Nady ENCORE I operating instructions

Nady Wireless Systems are type accepted under FCC rules parts 90, 74 and 15. The
device complies with RSS-210 of Industry & Science Canada. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference and
(2) this device must accept any interference received, including interference that may
cause undesired operation.

VHF Wireless Microphone System

NADY SYSTEMS, INC.

6701 Shellmound Street • Emeryville, CA 94608 USA
Tel: [phone] • Fax: [phone]
www.nady.com

CONTENTS

CONTENTS ...........................................................................................2

INTRODUCTION ....................................................................................3

USING THIS MANUAL ...........................................................................3

SYSTEM FEATURES ................................................................................4

ENCORE I RECEIVER ..............................................................................5

WHT HANDHELD MICROPHONE TRANSMITTER .....................................8

WLT LAVALIER/LAPEL OR HEADWORN MICROPHONE

BODYPACK TRANSMITTER ...................................................................10

WGT INSTRUMENT BODYPACK TRANSMITTER .....................................12

THE LINK 2™ PLUG-IN TRANSMITTER. ..................................................14

SPECIFICATIONS .................................................................................17

SERVICE ..............................................................................................18

2

INTRODUCTION

ENCORE I RECEIVER

Controls Power ON/OFF, volume control, mute control
Connectors Balanced XLR and unbalanced adjustable
1/4" audio out jacks, 2.1 mm barrel-type
DC input jack
LED Indicators Power ON, 5-LED RF & AF level displays ,
Dimensions (Max.) 1.75" x 7.5" x 8.1" (4.4 x 19 x 20.7 cm)
Weight 1.6 lbs (.73 kg)
Power Requirements 12V @ 400mA, nominal,
AC/DC adapter supplied
Antenna 11.2" (28.5 cm), single telescopic

SERVICE

(U.S.) Should your Nady Encore I Wireless Microphone System require service,
please contact the Nady Service Department via telephone at [phone]
or e-mail to [e-mail] for a Return Authorization (R/A) Number and a
service quote (if out of warranty). Make sure the R/A Number is clearly marked
on the outside of the package and enclose a cashier’s check or money order (if not
prepaid with a credit card). Ship the unit prepaid to: Nady Systems, Inc., Service
Department, 6701 Shellmound Street, Emeryville, CA 94608. Include a brief
description of the problems you are experiencing.

Thank you for purchasing a Nady Encore I Wireless Microphone System and
congratulations on your choice. The Encore I is loaded with top professional operat­ing features and is the best performance and price value available in VHF wireless
systems.

USING THIS MANUAL

This booklet gives instructions for the operation of the Encore I VHF wireless, including
handheld, instrument, lavalier, headmic and plug-in transmitter systems. Please read
the instructions for your system completely before operating unit.
This manual will first list the features of the Encore I and then will take you step by
step to show you how to operate your new system. After reading the receiver instruc­tions, turn to the section of the booklet that covers the type of transmitter used with
your new system. Each section will give you detailed operating instructions. Also
included in this manual are system specifications and servicing information.

The warranty card enclosed with this system contains additional valuable warranty
and service information. Keep it in a safe place for future possible reference. Do not
attempt to service this unit yourself as it will void the warranty.

(International) For service, please contact the Nady distributor in your country
through the dealer from whom you purchased this product.

18
