FCC Compliance Statement…………………..…………. 3
Canada Compliance Statement………………………….. 3
Specifications………………………………………….… 3
Receiver Orientation (Front / Rear)…………………… 4
Keypad – Key Identification………………………….… 5
Main Features…………………………………………… 5
Display and Icon Identification…………….…………… 6
Programming - Near / Far Reception Setting…………… 6
Programming the Receiver (Auto Programming)………. 7
Programming the Receiver (Manual) ………………… 7
FM Radio, FM Radio Disable…………………………..… 8
Attaching the Receiver……………………..…………... … 9
Intellijack…………………….……………………………. 11
Warranty Information…………..…………..….……..…… 12
CONTENTS
2
![](/html/aa/aaaa/aaaab8996bedfaa436771d18e1e5457bac4319d9c42012d236c1e762c0e2a071/bg3.png)
FCC Compliance Statement
NOTE: This equipment has been tested and found to comply with the limits for a class B digital devise
pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a residential environment. This equipment generates, uses and can radiate
radio frequency energy and if not installed and used in accordance with the instruction manual may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the unit off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiver.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet different from that which the receiver is connected.
• Consult your MYE dealer or experienced Radio / TV technician
Canada Compliance Statement
INDUSTRY CANADA COMPLIANCE STATEMENT
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Product Description
The MYE MWC2-9 Receiver allows the user to listen to a TV or other audio source connected to a compatible
900MHz transmitter. It can also be used as an FM radio receiver. The MWC2-9 is powered by using a MYE
Entertainment CSAFE cable plugged directly into any standard cardio CSAFE port or MYE 9 Volt AC Adapter.
SPECIFICATIONS
900 MHz Frequency Range 903.000 TO 926.0000 MHz
FM Frequency Range
Input Sensitivity (20 dB SINAD) -85 dBm typical
Modulation FM Stereo deviation +/- 75KHz
Stereo Separation >25dB
Equalization Bass Boost, Flat
Audio Frequency Response 20 Hz to 18 kHz
Frequency Entry Scroll up/down.
Power 4.75 VDC TO +12VDC
87.5 to 107.9 MHz
3
![](/html/aa/aaaa/aaaab8996bedfaa436771d18e1e5457bac4319d9c42012d236c1e762c0e2a071/bg4.png)
FRONT FLANGE
FRONT MOUNTING
SCREWS
CABLE BLOCKS
CABLE EXIT HOLES
KEYPAD
CABLE EXIT HOLES
RECEIVER ASSEMBLY - FRONT VIEW
RECEIVER ASSEMBLY & MOUNTING - REAR VIEW
BAR CODE SERIAL NUMBER
AND RATING LABEL
CSAFE CABLE RJ45 JACK
MOUNTING BASE
LCD DISPLAY
FRONT MOUNTING SCREWS
UNSCREW TO RELEASE the
MOUNTING BASE ASSEMBLY.
(PLEASE READ “ATTACHING
THE RECEIVER” PGS. 8/9)
HEADPHONE JACK
REAR FLANGE
