Napoleon GSS42CFN Specifications

INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.

CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.

INSTALLATION AND

OPERATING INSTRUCTIONS

CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CR97-003, CAN1-2.21-M85, IAS U.S. 4-96.

OUTDOOR GAS FIREPLACE

GSS42N

NATURAL GAS MODEL

GSS42P

PROPANE GAS MODEL

1

CERTIFIED FOR CANADA AND UNITED STATES USING ANSI/CSA METHODS.

SAFETY INFORMATION

!

WARNING

If the information in these instructions are
not followed exactly, a fi re or explosion
may result causing property damage,
personal injury or loss of life.

- Do not store or use gasoline or other fl ammable
vapors and liquids in the vicinity of this or any
other appliance.

- WHAT TO DO IF YOU SMELL GAS:

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use
any phone in your building.

• Immediately call your gas supplier from a
neighbour’s phone. Follow the gas supplier’s
instructions.

• If you cannot reach your gas supplier, call the
fi re department.

- Installation and service must be performed by a

qualifi ed installer, service agency or the supplier.

WARNING: FOR OUTDOOR USE ONLY

!

WARNING

HOT GLASS WILL CAUSE

BURNS.

DO NOT TOUCH GLASS UNTIL

COOLED.

NEVER ALLOW CHILDREN TO

TOUCH GLASS.

$10.00

Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /

103 Miller Drive, Crittenden, Kentucky, USA, 41030

Phone [phone] • Fax [phone] • www.napoleonfi replaces.com • [e-mail]

1.22A

W415-0617 / D / 03.18.11

2

TABLE OF CONTENTS

1.0 INSTALLATION OVERVIEW 2

2.0 INTRODUCTION 3

2.1 DIMENSIONS 4

2.2 GENERAL INSTRUCTIONS 4

2.3 GENERAL INFORMATION 5

2.4 RATING PLATE INFORMATION 5

3.0 INSTALLATION 6

3.1 GAS INSTALLATION 6

3.2 GAS INLET LOCATIONS 7

3.3 OPTIONAL WALL SWITCH INSTALLATION 7

3.4 COMBUSTION AND VENTILATION AIR 8

4.0 FRAMING 8

4.1 CLEARANCE TO COMBUSTIBLES 8

4.2 MINIMUM ENCLOSURE CLEARANCES 10

4.3 MINIMUM MANTEL CLEARANCES 11

4.4 NAILING TAB 11

5.0 FINISHING 12

5.1 ANDIRON AND GRATE ASSEMBLY 12

5.2 LOG PLACEMENT 12

5.3 GLOWING EMBERS 13

5.4 CHARCOAL LUMPS/LAVA ROCK 13

5.5 HOOD 14

5.6 LOGO PLACEMENT 14

6.0 OPTIONAL REMOTE INSTALLATION 15

7.0 OPERATION 16

8.0 ADJUSTMENT 17

8.1 VENTURI ADJUSTMENT 17

8.2 FLAME CHARACTERISTICS 17

9.0 MAINTENANCE 18

10.0 REPLACEMENTS 19

11.0 TROUBLE SHOOTING 21

12.0 WARRANTY 23

13.0 SERVICE HISTORY 24

NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.

1.0 INSTALLATION OVERVIEW

HOOD, see
“HOOD” section.

ANDIRONS, see
“ANDIRON AND
GRA TE ASSEMBLY”
section.

RATING PLATE, see
“RATING PLATE
INFORMATION”
section.

GRATE, see
“ANDIRON AND
GRA TE ASSEMBLY”
section.

W415-0617 / D / 03.18.11

2.0 INTRODUCTION

• THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED.

• Do not operate appliance before reading and understanding operating instructions. Failure to operate
appliance according to operating instructions could cause fi re or injury.

• Any changes to this appliance or its controls can be dangerous and is prohibited.

• Risk of burns. The appliance should be turned off and cooled before servicing.

• Do not install damaged, incomplete or substitute components.

• Risk of cuts and abrasions. Wear protective gloves and safety glasses during installation. Sheet metal
edges may be sharp.

• Do not burn wood or other materials in this appliance.

• Provide adequate ventilation and combustion air. Provide adequate accessibility clearance for servicing
and operating the appliance. Never obstruct the front opening of the appliance.

• If appliance keeps shutting off, have it serviced. Keep burner and control compartment clean.

• Do not allow wind to blow directly into the appliance. Avoid any drafts that alter burner fl ame patterns.

• Children and adults should be alerted to the hazards of high surface temperature and should stay away
to avoid burns or clothing ignition.

• Young children should be carefully supervised when they are in the same area as the appliance.
Toddlers, young children and others may be susceptible to accidental contact burns. A physical barrier
is recommended if there are at risk individuals in the vicinity of the appliance. To restrict access to an
appliance, install an adjustable safety gate to keep toddlers, young children and other at risk individuals
away from hot surfaces.

• Clothing or other fl ammable material should not be placed on or near the appliance.

• Furniture or other objects must be kept a minimum of 4 feet away from the front of the appliance.

• Ensure you have incorporated adequate safety measures to protect infants/toddlers from touching hot
surfaces.

• Even after the appliance is off, it will remain hot for an extended period of time.

• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children
from hot surfaces. These screens and guards must be fastened to the fl oor.

• Any safety screen or guard removed for servicing must be replaced prior to operating the appliance.

• It is imperative that the control compartments, burners and circulating blower and its passageway in
the appliance and venting system are kept clean. The appliance should be inspected before use and
at least annually by a qualifi ed service person. The appliance area must be kept clear and free from
combustible materials, gasoline and other fl ammable vapors and liquids.

• Under no circumstances should this appliance be modifi ed.

• Do not use this appliance if any part has been under water. Immediately call a qualifi ed service
technician to inspect the appliance and to replace any part of the control system and any gas control
which has been under water.

• Keep the packaging material out of reach of children and dispose of the material in a safe manner. As
with all plastic bags, these are not toys and should be kept away from children and infants.

• This appliance must not be installed indoors or within any structure that prevents or inhibits the exhaust
gases from dissipating in the outside atmosphere.

!

WARNING

3

3.14A

W415-0617 / D / 03.18.11

4

2.1 DIMENSIONS

35 3/4”

21

36 3/8”

1

/8”

5

46

/8”2

2.2 GENERAL INSTRUCTIONS

ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RAN OUT,

WITH THE GLASS DOOR OPENED OR REMOVED.

NEVER OBSTRUCT THE FRONT OPENING OF THE APPLIANCE.

OBJECTS PLACED IN FRONT OF THE APPLIANCE MUST BE KEPT A MINIMUM OF 48” FROM THE

HIGH PRESSURE WILL DAMAGE VALVE. DISCONNECT GAS SUPPLY PIPING BEFORE PRESSURE
TESTING GAS LINE AT TEST PRESSURES ABOVE 1/2 PSIG. CLOSE THE MANUAL SHUT-OFF VALVE
BEFORE PRESSURE TESTING GAS LINE AT TEST PRESSURES EQUAL TO OR LESS THAN 1/2 PSIG.

USE ONLY WOLF STEEL APPROVED OPTIONAL ACCESSORIES AND REPLACEMENT PARTS WITH

THIS APPLIANCE. USING NON-LISTED ACCESSORIES (BLOWERS, DOORS, LOUVRES, TRIMS, GAS

COMPONENTS, VENTING COMPONENTS, ETC.) COULD RESULT IN A SAFETY HAZARD AND WILL

VOID THE WARRANTY AND CERTIFICATION.

THE APPLIANCE IS ONLY FOR USE WITH THE TYPE OF GAS INDICATED ON THE RATING PLATE.

THIS APPLIANCE IS NOT CONVERTIBLE FOR USE WITH OTHER GASES.

THIS GAS APPLIANCE SHOULD BE INSTALLED AND SERVICED BY A QUALIFIED INSTALLER to
conform with local codes. Installation practices vary from region to region and it is important to know the
specifi cs that apply to your area, for example in Massachusetts State:

• The appliance off valve must be a “T” handle gas cock.

• The fl exible connector must not be longer than 36 inches.

1

/2”

!

WARNING

FRONT FACE OF THE APPLIANCE.

FIRE RISK. EXPLOSION HAZARD.

The installation must conform with local codes or, in
absence of local codes, the National Gas and Propane
Installation Code CSA B149.1 in Canada, or the National
Fuel Gas Code, ANSI Z223.1 / NFPA 54 in the United
States.

W415-0617 / D / 03.18.11

www.ncertied.org

We suggest that our gas
hearth products be installed
and serviced by professionals
who are certied in the U.S.
by the National Fireplace

®

Institute

(NFI) as NFI Gas

Specialists

4.3A

The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during

A

OUU

T T

S F

any pressure testing of that system at test pressures in excess of 1/2 psig (3.5 kPa). The appliance must be
isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure
testing of the gas supply piping system at test pressures equal to or less than 1/2 psig (3.5 kPa).

When the appliance is installed directly on combustible material other than wood fl ooring, the appliance shall
be installed on a metal or wood panel extending the full width and depth.

2.3 GENERAL INFORMATION

FOR YOUR SATISFACTION, THIS APPLIANCE HAS BEEN TEST-FIRED TO ASSURE ITS OPERATION
AND QUALITY!

Altitude 0 - 2,000* 0 - 2,000*
Maximum Input 65,000 BTU/hr 65,000 BTU/hr
Minimum Inlet Gas Supply Pressure 4.5” Water Column 11” Water Column
Maximum Inlet Gas Supply Pressure 7” Water Column 13” Water Column
Manifold Pressure Under Flow Conditions 3.5” Water Column 10” Water Column

* When the appliance is installed at elevations above 2,000ft, and in the absence of specifi c recommendations
from the local authority having jurisdiction, the certifi ed high altitude input rating shall be reduced at the rate of
4% for each additional 1,000ft.

5

RATES AND EFFICIENCIES

NATURAL GAS PROPANE GAS

It is highly recommended to protect the logs from moisture (rain, snow). Cover the enclosure opening when not
in use.

This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certifi ed kit is used.

No external electricity (110 volts or 24 volts) is required for the gas system operation.
Expansion / contraction noises during heating up and cooling down cycles are normal and are to be expected.

2.4 RATING PLATE INFORMATION

For rating plate location, see “INSTALLATION OVERVIEW” section.
This illustration is for reference only. Refer to the rating plate on the appliance for accurate information.

CERTIFIED UNDER / HOMOLOGUÉ SELON LES NORMES: CGA CR97-003 (July, 1997) CSA US Req. 4-96, 3rd Ed. OUTDOOR GAS FIREPLACE / FOYER AU GAZ EXTÉRIEUR

MODEL

NATURAL

MODEL

P

PROPANE

AUTRES LIQUIDES ET VAPEURS INFLAMMABLES À

OU TOUT AUTRE APPAREIL.

N'ENTREPOSEZ PAS ET

“
“

SEE INSTALLATION INSTRUCTIONS FOR FRAMING CLEARANCES. POUR LES DÉGAGEMENTS AUX MATÉRIAUX D’OSSATURE, VOIR LE MANUEL D’INSTRUCTIONS.

“

WOLF STEEL LTD.

24 Napoleon Rd. Barrie, Ontario L4M 4Y8 Canada

“

“
“
“

GSS42

INCOMBUSTIBLE

“

W385-0376 / D

W415-0617 / D / 03.18.11

6

3.0 INSTALLATION

3.1 GAS INSTALLATION

RISK OF FIRE, EXPLOSION OR ASPHYXIATION. ENSURE THERE ARE NO IGNITION SOURCES SUCH AS

SUPPORT GAS CONTROL WHEN ATTACHING GAS SUPPLY PIPE TO PREVENT DAMAGING GAS LINE.

ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RUN OUT

WITH THE GLASS DOOR OPENED OR REMOVED. PURGING OF THE GAS SUPPLY LINE SHOULD BE

PERFORMED BY A QUALIFIED SERVICE TECHNICIAN. ASSURE THAT A CONTINUOUS GAS FLOW IS AT

THE BURNER BEFORE CLOSING THE DOOR. ENSURE ADEQUATE VENTILATION. FOR GAS AND

ELECTRICAL LOCATIONS, SEE “DIMENSION” SECTION.

ALL GAS CONNECTIONS MUST BE CONTAINED WITHIN THE APPLIANCE WHEN COMPLETE.

HIGH PRESSURE WILL DAMAGE VALVE. DISCONNECT GAS SUPPLY PIPING BEFORE TESTING GAS

VALVE SETTINGS HAVE BEEN FACTORY SET, DO NOT CHANGE.

Installation and servicing to be done by a qualifi ed installer.

A. Move the appliance into position and secure.
B. If equipped with a fl ex connector the appliance is designed to accept a 1/2” gas supply. Without the

connector it is designed to accept a 3/8” gas supply. The appliance is equipped with a manual shut off
valve to turn off the gas supply to the appliance.

C. Connect the gas supply in accordance to local codes. In the absence of local codes, install to the

current CAN/CSA-B149.1 Installation Code in Canada or to the current National Fuel Gas Code, ANSI
Z223.1 / NFPA 54 in the United States.

D. When fl exing any gas line, support the gas valve so that the lines are not bent or kinked.
E. The gas line fl ex-connector should be installed to provide suffi cient movement for shifting the burner

assembly on it’s side to aid with servicing components.

F. Check for gas leaks by brushing on a soap and water solution. Do not use open fl ame.

!

WARNING

SPARKS OR OPEN FLAMES.

LINE AT TEST PRESSURES ABOVE 1/2 PSIG.

30.1A

W415-0617 / D / 03.18.11

3.2 GAS INLET LOCATIONS

There are fi ve gas inlet locations on the ventless fi rebox enclosure. One on each side of the appliance, two
at the rear, and one on the bottom. Using the following illustrations identify the preferred inlet and remove
corresponding knock out.

"

7 1/

8

5

"15

/

16

16 1/

7

"23 5/

16

"

16

"

7 1/

8

"14

3.3 OPTIONAL WALL SWITCH INSTALLATION

!

WARNING

DO NOT CONNECT EITHER THE WALL SWITCH, THERMOSTAT OR GAS VALVE DIRECTLY TO 110

VOLT ELECTRICITY.

For ease of accessibility, an optional remote wall switch or millivolt thermostat may be installed in a convenient
location. Route a 2 strand, solid core millivolt wire from the valve to the wall switch or millivolt thermostat. The
recommended maximum lead length depends on wire size:
WIRE SIZE MAX. LENGTH
14 gauge 100 feet
16 gauge 60 feet
18 gauge 40 feet

Disconnect the existing wires from terminals 1 and 3 (from the
ON/OFF switch) and replace with the leads from the wall switch / millivolt thermostat.

TP

50.3

P

I

L

O

T

W415-0617 / D / 03.18.11

8

3.4 COMBUSTION AND VENTILATION AIR

This appliance is intended for installation on an outdoor patio or in your yard. It must never be installed inside
the warm air envelope of your structure.

It is highly recommended that this appliance be installed in a “sheltered” area. Direct wind will cause an erratic
fl ame and possible pilot or main burner outage.

An erratic fl ame could also lead to excessive carboning (black soot), this condition is not a safety issue but is
visually undesirable.

Typical installation may include covered patio, screened porch, gazebo or on an outside wall of a house.

* If installing a propane appliance the propane cylinder must always be on the exterior of such a
structure.

NOTE: Ensure the area has adequate ventilation.

4.0 FRAMING

4.1 CLEARANCE TO COMBUSTIBLES

!

WARNING

RISK OF FIRE!

IN ORDER TO AVOID THE POSSIBILITY OF EXPOSED INSULATION OR VAPOUR BARRIER COMING

IN CONTACT WITH THE APPLIANCE BODY, IT IS RECOMMENDED THAT THE WALLS OF THE

APPLIANCE ENCLOSURE BE “FINISHED” (IE: DRYWALL / SHEETROCK), AS YOU WOULD FINISH

ANY OTHER OUTSIDE WALL OF A HOME. THIS WILL ENSURE THAT CLEARANCE TO

COMBUSTIBLES IS MAINTAINED WITHIN THE CAVITY.

DO NOT NOTCH THE FRAMING AROUND THE APPLIANCE STAND-OFFS. FAILURE TO MAINTAIN

AIR SPACE CLEARANCE MAY CAUSE OVER HEATING AND FIRE. PREVENT CONTACT WITH

SAGGING OR LOOSE INSULATION OR FRAMING AND OTHER COMBUSTIBLE MATERIALS. BLOCK

OPENING INTO THE CHASE TO PREVENT ENTRY OF BLOWN-IN INSULATION. MAKE SURE

INSULATION AND OTHER MATERIALS ARE SECURED.

WHEN CONSTRUCTING THE ENCLOSURE ALLOW FOR FINISHING MATERIAL THICKNESS TO
MAINTAIN CLEARANCES. FRAMING OR FINISHING MATERIAL CLOSER THAN THE MINIMUMS

LISTED MUST BE CONSTRUCTED ENTIRELY OF NON-COMBUSTIBLE MATERIALS. MATERIALS
CONSISTING ENTIRELY OF STEEL, IRON, BRICK, TILE, CONCRETE, SLATE, GLASS OR PLASTERS,
OR ANY COMBINATION THEREOF ARE SUITABLE. MATERIALS THAT ARE REPORTED AS PASSING

ASTM E 136, STANDARD TEST METHOD FOR BEHAVIOUR OF MATERIALS IN A VERTICAL TUBE

FURNACE AT 750°C AND UL763 SHALL BE CONSIDERED NON-COMBUSTIBLE MATERIALS.

MINIMUM CLEARANCE TO COMBUSTIBLES MUST BE MAINTAINED OR A SERIOUS FIRE HAZARD

COULD RESULT.

THE APPLIANCE REQUIRES A MINIMUM ENCLOSURE HEIGHT. MEASURE FROM THE APPLIANCE

BASE.

IF STEEL STUD FRAMING KITS WITH CEMENT BOARD ARE PROVIDED, THEY MUST BE

INSTALLED.

71.1

W415-0617 / D / 03.18.11

Minimum Clearance to Combustibles construction from appliance and vent surfaces:

22

1

/

4

"

47

1

/

8

”

36"

S

T

EEL HEADER

S
T
E
E
L

S
T

8

D

S
T
E
E
L

S
T

8

D

STEEL HEADE

R

Framing 0” to stand-offs (rear and sides only)
Use a steel header for the top and two steel studs on the sides.
Finishing 1” to back and sides
Non-combustible fi nishing 18” to top
4” to sides of appliance opening

Non-combustible fi nishing material (ie. cement board, brick, stone, tile) may

be used to fi nish the front of the appliance.
Recessed depth 22 1/4“
Enclosure top 58 1/2” from bottom of appliance
Clearance to ceiling 84” from bottom of appliance.

It is recommended that the walls of the appliance enclosure be fi nished. This would ensure that clearance to
combustibles is maintained within the cavity.

It is best to frame your appliance after it is positioned. Use 2x4’s and frame to local building codes.

"1

"1

"57 1/

4

9

OUTSIDE

CHASE

NOTE:

If this wall surface is inside

the building’s warm envelope ...

... this wall surface must

be an exterior wall surface.

"47 1/

8

"47 1/

8

"81

1

/

4

22

"22 1/

4

"

"47 1/

8

INSIDE
CHASE

"18

W415-0617 / D / 03.18.11

10

!

WARNING

USE ONLY NON-COMBUSTIBLE MATERIAL SUCH AS CEMENT BOARD, CERAMIC TILE, MARBLE,

ETC. WHEN FINISHING TO THE APPLIANCE. DO NOT USE WOOD OR DRYWALL.

*From top of unit.
** An outdoor sealant must be used along the

edge of the fi replace and the non-combustible
material to keep water from entering the chase.

4.2 MINIMUM ENCLOSURE CLEARANCES

STEEL
STUD

OUTDOOR
SEALANT **

4"

NON-COMBUSTIBLE
FINISHING MATERIAL

1

/8"

47
55 1/8"

STEEL

HEADER

18" *

STEEL

STUD

53 3/4"

4"

This appliance requires a minimum enclosure height of 58 1/2”

For temperature requirements, the enclosure space around and above the fi replace must be left unobstructed.

W415-0617 / D / 03.18.11

4.3 MINIMUM MANTEL CLEARANCES

!

RISK OF FIRE, MAINTAIN ALL SPECIFIED AIR SPACE CLEARANCES TO COMBUSTIBLES. FAILURE

TO COMPLY WITH THESE INSTRUCTIONS MAY CAUSE A FIRE OR CAUSE THE APPLIANCE TO

OVERHEAT. ENSURE ALL CLEARANCES (I.E. BACK, SIDE, TOP, VENT, MANTEL, FRONT, ETC.) ARE

CLEARLY MAINTAINED.

WHEN USING PAINT OR LACQUER TO FINISH THE MANTEL, THE PAINT OR LACQUER MUST BE

HEAT RESISTANT TO PREVENT DISCOLOURATION.

We recommend all mantels made from non-combustible material. If using combustible materials, follow the
chart below.

NOTE: Mantel temperatures will rise above normal temperatures
and may be hot to the touch.

32
30

MANTEL

HEIGHT

28
26
24

WARNING

TOP OF

FIREPLACE

73.1

8” MANTEL

6”

30”

28”

26”

11

4”

2”

24”

4.4 NAILING TAB

To install the appliance face fl ush with the fi nished
surface, position the framework to accommodate the
thickness of the fi nished surface. Bend out the six
nailing tabs, attached on top and on either side of the
appliance and secure to the 2x4 framing. The tabs will
facilitate the installation of either a
surface thickness.

42

86 10

MANTEL

DEPTH

1

/

” or 3/4” fi nished

2

35 3/4”

W415-0617 / D / 03.18.11

12

5.0 FINISHING

5.1 ANDIRON AND GRATE ASSEMBLY

A. With the 2 andirons laying face down, secure the grate

overtop using 2 of the 1” hex head screws (supplied in the
manual baggie).

B. Install the grate/andiron assembly to the burner base using

4 x 1” hex head screws (supplied in the manual baggie).

5.2 LOG PLACEMENT

FAILURE TO POSITION THE LOGS IN ACCORDANCE WITH THESE DIAGRAMS OR FAILURE TO USE

ONLY LOGS SPECIFICALLY APPROVED WITH THIS APPLIANCE MAY RESULT IN PROPERTY

LOGS MUST BE PLACED IN THEIR EXACT LOCATION IN THE APPLIANCE. DO NOT MODIFY THE

PROPER LOG POSITIONS, SINCE APPLIANCE MAY NOT FUNCTION PROPERLY AND DELAYED

THE LOGS ARE FRAGILE AND SHOULD BE HANDLED WITH CARE.

PHAZERTM logs and glowing embers exclusive to Napoleon, provide a unique and realistic glowing effect that is

different in every installation. Take the time to carefully position the glowing embers for a maximum glowing effect.
Log colours may vary. During the initial use of the appliance, the colours will become more uniform as colour
pigments burn in during the heat activated curing process.

!

WARNING

DAMAGE OR PERSONAL INJURY.

IGNITION MAY OCCUR.

Use only accessories

designed for and listed

with your specific log

set.

A

B

76.1A

1

A. Place the rear log #1 onto the locating pins

along the back edge of the burner.

PORT CAVITY

2

B. Position log #2 onto the locator pins on

the burner. Ensure the port cavity on the
underside of the log is positioned such that
it runs over the ports allowing them to be
exposed.

W415-0617 / D / 03.18.11

3

13

4

C. Place the end of log #3 on the right side of

the knot of log #1. The “Y” in the log should
straddle the knot on top of log #2.

5

E. Position the slot in the bottom of log #5 onto

the bracket beside the burner on the right,
and against the back side of the andiron with
the charred face of the log to the front.

IMPORTANT

IT IS HIGHLY RECOMMENDED TO PROTECT THE LOGS FROM MOISTURE.

COVER THE FIREBOX WHEN NOT IN USE.

D. Place locating pin in the end of log #4 into the

hole in log #2. Place the locating pin on the
underside of the “Y” in log #4 into the hole in
log #1.

5.3 GLOWING EMBERS

Glowing embers (not supplied) may be used to enhance the fl ame’s appearance.

5.4 CHARCOAL LUMPS/LAVA ROCK

A. Place lava rock around the base of the fi replace,

making sure not to block any burner ports or valve
access. Retain a small amount of lava rock for step C.

B. Place formed charcoal lumps around the front and

sides of the unit.

C. Use remaining lava rock to blend with the charcoal

lumps.

W415-0617 / D / 03.18.11

14

LOGO

½"

5.5 HOOD

DO NOT OPERATE WITHOUT HOOD IN PLACE. THE APPLIANCE HOOD MUST NOT BE MODIFIED OR

NOTE: Remove the hood from the inside of the
appliance by cutting the strap holding it in place.

A. Line the 3 tabs on the back of the hood up with

the 3 slots in the appliance front.

B. Tilt the hood to insert the tabs into the slots and

allow the hood to come forward and rest against
the fi rebox.

5.6 LOGO PLACEMENT

!

WARNING

REPLACED WITH ANOTHER HOOD.

Remove the backing of the logo supplied. Centre the logo on the
front of the appliance, ½” in from the left side, as shown.

LOGO

½"

W415-0617 / D / 03.18.11

6.0 OPTIONAL REMOTE INSTALLATION

15

REMOTE

RECEIVER

TO OPE

PRE

SS

N

SLIDE
SWITCH

BA

T.L

OW

F
IREPL

R
EM

ACE

O
TE

O

O

N

FF

REMOT

E

FACEPLATE

VALV E

JUNCTION

BOX

REAR BURNER BASE

A. Slide the junction box into the hole located at the rear of the burner base. Secure using two of the

screws provided.

B. Secure the faceplate to the junction box with two of the screws provided.
C. Insert the remote receiver (with batteries installed) though the opening in the faceplate and into

the junction box. The remote receiver is secured and released with a catch mechanism, push the
receiver into the catch to secure.

D. Insert the slide switch into it’s marked position on the faceplate.
E. Replace the existing switch wires connected to the terminals on the valve marked TH/TP and TH with

those running from the junction box.

NOTE: The remote switch on the side of the unit is no longer operational.

W415-0617 / D / 03.18.11

16

A

7.0 OPERATION

!

WARNING

IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT

CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.

When lit for the fi rst time, the appliance will emit an odor for a few hours. This is a normal temporary condition
caused by the “burn-in” of paints and lubricants used in the manufacturing process and will not occur again.

fter extended periods of non-operation such as following a vacation or a warm weather season, the appliance
may emit a slight odor for a few hours. This is caused by dust particles in the heat exchanger burning off. In
both cases, suffi ciently ventilate the area.

FOR YOUR SAFETY READ BEFORE LIGHTING:

A. This appliance is equipped with a pilot which must be lit by hand while following these instructions exactly.
B. Before operating smell all around the appliance area for gas and next to the fl oor because some gas is

heavier than air and will settle on the fl oor.
C. Use only your hand to turn the gas control knob. Never use tools. If the knob will not turn by hand, do not
try to repair it. Call a qualifi ed service technician. Force or attempted repair may result in a fi re or
explosion.
D. Do not use this appliance if any part has been under water. Immediately call a qualifi ed service technician
to inspect the appliance and replace any part of the control system and any gas control which has been
under water.

WHAT TO DO IF YOU SMELL GAS:

• Do not use a mobile or land phone.

• If you cannot reach your gas supplier, call the fi re
department.

• Do not try to light any appliance.

• Immediately call your gas supplier from a
neighbour’s phone. Follow the gas supplier’s
instructions.

• Turn off all gas to the appliance.

LIGHTING INSTRUCTIONS:

1. Stop! Read the above safety information on this label.

2. Turn the gas knob clockwise to off.

3. Wait fi ve (5) minutes to clear out any gas. If you smell gas including near the fl oor, STOP! Follow “B” in the

above safety information on this label. If you don’t smell gas go to the next step.

4. If the appliance is equipped with fl ame adjustment valve turn clockwise to off.

5. Find pilot located in front of back log.

6. Turn gas knob counter-clockwise to pilot.

7. Depress and hold gas knob while lighting the pilot with the push button igniter. Keep knob fully depressed

for one minute, then release. If pilot does not continue to burn repeat steps 3 through 7.

8. With pilot lit, turn gas knob counter-clockwise to on.

9. If equipped with fl ame adjustment valve, push and turn knob to high.

10. If equipped with remote on-off switch, main burner may not come on when you turn the valve to on or high.

Remote switch must be in the on position to ignite burner.

TO TURN OFF GAS:

Push in gas control knob slightly and turn clockwise to off. DO NOT FORCE.

47.9

W415-0617 / D / 03.18.11

8.0 ADJUSTMENT

8.1 VENTURI ADJUSTMENT

CARBON CAN BE DISTRIBUTED IN SURROUNDING LIVING AREA IF THE AIR SHUTTER IS

This appliance has an air shutter that has been factory set open according
to the chart below:

Regardless of venturi orientation, closing the air shutter will cause a more
yellow flame, but can lead to carboning. Opening the air shutter will cause a
more blue flame, but can cause flame lifting from the burner ports. The
flame may not appear yellow immediately; allow 15 to 30 minutes for the
final flame colour to be established.

AIR SHUTTER ADJUSTMENT MUST ONLY BE DONE BY A QUALIFIED
INSTALLER!

!

WARNING

IMPROPERL Y ADJUSTED.

17

49.5

VENTURI
BURNER

AIR
SHUTTER
OPENING

ORIFICE

49.1

8.2 FLAME CHARACTERISTICS

It’s important to periodically perform a visual check of the pilot and
burner fl ames. Compare them to the illustrations provided. If any fl ames
appear abnormal call a service person.

NG

LP

3/8” - 1/2”

FLAME MUST

ENVELOPE UPPER

3/8" TO 1/2" OF

THERMOCOUPLE &

THERMOPILE

54.2

GSS42

1/8”
1/4”

W415-0617 / D / 03.18.11

18

9.0 MAINTENANCE

MAINTENANCE

MAINTENANCE

MAINTENANCE

TURN OFF THE GAS AND ELECTRICAL POWER BEFORE SERVICING THE APPLIANCE.

APPLIANCE MAY BE HOT, DO NOT SERVICE UNTIL APPLIANCE HAS COOLED.

DO NOT USE ABRASIVE CLEANERS.

CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper
and dangerous operation. Verify proper operation after servicing. This appliance and its venting system
should be inspected before use and at least annually by a qualifi ed service person. The appliance area must
be kept clear and free of combustible materials, gasoline or other fl ammable vapors and liquids. The fl ow of
combustion and ventilation air must not be obstructed.

1. In order to properly clean the burner and pilot assembly, remove the logs, rocks and/or glass to
expose both assemblies.

2. Keep the control compartment, media, burner, air shutter opening and the area surrounding the logs
clean by vacuuming or brushing, at least once a year.

3. Check to see that all burner ports are burning. Clean out any of the ports which may not be burning or
are not burning properly.

4. Check to see that the pilot fl ame is large enough to engulf the fl ame sensor and/or thermocouple /
thermopile as well as reaches the burner.

5. Replace the cleaned logs, rocks or glass. Failure to properly position the media may cause carboning
which can be distributed in the surrounding living area.

6. Check to see that the main burner ignites completely on all openings when turned on. A 5 to 10
second total light-up period is satisfactory. If ignition takes longer, consult your local authorized dealer /
distributor.

!

WARNING

40.16

Stainless steel tends to oxidize or stain in the presence of chlorides and sulfi des, particularly in coastal areas
and other harsh environments, such as the warm, highly humid atmosphere around pools and hot tubs. These
stains could be perceived as rust, but can be easily removed or prevented. To provide stain prevention and
removal, wash all stainless steel surfaces every 3-4 weeks or as often as required with fresh water and/or
stainless steel cleaner.

CLEANING THE STAINLESS STEEL SURFACE:

Do not use abrasive cleaners or steel wool on the stainless steel parts. Doing so will scratch the fi nish. Sur-
faces should be cleaned with warm soapy water while the metal is still warm to the touch. To clean stainless
surfaces, use a stainless steel or non-abrasive cleaner. Always wipe in the direction of the grain. Over time,
stainless steel parts discolour when heated, usually to a golden or brown hue. This discolouration is normal
and does not affect the performance of the appliance.

81.1

W415-0617 / D / 03.18.11

10.0 REPLACEMENTS

FAILURE TO POSITION THE PARTS IN ACCORDANCE WITH THIS MANUAL OR FAILURE TO USE

ONLY PARTS SPECIFICALLY APPROVED WITH THIS APPLIANCE MAY RESULT IN PROPERTY

DAMAGE OR PERSONAL INJURY.

** THIS IS A FAST ACTING THERMOCOUPLE. IT IS AN INTEGRAL SAFETY COMPONENT. REPLACE ONLY WITH

A FAST ACTING THERMOCOUPLE SUPPLIED BY WOLF STEEL LTD.

Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally
all parts can be ordered through your Authorized dealer / distributor.

FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE ORIGINAL INVOICE WILL BE
REQUIRED TO HONOUR THE CLAIM.

When ordering replacement parts always give the following information:

• Model & Serial Number of appliance

• Installation date of appliance

• Part number

• Description of part

• Finish

* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR FURTHER INFORMATION, CONTACT YOUR
AUTHORIZED DEALER.

!

WARNING

19

41.2

COMPONENTS

REF NO. PART NO. DESCRIPTION

1 W357-0001 PIEZO IGNITER
2 W680-0015 THERMOPILE
3 W680-0014 THERMOCOUPLE**
4 W010-1194 NATURAL GAS PILOT ASSEMBLY
4 W010-1201 PROPANE GAS PILOT ASSEMBLY
5 W455-0070 NATURAL GAS PILOT INJECTOR
5 W455-0068 PROPANE GAS PILOT INJECTOR
6 W725-0028 NATURAL GAS VALVE
6 W725-0029 PROPANE GAS VALVE
7* W750-0188 WIRE, HARNESS
8* W456-0023 #23 NATURAL GAS BURNER ORIFICE
8* W456-0043 #43 PROPANE GAS BURNER ORIFICE
9* W660-0009 ON/OFF SWITCH
10 W010-1739 BURNER, PAN ASSEMBLY
11* W240-0005 ELECTRODE LEAD
12* W385-0334 NAPOLEON® LOGO
13 W335-0048 HOOD
14 W330-0060 HINGE, FEMALE
15 W330-0059 HINGE, FEMALE
16 W330-0062 HINGE, MALE
17* W325-0028 DOOR HANDLE
18 W300-0093 GLASS
19* W010-1747 ASSY, MAGNET BRACKET
20 GL-644 LOG SET
21 W135-0205 BACK LOG (#1)
22 W135-0206 MIDDLE LOG (#2)
23 W135-0207 RIGHT LOG (#3)
24 W135-0208 LEFT LOG (#4)
25 W135-0218 CROSSOVER LOG (#5)

W415-0617 / D / 03.18.11

20

COMPONENTS

REF NO. PART NO. DESCRIPTION

26 W185-0023 GRATE
27 W715-0629 ANDIRONS
28* W550-0006 LAVA ROCK
29* W550-0002 CHARCOAL LUMPS

ACCESSORIES

REF NO. PART NO. DESCRIPTION

30 GD840KT BRICK KIT
31* W361-0016 GLOWING EMBERS
32* F40 REMOTE CONTROL

1

6

10

27

2

**3

5

14

15

16

26

30

4

20

13

18

21

23

24

25

22

W415-0617 / D / 03.18.11

11.0 TROUBLE SHOOTING

!

WARNING

ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RAN OUT,

WITH THE GLASS DOOR OPEN OR REMOVED.

TURN OFF THE GAS AND ELECTRICAL POWER BEFORE SERVICING THE APPLIANCE.

APPLIANCE MAY BE HOT, DO NOT SERVICE UNTIL APPLIANCE HAS COOLED.

DO NOT USE ABRASIVE CLEANERS.

SYMPTOM PROBLEM TEST SOLUTION

Main burner goes out; pilot
stays on.

Main burner goes out; pilot
goes out.

Pilot goes out when the
gas knob is released.

The gas valve has an
interlock device which
will not allow the pilot
burner to be lit until
the thermocouple
has cooled. Allow
approximately 60
seconds for the
thermocouple to cool.

Pilot burning; no gas to
main burner; gas knob
is on ‘HI’; wall switch /
thermostat is on.

Pilot will not light. No spark at pilot burner. - Check if pilot can be lit by a match.

PILOT

BURNER

THERMOCOUPLE

THERMOPILE

Pilot fl ame is not large
enough or not engulfi ng the
thermopile.

Thermopile shorting. - Clean thermopile connection tot he valve. Reconnect.

Remote wall switch wire is too
long; too much resistance in
the system.

Faulty thermostat or switch. - Replace.
Refer to “MAIN BURNER GOES OUT; PILOT STAYS ON”

System is not correctly
purged.

Out of propane gas. - Fill the tank.
Pilot fl ame is not large

enough.
Pilot fl ame is not engulfi ng the

thermocouple
Thermocouple shorting / faulty. - Loosen and tighten thermocouple.

Faulty valve. - Replace.
Thermostat or switch is

defective
Wall switch wiring is defective. - Disconnect the switch wires & connect a jumper wire

Main burner orifi ce is plugged. - Remove stoppage in orifi ce.
Faulty valve. - Replace.

Out of propane gas. - Fill the tank.
Spark gap is incorrect. - Spark gap should be 0.150” to 0.175” (5/32” to 11/64”

No gas at the pilot burner. - Check that the manual valve is turned on.

21

- Turn up the pilot fl ame.

- Replace pilot assembly.

- Replace thermopile / valve.

- Shorten wire to connect length or wire gauge.

- Purge the gas line.

- Turn up the pilot fl ame.

- Gently twist the pilot head to improve the fl ame pattern
around the thermocouple.

- Clean thermocouple and valve connection.

- Replace thermocouple.

- Replace valve.

- Connect a jumper wire across the wall switch terminals;
if main burner lights, replace switch / thermostat.

across terminals 1 & 3; if the main burner lights, check
the wires for defects and/or replace wires.

- Check that the wire is connected to the push button
igniter.

- Check if the push button igniter needs tightening.

- Replace the wire if the wire insulation is broken or frayed.

- Replace the electrode if the ceramic insulator is cracked
or broken.

- Replace the push button ignitor

approx.) from the electrode tip and the pilot burner. To
ensure proper electrode location, tighten securing nut
(fi nger tight plus 1/4 turn).

- Check the pilot orifi ce for blockage.

- Replace the valve.

- Call the gas distributor.

42.10

W415-0617 / D / 03.18.11

22

SYMPTOM PROBLEM TEST SOLUTION

Pilot goes out while
standing; Main burner is in
‘OFF’ position.

Flames are consistently
too large or too small.
Carboning occurs.

Carbon is being deposited
on logs or combustion
chamber surfaces.

White / grey fi lm forms. Sulphur from fuel is being

Remote wall switch is in
’OFF’ position; main burner
comes on when gas knob
is turned to ‘ON’ position.

Gas piping is undersized. - Turn on all gas appliances and see if pilot fl ame fl utters,

diminishes or extinguishes, especially when main burner
ignites. Monitor appliance supply working pressure.

- Check if supply piping size is to code. Correct all
undersized piping.

Unit is over-fi red or underfi red. - Check pressure readings:

- Inlet pressure can be checked by turning screw (A)
counter-clockwise 2 or 3 turns and then placing pressure
gauge tubing over the test point. Gauge should read
7” (minimum 4.5”) water column for natural gas or 13”
(minimum 11”) water column for propane. Check that
main burner is operating on ‘HI’.

P

I

L

O

T

Air shutter has become
blocked.

Flame is impinging on the logs
or combustion chamber.

deposited on glass, logs or
combustion chamber surfaces.

Wall switch is mounted upside
down.

Remote wall switch is
grounding.

Remote wall switch wire is
grounding.

Faulty valve. - Replace.

- Outlet pressure can be checked the same as above
using screw (B). Gauge should read 3.5” water column
for natural gas or 10” water column for propane. Check
that main burner is operating on ‘HI’.

- AFTER TAKING PRESSURE READINGS, BE SURE TO
TURN SCREWS CLOCKWISE FIRMLY TO RESEAL.
DO NOT OVER TORQUE.

- Leak test with a soap and water solution.

- Ensure air shutter opening is free of lint or other
obstructions.

- Check that the logs are correctly positioned.

- Open air shutter to increase the primary air.

- Check the input rate: check the manifold pressure and
orifi ce size as specifi ed by the rating plate values.

- Clean the glass with a recommended gas appliance
glass cleaner.

- DO NOT CLEAN GLASS WHEN HOT.

- If deposits are not cleaned off regularly, the glass may
become permanently marked.

- Reverse.

- Replace.

- Check for ground (short); repair ground or replace wire.

W415-0617 / D / 03.18.11

42.10_2

12.0 WARRANTY

NAPOLEON® gas appliances are manufactured under the strict Standard of the world recognized

NAPOLEON® products are designed with superior components and materials, assembled by trained craftsmen who take

great pride in their work. The burner and valve assembly are leak and test-fi red at a quality test station. Once assembled

the complete appliance is thoroughly inspected by a qualifi ed technician before packaging to ensure that you, the customer,

receives the quality product that you expect from NAPOLEON®.

NAPOLEON® GAS APPLIANCE 5 YEAR LIMITED WARRANTY

All stainless steel components of your new NAPOLEON® gas appliance are warranted against defects for
fi ve years.
All parts such as gas valves, logs, gasketing are covered and NAPOLEON® will provide replacement parts
free of charge during the fi rst year of the limited warranty.*
Labour related to warranty repair is covered free of charge during the fi rst year. Repair work, however,
requires the prior approval of an authorized company offi cial. Labour costs to the account of NAPOLEON®
are based on a predetermined rate schedule and any repair work must be done through an authorized
NAPOLEON® dealer.
* Construction of models vary. Warranty applies only to components included with your specifi c appliance.

NAPOLEON® warrants its products against manufacturing defects to the original purchaser only. Registering your warranty is not necessary.
Simply provide your proof of purchase along with the model and serial number to make a warranty claim. NAPOLEON® reserves the right to have
its representative inspect any product or part thereof prior to honouring any warranty claim. Provided that the purchase was made through an
authorized NAPOLEON® dealer your appliance is subject to the following conditions and limitations:
Warranty coverage begins on the date of original installation.
This limited warranty applies only while the unit remains at the site of original installation, and only if the unit is installed in Canada or the United
States.
This factory warranty is nontransferable and may not be extended whatsoever by any of our representatives.
Installation must be done in accordance with the installation instructions included with the product and all local and national building and fi re codes.
This limited warranty does not cover damages caused by misuse, lack of maintenance, accident, alterations, abuse or neglect and parts installed
from other manufacturers will nullify this warranty.
This limited warranty further does not cover any scratches, dents, corrosion or discolouring caused by excessive heat, abrasive and chemical
cleaners, mechanical breakage of logs and embers.
In the fi rst year only, this warranty extends to the repair or replacement of warranted parts which are defective in material or workmanship provided
that the product has been operated in accordance with the operation instructions and under normal conditions.
After the fi rst year, with respect to this Limited Warranty, NAPOLEON® may, at its discretion, fully discharge all obligations with respect to this
warranty by refunding to the original warranted purchaser the wholesale price of any warranted but defective part(s).

After the fi rst year, NAPOLEON® will not be responsible for installation, labour or any other costs or expenses related to the reinstallation of a
warranted part, and such expenses are not covered by this warranty.
Notwithstanding any provisions contained in this Limited Warranty, NAPOLEON’S responsibility under this warranty is defi ned as above and it shall
not in any event extend to any incidental, consequential or indirect damages.
This warranty defi nes the obligations and liability of NAPOLEON® with respect to the NAPOLEON® gas appliance and any other warranties
expressed or implied with respect to this product, its components or accessories are excluded.
This limited warranty does not cover damages resulting from the use of components not supplied with the appliance, or the use of fuel other than
those specifi ed.
Any damages to appliance due to weather, long periods of dampness, condensation, damaging chemicals or cleaners will not be the responsibility
of NAPOLEON®.
The bill of sale or copy will be required together with a serial number and a model number when making any warranty claims from your authorized
dealer. The warranty registration card must be returned within fourteen days to register the warranty.
NAPOLEON® reserves the right to have its representative inspect any product or part thereof prior to honouring any warranty claim.
All parts replaced under the Limited warranty policy are subject to a single claim.
All parts replaced under the warranty will be covered for a period of 90 days from the date of their installation.
The manufacturer may require that defective parts or products be returned or that digital pictures be provided to support the claim. Returned
products are to be shipped prepaid to the manufacturer for investigation. If a product is found to be defective, the manufacturer will repair or replace
such defect.
Before shipping your appliance or defective components, your dealer must obtain an authorization number. Any merchandise shipped without
authorization will be refused and returned to sender.
Shipping costs are not covered under this warranty.
Additional service fees may apply if you are seeking warranty service from a dealer.
Labour, travel, diagnostic tests, shipping and other related charges are not covered by this warranty.

ALL SPECIFICATIONS AND DESIGNS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE DUE TO ON-GOING PRODUCT IMPROVEMENTS.

NAPOLEON® IS A REGISTERED TRADEMARK OF WOLF STEEL LTD.

23

ISO 9001 : 2008 Quality Assurance Certifi cate.

CONDITIONS AND LIMITATIONS

2.9B

W415-0617 / D / 03.18.11

24

13.0 SERVICE HISTORY

W415-0617 / D / 03.18.11

43.1
