SMALL
SERIES
905
H
L
W
SPECIFICATIONS
Interior dimensions
Exterior dimensions
Weight (empty)
Lid depth
Base depth
Max buoyancy
Temperature range
Airline cabin carry-on
Watertight
Warranty
L9.4" x W7.4" x H5.5"
L239mm x W188mm x H140mm
L12.5" x W10.1" x H6.0"
L318mm x W257mm x H152mm
3.3 lbs | 1.5 kg
1.4" | 36mm
4.1" | 104mm
17 lbs | 7.7 kg
Min -20°F (-29°C ) Max 140°F (60°C)
Yes
Yes - IP67
Conditional lifetime guarantee
CERTIFICATIONS MATERIALS
IPX7 INGRESS PROTECTION - WATERPROOF
IP6X INGRESS PROTECTION - DUSTPROOF
ATA SPECIFICATION 300 - CATEGORY 1 IMPACT
ASTM D-4169 DC-18 - DROP TEST
ASTM D-4169 DC-18 - VIBRATION
ASTM D-4169 DC-18 - RAINFALL
MIL-STD-810F - IMMERSION
Case shell – NK-7 high impact polypropylene
Latches – Nylon 66
Handle – NK-7 high impact polypropylene | TPE
Purge valve – Nylon 66 | Gore® membrane | Silicone washers
Pins/hardware – 304 stainless steel
Gasket – EPDM
Copyright © 2017 Plasticase inc. All rights reserved.
nanuk.com
SMALL SERIES
905
STANDARD FEATURES
1 -
Powerclaw Latching System
2 -
Waterproof IP67 Rated
3 -
Impact Resistant NK-7 Resin
4 -
Padlockable
5 -
Stackable
6 -
Molded-in Bezel System
7 -
Soft Grip Handle Stay
8 -
Automatic Pressure Release Valve
9 -
Integrated Lid Stay
10 -
100% Stainless Steel Hardware
11 -
Lifetime Guarantee
AVAILABLE COL ORS
4
2
3
6
8
7
10
1
Black 0001 Graphite 0007 Lime 0002 Olive 0006 Orange 0003 Silver 0005 Yellow 0004
AVAILABLE OPT IONS
Multilayer cubed foam Padded divider
Aluminum panel
Lexan panel TSA approved padlock Shoulder strap
CUSTOM OPTIONS
Custom printing Custom foamCustom label
Copyright © 2017 Plasticase inc. All rights reserved.
Custom panel
nanuk.com
