NP-DTM7D24H

SINGLE ANNUAL EVENT TIMER

WI1344A 12/05

DESCRIPTION

The NP-DTM7D24H is a 24 Hour / 365 Day Event Timer that
supports a varied range of applications, including but not lim­ited to: Security, Home and Building Automation, Access
Control, Lighting Control, etc. The NP-DTM7D24H is
equipped with an independently controlled form “C” relay con­tact that provides many latching and/or momentary operations
during a program schedule. The EPROM memory allows you
to program the unit prior to/or during field installation. Events
can be set for single or multiple operations on a daily and/or
weekly schedule. The Block-programming feature allows re­peating an event on any combination of consecutive days.
The NP-DTM7D24H compensates for daylight saving time if
desired. Also, individually selected holiday exceptions may
be programmed to override regularly scheduled events.

FEATURES

• Standby current: 10mA (relay OFF) 50mA (relay ON).

• 12 to 24 volts AC or DC operation

• Battery charging current: 100mA.

• Form “C” relay contacts are rated 10Amps @120VAC/28VDC.

• EPROM memory protects against loss of programming due to

power failure.

• Accurate crystal controlled clock.

• Momentary and/or Latching Events.

• 50 individually programmed daily/weekly events.

• Block programming capacity can accommodate a total of 350

events per week.

• 10 programmable Holiday dates.

• “First man in” option.

• Alphanumeric LCD display simplifies programming.

• Standard or Daylight Saving Time settings.

• Automatic compensation for leap year.

• Built-in charger for 12VDC sealed lead acid or gel type batteries

(Max charge current 100mA).

• Lithium battery backup maintains clock (optional).

• User-friendly programming.

Board dimensions: 30mm(H) x 135mm(W) x 77mm(L)

INSTALLATION INSTRUCTIONS

1. Mount NP-DTM7D24H in desired location / enclosure.

Carefully Review:

• "Basic Operation" section (below)

• "Terminal Identification Table" (below)

• "Push Button Layout" and "Description" (page 2)

• "Programming Instructions" (pages 2-3)

2. Connect 12 to 24 Volts AC or DC to terminals marked
[+ DC –, ~ AC ~]. (When using DC carefully observe polarity).

3. Connect 12VDC battery (optional) to terminals marked
[+ BAT –, 12VDC].

4. Insert lithium battery (optional/not supplied--order part
CR2032) in battery holder with the + positive side facing up.

5. Connect devices to be controlled to dry outputs marked
[NO, C, NC].

Note: It is important when connecting DC powered electro-

mechanical devices such as Magnetic Locks, Electric
Strikes, Bells, Relays, etc. to install a catch diode across
the pos (+) and Neg. (-) terminals of the device. Connect
diode as close to the device as possible with the banded
side facing the Pos. (+) terminal. This will reduce the possi­bility of interference.

6. Program clock and desired event schedule (see Program­ming Instructions, pages 2-3.

BASIC OPERATION:

NP-DTM7D24H controls an independently operated dry form
“C” relay output. Relay can be programmed to: turn on
(latch), turn off (release latch) or pulse (momentary toggle) at
a specified time and day (this is referred to as an "event").
Events are programmed via the push buttons and LCD dis­play. Events may be programmed to occur on any day of the
week at any time. In addition, events may be repeated at a
specific time on two (2) or more consecutive days (i.e. M-F,
Sun-Th, etc.). Multiple combinations of individual and block
events may be programmed. Holiday exceptions are individu­ally selected by date and will override all regularly scheduled
events.

The four (4) output relay modes consist of: Relay OFF - De­energizes the relay until a relay ON event is detected. Relay

ON - Energizes the relay until a relay OFF event is detected.
Disable - Used to cancel an existing programmed event.
Pulse - Momentarily energizes the relay for a selectable time

period of 1 second to 15 seconds. Time is displayed in 24 hr.
military format.

TERMINAL IDENTIFICATION

Terminal Function/Description

NO, C, NC Dry Contact output used to switch controlled devices. When these relays are energized

+ BAT –

(ON) the NC and C terminals are open and the NO and C terminals are closed. When
this relay is de-energized (OFF) the NC and C terminals are closed and the NO and C
terminals are open.

+ DC –

AC or DC Input 12 to 24 Voltages. When using DC carefully observe polarity.

~ AC ~

12VDC standby battery input (battery leads provided).

12VDC

FM When this terminal is connected to DC Neg. (-) the “First Man in” feature is enabled.

The relay will remain in its present position until this connection is terminated. At that
time the relay will resume normal operation and latest scheduled events will occur.

Push Button Layout:

Push

Button

SET Scrolling keys for programming. Escaping out of

ENTER Accepts selections made to programming.

UP Scrolls through selections.

DWN Scrolls through selections.

Push Button Description Table

Function/Description

existing programming.

UP and DOWN keys can be used to select data entries.
After scrolling to the correct entry, depress ENTER to ac­cept.

PROGRAMMING INSTRUCTIONS:

Note: The flashing cursor denotes location of data en-

try selection to be made. If an entry was made in error
or requires changing, depress SET to backspace,
make the correct selection and depress ENTER to ac­cept data and advance the cursor.

A. SETTING E VENTS :

Depress SET until appears in display.

Depress ENTER. will appear in display.

Depress ENTER until the flashing cursor appears un-

der OFF in display. Now select type of event required,
by scrolling using the UP and DWN push buttons until
either:

ON - Relay ON (latching mode).
OFF - Relay OFF (latching mode).
PL - Relay Pulse (momentary).

...appears in display and depressing ENTER will make

selection.

When selecting the pulse mode PL01 will appear in the

display. It is now necessary to assign the length of time
(duration of relay activation). The pulse can range in
length from 1-second minimum to 15-seconds maxi­mum and is selected by using UP or DWN push but­tons, and then depressing ENTER to accept.

ENTER TO

SET EVENT

#01 OFF

SU 00:00

Note: If pulse duration is not selected relay output de-

faults to 1-second.

Next select the day of the week or BK* for weekly re-

peat and time (military) by scrolling using UP and DWN
push buttons and depress ENTER to accept.

You may continue to program events by repeating the

previous steps or exit programming by depressing SET.

Note: When programming additional events it is neces-

sary to select the next consecutive event number fol­lowing the last event program to continue.

*See section B

B. Setting Block (weekly repeat):

Next select block programming by depressing SET until

appears in display.

ENTER TO

SET BK

Depress ENTER. will appear in display.

BK=SA/SU

TIME=DS

Example: To select Monday through Friday, repeat op-

eration. With flashing cursor under SA depress UP or
DWN to change to MO then depress ENTER to move

flashing cursor to SU and depress UP or DWN to
change FR. Depress ENTER--flashing cursor will now
be under TIME = DS. Press ENTER if you wish to select
DS (Daylight Saving mode). If your area does not re­quire Daylight Saving adjustment, depress UP or DWN
to change to (Standard Time mode) ST will appear in
display. Depress ENTER to accept correct selection.

C. Setting Holiday Events:

Depress SET until appears in display.

ENTER TO

SET EVENT

Depress ENTER. will appear in display.

#01 ^ ON
HL 00:00

Next select HL to indicate as Holiday Event and time by

scrolling using UP and DWN push buttons and depress
ENTER to accept.

You may continue to program more holiday events by

repeating the previous steps or exit programming by
depressing SET.

D. Setting Holiday Dates:

It is now necessary to assign these holiday events spe-

cific calendar dates, which they are to occur. To select
Holiday events depress SET until

appears in the display.

ENTER TO

SET HOL
