Mystery MJ-2.120 PART LIST

BUYER : DELTA MODEL : MJ2.120 CODE :

PART LIST(MJ2.120)

NO CODE NAME STAN Q'TY REMARK

1 B-FLUX------1 FLUX NT2016 @50000 1.00
2 B-IPA-------1 IPA 2070 15kg:@28,000 g 1.00
3 B-SLDR-BAR--1 SOLDER BAR 60% kg:$4.2 g:$0.0042 1.00
4 B-SLDR-WIRE-1 SOLDER WIRE 60% kg:$4.0 g:$0.004 1.00
5 B-TUB-EMP1--1 TUBE EMPIRE 1mm/O.O5 @70 1.00
6 G-LED-HOLDER6 HOLDER LED ASS'Y TOH-30FOGD1-B(G/R) 1.00 LED1+LED2
7 H-CER-100CH-1 CER CAP 100PF CH 3.00 C133, C151, C251
8 H-CER-100CHT1 CER CAP 100PF CH TP TYPE 3.00 CX131, C231, C233

9 H-CER-47CHT-1 CER CAP 47PF CH TP TYPE 2.00 C312, C412
10 H-COPER-2---1 COPER 2P NI 1t 2P_15mm_10mm(h) 1.00 COP1
11 H-DIO-25C---2 DIODE YG225C2 YG225C2 Y=24 1.00 DF1
12 H-DIO-25N---2 DIODE YG225N2 YG225N2 Y=24 1.00 DF2
13 H-DIO-4002--1 DIODE IN4002 1.00 D30
14 H-DIO-4148--1 DIODE IN4148M 4.00 D1, D2, D101, D202
15 H-DIO-5402--1 DIODE IN5402 1.00 D5
16 H-DIZ-1W15V-1 DIODE ZENER TZP15B IN4744/1W 2.00 ZD1, ZD2
17 H-E13-25SM--1 EC1000/25 12.5x20SMS 2.00 C7, C8
18 H-E1-50SHT--1 EC 1/50 5x11 SHL TP TYPE 2.00 C135, C235
19 H-E220-16SHT1 EC 220/16 6.3x11 SHL TP TYPE 1.00 CX2
20 H-E223-35SH-1 EC2200/35 16x25 SHL 2.00 C12, C13
21 H-E330-16SH-1 EC 330/16 8X11.5 SHL 3.00 CX1, CX4, C20
22 H-E4.7-50SHT1 EC 4.7/50 5X11 SHL TP TYPE 4.00 C1, C105, C205, C2
23 H-E470-16SH-2 EC470/16 8X11.5 SHL 2.00 C401, C402
24 H-E47-16SHT-1 EC 47/16 5x11 SHL TP TYPE 2.00 C132, C232
25 H-E47-25SHT-1 EC 47/25 5x11 SHL TP TYPE 2.00 C311, C411
26 H-FUS-25A---2 FUSE ATC-25A 1.00
27 H-FUS-HOL3-31 HOLDER FUS P3 DKT-08011 PCB-INSERT 1.00 FU1
28 H-IC-4560L--1 IC NJM4560L SIP 6.00 IC3, IC4, IC5, IC6, IC7, IC8
29 H-IC-494CN--1 IC 494CN 1.00 IC301
30 H-JAK-R4PBR-1 JACK RCA 4P BRASS DKJ44104 W/W 1.00 JK1
31 H-JW-JUMPW06T JUMP WIRE 0.6T 95.00
32 H-MFB-104P5-1 CAP/M-FILM 104/63V BOX FILM 104 1.00 C257

1/3

BUYER : DELTA MODEL : MJ2.120 CODE :

PART LIST(MJ2.120)

NO CODE NAME STAN Q'TY REMARK

33 H-MFB-104P5T1 CAP/M-FILM 104/63V BOX FILM 104 TP TYPE 14.00 CP1, CP2, C302, C303, C304, C402, C403, C404,
34 H-MFB-104P5T1 CAP/M-FILM 104/63V BOX FILM 104 TP TYPE 0.00 C157, CP20, CP21, C25, C158, C258
35 H-MFB-473P5T1 CAP/M-FILM 473/63V BOX FILM 473 TP TYPE 8.00 C305, C306, C307, C308, C405, C406, C407, C488
36 H-MFB-683P5T1 CAP/M-FILM 683/63V BOX FILM 683 TP TYPE 4.00 C309, C310, C409, C410
37 H-MOS-44----4 MOSFET FQP50N06 N-CH TO220 2.00 Q7, Q8
38 H-MYR-102T--2 MYLAR 102(0.001/50) TP TYPE "J" 2.00 C5, C6
39 H-MYR-222T--2 MYLAR 222(0.0022/50) TP TYPE "J' 2.00 C313, C413
40 H-MYR-682T--2 MYLAR 682(0.0068/50) TP TYPE "J" 2.00 C3, C4
41 H-PBA-2050A52 MAIN PCB UT250 216x163_XPC BLACK 1.00 COLOR : BLACK
42 H-PTRC-12---2 RFC COIL BAR (D/N) 5uH/L 8x25 2/12 1.00 L1
43 H-PTTO-36--68 P.T TROIDE 36mm D/N MR9502 5T/9T D/N 1.00 T1
44 H-R14-100---1 RESISTOR 1/4W 100 2.00 R21, R22
45 H-R14-13----1 RESISTOR 1/4W 1K 1.00 R35
46 H-R14-220---1 RESISTOR 1/4W 220 2.00 R164, R264
47 H-R18-100---1 RESISTOR 1/8W 100 8.00 R150, R159, R154, R155, R255, R254, R258, R259
48 H-R18-103---1 RESISTOR 1/8W 10K 20.00 R117, R119, R217, R209, R219, R265, R273, R1,
49 H-R18-103---1 RESISTOR 1/8W 10K 0.00 R2, R5, R7, R10, R11, R12, R13, R165,
50 H-R18-103---1 RESISTOR 1/8W 10K 0.00 R420, R421, R109, R173
51 H-R18-113---1 RESISTOR 1/8W 11K 2.00 R318, R418
52 H-R18-124---1 RESISTOR 1/8W 1.2K 2.00 R161, R261
53 H-R18-13----1 RESISTOR 1/8W 1K 22.00 R153, R156, R118, R33, R218, R253, R256, R17,
54 H-R18-13----1 RESISTOR 1/8W 1K 0.00 R18, R32, R304, R308, R310, R312, R319, R410,
55 H-R18-13----1 RESISTOR 1/8W 1K 0.00 R404, R408, R412, R419, R168, R270
56 H-R18-204---1 RESISTOR 1/8W 2K 2.00 R162, R262
57 H-R18-220---1 RESISTOR 1/8W 220 4.00 R19, R20, R314, R414
58 H-R18-223---1 RESISTOR 1/8W 22K 6.00 R307, R313, R315, R407, R413, R415
59 H-R18-244---1 RESISTOR 1/8W 2.4K 3.00 R8, R316, R416
60 H-R18-33----1 RESISTOR 1/8W 3K 1.00 R14
61 H-R18-333---1 RESISTOR 1/8W 33K 4.00 R174, R175, R274, R275
62 H-R18-334---1 RESISTOR 1/8W 3.3K 1.00 R6
63 H-R18-393---1 RESISTOR 1/8W 39K 6.00 R302, R305, R306, R402, R405, R406
64 H-R18-394---1 RESISTOR 1/8W 3.9K 5.00 R27, R163, R169, R262, R271

2/3
