Napco TRILOGY BROCHURE

Download

Page 1

Trusted

Trilogy Locks

Everywhere

Page 2

• • •

Trilogy

• • • • • • •

Trilogy economical audit trail cylindrical

security lock

DL2800

•

Trilogy

#1 Best-Selling

Electronic Access

Lock in the USA

DL2700 Series

Grade 1

Retrofit Any Knobset

Trilogy® T2 standalone digital cylindrical keyless door lock

DL2700 SERIES

#1 Best-selling access lock in its class, the keyless electronic door lock – now with more codes & power!

• Up to 100 3-5 digit codes, ﬁ ngertip programmable: 1 master code, 10 managers, 90 basic users, 3 one-time service codes

hospital retail airport schools

• Durable BHMA Grade 1, all-metal vandalproof keypad, ﬁ ngertip programmable

• Standalone keyless access installed in under an hour; easily retroﬁ ts standard knobsets

• Long life 5AA battery operated; 200,000 cycles, typ.

• Low battery alert; mechanical key override; non-handed

• Choice of 7 architectural ﬁ nishes including standard US26D Satin chrome, US3 polished brass, and US5 Antique Brass

• Also available with 5 different interchangeable core preps

• Outdoor version of above, -31˚ to +151˚F, weatherproof models

Audit Trail

Trilogy economical audit trail cylindrical security lock

DL2800

• 1000 event audit trail log, time-stamped by day, date, time and user

• 150 schedules: automatic lock/unlock,etc.

• 200 user codes: Master, manager, supervi-

sor and basic users. Also one-time service code (3-6 digits)

• Weatherproof -31˚ to +151˚F

• 5AA Battery operated; 80,000 cycles, typ.

• Also, DL3000 Advanced version, with 300

user codes & 1600 event audit trail

All Trilogys feature

no fee/license FREE

Windows-based

software

pharmacy

ofﬁce

Restrooms/Classrooms

Trilogy Privacy/Lock Down Pushbutton –for restrooms, on-call rooms, ﬁ le rooms, ﬁ tting rooms, classrooms

DL4100 CYLINDRICAL PRIVACY LOCK

• Privacy Pushbutton – on inside door to temporarily lock-out keypad codes

• Occupied and multi-status LED indicator, ﬂ ashes when time-settable privacy/locked session is on

• Self-stick instructional signage, supplied (bilingual Eng./Span.)

• 2000 PIN codes; 500 scheduled events; 40,000 audit trail

• Keypad or PC programming/reporting

• Weatherproof -31˚ to +151˚F

• 5AA battery operated; 60,000 cycles, typ.

• Mortise lock version, 4500 Series

ID Card Use

Trilogy Prox Lock With Audit Trail

PDL3000: TRILOGY CYLINDRICAL PROX LOCK WITH AUDIT TRAIL

• 2000 user codes (3-6 digits) and/or accepts HID

• Multilevel security - Master; manager; supervisor; basic users

• Easy Tap & Add batch ID card enrollment mode allows many cards to be quickly added without PC –also- downloadable from PC or enroller tool

• 40,000 event audit trail log

• 150 scheduled events

• PC programming/reporting

• Quick passage mode

• Weatherproof -31˚ to +151˚F

• 5AA Battery operated; 60,000 cycles, typ.

prox cards and keyfobs

Page 3

High Security Pin/Prox ID

Trilogy high security mortise locks and keyless gate locks with and without prox

DL3500 SERIES TRILOGY MORTISE PIN LOCKS

• 300 User codes: Master, manager, supervisor & basic users for keyless gate locks

• Fingertip or Windows PC-programmable

• Weatherproof -31˚ to +151˚F

• Real time clock enables up to 500 sched-

uled events and holiday schedules

• 40,000 Event audit trail provides a printed time/date- stamped log of all electronic activity

• Long-life 5AA batteries for 80,000 cycles, typ. and low-battery alert

• 1 3/8” (3.5 cm) mortise cylinder supplied

• 40,000 event audit trail log

• 500 scheduled events, e.g., lock or unlock

• PC programming/reporting

• Quick passage mode

• Program data transferred to lock via PC

or module

• Classroom latch, available in right hand or left handed lock model

PDL3500 SERIES TRILOGY MORTISE PIN/PROX ID LOCKS

Built in HID prox reader, similar to above, but with:

• 2000 user codes (3-6 digits) and/or HID prox cards/fobs

• Multilevel security - Master; manager; supervisor; basic users

• Easy Tap & Add batch prox ID card enrollment mode allows many cards to be quickly added without PC –also– downloadable from PC or prox enroller tool

• PC programming/reporting

• Quick passage mode

• Program data transferred to lock via PC

or module

• 5AA battery operated; 75,000 cycles, typ.

• Classroom latch, available in right hand or

left handed lock model

Glass/Aluminum Doors

Trilogy Narrow Stile Pushbutton aluminum door trim latch locks for PIN or Prox ID card access

DL1200, DL1300, PDL1300

• DL1200 supports 100 3-5 digit PIN user

codes , ﬁ ngertip programmable

• DL1300 supports 2000 users, PC programming/reporting and features 40,000 event audit trail by user and 500 event schedule/real time clock (e.g., lock/unlock by time)

• PDL1300 Prox-reader model of above, supports 2000 Prox ID cards and/or PIN users. Version of 1YND1 with built-in HID Prox reader and tap-add enroller function for ID inputting at the lock.

• Aluminum door retroﬁ t outside trim for Adams Rite 4730, 4900 Series and MS1850S and MS1950S Series latch locks

• Add keyless convenience to mechanical latch locks from Trilogy’s all-metal, vandal-resistant 12-button keypad and/ or automatic timed-scheduled locking/ unlocking, PC programming & audit trail with P/DL1300 Series

• Weatherproof -31˚ to +151˚F

• Long-life, battery-operated for 100,000

and 80,000 cycles respectively, typ. on 2 lithium 3V batteries, supplied; low battery alert

• Key override mortise cylinder, 1-1/4" supplied. (Supports 1-1/8", 1-1/4" and 1-3/8"). Backsets 31/32",1-1/8" and 1-1/2" ; Stile thickness 1-3/4"

• Non-handed; fully ﬁ eld-reversible

• US26D satin chrome or US10B Duronodic

1850, 1950, 4710, 4070,

Exit Doors

TrilogyExit retroﬁ ts existing exit bars and saves manpower on guard tours

Upgrade existing panic bars with Trilogy® Exit pushbutton PIN code or Prox ID card access. Get Trilogy convenience and set un/lock schedules to save the manpower required to physically dog-down doors, plus get event logs of use. Use with panic exit devices from most major manufacturers.

• ETDL Series support 2000 PIN code users, Yale, Sargent versions, respectively

• ETPDL Series Prox-reader model of above, supports 2000 Prox ID cards and/ or PIN users. Built-in HID Prox reader and tap-add enroller at the lock. Yale, Sargent versions, respectively

• Clutch mechanism ensures long life and durability

• Fingertip and/or Windows Programmable

• Real Time Clock for up to 40,000 Event Time/Date-Stamped Audit Trail

• Up to 500 Lock/Unlock Schedules (with Time Zone Support)

• Non-Handed; Fully Field Reversible

• Battery operated; uses 5 AA batteries

• Rim cylinder supplied; Choice of 7 ﬁ nishes

• Retroﬁ t Von Duprin

& Yale

, Dorma® 9300, Arrow® 3800,

Sargent 9800

, Precision® 1100 & Cal Royal®

99, Corbin® ED5000

Page 4

Glass Pushbar Doors

Narrow Stile TrilogyExit keyfree convenience and greater security for panic exit devices on aluminum frame glass doors

Trilogy Narrow Stile Exit Trim retroﬁ ts

Arrow

, DCI®, Von Duprin® and Dorma®

panic exit bars - ideal for storefronts!

• DL1200ET supports 100 3-5 digit PIN user codes, all-metal keypad, programmable

• DL/PDL1300ET 2000 PINs or Prox IDs (PDL) plus PC programming, auto-scheduling lock/unlock & audit trail

• Weatherproof -31˚ to +151˚F.

• 2 lithium 3V long-life, batteries for

100,000 & 80,000 cycles respectively, typ.

Trilogy: Keyless access locks trusted

by more leading retailers, ﬁ rms,

hospitals, schools & airports

Access Keypads

Trilogy Matching Weatherproof PIN/Prox. ID Access Keypads

DK3000 & PDK3000 TRILOGY PIN & PIN/PROX ID KEYPADS

12/24VAC/DC Wall mount or single gang box. Ideal for elevator banks, gates and for use with electric strikes or mag locks. Match ﬁ t and function with Trilogy Locks.

• 2000 users (PIN code or prox ID on PDL model)

• 2 High-Current Rated 8A Relays for entry, alarm zone shunting or lock release by 500 event real-time schedule

• Keypad or PC programmable

• 40,000 Event audit trail print to PC

• Timed Egress Input – Selectable door

open times 5, 10 or 15 seconds

• Tamper supervised (reportable to alarm system)

• Remote release feature; request-to-exit input

• Weatherproof -31˚ to 151˚F

Communicate Wirelessly

Trilogy Networx™ communicate wirelessly via Ethernet or 802.11

• Wireless networking eliminates door-todoor programming and audit trail queries by communicating wirelessly via ethernet or 802.11

• Systemwide global lockdown/unlock in under 10 seconds from any lock or the network’s PC

• Unsurpassed battery-life, exceeding 5 years

• Up to 2000 locks and a PC communicate wirelessly, AES-encrypted thru 900MHz bidirectional gateways

• No wiring; No repeaters; No hardwiring to server; NO extra power supplies, No access panels

• Remote Management via VPN-connection

• Networx locks share one common da-

tabase with original standalone Trilogy locks and can operate as standalones until networking is done

• 5,000 3-6 digit PIN users and/or HID prox ID cards (PD-models), 500 scheduled events (incldg program uploads) and 35,000 event log

• Models for all doors: Cylindrical (P/ DL6100 Series); Mortise (P/DL6500 Series) locks & retroﬁ t exit trim models for most brands: Von Duprin, Corbin, Yale, Dorma,

Arrow, Sargent (ETDLN/PDLN)

Amityville, NY 11701 • USA • 1-800-ALA-LOCK 631-789-4871 • Fax: 631-789-3383 • www.alarmlock.com

Trilogy® is a registered trademark of Alarm Lock. © Alarm Lock, 2010 Speciﬁ cations subject to change. Patents Pending. ALA494

HID®, Adams Rite®, Yale®, Sargent®, Von Duprin®, Arrow®, Cal Royal®, Precision®, Microsoft Windows®, DCI ® and Dorma® are trademarks of their respective companies
