MYSON
heatingthroughinnovation.
PANEL RADIATORS.
TECHNICAL GUIDE
NOVEMBER 2013
1. ULOW-E2 04
l
General Specifications 05
l
Technical Information 06
l
Heat Outputs & Accessories 07
2. FINESSE 08
l
General Specifications 09
l
Technical Information 10
l
Heat Outputs & Technical Characteristics 11
3. PREMIER Compact 12
l
General Specifications 13
l
Technical Information 14
l
Heat Outputs 18
4. PREMIER HE 12
l
General Specifications 13
l
Technical Information 15
l
Heat Outputs 20
5. PREMIER Metric (2 & 4 Tap) 12
l
General Specifications 13
l
Technical Information 16
l
Heat Outputs 22
6. SELECT Compact 12
l
General Specifications 13
l
Technical Information 17
l
Heat Outputs 26
7. LST 28
l
General Specifications 29
l
Technical Information 30
l
Heat Outputs 31
l
Controls 32
8. Heating Controls 33
l
Valves 34
03
Contents
General Specifications
Approval and Certification
All MYSON ULOW-E2 radiators are
manufactured and tested to BS EN 442. Every
radiator carries the BS Kitemark which
certifies independent approval of heat output
and verifies production under a quality system
to BS EN ISO 9001.
All MYSON ULOW-E2 radiators carry a two
year guarantee from date of manufacture
against defects caused by faulty materials or
manufacture.
Paint Finish
Every MYSON ULOW-E2 radiator is primer coated.
An epoxy polyester finishing coat in white (RAL 9016) is applied
to all front and rear surfaces allowing the radiator to be fitted
without further painting
*
.
Packaging
Every MYSON ULOW-E2 radiator is wrapped in paper and has
strong cardboard corners. The front side of the radiator is double
protected with an additional hard cardboard and then wrapped
together in shrink wrap. Each radiator is clearly labelled with size
and type, and packed with the appropriate number of brackets.
An assembly instruction, and instruction manual is also included.
Fixings
All MYSON ULOW-E2 radiators are supplied with concealed
wall mounting brackets. The table of dimensions gives further
details.
For the correct installation of radiators it is essential that the
fixing of the radiator is carried out in such a way that it is suitable
for intended use AND predictable misuse. A number of elements
need to be taken into consideration including the fixing method
used to secure the radiator to the wall, the type and condition of
the wall itself, and any additional potential forces or weights that
may happen to be applied to the radiator, prior to finalising
installation. IN ALL CASES IT IS STRONGLY RECOMMENDED
THAT A SUITABLY QUALIFIED PROFESSIONAL INSTALLER OR
SIMILAR TRADESPERSON CARRIES OUT THE INSTALLATION.
PLEASE NOTE: The fixing materials provided are only intended for installation on
walls made of solid wood, bricks, concrete or on timber-frame stud walls where the
fixing is into the timber. All walls being considered should have no more than a
maximum of 3mm wall finishing. For walls made of other materials, for example
hollow bricks, please consult your installer and/or specialist supplier. ONCE AGAIN,
IF YOU ARE UNSURE, IT IS STRONGLY RECOMMENDED THAT A SUITABLY
QUALIFIED PROFESSIONAL INSTALLER OR SIMILAR TRADESPERSON CARRIES
OUT THE INSTALLATION.
Application
MYSON ULOW-E2 radiators are for use on two pipe pumped
indirect domestic and commercial central heating installations,
with a maximum working temperature of 60
o
C. The system
should be designed in accordance with BS EN 12828:2003 or
BS EN 12831:2003 as appropriate, with particular care taken to
avoid air entry or water discharge.
We do not recommend the use of single feed indirect cylinders,
as the possibility of aeration due to water interchange may lead
to corrosion.
The installation work must be carried out in accordance with
recognised good practice, and precautions taken to avoid
contamination which could lead to corrosion. If a corrosion
inhibitor or other water treatment is to be used, the
Manufacturer’s Instructions must be strictly followed.
The recommendations of BS 7593, Code of Practice for
treatment of water in domestic hot water central heating
systems, should be followed where appropriate.
Safety Precautions
Radiators are hot when in use, and as such, present a risk of
burns to users on prolonged contact. The temperature of a
radiator is dependent on the temperature of the system water,
as set by the system installer or user. Installers and users should
ensure that those who may come into close proximity to hot
radiators are aware of the risk of burns. Installers and users
should take all necessary steps to minimise the risks of burns.
If the risk is significant, consideration should be given to
installing low surface temperature radiators, or to placing guards
in front of the radiators.
Electrical Data
All ULOW-E2 models require an electrical supply of 220-240V50Hz.
BS EN 442
2
2
2
*Specification is correct for white version only.
05
ULOW-E2 General Specifications
ULOW-E2
Length
(mm)
Weight (kg)
Water
Content (l)
No. of Fans Comfort Boost
Power
(W)
Sound Pressure
(dBA) (at 2.5m)
B M8
B M6
A M8
A M6
Sound levels tested in accordance with ISO 3741.
07
ULOW-E2 Heat Outputs & Accessories
The ULOW-E2 comes with a thermostatic radiator valve as standard. The twin entry valve and nut & olive pack should be purchased separately.
Order CodeProduct
Twin Entry Valve (Straight)
Twin Entry Valve (Angled)
Twin Entry Reversible Flow Valve (Straight)
Twin Entry Reversible Flow Valve (Angled)
Nut & Olive Pack (10mm)
Nut & Olive Pack (15mm)
E2TEVS
E2TEVA
E2TERVS
E2TERVA
E2NOP10
E2NOP15
E2TEVS
E2TEVA
E2TERVS E2TERVA
E2NOP10 / E2NOP15
Operating Pressures
Every MYSON ULOW-E2 radiator is tested to a pressure of 10 bar and
is suitable for a working pressure of up to 13 bar.
Maximum operating temperature: 60°C (because of the fan units).
Nominal
Height
600 mm
ULOW-E2 - Type 22
(with factory fitted top grille and side panels)
400
600
800
1000
1200
1400
1600
Nominal
Length
(mm)
Static
Comfort
Boost
Static
Comfort
Boost
Static
Comfort
Boost
Static
Comfort
Boost
Static
Comfort
Boost
Static
Comfort
Boost
Static
Comfort
Boost
Operation
Mode
Heat Outputs
@ ΔT 10°C
Heat Outputs
@ ΔT 20°C
Heat Outputs
@ ΔT 30°C
Heat Outputs
@ ΔT 40°C
Heat Outputs
@ ΔT 50°C
Watts Btu/h Watts Btu/h Watts Btu/h Watts Btu/h Watts Btu/h
Order Code
(White)
*
74 252 184 628 314 1071 459 1566 616 2102
125 427 272 928 430 1467 595 2030 766 2614 ULOW 040
147 502 317 1082 498 1699 686 2341 879 2999
111 379 276 942 471 1607 688 2347 923 3149
188 641 409 1396 647 2208 895 3054 1151 3927 ULOW 060
220 751 475 1621 746 2545 1027 3504 1316 4490
148 505 368 1256 628 2143 917 3129 1231 4200
250 853 545 1860 862 2941 1192 4067 1534 5234 ULOW 080
294 1003 634 2163 996 3398 1371 4678 1757 5995
185 631 460 1570 785 2678 1147 3914 1538 5248
312 1065 681 2324 1077 3675 1490 5084 1917 6541 ULOW 100
367 1252 792 2702 1244 4245 1712 5841 2194 7486
222 757 552 1883 942 3214 1376 4695 1846 6299
374 1276 817 2788 1292 4408 1787 6097 2299 7844 ULOW 120
440 1501 950 3241 1492 5091 2054 7008 2632 8980
259 884 644 2197 1099 3750 1605 5476 2153 7346
436 1488 953 3252 1507 5142 2085 7114 2682 9151 ULOW 140
514 1754 1109 3784 1741 5940 2398 8182 3073 10485
296 1010 736 2511 1256 4285 1834 6258 2461 8397
499 1703 1090 3719 1723 5879 2384 8134 3067 10465 ULOW 160
587 2003 1267 4323 1989 6786 2739 9345 3510 11976
*For the black model, simply add a ‘B’ to the end of the order code.
ULOW-E2
Accessories
Nominal Height
600
(mm)
143143
M6
157.5452.5
M8
B (mm) A (mm) B (mm)A (mm)
600mm Wall Bracket
Dimension Y =
Overall Length
2
09
FINESSE General Specifications
FINESSE
General Specifications
Approval and Certification
MYSON FINESSE electric panel radiators
are produced under a quality system to
BS EN ISO 9001.
MYSON FINESSE electric panel radiators
carry a ten year guarantee from date of
manufacture against defects caused by faulty
materials or manufacture except for the
electrical and electronic components that are
covered by a two year warranty.
Paint Finish
All FINESSE electric panel radiators are de-greased,
phosphated and primer coated. An epoxy polyester finishing
coat in white (RAL 9016) is applied to all front and rear surfaces
allowing the radiator to be fitted without further painting.
Packaging
Every MYSON FINESSE electric panel radiator is packed in
robust cardboard packaging specially designed to ensure that
the product reaches you in perfect condition. Each radiator is
clearly labeled with size and type, and packed with the
appropriate number of brackets.
Fixings
MYSON FINESSE electric panel radiators are supplied with
concealed wall mounting brackets. Please refer to the Bracket
Positions and Dimensions on page 10 for details. For the correct
installation of radiators it is essential that the fixing of the
radiator is carried out in such a way that it is suitable for
intended use AND predictable misuse. A number of elements
need to be taken into consideration including the fixing method
used to secure the radiator to the wall, the type and condition of
the wall itself, and any additional potential forces or weights that
may happen to be applied to the radiator, prior to finalising
installation. IN ALL CASES IT IS STRONGLY RECOMMENDED
THAT A SUITABLY QUALIFIED PROFESSIONAL INSTALLER OR
SIMILAR TRADESPERSON CARRIES OUT THE INSTALLATION.
PLEASE NOTE: The fixing materials provided are only intended for installation on
walls made of solid wood, bricks, concrete or on timber-frame stud walls where the
fixing is into the timber. All walls being considered should have no more than a
maximum of 3mm wall finishing. For walls made of other materials, for example
hollow bricks, please consult your installer and/or specialist supplier. ONCE AGAIN,
IF YOU ARE UNSURE, IT IS STRONGLY RECOMMENDED THAT A SUITABLY
QUALIFIED PROFESSIONAL INSTALLER OR SIMILAR TRADESPERSON CARRIES
OUT THE INSTALLATION.
Accessories
Touch up Paint
A handy 12ml container of touch up paint with
integral brush applicator in RAL 9016 is
available on request.
RF Programmer
The MYSON FINESSE radiator can be used as
a stand alone radiator or can be connected to
a radio frequency programmer via a wireless
wall receiver.
Application
All installation work and wiring work related to the radiators,
thermostats and programmers must be carried out only when
de-energized. The appliance should be commissioned by
qualified professionals only. Make sure to adhere to valid safety
regulations. Any repairs or maintenance within the warranty
period should be carried out only by approved service engineers
confirmed by MYSON.
Safety Precautions
Some parts of this product can become very hot and cause
burns. Particular attention has to be given where children and
vulnerable people are present. Installers and users should take
all necessary steps to minimise the risks of burns. If the risk is
significant, consideration should be given to placing guards in
front of the radiators.
In order to avoid overheating, do not cover the radiator. “Do not
cover” means that the radiator must not be used for drying
clothes, for example, by placing them directly on the radiator.
BS EN 442
2
2
2
11
FINESSE Heat Outputs & Technical Characteristics
FINESSE
l
MYSON FINESSE is class 2 and splash resistant (IP44).
l
MYSON FINESSE complies with the European Directive
2004/108/EC (CE Marking on all appliances).
Length (mm)
Technical Characteristics Optional Extra - RF Programmer
Waste Disposal According to The WEEE Directive (2002/96/EC)
Safety Clip-on Brackets
300 500
135
90
205
163
Nominal
Height (mm)
C
D
C
D
L
Waste disposal according to the WEEE Directive
(2002/96/EC). The symbol on the product label
indicates that the product may not be handled as
domestic waste, but must be sorted separately.
When it reaches the end of its useful life, it shall be
returned to a collection facility for electrical and
electronic products. By returning the product, you will help to
prevent possible negative effects on the environment and health
to which the product can contribute if it is disposed of as ordinary
domestic waste. For information about recycling and collection
facilities, you should contact your local authority/municipality or
refuse collection service or the business from which you
purchased the product. Applicable to countries where this
Directive has been adopted.
Nominal Height
300 mm
FINESSE
Double Panel “Xtra”
500
800
1000
1300
1600
2000
Nominal Length
(mm)
Heat Outputs
(Rated Watts)
Order Code
500 FE 30 DX 50
750 FE 30 DX 80
1000 FE 30 DX 100
1250 FE 30 DX 130
1500 FE 30 DX 160
2000 FE 30 DX 200
Nominal Height
500 mm
400
500
650
800
950
1250
500 FE 50 DX 40
750 FE 50 DX 50
1000 FE 50 DX 65
1250 FE 50 DX 80
1500 FE 50 DX 95
2000 FE 50 DX 125
0.1°C
-10°C + 50°C
+5°C + 30°C
PWM
Class 1 – IP44
230 VAC – 50 Hz
~3.5 W
TRIAC 230 VAC 8A
l
EN 60730-01
l
EN 61000-6-1
l
EN 61000-6-3
l
EN 61000-4-2
l
LV Directive
2006/95/CE
l
EMC Directive
2004/108/CE
Measured temperature precision
Operating temperature
Setting temperature range
Control characteristics
Electrical protection
Power supply
Controls consumption
Output
The thermostat has been
designed to comply with the
following Directives and
Standards.
l
Install and plug the radiator into a switched fuse spur along
with the wireless wall receiver. NB: The RF programmer will
not work without the wireless wall receiver.
l
Install the RF programmer in a suitable location.
l
Connect the wireless wall receiver to the RF programmer
using the manufacturers instructions on both products.
PLEASE REFER TO THE MANUFACTURERS MANUAL FOR
FULL INSTALLATION INSTRUCTIONS.
Switched Fuse Spur*
RF Programmer
Wireless
Wall
Receiver
Wall
.
.
.
.
Wall
500mm Wall Bracket
300mm Wall Bracket
Step 1 Step 2
*When installing in a bathroom or wet room, please refer to the FINESSE
Installation, Operating & Instruction Manual.
Loading...
