Napoleon PRO285EBK User Manual
www.napoleongrills.com
EN
FR
PG.15
ES
PG.29
APPLY SERIAL NUMBER LABEL FROM CARTON
!
!
Serial No.
XXXXXX000000
MODEL NO.
DO NOT DISCARD
PRO285E
WARNING! POTENTIAL SHOCK HAZARD
WARNING! Failure to follow the instrucons in this manual could result in re or burn hazard
which could cause property damage, personal injury or death. Read and follow all warnings and
instrucons in this manual prior to operang grill.
WARNING!
• For Outdoor Household Use Only
• When using powered appliances, basic safety precauons, including the following, should always
be followed to reduce the risk of fire, electric shock, personal injury and material damage.
• Retain this manual for future reference.
This appliance is rated for
120 VAC - 60 Hz
1500 W
Wolf Steel Ltd.
214 Bayview Drive,
Barrie, Ontario, CANADA L4N 4Y8
grills@napoleonproducts.com
N415-0478 OCT 18.18
www.napoleongrills.com
EN
2
*Conditions and Limitations
This Limited Warranty creates a warranty period as specified in the
aforementioned table, for any product purchased through an authorized NAPOLEON
dealer, and entitles the original purchaser to the specified coverage in respect of
any component replaced within the warranty period, either by NAPOLEON or an
authorized NAPOLEON dealer, to replace a component of such product that has
failed in normal private use as a result of a manufacturing defect. The “50% off”
indicated in the table means the component is made available to the purchaser at
a 50% discount off the regular retail price of the component for the period
indicated. This Limited Warranty does not cover accessories or bonus items.
For greater certainty, “normal private use” of a product means that the product:
has been installed by a licensed, authorized service technician or contractor, in
accordance with the installation instructions included with the product and all
local and national building and fire codes; has been properly maintained; and has
not been used as a communal amenity or in a commercial application.
Similarly, “failure” does not include: over-firing, blow outs caused by
environmental conditions such as strong winds or inadequate ventilation,
scratches, dents, corrosion, deterioration of painted and plated finishes,
discoloration caused by heat, abrasive or chemical cleaners or UV exposure,
chipping of porcelain enameled parts, or damages caused by misuse, accident,
hail, grease fires, lack of maintenance, hostile environments such as salt or
chlorine, alterations, abuse, neglect or parts installed from other manufacturers.
Should deterioration of parts occur to the degree of non-performance (rusted
through or burnt through) within the duration of the warranted coverage, a
replacement part will be provided. The replacement component is the sole
responsibility of NAPOLEON defined by this Limited Warranty; in no event will
NAPOLEON be responsible for installation, labor or any other costs or expenses
related to the re-installation of a warranted part, for any incidental,
consequential, or indirect damages or for any transportation charges, labor costs
or export duties.
This Limited Warranty is provided in addition to any rights afforded to you by local
laws. Accordingly, this Limited Warranty imposes no obligation upon NAPOLEON
to keep parts in stock. Based on the availability of parts, NAPOLEON may at its
discretion discharge all obligations by providing a customer a prorated credit
towards a new product. After the first year, with respect to this Limited Warranty
NAPOLEON may, at its discretion, fully discharge all obligations with respect to
this warranty by refunding to the original warranted purchaser the wholesale price
of any warranted but defective part(s).
The bill of sale or copy will be required together with a serial number and a model
number when making any warranty claims from NAPOLEON.
NAPOLEON reserves the right to have its representative inspect any product or part
prior to honoring any warranty claim. You must contact NAPOLEON Customer Service
or an authorized NAPOLEON dealer to obtain the benefit of the warranty coverage.
napoleongrills.com
Napoleon President’s 10 Year Limited Warranty
NAPOLEON products are designed with superior components and materials, and are assembled by trained craftsmen
who take great pride in their work. This grill has been thoroughly inspected by a qualified technician before packaging
and shipping to ensure that you, the customer, receive the quality product you expect from NAPOLEON.
NAPOLEON warrants that components in your new NAPOLEON product will be free from defects in material and
workmanship from the date of purchase, for the following period:
Aluminum castings / stainless steel base ..........................................10 years
Porcelain-enameled grease shield ................................................... 5 years full coverage, plus 50% off until the 10
th
year
Porcelain-enameled cast iron cooking grids ...................................... 5 years full coverage, plus 50% off until the 10
th
year
Heating element and thermostat ....................................................... 2 years
All other parts .................................................................................... 2 years
N415-0478 OCT 18.18
www.napoleongrills.com
EN
3
!
SAVE THESE INSTRUCTIONS
CAUTION! Risk of electric shock. If an extension cord is used, it must be a grounding-type 3-wire
cord. Its marked electrical rang must be at least as great as the electrical rang of the appliance. Suitable
outdoor extension cords are surface marked with the sux leer “W” and have a tag stang “Suitable for
use with outdoor appliances.” The cord must be arranged so that it will not drape over a tabletop where
it can be pulled by children or tripped over unintenonally. The connecon to the extension cord must be
kept dry and o the ground. Never connect two or more extension cords together.
IMPORTANT SAFEGUARDS
• Use this grill only as described in this manual. Any other use not recommended in this manual may cause fire, electric shock, or
injury to persons.
• Do not use the appliance for other than intended use.
• This grill is intended for outdoor household use only. Do not use indoors or for commercial cooking.
• Do not in any way alter this product or its use.
• Do not use charcoal or other combusble fuels in this grill. This grill is not designed for charcoal use and a fire could result. The
fire could create an unsafe condion and damage to the grill.
• Do not build this model of grill in any built-in or slide-in construcon. Ignoring this warning could cause a fire or an explosion
that may damage property or cause serious bodily injury or death.
• The use of accessory aachments not specifically recommended by Napoleon may cause injuries.
• Do not place on or near a hot gas or electric burner, or in a heated oven.
Electrical Safeguards:
• This appliance conforms to technical standards and the safety requirements for electrical devices.
• Always ensure that the electrical outlet being used has the correct voltage according to the input power of the appliance. Out-
lets must also be suitable for equipment with a power consumpon of 1500 Was.
• Make sure no other high waage appliances are plugged into the same circuit when using grill.
• The appliance must only be connected to a properly grounded outlet.
• The electricity supply should be provided through a residual current device (RCD) having a rated residual operang current not
exceeding 30 mA.
• Do not operate unit if plug receptacle is damaged.
• The power cord should be regularly examined for signs of damage, and the appliance is not to be used if the cord is damaged.
• Do not operate the grill with a thermostat that has a damaged cord or plug. If the supply cord is damaged, it must be replaced
by a special assembly available from Napoleon or a Napoleon authorized dealer.
• Only use the thermostat specified by Napoleon: Z690-0003 (DCT-002B).
Safe Operaon:
• Always plug the thermostat into the grill before plugging the power cord into the outlet. When removing the thermostat from
the grill, unplug it from the outlet first.
• Do not aempt to insert the thermostat unless the element is secured in the base casng.
• Always insert the thermostat into the element with the knob facing upwards.
• Pulling controller by the knob could cause it to come o. Remove thermostat by gripping on its side.
• If a are up occurs, do not use water to put out fire. Turn the grill to OFF. Unplug the power cord and wait for the grill to cool.
• Keep the plug and cord dry when in use. Do not use the electric grill in the rain.
• Operate grill only on a level, stable surface.
• Do not touch hot surfaces. Use handles or knobs.
• Do not allow the cord to hang over table edges, or touch hot surfaces.
• The grease tray must be in place at all mes during grill operaon.
• Do not move the grill while it is in use.
• Do not leave grill unaended whenever in use.
• Keep young children, elderly and pets away while the grill is in use. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilies, or lack of experience and knowledge, unless they have been
given supervision or instrucon concerning use of the appliance by a person responsible for their safety.
• Do not use grill near combusble materials such as wood, dry grass, shrubs, etc.
• Do not allow grill to come into contact with ammable materials such as paper, walls, draperies, towels, chemicals, etc.
• Do not use the grill in high trac areas. Locate power cord away from trac areas.
• To protect the barbecue, do not use the grill within 3 m / 10 feet of pool, pond or other body of water.
• Do not use as a heater.
• Allow the appliance and any collected grease or food drippings to cool before moving or storing it.
Cleaning:
• Clean the drip pan regularly.
• Unplug the grill before cleaning. Allow to cool before removing or installing parts.
• Do not immerse electrical components in water when cleaning.
• To protect against electrical shock, do not immerse plug, cord or thermostat in water or any liquid. Do not clean the grill by
spraying water.
Storage:
• Unplug the grill when not in use and keep the plug and cord dry.
• Do not leave thermostat in the ON posion during periods of non-use.
• Store the grill indoors when not in use - out of the reach of children.
• During long periods of non-use, remove the thermostat from grill.
SAVE THESE INSTRUCTIONS
N415-0478 OCT 18.18
www.napoleongrills.com
EN
!
4
DIMENSIONS
74cm [29”]
PRO285E GRILL
37cm X 54cm (IRREGULAR) = 1840 cm2 (14 1/2” X 21 1/4” (IRREGULAR) = 285 in2
47cm [18 1/2”]
OVERALL HEIGHT
38cm [14 3/4”]
(64cm [25 1/5”]
21cm [8 1/4”]
(GRILL HEIGHT)
40cm [15 3/4”]
31cm [12 1/4”]
CAUTION! During unpacking and assembly we recommended you wear work gloves and safety
glasses for your protecon.
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate, which are
known to the State of California to cause cancer and birth defects or other reproducve harm. For more
informaon go to www.P65Warnings.ca.gov.
N415-0478 OCT 18.18
www.napoleongrills.com
EN
5
!
!
Cooking Instrucons
WARNING! Do not use this grill under extended awnings. Failure to follow these instrucons
could result in a re or personal injury.
DANGER! Allow the grill to cool to the touch before moving or storing. Failure to do so could result
in a re resulng in property damage, personal injury or death.
When lit for the first me, the grill will emit a slight odour. This is a normal temporary condion caused by
the burning of internal paints and lubricants used in the manufacturing process and will not occur again.
Simply run the thermostat on high with the lid open for approximately ½ hour. When cooking very lean
meats, such as chicken breasts, or lean pork, the grids can be oiled before pre-heang to reduce scking. Cooking meat with a high degree of fat content may create are-ups. Either trim some fat or reduce
temperatures to prevent this.
Grilling Chart
Preheat on HIGH for 15-20 minutes with a closed lid, then set to desired temperature. This is a guideline
for cooking in outdoor temperature of 22⁰C.
To add a trademark taste to your cooking, try the Napoleon woodchip smoker as an oponal accessory
with mesquite- or hickory-avoured woodchips.
Food Control Seng Cooking Time Helpful Suggesons
High seng, 2 min. each side
Steak
2.54 cm (1 in.)
thick
Hamburger
1.27 cm (1/2
in.) thick
Chicken pieces
Pork chops Medium 6 min. per side
High seng, 2 min. each side
then Medium seng
High seng, 2 min. each side
then Medium seng
High seng, 2 min. each side
High seng, 2 1/2 min. each
side
High seng, 3 min. each side
High seng, 2 min. each side
then Medium-Low to Low
seng
4 min. – Rare
6 min. – Medium
8 min. – Well
done
4 min. – Rare
5 min. – Medium
6 min. – Well
done
20-25 min.
When selecng meat for
grilling, ask for marbled fat
distribuon. The fat acts as
a natural tenderizer while
cooking and keeps it moist and
juicy.
Preparing hamburgers to order
is made easier by varying the
thickness of your paes.
The joint connecng the thigh
and the leg from the skinless
side should be sliced 3/4 of the
way though for the meat to lay
aer on the grill. This helps it
to cook faster and more evenly.
Trim o the excess fat before
grilling. Choose thicker chops
for more tender results.
N415-0478 OCT 18.18
High seng for 5 minutes
Spare ribs
Lamb chops
Hot dogs Medium - Low 4-6 min.
Low to finish
High seng for 5 minutes
Medium to finish
20 min. per side
turn oen
15 min. per side
Choose ribs that are lean and
meaty. Grill unl meat easily
pulls away from the bone.
Trim o the excess fat before
grilling. Choose extra thick
chops for more tender results.
Select the larger size wieners.
Slit the skin lengthwise before
grilling.
www.napoleongrills.com
EN
6
Troubleshoong
Problem Possible Causes Soluon
No heat Thermostat turned o.
No power.
Turn thermostat to maximum seng.
Ensure thermostat is fully seated in grill
plate and properly plugged into outlet.
Try another outlet.
Check for tripped circuit breaker. Reset.
Turn thermostat to maximum seng.
Pre-heat grill with lid closed for 15-20
minutes.
Faulty thermostat or grill plate.
Low heat. Improper preheang
Excessive buildup in base of grill.
Excessive are-ups/
uneven heat.
Circuit breaker trips or
fuse blows.
Excessive fat in meat.
Excessive cooking temperature.
Grease buildup.
Power surge
Another appliance plugged into
same circuit as grill.
Moisture or water in thermostat
or electrical connecons.
Replace thermostat or grill plate.
Preheat 15-20 minutes. Increase
thermostat seng.
Clean out excessive debris in base.
Trim fat from meat before grilling.
Adjust temperature as needed.
Clean grill.
Turn controller to OFF posion before
plugging into electrical outlet.
Do not use other electrical appliances on
same circuit.
Keep thermostat and electrical components
dr y.
N415-0478 OCT 18.18
www.napoleongrills.com
EN
OPTIONAL SHELF
1 2
OPTIONAL STAND
7
1
2
x4
N415-0478 OCT 18.18
www.napoleongrills.com
EN
8
!
Cleaning Instrucons
WARNING! Always wear protecve gloves and safety glasses when servicing your grill.
WARNING! To avoid the possibility of burns, maintenance should be done only when the grill is
cool. Avoid unprotected contact with hot surfaces. Ensure grill is turned o. Clean grill in an area where
cleaning soluons will not harm decks, lawns, or paos. Do not use oven cleaner to clean any part of
this grill. Do not use a self-cleaning oven to clean cooking grids or any other parts of the grill. Barbecue
sauce and salt can be corrosive and will cause rapid deterioraon of the grill components unless
cleaned regularly.
Cast Iron Cooking Grids: The cast iron cooking grids supplied with your new grill oer superior heat
retenon and distribuon. By regularly seasoning your grids you are adding a protecve coang, which
will aid in resisng corrosion and increase your grids non-sck capabilies.
First Time Use: Wash the cast iron grids by hand with mild dish soap and water to remove any residue
from the manufacturing process (never wash in a dish washer). Rinse thoroughly with hot water and dry
completely with a so cloth. This is important to avoid moisture from entering the cast iron. When lit for
the first me, the grill will emit a slight odour.
Seasoning: Using a so cloth, spread VEGETABLE SHORTENING over the enre grid surface ensuring all
grooves and corners are covered. Do not use salted fats such as buer or margarine. Pre-heat your grill for
15 minutes, then place the seasoned cooking grids in the grill. Turn the burner control knobs to medium
with the lid closed. Allow the cooking grids to heat for approximately one-half hour. Turn the controller
to OFF and let the cooking grids stand unl cool. This procedure should be repeated several mes
throughout the season, although it is not required for daily use (follow daily usage procedure below).
Daily Usage: Before pre-heang and cleaning with a brass wire grill brush, coat the enre top surface of
the cooking grids with vegetable shortening. Pre-heat the grill and then brush away any unwanted residue
with a brass wire brush.
Cleaning Inside The Grill: Remove the cooking grids. Use a so brass wire brush to clean loose debris from
the insides of the lid. Brush all debris from inside the grill into the removable drip pan. Remove the base
liner (drip pan grease catcher). Do not use abrasive cleaners to clean the porcelain base liner. To remove
stubborn stains, soak in soapy water to loosen dirt. Clean with a non-abrasive cleaner and bu dry with a
clean cloth. Ensure that the grill plate is placed properly when reinstalled.
Drip Pan: Slide the drip pan out for easy cleaning. It should be cleaned frequently (every 4-5 uses) to
avoid grease buildup. Grease and excess drippings accumulate in the drip pan located under the grill.
Accumulated grease can cause a fire hazard. Do not line the drip pan with aluminum foil, as it can prevent
the proper amount of air needed for burner to operate. The pan should be scraped out with a puy knife
or scraper.
Cleaning the Outside of the Grill: Do not use any abrasive cleaners to clean painted parts. To protect the
enamel finish, use a mild detergent with so cloth or brush to wipe away and remove any acidic residue.
Bu dry with a clean cloth.
N415-0478 OCT 18.18
www.napoleongrills.com
EN
Cleaning Steps
9
1
Disassembly:
1. Unplug the cord from wall and remove the thermostat.
2. Remove cooking grids.
3. Li heang element out of grill.
4. Remove the base liner.
2
3
2
4
1
N415-0478 OCT 18.18
www.napoleongrills.com
EN
10
!
Reassembly:
1. Reinsert the base liner.
2. Place the curved ends of the heang element back into its support clips.
Lower the heang element into place.
3. Reinsert the thermostat and cooking grids.
1
2
1
3
2
CAUTION!
in the base casng.
Do not aempt to insert the thermostat into the element, unless the element is secured
N415-0478 OCT 18.18
www.napoleongrills.com
EN
KEEP YOUR RECEIPT AS PROOF OF PURCHASE TO VALIDATE YOUR WARRANTY.
Ordering Replacement Parts
11
Warranty Informaon
MODEL:
DATE OF PURCHASE:
SERIAL NUMBER:
(Record informaon here for easy reference)
For replacement parts and warranty claims, contact the Napoleon dealer where the product was purchased.
Before contacng the dealer, check the Napoleon Grills Website for more extensive cleaning, maintenance,
troubleshoong and parts replacement instrucons at www.napoleongrills.com.
To process a claim, the following informaon is required:
1. Model and serial number of the unit.
2. Part number and descripon.
In some cases, Napoleon could request to have the parts returned to the factory for inspecon before
providing replacement parts.
3. A concise descripon of the problem (‘broken’ is not sucient).
4. Proof of purchase (photocopy of the invoice).
Before contacng Napoleon dealer, please note that the following items are not covered by the warranty:
• Costs for transportaon, brokerage or export dues.
• Labour costs for removal and reinstallaon.
• Costs for service calls to diagnose problems.
• Discolouraon of stainless steel parts.
• Part failure due to lack of cleaning and maintenance, or use of improper cleaners
(oven cleaner or other harsh chemicals).
N415-0478 OCT 18.18
www.napoleongrills.com
EN
12
Parts List
ITEM PART NUMBER DESCRIPTION 285
1 N010-1008-SER lid assembly x
2 Z305-0012-BK2FL cooking grids le x
3 Z305-0013-BK2FL cooking grids right x
4 N325-0083-SER lid handle x
5 N370-0861-SER element bracket front/ rear x
6 Z585-0015-BK2GL base liner x
7 Z010-0049 element x
8 Z135-0003-BK1HT base casng x
9 Z690-0003 thermostat x
10 N010-1009-SER cradle assembly x
N075-0091 leg cradle front/ back x
N075-0091-EQ leg cradle front EQ x
11 N710-0079 drip pan x
12 N010-0830 drip pan plate assembly x
13 N135-0048-BK1HG lid casng x
14 N685-0023 temperature guage x
15 Z585-0014 lid heat shield x
16 N010-1010-SER lid handle assembly x
17 N485-0023 clevis pin 6MM X16MM x
18 N485-0021 hairpin coer pin 2MM X 28MM x
19 N655-0179 lid handle support le x
20 N655-0180 lid handle support right x
21 N570-0107 pan head screw 10-24 30 MM x
22 Z735-0009 lock washer M5 x
PRO285-STAND oponal cart and shelves ac
x - standard ac - accessory
N415-0478 OCT 18.18
www.napoleongrills.com
EN
Parts Diagram
1
3
2
6
9
8
10
18
13
1
14
15
20
21
22
19
16
17
16
5
12
11
4
7
13
N415-0478 OCT 18.18
www.napoleongrills.com
EN
14
Notes
N415-0478 OCT 18.18
Loading...
