math.llb directory.
©
National Instruments Corporation 2-23 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
Signal Processing Palette
For function and reference information about the Signal Processing VIs,
refer to the Signal Processing VIs topic in the LabVIEW Online Reference.
Table 2-4 lists the subpalettes you find in the Functions»Signal
Processing palette, and lists the previous location of the VIs or functions in
LabVIEW 5.0.
Table 2-4.
Signal Processing VIs Current and Previous Locations
Signal Processing Subpalettes Previously Located in...
Signal Generation Analysis palette
Time Domain Analysis palette
(These functions were found in the Analysis palette’s Signal
Processing subpalette)
Frequency Domain Analysis palette and G Math Toolkit
(Combines the FFT and Power Spectrum VIs found in the
Analysis palette’s Signal Processing subpalette and the VIs
found in the G Math Toolkit’s Transforms palette.)
Measurement Analysis palette
Filters Analysis palette
Windows Analysis palette
You can find examples of the Signal Processing VIs in the
Examples\Math\sig_proc.llb directory.
Integration of the Picture Control VIs
With LabVIEW 5.1, you can display complex images and graphs using
functionality that previously was included only in the Picture Control
Toolkit. Because the Picture Control Toolkit has been integrated into the
LabVIEW Full Development System, you can use any of the VIs in the
Picture Control VI Library. The Picture Control VIs include drawing
operations you can use to create diagrams and build images dynamically.
You can create new front panel displays such as specialized bar graphs, pie
charts, or Smith charts. You also can display and animate arbitrary objects
such as robot arms, test equipment, or a two-dimensional display of a
real-world process. For detailed information about these VIs, refer to the
Graphics and Sound VIs topic in the LabVIEW Online Reference.
LabVIEW 5.1 Addendum 2-24
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
Note The Picture Control VIs are available on all platforms and versions with the
exception of the Windows base version.
You can find examples of the Picture Control VIs in the
Examples\Picture directory.
Sound VIs for Windows and Macintosh
You can use the Sound VIs to integrate sound into your VIs. Some of the
things you can do are create a beep to alert the user of an error, play a
file, and read and write sound data.
For more information, refer to the Sound VIs topic in the LabVIEW Online
Reference. To access the Sound VIs, select the Functions»Graphics &
Sounds»Sound palette from the block diagram. You can find examples of
the Sound VIs in the
Note The Sound VIs are not available on the UNIX operating systems.
Examples\Sound\sndExample.llb directory.
Generating Reports in LabVIEW for Windows
Note You can use the report generation functions on 32-bit Windows operating systems
only (Windows 95/98/NT). This functionality is based on ActiveX technology,
which is not available on Macintosh and UNIX platforms. On Macintosh and
UNIX platforms, refer to Chapter 5, Printing and Documenting VIs, in the
G Programming Reference Manual .
.wav
(
UNIX) Use the System Exec VI to print a file through a command line
function. The VI is located in Functions»Communication.
(
Macintosh) You can use the AESend Print Document VI to direct your
applications to print a document. The VI is located in
Functions»Communication»Apple Event.
On Windows platforms, you can create reports of any text-based
information a VI generates or the user enters into a string parameter, or
you can create a report from an array of 2D numbers. For example, if
you develop a LabVIEW program that tests functions, you can create a
text-based report of which functions passed and which failed.
©
National Instruments Corporation 2-25 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
To create reports using the Report Generation VIs, go to the
Functions»Report Generation palette. You can use the Report Generation
VIs to do the following:
• Set up a report’s headers and footers (which can include date and time
stamps)
• Set character font, size, style, and color
• Set a report’s margins and tabs
• Determine what information appears on a particular line or page of
areport
• Set a report’s orientation on a page (lengthwise or widthwise)
• Include text from other files in a report
• Clear information from an existing report (to re-use the report’s
formatting in a new report)
• Automatically print a report
• Dispose of a report after it is printed (which saves memory)
Hints for Generating Reports in LabVIEW
Make sure any information you want to print is formatted into a string
(unless you want to print a 2D array of numbers as a table). If you have a
lot of information and you want to write it to a report, you likely will use
one or more of the String functions. See Chapter 6, String Functions, in the
LabVIEW Function and VI Reference Manual, for information on the
String functions and how they format data.
Use the Easy Text Report VI for less-complicated reports. The following
section, Easy Text Report VI Overview, contains more information on
thisVI.
Easy Text Report VI Overview
The Easy Text Report VI creates a basic report from a block of text. This
VI is appropriate if you do not need to have fine-grain control over all
aspects of the report, and if you do not have a lot of varying data or a
numeric table in the report.
With the Easy Text Report VI, you can specify the text font, set up the
header and footer, set margins, specify a printer, and set the page’s
orientation. However, you cannot control where information is placed,
append information from another file, or clear the report of font styles,
headers and footers, or text. The Easy Text Report VI disposes of the
reportautomatically, which frees up memory space.
LabVIEW 5.1 Addendum 2-26
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
See the Easy Text Report VI description in the Report Generation VI
Descriptions section later in this chapter for information on this VI’s
parameters.
Tip See the block diagram of the Easy Text Report VI for a good example of how
you can use the other VIs in the Report Generation palette to create a report.
Report In/Report Out Parameters
The Report in and Report out parameters link the VIs used to create a
report. All of the Report Generation VIs have both these parameters, with
the following exceptions:
• Easy Text Report VI has neither of these parameters.
• Dispose Report VI has only the Report in parameter.
• New Report VI has only the Report out parameter.
Use these parameters to link a report to the VIs that control a report’s
appearance, data, and printing. These parameters give you the flexibility
to add and control several different features on one report.
Tokens
Tokens are strings you can enter that generate information automatically.
You can use tokens to number pages and place a timestamp on the report.
These especially are useful in the headers and footers. There are several
tokens you can enter in any parameter that takes a string. For example, if
you are using the Easy Text Report VI, entering the token
of the footer strings causes a page number to appear in the footer of every
page of the report.
<page> in one
Table 2-5 lists some of the more useful tokens.
Table 2-5. Token Descriptions
Token Description
<page>
<pages>
<pagenofm>
Current page number
Total number of pages
Current page number along with the total number of
pages in the report.
Example: 7 of 30
©
National Instruments Corporation 2-27 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
Table 2-5.
Token Description
<shortdate>
Current date in the form xx/xx/xx.
Example: 10/5/98
The month, date, and year order defaults to the date
settings of your operating system.
<longdate>
Current date in the form Day, Month and Date, Year.
Example: Monday, October 05, 1998
The month, date, and year order defaults to the date
settings of your operating system.
<time>
Current time in the form Hour:Minute:Second
AM/PM.
Example: 1:58:22 PM.
This token defaults to the clock settings on your
computer (that is, whether it uses a 12-hour or 24-hour
clock).
Report Generation VI Descriptions
This section describes the Report Generation VIs, including descriptions
and data types of each parameter. From the block diagram, you can reach
the new Report Generation palette by selecting Functions»Report
Generation.
Token Descriptions (Continued)
LabVIEW 5.1 Addendum 2-28
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
The Report Generation palette has two subpalettes:
• Functions»Report Generation»Report Layout
• Functions»Report Generation»Advanced Reports
You can find examples of the Report Generation VIs in the
Examples\Reports\TextReportExample.llb directory.
Report Generation Parameter Descriptions
This section describes the parameters used by the Report Generation VIs.
append on new line? (F), if the
information onto a new line in the report. The default value is
True value is selected, appends the
False.
center footer text is the information you want to appear in the center
portion of the footer.
center header text is the information you want to appear in the center
portion of the header.
Column Headers determines how each column is labeled in the table.
Column width defines the width of each column in the report’ s table. The
value you enter is in inches or centimeters, depending on the settings you
enter in measurement system or measurement system for columns. The
default value is 1.
error in
error out
file path is the path of the text file from which you want to pull information
into your report. You must include the file’s path in this parameter.
Font Settings allows you to set the font of your report.
Charset sets the character set used in the report (such as the set
for a specific language).
Weight sets the characters’ weight.
Name specifies the font used in the report. You can type in the
name of any font available on your system.
Note
The name you enter must match the font name exactly.
Size specifies the size of the font in number of points.
©
National Instruments Corporation 2-29 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
g
Font Settings indicates what font settings currently are used in a report.
Footers allows you to set up what information appears in the footer of each
page of the report. You can type in text, leave the parameters blank, or type
in a token (see Tokens, earlier in this chapter, for information on the tokens
you can enter).
Charset indicates the character set used in the report (such as the
set for a specific language).
Weight indicates how dark bold characters appear.
Name indicates the font used in the report.
Size indicates the size of the font in number of points.
left is the information you want to appear in the left side of the
footer.
center is the information you want to appear in the center portion
of the footer.
right is the information you want to appear in the right side of the
footer.
determines how the numbers appear in each cell of the table,
format strin
such as
01, 1, 1.0, or 1.00.
It is as defined by Format & Append:
[Str]%[-][0][Width][.Precision]Conversion[Str]
where - causes left justification and 0 pads with zeros.
Conversions: d (decimal), x (hexadecimal), o (octal), f (fractional),
e (scientific), or g (scientific).
For example, if you wanted the numbers to appear in each as 1.00, you
would use the default value: %.2f.
Refer to the Format & Append and Format Strings Overview topic in the
LabVIEW Online Reference for more information on v alues you can enter
in format string.
Headers allows you to set up what information appears in the header of
each page of the report. Y ou can type in te xt, leav e the parameters blank, or
type in a token (see Tokens, earlier in this chapter, for information on the
tokens you can enter).
LabVIEW 5.1 Addendum 2-30
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
left is the information you want to appear in the left side of the
header.
center is the information you want to appear in the center portion
of the header.
right is the information you want to appear in the right side of the
header.
left footer text is the information you want to appear in the left side of the
footer.
left header text is the information you want to appear in the left side of the
header.
Margins set where the information is placed on each page of the report.
You set the margins with the following parameters:
left or LeftMargin sets the report’s left margin in inches or
centimeters.
right or RightMargin sets the report’s right margin in inches or
centimeters.
top or TopMargin sets the report’s top margin in inches or
centimeters.
bottom or BottomMargin sets the report’s bottom margin in
inches or centimeters.
measurement system has three options: US, which sets the margins in
inches; Metric, which sets the margins in centimeters; and Default, which
sets the margins in the measurement system set up on your computer.
measurement system for columns determines whether the value you enter
in column width is in inches or centimeters. There are three options: US,
which sets the columns in inches; Metric, which sets the columns in
centimeters; and Default, which sets the columns in the measurement
system set up on your computer.
Number of Copies (1) specifies how many copies of the report you want
to print. If you do not specify a number, one copy is printed.
Numerical Data is the numerical information included in the table. The
information must be a 2D array.
©
National Instruments Corporation 2-31 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
orientation specifies how the report appears when it is printed. You can
choose from portrait, which prints the report widthwise, or landscape,
which prints the report lengthwise.
Printer Name specifies the name of the printer that you want to print this
report. If you do not enter a printer name, then this VI uses the default
printer set up on your computer. If you do specify a printer name, you must
have that printer configured for use with your computer. If you do not
specify a printer, you must hav e a def ault printer specif ied on your system.
Report in links a report to the VIs used to control a report’s appearance,
data, and printing. This holds the report before the VI generates new data
for the report.
Report out links a report to the VIs used to control a report’s appearance,
data, and printing. This holds the report after the VI generates new data for
the report.
right footer text is the information you want to appear in the right side of
the footer.
right header text is the information you want to appear in the right side of
the header.
Row Headers determines how each row is labeled in the table.
Rows/Page determines ho w many ro ws appear on each printed page of the
report. If set to
0, as many rows as can fit on the page are printed and
column headers are not repeated on each page.
Separate Page? Places the table on a new page of the report.
Text is the information you want to include in the report. Any information
you want to include must be in a string.
Text Color (unchanged) lets you select the color of the text in the report.
You can use the color box constant with this parameter (which you access
from the Functions»Numeric»Additional Numeric Constants palette).
Text Color indicates the color currently used for the text in the report.
T ext Data is the information you want to be printed in tab ular form. If you
are using a table control, pass the table’s value to this parameter.
LabVIEW 5.1 Addendum 2-32
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
Text Options specifies how the text appears in the report.
Italic determines whether subsequent text appears in italics in the
report.
Strike Through determines whether subsequent text appears with
strikethroughs in the report.
Underline determines whether subsequent text appears
underlined in the report.
Bold determines whether subsequent text appears bold in the
report.
Text Options indicates what text options currently are set in a report.
Italic indicates whether Italics currently are used in the report.
Strike Through indicates whether strikethroughs currently are
used in the report.
Underline indicates whether underlines currently are used in the
report.
Bold indicates whether bold currently is used in the report.
ext to be Printed is the information you want to include in the report. Any
T
information you want to include must be in a string.
width sets the report’s tabs width in inches or centimeters. If you do not
enter a tab length, the default value .25 is used.
Easy Text Report
Allows you to pass in a block of text (such as a log) along with optional formatting
information, then print the report to a designated printer. (If you do not specify a printer,
the default printer is used.)
Note
©
National Instruments Corporation 2-33 LabVIEW 5.1 Addendum
You cannot use this VI with any other NI Report VIs. Also notice that this VI does
not give you fine-grain control over formatting your report. For more complicated
reports (such as those with lots of different kinds of inf ormation), use the other VIs
found in the Report Generation palette.
Chapter 2 New Features in LabVIEW 5.1
You might find using tokens with this VI helpful, particularly in the Headers and Footers
parameters. For example you might want to giv e the report a time stamp. See the Tokens topic,
earlier in this chapter, for more information on some common tokens for this VI.
Append File to Report
Appends the text from a text file (.txt) into the current repor t. You must wire the file path
(including its path) to the VI. The text is appended within the report.
Append Report Text
Appends text to the selected report. The input into Text must be a string. The selected report
is the one passed into Report In. You can append the text to the current position of the cursor
in the report or on a new line.
LabVIEW 5.1 Addendum 2-34
©
National Instruments Corporation
Append Numeric Table to Report
Takes a 2D array of numbers and appends it to a report as a table with the given column
widths.
Append Text Table to Report
T akes a 2D array of strings and appends it to a report as a table with the giv en column widths.
Chapter 2 New Features in LabVIEW 5.1
Clear Report
Clears the report of all text, headers, footers, and formatting information.
Clear Report Text
Clears the text and related formatting information from the report.
©
National Instruments Corporation 2-35 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
Dispose Report
Closes the report and releases its interface, which saves memory. No further operations are
permitted on the report. However, you can create a new report. You can use this VI only as
the last VI in the report function you are creating.
Get Report Settings
Retrieves information about the current font and text settings of a given report. The
information is displayed on the front panel.
New Report
Creates a new report. You must use this VI to create a report if you do not use the
Easy NI Report VI.
New Report Line
Starts a new line in the report to which you can append text or append another file.
LabVIEW 5.1 Addendum 2-36
©
National Instruments Corporation
New Report Page
Adds a new page in the report to which you can append text or append another file.
Print Report
Prints the report to a designated printer or to the default printer set up on your computer.
Set Report Font
Sets the font properties for the report, including those in the headers and footers. The av ailable
options include italic, bold, strikethrough, underline, color, font name, font size, character set
and weight.
Chapter 2 New Features in LabVIEW 5.1
Set Report Footer Text
Sets the text for the report footer.
You might find that using tokens with this VI is helpful, particularly in the Headers and
Footers parameters. For example, you might want to put a time stamp in the footer. See the
Tokens topic, earlier in this chapter, for more information on some common tokens for
this VI.
©
National Instruments Corporation 2-37 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
Set Report Header Text
Sets the text for the VI header.
You might find that using tokens with this VI is helpful, particularly in the Headers and
Footers parameters. For example, you might want to give the report a time stamp in the
header. See the Tokens topic, earlier in this chapter, for more information on some common
tokens for this VI.
Set Report Margins
Sets the margins of the specified report.
Margins are defined by a cluster of four values: left , right, top, and bottom margins. Also, you
must specify the measurement system (US, Metric, or Default) that determines your units of
measurement. Selecting US gives you inches, selecting Metric gives you centimeters, and
selecting Default giv es you the units of the current measurement system configured on your
computer.
Set Report Orientation
Determines whether the report is printed in landscape or portrait orientation.
LabVIEW 5.1 Addendum 2-38
©
National Instruments Corporation
Set Report Tab Width
Sets the tab width in the report. To place a tab in your text, insert the token <tab> in the text
string. Alternatively, you can use the Concatenate String function and insert a tab constant to
build the text string.
Enhancements to DAQ
This section describes the data acquisition (DAQ) enhancements in
LabVIEW 5.1.
DAQ Solution Wizard
You can now use the DAQ Solution Wizard even if you have no DAQ
devices configured on your computer. However, without DAQ devices
installed on your computer you cannot specify particular board options, and
any opened solutions cannot be run until you install the appropriate DAQ
device.
Chapter 2 New Features in LabVIEW 5.1
Support for NI-DAQ for Windows and Macintosh
LabVIEW 5.1 for Windows 95/NT ships with NI-DAQ 6.5. LabVIEW 5.1
for the Macintosh platform ships with an updated version of NI-DAQ 6.1.
The DAQ Channel Wizard has been upgraded in NI-DAQ 6.5 and now is
integrated in with the Measurement & Automation Explorer (the NI-DAQ
configuration utility), which allows you to configure and test your National
Instruments products from one common application.
New Syntax Element for Nonsequentially Scanned SCXI Module Channels
If you operate a module in parallel mode, you can specify an SCXI channel
either by specifying the corresponding onboard channels or by using the
SCXI channel syntax. This syntax is described in the SCXI Channel
Addressing section of Chapter 20, Special Programming Considerations
for SCXI, in the LabVIEW Data Acquisition Basics Manual.
©
National Instruments Corporation 2-39 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
If you are scanning modules, you can scan an arbitrary number of channels
for each module using channel list elements that are components of the
SCXI channel syntax. Previously, however, the channels of each module
needed to be scanned in consecutive, ascending order.
Now, with LabVIEW 5.1, you can scan modules ran domly, provided that
the module is capable of random scanning. The new syntax appears below:
Channel List Element Channel Specified
OBz!SCx!MDy!(a,…,n)
Channel a through n in the module in
slot y of the chassis with ID x are
multiplexed randomly onto onboard
channel z.
For example, if you wanted to sequentially scan channels 2, 3, 4, and 5,
you could use the following channel list element:
ob0!sc1!md2!(2,3,4,5)
You could also use the channel list element ob0!sc1!md2!2:5.
However, to scan the module’s channels randomly, you could use the
following channel list element:
ob0!sc1!md2!(5,1,3,5)
You could also use a colon ( : ) in the list to scan a series of channels
sequentially, as in the following channel list element:
ob0!sc1!md2!(2,1,4,7:11,13,15)
In addition, you can use semicolons instead of commas within the
parentheses and achieve the same scan:
ob0!sc1!md2!(2;1;4;7:11;13;15)
Enhancements to VISA
LabVIEW 5.1 has two new VISA functions as well as a new VISA palette
that contains the interface-specific functions. You can reach the new palette
by selecting Functions»Instrument I/O»VISA»Interface Specific.
This palette replaces the Functions»Instrument I/O»VISA»VISA Serial
palette. In versions of LabVIEW previous to LabVIEW 5.1, the following
LabVIEW 5.1 Addendum 2-40
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
three VIs could be found on the VISA Serial palette but are now on the
Interface Specific palette:
• VISA Set Serial Buffer Size
• VISA Flush Serial Buffer
• VISA Serial Break
In addition to the above existing functions, you can find the following two
new functions on the Interface Specific palette:
• VISA GPIB Control REN
• VISA VXI Cmd or Query
The VISA GPIB Control REN function asserts or deasserts the GPIB
Remote Enable interface line according to a specified mode. The VISA
VXI Cmd or Query function sends a command or query, or receives a
response to a query previously sent to the device.
You can find examples of the VISA VIs in the
Examples\Instr\visa.llb directory.
Enhancements for Building and Distributing Applications
This section describes the new features for building and distributing
applications now available in LabVIEW.
Note
Building Executable Programs
©
National Instruments Corporation 2-41 LabVIEW 5.1 Addendum
This functionality is available only in the LabVIEW Professional Development
System or if you purchase the Application Builder Libraries.
In LabVIEW 5.1, the process for building an application has been
streamlined. Previously, to do so you had to save your VIs to a library, then
build an application using the Build Application dialog box. Further, to
build an installer in Windows you had to use the Create Distribution Kit
dialog box.
Now , in LabVIEW 5.1, you can use the Build Application dialog box to do
all of these operations. Y ou can configure the application to various settings
within the tabs on the Build Application dialog box. After you define these
settings, you can save them in a script so that you can easily rebuild the
application.
Chapter 2 New Features in LabVIEW 5.1
Building an Application
Complete the following instructions to build an application in LabVIEW.
1. Select Project»Build Application…. The Build Application dialog
box appears. The Build Application dialog box contains the following
tabs: Target, Source Files, VI Settings, App Settings, and Installer.
You can create a new build or load a build file that you created
previously.
• If you want to create a new application, proceed to Step 2.
• If you already have a build f ile, click Load… and choose the .
2. From the Target tab, specify the following information:
• Application name—The name of the application you are
• Destination directory—The path and name of the directory in
• Support file directory —The path and name of the directory in
3. Under the Build section of the Target tab, choose one of the following
two options:
• Single application containing all VIs—Check this option to
• Small application with external file for subVIs—Check this
4. From the Source Files tab, you can configure the VIs that make up
your application. You can specify top-level VIs, dynamically loaded
VIs, and additional non-VI files (such as readme files). You can update
the file list automatically as VIs are added or removed from your
hierarchies. Depending on what kind of source files you want to add,
complete the instructions below.
a. If you want to add top-level VIs, click Add Top Level VI….
b. If you want to add dynamic VIs, click Add Dynamic VI….
bld
file to load. Then proceed to Step 6.
creating. This file should have a .
exe extension.
which to create and save your new application.
which to save any support files.
create a single application containing all of your VIs.
option if you want to keep the main application small.
The Open dialog box appears where you can enter a file name,
or browse to find the VIs you want to add. When you select a
top-level VI, LabVIEW automatically includes all its subVIs and
related files (such as menu files or DLLs).
If your VI dynamically calls any subVIs using the VI Server,
LabVIEW cannot detect them automatically, so you must add
them by using this option.
LabVIEW 5.1 Addendum 2-42
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
c. If you want to add support files, click Add Support File….
When you use this option, data files copy over to your application
directory automatically. In addition to VI files (VIs, controls,
menus, external subroutines, and so on), you can determine the set
of DLLs referenced by your application. Because there are DLLs
you might not want to redistribute, LabVIEW includes only those
DLLs that are within the source hierarchy directories and the
LabVIEW directory. If you want to include DLLs that are in the
System directory , for example, you can include them as additional
non-VI files manually.
d. If you want to remove a file from the list, click the file to highlight
it and click Remove File.
5. Click Save to save the information you have entered. The Save As
dialog box appears. Enter a file name with a *.
bld extension to save
the information you have entered into this dialog box.
6. Click Build. The Build Status dialog box appears.
7. After the build operation finishes, click Done to close the Build
Application dialog box.
Customizing Application Features
1. If you want to customize some destination settings, select Custom
Destinations… from the Source Files tab. The Destination Settings
dialog appears, in which you can configure the following settings:
• You can modify your destination directory.
(Windows)
•
If you want to add a program item to your Start menu
as part of an installer, select the Create program item checkbox
and enter the name.
(Windows)
•
If you are creating an installer, you can specify how you
want to Replace existing files. Select Never, Ask, If Newer, or
Always, depending on how or if you want to be prompted.
2.
(Windows
Macintosh)
and
From the App Settings tab, you can
customize the features in your application. You can choose to specify
the memory size for the Macintosh, or customize icons and ActiveX
server features on Windows.
(Windows)
a.
If you want to specify your own icon, click the Custom
icon checkbox and designate the path to the icon.
(Windows)
b.
If you want to enable the ActiveX server, click the
Enable ActiveX server checkbox. Your application can then
respond to requests from ActiveX clients. The functionality of the
ActiveX server in your application is a subset of the LabVIEW
©
National Instruments Corporation 2-43 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
c.
Modifying VIs as Part of the Build
Use the VI Settings tab to specify the modifications to your VIs that you
want to make part of the application build. You can choose to enable or
disable various window option and execution option VI Setup settings.
These settings apply to the build process only and do not affect your
original source VIs.
ActiveX server. When you build an application myapp.exe, an
ActiveX type library
myapp.tlb is also created along with the
executable. The type library defines a createable class,
Application, and a dispatch class, Virtual Instrument, and exports
the properties and methods for these classes. You can find the
Help for these properties and methods in
LabVIEW
Help directory . When you distribute the application
lvcomm.hlp in the
make sure the type library and the help file are located with the
executable.
When you assign the name of the application to the server name,
your application is uniquely identified in the system registry. Once
you build the application, you should run it at least once to enable
registry with the system. After the application is registered,
ActiveX clients access the server objects using serv er names. For
example, if you specify the server name as
instantiate an application object using the
(Macintosh) Use the Memory Size control to specify the memory
myapp, clients
myapp.application.
allocated to the application.
LabVIEW removes debugging code, block diagrams, and unnecessary
front panels, making your application as small as it can be. The removal
of front panels is a new feature with LabVIEW 5.1. LabVIEW can detect
which panels are necessary in almost all cases. However, if you open a front
panel dynamically using the VI Server, you must specify that the panel is
needed using the VI Settings tab.
You can edit only a single row at a time. By default, all unnecessary panels
are removed. You can override the default and include the panel by setting
the Remove Panel option to No.
To change settings, select a VI so that it is highlighted in the list. Click Edit
Build Settings…. The Edit Build Settings dialog box appears. For each
setting you can choose yes, no, or no change. When you have made all the
settings, click Change. Verify that all the settings are the way you want
them for each VI in the build.
LabVIEW 5.1 Addendum 2-44
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
Note This completes the build application process on the UNIX and Macintosh
platforms. The steps described in the following section apply to Windows only.
Creating an Installer (Windows only)
1. From the Installer tab, click the Create installer checkbox. Verify the
following sections of this tabbed page. If you create an installer, the
installer is written to the directory that contains your application. The
disk images are created in a disks subdirectory of the destination
directory that you specified on the Target tab. This directory will
contain a setup program as well as files named
and so on. If you plan to put the disk images on floppy, it is best to copy
the
setup and data.001 files to the first floppy, copy the data.002
file to the second floppy, and so on.
• Installation name
• Start menu program group
• Default installation directory
• Installation language
• Media size
• Extra space on first disk (KB)
The Media size item lets you specify how the file is to be
segmented—for 720 KB, 1.2 MB, or 1.4 MB floppies. Even if you
plan to distribute the files by CD, it is necessary to segment them.
However , if you want to run the installer from a CD or from your dri ve,
you can place all of the files in the same directory and run the setup
program from that directory.
The Extra space on first disk (KB) item lets you reserve space on the
first disk. You might reserve space on the first disk if you want to put
a readme file on the first floppy.
2. Click the Advanced button. The Advanced Installer Settings dialog
appears.
a. If you would like to create an uninstaller, click the Create
uninstaller checkbox.
b. If you would like to run a program after the installation, click the
Run executable after installation checkbox and enter the
executable and command line argument information.
3. Select the Run executable after installation item if you want to run a
program after the installation completes. Additionally, you can use this
item to run a program that finishes the installation. For example, you
might write a DOS batch program or a C program that modifies a
data.001, data.002,
.ini
©
National Instruments Corporation 2-45 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
file or a registry file. Install the file as part of your installation and
then run it afterwards to make the necessary modifications. The file
that you run must be one of the files that you install.
4. If you choose to run an executable after the installation completes, you
can use the Command line arguments to specify arguments passed to
the program. In addition to specifying standard arguments, you can
embed any of the following items in the command line argument
string:
%dest The application installation directory
%src The directory that contains setup.exe
chosen by the user
%group
%name The installation name
The installation program group name
If any of these options are present at installation time, they are replaced
with the proper values before the arguments are passed to the
executable.
Run-Time Engine for the Application Builder for Windows
When you develop an executable program with LabVIEW for Windows
and ship it to another computer, you must also include the LabVIEW
Run-Time Engine. The computer on which the program runs must install
this component using the LabVIEW Run-Time Engine Installer before the
program executes.
If you distribute a program using Build Application, the Run-Time Engine
is installed automatically.
This enhancement greatly reduces the size of the executable program.
Note
After the Run-Time Engine is properly installed on a machine, it can run any
executable program developed in LabVIEW. You only have to include the
Run-Time Engine with the first program sent to each computer.
LabVIEW 5.1 Addendum 2-46
©
National Instruments Corporation
Enhancements to Networking
This section describes the networking enhancements in LabVIEW 5.1.
DataSocket VIs for Windows
DataSocket technology facilitates the exchange of data and information
between an application and a number of different data sources and targets.
These sources and targets include files and HTTP/FTP servers.
In LabVIEW 5.1, new VIs provide a simple yet intuitive way to access and
use DataSocket technology within LabVIEW. You can create applications
that share data among many different sources using a single Application
Programming Interface (API).
The DataSocket VIs are available only for Windows platforms. For more
information about the new DataSocket VIs, refer to the DataSocket VIs
topic in the LabVIEW Online Reference. You can find examples of the
DataSocket VIs in the
Internet/HTTP Services
Internet/HTTP services are available on all platforms and versions for
LabVIEW 5.1, and give you capability to do the followi ng:
• Publish HTML documents
• Generate HTML-readable images of a VI’s front panel acros s the Web
• Generate animated versions of a VI’s front panel on the Web
• Use basic access control to limit which VIs may be viewed and by
whom
Examples\Comm\datasktx.llb directory.
Chapter 2 New Features in LabVIEW 5.1
Note
©
National Instruments Corporation 2-47 LabVIEW 5.1 Addendum
If you want to control VIs from a browser, or you need to dynamically create
HTML documents from your LabVIEW program, or you need more sophisticated
access control, consider the Internet Toolkit, also availab le from National
Instruments.
The Edit»Preferences dialog box now includes three new list box options
that you use to set up the built-in Web Server:
• Web Server: Configuration
• Web Server: Browser Access
• Web Server: Visible VIs
Chapter 2 New Features in LabVIEW 5.1
The Web Server
With the Web Server in LabVIEW, you can publish your VI front panels
on the World Wide Web along with HTML documents.
The built-in Web Server is intended for users that need to make the panels
of their running VIs visible on the Internet, but do not require sophisticated
security features nor want to control VIs through the Internet.
The Web Server Configuration Dialog Box
You use the Web Server Configuration dialog box to set up the Web
Server.
Access the Web Server Configuration dialog box by selecting
Edit»Preferences and then Web Server: Configuration from the
drop-down menu. Table 2-6 describes the available options.
Table 2-6.
Web Server Configuration Dialog Box Options
Option Description
Web Server Enabled Enables the Web Server to publish front
panel images and HTML documents.
The default status is
Off.
Root Directory The directory that contains HTML
documents published by the LabVIEW
Web Server. The default path is
<LabVIEW>\www.
HTTP Port The TCP/IP port used to access the
Web Server. The default port is
80.
Timeout How long (in seconds) the Web Server
waits while reading a request befor e it times
out. The default value is
60.
Log File The path to the data log file in which
time-stamped information about
connections is saved. The default path is
<LabVIEW>\www.log.
LabVIEW 5.1 Addendum 2-48
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
The Web Server Browser Access Dialog Box
The Web Server Browser Access dialog box lists the remote computers
on the Internet that are allowed to access the Web Server.
Access the Web Server Browser Access dialog box by selecting
Edit»Preferences and selecting Web Server: Browser Access in the
drop-down menu.
Figure 2-6.
©
National Instruments Corporation 2-49 LabVIEW 5.1 Addendum
Web Server Browser Access Dialog Box
Chapter 2 New Features in LabVIEW 5.1
Table 2-7 describes the available options.
Browser Access List Lists computers or domains that have
Text box Changes or adds an entry to the list. To add
Table 2-7. Web Server Browser Access Dialog Box Options
Option Description
access to the W eb Server . Click and drag an
entry in this list to move it in the access list.
If an entry permits access to the W eb Server
from an address, a check mark appears next
to its name. If an entry denies access to the
W eb Serv er, an X appears next to its name.
If no symbol appears next to the entry, the
syntax for the entry is incorrect.
an entry, click the Add button and type in
this box. T o change an existing entry, select
it from the Access List and edit it in this
box.
Allow Access and
Deny Access
Determines whether the current entry has
access to the Web Server. Click the Allow
Access radio button to grant a computer or
a domain access to the Web Server. Click
the Deny Access radio button to deny a
computer or domain access to the Web
Server.
Add Adds a new entry to the Access List
following the item currently highlighted in
the Access List.
Remove Removes the highlighted entry from the
Access List.
When a browser attempts to connect to the W eb Server , the server e xamines
the entries in the Browser Access List to determine whether the computer
is permitted access. If an entry in the list matches the computer’s address,
the server either permits or denies access, based on how you set up the
entry. If a subsequent entry also matches the computer’s address, that
permission is used in place of the previous permission.
LabVIEW 5.1 Addendum 2-50
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
For example, if you give a.test.site.com and b.test.site.com
access, but do not extend access to all addresses ending in
.test.site.com (where the * wildcard indicates all), the two computers
still have access. If no entry matches the client address, access is denied.
(See Table 2-8 for more information on the * wildcard and permitting
matching access entries).
To specify an Internet host address, enter its domain name or IP address.
You can use the * wildcard when specifying Internet host addresses. For
example, you can specify all hosts within the domain
entry
*.domain.com. You can specify all hosts in the subnet whose first
two octets are
130.164 with the entry 130.164.*. The entry * matches
domain.com with the
all addresses.
Table 2-8 shows examples of TCP/IP Access List entries.
Table 2-8. Examples of Access List Entries
Access String Matches
*
test.site.com
*.site.com
All hosts
The host whose domain name is
test.site.com
All hosts whose domain names end with
.site.com
130.164.123.123
130.164.123.*
The host with the IP address 130.164.123.123
All hosts whose IP addresses start with
130.164.123
In the Web Server Browser Access Dialog Box shown earlier in Figure 2-6,
all hosts in the
exception of all hosts in the
hosts
a.test.site.com, b.test.site.com, and 130.164.123.123
also have access to the server. The host
access, even though it is in the
site.com domain have access to the server, with the
test.site.com domain. Additionally, the
public.site.com does not have
site.com domain.
By default, all hosts have access to the Web Server.
Note If the Web Server runs on a system that does not have access to a DNS server,
do not use domain name entries in the Access List. Requests to resolve the domain
name or an IP address fail, slowing down the system. For performance reasons,
place frequently matched entries toward the bottom of the Access List.
©
National Instruments Corporation 2-51 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
The Web Server Visible VIs Dialog Box
Because the Web Server publishes front panels to the Web, it is best to
specify which VI front panels you allow to be published. Through the Web
Server: Visible VIs dialog box, you specify which front panels can be
published to the Web.
You access the Web Server Visible VIs dialog box by selecting
Edit»Preferences and selecting Web Server: Visible VIs in the
drop-down menu.
Figure 2-7.
LabVIEW 5.1 Addendum 2-52
Web Server Visible VIs Dialog Box
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
Table 2-9 describes the available options.
Table 2-9. Web Server Visible VIs Dialog Box Options
Option Description
Visible VIs Specifies the VIs or groups of VIs whose front
panels may be published by the Web Server. Click
and drag an entry in this list to move it in the Visible
VIs list. If an entry permits a VI or group of VIs to
be seen, a check mark appears next to its name. If
an entry denies such access, an X appears next to its
name. If no symbol appears next to the entry, the
entry’s syntax is incorrect.
Text box Changes or adds an entry to the list. T o add an entry ,
click the Add button and type in this box. T o change
an existing entry, select it from the Visible VIs list
and edit it in this box.
Allow Access
and
Deny Access
Determines whether the front panel of the current
entry can be published by the W eb Server . Click the
Allow Access radio button if you want to allow the
front panel of the VI or group of VIs to be published
by the Web Server. Click the Deny Access radio
button if you do not want to allow the front panel of
the VI or group of VIs to be published by the Web
Server.
Add Adds a new entry to the Visible VIs list after the
current item highlighted.
Remove Removes the highlighted entry from the Visible VIs
list.
Each entry in the Visible VIs list describes a VI name or a VI path and
might contain wildcard characters. Entries that contain path separators are
compared against VI paths, while entries that do not contain path separators
are compared against VI names only.
When a web browser attempts to obtain a VI front panel image, the serv er
examines the Visible VIs list to determine if it should grant access to the
requested VI’s image. If an entry in the list matches the requested VI, the
Web Server either permits or denies access to that VI’s image, based on
©
National Instruments Corporation 2-53 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
how that entry is set up. If a subsequent entry also matches the VI, its access
permission is used in place of the previous permission. If there is no VI in
the list that matches the requested VI, access to the VI’s image is denied.
Y ou can use wildcard characters in the Visible VIs list so an entry in the list
matches more than one VI. Use the wildcard characters shown in
Table 2-10.
Wildcard Action
Table 2-10. Wildcard Characters in Visible VIs List
‘?’
Matches exactly one arbitrary character, ex cept for
the path separator
‘*’
Matches zero or more arbitrary characters, except
for the path separator
‘**’
Matches zero or more arbitrary characters,
including the path separator
If you want to match a VI with a name that contains a wildcard character,
you must escape that character using
‘\’ (Macintosh and UNIX), or ‘`’
(Windows).
Table 2-11 shows examples of Visible VI list entries. The examples use
UNIX path separators.
Table 2-11. Examples of Visible VI List Entries
VI Access String Matches
*
/usr/labview/*
/usr/labview/**
All VIs
All VIs in the directory /usr/labview/.
All VIs in the directory /usr/labview/
and any of its sub-directories
Test.vi
Any VI named Test.vi
OK\?
In the Web Server Visible VIs Dialog Box shown earlier in Figure 2-7,
all VIs in the
c:\labview\server directory have front panels that you
can see on the web. All VIs in the
its sub-directories are exported as well, with the exception of the VI
c:\labview\test\private.vi. Additionally, any VI that begins with
LabVIEW 5.1 Addendum 2-54
Any VI with the name OK?
c:\labview\test directory and all
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
the string srvr_ and ends with the string
begins with the string
local_
even if it is located within the
and ends with the string
c:\labview\server
is exported. No VI that
.vi
is exported,
.vi
directory.
By default, the front panel image of all VIs are visible.
Configuring the Web Server
Complete the following steps to configure the Web Server.
1. Select Edit»Preferences and choose Web Server: Configu ration in
the drop-down menu.
See The Web Server Configuration Dialog Box section earlier in this
chapter for more information on this dialog box.
2. Enter a Root Directory , which is the directory where the W eb Serv er’ s
HTML files are located. The default path is
<LabVIEW>\www
3. In HTTP Port, specify the TCP/IP port the server uses.
The default port for HTTP is 80. You might specify a different port if
another HTTP Server already uses port 80 on your machine or if you
are on a system where you do not have permission to use reserved
ports.
If you use a non-default port, such as 8000, you must specify it on
URLs that refer to your server, as shown in this example:
http://hostname:8000/index.htm
.
4. In Timeout specify the number of seconds the W eb Server waits while
reading a request before the server times out. The default value is
5. Specify a Log File, which is the path of the file where information
about web connections is saved. The default path is
<LabVIEW>\www.log
.
.
60
.
Running the Web Server
You must run the Web Server in order to publish VI front panel images on
the World Wide Web.
To run the Web Server, check Web Server Enabled in the
Preferences»Web Server: Configuration dialog box.
©
National Instruments Corporation 2-55 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
Publishing Front Panel Images on the Web
Complete the following steps to publish a VI front panel image on the
World Wide Web.
1. Run the Web Server by checking Enable Web Server in the
Preferences»Web Server: Configuration dialog box.
2. Launch the VI(s) you want to publish to the web so they are in your
system’s memory.
Retrieving a Static Image of a VI Front Panel
Note
To retrieve an HTML-Readable Image of a VI front panel, the VI must be in
memory.
Complete the following steps to retrieve an HTML-readable image of a
front panel.
1. Open a Web browser.
2. T ype in a URL that includes the address of the LabVIEW Web Server,
the command for a static image (
.snap), a question mark (?) to
separate the URL from the parameters, and the name of the VI. The
URL takes the following form:
http://web.server.addr/.snap?VI_Name
You must encode the VI Name according to URL naming rules. Replace
special characters with their hexadecimal value preceded by a percent (%)
sign and replace spaces with a plus (+) sign.
For example, you can write the URL for the static image of the
Example.vi
http://web.server.addr/.snap?Test+Example.vi
as follows:
Test
Following the VI name, you can add parameters that specify attributes
for the image. See Static Front Panel Image (.snap URL) in the What URLs
Can I Use with My Front Panel Images? section later in this chapter for
more information on the characters you can enter in URLs to retrieve
images.
LabVIEW 5.1 Addendum 2-56
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
Viewing an Animated Version of a Front Panel
Complete the following steps to view an animated version of a front panel.
1. Open a Web browser.
2. T ype in a URL that includes the address of the LabVIEW Web Server,
the command for an animated image (
to separate the URL from the parameters, and the name of the VI. The
URL takes the following form:
http://web.server.addr/.monitor?VI_Name
You must encode the VI Name according to URL naming rules. Replace
special characters with their hexadecimal value preceded by a percent (%)
sign and replace spaces with a plus (+) sign.
With Netscape Navigator browsers, the Web Server uses the server-push
method to implement animations of front panel images. During a server
push, the server maintains an open connection and sends a new image after
a predefined period of time. W ith other browsers, the Web Server uses the
client-pull method to implement animation. During a client-pull animation,
the browser intermittently sends a request for each image.
Following the VI name, you can add parameters that specify attributes for
the image animation. See Animated Front Panel Image (.monitor URL) in
the What URLs Can I Use with My Front Panel Images? section later in this
chapter for more information on the characters you can enter in URLs to
retrieve images.
.monitor), a question mark (?)
Determining Which Front Panels are Visible
To make a VI’s front panel visible across the Web.
1. Open the Web Server Visible VIs dialog box by selecting
Edit»Preferences and selecting Web Server: Visible VIs in the
drop-down menu.
2. Choose Add.
3. T o deny a specif ic VI’s front panel from being viewed, type its path in
the Text box and choose Deny Access. To allow a specific VI’s front
panel to be viewed, types its path in the Text box and choose Allow
access.
Note
©
National Instruments Corporation 2-57 LabVIEW 5.1 Addendum
You also can allow or disallow the viewing of whole groups of VI front panels by
using wildcards. See the section The Web Server Visible VIs Dialog Box, earlier in
this chapter for more information on wildcards.
Chapter 2 New Features in LabVIEW 5.1
What URLs Can I Use with My Front Panel Images?
With the Web Server, you can publish images of your VI front panels on
the World Wide Web. You do not need to modify the VIs to display their
front panels.
Front Panel Image Formats
The Web Server can generate images of VI front panels in the Joint
Photographic Experts Group (JPEG) and Portable Network Graphics
(PNG) image formats.
The JPEG image format is a public domain image format that all current
browsers support. It has been developed for the distribution of real-life
images and photographs and uses a lossy compression algorithm to reduce
the memory size of an image. When you use JPEG on images that contain
lines and text, such as front panels, the resulting image often displays
artifacts of the compression, such as fuzzy text or stray color pixels.
The PNG format is a recent public domain image format. The compression
algorithm in this format is lossless, which produces PNG images exactly
like the original images. PNG is designed to be the successor of the
Graphics Interchange Format (GIF), which also uses lossless compression.
PNG is an open standard that you also can use on true-color images.
Internet Explorer 4.0.1 and Netscape Navigator 4.0.4 support the PNG
format. Older browsers require a plug-in or an external application to view
PNG images.
Static Front Panel Image (.snap URL)
The .snap URL signals the server to return a static image of the front panel
of a VI currently in memory. The query parameters in the URL specify the
VI name and the attributes of the image.
You must open the front panel of the VI to take snapshots for static images
because closed front panels do not update the images of controls when the
value changes.
LabVIEW 5.1 Addendum 2-58
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
The syntax to use in the URL for static front panel images is as follows
(parameters in brackets [ ] are optional):
.snap?VI_Name
[&type=type]
[&depth=depth]
[&quality=quality]
[&compression=compression]
[&refresh=refresh]
[&full=full]
VI_Name is the name of the returned VI front panel. Y ou must encode the
VI name according to HTTP conventions. Replace special characters with
%
xx
, where xx is the hexadecimal value of the character.
Type is the returned image type, either JPEG or PNG. If no type is
specified, the default type is used.
Depth is the depth of the returned image. Depth can be 1, 4, 8, or 24 bits.
If no depth is specified, the default depth is used.
Quality is the image quality and memory size of the JPEG front panel
image. Quality can be between 0 and 100. If no quality is specified, the
default quality is used.
Compression is the compression level used for compressing PNG images.
Compression can be between 0 and 7. If no compression is specified, the
default PNG compression is used.
Refresh is the maximum age of a cached image. If a cached image is older
than refresh seconds, a new image is generated.
Full specifies whether to return the image of all controls or just the part
visible in the window. Set full to on to indicate all controls and off to
indicate the window content. If no full is specified, the image of the visible
front panel in the window is returned.
©
National Instruments Corporation 2-59 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
The following are some examples on how you would use this syntax:
• T o return the front panel image of the VI
foo using the default image type, depth, and quality, use the
following code:
http://foo/.snap?My%20VI.vi
• To return the front panel image of the VI Test 1.vi from the
computer
following code:
http://foo/.snap?Test%201.vi&depth=24&type=png
• To embed the image of the VI Example.vi, in an HTML document
on the same system, use the following code:
<IMG SRC="/.snap?Example.vi">
• To embed the image of the VI Example.vi running on the computer
foo in any HTML document, use the following code:
<IMG SRC="http://foo/.snap?Example.vi">
Animated Front Panel Image (.monitor URL)
The .monitor URL signals the server to return an animated image of the
front panel of a VI currently in memory. The query parameters in the URL
specify the VI name, attributes of the animation, and attributes of the
image.
My VI.vi from the computer
foo using image depth=24 and image type=PNG, use the
For example, you can write the URL for the animated image of the VI
Test Example.vi, which updates once every two seconds for three
minutes, as follows:
http://web.server.addr/.monitor?Test+Example.vi&refresh=2&lifespan=180
For Netscape Navigator browsers, the server uses the server-push method
of animation. The server accomplishes this animation by taking subsequent
snapshots of the front panel image and sending them to the client. With
other browsers, the server uses the client-pull method of animation.
You must open the front panel of the VI to take snapshots for animated
images because closed front panels do not update the images of controls
when the value changes.
LabVIEW 5.1 Addendum 2-60
©
National Instruments Corporation
Chapter 2 New Features in LabVIEW 5.1
The syntax to use in the URL for static front panel images is as follows
(parameters in brackets [ ] are optional):
.monitor?VI_Name
[&type=type]
[&depth=depth]
[&quality=quality]
[&compression=compression]
[&refresh=refresh]
[&full=full]
[&lifespan=lifespan]
VI_Name is the name of the returned VI front panel. Y ou must encode the
VI name according to HTTP conventions. Replace special characters with
%
xx
, where xx is the hexadecimal value of the character.
Type is the returned image type, either JPEG or PNG. If no type is
specified, the default type is used.
Depth is the depth of the returned image. Depth can be 1, 4, 8, or 24 bits.
If no depth is specified, the default depth is used.
Quality is the image quality and memory size of the JPEG front panel
image. Quality can be between 0 and 100. If no quality is specified, the
default quality is used.
Compression is the compression level used for compressing PNG images.
Compression can be between 0 and 7. If no compression is specified, the
default PNG compression is used.
Refresh is number of seconds between each succeeding image.
Full specifies whether to return the image of all controls or just the part
visible in the window. Set full to on to indicate all controls and off to
indicate the window content. If no full is specified, the image of the visible
front panel in the window is returned.
©
National Instruments Corporation 2-61 LabVIEW 5.1 Addendum
Chapter 2 New Features in LabVIEW 5.1
Lifespan is the number of seconds the front panel animation lasts. Setting
Lifespan=0 implies that the animation continues until the browser
cancels it. If no lifespan is specified, the default lifespan is used.
Note When using client-pull animations, the lifespan is ignored.
The following are some examples on how you would use this syntax:
• To generate an animated front panel image of the VI
the computer
foo using the default image type, depth, and quality,
use the following code:
http://foo/.monitor?My%20VI.vi
• To generate a 60-second animation of the front panel image of the VI
Test 1.vi from the computer foo using the default image type and
quality but using
http://foo/.monitor?Test%201.vi&refresh=5&lifespan=60
refresh=5, use the following code:
• T o embed the image of the VI Example.vi in an HTML document on
the same system, use the following code:
<IMG SRC="/.monitor?Example.vi">
• To embed the image of the VI Example.vi running on the computer
foo in any HTML document, use the following code:
<IMG SRC="http://foo/.monitor?Example.vi">
My VI.vi from
Enhancements to Examples and Activities
You can run example VIs to help you get started with LabVIEW. To
generate or find examples similar to your application, refer to the Solution
Wizards (on Windows and PCI Macintosh only) or to the Search Examples
online help file (Windows only), which you can access from the LabVIEW
startup dialog box.
In addition to the example VIs, a good way to get started with LabVIEW is
to complete the activities available to you in the LabVIEW User Manual
and in the LabVIEW Online Reference.
Note The LabVIEW Online Reference has the most up-to-date information regarding
paths to VIs, functions, and controls.
©
LabVIEW 5.1 Addendum 2-62
National Instruments Corporation
Manual Clarifications and
Additions
This appendix clarifies and corrects information in the LabVIEW manual
set. Because these manuals were not revised for the version 5.1 release of
LabVIEW , this appendix contains information relevant only to the previous
release.
Enhancements to LabVIEW 5.1 have rendered some information in these
manuals incorrect, particularly illustrations of palettes and navigation paths
to functions and controls, including those in activities. See Chapter 2, New
Features in LabVIEW 5.1, for updated informati on and descriptions of new
features.
Multithreading
Color of Code Interface and Call Library Function Nodes—The color
of a code interface node (CIN) or Call Library Function node on a block
diagram changes depending on whether LabVIEW considers it reentrant.
If LabVIEW considers a CIN or Call Library Function node reentrant,
LabVIEW assigns it the current primitive color (the default is pale yellow).
If a CIN or Call Library Function node is not considered reentrant, its color
is orange. This color designation exists on all platforms, even if the
platform itself is not threaded.
A
ActiveX
ole_lv5container.dll—The ActiveX Container uses a DLL named
ole_lv5container.dll, which is located in the resource directory.
If you build an application that includes ActiveX controls and move it to
another machine, you must install this file in the same directory as the built
application or in the
references to
©
National Instruments Corporation A-1 LabVIEW 5.1 Addendum
ole_container.dll should be ole_lv5container.dll.
System directory. In the LabVIEW documentation,
Appendix A Manual Clarifications and Additions
Data Format—The compatibility VIs for the LabVIEW 4.x Automation
functions require that you pass flattened data in the LabVIEW 4.x format.
LabVIEW 5.x loads your LabVIEW 4.x VIs and automatically selects the
Convert 4.x Data option for the Flatten To String and Unflatten From
String functions, which are found in the Advanced»Data Manipulations
palette.
Instrumentation
Signal Generator by Duration VI—The Signal Generator by Duration
VI has been added to the Signal Processing»Signal Generation palette.
This VI generates a signal with a shape given by the waveform type: sine,
cosine, triangle, square, sawtooth, increasing ramp, or decreasing ramp.
CVI Function Panel Converter Changes—The improved CVI Function
Panel Converter creates hierarchical text menus so you can find functions
quickly. Two new options have been added to the CVI Function Panel
Converter. These options are ON by default.
• Map ViSession type to VISA Session RefNum—This option
specifies that instrument session numbers of type V iSession in the CVI
Function Panel are converted to LabVIEW VISA RefNums in the
resulting VI. Functions that contain the string
automatically register with the VISA refnum; functions that contain
_close in their name automatically close the VISA refnum.
• Create instr.lib menu mirroring CVI Class Hierarchy—
This option specifies that when converting a Function Panel file,
a palette menu for the instrument is created in the Instrument Drivers
menu. This menu is organized hierarchically according to the Function
Panel Tree in the
_init in their name
.fp file.
General Interface Features
Icon and Text Palettes
You can display palettes in three modes: Standard, All Icons, or All Text.
Choose the palette display mode in the Edit»Select Palette Set»Display
Style submenu.
In All Text mode, you right-click to access the Controls or Functions
palette. These text palettes contain the names of options. Items in text
palettes are organized in the same order as in the icon palettes when you
read the icon palette row by row, left to right. Empty spaces in the icon
LabVIEW 5.1 Addendum A-2
©
National Instruments Corporation
File Manager Tool
Appendix A Manual Clarifications and Additions
palettes are skipped. Unlike icon palettes, you cannot tack down text
palettes or subpalettes. In All Text mode, LabVIEW displays text palettes
in the Project menu and the Find dialog box. In Standard or All Icons
mode, LabVIEW displays icon palettes.
Standard is the default mode. In Standard mode, all palettes default to icon
palettes, but you can edit individual palettes to display them as text palettes.
When you edit a palette by selecting Edit»Edit Control & Function
Palettes…, LabVIEW displays the palettes in All Icons mode. Y ou cannot
edit palettes in the other modes because they do not contain as much
information (icon palettes have both icons and two-dimensional layout,
while text palettes do not). To specify the mode for the Functions or
Controls palette, right-click on the palette—but not on a subpalette
icon—and select either Icons or Text from the Standard Menu View
submenu. The mode you select affects only the menu you are editing.
The File Manager tool, which you access by choosing Project»
File Manager…, simplifies copying, renaming, and deleting files within
VI libraries (LLBs). You also can use this tool to create new LLBs and
directories and convert LLBs to and from directories.
To avoid performing a file operation on a VI already in memory, close all
VIs that might be affected before using this tool.
In the File Manager dialog box, shown in the following figure, you can
view two locations (directory or LLB) simultaneously. When you select a
file, you can copy, rename, or delete it using the corresponding buttons
between the two lists. Click New… to create a new directory or LLB.
©
National Instruments Corporation A-3 LabVIEW 5.1 Addendum
Appendix A Manual Clarifications and Additions
Figure A-1. File Manager Tool Dialog Box
If you select an LLB, you can click Convert LLBs to Dirs to convert it to
a directory . If you select a directory and click this button, the tool scans for
all LLBs within that directory and gives you the option to convert them to
directories. The new directory is created in the same location as the
original LLB.
If you assign the new directory a name that differs from that of the original
LLB, LabVIEW searches for the files that were within the LLB when
calling a VI (even when the name is the same minus the
When you convert an LLB to a directory, you have the option to back up
the LLB (the
.llb extension changes to .llx).
T o conv ert a directory to an LLB, select a directory and click Convert Dirs
to LLBs.
Click Check Filenames to scan a directory or VI library for
platform-dependent filenames. The tool scans all filenames for invalid
characters (
:, \, /, ?, *, <, >, or |) and v erifies filenames to be 31 characters
or less (a limitation on the Macintosh). The Check Filenames option also
scans files within LLBs. These files are portable, even if their names
LabVIEW 5.1 Addendum A-4
.llb extension).
©
National Instruments Corporation
contain characters that are invalid on some platforms. By scanning within
LLBs, this tool helps you detect potential problems if you move your files
out of VI libraries.
Use the Show dates option at the bottom of the dialog box to display file
modification dates next to each file. You can choose to sort the files
alphabetically or by date and disable files with the same name and date in
both directory listings. Use this technique when comparing two directories
to determine whether any files have changed.
Other General Interface Features
Dragging and Dropping VI Icons—LabVIEW 5.0 simplified the creation
of VI icons. By dragging an image file and dropping it onto the VI icon in
the upper-right corner of a front panel, a 32-by-32 version of the image
replaces the existing icon.
You can drag a VI icon from the icon pane in the upper-right corner to a
block diagram to instantly create a subVI call. By pressing <Shift> while
dragging the VI icon, you automatically wire the non-default values of the
controls as constants for the subVI.
If the subVI already appears in a block diagram, pressing <Shift> while
dragging onto the existing call updates the attached constants. A control at
its default value discards the constant attached to the subVI, and an input
wired to anything other than a constant is unaffected.
Appendix A Manual Clarifications and Additions
When you press <Shift> while double-clicking a subVI icon to open the
subVI front panel, LabVIEW loads the values of the constants wired to
the subVI into the front panel controls. All unwired controls retain the
default values.
You also can use the drag-and-drop technique for global variables and
custom controls. Additionally, you can drag a VI icon into a VI refnum on
a front panel control to load VIs into memory dynamically, which is part of
the VI Server functionality .
Print to RTF/HTML Feature—The Print to RTF/HTML feature can
export graphics in uncompressed graphics interchange format (GIF). To
use this feature, select File»Print Documentation, and select RTF File or
HTML File from the Destination pull-down menu.
©
National Instruments Corporation A-5 LabVIEW 5.1 Addendum
Appendix A Manual Clarifications and Additions
Configuration File VIs—The Configuration File VIs, which you can
access from the Functions»File I/O»Configuration File VIs palette,
provide tools for reading from and writing to a platform-independent
configuration file similar in format to a Windo ws initialization (
Macintosh Open Transport Support —LabVIEW 5.x supports
Open Transport on Power Macintosh machines. Open Transport is a
PowerPC-native networking driver.
New Preferences Options—La b V IE W 5 . x adds the following two options
in the Miscellaneous view of the Edit»Preferences… dialog box:
• Automatically close VISA sessions—Use this option to specify that
VISA sessions, like file refnums, close automatically when the
top-level VI goes idle. The default is ON, which closes VISA sessions
automatically.
• Treat read-only VI as locked—Using this option, you can choose
whether to treat read-only VIs as locked. You cannot edit locked VIs,
but you can re-compile and execute them. By default the option is not
selected so that read-only VIs appear normally. However, you cannot
save the VI to the same location (the read-only file) unless you change
the file permissions outside LabVIEW . This behavior is consistent with
the behavior in previous versions of LabVIEW. When using the VI
Server, the read-only status of f iles is ignored except when saving. This
option is designed primarily to support the source-code control of the
Professional G Developers Toolkit.
.ini) file.
Execution System Selection —The default preferred execution system
for a VI is same as caller. This setting allows the VI to run in the same
execution system in which caller is running when the subVI call to the VI
is made. The same as caller setting has the lowest run-time overhead.
When you set a VI to same as caller and you run it at the top level, it runs
in the standard execution system at its selected priority.
Icon Editor—The Undo button has been removed from the Icon Editor,
but you can undo an action by selecting Edit»Undo or
Offscreen Updates Default Value—The default value for offscreen
updates is now ON instead of OFF.
LabVIEW 5.1 Addendum A-6
<Ctrl-Z>.
©
National Instruments Corporation
Appendix A Manual Clarifications and Additions
Support for Template VIs and Controls
You can save commonly used VIs and controls as templates. To create a
template VI, save a VI with a
typedefs). When you open a template VI or control, the new file you create
is named automatically using your template name and a number
corresponding to the number of times it has been opened. When you finish
editing the VI and save it, LabVIEW prompts you to enter a new name for
the file.
.vit extension (or .ctt extension for
T o modify a template, open it, make your changes, then save over the
(or
.ctt) file that you originally created.
(Macintosh)
dialog box in the Finder to change a VI to a template.
You also can use the Stationery Pad checkbox of the Get Info
Adding VIs to the Project and Help Menus
Y ou can add VIs to the Project and He lp menus by placing them inside the
Project or Help directories in the LabVIEW directory. You can use this
technique to provide quick access to VIs that act as tools in your system.
National Instruments uses this feature to make the Tech Support VIs
accessible from the Help menu. Also, if you have the Application Builder
libraries installed, you can see a Build Application… option in the Project
menu.
Any VI placed at the top level of the
appended directly to the corresponding menu. If you create a subdirectory ,
a submenu is appended.
Project or Help directory is
Allocation of Threads on Concurrent PowerMAX
and Solaris 2
.vit
On Concurrent PowerMAX and Solaris 2, LabVIEW allocates threads as
described below.
If LabVIEW has permission to increase its Light Weight Process (LWP)
priorities from the default, it binds all created threads to LWPs.
• Profiling is very accurate because each thread is bound to a LWP and
the kernel monitors the execution timing of LWPs.
©
National Instruments Corporation A-7 LabVIEW 5.1 Addendum
Appendix A Manual Clarifications and Additions
• The LabVIEW priority system is reflected in the way the kernel runs
LWPs. Higher-priority execution threads (LWPs) take over the system,
not allowing lower-priority system tasks to execute.
• Switching between threads might require more time because
LabVIEW runs through the system scheduler.
(PowerMAX) LabVIEW for Concurrent PowerMAX always binds threads to
LWPs. Unless you have permission to adjust priorities to LWPs, LabVIEW
will stop, indicating that it does not have enough permission to run. The
permissions you need depends on the scheduler you are using. If you are
using the time-shared scheduler—the default—you need the
privilege. If you are able to use the real-time scheduler, you do not need any
additional privileges.
(Solaris 2) If LabVIEW for Solaris cannot increase its LWP priorities from
the default, it creates a LWP per thread, but leaves the threads and LWPs
unbound so the created threads have a pool of LWPs on which to run. The
typical user does not have permission to raise LWP priorities. If LabVIEW
threads are not bound to LWPs:
• Profiling strictly uses wall-clock time. Threads might switch LWPs
dynamically without kernel knowledge, so LabVIEW cannot use LWP
timing statistics.
• The LabVIEW priority system only has an effect internal to LabVIEW.
The system treats all the LabVIEW LWPs as another process to
schedule at the same priority as any other task in the system.
• Context switching between threads might be faster because it does not
involve the kernel scheduler.
P_TSHAR
The About LabVIEW dialog box, which you can view by choosing
Help»About LabVIEW…, indicates how LabVIEW currently allocates
threads.
Clarifications to the LabVIEW User Manual
The following clarifications pertain to the LabVIEW User Manual:
• In Chapter 2, Creating VIs, the text and an illustration in Activity2-3,
Create an Icon Connector, refer to an Undo button in the Icon Editor.
The Undo button has been removed, but you can undo an action by
selecting Edit»Undo or <Ctrl-Z>.
©
LabVIEW 5.1 Addendum A-8
National Instruments Corporation
Appendix A Manual Clarifications and Additions
• In Chapter 6, Strings and File I/O, the block diagram in Activity 6-3,
String Subsets and Number Extraction, shows the From
Exponential/Fract/Eng function. The block diagram should show the
Scan From String function, as described in the text.
• In Chapter 7, Getting Started with a LabVIEW Instrument Driver, the
Interactively Testing Component VIs section describes how to access
open VISA sessions. On the pop-up menu of a VISA session control,
if Open Sessions... is always grayed out, make sure that the
Automatically Close VISA Sessions option in
Edit»Preferences»Miscellaneous is unchecked.
• In Chapter 15, Spectrum Analysis and Measurement, the pathname for
library that includes the THD Example VI in Activity 15-3, Calculate
Harmonic Distortion, should be
examples\analysis\measure\measxmpl.ll.
•
(Windows 95) In the Using NetDDE section of Chapter 23, Using DDE,
the manual refers to
name is
REGEDIT.
REGEDIT and REDEGIT executables. The correct
• In Chapter 25, Program-to-Program Communication, the PPC Client
Example section refers to the PPC Open Connection, PPC Open
Session, PPC Close Session, and PPC Close Connection VIs. These
should be the PPC Open Port, PPC Start Session, PPC End Session,
and PPC Close Port VIs, respectively. The PPC Server Example
section refers to the PPC Close Session VI, which should be the PPC
End Session VI.
VISA Error Codes
The following table lists numeric VISA error codes that were not included
in the printed documentation.
Error Code Error Name Description
1073676443
1073676442
1073676441
1073676440
1073676424
©
National Instruments Corporation A-9 LabVIEW 5.1 Addendum
VI_SUCCESS_SYNC Operation completed successfully, but the operation was
actually synchronous rather than asynchronous.
VI_SUCCESS_NESTED_EXCLUSIVE Operation completed successfully, and this session has
nested exclusive locks.
VI_SUCCESS_NESTED_SHARED Operation completed successfully, and this session has
nested shared locks.
VI_SUCCESS_NCHAIN Event handled successfully. Do not invoke any other
handlers on this session for this event.
VI_WARN_NSUP_BUF The specified I/O buffer is not supported.
Appendix A Manual Clarifications and Additions
Error Code Error Name Description
1073676421 VI_WARN_UNKNOWN_STATUS The status code passed to the operation could not be
interpreted.
1073676420 VI_WARN_NSUP_ATTR_STATE Although the specified state of the attrib ute is v alid, it is
not supported by this resource implementation.
1073676418 VI_WARN_NULL_OBJECT The specified object reference is uninitialized.
1073676416 VI_SUCCESS_QUEUE_NEMPTY Wait terminated successfully on receipt of an event
notification. There is at least one more event occurrence
of the type specified by inEventType available for this
session.
1073676413 VI_SUCCESS_DEV_NPRESENT Session opened successfully, but the device at the
1073676407 VI_WARN_CONFIG_NLOADED The specified configuration either does not exist or
1073676294 VI_SUCCESS_MAX_CNT The number of bytes transferred is equal to the input
1073676293 VI_SUCCESS_TERM_CHAR The specified termination character was read.
1073676292 VI_SUCCESS_QUEUE_EMPTY Operation completed successfully, but queue was
1073676291 VI_SUCCESS_EVENT_DIS Specified event is already disabled for at least one of the
1073676290 VI_SUCCESS_EVENT_EN Specified event is already enabled for at least one of the
-1073807202 VI_ERROR_LIBRARY_NFOUND A code library required by VISA could not be located or
-1073807204 VI_ERROR_SESN_NLOCKED The current session did not have a lock on the resource.
-1073807215 VI_ERROR_INV_MODE Invalid mode specified.
-1073807229 VI_ERROR_INV_LENGTH Invalid length specified.
-1073807240 VI_ERROR_INV_PARAMETER The value of some parameter (which parameter is not
-1073807246 VI_ERROR_RSRC_BUSY The resource is valid, but VISA cannot currently
-1073807247 VI_ERROR_USER_BUF A specified user buffer is not v alid or cannot be accessed
-1073807248 VI_ERROR_NSUP_ALIGN_OFFSET The specified offset is not properly aligned for the
specified address is not responding.
could not be loaded. VISA-specified defaults will be
used.
count.
already empty.
specified mechanisms.
specified mechanisms.
loaded.
known) is invalid.
access it.
for the required size.
access width of the operation.
LabVIEW 5.1 Addendum A-10
©
National Instruments Corporation
Appendix A Manual Clarifications and Additions
Error Code Error Name Description
-1073807252 VI_ERROR_ASRL_OVERRUN An overrun error occurred during transfer. A character
was not read from the hardware before the next
character arrived.
-1073807253 VI_ERROR_ASRL_FRAMING A framing error occurred during transfer.
-1073807254 VI_ERROR_ASRL_PARITY A parity error occurred during transfer.
-1073807263 VI_ERROR_NSYS_CNTLR The interface associated with this session is not the
system controller.
-1073807271 VI_ERROR_RESP_PENDING A previous response is still pending, causing a multiple
query error.
-1073807275 VI_ERROR_NSUP_VAR_WIDTH Cannot support source and destination widths that are
different.
-1073807278 VI_ERROR_INV_WIDTH Invalid access width specified.
-1073807301 VI_ERROR_QUEUE_ERROR Unable to queue the asynchronous operation.
-1073807303 VI_ERROR_IN_PROGRESS Unable to queue the asynchronous operation because
there is already an operation in progress.
-1073807312 VI_ERROR_ABORT User abort occurred during transfer.
-1073807313 VI_ERROR_NENABLED You must be enabled for events of the specified type in
-1073807315 VI_ERROR_QUEUE_OVERFLOW The event queue for the specified type has overflowed
-1073807327 VI_ERROR_INV_ACCESS_KEY The access key to the specified resource is invalid.
-1073807328 VI_ERROR_INV_LOCK_TYPE The specified type of lock is not supported by this
-1073807333 VI_ERROR_INV_DEGREE Specified degree is invalid.
order to receive them.
(usually due to previous events not ha ving been closed).
resource.
©
