Manifold Specification
FLOORTEC Underfloor Heating
Dimensions
Application
The MYSON FLOORTEC manifold provides water to an
underfloor heating system of up to 12 loops.
Functions
The manifold provides a quick and simple installation. The unit
consists of a stainless steel manifold complete with all of the
fittings. The manifold has been designed to connect directly onto
a MYSON FLOORTEC manifold control centre without the need
for extra brackets or support.
General Information
1 x Manifold
1 x Auto Air Vent
1 x Pressure Gauge
1 x Pr Isolating Valves
Manifold Adaptors
Seals
Technical Data
MYSON FLOORTEC manifolds are available from a 2 port up to
a 12 port.
All dimensions in mm unless otherwise stated.
Number of Ports 2 3 4 5 6 7 8 9 10 11 12
Length (mm)
350 380 415 470 525 580 635 690 745 800 855
Manifold Dimensions
