INTRODUCTION

GENERAL INSTRUCTIONS

5

1. Combustion and dilution air is brought into the unit
through the fresh air intake collars located on the top
rear of the unit.

2. The combustion air is brought into the firebox through
many small holes in the airwash located at the top and
sides of the opening.

3. The dilution air is introduced high in the firebox above
the baffle to cool the chimney.

4. A single air control regulates the burn rate.

5. Inside the firebox combustion takes place and ex-

hausts out the chimney.

6. The optional blower can be installed to draw fresh
outside air into the home (not recommended in colder
climates), then either the NZ150-KT kit or the NZ64 blower
can be installed inside and will circulate the air into your
home.

W415-0594 / A / 02.15.07

6

GENERAL INFORMA TION

FEATURES

• Maximum log length of 32"

• Large firebox capacity - 4.8 cu ft.

• Long burn time - up to 14 hours.

• Large glass doors for maximum visibility

• Firebrick lining for firebox protection

• Optional 320 CFM blower for convection heat

• Thermostat for automatic control of the blower

• Outside air for combustion

HEA TING SPECIFICATIONS

Approximate Heating Capacity up to 3,000 square feet
(Will vary with the home's floor plan, insulation and outside

temperature.)
Maximum burning time up to 14 hours
BTU Output per hour 10,000 to 80,000
(Cord wood method)

ELECTRICAL SPECIFICA TIONS

The blower on "HIGH" draws 2.2 amps on 120 volts A.C.
(approximately 250 watts).

P ACKING LIST

Shipped with the fireplace:

Installation manual
Baffle
Ember strip
Log retainer
Flex duct w/ start collar 10' length, 6" dia (1 for NZ150-KT or
blower kit and 2 for outside combustion air supplies).

Shipped with faceplate:

faceplate
12 faceplate screws

Shipped with the door(s):

Installation instuctions and hardware

EP A COMPLIANCE

This heater has been certified epa exempt.

CALIFORNIA PROP 65 WARNING:
Use of this product may produce smoke which

contains chemicals known to the State of Califor­nia to cause cancer, birth defects, or other repro­ductive harm.

Do not use makeshift compromises during
installation. Do not block or restrict air, grille or lou­vre openings! Do not add a hood.

Burning your unit with door open or ajar creates a
fire hazard that may result in a house and/or chimney
fire.

All venting connections must be in compliance with

the chimney manufacturers installation instructions.
Clearances referred to throughout this manual are

the minimum requirements.
Your Napoleon fireplace must be installed in accord-

ance with all national and local building code stand­ards and the standard of Chimney and Fireplaces,
Vents and Solid Fuel Burning Appliances NFPA #211.
Consult the authority having jurisdiction (such as
municipal building department, fire department, fire
prevention bureau, etc.) to determine the need to
obtain a permit. If you are in doubt about the proper
installation for your situation, contact your dealer or
local building or fire official. The manufacturer does
not guarantee that this fireplace and its options will
completely heat your entire home.

Expansion / contraction noises during heating up
and cooling down cycles are normal and to be ex­pected.

It is recommended that in all cases, the fireplace
be secured to the floor. Use the pallet packing brack­ets to accomplish this.

CARE OF GLASS, AND PLA TED P ARTS

If the glass is not kept clean permanent discolouration and /
or blemishes may result. Normally a hot fire will clean the
glass. The most common reasons for dirty glass include: not
using sufficient fuel to get the stove thoroughly hot, using
green or wet wood, closing the draft so far that there is insuf­ficient air for complete combustion. If it is necessary to clean
the glass, use a soft cloth with a non-abrasive cleaner.

Do not clean the glass when hot!

The glass is very strong but do not let burning fuel rest or fall
against it and always close the door gently. Never force it

shut!

If the glass should ever crack while the fire is burning, do not
open the door until the fire is out and do not operate the stove
again until the glass has been replaced with a new 5mm
thick piece of ceramic glass, available from your Napoleon /
Wolf Steel Ltd. dealer. Do not substitute materials.
For information on glass removal and replacement, see
Maintenance.
Do not use abrasive cleaners to clean plated parts. Buff lightly
with a clean dry cloth.

W415-0594 / A / 02.15.07

HI-EFFICIENCY HEA TING

A HOT AIR GRAVITY VENT SYSTEM (NZ221) may be

used to distribute heat to an adjoining room (located either
above, or beside the room containing the fireplace) by way of
vents. Air flow through this vent must be experimented with
and the dampers of the grill adjusted manually to suit your
requirements. This may take a few attempts; thereafter ad­justments should no longer be required as is normally expe­rienced with your central heating system registers.

The hot air vent must be installed in an upward direction!
NEVER install in a downward direction.

vent system is not to be connected to a central heating
system.

No more than two hot air gravity vents may be connected to
the fireplace. Individual vent runs are not to exceed 10 feet.

All hot air gravity vents must be insulated.

The hot air gravity

INSTALLATION / FRAMING

7

49 1/2"

51 1/2"

50

24"

1

/4"

43"

OMB

C

AVERTISSEM

IR

A

SEULEMEN

W

C

BLOWER

IR

N A

USTIO

CONNECTION ONLY

LY

ON

AVERTISSEMENT:

ENT:

CONNEXION DE LA

T

BURAN

OM

SOUFFLERIE

T

SEULEMENT

WARNING:

NING:

AR

6 5/8"

10 3/4"

8"

30 3/4"

29 1/2"

1

/2"

27

15"

24 3/4"

6 1/2"

4 3/8"

3

/8"

19

25 3/16"

41"

48

5

/8"

30 3/4"

50"

61 1/2"

87"

50"

61

"

2

/

1

123"

30 3/4"

50"

61 1/2"

When framing in unit,When framing in unit,

When framing in unit,

When framing in unit,When framing in unit,

allow fallow f

or for f

allow f

allow fallow f

inishing mainishing ma

or f

inishing ma

or for f

inishing mainishing ma

terial thicterial thic

terial thic

terial thicterial thic

MIN

knesskness

kness

knesskness

21"

2 layers2 layers

2 layers

2 layers2 layers

of 1/2" cementof 1/2" cement

of 1/2" cement

of 1/2" cementof 1/2" cement

..

.

..

board needed to fill gap Aboard needed to fill gap A

board needed to fill gap A

board needed to fill gap Aboard needed to fill gap A

.

W415-0594 / A / 02.15.07

8

LOCA TION AND CLEARANCES

The fireplace is
shipped with a set-up
face that is 1/8" larger
on the top, bottom
and each side than
the faceplate. Leave
the set-up face in
place to act as a tem­plate when installing
the finishing face.

Do not build shelves or cupboards into the area
above the fireplace.

MAINTMAINT

MAINT

MAINTMAINT

Framed enclosure
Rear - 0" to stand-offs (rear)
Sides - 6" to sides*
Ceiling - 120" from the base of the unit
(enclosure) (unless shielded with metal studs

Ceiling - 84" from the base of the unit
(in front of fireplace)
Chimney - 2" (follow manufacturers instructions)

Hot Air Gravity Ductwork Insulation

This enclosure must provide greater clearance if air
intake vents are run vertical along side the fireplace.

SOLID PSOLID P

SOLID P

SOLID PSOLID P

Ceiling - 120" from the base of the unit
(enclosure) (unless shielded with metal studs

AIR COOLEDAIR COOLED

AIR COOLED

AIR COOLEDAIR COOLED

Ceiling - 84" from the base of the unit
(enclosure)

AIN THESE MINIMUM CLEARANCES TAIN THESE MINIMUM CLEARANCES T

AIN THESE MINIMUM CLEARANCES T

AIN THESE MINIMUM CLEARANCES TAIN THESE MINIMUM CLEARANCES T

COMBUSTIBLES:COMBUSTIBLES:

COMBUSTIBLES:

COMBUSTIBLES:COMBUSTIBLES:

and cement board).

- 1"

AA

CK CHIMNEYCK CHIMNEY

A

CK CHIMNEY

AA

CK CHIMNEYCK CHIMNEY

and cement board).

OO

O

OO

Note: In order to avoid the possibility of exposed insulation
or vapour barrier coming in contact with the fireplace body , it
is recommended that the walls of the fireplace enclosure
be “finished” (ie: drywall/sheetrock), as you would finish any
other outside wall of a home. This will ensure that clear­ance to combustibles is maintained within the cavity.

Objects placed in front of the fireplace must be kept a
minimum of 48" away from the front face of the unit.

IMPORTANT

This unit, fully dressed, weighs 850 lbs
(385.6kg)

Ensure there is adequate floor support for the
unit, chimney and facing material. Some ma­terial could weigh thousands of pounds.

We recommend that the
fireplace be secured to
the floor in all cases.

Using the door
opening as a datum,
level the fireplaceby
shimming under­neath the fireplace.

Remove and dis­card the lifting han­dles. Bend the tabs
down and secure
the unit to the floor.

The fireplace enclosure must be provided with sufficient
air circulation to avoid a fire hazard. Install ventilation grilles
(minimum openings of 40 sq. inches) at both floor and
ceiling levels of the enclosure. These grilles must not re­strict the flow of heat by more than 25%.
Do not install into any area having a height less than 7 feet
(ceiling of enclosure to fireplace bottom, excluding hearth
height).
The location of windows, doors and the traffic flow in the
room where the stove is to be located should be considered.
If possible, you should choose a location where the
chimney will pass through the house without cutting a floor
or roof joist.

W415-0594 / A / 02.15.07

WHEN USING A SOLID P ACK CHIMNEY

9

The fireplace face and
enclosure ceiling must be
framed using 2x4 metal
studs.
The minimum enclosure
ceiling height is 7 feet.
Non-combustible
materials (cement board
and metal studs) must be
used.

WHEN USING AN AIR COOLED CHIMNEY

W415-0594 / A / 02.15.07

10

OUTSIDE COMBUSTION AIR

Note: Incorporate a vertical loop or trap
into air liners to reduce air flow when
unit is not in use.

Insulating the in­take liners is
recommended
in colder

climates to pre­vent condensa­tion from
occuring.

The Napoleon
Model NZ6000
takes outside
air directly into
the fireplace
through the
openings in the left and
right hand sides.

Decide on the most convenient lo­cation for the fresh air inlet ducts and
hoods which may be installed above or below
floor level.

The fresh air inlet ducts and hoods must beThe fresh air inlet ducts and hoods must be

The fresh air inlet ducts and hoods must be

The fresh air inlet ducts and hoods must beThe fresh air inlet ducts and hoods must be
installed.installed.

installed.

installed.installed.

Secure and seal the intake liners to the collars using 3
sheet metal screws, and high temperature sealant.

The duct terminations must be located so they can not be
blocked (i.e. snowdrifts). 4' above grade is recommended.

Make a 6 ½" inch hole to suit in an outside wall of the
house. From outside, place the fresh air hood into the hole,
open side down. Seal with caulking and secure.

MANTLE CLEARANCES

An optional combustible mantle must be a minimum of
12" above the top of the faceplate and not to extend more
than 2" from the surface. See chart below for further
information.

Vertical Horizontal

rise is run may be:

between:

6' & 10' max 5'

3' & 6' 15'
1' & 3' 20'
0' & 1' 25'

Included with the fireplace
are:

- two 10' lengths of vent. Use
a connector and seal if add-

ing more length.

- two of intake hoods.

The vertical height of the air intake liner must not be
greater than 2/3 the height of the chimney. If additional

liner length is required, it may be doubled by increasing
the size from 6" diameter to 8" diameter. Use a 6" to 8"
increaser at the hood and a decreaser at the fireplace.
Values in brackets represent 8" diameter intake liners.

W415-0594 / A / 02.15.07

HEARTH EXTENSION

11

An acceptable 61½" x 20" non-combustible (ie: brick, stone
or ceramic tile) hearth extension must be installed.
Hearth must extend 20" in front of the faceplate when it is
not elevated (see local building codes).
Hearth must extend a minimum of 6" to both sides of the
unit (61 ½").
Hearth must be a minimum of 1" thick cement board (or
equivalent) plus ¼" ceramic tile.

Ensure that the gap
between the
fireplace and a
combustible hearth
extension is sealed
with sand/cement
grout or covered
with a metal strip (or
both) to prevent
sparks and embers
from falling into this
area.

See hearth

examples.

Elevated hearths must be constructed of non-Elevated hearths must be constructed of non-

Elevated hearths must be constructed of non-

Elevated hearths must be constructed of non-Elevated hearths must be constructed of non­combustible materials such as cement blockscombustible materials such as cement blocks

combustible materials such as cement blocks

combustible materials such as cement blockscombustible materials such as cement blocks
or bricor bric

or bric

or bricor bric

While the fireplace can be installed directly on the floor, a
non-combustible hearth extension is required in front of
the fireplace, that must not be built higher than the bottom
of the fireplace faceplate. It may therefore be advisable to
build the fireplace on a raised platform.
Hearths raised minimum 6 ½" must extend a minimum of
18".

kk

ss

..

k

s

.

kk

ss

..

W415-0594 / A / 02.15.07

12

ELEVATED HEARTH

HEARTH EXAMPLES

RAISED HEARTH

ELEVATED / RAISED HEARTH

W415-0594 / A / 02.15.07

FACE PLA TE, UPPER GRILL, KEY STONE & DOOR INSTALLA TION

13

1

Remove the
facing template held
in place with the 12
screws shown. Dis­card the screws and
template.

2

Mount the keystone
and upper grill to the face­plate, as shown, using the
4 nuts supplied.

Right Door Handle

4

- Insert the door rod through the
round hole of the latch ensuring

(operating)

the flat edge of the “D” shaped

hole points towards the

hinges.

- Slide the end of the door
rod through the bushing at
the top of the door as
shown.

- Insert the handle shaft
through the door and the
latch.

-Secure with 2 flat wash­ers and a nut.

See Note #1

- Feed the handle through
the handle spacer and into

the
handle

shaft.

Remove the backing and place logo onto the bottom
left corner of the faceplate.

Ensure that the pressure switch actuating arm and airEnsure that the pressure switch actuating arm and air

Ensure that the pressure switch actuating arm and air

Ensure that the pressure switch actuating arm and airEnsure that the pressure switch actuating arm and air
control rod, protrude through the faceplate when in-control rod, protrude through the faceplate when in-

control rod, protrude through the faceplate when in-

control rod, protrude through the faceplate when in-control rod, protrude through the faceplate when in­stalled.stalled.

stalled.

stalled.stalled.

Remember to record your serial # in the manual for
future quick reference.

Secure the

3

faceplate to the

unit, using the 12
screws supplied.

Start all 12 screws,
then tighten evenly.

Left Door Handle

(fixed)

- Insert the handle shaft
through the door.

- Secure with a lock
washer, 2 flat washers
and a nut.

- Feed the handle through
the handle spacer and

into the handle shaft.

See Note #2

Note #1: You may need to move washers to the other side

of the latch to obtain sufficient door seal.
Note #2: The final angle of the left door handle should

mirror the right door handle in the closed position. Tighten
the nut to secure the left handle at the desired angle.

W415-0594 / A / 02.15.07

14

Place brass

5

washers onto
the faceplate hinge
bushing (2 extra
washers are sup­plied in order to level
the doors if needed).

6

Install the air
control
threaded rod
and knob.

Slide the door hinge pin
into the faceplate hinge
bushing.

To remove the doors, open them slightly and lift them out of
the faceplate hinge bushings.

CHIMNEY INST ALLATION

A raised hearth together with the fireplace built on a raised
platform is recommended for easier wood loading and fire
viewing.

The diameter of the chimney is 8".
A chimney venting the fireplace shall not vent any other

appliance.
The minimum overall chimney height from the top of

the fireplace is 15 feet.
The maximum overall chimney height from the top of

the fireplace is 34 feet.
Factory-built chimney systems for use in dwellings

constructed for three or more families must be enclosed
above the room in which the fireplace is located. This
enclosure must have a fire resistance rating equal to or
greater than that of the floor or roof assembly through
which they pass.

If the chimney system is enclosed within the attic area,
a rafter radiation shield is required.

The chimney should not be built with an offset angle in
excess of 45° in Canada and 30° in USA.

The chimney must extend at least 3 feet above its point
of contact with the roof and at least 2 feet higher than
any wall, roof or building within 10 feet.

If the chimney extends more than 5 feet above the roof,
it must be secured using a roof brace or guide wires.

Ensure that minimum clearances are maintained.
Portions of the chimney that extend through accessible

spaces must always be encased to avoid personal
contact with the chimney and thereby avoid damage to
the chimney.

A raincap must be installed to avoid internal damage
and corrosion.

The chimney must be supported at a maximum of 20
foot intervals (approx. 200 lbs/20 ft).

This fireplace was tested to CAN /ULC S610 Standard for
Factory Built Fireplaces, and to UL 127 Factory Built
Fireplaces. This Factory Built Fireplace is certified to burn
Fire Wood. The Factory Built Fireplace model: NZ6000
has met test criteria for Zero Clearance Installation to
Combustible Surfaces.

Any 8" diameter chimney listed to these standards may be
installed. In accordance with these standards, the unit may
also be connected to any chimney listed to CAN/ULC-S604
and CAN/ULC-S629 for Canada or UL-103HT for the United
States.

Installation of all types of factory-built chimney systems is
to be in accordance with the chimney manufacturers in­stallation instructions. An appropriate chimney manufac­turers anchor base plate and anchor base plate gasket is
required in order to initiate their system. Use the high tem­perature gasket, supplied, to seal between the anchor plate
and the fireplace top. Air cooled chimney systems are not
recommended in colder climates.

W415-0594 / A / 02.15.07

No Off-Set. Minimum overall chim­ney height is 15 feet.

Single off-set with two 15°, 30° or
45° elbows. Minimum overall
chimney height is 15 feet.

15

4 ELBOWS2 ELBOWSSTRAIGHT UP

Double off-set with four 15°, 30° or
45° elbows. Minimum overall chim­ney height is 15 feet.

* The first flue offset closest to the top of the
unit must be a minimum distance of 12 inches
from the top of the fireplace.

1. Move the fireplace into position. Try to center the ex­haust flue of the fireplace, midpoint between two joists to
prevent having to cut them. Use a plumb bob to line up the
centre.

2. Cut and frame an opening in the ceiling to provide a
minimum clearance of 2" between the outside of the chim­ney and any combustible material. DO NOT FILL THIS
SPACE WITH ANY TYPE OF MATERIAL! Nail headers
between the joists for extra support. Firestop spacers must
be placed on each framed opening in any floor or ceiling
that the chimney passes through.

3. Hold a plumb bob from the underside of the roof to
determine where the opening in the roof should be. Cut
and frame the roof opening maintaining proper 2" clear­ances.

NOTE: 30° or 45° offsets may be installed back to

back.

ADDING CHIMNEY SECTIONS

Add chimney sections, securely , to the required height. Use
a rafter radiation shield whenever the chimney system is
enclosed within an attic area.

- Chimney must extend 3' above the roof.

- Chimney must extend 2' above any portion of the roof
within 10' of the chimney.

W415-0594 / A / 02.15.07

16

OFFSET CHIMNEY INST ALLATION INST ALLING FLASHING AND STORM

The first flue offset closest to the top of the unit
must be a minimum distance of 12" from the top
of the fireplace.

Attach an elbow to the chimney section, angled toward the
offset. Secure with 3 - #8X1/2" sheet metal screws. To
achieve the minimum offset, attach and secure a second
elbow. To achieve longer offsets, you may install any
available length of chimney pipe between the elbows to a
maximum length of 4'.

Supports must be used on the first vertical chimney sec­tion after a return elbow.

Remove the nails from the shingles above and to the sides
of the chimney. Place the flashing over the chimney pipe
and slide underneath the sides and upper edge of the
shingles. Ensure that the chimney pipe is properly centered
within the flashing, giving a 3/4" margin all around. Fasten
to the roof on the top and sides. DO NOT NAIL through the
lower portion of the flashing. Make weather-tight by seal­ing with caulking. Where possible, cover the sides and top
edges of the flashing with roofing material. Apply water­proof caulking, provided with the flashing, around the chim­ney, 1" above the top of the flashing and push the storm
collar down into the caulking. Insert a rain cap onto the top
of the last chimney section.

COLLAR

W415-0594 / A / 02.15.07

CONNECTION TO A MASONRY CHIMNEY

The Napoleon Model
NZ6000 may be
connected to either a
lined or unlined
masonry chimney.

IF THE CHIMNEY
IS LINED,

must be made of
vitrified clay and be in
sizes of 8" square or
8" round (inside
diameters) or 8"x12"
with a minimum
height of 15 feet
above the fireplace.

Eight inch round flues
are recommended.

Installation must
conform to both
national and local
code requirements.

the flues

17

IF THE CHIMNEY IS UNLINED, a stainless steel liner

listed to either Standard ULC-S640M in Canada or UL­1777 in the USA: Liners for New Masonry Chimneys, may
be used to connect the fireplace to the chimney. The liner
must be continuous from the fireplace to the chimney cap
and be installed only per manufacturers instructions. In
both cases, the chimney structure must be supported by
angle iron anchored into the masonry walls. The allow­able masonry used in chimney construction is 3-1/2" brick,
solidly mortared and fully encasing the flue. Ensure there
are no leaks.

In no case is the masonry enclosure to be supported
by the NZ6000 fireplace. Allow a 1" (one inch) air cavity
for expansion.

ANCHOR PLATE

HI-TEMP GASKET

FIREPLACE TOP

FLUE TILE SUPPORT FOR A MASONRY FIREPLACE

FIREPLACE TOP

For a masonry fireplace use a flue tile support. For a pre­fabricated chimney use an anchor plate.

W415-0594 / A / 02.15.07

18

AIR COOLED CHIMNEY INSTALLATION

1. Remove the knock out.

2. Cut away the insulation to gain access to the ring.

3. Remove the ring secured by four screws.

4. Slide the starter collar through the insulation wrap and

affix using the four screws removed in step 3.

5. Secure the inner liner of the chimney to the fireplace 8"
collar using 3 screws supplied with the starter collar (W170-

0098).

6. Follow the chimney manufacturer's instructions for in­stalling the chimney.

AIR COOLED CHIMNEY REQUIREMENTS

Use only the fUse only the f

Use only the f

Use only the fUse only the f

ollowing brollowing br

ollowing br

ollowing brollowing br

and and type ofand and type of

and and type of

and and type ofand and type of

stnenopmoCyenmihCMD8IMF

noitceSyenmihC"21MD8-21
noitceSyenmihC"81MD8-81
noitceSyenmihC"42MD8-42
noitceSyenmihC"63MD8-63

C"84MD8-84

noitceSyenmih

stesffOMD8-E03

gnihsalF8F21ro8F6

paCyenmihCTH8-LTR

troppuSfooRSR83

potseriFMD8-SF

stnenopmoCyenmihCleetSfloW

ralloCretratSTK-CAZN

c c

himnehimne

c

himne

c c

himnehimne

yy

..

y

.

yy

..

FINISHING

ATTACHING THE HANDLE AND

AIR CONTOL KNOB

The door latch is adjusted by moving the washer from one
side of the latch to the other. T ighten the outer nut to secure
the latch.

W415-0594 / A / 02.15.07

Install the air control threaded
rod and knob.

19

SECONDAR Y AIR TUBE

REMOV AL / INSTALLA TION

FIREBRICK AND BAFFLE

INSTALLATION

OPTIONAL NZ64 BLOWER KIT INSTALLATION

Route a 120 Volt, 60Hz electrical supply (not supplied) from
the electrical box on the side of the unit to the electrical box
on the blower housing.

The unit comes complete with a safety switch and a ther­mally activated switch.

For complete instructions, see

blower kit.

W415-0594 / A / 02.15.07

20

NZ64 BLOWER INSTALLATION

This unit is supplied with a pressure switch andThis unit is supplied with a pressure switch and

This unit is supplied with a pressure switch and

This unit is supplied with a pressure switch andThis unit is supplied with a pressure switch and
a thermally activated switch. Ensure that thea thermally activated switch. Ensure that the

a thermally activated switch. Ensure that the

a thermally activated switch. Ensure that thea thermally activated switch. Ensure that the
pressure switch actuating arm protrudespressure switch actuating arm protrudes

pressure switch actuating arm protrudes

pressure switch actuating arm protrudespressure switch actuating arm protrudes
through the faceplate when installed.through the faceplate when installed.

through the faceplate when installed.

through the faceplate when installed.through the faceplate when installed.
The blower will only operate when the doors areThe blower will only operate when the doors are

The blower will only operate when the doors are

The blower will only operate when the doors areThe blower will only operate when the doors are
fully closed.fully closed.

fully closed.

fully closed.fully closed.

3. Connect the 6” collar to the blower opening located
on the side of the unit. An optional opening is covered on
the other side of the unit. If this location is preferred, switch
the cover plate and collar.

Secure by reaching through the collar and bending the
tabs.

Use sealant to ensure that the connection is air tight.

1. Remove the template.

2. Position the blower to an in-

side or outside wall into a framed open-

3

ing 12
not recommended in colder climates as cold air may
be drawn into the house when the fireplace is off.)

The blower housing should be installed onto aThe blower housing should be installed onto a

The blower housing should be installed onto a

The blower housing should be installed onto aThe blower housing should be installed onto a
level surface large enough to support the blowerlevel surface large enough to support the blower

level surface large enough to support the blower

level surface large enough to support the blowerlevel surface large enough to support the blower
assembassemb

assemb

assembassemb

Allow for finishing material when securing theAllow for finishing material when securing the

Allow for finishing material when securing the

Allow for finishing material when securing theAllow for finishing material when securing the
blower housing, as the grill mounts to the hous-blower housing, as the grill mounts to the hous-

blower housing, as the grill mounts to the hous-

blower housing, as the grill mounts to the hous-blower housing, as the grill mounts to the hous­ing.ing.

ing.

ing.ing.

W415-0594 / A / 02.15.07

/8” wide by 10 1/2” high. (Outside wall

lyly

..

ly

.

lyly

..

We recommend installing the blower in a different room or
even different level of the house. This will generate greater
air movement and improve the distribution of the warm air
coming from the fireplace.

21

4. Electrical Connection
a) Remove the junction box covers on the unit and the

blower.
b) Removing the junction box cover on the unit exposes 4

black, labeled wires:
Two wires labelled "by-pass" - go to by-pass (summer)

switch (not supplied - overides the thermally activated
switch enabling the user to run the blower without heat).

Important:
Marrett by-pass (summer) switch wire leads

rately (do not connect together),rately (do not connect together),

rately (do not connect together),

rately (do not connect together),rately (do not connect together),

switch is not desired.

One wire labelled "blower" - connects to KB-35 rheostat
(not supplied) and then KB-35 blower wire connects to
white blower wire.

One wire labelled "L1" - connects to power (hot lead).
c) Removing the junction box cover on the blower exposes

3 coloured wires:
One black wire - connects to power "L2" (neutral lead).
One green wire - connects to ground.
One white wire - connects to KB-35 rheostat (not supplied)

See above.

if the by-pass

sepa-sepa-

sepa-

sepa-sepa-

5. Connect the 6” liner to the unit and blower collars. Se­cure using 3 screws on each end and seal with caulking.

Liner supplied stretches to a maximum of 10’.Liner supplied stretches to a maximum of 10’.

Liner supplied stretches to a maximum of 10’.

Liner supplied stretches to a maximum of 10’.Liner supplied stretches to a maximum of 10’.

6. Insert the filter into the grill. Foam gasket (1/2” weather
stripping) between the grill and blower housing is recom­mended, but not supplied.

The blower filter is washable.

7. The bottom lip of the grill latches over the bottom lip of
the housing. Use two screws to secure the top of the grill to
the facing.

NZ150-KT KITNZ150-KT KIT

NZ150-KT KIT

NZ150-KT KITNZ150-KT KIT

The circulation air inlet pipe must terminate outside of the
fireplace enclosure to ensure proper air flow around the
firebox.

The 6" circulation air inlet pipe may be connected to either
the NZ64 blower kit or the NZ150-KT kit.

Avoid terminating higher than the bottom of the doors on
the unit to prevent air flow reversal.

An optional opening is
covered on the other side of the unit. If this loca­tion is preferred, switch the cover plate and collar.

W415-0594 / A / 02.15.07

22

NZ64 BLOWER REPLACEMENT

1. Remove the grill and filter by removing the 2 securing
screws.

4. Slide the bracket and blower out of the housing.

5. Disconnect the wire connector from the blower.

6. Remove the old blower from the bracket by removing the

four screws.

2. Remove the nut securing the blower bracket to the hous­ing.

3. Lift the handles to pull the blower and bracket off of the
stud.

NSK OPTIONAL SCREEN KIT

Use the screen when you are in the room to enjoy theUse the screen when you are in the room to enjoy the

Use the screen when you are in the room to enjoy the

Use the screen when you are in the room to enjoy theUse the screen when you are in the room to enjoy the

ambience ofambience of

ambience of

ambience ofambience of

Medium sized wood loads should be used to preventMedium sized wood loads should be used to prevent

Medium sized wood loads should be used to prevent

Medium sized wood loads should be used to preventMedium sized wood loads should be used to prevent

logs from rolling against the screen.logs from rolling against the screen.

logs from rolling against the screen.

logs from rolling against the screen.logs from rolling against the screen.

W415-0594 / A / 02.15.07

an open, w an open, w

an open, w

an open, w an open, w

ood crood cr

ood cr

ood crood cr

acac

ac

acac

kk

ling fling f

k

ling f

kk

ling fling f

irir

ee

..

ir

e

.

irir

ee

..

7. Secure the new blower to the existing bracket using the
four screws removed in step 6.

8. Slide the new blower/bracket assembly into the hous­ing.

Ensure that the blower bracket slides into the clips at the
back of the housing on either side.

9. Push the assembly into the housing as far in as pos­sible.

10. Secure the assembly to the housing using the nut re­moved in step 2.

11. Re-secure the grill by replacing the 2 securing screws.

Chimney action may not allow the screen to beChimney action may not allow the screen to be

Chimney action may not allow the screen to be

Chimney action may not allow the screen to beChimney action may not allow the screen to be

used in some installations due to the resultingused in some installations due to the resulting

used in some installations due to the resulting

used in some installations due to the resultingused in some installations due to the resulting

smoksmok

e spillae spilla

smok

e spilla

smoksmok

e spillae spilla

mama

y help pry help pr

ma

y help pr

ma

ma

y help pry help pr

burn at a faster rate and heat output will beburn at a faster rate and heat output will be

burn at a faster rate and heat output will be

burn at a faster rate and heat output will beburn at a faster rate and heat output will be
less with the screen compared to the stoveless with the screen compared to the stove

less with the screen compared to the stove

less with the screen compared to the stoveless with the screen compared to the stove

operation with the glass doors closed.operation with the glass doors closed.

operation with the glass doors closed.

operation with the glass doors closed.operation with the glass doors closed.

gg

ee

. Opening the b. Opening the b

g

e

. Opening the b

gg

ee

. Opening the b. Opening the b

ee

vv

ent smokent smok

e

v

ent smok

ee

vv

ent smokent smok

e spillae spilla

e spilla

e spillae spilla

y-pass dampery-pass damper

y-pass damper

y-pass dampery-pass damper

gg

ee

. W. W

ood willood will

g

e

. W

ood will

gg

ee

. W. W

ood willood will

OPERA TING INSTR UCTIONS

j

-

r

Expansion / contraction noises during heating up and cool­ing down cycles are normal and to be be expected.

OPERA TING SOUNDS AND SMELLS

A slight humming sound may be heard depending on the
location of the blower. This sound may be minimized by
turning down the blower.

When first installed, the fireplace and the steel are cold
and must become hot before the fireplace will function
well. During the break-in period (the first 2 or 3 fires) create
only small, hot fires using kindling; this will allow the fire­brick to cure. Do not be alarmed if small hairline cracks
develop in the firebrick. This is a normal occurrence and
does not pose a safety hazard. The paint may also smell a
little for the first few fires as it cures and you may wish to
open a door or window to alleviate the smell.

There are many different ways to start a fire, review the
hints and warnings in this section to ensure the fire is
started properly.

ST ARTING A FIRE

Make sure the air control is on high (far right position). You
may also open the doors 1" to 2" during the first five minutes
of start-up, if additional air is needed.

Opening the by-pass damper will help heat up the chimney
more quickly. If desired close after draft is established.

Never use gasoline, gasoline-type lantern fuel, kerosene,
charcoal lighter fluid, or similar liquids to start or freshen­up a fire in this fireplace. Keep all such liquids well away
from the fireplace while it is in use.

If using a firestarter, use only product s specifically designed
for fireplaces - follow the manufacturer's instructions
carefully.

Use plenty of newspaper and kindling to ensure the
fireplace reaches a proper temperature. Once the kindling
is burning rapidly, place a few larger pieces of wood onto
the fire.

Tip: When first lighting a fire, if the smoke is not quickly
drawn into the chimney, there may be a downdraft or cold
air in the chimney.

23

Roll up some newspaper, light it and place it near the fire­place flue until the chimney begins to draw. When a fire is
burning, open the door slowly to avoid drawing smoke into
the room.

A properly installed Napoleon fireplace should not smoke.
If yours does, check the following: Has the chimney had
time to get hot? Are the air int ake hoods blocked closed? Is
the smoke passage blocked anywhere in the fireplace or
chimney? Is the smoke flow impeded by too long a
horizontal pipe or too many bends? Is it a weak draft per­haps caused by a leaky chimney, a cold outside chimney,
too short a chimney, or a chimney too close to trees or a
higher roof?

DRAFT CONTROL

Draft is the force which moves air from the fireplace up
through the chimney. The amount of draft in your chimney
depends on the length of the chimney, local geography,
nearby obstructions and other forces. Adjusting the draft
control regulates the temperature. The draft can be ad-

usted from a low burn rate with the air control on the low

setting to a fast burn rate with the air control on the high

setting (far right position).
Inadequate draft may cause back-puffing into the room

and may cause plugging of the chimney. Too much draft
may cause an excessive temperature in the fireplace, glow­ing red fireplace parts or an uncontrollable burn which can
all lead to a chimney fire or a permanent damage to the
unit.

Remove all source of gasoline or other flamma
ble vapours and liquids in the vicinity of this o
other appliances prior to lighting.

1. To start, a brisk fire is required. Place loosely crumpled
paper on the floor of the fireplace behind the log retainer.

W415-0594 / A / 02.15.07

24

2. Cover with dry kindling.

3.Open the draft control fully by moving the lever to the right
(HIGH setting).

5. To maintain a brisk fire, a hot coal bed must be estab­lished and maintained.

6. Slowly add larger wood (2x4 size pieces). Lay the pieces
lengthwise from side to side in the hot coal bed with a
shallow trench between, so that the primary air can flow
directly into this trench and ignite the fuel above.

4. Light the paper and leave the door slightly ajar (one to
two inches) until all kindling is burning.

W415-0594 / A / 02.15.07

7. When the fire seems to be at its peak, medium sized
logs may be added. Once these logs have caught fire,
carefully close the door.

Closing the door too quickly after refueling will reduce
the firebox temperature and may result in an
unsatisfactory burn.

25

As soon as the door is closed, you will observe a change
in the flame pattern. The flames will get smaller and lazier
because less oxygen is getting into the combustion cham­ber. The flames, however, are more efficient. The flames
will remain lazy but become larger again as soon as the
firebricks have been heated thoroughly and the chimney
becomes heated and provides a good draft.

Can't get the fireplace operating? Use more kindling and
paper. Assuming the chimney and vent are sized correctly
and there is sufficient combustion air, the lack of suf ficiently
dry quantities of small kindling is the problem. Thumb size
is a good gauge for small kindling diameter.
Can't get heat out of the fireplace? One of two things may
have happened. The fireplace door may have been closed
prematurely and the fireplace itself has not reached opti­mum temperature. Re-open the door and/or draft control to
re-establish a brisk fire. The other problem may have been
wet wood. The typical symptom is sizzling wood and mois­ture being driven from the wood.

FUEL LOADING AND B URN CYCLE

The bricks will be nearly all white and the glass mostly
clear. The whiteness of the bricks and the cleanness of the
glass are good indicators of your operating efficiency.

At this point, the roaring fire that you see when the door is
opened is wastefully drawing heated room air up the
chimney -- certainly not desirable.

So always operate with the door fully closed once the me­dium sized logs have caught fire.

You can now add larger pieces of wood and operate the
fireplace normally. Once the fireplace is entirely hot, it will
burn very efficiently with little smoke from the chimney . There
will be a bed of hot coals in the firebox so you can safely fill
the firebox with wood to the top of the andirons.

Not enough heat is produced when only one or two pieces
of wood are burned.

A minimum of three pieces are needed to encase a bed of
coals that sustains the fire. Loosely stacked wood burns
quicker than a tightly packed load.

Wood burns in cycles rather than giving a steady output of
heat. It is best to plan these cycles around your household
routine so that only enough coals are left to start the next
load. In the evening, load your fireplace, at least, a half­hour before bed to ensure the fire is hot enough to close
the draft control for an overnight burn.

Burn only dry seasoned wood. It produces more heat and
less soot or creosote. Do not burn ocean beach wood. Its
salt content can produce a metal eating acid.

W415-0594 / A / 02.15.07

26

RE-LOADING THE FIREPLA CE

When refueling open the door slowly to prevent smoke
spillage. Use a pair of long fireplace gloves when feeding
the fire. Keep a small steel shovel nearby to use as a
poker and to remove ashes. Do not store wood within 4
feet (1m) of the fireplace.

Follow the directions below to minimize smoke spillage
while re-loading the fireplace.

1. Move the air control to high.

2. Open the door slightly. Allow the airflow inside the firebox
to stabilize before opening the doors fully.

3. Load wood to the top of the cast retainers and burn at a
medium low setting.

FLASH FIRES

A flash fire is a small fire burned quickly when you don't
need much heat. After your kindling has "caught", load at
least 3 pieces of wood, stacked loosely. Burn with the draft
control fully open or closed only slightly.

3. After approximately 30 minutes, depending on the size of
the load, close the draft control completely making sure
that the fire is not extinguished.

4.In the morning the fireplace should still be hot, with
embers in the coal bed. Stir the coals and load small pieces
of wood to re-ignite the fire, if desired.

Note: Differences in chimney height and draft may lower
overall burn times.

DO NOT OVERFIRE THE FIREPLACE! Overfiring can occur
by: a) burning large amounts of smaller wood pieces. b)
vigorously burning large loads of wood with the draft control
on "HIGH" (fully open) for long periods of time (one or two
hours).

ASH REMOV AL PROCEDURES

A bed of ashes approximately 1 inch deep should be left on
the firebox bottom to help maintain a hot charcoal bed.
When the fire has burned down and cooled, remove any
excess ashes. To remove the ash, follow the directions
below.

1. After the last coal has extinguished, let the fireplace cool
at least two hours.

2. Open the fireplace doors.

3. Scoop the ash from the firebox into a metal, airtight, con­tainer with a lid. Cover the container with the lid and move
the container away from the fireplace to ensure the ashes
cool. Dispose of the ashes.

Warning: Improper disposal of ashes result in fires. Do
not discard ashes in cardboard boxes, dump in back yards,
or store in garages.

Note: If using a vacuum to clean up ashes, be sure the
ashes are entirely cooled. Using a vacuum to clean up
warm ashes could cause a fire inside the vacuum.

OVERNIGHT BURN

This fireplace is large enough to accomodate overnight,
14 hour burns. Follow these steps below to achieve an
overnight burn.

1. Get the fireplace hot by moving the air control to high
and letting the fireplace burn for 15 minutes.

2. Load your larger pieces of wood compactly , packed close
enough to prevent the flames from penetrating it completely.

W415-0594 / A / 02.15.07

TIPS FOR BURNING

• Create a large fire to heat up the fireplace before adjusting to a slower burn.

• To create a large, quick burning fire, use small pieces of wood.

• For a lower, but extended burn, stack larger pieces of wood close together.

• For long burns, leave a 1-2" bed of ashes.

• Burn dry wood only.

• With the exception of overnight burns, create large, quick burning fires whenever possible. Smaller,
slow burning fires, using large logs, cause the glass to become dirty. Larger, quick burning fires
using medium sized wood to refuel frequently are much more efficient.

MAINTENANCE

RUN-AWA Y OR CHIMNEY FIRE

Run-away fires can be the result of FOUR major factors:

1. Using incorrect fuel, or small fuel pieces which would
normally be used as kindling.

2. Leaving the door ajar too long and creating extreme
temperatures as the air rushes in the open door.

3. Improperly installed or worn gaskets.
SOLUTIONS:

1. Do not burn treated or processed wood, coal, charcoal,

coloured paper or cardboard.

2. Be careful not to overfire the unit by leaving the door
open too long after the initial start-up.

3. Replace worn, dried out (inflexible) gaskets.
WHA T TO DO IF A RUN-A WA Y OR CHIMNEY FIRE ST ARTS:

1. Close the draft fully (lowest position).

2. Call the local fire department.

3. Examine the chimney, attic and roof of the house, to see

if any part has become hot enough to catch fire. If neces­sary spray with a fire extinguisher or water from a garden
hose.

4. Do not operate the stove again until you are certain the
chimney has not been damaged.

FIRE EXTINGUISHERS AND SMOKE

DETECTORS

All homes with a solid fuel burning fireplace should have
at least one fire extinguisher in a central location, known to
all, and at least one smoke detector in the room containing
the fireplace. If it sounds an alarm, correct the cause but
do not de-activate or relocate the smoke detector.

27

GLASS & GASKET REPLACEMENT

At the end of each burning season inspect the door gasket
ensuring that it is not worn or loose. Replace with proper
fibreglass rope. The purpose of door gasketing is to seal
the firebox. If the doors are not sealed, air leaks into the
firebox, creating a quick burning fire. This situation is not
desireable for overnight or extended burns.
Replace cracked or broken glass immediately. When re­installing the glass, be sure that the glass and gasket
create a solid seal around door frame. Follow the instruc­tions below for glass removal. You many require a flat tool
to gently press the gasket between the glass and the door.
WARNING: Make sure that the glass and gasket are fully
installed down into the glass retainer . If the glass protrudes
too far out of the retainer, the glass will shatter when the
door is closed.

W415-0594 / A / 02.15.07

28

CREOSOTE FORMA TION AND REMOVAL SELECTING WOOD

When wood is burned slowly, it produces tar and other
organic vapours which combine with expelled moisture to
form creosote. These vapours condense in the relatively
cooler chimney flue of a slow burning fire and when ig­nited, make an extremely hot fire. Check your chimney for
creosote and soot build-up monthly until a safe frequency
for cleaning is established (minimum once a year). If ac­cumulation is excessive, clean the chimney. You may want
to call a professional chimney sweep to clean it. Both the
chimney and the fireplace have to be cleaned at least once
a year or as often as necessary.

Burn only dry, clean unpainted wood that has been sea­soned. It produces more heat and less soot or creosote.
Freshly cut wood contains about 50% moisture while after
proper seasoning only about 20% of the water remains. As
wood is burned, this water boils off consuming energy that
should be used in heating. The wetter the wood, the less
heat is given off and the more creosote is produced. Dry
firewood has cracks in the end grain.

Both hardwood and softwood burn equally well in this fire­place but hardwood, which is denser, will weigh more per
cord and burn a little slower and longer.

Firewood should be split and stacked in a manner that air
can get to all parts of it and covered in early spring to be
ready for burning that fall.

W415-0594 / A / 02.15.07

REPLACEMENTS

Contact your dealer for questions concerning prices and
policies on replacement parts. Normally all parts can be
ordered through your Napoleon dealer or distributor.

When ordering replacement parts always give the follow­ing information:

29

1. MODEL & SERIAL NUMBER OF FIREPLACE

2. INSTALLATION DATE OF FIREPLACE

3. PART NUMBER

4. DESCRIPTION OF PART

5. FINISH

FORFOR

FOR

FORFOR

THETHE

THE

THETHE

WARRANTYWARRANTY

WARRANTY

WARRANTYWARRANTY

ORIGINALORIGINAL

ORIGINAL

ORIGINALORIGINAL

REPLREPL

REPL

REPLREPL

INVOICEINVOICE

INVOICE

INVOICEINVOICE

AA

CEMENTCEMENT

A

CEMENT

AA

CEMENTCEMENT

WILLWILL

WILL

WILLWILL

CLAIMCLAIM

CLAIM

CLAIMCLAIM

PP

P

PP

BEBE

REQUIREDREQUIRED

BE

REQUIRED

BEBE

REQUIREDREQUIRED

..

.

..

ARAR

AR

ARAR

TSTS

TS

TSTS

, ,

,

, ,

AA

A

AA

PHOPHO

PHO

PHOPHO
TOTO

TO

TOTO

TT

OCOPYOCOPY

T

OCOPY

TT

OCOPYOCOPY

HONOURHONOUR

HONOUR

HONOURHONOUR

OFOF

OF

OFOF

THETHE

THE

THETHE

FIREPLACE AND A CCESSORY

REPLACEMENT PARTS

# PART NO. DESCRIPTION

1 W300-0069 DOOR GLASS
2* W562-0035 DOOR OR GLASS GASKET
3* W562-0036 DOOR GASKET - CENTRE
4* W010-1225 GLASS & GASKET
5* W690-0005 120V THERMOST AT
6 W090-0099 REAR FIREBRICK
7 W090-0101 BOTTOM RIGHT FIREBRICK
8 W090-0100 BOTTOM LEFT FIREBRICK
9 W090-0098 RIGHT SIDE FIREBRICK
10 W090-0097 LEFT SIDE FIREBRICK
11 W010-1399 BAFFLE
12 W062-0018 BLOWER - NZ64
13* KB35 VARIABLE SPEED CONTROL INCL KNOB
14* W690-0002 HEAT SENSOR
15 W010-1184 LEFT DOOR ASSEMBLY
16 W010-1183 RIGHT DOOR ASSEMBLY
17* W200-0141 PRIMARY AIR PLATE
18* W555-0047 PRIMARY AIR ROD
19 W380-0017 PRIMARY AIR KNOB
20 W010-1193 PRIMARY AIR ACCESS COVER
21 W010-1180 ASH LIP ASSEMBLY
22 W325-0029 DOOR HANDLE - BIRD CAGE
23* W175-0002 8" COUPLER
24* NZ220-2 5'X8" DIA. AIR VENT (FOR GRAVITY HOT AIR VENT)
25* W410-0005 10'X8" DIA AIR VENT (FOR CENTRAL HEATING SYSTEM)
26* W010-0067 VENT SUPPORT BRACKET (FOR CENTRAL HEATING

27 W715-0628 ANDIRONS
28 W185-0020 GRATE
29* W385-0245 NAPOLEON LOGO
30 W410-0026 10'X6" AIR SUPPLY VENT
31 W010-1594 SECONDARY AIR TUBE
32 W290-0121 GASKET, SECONDARY AIR TUBE
33* W450-0028 NUT, HEX BRASS

SYSTEM

)

* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED.

FOR FURTHER INFORMATION, CONTACT YOUR

NAPOLEON

DEALER.

ACCESSORIES

# PART NO. DESCRIPTION

34 H335-K ARCHED DOORS - BLACK
34 H335-G ARCHED DOUBLE DOORS ­34 H335-SC ARCHED DOUBLE DOORS - SATIN CHROME FINISH
34 H335-WI ARCHED DOUBLE DOORS - WROUGHT IRON FINISH
35 FPK FACEPLATE ARCHED - BLACK
35 FPSC FACEPLATE ARCHED - SATIN CHROME FINISH
35 FPWI FACEPLATE ARCHED - WROUGHT IRON FINISH
36 UGK UPPER GRILL ARCHED - BLACK
36 UGG UPPER GRILL ARCHED - GOLD PLATED
36 UGSC UPPER GRILL ARCHED - SATIN CHROME FINISH
37 KSK KEYSTONE - BLACK
37 KSG KEYSTONE - GOLD PLATED
37 KSSC KEYSTONE - SATIN CHROME FINISH
38 NSK ARCHED DOUBLE SCREEN KIT WITH STAND
39 CP CRANE AND POT
40* NZ221 GRAVITY HOT AIR VENT KIT
41 NM228-M FLUE TILE SUPPORT
42 NZAC-KT AIR COOLED CHIMNEY KIT
12* NZ64 BLOWER KIT
31* W250-0005 BLOWER FILTER
32 W305-0007 BLOWER GRILL
33* NZ150-KT CIRCULATION AIR MOUNTING KIT

GOLD PLATED

W415-0594 / A / 02.15.07

30

W415-0594 / A / 02.15.07

TROUBLE SHOO TING GUIDE

B

EFORE ATTEMPTING TO TROUBLESHOOT, PURGE YOUR UNIT AND INITIALLY LIGHT THE PILOT AND THE MAIN BURNER WITH THE GLASS DOOR OPEN

SYMPTOM PROBLEM TEST SOLUTION

Smoke enters the
room during start­up.

Cold air blockage. - burn a piece of newspaper to establish a draft.
Close the doors.

- if the flame is not getting enough air, first make sure the air control
is open. If additional air is needed, open the doors a small crack
only.

- open the by-pass damper

31

.

Kindling does not
start - fire smol­ders.

Smoke enters the
room while re­loading.

Fireplace does
not burn hot
enough.

Blower does not
run.

Faceplate is cold. This is normal. - the air leading into the firebox comes from the exterior. In some

Cold air blockage. - burn a piece of newspaper to establish a draft.

Not enough starter paper.
Not enough air.

Insufficient Draft. - Chimney height and outside conditions can negatively affect draft.

Wood is wet. - see the section on "Selecting Wood" for details.
Insufficient Draft.

Air control is not wide open.

The by-pass damper is in the
"open" position

Fireplace is not up to
temperature.

Electricity is cut to the blower.

- use additional newspaper if necessary.

- first make sure the air control is fully open. If additional air is
needed, a small crack in the doors is all that is needed.

In these cases a small amount of smoke may enter the home. Add­ing more pipe or a draft-inducing cap may help.

- Chimney height and outside conditions can negatively affect draft.
In these cases a small amount of smoke may enter the home. Add­ing more pipe or a draft-inducing cap may help.

- make sure the air control is open all the way . Slide the control back
and forth rapidly to insure the control is not stuck.

- close the by-pass damper

- this is normal. The blower will come on when the fireplace is hot ­usually 15 to 30 minutes.

- check the household breaker or fuse to make sure it is operable.

cases this air comes into the firebox and exits up the chimney. This
will not damage the fireplace.

Fireplace does
not burn overnight.

The doors are not sealing. - the doors are not sealing - see the section "Door Glass / Gasket

"open" position

Replacement" for details.

- close the by-pass damperThe by-pass damper is in the

W415-0594 / A / 02.15.07

32

RATING PLATE

W415-0594 / A / 02.15.07

RATING PLA TE IS L OCATED BEHIND THE FIREPLA CE FACEPLATE.
