OWNER’S MANUAL

Portable Sound System 150

PORTABLE SOUND SYSTEM 150

Congratulations on your choice of a portable sound system
— you have purchased one of the finest portable sound
systems on the market today. This unit was developed
using the expertise of professional sound engineers and
working musicians. You will find that your new NADY
AUDIO portable sound systems has superior performance
and greater flexibility than any other portable sound
systems in its price range. Please read this manual
carefully to get the most out of your new unit.

Thanks for selecting NADY AUDIO as your choice in
portable sound systems.

FEATURES

• Convenient portable PA package with luggage-style handle and wheels for easy transport

• 5-Channel stereo 150W RMS powered mixer AMA™ (Automatic Maximum Amplitude) limiter speaker protection

• Stereo two-way speaker system with 10" woofer and piezoelectric tweeter horn, two speaker cables, and two folding
speaker stands

• Three combo XLR / 1/4" mic/line inputs and one XLR mic input, all with 15V phantom power, and two stereo source
inputs for CD, VCR, or DVD or other audio sources. All inputs with bass, treble, and reverb controls.

• Separate left and right master output 60mm linear fader level controls, choice of eight digital reverb and eight digital
delay effects, and five-band graphic equalizer with FLI™ (Feedback Locating Indicators).

• One Starpower™ dynamic microphone and 20 foot XLR microphone cable

• Storage compartments for microphones, cables and accessories

• Variable-speed fan

• Stereo RCA auxiliary outputs

TABLE OF CONTENTS

FEATURES ....................................................................... 2

WARNING ......................................................................... 3

INTALLATION ................................................................... 4

1. INSPECTION.......................................................... 4

2. SETUP.................................................................... 4

FRONT PANEL CONTROLS & CONNECTIONS ............ 5

Date of Purchase ____________________________________

Dealer’s Name ______________________________________

City _______________________________________________

State _____________________ Zip _____________________

Model # ____________________________________________

REAR PANEL CONTROLS & CONNECTIONS .............. 7

SPECIFICATIONS ............................................................ 7

Serial # ___________________

2

WARNING

An equilateral triangle enclosing a lightening flash/arrowhead symbol is
intended to alert the user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure which may be of sufficient

ATTENTION

:

RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR

magnitude to constitute a risk of electric shock.

An equilateral triangle enclosing an exclamation point is intended to alert
the user to the presence of important operating and service instructions in
the literature enclosed with this unit.

IMPORTANT SAFETY INSTRUCTIONS

When using this electronic device, basic precautions should always be taken, including the following:

1. Read all instructions before using the product.

2. Do not use this product near water (e.g., near a bathtub, washbowl, kitchen sink, in a wet basement, or near a swimming

pool, etc.).

3. This product should be used only with a cart or stand that will keep it level and stable and prevent wobbling.

4. This product, in combination with headphones or speakers, may be capable of producing sound levels that could cause

permanent hearing loss. Do not operate for a long period of time at a high volume level or at a level that is uncomfortable.

If you experience any hearing loss or ringing in the ears, you should consult an audiologist.

5. The product should be positioned so that proper ventilation is maintained.

6. The product should be located away from heat sources such as radiators, heat vents, or other devices

(including amplifiers) that produce heat.

7. The product should be connected to a power supply only of the type described in the operating instructions or as marked on the

product. Replace the fuse only with one of the specified type, size, and correct rating.

8. The power supply cord should: (1) be undamaged, (2) never share an outlet or extension cord with other devices so that the

outlet’s or extension cord’s power rating is exceeded, and (3) never be left plugged into the outlet when not being used for

a long period of time.

9. Care should be taken so that objects do not fall into, and liquids are not spilled through, the enclosure’s openings.

10. The product should be serviced by qualified service personnel if:

A. The power supply cord or the plug has been damaged.

B. Objects have fallen into, or liquid has been spilled onto the product.

C. The product has been exposed to rain.

D. The product does not appear to operate normally or exhibits a marked change in performance.

E. The product has been dropped, or the enclosure damaged.

11. Do not attempt to service the product beyond what is described in the user maintenance instructions. All other servicing should

be referred to qualified service personnel.
