Mystery MDV-30 Service Manual

Appearance

Specification

Harness Connection Diagram

Circuit Diagram

Circuit Operating

Block Diagram

Troubleshooting Guide

PCB Pattern

Assembly/Disassembly Drawing

Part List

06

07

08

09

14

16

17

21

24

25

MYSTERY
MDV-30

APPEARANCE

6

FRONT

REAR

Power indicatior

A/V In

SkipStop

Eject

APPEARANCE

Power

Play/
Pause

Earphone
output jack

I.R

DVD disc holder

A/V Out CoaxialRemote eye

in jack

Power jack

SPECIFICATION

7

INTRODUCTION

This DVD Player supports more 500 lines horizontal resolution, Dolby digital (AC-3) and outputs

digital DTS so that it provides the video and sound quality of the effect like a real theater. It can

also supports not only VIDEO CD but also CD, CD-R, CD-RW.

FEATURES

500 and more horizontal resolution

DVD, VCD, CD, CD-R, CD-RW

Dolby Digital Decoding

2CH Analogue signal output

DTS digital output

ZOOM

Special Play (Slow/Fast Play)

Composite output

More than 500 linesHorizontal Resolution

Basic
Specification

Audio

Convenience

Connection

Size

Weight

Compatible Disc

Dolby Digital

DTS

ZOOM

Volume control

Special play

MP3 Play

Output

Video

Audio

Video

Audio

DVD, VCD, CD, CD-R, CD-RW

Analogue 2Ch output & Digital output

Digital output

OK

OK

OK

OK

1 Composite terminal

2 2Ch RCA terminal (R/L, each) / 1 Coaxial terminal

Input

1 Composite terminal

2 2Ch RCA terminal (R/L, 2 each)

180 x 214 x 50 (W x D x H)

About 1.5 Kg

SPECIFICATIONS

SPECFICATION

SPECIFICATION

HARNESS CONNECTION DIAGRAM

8

CIRCUIT DIAGRAM

FRONT

CIRCUIT DIAGRAM

9

CIRCUIT DIAGRAM

10

MPEG

CIRCUIT DIAGRAM

11

RF AMP

CIRCUIT DIAGRAM

12

OUTPUT CONN

CIRCUIT DIAGRAM

13

AUDIO

CIRCUIT OPERATING

14

FRONT

VFD DRIVER : IC401 (V6313)

1. INTRODUCTION
With following functions, IC401 realizes the serial communication with MPEG (ES6629)
according to software.

CMOS Technology
Key Scanning (12 x 2 matrix)
8-step Dimming Circuit
Multi Display mode (10digit 16segment)
LED port supportable (5Ch, max 20mA)
I2C EPROM interface
POWER SW 1Port

2. INPUT/OUTPUT TERMINAL

INPUT : Receive VSTB, VCLK and VDAT from MPEG (ES6629) and scan key input at

voltage level.
OUTPUT : Output VDAT to MPEG (ES6629) and operate VFD.
With key value stored at EPROM by direct I2C communication, power control by
remote control signal is possible.

DESCRIPTION OF FRONT OPERATION

1. KEY SCAN & VFD DRIVER (V6313) INTERFACE

2. DESCRIPTION OF OPERATION
If a user presses a key while MPEG chip (ES6629) is scanning a key thru VFD Driver IC (V6313),
V6313 receives key input and if it inputs serially the received data to MPEG chip (ES6629), it
analyzes and proceed the command.
Operate the action according to an input command.
After EPROM reads and compares the remote control code received from IR remote control
sensor, power is controlled using PSW in case of KEY code.

CIRCUIT OPERATING

CIRCUIT OPERATING

15

AUDIO

2CH AUDIO

1. INTRODUCTION
Receive FR and FL signals from MPEG Chip (ES6629), amplify (IC804) them to output
analogue signals to 2CH Jack (JK802).
Receive the output digital signal from MPEG Chip (ES6629) and output digital signal by
coaxial Jack.

OP-AMP : IC804 (LM4558)

1. INTRODUCTION
Dual Operating Amplifier

2. FUNCTIONS
Amplify the analogue voice signal from D/A converter IC.
Taking right/left channels each, amplify and output these two channels to AV OUTPUT.

3. INTERNAL BLOCK DIAGRAM

4. TRUTH TABLE

IC804
LM4558

INH A B C ON SWITCH

LLLLX

0YDZ0

LHLLX

1YDZ0

LLHLX

0YDZ0

LHHL X

1Y1Z0

LLLHX

0YDZ1

LHLHX

1YDZ1

LLHHX

DY1Z1

LHHH X

1Y1Z1

LXXX NONE

BLOCK DIAGRAM

BLOCK DIAGRAM

16

TROUBLESHOOTING GUIDE

17

Power error

Impress power?

Yes

No

Must impress power. Impress power.

No

IC902 KA7805 is not
working.

1. +12V must be running for the voltage of No.1
pin and No.2 pin in IC902.

2. +5V must be running for the voltage of No.3
pin and No.2 pin in IC902.

3. Check the surrounding circuit of IC902 KA7805.

4. If 1. is working and 2. is not working, replace
IC.

No

IC903 KA7809 is not
working.

1. +12V must be running for the voltage of No.1
pin and No.2 pin in IC903.

2. +9V must be running for the voltage of No.3
pin and No.2 pin in IC903.

3. Check the surrounding circuit of IC903 KA7809.

4. If 1. is working and 2. is not working, replace
IC.

No

No

Q3, QQ4 ASM1117 is
not working.

1. +5V must be running for the voltage of No.3
pin and No.1 pin in Q3, QQ4.

2. +3.3V must be running for the voltage of No.2
pin and No.4 pin in Q3, QQ4.

3. Check the surrounding circuit of IC903 KA7809.

4. If 1. is working and 2. is not working, replace
IC.

Q4, ASM1117 is not
working.

1. +3.3V must be running for the voltage of No.3
pin and No.1 pin in Q4.

2. +2V must be running for the voltage of No.2, 4
pin and No.1 pin in Q4.

3. Check the surrounding circuit of Q4 ASM1117.

4. If 1. is working and 2. is not working, replace
IC.

Yes

Yes

Yes

Yes

+5V power is running?

+9V power is running?

+3.3V power is running?

+2V power is running?

OK

POWER CIRCUIT

TROUBLESHOOTING GUIDE

TROUBLESHOOTING GUIDE

18

Front key operation defect

Properly update

the loader software?

Yes

No

Other software is not
working as the key
port is different.

P80 SOFTWEAR UPDATE.
(If the power can not be on with power button
after other firmware update, impress +5V to PSW
by compulsion and power on.)

No

As IC401 controls the
overall functions of
FRONT, power should
be impressed.

The pulse of IC 401
(V6313) No.11~16 pin
is not impressed to
switch.

1. +5V must be running for No.42 pin of IC401.
(In case of SET OFF status)

2. Should check the cold soldering of No.10 and
40 pin in IC401.

1. Of D401~D406 DIODE, check the defective
switch part.

2. Check the disconnected line 6point at IC 401
No.11 ~16 pin and D401~D406.

No

Yes

Yes

+5V is impressed

to No.10 and 40

pin

of

IC401(V6313)?

All key is working?

OK

FRONT CIRCUIT

TROUBLESHOOTING GUIDE

19

AUDIO CIRCUIT

1. ANALOG OUT

CAUTION :
Before checking audio circuit, check configurations on SET UP MENU with the remote control first.

Audio output defect

Is RCA cable

properly connected to

signal input edge?

Yes

No

RCA cables should be
connected to
equipment fitting three
colors.

1. Yellow - Video output / Gray - Video input.

2. Red / White - Audio output or Audio input.

3. Black - DIGITAL OUT.

No

The signal is not
impressed at Loader
or amplification is not
made at U13B.

The signal is not
impressed at Loader
or amplification is not
made at U13A.

Switching port of IC is
not controlled when
input status is normal.

1. The analogue signal must be running at IC804B
No.6 and 5 pin.

2. If analogue signal is running at IC804B, check
the parts mounting status of signal line.

3. If there is no problem at 1. and 2. replace IC.

1. The analogue signal must be running at IC804A
No.2 and 3 pin.

2. If analogue signal is running at IC804A, check
the parts mounting status of signal line.

3. If there is no problem at 1. and 2. replace IC.

No

No

1. At DVD MODE, IC803 No.9 pin must be high
and No.10 pin must be low.

2. At AUX MODE, IC803 No.9 and 10 pin must be
low status.

3. If 1. 2. is working normally and +9V is
impressed to IC803 No.16 pin, replace IC.

Yes

Yes

Yes

Is AUDIO

waveform of IC804B LM4558

IC 7pin yielded?

Is AUDIO

waveform of IC804A LM4558

IC 1 pin yielded?

Is AUDIO

waveform of IC803 3 and

13 pin yielded?

OK

2. DIGITAL OUT

TROUBLESHOOTING GUIDE

CAUTION : Before checking coaxial circuit, check its connection with Receiver first.

Digital out output defect

In Audio SET UP

of SET UP MENU, SPDIF

OUTPUT is ON?

Yes

OK

No

If SPDIF OUTPUT is
OFF in SET UP MENU,
Digital out is not
supported at software.

Move to SETUP MENU/AUDIO SETUP/
SPDIF OUTPUT/ ON mode.

VIDEO CIRCUIT

CAUTION :
Before checking video circuit, check configurations on SETUP MENU with the remote control first.

Video signal output defect

When video signal

is running, TV screen is

properly shown?

Yes

VIDEO signal is

running at IC802 (NJM2246)

No.7 pin?

Yes

No

It doesn’t match either
NTSC/PAL method
with TV setting.

No

Switching port of IC is
not controlled when
input status is normal.

1. Move to SETUP MENU/PREFERENCE/TV
TYPE MODE.

2. Match MULTI/NTSC/PAL with TV setting.

1. VIDEO signal must be running at IC802 No.7 pin.

2. At DVD model, IC802 No.2 pin must be low and
No.4 pin must be high status.

3. If 1. and 2. is normal and +9V is impressed to
No.16 pin, replace IC802.

20

OK

PCB PATTERN

21

FRONT PCB

PCB PATTERN

PCB PATTERN

22

BOTTOM PCB

PCB PATTERN

23

TOP PCB

PART LIST

bf

EU-AP80P80T-01 AV Input P80/P80T

EU-DP80T112-01

Mainboard

P80 18-

P80T112-01

bm1

bhAlm

01

A02 11*3 three colored output (horizontal)

A03 1AVInput board P80/P80T

A04 1Fibre cardboard

B01 1Mainboard P80 2004-04-15

B02 580603 0.1uF 25V M Y5V

B03 80603 1000PF K 25V COG

B04 40603 4700PF K 25V COG

B05 50603 1uF M 25V X7R

B06 20603 0.047uF M 25V Y5V

B07 10603 6800PF K 25V COG

B08 30603 560PF 25V J COG

B09 10603 47PF 25V J COG

B10 30603 0.015uF 25V M Y5V

B11 50603 33PF 25V J COG

B12 70603 470PF 25V J COG

B13 30603 0.01uF K 25V COG

B14 10603 820PF 25V J COG

B15 40603 680PF 25V J COG

B16 30603 100PF 25V J COG

B17 20603 0.22uF 10% 50V X7R

B18 10603 160PF 25V J COG

B19 10603 0.033uF 25V K Y5V

B20 40603 150PF 25V J COG

B25 2CD110 220u/35V footstool lengh7mm

B26 3CD110 10u/25V Dia.5mm 2.0mm footstool lengh7mm

B29 17CD110 100u 16V 2.0MM footstool lengh7mm 5X11

B30 1CD110 4.7uF/25V H5R4 2.5mm footstool lengh7mm

B31 2CD110 220u 16V 2.0mm footstool lengh 7mm

B32 2CD110 470uF/16V footstool lengh7mm

B33 12CD110 10u/25V Dia.4mm height 5mm footstool lengh 7mm

B34 4CD26C 100u 16V Dia.6mmheight 5mm footstool lengh7mm

B35 3SRN10

B36 1SRN4.7K

B37 200603 10K 5% 1/16W

B38 100603 3.3K 5% 1/16W

B39 120603 4.7K 5% 1/16W

B40 10603 68K 5% 1/16W

B41 10603 20K 5% 1/16W

B42 30603 33K 5% 1/16W

B43 10603 1.2K 5% 1/16W

B44 20603 5.1K 5% 1/16W

B45 40603 6.8K 5% 1/16W

B46 210603 33 5% 1/16W

B47 10603 12K 1% 1/16W

mc

dh

15PIN pedestal 2.5mm

PART LIST

25

PART LIST

26

bf

bm1

mcbhBlm

48

dh

10603 12K 5% 1/16W

B49 20603 100K 5% 1/16W

B50 30603 18K 5% 1/16W

B51 140603 0 5% 1/16W

B52 30603 10 5% 1/16W

B53 20603 47K 5% 1/16W

B54 170603 1K 5% 1/16W

B55 40805 1 5% 1/10W

B56 30603 1.5K 5% 1/16W

B57 10603 1M 5% 1/16W

B58 10603 3.3 5% 1/16W

B59 10603 390 5% 1/16W

B60 70603 75 5% 1/16W

B61 10603 100 5% 1/16W

B62 20603 2.2K 5% 1/16W

B63 10603 3K 5% 1/16W

B64 20603 22K 5% 1/16W

B65 10603 180 5% 1/16W

B66 10603 470 5% 1/16W

B67 20603 120 5% 1/16W

B68 20603 200 5% 1/16W

B69 20603 330 5% 1/16W

B70 8spool 0805 101

B71 1spool 0805 3.3uH

B72 2spool 0805 2.4uH

B74 1Inductance 10uH/0.5A P80

B75 1Inductance winding1mH/1A P80

B76 1Inductance winding150uH 6mm 800mA

B77 6diode 1N4148

B78 1diode SB560

B79 1diode SB240

B80 11N5819

B81 1diode 1N4007 brede

B82 1manostant Z3.6V 1/2W brede

B83 2audion A733SOT-223

B84 6audion C945 SOT-223

B85 2audion 3904

B86 2FHK3018

B87 22SB1132QR (SOT89EBC) ROMN SMD

B88 1B772

B89 3AMS1117 outside

B90 1ST7805 TO-220 ST

B91 1PQ1CY1032Z

B92 17809 TO220 ST

B93 1VT6313

PART LIST

27

bf

bm1

mcbhBlm

95

dh

1NJM2246

B96 1CD4052BC SOP16 2 groups 1 in 4

B97 14558 SOP8 ST

B98 1ES6629F

B99 1BA5954FP ROMN

BA1 1TL3472

BA2 1ES6603S

BA3 129F800B TSOP -70

BA4 124C02

BA5 14M*16 SDRAM StarRam

BA6 1WM8761

BA7 1455E

BA8 127M diode 70 degree (low)

BB1 25PIN pedestal 2.0MM

BB2 16PIN pedestal 2.0 right angle

BB3 14PIN pedestal 2.0MM 90 degree

BB4 112Pin pedestal 2.0mm FFC (2.0/2) angle 90 degree

BB6 1HOP-1200 JP24-0.5mm

BB7 1single output (black)

BB8 11*3three colored output (horizontal)

BC1 14Pin power jack 5559-4AW

BC2 1earphone faucet CKX-3.5-07 five stilts

BC3 16287

BD1 1G686 SOT23

EU-EP80P80T-02

Earphone

P80/P80T W/O 4PIN

C01 60805 10K 5% 1/10W

C02 2CD110 10u/25V dia.4mm high 5mm length 7mm

C03 2CD110 47u/16V 5(W)*5(H)mm P80

C04 2CD26C 100u 16V dia.6mm high 5mm length 7mm

C05 1earphone faucet CKX-3.5-07 five stilts

C06 14PIN wiring2.0mm 60mm P80

C07 1LM4808M SOP8

C08 1earphone boardP80/P80T

EU-FP801-03

Front control panel

P80/P80T 18-

P80T114-01

D01 1RT13 100 J brede

D03 1RT13 10K J brede

D04 6Diode1N4148 brede

D05 1color light (blue) 3004UB

D06 1CD110 47u/16V 5(W)*5(H)mm P80

D07 6horizontal touch power6*6*5

D08 15.5MM wire

D09 1receiverPIC-331LM

D10 1front panel P80/P80T 2004-04-15

D11 112Pin spool FCC 1.0mm 110mm P80

EU-FP80F004-01

Front unit

P80/P80T(silver) AKI

E01 1front panel P80 (silver) AKI

E02 1window P80 (silver)

E03 1power button P80

PART LIST

28

bf

bm1

mcbhElm

04

dh

1tray buttonP80

E05 14 keys P80

E06 1IR window P80

E07 1light pole P80

E08 1earphone underlay P80

E09 1screwPTPW3*8-HO-9

F02 8front control panel P80/P80T 18-P80T114-01

F03 1Earphone P80/P80T without 4PIN pedestal

F04 1AV input unit P80/P80T

F05 1Mainboard P80 18-P80T112-01 2004-04-15

F06 1front panel P80/P80T(silver) AKI

F10 1loader(DV34) sanyo

F11 1P80/P80T KZG-D03 39mm loader bracket SANYO DV34

F12 1power cable P80/P80T(1.5m) with DC

F13 1P80/P80T IR SENSOR AND CABLE (1.2M)

F14 1P80/P80T AV cable (1.2m)

F15 1rear P80 AKI (without RF) (electrolytical board)

F16 1cover(silk)P80 RIFA

F17 1base P80 (electrolytical board)

F18 1bracket hook P80 RIFA (silk)

F19 2remote controller P80/P80T B004-24 AKI

F21 124Pin wiring FCC 0.5mm 60mm P80

F22 15PIN linker 2.0mm 200mm P80

F23 15PINlinker 2.0mm 250mm P80

F25 1footstool P80/P80T

F26 4foam top P80/P80T

F27 1foam bottom P80/P80T

F30 1carton box P80/P80T with 5 sets AKI B004-24

F31 1giftbox P80/P80T (neutral)

F33 1screw BT3*7BB-HO round3*7(with higher-rigidity) black

F35 0.200screwBT3*6BB-HNi round3*6(with higher-rigidity)nickel-plate

F36 1screw (TA4*10-HNi) P80/P80T

F37 4screwBT3*6FB-HNi 3*6(with higher-rigidity)nickel-plate

F38 166PIN wiring2.0mm 70mm P80

F39 4plustic bag (90*60open)

F40 2plastic bag (250*95 open)

F41 1all paster (15mm)

F42 2(80MM)

F45 1product serial paster AP001-AP500

F46 1Instruction manual P80/P80T neutral

F50 1Av wire 1.3M

F51 1rear label E4 P80 B004-24

F52 1warranty seal :round

P80

MEMO

29

MEMO

30
