Myson KICKSPACE 500, KICKSPACE 600-12V, KICKSPACE 80S, KICKSPACE 800, KICKSPACE 600 Operating Manual

COMPLETE HEATING SOLUTIONS

KICKSPACE®500, 600
600-12V, 800, 80S & 80D

INSTALLATION & OPERATING MANUAL

PLEASE LEAVE THIS MANUAL WITH THE END USER

1.0 Safety Information

For MYSON KICKSPACE®500, 600, 600-12V,
800, 80S & 80D, a fused (3A) electrical spur with
a switch having 3mm separation on all poles must
be provided in an easily accessible position
adjacent to the unit.

For the KICKSPACE®600-12V, a fused electrical
spur having 3mm separation on all poles must be
provided in an easily accessible position adjacent
to the transformer. Both the fused spur and the
transformer must not be positioned in a
bathroom or other similar high humidity area.

If the supply cord to the KICKSPACE®500, 600,
600-12V, 800, 80S & 80D is damaged, it must be
replaced by the manufacturer, its service agent or
similar qualified persons in order to avoid a
hazard. This appliance can be used by children
aged from 8 years and above and persons with
reduced physical or mental capabilities or lack of
experience and knowledge if they have been
given supervision or instruction concerning the
use of the appliance in a safe way and understand
the hazards involved.

Children shall not play with the appliance.
Cleaning and user maintenance shall not be made
by children unless they are older than 8 years and
supervised.

Keep the appliance and its cord out of reach of
children aged less than 8 years.

Children of less than 3 years should be kept
away from the unit unless continuously
supervised.

Children aged from 3 years and less than 8 years
shall only switch on / off the appliance provided
that it has been placed or installed in its normal
operating position and they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the
hazards involved.

Children aged from 3 years and less than 8 years
shall not plug in, clean the appliance or perform
user maintenance.

WARNING: KICKSPACE®500, 600, 800, 80S & 80D models must be earthed.

1.0 Safety Information 02

2.0 Installation 03

3.0 Water Connection 03

4.0 Electrical Connection 04

5.0 Controls 04

6.0 Troubleshooting 04

7.0 Appendix 05

Contents

The KICKSPACE®500, 600, 600-12V, 800, 80S & 80D MUST NOT be installed in a bathroom or
other similar high humidity area.

02

KICKSPACE

®

500, 600, 600-12V, 800, 80S & 80D

KICKSPACE

®

500, 600, 600-12V, 800, 80S & 80D

INSTALLATION & OPERATING MANUAL

01.01.2018

03

KICKSPACE

®

500, 600, 600-12V, 800, 80S & 80D

2.0 Installation

l Before proceeding with the installation, the heating system

design must be considered and the unit correctly sized to
meet the heat loss requirements of the room.

l Before proceeding with the installation, unpack the carton

contents and check against the checklist below:

1. KICKSPACE

®

unit.

2. Flexible hoses including isolating valves (1 pair).

3. Instruction manual.

4. Warranty card.

5. Grille.

6. Screw fixing kit (with grille).

7. Transformer (12V model only).

8. Connector (12V model only).

l This MYSON KICKSPACE

®

fan convector is designed for
installation in the cavity beneath kitchen cupboards on the
vacant floor space, or other similar locations.

l For KICKSPACE

®

500, 600, 600-12V & 800 a minimum of
25mm clear headroom is required above the top of the
KICKSPACE

®

when fitted.

l The unit should be mounted on a clean and level floor area

under the cupboard base.

l KICKSPACE

®

80S & 80D models can only be installed if there
is a minimum height of 80mm from the top of the floor
covering to the underside of the kitchen unit (see Fig. 1).

l KICKSPACE

®

500, 600, 600-12V & 500 floor mounting (see

Fig. 2a) - The KICKSPACE

®

is normally fitted directly onto the

floor and the base of the unit is fitted with four mounting feet.

l KICKSPACE

®

500, 600, 600-12V & 500 plinth mounting

(see Fig. 2b) -

• As an alternative to floor mounting the unit may be fitted
into the plinth.

• A suitable support must be securely fitted to the floor.

• The top of the support must be level with the lower edge of
the cut-out when fitted.

l KICKSPACE

®

80S & 80D floor mountings (see fig. 2c) - Applies

to 80S & 80D units in 80mm plinth height kitchen unit.

l Decide the position of the KICKSPACE

®

, mark out and cut the

plinth to the dimensions using table on page 6.

l Position the KICKSPACE

®

under the cupboard in the required

location, with the front edge just behind the line of the plinth.

l Replace the plinth and bring the KICKSPACE

®

forward into
the opening so the front edge projects approximately 10mm
through the plinth.

l Align the grille and secure it to the unit with two screws

supplied (use the shorter screws). (See Fig. 3).

l Secure the unit/grille to the plinth with two screws supplied

(use the longer screws). (See Fig. 3).

l Complete the electrical installation, switch on and test the

KICKSPACE

®

(see Fig. 3).

l When installed in a kitchen consideration should be given to

storage of perishable goods in the cupboard above.

3.0 Water Connection

l The KICKSPACE®should only be used on closed circulation,

two pipe, pump assisted central heating systems.

l For optimum fan convector heating performance the system

must be capable of providing sufficient hot water through the
heat exchanger. This means that:

1. The minimum pipe size from boiler to fan convector must
be at least 15mm. Microbore pipe MUST NOT be used.

2. Where the unit is fitted on to a system with other emitters
a separate circuit for the fan convector should be
considered to provide adequate water flow.

3. The system water temperature on the return of the
KICKSPACE

®

must be above 43°C for the fan to switch on.

4. This unit is NOT suitable for one-pipe systems.

5. Optimum performance will require effective balancing of

the whole system.

6. This unit must not be used to replace a radiator in an
existing system unless an adequate flow of water can be
guaranteed.

l Connect valve ends of the flexible pipes to the KICKSPACE

®

.

Note: The direction of the arrows on the valves are not
significant in this application (see Fig. 4).

l Open valves fully, check pipe connections for leaks and vent

the heat exchanger. A vent screw is provided to vent the heat
exchanger.

Pipework must be positioned correctly to ensure
flexible hoses are not kinked when installed
(see Figs. 5a & 5b). Only use the hose sets
supplied with this unit. Do not use old or
alternative hose sets.
