Napoleon WHVF24N Installation Manual

INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
INSTALLATION AND
OPERATING INSTRUCTIONS
CERTIFIED UNDER AMERICAN NATIONAL STANDARDS: ANSI Z21.11.2 FOR UNVENTED ROOM HEATERS.
FOR INDOOR USE ONLY
WHVF24N
SAFETY INFORMATION
!
WARNING
If the information in these instructions are not followed exactly, a fi re or explosion may result causing property damage, personal injury or loss of life.
- Do not store or use gasoline or other fl ammable vapors and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch; do not use any phone in your building.
Immediately call your gas supplier from a neighbour’s phone. Follow the gas supplier’s instructions.
If you cannot reach your gas supplier, call the fi re department.
- Installation and service must be performed by a qualifi ed installer, service agency or the supplier.
- This is an unvented gas-fi red heater that uses air (oxygen) from the room in which it is installed. Provisions for adequate combustion and ventilation air must be provided. Refer to section “ COMBUSTION AND VENTILATION AIR PROVISIONS”.
This appliance may be installed in an aftermarket, permanently located, manufactured (mobile) home, where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases.
!
NATURAL GAS
WHVF24P
PROPANE
WARNING
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
EN
103 Miller Drive, Crittenden, Kentucky, USA, 41030
Phone (705)721-1212 • Fax (705)722-6031 • www.napoleonfi replaces.com • hearth@napoleonproducts.com
$10.00
1.43A
W415-1158 / B / 01.09.17
2
TABLE OF CONTENTS
EN
1.0 INSTALLATION OVERVIEW 3
2.0 INTRODUCTION 4
2.1 DIMENSIONS 5
2.2 GENERAL INSTRUCTIONS 5
2.3 GENERAL INFORMATION 6
2.4 RATING PLATE INFORMATION 7
3.0 INSTALLATION 8
3.1 COMBUSTION AND VENTILATION AIR PROVISIONS 8
3.2 DETERMINING CONFINED OR UNCONFINED SPACE 8
3.3 GAS INSTALLATION 10
3.4 MOBILE HOME 10
3.5 MOUNTING THE APPLIANCE 11
3.6 MINIMUM CLEARANCE TO COMBUSTIBLES 13
4.0 FINISHING 14
4.1 SURROUND INSTALLATION / REMOVAL 14
4.2 DOOR REMOVAL / INSTALLATION 15
4.3 GLASS MEDIA 16
5.0 IGNITION SYSTEM DIAGRAM 16
6.0 OPERATION 17
6.1 LIGHTING AND OPERATING INSTRUCTIONS 17
7.0 ADJUSTMENTS 18
7.1 VENTURI ADJUSTMENT 18
7.2 FLAME CHARACTERISTICS 18
8.0 MAINTENANCE 19
8.1 ANNUAL MAINTENANCE 20
8.2 CARE OF GLASS 21
8.3 CARE OF PLATED PARTS 21
8.4 DOOR GLASS REPLACEMENT 21
9.0 REPLACEMENTS 22
9.1 OVERVIEW 23
10.0 TROUBLESHOOTING 24
11.0 WARRANTY 25
NOTE: Changes, other than editorial, are denoted by a line in the margin.
W415-1158 / B / 01.09.17
1.0 INSTALLATION OVERVIEW
Mantel, see “MINIMUM CLEARANCES TO COMBUSTIBLES” section.
Side Wall
3
EN
Rating plate, see “RATING PLATE INFORMATION” section.
Surround, see “FINISHING” section.
Side Wall, see “MINIMUM CLEARANCES TO COMBUSTIBLES” section.
Batteries must be disposed of according to the local laws and regulations. Some batteries may be recycled, and may be accepted for disposal at your local recycling center. Check with your municipality for recycling instructions.
W415-1158 / B / 01.09.17
4
2.0 INTRODUCTION
EN
(
!
WARNING
THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED.
ANY CHANGES TO THIS APPLIANCE OR ITS CONTROLS CAN BE DANGEROUS AND IS PROHIBITED.
Under no circumstances should this appliance be modifi ed.
Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to operating instructions could cause fi re or injury.
Risk of burns. The appliance should be turned off and cooled before servicing.
Do not install damaged, incomplete or substitute components.
Risk of cuts and abrasions. Wear protective gloves and safety glasses during installation. Sheet metal edges may be sharp.
Provide adequate ventilation and combustion air. Provide adequate accessibility clearance for servicing and operating the appliance. Never obstruct the front opening of the appliance.
If the appliance shuts off, do not re-light until you provide fresh air. If appliance keeps shutting off, have it serviced. Keep burner and control compartment clean.
Do not burn wood or other materials in this appliance.
Children and adults should be alerted to the hazards of high surface temperature and should stay away to
avoid burns or clothing ignition.
Young children should be carefully supervised when they are in the same room as the appliance. Toddlers,
young children and others may be susceptible to accidental contact burns. A physical barrier is recommended if there are at risk individuals in the house. To restrict access to an appliance, install an adjustable safety gate to keep toddlers, young children and other at risk individuals out of the room and away from hot surfaces.
Due to high temperatures, the appliance should be located out of traffi c and away from furniture and draperies.
Ensure you have incorporated adequate safety measures to protect infants/toddlers from touching hot surfaces.
Clothing or other fl ammable material should not be placed on or near the appliance.
Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from hot surfaces. These screens and guards must be fastened to the fl oor.
Any safety screen or guard removed for servicing must be replaced prior to operating the appliance.
It is imperative that the control compartments, burners and circulating blower and its passageway in the appliance are kept clean. The appliance should be inspected before use and at least annually by a qualifi ed service person. More frequent cleaning may be required due to excessive lint from carpeting, bedding material, etc. The appliance area must be kept clear and free from combustible materials, gasoline and other ammable vapours and liquids.
Furniture or other objects must be kept a minimum of 4 feet (1.2m) away from the front of the appliance.
Do not use this appliance if any part has been under water. Immediately call a qualifi ed service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water.
Do not allow fans to blow directly into the appliance. Avoid any drafts that alter burner fl ame patterns.
Do not use a blower insert, heat exchanger insert or other accessory not approved for use with this appliance.
Carbon or soot should not occur in a vent free appliance as it can distribute into the living area of your home. If you notice any signs of carbon or soot, immediately turn off your appliance and arrange to have it serviced by a qualifi ed technician before operating it again.
Keep the packaging material out of reach of children and dispose of the material in a safe manner. As with all plastic bags, these are not toys and should be kept away from children and infants.
As with any combustion appliance, we recommend having your appliance regularly inspected and serviced as well as having a Carbon Monoxide Detector installed in the same area to defend you and your family against Carbon Monoxide.
If equipped, the screen must be in place (closed) when the appliance is in operation.
Ensure clearances to combustibles are maintained when building a mantel or shelves above the appliance. Elevated temperatures on the wall or in the air above the appliance can cause melting, discolouration or damage to decorations, a T.V. or other electronic components.
3.4C
W415-1158 / B / 01.09.17
2.1 DIMENSIONS
22"
559mm
19 1/4"
18 1/2"
470mm
32 3/8"
822mm
8 3/4"
222mm
6 7/8"
175mm
487mm
1 1/4” [32mm]
23 3/4"
1 3/4”
[44mm]
GAS INLET OPTION 2
605mm
2 1/2”
[63mm]
2 1/2”
[63mm]
2.2 GENERAL INSTRUCTIONS
!
WARNING
* CARBON MONOXIDE POISONING MAY LEAD TO DEATH
EARLY SIGNS OF CARBON MONOXIDE POISONING RESEMBLE THE FLU, WITH HEADACHE,
DIZZINESS AND/OR NAUSEA. IF YOU HAVE THESE SIGNS, THE HEATER MAY NOT BE WORKING
PROPERLY. GET FRESH AIR AT ONCE! HAVE HEATER SERVICED.
SOME PEOPLE SUCH AS PREGNANT WOMEN, PERSONS WITH HEART OR LUNG DISEASE,
ANEMIA, THOSE UNDER THE INFLUENCE OF ALCOHOL, THOSE AT HIGH ALTITUDES, ARE MORE
AFFECTED BY CARBON MONOXIDE THAN OTHERS.
1 3/4”
[44mm]
2 1/2”
[63mm]
5
GAS INLET OPTION 1
2 1/8”
[54mm]
EN
FAILURE TO KEEP THE PRIMARY AIR OPENING(S) OF THE BURNER(S) CLEAN MAY RESULT IN
SOOTING AND PROPERTY DAMAGE.
THE APPLIANCE IS ONLY FOR USE WITH THE TYPE OF GAS INDICATED ON THE RATING PLATE.
THIS APPLIANCE IS NOT CONVERTIBLE FOR USE WITH OTHER GASES. THIS APPLIANCE IS
INTENDED FOR SUPPLEMENTAL HEATING.
OBJECTS PLACED IN FRONT OF THE HEATER SHOULD BE KEPT A MINIMUM OF 48” (1219.2mm)
AWAY FROM THE FRONT FACE OF THE APPLIANCE. KEEP APPLIANCE AREA CLEAR AND FREE
FROM COMBUSIBLE MATERIALS, GASOLINE AND OTHER FLAMMABLE VAPORS AND LIQUIDS.
USE ONLY WOLF STEEL APPROVED OPTIONAL ACCESSORIES AND REPLACEMENT PARTS WITH
THIS APPLIANCE. USING NON-LISTED ACCESSORIES AND REPLACEMENT PARTS (BLOWERS,
LOUVRES, TRIMS, GAS COMPONENTS, VENT COMPONENTS, ETC.) COULD RESULT IN A SAFETY
HAZARD AND WILL VOID THE LIMITED LIFETIME WARRANTY.
THIS APPLIANCE MUST NOT BE INSTALLED IN A BATHROOM.
DO NOT OPERATE WITHOUT CERAMIC CATALYST IN PLACE.
This gas appliance should be installed and serviced by a qualifi ed installer to conform with local codes. Installation practices vary from region to region and it is important to know the specifi cs that apply to your area, for example: in Massachusetts State:
The appliance off valve must be a “T” handle gas cock.
• The fl exible connector must not be longer than 36” (914.4mm).
The appliance is not approved for installation in a bathroom unless the appliance is a direct vent sealed combustion product.
A carbon monoxide detector is required in all rooms containing gas fi red appliances.
• WARNING: This product must be installed by a licensed plumber or gas fi tter when installed within the commonwealth of Massachusetts.
Un-vented room appliance shall be installed in accordance with 527 CMR 30.00 and 248 CMR 3.00 through 7.00.
Sellers of un-vented propane or natural gas-fi red space / room appliances shall provide to each purchaser a copy of 527 CMR 30.00 upon the sale of the appliance from http://www.napoleonfi replaces. com/ Webshare/installation_manuals/mass_requirements.pdf
W415-1158 / B / 01.09.17
EN
6
In absence of local codes, install the appliance to the current National Fuel Gas Code, ANSI Z223.1 Installation Code which can be obtained from:
American National Standards Institute Inc. or National Fire Protection Association Inc.
1430 Broadway Batterymarch Park New York, NY 10018 Quincy, MA 02269
The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (35mb). The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psig (35mb). When installed with a blower the junction box must be electrically connected and grounded in accordance with local codes. In the absence of local codes, use the current ANSI / NFPA 70 National Electric Code. In the case where the blower is equipped with a power cord it must be connected into a properly grounded receptacle. The grounding prong must not be removed from the cord plug.
www.ncertied.org
As long as the required clearance to combustibles is maintained, the most desirable and benefi cial location for the appliance is in the center of a building, thereby allowing the most effi cient use of the heat created. The location of windows, doors and the traffi c fl ow in the room where the appliance is to be located should be considered.
* Air shortage caused by an inadequate air supply, improper log positions, the addition of foreign or unapproved materials or the failure to properly maintain the appliance, may result in incomplete combustion of the fuel. Incomplete combustion results in soot being deposited inside the fi rebox as well as surfaces outside the appliance. If any soot deposits are observed, shut off the appliance immediately and arrange for it to be serviced by a qualifi ed technician. Incomplete combustion can also generate increased levels of carbon monoxide (CO).
We suggest that our gas hearth products be installed and serviced by professionals who are certied in the U.S. by the National Fireplace Institute Specialists
®
(NFI) as NFI Gas
2.3 GENERAL INFORMATION
FOR YOUR SATISFACTION, THIS APPLIANCE HAS BEEN TEST-FIRED TO ASSURE ITS OPERATION AND QUALITY!
RATES AND EFFICIENCIES
NATURAL GAS PROPANE GAS
Altitude 0-2000* 0-2000*
Maximum Input 9,000 BTU/hr (2.6kw/hr) 9,000 BTU/hr (2.6kw/hr)
Effi ciency 99.9% 99.9%
Minimum Inlet Gas Supply Pressure 4.5” Water Column (11.2mb) 11” Water Column (27.3mb)
Maximum Inlet Gas Supply Pressure 7” Water Column (17.4mb) 13” Water Column (32.8mb)
Manifold Pressure Under Flow Conditions 3.5” Water Column (8.7mb) 10” Water Column (25mb)
* When the appliance is installed at elevations above 2,000ft (609.6m), and in the absence of specifi c recommendations from the local authority having jurisdiction, the certifi ed high altitude input rating shall be reduced at the rate of 4% for each additional 1,000ft (304.8m).
This appliance is suitable for mobile home installation. The natural gas model can only be installed in a mobile home that is permanently positioned on its site and fueled with natural gas. This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases.
The appliance is equipped with two catalytic tiles which are designed to fi lter out harmful gases and limit carbon monoxide output. It is likely that with the appliance in operation, the catalytic tiles will actually scrub the carbone monoxide normally found in the room and reduce it to a lower level. The tiles must not be altered or removed. Do not operate the appliances when using products such as paint, paint thinner, adhesives, etc. These products will permanently affect the catalytic tiles’ ability to scrub the air.
Expansion / contraction noises during heating up and cooling down cycles are normal and are to be expected.
W415-1158 / B / 01.09.17
2.4 RATING PLATE INFORMATION
7
For rating plate location, see “INSTALLATION OVERVIEW” section.
This illustration is for reference only. Refer to the rating plate on the appliance for accurate information.
NOTE: The rating plate must remain with the appliance at all times. It must not be removed.
CERTIFIED UNDER: ANSI Z21.11.2-2011 UNVENTED ROOM HEATER THIS APPLIANCE SHALL NOT BE INSTALLED IN BATHROOM, AND IS INTENDED FOR SUPPLEMENTAL HEATING. THIS APPLIANCE MAY BE INSTALLED IN AN AFTERMARKET, PERMANENTLY LOCATED, MANUFACTURED (MOBILE) HOME, WHERE NOT PROHIBITED BY LOCAL CODES. THIS APPLIANCE IS ONLY FOR USE WITH THE TYPE OF GAS INDICATED ON THE RATING PLATE. THIS APPLIANCE IS NOT FIELD CONVERTIBLE FOR USE WITH OTHER GASES. THIS IS A GAS-FIRED UNVENTED ROOM HEATER THAT REQUIRES ADEQUATE COMBUSTION AND VENTILATION AIR.
WHVF24N CWHVF24N
*0-2000FT ALTITUDE *0-2000FT 9,000 BTU/HR INPUT 9,000BTU/HR
BQ902C01 CONTROL BQ902C01
BENAN 20310 (NG) PILOT
*ABOVE 2,000FT, CONSULT LOCAL AUTHORITY HAVING JURISDICTION.
MANIFOLD PRESSURE: 3.5” WATER COLUMN (NG) MIN. SUPPLY PRESSURE: 4.5” WATER COLUMN (NG) MAX. SUPPLY PRESSURE: 7” WATER COLUMN (NG)
MANIFOLD PRESSURE: 10” WATER COLUMN (LP) MIN. SUPPLY PRESSURE: 11” WATER COLUMN (LP) MAX. SUPPLY PRESSURE: 13” WATER COLUMN (LP)
CERTIFIED FOR / CERTIFIEE
POUR CANADA / USA
REFERENCE # 161746
WHVF24PCWHVF24P
BENAN 20310 (LP)
LEDOM ENAPORP LEDOM SAG LARUTAN
EN
NOT FOR USE WITH SOLID FUEL
WARNING: DO NOT ADD ANY MATERIAL TO THE APPLIANCE,
WHICH WILL COME IN CONTACT WITH THE FLAME. DO NOT USE ACCESSORIES NOT APPROVED FOR USE WITH THIS APPLIANCE. APPLY LOOSE MATERIAL PER INSTRUCTIONS MANUAL. DO NOT APPLY EXTRA MATERIAL OR MATERIAL NOT SUPPLIED WITH THE APPLIANCE. IMPROPER INSTALLATION, ADJUSTMENT, ALTERNATION, SERVICE OR MAINTENANCE CAN CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. REFER TO THE OWNER’S INFORMATION MANUAL PROVIDED WITH THIS APPLIANCE. INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER, SERVICE AGENCY OR THE GAS SUPPLIER.
MINIMUM CLEARANCE TO COMBUSTIBLE MATERIAL (FROM APPLIANCE):
MANTEL 20” FLOOR 10” SIDES 7”
WOLF STEEL LTD.
24 NAPOLEON ROAD, BARRIE, ON, L4M 0G8 CANADA
SERIAL NUMBER
WHVF24
W385-1902_B
W415-1158 / B / 01.09.17
A
A
8
3.0 INSTALLATION
EN
3.1 COMBUSTION AND VENTILATION AIR PROVISIONS
This appliance shall not be installed in a confi ned space or unusually tight construction unless provisions are provided for adequate combustion and ventilation air.
The National Fuel Gas Code, ANSI Z223.1 / NFPA 54 defi nes a confi ned space as a space whose volume is less than 50 cubic feet per 1,000 Btu per hour (4.8 m3 per kw) of the aggregate input rating of all appliances installed in that space and an unconfi ned space as a space whose volume is not less than 50 cubic feet per 1,000 Btu per hour (4.8 m3 per kw) of the aggregate input rating of all appliances installed in that space. Rooms communicating directly with the space in which the appliances are installed, through openings not furnished with doors are considered a part of the unconfi ned space.
17.1A
The WHVF24 is rated at 9,000 BTUs per hour for natural gas and propane and therefore requires a minimum unconfi ned space of 450 cubic feet.
3.2 DETERMINING CONFINED OR UNCONFINED SPACE
To determine the volume of the room where the appliance is to be installed, multiply the width x the length x the ceiling height of that room measured in feet. If any adjoining rooms are connected by grilles or openings such as kitchen pass-throughs, etc., the volume of those rooms may be added to the total.
Multiply the room volume by 1000 and divide this amount by 50 to determine the maximum BTU/hr that the space can support with adequate combustion and ventilation air.
dd the Btu/hr of all fuel burning appliances located within the space such as gas furnace, gas water appliance, etc. Do not include direct vent gas appliances which draw their input and output air from and to the outdoors.
!
IF THE AREA IN WHICH THE APPLIANCE MAY BE OPERA TED IS SMALLER THAN THAT DEFINED AS
AN UNCONFINED SP ACE OR IF THE BUILDING IS OF UNUSUALLY TIGHT CONSTRUCTION, PROVIDE
ADEQUA TE COMBUSTION AND VENTILATION AIR BY ONE OF THE METHODS DESCRIBED IN THE
NA TIONAL FUEL GAS CODE ANSI Z223.1/ NFPA 54 , AIR FOR COMBUSTION AND VENTILATION, OR THE
APPLICABLE LOCAL CODE.
IF THE AREA IN WHICH THE APPLIANCE MAY BE OPERA TED DOES NOT MEET THE REQUIRED VOLUME
FOR INDOOR COMBUSTION AIR, COMBUSTION AND VENTILATION AIR SHALL BE PROVIDED BY ONE
OF THE METHODS DESCRIBED IN THE ANSI Z223.1 / NFPA 54, THE INTERNATIONAL FUEL GAS CODE,
OR APPLICABLE LOCAL CODES.
Unusually tight construction is defi ned as construction where: A) Walls and ceilings exposed to the outside atmosphere have a continuous water vapour retarder with a
rating of 1 perm (6 x 10-11 kg per pa-sec-m2) or less with openings gasketed or sealed, and
B) Weather stripping has been added on openable windows and doors, and C) Caulking or sealants are applied to areas such as joints around window and door frames, between sole
plates and fl oors, between wall-ceiling joints, between wall panels, at penetrations for plumbing, electrical, and gas lines, and at other openings.
n unvented room appliance is recommended for use as a secondary heat source rather than as a primary source. Gas combustion produces water vapour which could occur at the rate of approximately one ounce of water for every 1,000 BTU/hr of gas input. During the cold weather season, indoor humidity levels tend to be low. Consequently, this water vapour can enhance the living space. However if a problem should occur:
A) Ensure suf cient combustion and circulation air B) Use a dehumidi er C) Do not use the unvented room appliance as a primary heat source
Without suffi cient fresh air for proper operation, poor fuel combustion can result. Carbon Monoxide is a result of poor combustion. If additional fresh air is required, use one of the methods described in the National Fuel Gas Code, ANSI Z223.1 / NFPA54 or the applicable local code.
WARNING
W415-1158 / B / 01.09.17
