NPFC Series

LITHIUM IRON PHOSPHATE BATTERY

LiFePO4 Battery Module for Telecom

NPFC Series

(LiFePO4 Battery Module for Telecom)

OPERATION MANUAL

Version 9.0

NARADA POWER SOURCE CO., LTD

Email: intl@narada.biz Website: en.naradapower.com

CONTENTS

Notes

One

Two

Three

Safety and Warning

Product Introduction

Product Features

Main application

Dimension

Layout

Working principle

Technical Characteristic

Discharge performance

Charge performance

Operation

Parameter settings

Operation condition

Four

Five

01 02

Storage and Installation

Storage

Installation

Maintenance

General

Troubleshooting and Solutions

Annex1

Annex2

Annex3

Annex4

NPFC Series

LiFePO4 Battery Module for Telecom

Safety and Warning Chapter Notes

The NPFC series LiFePO4 battery system installation, operation, maintenance should follow

important recommendations in this manual:

The equipment shall be installed by the professional trained staff.

Battery maintenance should be carried out by the experienced professionals and aware of the

preventive measures on the potential harm of the battery.

Note: Be care of the risk of electric shock for large current in case of battery short circuit, pay

attention to the following points during operation

■ Remove watches, rings or other metal objects

■ Use tools with insulated handles

■ Do not place tools or metal objects on the battery

Do not direct access to the battery system to the mains grid power outlet.

Do not put the battery system into re, do not use or storage the battery near to the high

temperature source.

Do not use liquid or other objects placed into the battery system.

Product Introduction Chapter One/01

Product Features

NPFC series battery system is 48V system for communications back-up type LiFePO4 (lithium iron

phosphate) battery products, the system uses the advanced LiFePO4 battery technology with the

benet of long cycle life, small size, light weight, safety and environmental protection, and has a

strong environmental adaptability, it is idea for harsh outdoor environments.

The system also integrates a smart battery management and monitoring module, support for remote

centralized monitoring and remote battery management and maintenance, to meet the requirements

of unattended. Therefore, the NPFC system can fully meet the backup power supply requirements of

the access network equipment, mobile communications equipment, transmission equipment, micro

base stations and microwave communication equipment.

Main application

Do not open or cut the battery, not hit, throw or step on the battery.

Using special communication between battery module and power plant to charge battery

Be sure to subject to charge and discharge parameters setting in this manual.

The output interface of the system is still voltage when grid power cut, avoid electric shock or

short circuit when operation.

Please check if the box is damaged. If damaged, please immediately notify the supplier

If you nd leaking liquid or white powder residue on product, prohibit operation.

Please take care of the following marks

Warning

Read the

manual

Electricity

danger

Fire

forbidden

Protecting

your eyes

Circle used

Watch

Short-circuits

Do not put

batteries into

dustbin

With adults

custody

The product has

passed the UL

authentication

Network Telecommunication Facilities

OSP

Terminal of FTTX

Access network system

Indoor distribution system

Telecom BTS

Integrated outdoor power cabinet

UPS

Internet data center (IDC)

Solar energy

Common Bonding Network (CBN) and or Isolated Bonding Network (IBN)

03 04

Dimension Layout

NPFC Series

LiFePO4 Battery Module for Telecom

Fig.1-1 Structural Drawing of NPFC Series Batteries (48NPFC100 as example)

Battery

①

Model

48NPFC10

48NPFC20

48NPFC50

48NPFC80 (3U)

48NPFC80 (5U)

48NPFC100 (5U 19”)

Fig.1-2 Battery Output Terminal

Table 1-1 Battery Model & Dimension of NPFC Series

Typical Weight

(kg)

7.3

13.4

28.5

39.0

40.0

45.5

Dimensions(mm)

Width

(No ear)

442

442.5

Height

132.5

222

Depth L Φ

243

400

Battery Output

Terminal

10mm

13mm

Fig. 1-3 Layout of Front Panel for NPFC Series Batteries

(Received product may not have all parts above, this instruction is as an example)

Table 1-2 Instruction for Layout of Front Panel

No. Detailed Information

Marks

SOC

ALM

RUN

Functions

Indicators for

capacity

Indicator for

alarms

Indicator for

running status

SOC is short for state of charge. There are four green LED

lights in front panel indicating SOC. Each SOC LED light

represents 25% of rated capacity. Detailed information is

shown in Annexed Table 1.1.

There is one red LED light in front panel indicating alarms.

Detailed information is shown in Annexed Table 1.3.

There is one green LED light in front panel indicating

running status. Detailed information is shown in Annexed

Table 1.2.

48NPFC100 (3U 23”)

★48NPFC100 (3U 19’’)

Note:

①Battery Model

②★48NPFC100

(3U 19’’)

05 06

Battery models listed in the datasheet are standard products. Narada can also supply customized design in cell, BMS and dimensions for various application scenarios.

The height of this battery is 138mm, is a litter higher than 132.5mm(3U).

48.0

42.0

522.5

442.5

132.5

138

420

400

13mm

ADD Dip

switch

Address of

communication

ADD is applicable to modules connected in parallel. ADD

consists of six binary bits. Detailed information is shown

in Annex 2.

NPFC Series

LiFePO4 Battery Module for Telecom

RS2325

communication

port

RS232 communication port just for software upgrade now.

Working Principle

The NPFC battery system mainly includes Lithium battery pack, battery protection, cell balancing

It is adopting RS485 series port communication pattern

to upload data. Contents of data transmit include

RS485

RESET

Dry

contact

Power

switch

Battery

Output

LCD

(optional)

communication

port

Reset button

Dry contact

indicators

ON/OFF switch

Terminals for

battery output

Display battery

information

BMS parameters, battery running status, alarms, etc.

Communication of modules connected in parallel is

available through RS485.

Press RESET button when abnormity occurs to assure

stability of battery performance.

Failure Alarm: indicate BMS or battery fail including but

not limited to charge and discharge MOS fail, cell voltage

under 0.5V, NTC disconnect, and so on.

When turn-off, battery get into sleep mode, and cut-off

output, the alarm output also will be stopped.

Using terminals with four or two cores. Polarities are +, -,

+, - from left to right. The two ‘+’ and ‘-’ are equal relatively.

Detailed information is shown in Fig. 1-2.

Detailed information is shown in Annexed Table 3.

unit, monitoring module and charge-discharge management module for optional. Its schematic

diagram shown in Figure 1-4

Fig. 1-4 Schematic Diagram

LFP cells

Cell protection

Cell balancing

Chemical power, energy storage and power supply components.

Protect LFP cells against overcharge, over discharge, over current, over

temperature, short circuit

Equalization LFP cells for cells unbalanced

Support centralized monitoring system (optional according to customer

requirements)

GND

Removable

Panel

(optional)

Ground screw

Removable

Panel

Connect earth by exible cable above GREEN Sheathed,

UL94-V0, gauge of the grounding wire should be equal to

or greater than the gauge of the battery return wire.

Battery BMS can be removable and replace easily through

this.

Monitoring

NPFC battery working principle:

DC power input rectier after lter, DC divided two circuits, one circuit directly supply the load, another

circuit charge lithium battery. When grid power on, the system supplies the loads and charging inside

lithium batteries; When grid power failure, lithium inside system supply DC power to the load, to

Handle

handle

The handle is used to push and pull the battery easily

from battery cabinet.

Not recommend use handle to handing the battery.

ensure uninterrupted power supply as power system.

Battery Management System (BMS)

Smart BMS technology is adopted for battery modules of NPFC series to assure smart automatic

07 08

Side

mounting

Wall-hanging

installation

The side mounting is used to wall-handing installation battery.

Also use the ear to handle the battery.

management for batteries. Features of BMS are shown as below:

There is a centralized monitoring unit in BMS. Functions such as remote measurement, remote

communication, remote controlling are available. Battery modules can be controlled remotely

by staffs in control center. NPFC series are in line with the requirements of the development of

modern communications technology.

NPFC Series

Technical Characteristic Chapter Two/02

LiFePO4 Battery Module for Telecom

It is combined by technologies of power source and computer. Parameters and status of rectiers

and AC/DC distributions can be detected and controlled.

Excellent electromagnetic compatibility. BMS used for battery modules of NPFC series can

comply with the outdoor power plants during operation, no interfere with each other.

BMS can provide protections against overcharge, over-discharge, over-temperature, over current,

short circuit, etc., to assure reliable safety and operation life.

With patented cell balancing technology, BMS provide high efciency for cell balancing and

prolong system operate life.

Conguration exibility, support parallel connection expansion

Discharge performance

Fig.2-1 Discharge curve at different constant current of NPFC series

Charge performance

Fig.2-2 Charge curve at different current limitation of NPFC series

09 10

NPFC Series

LiFePO4 Battery Module for Telecom

Operation Chapter Three/03

Parameter settings

Lead-acid batteries can be replaced by lithium battery of NPFC series if power is matched. Table 3-1

is new parameter settings of power plant for lithium battery.

Table 3-1 Parameter Settings of Power Plant for NPFC Series Batteries

No. Defaults

Float charge voltage

Equalization charge voltage

Standard charge current

Charge current limitation

Equalization charge interval

Equalization charge duration

Condition to equalization charge

Condition to oat charge

Recovered LLVD voltage

Parameters

Units

day

54.0

NA or 54.1

0.2C

0.5C ~ 1.0C

0.05C

50.0

Storage and Installation Chapter Four/04

Storage

■ Storage temperature range: 0°C to 40°C.

■ Storage battery should be at 50%-80%SOC.

■ Recharge charge before using to recover capacity loss of self-discharge during storage and

transport.

■ Recharge battery during long-term storage for self-discharge. Recharge program as follow table:

Single Module Recharge ProcedureRecharge intervalStorage temperature

0°C-30°C

30°C-40°C

Every 6 months

Every 3 months

■ Storage battery over 40°C or under 0°C will reduce battery life,

■ Storage battery in dry and low temperature, well ventilated place

■ Battery performance degradation after long-term storage, please shorten shelf time as possible

as you can.

1) Charge with 0.2C to 100%SOC

2) Discharge with 0.2C to 0%SOC

3) Charge with 0.2C per module for 4 hours

Note:

1.Equalization charge is requested to switch off for NPFC series batteries.

2.Rectier parameter shall be set according to specic site requirement based on battery units used.

3.If the battery connected more than 2 in parallel, the max. charge current recommend 0.5C.

LLVD

BLVD

Temperature compensation for oat charge

Temperature compensation for equalization charge

-mV/°C

47.0

43.2

Installation

Unboxing & Inspection

■ Please study this manual before installation.

■ Please inspect the package before unboxing, if any destroy with appearance, contact with the

supplier as soon as possible.

■ This device shall be installed and operated by professionals.

Preparation for Installation

Operation Condition

Table 3-2 Requirements for Operation Environment

■ Batteries shall not be placed in direct sunshine or close to heat source.

■ Batteries shall be installed in place with good ventilation to assure enough heat dissipation.

■ Batteries shall be placed in are with clean ambient and low humidity.

Discharge

Temperature

Range (°C)

Recommended

Temperature(°C)

Humidity

11 12

Charge

Storage

Discharge

Charge

Storage

-20 ~ +60

0 ~ +60

0 ~ +40

+15 ~ + 35

+15 ~ + 30

5% ~ 95%

■ Heavy weight shall not be placed on any cable.

■ Following are the tools possibly but not limited be use for installation:

Tool items (possibly but not limited)

NPFC Series

LiFePO4 Battery Module for Telecom

Installation of Battery Modules

1.Installation and xation

Battery modules of NPFC series are applicable to installation in cabinets and wall-hanging.

■ cabinet installation

Insert battery module into cabinet, and x two handles of battery module with cabinet rack using

4pcs M6 screws.

■ Wall-hanging installation

Wall-hanging installation also can be adopted, x two handles of battery module with triangle rack

on the wall using 4pcs M6 screws.

2.Ground connection

Connect earth by exible cable above GREEN Sheathed, UL94-V0, gauge of the grounding wire

should be equal to or greater than the gauge of the battery return wire, .no less than 6AWG,

connection through 2-hole 0.75in center spacing, on right side of cabinet back.

Fig. 4-1 Ground connection for NPFC Series Batteries

Preferred

Forbidden (Except for 48NPFC10, 48NPFC20, 48NPFC100-19)

Alternate

3.Battery output connection

■ Connect ‘+’ of battery output with positive copper bar of power plant, and ‘-’ with negative copper

bar or power switch.

■ If multi battery modules will be connected in parallel, please take note of follows:

The battery modules connected no more than 8 in parallel.

The minimum spacing between batteries is 10mm.

Connect ‘+’ of battery output of each battery module with positive copper bar of power plant,

and ‘-’ with negative copper bar of power plant or power switch separately.

Length of cable between battery module and power plant shall be less than 2.0m. To make sure

similar voltage drop of cable for each battery, length of all positive and negative cables should be

the same.

■ Color for cable between ‘+’ and positive bar is suggested as RED, and cable between ‘-’ and

negative as BLACK.

■ The picture of paralleling connection for NPFC Series Batteries see Fig. 4-2. There is a tray under

each battery to support the battery.

13 14

Fig. 4-2 Layout of paralleling connection for NPFC Series Batteries

4.Power on for battery module

■ When installation is accomplished, battery module is in dormant state. Once power on for the

power plant and battery module, battery will go into normal running status, and discharge/charge

can be available.

■ Parameter settings for lithium battery modules in power plant are shown in Table 3-1.

NPFC Series

Fig. 4-3 How to handle the empty RS485 port for NPFC Series Batteries

LiFePO4 Battery Module for Telecom

6.Discharge with dummy load

■ Dummy load cannot be larger maximum discharge current of each battery model according to the

datasheet, and BLVD is larger than 43.2V.

■ Voltage drop on cable between battery module and power plant shall be less than 0.5V. Method of

calculation for cross sectional area of cable is shown as below.

A=ΣI×L/(K×△U)

In the above formula, A is across sectional area of wire (mm2), ΣI is the total current (A), L is length

of cable, △U is the permit voltage drop on cable (V), and K is electrical conductivity of wire. For

example, for copper, K = 57.

5.RS232/RS485 communication connection

■ If there is only one battery module in operation, communication between battery module and

computer can available through RS485.

■ If there are more than one battery modules in operation, parallel communication can be available

using RS485.

■ The last battery in each rack have an empty RS485 port for CAN cable terminal resistor. The other

end of communication cable, use the electric tape to seal it.

■ RS232 communication port just for software upgrade.

■ Communication protocols for RS485 are shown in Annex 3.

■ Dry contact should be connected when battery connected in electric circuit.

15 16

NPFC Series

LiFePO4 Battery Module for Telecom

Maintenance Chapter Five/05

General

Proper maintenance will prolong the life of a battery and will aid in assuring that it can satisfy its

design requirements. A good battery maintenance program will serve as a valuable aid in determining

the need for battery replacement. The users must consider their application and reliability needs

if maintenance procedures, other than those recommended in this document, are used. Battery

maintenance should be performed by personnel knowledgeable of batteries and the safety

precautions involved.

■ The battery shall be recharged every three months if in long time storage

■ Please clean the dust by the dust collector when dust is accumulated on vent

■ Please use clean and dry cloth/fabric to clean up the cabinet, if need further cleaning, please use

neutral cleanser. Alcohol or ammonia synthesis is forbidden.

■ Carrying shall be handled gently, prevent from severe compact

■ Prevent battery from splashing liquid

■ Suggest inspect the tighten of output screw every two years

Troubleshooting and Solutions

Table 5-1 Troubleshooting and Solutions

Troubles Solutions

Protection against under-voltage

Protection against over-temperature or under-

temperature (cell temperature is lower than -20°C

or higher than 70°C)

Battery cannot

discharge

Battery output is short circuit

Protection against over current

System failure

Battery is fully charged. Normal charge

management

Protection against over voltage

Troubleshooting

Charge battery

Regulate cell temperature in

the range of -20°C to 70°C for

discharge

Relieve short circuit and charge

battery

Remove some unimportant load

and charge battery

Shutdown system and call

maintenance service

Do not need to solve

Battery cannot

charge

All LED indicators

Communication

failure

Protection against over-temperature or under-

temperature (cell temperature is lower than -10°C

or higher than 70°C)

System failure

Fault of communication cable

Halt of System communication management

System failure

Regulate cell temperature in the

range of 0°C to 55°C for charge

Shutdown system and call

maintenance service

Shutdown system

Call for maintenance service

Inspect communication cable

Press RESET button

Shutdown system

Call for maintenance service

Different ash status of LED indicators represents corresponding running status or alarms. Detailed

information is shown Annex 1.

Note: The improvement of product and technology, and the possible of battery specication and appearance changes, Narada hold the right of nal explanation!

NPFC Series

LiFePO4 Battery Module for Telecom

Annex 1-Instructions for LED Flash

Annex Table 1.1 – SOC LED Indicators Description

○

Note: mean light on, ○ mean light off

Annex Table 1.2 – RUN Indicators Description

Flash Status

Flash 1

Flash 2

Activation state, but neither charge nor discharge

○

Running Status of Battery

Charging state

Annex 2 – Instructions for ADD Dip Switch

ADD Dip Switch is applicable to modules connected in parallel. ADD consists of four binary bits

SOC

75% ~ 100%

○

50% ~ 75%

25% ~ 50%

0% ~ 25%

Annexed Table 2.1 – Instruction for Addresses of Communication

Instructions for ADD Dialing

1 2 3 4

OFF

Module No.

Default ADD

PACK 1

PACK 2

PACK 3

PACK 4

PACK 5

PACK 6

PACK 7

PACK 8

Binary

Code

0000

0001

0010

0011

0100

0101

0110

0111

1000

Continue light

Extinguish

Discharging state

Dormant state

Annex Table 1.3 – ALM Indicators Description

Flash Status

Extinguish

Flash 2

Flash 3

Extinguish

Alarm Information of Battery

Minor Alarm(Various Alarm Status)

Fail(Various fail)

Major Alarm(Various protection status)

Normal, no alarm

Annex Table 1.4 – Flash Instruction of LED Indicators

ON OFF

Flash 1

0.25s

3.75s

Annexed Table 2.2 – Instruction of ADD for Parallel Communication

Default

0000

Note: Counting of ADD must begin from 0001, without interruption, or parallel communication cannot be available

PACK 1

0001

PACK 5

0101

PACK 2

0010

PACK 6

0110

PACK 3

0011

PACK 7

0111

PACK 4

0100

PACK 8

1000

Flash 2

Flash 3

19 20

0.5s

1.5s

NPFC Series

LiFePO4 Battery Module for Telecom

Annex 3 – Communication Protocol for RS232 and RS485

There is one RS232 port in front panel for software upgrade, and one RS485 port in front panel

for communication between battery and PC, also for communication between battery modules

connected in parallel.

Annex Table 3.1 – RJ11 Pins Assignment (RS232)

RJ11 Pins

RJ45 Pins

4,5,6,7,8

Denition

GND

Pack receipt,

computer delivery

Pack delivery,

computer receipt

No connection

2 RXD Receive data - From battery to computer

3 TXD Deliver data - From computer to battery

5 GND – Signal ground

Annex Table 3.2 – RJ45 Pins Assignment (RS485)

Denition

GND

RS485_A

RS485_B

No connection

Sketch

Annex 4 – LCD Menu Instruction

Press “MENU” to enter the following interface Welcome Battery manage system

The “Battery Parameters” subdirectory

■ Voltage: xxxx V

■ Current: xxxx A (charge:+, discharge:-)

The “Battery Temperature” Subdirectory

■ Temperature01:xx°C

■ Temperature02:xx°C

■ Temperature03:xx°C

■ Temperature04:xx°C

■ PCB Temperature: xx°C

■ Environment Temperature: xx°C

■ The “Cell Voltages” Subdirectory

■ Cell01: xxxx mV

■ Cell02: xxxx mV

■ Cell03: xxxx mV

■ Cell04: xxxx mV

■ Cell05: xxxx mV

■ Cell06: xxxx mV

■ Cell07: xxxx mV

■ Cell08: xxxx mV

■ Cell09: xxxx mV

■ Cell10: xxxx mV

■ Cell11: xxxx mV

■ Cell12: xxxx mV

■ Cell13: xxxx mV

■ Cell14: xxxx mV

■ Cell15: xxxx mV

■ Cell16: xxxx mV

■ SOC: xxxx%

■ Nominal Capacity: xxxx Ah

The “Battery parameter settings” Subdirectory Non-manufacturers cannot enter 10 NPFC series LiFePO4 Battery System for Telecommunication Operation manual V1.0 The “Version Information” Subdirectory

Press “MENU” next Press “MENU” to enter the following interface Battery parameters query Battery status Battery parameter settings Version Information

The ‘Battery Status’ Subdirectory

■ Status: IDLE/CHARGE/DISCHARGE

■ “Alarm status” Subdirectory

■ Overvoltage alarm YES/NO

■ Under voltage alarm YES/NO

■ Over temperature YES/NO

■ Under voltage alarm YES/NO

■ Under capacity alarm YES/NO

■ Difference voltage YES/NO

■ Overcurrent YES/NO

■ Charger Reverse alarm YES/NO

■ “Protection status” Subdirectory

■ Overvoltage protect YES/NO

■ Under voltage protect YES/NO

■ Over temperature protect YES/NO

■ Under temperature protect YES/NO

■ Over current protect YES/NO

■ Short current protect YES/NO

■ “Fail alarm” Subdirectory

■ Sampling line: OK/ERROR

■ Charge MOSFET: OK/ERROR

■ Discharge MOSFET: OK/ERROR

■ Sampling chip: OK/ERROR

■ Short current times: xxxx

■ Temperature protect times: xxxx

■ Over protect times: xxxx

■ Over current times: xxxx

■ Under voltage times: xxxx

■ “BMS version” Subdirectory

■ BMS software version

■ BMS hardware version

21 22

■ The “LCD version” Subdirectory

■ LCD software version:

■ LCD hardware version:

After-sale Services

NARADA POWER SOURCE CO., LTD.

Building A, No.822 Wen'er West Road, Hangzhou, Zhejiang, China Tel: +86-571-56975980 Fax: +86-571-56975955 Website: en.naradapower.com E -mail: intl@narada.biz

NARADA ASIA PACIFIC PTE. LTD.

Block 9 Khaki Bukit Road 1 #02-10 Eunos Technolink, Singapore 415938 Tel: +65-6848 1191 Fax: +65-6749 3498 Website: www.narada-ap.com Email: sales@narada-ap.com

NARADA EUROPE (UK) LIMITED

Spectrum House, Dunstable Road, Redbourn, St. Albans, Herts Al3 7PR Tel: +44 (0)845 612 2031 Fax: +44 (0)845 612 2031 E-mail: sales@naradaeurope.com

Narada NPFC, 48NPFC10, 48NPFC80 (3U), 48NPFC80 (5U), 48NPFC100 (5U 19”) Operation Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
