MyQ Smart Garage Quick Start Manual

SMART

™

GARAGE

Hub

Quick Start Guide

by

821LMB

To reduce the risk of SEVERE INJURY to persons:

• DO NOT enable the MyQ® Smart Garage™ Hub if operating either one-piece or
swinging doors. To be enabled ONLY on a sectional door.

WARNING: This product can expose you to chemicals including lead, which
are known to the State of California to cause cancer or birth defects or other
reproductive harm. For more information go to www.P65Warnings.ca.gov

Read instructions thoroughly BEFORE beginning.

If using this product with residential door openers, this product must
be used only with door openers manufactured after 1993 that utilize
photoelectric sensors. The photoelectric sensors are always located on
or near the bottom of the door track.

BEFORE YOU START, YOU MUST HAVE…

A router with

2.4GHz Wi-Fi

Mobile device connected to

®

your home Wi-Fi network

Compatible garage

door opener

To see a list of compatible garage door openers go to:

www.LiftMaster.com/MyQCompatibility

WHAT’S IN THE BOX

Mounting bracket

Hardware for Wi-Fi Hub

(5/32" x 1-1/2" screws)

Hardware for

Door Sensor

(5/32" x 3/4" screws)

Fastening Strips for

Door Sensor

Wi-Fi Hub

Blue LED

Green LED

Yellow LED

Power Adapter

NOTE: Additional door sensors sold separately.

Tools Needed: Drill, 5/32" Drill Bit, Screwdriver, Ladder

Door Sensor

Red
LED

Test

Button

Warning Label

(not shown)

FOR SECURITY SYSTEM OR HOME AUTOMATION SETUP

MyQ® Smart Garage™ Hub works with a variety of home security and home
automation apps.

Visit: www.LiftMaster.com/WorkswithMyQ for more details.

INSTALL

1. Check your Wi-Fi

• Check the Wi-Fi signal in the garage, where the Wi-Fi Hub will be mounted.

• Make sure you have two or more Wi-Fi bars.

NOTE: If there are signal strength issues, please visit

https://www.liftmaster.com/wifi supportvideos for instructional videos.

(mounting area)

INSTALL

2. Install the Door Sensor

• Remove the pull tab from the sensor to
activate the battery.

• Install the door sensor on the top panel
of the garage door using the fastening
strips or provided hardware.

TIP: Test your door sensor every 6 months or
if the MyQ system is not working as expected.

• Press the test BUTTON on the door
sensor, the LED on the door sensor should
fl ash and the Wi-Fi Hub should beep.

• Perform this test 6 times. If the LED
doesn’t fl ash or the Wi-Fi Hub doesn’t
beep each time, replace the battery in the
door sensor with a CR2450 battery.

LED

Test
BUTTON

Door Sensor

“TOP” MUST

always face UP

OR

Screws

CR2450 Battery

Fastening
Strips

INSTALL

3. Power Up the Wi-Fi Hub

• Find a convenient location in the
garage and power the Wi-Fi Hub
by plugging it in. The blue LED
will start blinking.

Blue LED blinks

4. LiftMaster MyQ® app

• Download the LiftMaster
MyQ® app or open the app if
it is already installed.

• Create or sign-in to your
account and follow the
in-app instructions.

Download

App

5. Install the Wi-Fi Hub

• After successfully completing all of the steps in the LiftMaster MyQ® app, install
the Wi-Fi Hub on the ceiling, near the garage door opener.

• Plug it in and make sure the green LED turns on solid.

• Wi-Fi Hub light MUST be visible if you’re standing in the doorway of the garage.

Wi-Fi Hub

TIP: Wrap excess power

Door Control

Warning
Label

adapter cable around the
mounting bracket.

6. Apply Warning Label

• Attach the warning label to the wall next to the door control.

Go to: www.LiftMaster.com/MyQSupport

One Year Limited Warranty

Need Help?

LiftMaster® warrants to the fi rst consumer purchaser of this product that it is free from defect

in materials and/or workmanship for a period of 1 year from the date of purchase.

Software Agreement

Use of this product and the software embedded within the product is

subject to the copyright notices, terms, and conditions available at:

NOTICE: This device complies with Part 15 of the FCC rules and Industry Canada’s license-exempt RSSs.
Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired operation.

Any changes or modifi cations not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.

This device must be installed to ensure a minimum 20 cm (8 in.) distance is maintained between users/
bystanders and device.

This device has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC rules and Industry Canada ICES standard. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

http://www.myLiftMaster.com/agreement

Wi-Fi® is a registered trademark of Wi-Fi Alliance.
