RACE
max
30kg
(2x )
Portabici da gancio in acciaio con corsie in alluminio
IT
Tow bar mounted bike carrier in steel with bike support runners in aluminium
EN
Porte-vélos sur attelage en acier avec supports de roue en aluminium
FR
AHK-Fahrradträger aus Stahl mit Trägerschienen aus Aluminium
DE
max
45kg
(3x )
max
60kg
(4x )
Race Race 3 Race 4
Codice art. 000015200000 000015300000 000015400000
Portata max / Max load 30 kg 45 kg 60 kg
Nr. bici max / Maximum bike nr. 2 3 4
Fissaggio / Fixing system Con attrezzi / Tools required Con attrezzi / Tools required Con attrezzi / Tools required
TÜV Tested Tested Tested
XP R18-904-4:2008 Fully compliant Fully compliant Fully compliant
DIN 75302 Fully compliant Fully compliant Fully compliant
W
H
L
H
W
L
L x W x H : 120x40x14 cm L x W x H : 120x47,5x14 cm L x W x H : 120x54x17 cm
12,4 Kg 15 Kg 18 Kg
L x W x H : 80x120x111 cm L x W x H : 80x120x109 cm L x W x H : 80x120x123 cm
195 Kg 186 Kg 308 Kg
P.z : 14 P.z : 11 P.z : 8
MIN Ø30 mm
MAX Ø50 mm
MIN 30x30 mm
MAX 50x70 mm
MIN 22”
MAX 29”
MAX 45 mm
MAX 110 cm
