MySwing Professional Quick Start Manuals

STEP 1 MYSWING PROFESSIONAL INCLUDES: STEP 2 IMPORTANT

Case Keyboard

Charging Case Body Sensor ×17 Shaft Sensor ×2 Receiver

Body Sensor Base ×15

MySwing Pro sensors must always be kept at least 3 feet away from all magnetic
elds. Magnetizing a sensor will cause noticeable errors in the avatar. If this occurs
repeatedly, contact Customer Service to have the sensor recalibrated or replaced.

Keep Away From Magnetic Fields. Connect the straps to the sensor bases.

Use the appropriate length of strap that ts the player for each segment. Attach
the straps according to the diagram.

Attach the appropriate label (e.g. forearm, thigh, etc.) to the straps, if desired.

Velcro Straps ×15 Antenna

Tablet Shoulder Harness Transformer for Charging Case

Shoulder Harness

Place the sensors into the bases.

Rotate the sensors 90 degrees counter-clockwise. Handle the sensors gently,
do not over tighten.

Attach shaft sensor just below the grip with charging contacts pointing down.

Align the shaft sensor parallel to the club face as shown.

To turn on, hold the button for 2 seconds.

To turn off, hold the button for 5 seconds.

LED Colors

LED Status

STEP 4 THE SENSOR LED’S

frequency 1 frequency 2 frequency 3

frequency 4 frequency 5

charging, low battery,

or sensor error

Green ( frequency 1 ) is the default.
( multiple systems in close proximity must use different frequencies )

Slow Blink

Standby

Fast Blink Working

Double Blink every 3
seconds

Sleep Mode

Blinking Red LED

Indicates Low Battery

( approximately 20 minutes remaining )

Constant Red Light
outside of charging dock

Sensor Error

( Reset Sensor )

3 Feet

Start mySwing Professional software.

Add new student by clicking the plus button.

Enter Student’s Information, Height, Wingspan, and Agree to the Terms of Use.

Proceed to Screen/Swing Tab.

Click on the Connect icon and follow the on-screen instructions.

STEP 5 CONNECT TO TABLETSTEP 4 THE SENSOR LED’S

Parallel

PART 1 PART 2 PART 3 PART 1 PART 2

STEP 3 GETTING STARTED

STEP 3 GETTING STARTED

STEP 3 GETTING STARTED

To reset sensor, turn on, then hold the button for 10 seconds.
( Sensor must be fully recharged after reset. )

PART 1

www.myswing.com

powered by

Gently place each sensor into the charging case.

Close the charging case cover.

Connect the transformer to the charging case, make sure all LED’s are

constant red.

When a sensor is fully charged, the red LED will turn off.

Any Changes or modications not expressly approved by the party responsible for compliance could void the

user's authority to operate the equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

—Reorient or relocate the receiving antenna.

—Increase the separation between the equipment and receiver.

—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

—Consult the dealer or an experienced radio/TV technician for help.

STEP 8 CHARGING THE SENSORS

Click the channel button in the top right corner.

Select the channel.

Check sensors for correct LED color.

If a sensor’s LED color is not correct,

it must be changed manually.

STEP 7 AUTOMATIC FREQUENCY CHANGE

Feet are straight and square to the target line, six inches apart.
Hold arms horizontal in both directions.
Upper arms aligned with the body.

Feet remain in the same position with thumbs placed on the seams
of the pants.

Feet remain in the same position with arms extended, with slight
knee bend.

Feet are straight and square to target line, six inches apart.
Arms extended in front of player.
Upper arms parallel to each other.
Upper arms parallel to the ground.

Follow the on screen calibration procedure. Make sure antenna is facing player
before proceeding.

* only necessary if using multiple systems

STEP 6 CALIBRATION

Quick Calibration

Advanced Calibration

QUICK START GUIDE

Hold arms horizontal in both directions.

Feet remain in same position.

STEP 6 CALIBRATION

Upper arms aligned with the body.

Stand tall and straight.
Upper arms as close to the body as possible.
Forearms parallel to the ground.
Palms facing each other and thumbs pointing up.

Remain in L Pose posture.
Rotate both forearms out 90 degrees

(or as much as possible)

.

Use the middle ngers as the axes of rotation.

7 Pose

T Pose

A Pose

S Pose

T Pose

L Pose

LL Pose

PART 2

Contact Support

TOLL FREE Support Number 1-844-843-1270

or

E-mail:

[e-mail]

MySwing Golf, Inc.

16411 N. 90th St. Ste. 101

Scottsdale, AZ 85260

Feet remain in same position.

Feet remain in same position.
