INTRODUCTION
New & Reconditioned Equipment & Parts - www.southeasternequipment.net
Dear Customer:
Congratulations on the purchase of your new Speedster® LTD Carpet
Extractor. As technology continues to develop you can work condently
knowing that both Mytee Products and its employees are equally dedicated to
developing with the industry and its advances.
Like any other piece of machinery or technology, the Speedster® LTD also
requires proper maintenance and care to keep the product working over
extended use. Neglecting your machine, abusing it or not operating it properly
can void its warranty and prevent the machine from performing to the quality
and standard you’d expect out of the Mytee Products line.
If you have any warranty concerns or questions, please review this manual
thoroughly or do not hesitate to contact your distributor. If there are questions
regarding maintenance, replacement, or ordering parts please contact an
authorized Mytee Products Service Center. To see an updated list please visit
our website at http://www.mytee.com/support/service-centers.
Before using your Mytee product, please read this manual thoroughly.
Sincerely,
Mytee Customer Care Dept.
2
TABLE OF CONTENTS
New & Reconditioned Equipment & Parts - www.southeasternequipment.net
IMPORTANT SAFETY INFORMATION
1
2
AT A GLANCE 6
1.1 - Technical Specications 6
1.2 - Included with the Speedster® LTD 7
1.3 - Speedster® LTD Features 8
1.5 - Switch Plate 9
MACHINE OPERATION 10
2.1 - Powering the Speedster® LTD 10
2.2 - Connecting Vacuum & Solution Hoses 10
2.3 - Filling the Solution Tank 10
2.4 - Switching on the Speedster® LTD 10
2.5 - The Auto-Fill & Pump-Out Features 10
2.6 - The Prime Valve 11
2.7 - Emptying the Recovery Tank 11
4
2.8 - Emptying the Solution Tank 11
3
4
5
MACHINE MAINTENANCE 12
3.1 - Opening the Unit for Maintenance 12
3.2 - Filter Maintenance 12
3.3 - Ball Float Maintenance 12
3.4 - System Maintainer 12
AVAILABLE ACCESSORIES 13
TROUBLESHOOTING 14
3
IMPORTANT SAFETY INFORMATION
New & Reconditioned Equipment & Parts - www.southeasternequipment.net
Grounding Instructions
This machine must be grounded. If it should malfunction
or break down, grounding provides a path of least resistance for electrical shock. This machine is equipped with
a cord having an equipment-grounding conductor and
grounding plug. The plug must be plugged into an appropriate outlet that is properly installed in accordance with
all local code and ordinances. Do not remove ground pin;
if missing, replace plug before use.
Improper installation of the equipment-grounding
conductor can result in a risk of electric shock. Be sure to
check with a qualied electrician or service person if you
are in doubt as to whether the outlet is properly grounded.
If the plug will not t in the outlet do not modify the plug or
the machine’s cord, instead have a proper outlet installed
by a qualied technician.
This machine is for use on a nominal 120-volt circuit and
with a grounding plug similar to the one in Figure 1 below.
If a proper outlet is not available, follow the illustrations of
Figure 2 & 3 to install a temporary-grounding plug. This
temporary work-around should be used only until a proper
outlet (Figure 1) can be installed by a qualied electrician.
When and if this type of adapter is employed, screw the
adapter’s extended tab into place with a metal screw.
However, grounding adapters are not approved for use in
Canada.
Again, be sure to check the grounding pin for damages
and replace if necessary.
Parts and Service
Please contact Mytee service personnel or a Mytee authorized Service Center using Mytee original replacement
parts and accessories if repairs need to be performed.
When and if calling Mytee for support, please have your
Model and Serial Number available for faster assistance.
Name Plate
The Model and Serial Number are located on the lower
half of the back of the machine near the power plug and
will be required for ordering replacement parts. You can
use the space provided in this manual to note down both
for future referencing.
Unpacking the Machine
When your new machine is delivered, please carefully
inspect both the shipping carton and the machine for
damages. If damage is evident, save both the shipping
carton and machine so that the delivering carrier can
inspect it. Contact the carrier immediately to le a freight
claim if there has been any damage.
Caution and Warnings
Symbols
Mytee uses the symbols below to signal potentially dangerous conditions. Always read this information carefully and take the necessary steps to protect
personnel and property.
The Green, or Green-Yellow, wire in the cord is the
grounding wire. When replacing a plug, this wire must be
Is used to warn of immediate hazards that will cause
severe personal injury or death.
attached to only the grounding pin.
DO NOT use extension cords.
Is used to call attention to a situation that could cause
Please Note for America use only.
severe personal injury.
Grounded Outlet
Adapter
Is used to call attention to a situation that could cause
Metal
Screw
Tab for Grounding
Grounding Pin
Figure 1
Grounded Outlet Box
Figure 2 Figure 3
Screw
minor personal injury or damage to the machine or other
property. When using an electrical appliance, basic
precautions should always be followed, including the
following: Read all instructions before using this machine.
This product is intended for commercial use only.
4
IMPORTANT SAFETY INFORMATION
New & Reconditioned Equipment & Parts - www.southeasternequipment.net
To reduce the risk of re, electrical shock, or injury:
1. Read all instructions before using equipment.
2. Use only as described in this manual. Use only manu-
facturer’s recommended attachments.
3. Always unplug power cord from electrical outlet
before attempting any adjustments or repairs.
4. Do not unplug by pulling on cord. To unplug, grasp the
plug, not the cord.
5. Do not pull or carry by cord. Do not close a door on
cord or pull cord around sharp edges or corners.
6. Do not run appliance over cord. Keep cord away from
heated surfaces.
7. Do not use with damaged cord or plug. If cord is
damaged, repair immediately.
8. Do not use outdoors or on wet surfaces and/or
standing water.
9. Always unplug or disconnect the appliance from
power supply when not in use.
18. When cleaning and servicing the machine, local or
national regulations may apply to the safe disposal
of liquids which may contain: chemicals, grease, oil,
acid, alkalines, or other dangerous liquids.
19. Do not leave operating unattended.
10. Do not allow to be used as a toy. Close attention is
necessary when used by or near children.
11. Do not use in areas where ammable or combustible
material may be present.
12. Do not leave the unit exposed to harsh weather
elements. Temperatures below freezing may damage
components and void warranty.
13. Use only the appropriate handles to move and lift unit.
Do not use any other parts of this machine for this
purpose.
14. Keep hair, loose clothing, ngers, and all parts of the
body away from all openings and moving parts.
15. Use extra care when using on stairs.
16. To reduce the risk of re or electric shock, do not use
this machine with a solid-state speed control device.
17. The voltage and frequency indicated on the name
plate must correspond to the wall receptacle supply
voltage.
5
1 - AT A GLANCE
New & Reconditioned Equipment & Parts - www.southeasternequipment.net
1.1 - Technical Specications
LTD3
Recovery Tank
Solution Tank
Vacuum
Motors
Solution Pump
Pump-Out
Heater
Wheels
Casters
Power Cord
Amp Draw
Machine
Weight
Machine
Dimensions
11 gallon capacity (approx.)
11 gallon capacity (approx.)
Dual 3-stage, 200 CFM, 130” water lift
500 PSI, 1.5 GPM
3.3 GPM
1,600 watt - 210º max.
10” foam-lled
4” locking
Dual 50’ 12/3
Cord 1: 20 amps @ 115V 60Hz
Cord 2: 20 amps @ 115V 60Hz
160 lbs.
30” x 20” x 42”
LTD5
Recovery Tank
Solution Tank
Vacuum
Motors
Solution Pump
Pump-Out
Wheels
Casters
Power Cord
Amp Draw
Machine
Weight
Machine
Dimensions
11 gallon capacity (approx.)
11 gallon capacity (approx.)
Dual 3-stage high performance, 230
CFM, 144” water lift
500 PSI, 1.5 GPM
3.3 GPM
10” foam-lled
4” locking
Dual 50’ 12/3
Cord 1: 20 amps @ 115V 60Hz
Cord 2: 14 amps @ 115V 60Hz
160 lbs.
30” x 20” x 42”
LTD12
Recovery Tank
Solution Tank
Vacuum Motors
Solution Pump
Pump-Out
Wheels
Casters
Power Cord
Amp Draw
Machine Weight
Machine Dimensions
11 gallon capacity (approx.)
11 gallon capacity (approx.)
Dual 3-stage, 200 CFM, 130” water lift
Adjustable 50-1,200 PSI, 2.2 GPM
3.3 GPM
10” foam-lled
4” locking
Dual 50’ 12/3
Cord 1: 20 amps @ 115V 60Hz
Cord 2: 15 amps @ 115V 60Hz
180 lbs.
30” x 20” x 42”
