MINIWIRE Manual 3:1 Pitch
Wire Binding Machine
Instruction Manual
MINIWIRE
Punching Capacity
Warranty
Adjustable
Adjustable
15" x 10.5" x 5"
14 lbs & 0.41 CbFt
2 Years
Specifications
10 sheets (20 lb paper) or
2 sheets of plastic covers
3/16" to 9/16"
32 Holes
Letter
3:1
Binding Size
Pitch
Number of Holes
Format
Depth Margin
Side Margin Guide
Machine Dimensions
Weight & Volume
WARRANTY POLICY
YOUR HAS A WARRANTY OF 2 YEARS FROM
DATE OF PURCHASE. IN THE EVENT OF A MANUFACTURER’S DEFECT, MY BINDING WILL REPAIR OR REPLACE IT.
IMPORTANT: THIS WARRANTY DOES NOT COVER DAMAGES DUE TO IMPROPER USE OR MISTREATMENT OF THE
UNIT, INCLUDING EXTRAORDINARY EVENT LEADING TO
THE DAMAGE OF THE MACHINE, WHETHER IT IS REVERSIBLE OR NOT.
Wire Binding Machine
OPERATIONAL MANUAL
1-800-944-4573
FEATURES
Wire Holder
Wire Closer
Punch Handle
Wire Closer
Control
Entrance
Paper
PUNCHING
1. Use Depth Margin Guide to set the preferred punching margin.
2. Move the Side Margin Guide to center the holes on your documents.
3. Insert the documents (10 sheets of 20lb paper max) and press down on
the Punch Handle to punch holes, then release back to original position.
Repeat Step 3 as needed.
1
2
3
Depth
Margin
Guide
Side Margin Guide
ASSEMBLY
1) Place your on top of a sturdy table.
2) Install Punch Handle and tighten screw.
Waste Drawer
(below machine)
BINDING
4. Place the wire on the Wire Holder with the opening facing upward (not
shown).
5. Insert punched documents into the wire.
6. Rotate the Wire Closer Control to the correct wire size.
7. Place the inserted documents in the Wire Closer with the wire opening
facing down. Press down on the handle and release back to original
position. Remove document from the Wire Closer. You now have a wire
bound book.
5
6 7
