Why
• Perfect for around the pool and patio
• Ideal for cafés and outdoor restaurants
• Fits into almost any space
• Residential and commercial applications
N
the heater to wherever you want the warmth! Napoleon
infrared radiant heat rays which heat objects rather than the surrounding air,
keeping you cozy and warm by the pool, spa or on your deck long after the sun
goes down. Infrared heat provides efficient, clean burning performance and
uses less fuel while providing ultimate comfort.
Why fight with extension cords, Napoleon’s patio heaters operate using a
concealed propane cylinder, requiring no electricity; natural gas models are also
available to further increase fuel efficiency. The control panels are conveniently
placed, and safely out of reach for children.
Napoleon
featuring an easy access door on propane models and are designed for
permanent outside storage.
The visual appeal and radiant warmth of these modern, long life patio heaters
are a welcome feature at popular hotels and resorts, fine restaurants and cafés,
golf clubs, spas and ski lodges as well as residential patios. These professional,
commercial or lifestyle quality heaters are available for your own personal
pleasure in the privacy of your own yard. Napoleon
complement any backyard, patio, or pool space. Go ahead, extend your day in
the outdoors!
a Napoleon®patio heater?
apoleon®patio heaters allow you to extend outdoor activities during the
fall and kick off summer several weeks early to enjoy an evening
barbecue, early morning coffee, or any other entertaining event. Move
®
patio heaters are constructed of stainless steel or cast aluminum,
®
patio heaters generate
®
patio heaters will
Specifications
Product
Commercial
PTH2650SS
Commercial
PTH2650SSN
Lifestyle
PTHC38PK
Lifestyle
PTHC38NK
Lifestyle
PTH38PGM
Lifestyle
PTH38PSS
Lifestyle
PTH38PCP
Output
45,000
BTU
(12KW)
45,000
BTU
(12KW)
40,000
BTU
(11KW)
40,000
BTU
(11KW)
40,000
BTU
(11KW)
40,000
BTU
(11KW)
40,000
BTU
(11KW)
Material
304
Stainless Steel
304 Stainless Steel
Cast Aluminum
Body
Cast Aluminum
Body
304 Stainless Steel
with Gun Metal
Finish
304
Stainless Steel
304 Stainless Steel
with
Copper Finish
Igniter
Direct
Electronic
Ignition to
Main Burner
Continuous Spark
Direct
Electronic
Ignition to
Main Burner
Continuous Spark
Electronic
Pilot
Continuous
Ignition
Spark
Electronic
Pilot
Continuous
Ignition
Spark
Electronic
Pilot
Ignition
Continuous
Spark
Electronic
Pilot
Continuous
Ignition
Spark
Electronic
Pilot
Continuous
Ignition
Spark
Wheels
S
-
-
-
o
o
o
Table
-
-
-
-
o
o
o
Option
Heat Area
25'
25'
20'
20'
20'
20'
20'
(Diameter)
Adjustable
25,000 -45,000
Adjustable
25,000 -45,000
Adjustable
25,000 -40,000
Adjustable
25,000 -40,000
Adjustable
25,000 -40,000
Adjustable
25,000 -40,000
Adjustable
25,000 - 40,000
Heat Control
LP
NG
LP
NG
LP
LP
LP
LP/NG
Product Size
231cm x
70cm
91" x 31"
231cm x
70cm
91" x 31"
231cm x 79cm
91" x 31"
231cm x 79cm
91" x 31"
227cm x 79cm
89 1/2" x 31"
227cm x 79cm
89 1/2" x 31"
227cm x 79cm
89 1/2" x 31"
HxW
(cm & inches)
Optional Patio
Heater Cover
Fits any of the full size
patio heaters (including
those with optional table).
Made from heavy-duty
PVC material.
Easily accessible zipper
allows for quick removal
of cover.
#63800
Napoleon
®
Patio Heaters
Outdo or entertainment… anyw her e, anytime of the year !
Dare to compare!
Unlike most models available on the market which utilize carbon steel
beneath pre-coated finishes, Napoleon’s copper and gun metal finishes
are pre-coated over 304 stainless steel eliminating the possibility of rust.
Standard Features
• Adjustable heat control
• Wind re sistant desi gn
• Directs heat downwards
• Heats up to a 25' diameter
• Stainless steel emitter grids for optimal performance
• Concealed propane tank on LP models
• Aluminum reflector for direct heat
www.napoleonproducts.com
Table Top
PTH10PSS
S - standard, O - optional
Fireplace Inserts
All specifications and designs are subject to change without prior notice due to ongoing product improvements. Consult your owner’s manual for complete installation and operating instructions and check all local and national Building Codes and
Regulations. Not all features available on all models. Napoleon® is a registered trademark of Wolf Steel Ltd.Patent U.S.5, 676, 048-5, 617,778,DES433875,417497, Patents Pending. Images and colours may not be exactly as shown.
10,000
BTU
(2.9KW)
Outdoor Living
• 103 Miller Drive, Crittenden, Kentucky, USA41030
• 24 Napoleon Road, Barrie, Ontario, Canada L4M 4Y8
• 214 Bayview Drive, Barrie, Ontario, Canada L4N 4Y8
• 7200 Trans Canada Highway, Montreal, Quebec H4T 1A3
• Pomona, California, USA 91766
Fireplaces Call: 705-721-1212 • Grills Call: 705-726-4278
www.napoleonfireplaces.com • www.napoleongrills.com
304
Stainless Steel
Oil Stoves
Electronic
Igniter
Other Napoleon Products
Cast Iron Gas Stoves
-
Waterfalls Vent Free Fireplaces Electric Fireplaces Gas Fireplaces Gourmet Grills
7'
-
-
LP
103cm x
52cm
40 1/2" x 20
1/2"
Authorized Dealer
Printed in Canada
ADBRPH 12/2007
Features
RADIANT WARMTH with superior technology
& Benefits
High output, fuel efficient burner
Easy to use contr ol s
Commercial Series
Double Grate Conical Burner provides low
energy consumption with high heat output
Heavy Duty Outside
Perforated Stainless
Steel Screen
generates infrared
rays dir e c tin g he a t
where it’s needed
Inside “Insulator” Emitter
maintains high temperature
Perforated Stainless Steel Screen encases
valve for safety and provides cooling and
secondar y air for combustion
Dual Cone Shape Emitter
directs heat downward
allowing for more
effi ci ent heat
Heavy Duty Stainless
Steel Burner
Direct Electronic Ignition to
main burner with 100%
SAFEGUARD
Adjustable Heat Control
allows for temperature
modulation when less
heat is require d
TM
shut off
Stainless Steel Patio Heaters
• 304 Stainless steel
• Adjustable heat output
• Up to 45,000 BTU’s
• Direct electronic ignition
• High-output cast
aluminum valve
• Dual conical burner
• Wheels (LP Model) for
moving wherever you
want it
• Available in LP or
natural gas
Lifestyle Collection
Cast Aluminum
Patio Heaters
• Cast aluminum body with
rich pewter look
• Adjustable heat output
• Up to 40,000 BTU’s
• Decorative base
• Electronic ignition
• Available in LP or
natural gas
Table Top Patio Heater
This sleek designed
table-top patio heater
is both portable and
easy to use. With
10,000 BTU’s you can
be sure you and your
guests will be able to
enjoy an extended
time outdoors. Uses
1lb propane bottle or
optional 4’ hose to a
20lb tank.
PTH10PSS
Stainless Steel Patio Heaters
• Three choices available:
- 304 Stainless steel
- 304 Stainless steel with copper finish
- 304 Stainless steel with gun metal finish
• Adjustable heat output
• Up to 40,000 BTU’s
• Completely self contained, bullet style
• Optional post mount table
• Electronic ignition
• Available in LP only
Features
& Benefits
CONTROL PANEL
• adjustable heat up to
40,000 BTU’s
Durable, long lasting
cast aluminum valve
Easy roll wheels on LP model
for location flexibilit y
High Output Cast Aluminum Valve allows for maximum
45,000 BTU’s, excee ding industry standards
A 25' diameter of radiant
heat casts a warm glow
keeping you warm and
extending your
outdoor
enjoyment
Easy Ele ctr onic Push
Button Star t
Stainless Steel
LP Model: PTH2650SS
BURNER
• durable, high
efficiency burner
Cast Aluminum
LP Model: PTHC38PK
OPTIONAL POST
MOUNT TABLE
(bullet mo de l onl y )
• expands your
entertainment possibilities
Hold down clamps for
extra stabili t y on
natural gas mo dels
Natural Gas Model: PTH2650SSN
Cast Aluminum
Natural Gas Model: PTHC38NK
Copper Finish on 304 Stainless Steel
LP Model: PTH38PCP
Gun Metal Finish on 304 Stainless Steel
LP Model: PTH38PGM
www.napoleonproducts.com
304 Stainless Steel
LP Model: PTH38PSS
